Hy-Brid Lifts HB-1230 Use and care manual

BY CUSTOM EQUIPMENT LLC
OPERATIONS & SAFETY MANUAL
SELF-PROPELLED AERIAL WORK PLATFORM
SUPO-645
REV A
HB-1230
SERIES I

NOTES
Original instructions are written in English.
The purpose of this Operations and Safety manual is to provide users with the instructions and operating procedures
essential to properly and safely operate the Custom Equipment Hy-Brid Lift for its intended purpose, and to position
personnel and their necessary tools and materials.
THE OPERATION AND SAFETY MANUAL MUST BE
READ AND UNDERSTOOD PRIOR TO OPERATING THE MACHINE.
• The user/operator should not accept operating responsibility until the manual has been read and understood as well
as having operated the lift under supervision of an experienced and qualified operator.
• Because the manufacturer has no direct control over machine application and operation, proper safety practices are
the responsibility of the user and all operating personnel.
ANY MODIFICATION ON THIS MACHINE WITHOUT THE EXPRESS WRITTEN CONSENT OF THE
MANUFACTURER IS PROHIBITED.
Fall protection notice:
The guardrail system around the perimeter of the platform is the fall protection system for self-propelled elevating
work platforms per the ANSI/SIA A92.6 Standard. It is prohibited to use an Aerial Work Platform manufactured
by Custom Equipment, LLC. With any portion—or all—of the guardrails removed. Lanyard anchorage points on
this type of equipment are not required to conform to the applicable standard. However, if anchorage points for
lanyard attachments are required by site authorities or other regulations, the anchorage points on all equipment
manufactured by Custom Equipment, LLC. Are recommended to be used for work positioning restraints of
personnel only. Lanyard lengths are to be determined by operator/owner to restrict the operator to the confines
within the guardrail system.
USE OF FALL ARREST SYSTEMS ATTACHED TO ANCHORAGE POINTS
ON EQUIPMENT MAY CAUSE MACHINE TO TIP, RESULTING IN SERIOUS INJURY OR DEATH.
Lanyard
Attachment
Point
DANGER
WARNING
WARNING
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
2
If there is a question about application
and/or operation, contact:
Custom Equipment, LLC
2647 Hwy 175
Richfield, WI 53076
U.S.A.
P: [phone]
F: [phone]
www.hybridlifts.com

FOREWORD
Original instructions are written in English.
The purpose of this Operations and Safety manual is to provide users with the instructions and operating procedures
essential to properly and safely operate the Custom Equipment Hy-Brid Lift for its intended purpose, and to position
personnel and their necessary tools and materials.
THE OPERATION AND SAFETY MANUAL MUST BE
READ AND UNDERSTOOD PRIOR TO OPERATING THE MACHINE.
• The user/operator should not accept operating responsibility until the manual has been read and understood as well
as having operated the lift under supervision of an experienced and qualified operator.
• Because the manufacturer has no direct control over machine application and operation, proper safety practices are
the responsibility of the user and all operating personnel.
ANY MODIFICATION ON THIS MACHINE WITHOUT THE EXPRESS WRITTEN CONSENT OF THE
MANUFACTURER IS PROHIBITED.
Fall protection notice:
The guardrail system around the perimeter of the platform is the fall protection system for self-propelled elevating
work platforms per the ANSI/SIA A92.6 Standard. It is prohibited to use an Aerial Work Platform manufactured
by Custom Equipment, LLC. With any portion—or all—of the guardrails removed. Lanyard anchorage points on
this type of equipment are not required to conform to the applicable standard. However, if anchorage points for
lanyard attachments are required by site authorities or other regulations, the anchorage points on all equipment
manufactured by Custom Equipment, LLC. Are recommended to be used for work positioning restraints of
personnel only. Lanyard lengths are to be determined by operator/owner to restrict the operator to the confines
within the guardrail system.
USE OF FALL ARREST SYSTEMS ATTACHED TO ANCHORAGE POINTS
ON EQUIPMENT MAY CAUSE MACHINE TO TIP, RESULTING IN SERIOUS INJURY OR DEATH.
Lanyard
Attachment
Point
DANGER
WARNING
WARNING
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
B Y C U S TO M EQUIPME NT LLC
3

