Model # HOLT52XDB12
THD.com # 1002 462 630
HUSKY 52 IN. ADJUSTABLE HEIGHT WORK TABLE
We appreciate the trust and confidence you have placed in Husky through the purchase of this work table. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Husky!
SKU # 1002 942 124

Table of Contents
Table of Contents ......................................................
Safety Information
........................................................
Warranty ........................................................................
Pre-Assembly .......................................................
Assembly ...............................................................
Operation ................................................................
Safety Information
DANGER: Do not stand on this product. You
may fall or cause the product to tip.
WARNING: Keep the product on a level
surface. The product may become unstable and
tip if not properly leveled.
CAUTION: Do not lift this product directly
with a forklift or tow with any mechanical
devices.
CAUTION: Do not exceed the maximum weight
loading capacity of 300 lbs.
Care and Cleaning
...................................................
Service Parts ....................................................................
Tools Required ..............................................................
Hardware Included
.......................................................
Specifications ................................................................
Package Contents ................................................
2
DANGER: Is used to indicate a hazardous situation which,
if not avoided, will result in serious injury or death.
CAUTION:
if not avoided, may result in minor injury, moderate injury,
Is used to indicate a hazardous situation which,
or property damage.
WARNING:
Indicates a hazardous situation which, if not
avoided, could result in serious injury or death.
CAUTION:Read and follow all Safety Rules and Operating
Instructions before first use of this product.
WARNING:
Due to the product’s weight, it is recommended
that 2 or more people help assemble and move this
workbench to help reduce the risk of injury.
CAUTION:Check screws and bolts periodically for tightness.
2
2
3
4
4
4
5
4
6
8
8
9

Warranty
3
The manufacturer warrants the product to be free from defects in materials and workmanship for a period of three years from date of(3)
purchase. This warranty applies only to the original consumer and only to products used in normal use and service. If this product is
found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the
manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modifications, alteration
neglect or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, set up, or used in
any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product
as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material or
workmanship. This warranty shall not apply to the finish on any portion of the products such as surface and/or weathering, as this is
considered normal wear and tear.
The manufacturer does not warrant and specifically disclaims any warranty, whether express or implied, of fitness for a particular purpose,
other than the warranty contained herein. The manufacturer specifically disclaims any liability and shall not be liable for any consequential
or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product.
Contact the Customer Service Team at 1-888-HD-HUSKY or visit www.huskytools.com.
HUSKYTOOLS.COM
Please contact 1-888-HD-HUSKY for further assistance.

Pre-Assembly
TOOLS REQUIRED
Safety
goggles
HARDWARE INCLUDED
SPECIFICATIONS
BB
AA
Bolt M8 x 15L
4
Screw M6 x 15L
26
AA BB
Maximum capacity 300 lbs
4
NOTE:
NOTE:
Part Description Quantity
Phillips
10 mm
Wrench
CC
CC Washer M8 4
Hardware not shown to actual size.
Begin product assembly close to the final
intended location of your workbench. This product
is heavy and may be difficult to move after assembly.
13 mm
Wrench
dd
DD
DD 5/8 in. Wrench 1
screwdriver

5
Pre-Assembly (continued)
PACKAGE CONTENTS
HUSKYTOOLS.COM
Please contact 1-888-HD-HUSKY for further assistance.
Part Description Quantity
A Wood top 1
B Leg (Right) 1
C Crank handle 1
D Leveling feet 4
E Leg (Left) 1
F Top rail 1
G Rotating rod 1
H Support rail 1
I Caster 4
G
F
E
H
A
B
I
C
D
or

