HULALA HOME SBBSD0388 User manual

NOTE:
ITEM NO. SBBSD0388
This brochure contains IMPORTANT safty info. Please read and keep for
future reference.
1/16

MAINTAINANCE
AND WARNING
Keep furniture away from heat.
Do not clean furniture with harsh cleansers
or polish. Do not use detergents, Solvents,
abrasives, spray packs or leather cleaner. Use
non-color mild soap with warm water clean
spills(Mix 1:10 soap to water)
Do not place furniture under direct sunlight,
material will possibly fade over time.
Do not use on site dry Cleaning machine.
Children should not climb or jump on the
furniture.
Do not write on furniture without a padded
barrier to protect the surface.
Not for commercial use, For residential use
only.
Weight Limitation
80LBS
2/16

PARTS
LIST
3/16

Explosive View
4/16

HARDWARE
LIST
Be sure to check all packing material carefully for
small parts, which may have come loose inside the
carton during shipment.
5/16
SPARE

6/16
ASSEMBLY
INSTRUCTIONS
Preparing the panel 1.
1.Align the hole in the panel 1, screw in and tighten the cam bolt A by
screwdriver.
2.Insert the wooden dowel D into the predrilled hole in panel by hand.
Attach the metal drawer slider.
1. Separate the metal drawer slider as the picture show. Then you will get
female metal slider I and male metal slider J.
2. Align the hole in the female slider I and the hole in the panel 5 and 6,
screw in and tighten the screw E by screwdriver.

7/16
Attach the panel 3,4,5,6 to the panel 1. Align the holes in panel
3,4,5,6, insert the cam bolt A and wooden dowel D, put in nut B and
tighten by screwdriver. At last covered by part O.
Insert the panel 8 and 9 to the finished frame in step 3.
1.Slider the panel 8 into the grooves in panel 3,5 and 4,6.
2.Repeat the same way to finish panel 9 into the groove in
panel 5,6 as the picture show. Make sure it also into
groove in panel 1!

8/16
Preparing the leg frame.
Align the holes in part 18 and the holes in part 17, insert and tighten the
screw N by Allenkey P.
Screw in the adjustable nail part Q into the hole in the
part 17 as the picture show.
Connect the panel 2 to the finished part in step 4.
Align the holes in panel 3,4,5,6, insert and tighten
the screw C by Allenkey P as the picture show.

9/16
Attach the leg frame to the cabinet. Align the holes in the leg frame to the
holes in panel 2, insert the screw N
and tighten by Allenkey P as the
picture show.
Insert the part F into the panel 8 and panel 9, screw in and tighten the
screw E by screwdriver.
Attach the hardware R at the back of panel 1 . Align the hole
in the part R, screw in and tighten by screwdriver as
the picture show.

10/16
Preparing the drawer frame.
1.Align the holes in the panel 12, screw in and tighten the cam bolt A by
screwdriver.
2.Align the hole in the part L to the holes in panel 12, insert the screw M
and tighten by screwdriver.
3.Align the hole in the panel 15 to the holes in panel 13 and 14, insert and
tighten the screw H by screwdriver.
Assemble drawer.
1.Slide in the panel 16 into the groove on the panel 13 , 14 and 15.
2.Align the hole in the panel 13 and 14, insert the cam bolt A and put the
nut B in , then tighten by screwdriver
3.Cover the hole by part O.