TABLE OF CONTENTS
NOTES.......................................................................................................................................................................................... 2
FOREWORD ................................................................................................................................................................................ 3
TABLE OF CONTENTS............................................................................................................................................................... 4
INDEX OF FIGURES.................................................................................................................................................................... 5
SECTION 1 | PRODUCT DESCRIPTION.................................................................................................................................. 6
1.1 | GENERAL......................................................................................................................................................................................... 6
1.2 | MACHINE SPECIFICATIONS ...................................................................................................................................................... 7
SECTION 2 | SAFETY ................................................................................................................................................................. 9
2.1 | SAFETY SYMBOLS ......................................................................................................................................................................... 9
2.2 | GENERAL RULES AND PRECAUTIONS................................................................................................................................... 9
2.3 | SAFETY FEATURES...................................................................................................................................................................... 10
2.4 | SAFETY INDICATORS & INTERLOCKS................................................................................................................................... 10
2.5 | SAFETY CONTROLS....................................................................................................................................................................11
2.6 | MAINTENANCE LOCK............................................................................................................................................................... 12
2.7 | SAFETY GUIDELINES.................................................................................................................................................................. 13
SECTION 3 | DECALS............................................................................................................................................................... 14
3.1 | DECAL LOCATIONS ................................................................................................................................................................... 14
3.2 | DECAL DESCRIPTIONS............................................................................................................................................................. 15
3.3 | DECAL SYMBOLS........................................................................................................................................................................ 16
SECTION 4 | TRANSPORT, HANDLING & STORAGE.......................................................................................................... 19
4.1 | PRELIMINARY UNPACKING INSTRUCTIONS AND DEALER INSPECTION .................................................................. 19
4.2 | STORAGE...................................................................................................................................................................................... 19
4.3 | PREPARATION FOR TRANSPORT .......................................................................................................................................... 19
4.4 | LIFTING AND TIEDOWN POINTS.........................................................................................................................................20
4.5 | FORK LIFT POCKETS .................................................................................................................................................................20
SECTION 5 | OPERATION ....................................................................................................................................................... 21
5.1 | BEFORE YOU OPERATE ............................................................................................................................................................ 21
5.2 | STARTUP/SHUT DOWN............................................................................................................................................................22
5.3 | DRIVING AND STEERING.........................................................................................................................................................22
5.4 | ELEVATING AND LOWERING..................................................................................................................................................23
5.5 | EXTENDING THE PLATFORM..................................................................................................................................................23
5.6 | DAILY MAINTENANCE...............................................................................................................................................................23
5.7 | CHARGING THE BATTERY .......................................................................................................................................................24
5.8 | BATTERY DISPLAYS ....................................................................................................................................................................25
SECTION 6 | PRESTART INSPECTION ................................................................................................................................26
6.1 | PRESTART INSPECTION CHECKLIST...................................................................................................................................26
SECTION 7 | ADDITIONAL RESOURCES .............................................................................................................................. 27
7.1 | GENERAL LIFT INFORMATION ................................................................................................................................................ 27
7.2 | TECHNICAL REFERENCES ....................................................................................................................................................... 27
7.3 | PARTS DIAGRAMS....................................................................................................................................................................... 27
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
4

INDEX OF FIGURES
FIGURE 1: Pothole Guards .................................................................................................................................................................... 10
FIGURE 2: Emergency Lowering Valve...............................................................................................................................................11
FIGURE 3: Emergency Down Instruction .........................................................................................................................................11
FIGURE 4: Maintenance Lock Use ..................................................................................................................................................... 12
FIGURE 5: Maintenance Lock Storage............................................................................................................................................... 12
FIGURE 6: Decal Locations .................................................................................................................................................................. 14
FIGURE 7: Brake Release....................................................................................................................................................................... 19
FIGURE 8: Caster Lock .......................................................................................................................................................................... 19
FIGURE 9: Lift/Tie-Down Points, Front..............................................................................................................................................20
FIGURE 10: Lift/Tie Down Points, Rear..............................................................................................................................................20
FIGURE 11: Center of Gravity ...............................................................................................................................................................20
FIGURE 12: Base Controls..................................................................................................................................................................... 21
FIGURE 13: Platform Controls.............................................................................................................................................................. 21
FIGURE 14: Slide Lock Handle .............................................................................................................................................................23
FIGURE 15: Battery Charger LED Display..........................................................................................................................................25
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
B Y C U S TO M EQUIPME NT LLC
5