Assembly
6
6
While unpacking the unit, you can leave the workbench wood top (A)
1.
inside the original packaging to prevent the top from being
scratched during assembly.
Determine the front and back of the top before starting. The front of
2.
the wood top (A) has the Husky badge on the edge.
Attach the right leg (B) to the wood top (A) as shown using four
3.
M6x15L screws (AA). Be sure that the rotating mechanism faces the
Attach the rotating rod (G) to the rotating mechanism in the leg (B).
4.
Option 1: Attach the support rail (H) to the bottom of the leg (B) and leg
7a.
Attach the top rail (F) to the wood top (A), leg (B), and leg (E) using
6.
eighteen M6x15L screws (AA). Do not overtighten the screws.
Note: Do not overtighten the screws into the wood top to avoid
damaging the wood top.
(E) using four M8x15L bolts (BB) and four M8 washers (CC). Finger
inside of the work table.
Attach the left leg (E) to the wood top (A) using four M6x15L screws
5.
(AA). Finger tighten only. Be sure that the rotating rod (G) clicks into
the leg (E).
Note: Do not turn the rotating rod yet to ensure that the leg remains
at its lowest level.
tighten only. The support rail can attach in the middle or rear of the
legs. Attach it at your desired position. See step 7b for Option 2.
Front
AA
E
G
A
AA
E
B
F
B
H
E
BB
CC
Front
G
B
A
Front
AA
A
B

Assembly (continued)
7
10.
8.
9.
Square the workbench and then securely tighten all fasteners with a
Screw the four leveling feet (D) or casters (I) all the way into the leg
assemblies to the maximum depth. Some adjustment may be
Using two or more people, stand the workbench in its upright
necessary after the workbench is in the desired location to properly
position.
level and use the product.
10 mm and 13 mm wrench.
Note: Use caution to not overtighten.
11. Install the crank handle (C) into the shaft in the corner below the
Or
Caster installation
Leveling feet installation
wood top as shown.
Option 2: Attach the support rail (H) to the bottom of the leg (B) and
7b.
leg (E) using four M8x15L bolts (BB) and four M8 washers (CC).
Finger tighten only.
Note: Use caution to not overtighten.
Note: Leveling feet have been pre-assembled on the leg.
B
E
I
B
E
BB CC
H
D
C
B
E

Operation
Height Adjustment
HUSKYTOOLS.COM
Leveling Foot Adjustment
IMPORTANT : Ensure there is no weight on top of the
workbench when leveling.
8

1
2
□ Adjust each leveling foot (D) to the desired elevation with
□ Turn the lock nut counterclockwise to elevate and clockwise
a 5/8 in. wrench as shown.
to lower the leveling foot.
□
□
□
The steel in this product has been coated with industrial powder
harsh chemicals such as oil or grease to remain on the powder
®
coating surface. Use a glass cleaner ( Windex or equivalent product)
□
The wood top is made of Parawood (also called Rubberwood), which
®
cleaned with most gentle household cleaners, such as Windex .
Insert the crank handle (C) into the shaft and align it in the hole
until it is engaged.
To raise the table, turn the crank handle counterclockwise to
the desired height.
To lower the table, turn the crank handle clockwise until it
reaches the desired height.
To avoid damage, do not keep turning the crank handle once
□
□
□
Do not allow chemicals, water, or other substances to remain on the
to the wood.
Note: Some minor squeaking is normal when operating the
crank. Lubrication is not needed.
Maintenance
Please contact 1-888-HD-HUSKY for further assistance.
it has rested at its highest or lowest position.
Care and Cleaning
Maintaining the casters
□ Grease the casters annually using high quality
bearing grease.

1coating for a durable finish. To help protect this finish, do not allow
to clean and maintain all powder coated surfaces.
has a polyurethane coating to help protect it from moisture. It can be
wood top for extended periods of time to reduce the risk of damage
C

9
HUSKYTOOLS.COM
Please contact 1-888-HD-HUSKY for further assistance.
Service Parts
G
F
E
H
A
B
I
C
D
or
Part Description Quantity
A Wood top 1
B Leg (Right) 1
C Crank handle 1
D Leveling feet 4
E Leg (Left) 1
F Top rail 1
G Rotating rod 1
H Support rail 1
I Caster 4