SECTION 1 | PRODUCT DESCRIPTION
1.1 | GENERAL
Custom Equipment’s Hy-Brid Lifts are aerial work platforms designed to be safe and reliable. The purpose of the
machine is to elevate personnel, along with their necessary tools and materials to overhead work locations.
Manufacturer approval is required for any use other than the intended use.
Before operation, the operator must read and understand the manufacturer’s operating instructions and user’s safety
rules, or have them explained, understand all labels, warnings, and instructions displayed on the aerial platform or
have them explained, ensure that all occupant of the aerial platform wear appropriate protective equipment for the
conditions, including the environment in which the aerial platform will be operated.
The operator must inspect the workplace for environmental hazards such as, but not limited to drop-os, holes,
slopes, debris, floor or overhead obstructions, surface, wind and weather conditions, or presence of unauthorized
persons. Vibration does not create significant hazards on this machine.
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
6

1.2 | MACHINE SPECIFICATIONS
HB-1230
Working Height (maximum) 18 ft 5.49 m
Platform Height (maximum) 12 ft 3.66 m
Stowed Height 63.7 in 1.62 m
Ground Clearance (Pothole Guard Stowed) 3.25 in 8.2 cm
Ground Clearance (Pothole Guard Engaged) 0.375 in 0.95 cm
Overall Width 30 in 0.76 m
Overall Length 55.75 in 1.42 m
Platform (Retracted, Inside) 25 in x 53 in 0.64 m x 1.35 m
Slide-Out Deck Length 28.75 in 0.73 m
Guard Rail Height 43.3 in 1.1 m
Platform Entrance 20 in 0.51 m
Step Height N/A N/A
Wheel Base 46 in 1.17 m
Wheel Track 20 in 0.51 m
Turning Radius (Inside) Zero
Tire Size (Solid, Non-Marking) - Front / Rear 8 in / 12 in 20.3 cm / 30.5 cm
RATED LOAD
Lift Capacity (Evenly Distributed): 500lb / 2 Persons 226.8 kg / 2 Persons
Slide-Out Deck Capacity 250 lb / 1 Person 113.4 kg / 1 Person
Horizontal/Manual Force 100 lb 447 N
FLOOR LOADING
Machine Weight (Unloaded) (Approx.) 1670 lb 758 kg
Minimum Wheel Load-Contact Pressure 83.7 psi 577.2 kPa
Maximum Wheel Load-Contact Pressure 136.8 psi 973.4 kPa
Minimum Machine Loading-Floor Pressure 145.7 psf 6.98 kPa
Maximum Machine Loading-Floor Pressure 189.4 psf 9.08 kPa
ENVIRONMENTAL LIMITATIONS
Wind No Windy Conditions/Indoor Use Only
Rated Slope Level Surface
Tilt Sensor Activated 2° Longidudinal/1.5° Lateral
Gradeability (Stowed Position) 25% ( 14° Unloaded); 20% ( 11° Loaded)
Temperature -4°F to 104°F -20°C to 40°C
Vibration 8.2 ft/s2max 2.5 m/s2max
Sound - Normal Use, Alarms 86 dB, 100 dB 86 dB, 100 dB
SECTION 1 | PRODUCT DESCRIPTION
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
B Y C U S TO M EQUIPME NT LLC
7

SECTION 1 | PRODUCT DESCRIPTION
POWER SYSTEMS - Drive System (Proportional Electric):
Drive Speed (Platform Elevated) 0-0.5 mph 0-.22 m/s
Drive Speed (Platform Lowered) 0-2.6 mph 0-1.16 m/s
Lift/Lower Speed 19 s / 16 s 19 s /16 s
Hydraulic Pressure (max) 1000 psi 6895 kPa
Hydraulic Fluid Capacity 1 gal 3.55 L
Power System-Voltage 24V DC 24V DC
Batteries-Deep Cycle Marine (2) 12V
Group 24 AGM
(2) 12V
Group 24 AGM
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
8

FAILURE TO FOLLOW THIS WARNING WILL CAUSE
DEATH OR PERSONAL INJURY.
“DANGER” indicates an imminently hazardous situation,
which, if not avoided, will result in death or serious
injury.
FAILURE TO FOLLOW THIS WARNING MAY CAUSE
DEATH OR PERSONAL INJURY.
“WARNING” indicates a potentially hazardous situation,
which, if not avoided, could result in death or serious
injury
FAILURE TO FOLLOW THIS WARNING MAY CAUSE
INJURY OR DAMAGE TO EQUIPMENT.
“CAUTION” indicates a potentially hazardous situation
which, if not avoided, could result in minor or
moderate injury or damage to equipment
CAUTION
DANGER
WARNING
SECTION 2 | SAFETY
2.1 | SAFETY SYMBOLS
Warnings and instructions that have a direct impact on safety are identified with the following signals:
2.2 | GENERAL RULES AND PRECAUTIONS
An operator of any type of work platform is subject to certain hazards that cannot be protected by mechanical
means. It is therefore essential that operators be competent, careful, physically and mentally fit and thoroughly
trained in safe operation of this machine.
Although Custom Equipment, LLC conforms to specified ANSI & OSHA, it is the responsibility of the owner to
instruct operators with the safety requirements made not only by Custom Equipment, LLC, but by the various safety
boards in your area, as well as additional requirements set forth by ANSI & OSHA. If you come across a situation
that you think might be unsafe, stop the platform and request further information from qualified sources before
proceeding.
NEVER REACH BETWEEN SCISSORS LINKS OR PROP UP PLATFORM.
STEERING BRACKETS EXTENDING BEYOND THE SIDES OF THE BASE MAY OCCUR IN TIGHT TURNING
SITUATIONS.
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
B Y C U S TO M EQUIPME NT LLC
9

SECTION 2 | SAFETY
TIGHT TURNING WARNING - Potential damage to walls, etc., may occur in tight turning situations due to the
steering brackets extending beyond the sides of the base.
2.3 | SAFETY FEATURES
• Puncture-proof Wheels.
• Guardrails—43.3 in (1.1 m) height with 6 in (15 cm) kick plates.
• Non-slip Deck.
• Entrance Gate.
• Automatic Parking Brake.
• Free Descent Protection. A velocity fuse is installed in the hydraulic circuit to prevent the platform from
descending in case of a ruptured hydraulic hose. The platform is hydraulically locked until hose has been
replaced. DO NOT attempt to climb down o of platform. Risk of falling may occur. Wait for help to arrive!
• Decals: Danger, Caution, and Warning decals are displayed at various locations on this unit.
• Key Switch Security. A key switch is required to prevent unauthorized use.
2.4 | SAFETY INDICATORS & INTERLOCKS
Tilt Alarm
An audible alarm sounds when the machine is tilted, elevating fuctions will not function. Lower the platform and
move to a level surface immediately.
Descent/Motion Alarm
An audible alarm sounds when the machine is lowering. Some models also sound an alarm when the machine is
elevating or driving.
Pothole Protection
Pothole guards are required to be in place when the lift is in the elevated position. If the guards are blocked or not
functioning properly, elevating functions will not function. Lower the machine and do not operate until the problem
is repaired or the obstruction is removed.
FIGURE 1: Pothole Guards
A
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
10

SECTION 2 | SAFETY
2.5 | SAFETY CONTROLS
Descent - Manual Override
For manually lowering the scissors, a manual valve on the pump is provided. To lower the scissors, pull the cable
located near the rear of the machine.
IF PLATFORM SHOULD FAIL TO LOWER, DO NOT ATTEMPT TO CLIMB DOWN THE BEAM ASSEMBLY. SERIOUS
INJURY MAY RESULT. HAVE AN EXPERIENCED OPERATOR USE THE EMERGENCY LOWERING PROCEDURE TO
SAFELY LOWER THE PLATFORM.
BEFORE LOWERING PLATFORM, RETRACT THE DECK EXTENSION.
Emergency Stop
This lift is equipped with two emergency stop switches, one at the platform control and one at the base control,
that when activated, will render the unit inoperable until reset. To reset, pull the button out.
PUSHING THE EMERGENCY STOP BUTTON WILL APPLY BRAKES IMMEDIATELY. THIS MAY CAUSE UNEXPECTED
PLATFORM MOVEMENT AS THE MACHINE COMES TO A SUDDEN STOP. BRACE YOURSELF AND SECURE
OBJECTS ON THE PLATFORM DURING OPERATION OF THE MACHINE.
DE600E-29
FIGURE 2: Emergency Lowering Valve
FIGURE 3: Emergency Down Instruction
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
B Y C U S TO M EQUIPME NT LLC
11

SECTION 2 | SAFETY
2.6 | MAINTENANCE LOCK
The maintenance lock pins must be placed into position whenever the machine is being serviced in the raised or
partially raised position. Serious injury and/or death could result if maintenance lock is not used properly.
FIGURE 4: Maintenance Lock Use
C
FIGURE 5: Maintenance Lock Storage
C
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
12

2.7 | SAFETY GUIDELINES
Only qualified operators may operate this unit.
• All operators must read and understand the Operation and Safety Manual. They must understand all decals and
warning labels on unit.
• Do not work on platform if your physical condition is such that you feel dizzy or unsteady in any way.
• Do not neglect/misuse machine. Report any misuse of equipment to proper personnel.
• Prevent unauthorized use; when unit is not in use, remove key.
• It is recommended all personnel on unit wear approved personal protective equipment (PPE), i.e. head gear.
Use machine only for purposes for which it was intended.
• Lift should never be used as a crane.
• Do not exceed the load capabilities of the platform.
• Distribute load evenly over platform floor area.
• Never use unit as electrical grounds for arc welding.
• Do not override any hydraulic, mechanical, or electrical safety devices.
Check job site for unsafe working conditions.
• Watch out for others. Keep others clear of operating platform. Never allow others to pass under a raised
platform or position the platform over someone.
• Avoid contact with fixed objects (walls, buildings, or other machinery, etc) or moving vehicles (automobiles,
cranes, etc).
• Follow any applicable national trac regulations.
• Use indoors only. Lift is not designed for windy conditions or electrical storms.
• Unit must be on hard level surface before elevating. Do not operate on incline or uneven surface.
• You must maintain a clearance between any part of the machine, or its load, and any electrical line or apparatus.
Follow local power line clearance regulations.
DO NOT OPERATE MACHINE NEAR POWER LINES. THE PLATFORM AND ENCLOSURES ARE NOT INSULATED.
Equipment is only as safe as the operator.
• Do not use ladders or scaolding on the platform to obtain greater height.
• Do not enter or exit platform while machine is in motion.
• Never mount or dismount a raised platform.
• Make sure entry gate is secured before operating machine from the platform.
• Never belt or tie o to an adjacent structure.
• Secure tools and materials.
• Personnel must maintain a firm footing on the platform floor and work only within the platform area.
• It is recommended to avoid sudden braking or steering. Go slowly and leave more maneuvering room during
cold weather operation
Before operation, ensure that the machine is properly serviced.
• Do not use machine if it is not working properly.
• Make sure platform rails and pins are secured.
• Operator shall use the maintenance lock when performing all types of maintenance procedures.
• Do not smoke while charging the battery.
SECTION 2 | SAFETY
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
B Y C U S TO M EQUIPME NT LLC
13

SECTION 3 | DECALS
3.1 | DECAL LOCATIONS
5
1.2
1.8 1.12
1.17
1.10
1.11
1.17
1.4
1.5
1.16
1.19
1.18
3
1.9
1.17
1.11
1.10
1.17
1.13 1.12
1.8
2
1.2
1.5
1.18
1.1
4
1.6
1.16
1.15
1.3
1.7
1.19
A
1.14
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 129-21-008-50 DECALS,HB-1230 ANSI 1
1.1 DE600E-10 DECAL,MANUAL BOX 1
1.2 DE600E-14 DECAL,MAINT LOCK(SYMBOLS) 2
1.3 DE600E-29 E-DOWN DECAL (SYMBOLS) 1
1.4 DE601 DECAL,LOGO HY-BRID 1
1.5 DE603-6 MODEL# DECAL-HB-1230 2
1.6 DE613 LANYARD ATTACHMENT DECAL 1
1.7 DE619 CHARGER CORD DECAL 1
1.8 DE652 DECAL,WEBSITE 2
1.9 DE706 DECAL,UPR HB,ZTR,MID 1
1.10 DE707 DECAL,KEEP 2
1.11 DE708 DECAL,CLEAR 2
1.12 DE709 DECAL, LWR 2
1.13 DE710 DECAL,BRAKE RELEASE/NO TOW 1
1.14 DE711 QR CODES,MANUAL & SCHEMATICS 1
1.15 DE719 DECAL,CASTERLOCK 1
1.16 DE717-61 DECAL,SAFETY STRIPE (24.00") 2
1.17 DE717-62 DECAL,SAFETY STRIPE (12.00") 4
1.18 DE725 DECAL,CAPACITY,500#,2P,I,W/SO 2
1.19 DE721 DECAL,CASTERLOCK 2
FIGURE 6: Decal Locations
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
14

SECTION 3 | DECALS
3.2 | DECAL DESCRIPTIONS
ITEM # PART # DECAL MEANING OR DESIGNATION QTY.
1 129-21-008-50 Decals, HB-1230
1.1 DE600E-10 DECAL, MANUAL BOX 1
1.2 DE600E-14 Decal, MAINTENANCE LOCK 2
1.3 DE600E-29 DECAL,E-DOWN 1
1.4 DE601 DECAL, LOGO HY-BRID 1
1.5 DE603-6 Model# Decal - HB-1230 2
1.6 DE613 DECAL, LANYARD ATTACHMENT 1
1.7 DE619 DECAL, Charger Cord 1
1.8 DE652 Decal, Website 2
1.9 DE706 Decal, UPR HB, ZTR, Mid 1
1.10 DE707 Decal, Keep 2
1.11 DE708 Decal, Clear 2
1.12 DE709 Decal, Lower 2
1.13 DE710 Decal, brake release / no tow 1
1.14 DE711 QR codes, manual & Schematics 1
1.15 DE719 DECAL,CASTER LOCK 1
1.16 DE717-61 Decal, Safety Stripe (24.00”) 2
1.17 DE717-62 Decal, Safety Stripe (12.00”) 2
1.18 DE725 Decal, Capacity, 500#, 2p,I, w/so 2
1.19 DE721 DECAL,CASTER LOCK 2
2 DE704 DECAL, LOWER CONTROL 1
3 DE706 DECAL,UPPER CONTROL 1
4 NONE SERIAL NUMBER REFERENCE 1
5 NONE SERIAL NUMBER DECAL 1
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
B Y C U S TO M EQUIPME NT LLC
15

3.3 | DECAL SYMBOLS
Symbol Meaning
• No Authorized Use
• Do not operate this machine unless you have been trained in safe
operation.
• Training includes complete knowledge of the safety and operating
instructions contained in the manufacturer’s manual, your employer’s work
rules, and applicable government regulations.
• An untrained operator subjects himself and others to death or serious
injury.
• Read and understand all dangers and warning in the operator’s manual
before operating this machine.
• Improper use of this machine could cause death or serious injury.
• Inspect machine and make sure that it is operating properly, that all name
plate and hazard signs are in place and legible, and that the machine is in
accordance with the manufacturer’s maintenance requirements contained
in the operating and maintenance requirements contained in the operation
and maintenance manual and the daily safety checklist.
• Lanyard anchorage point location.
• Lanyard anchorage points are for work positioning restraints only.
• Use of fall arrest systems attached to anchorage points on mobile
equipment may cause machine to tip, resulting in serious injury or death.
• Crushing Hazard
• Do not enter the space beneath the work platform or scissor structure
unless the maintenance lock is in place.
• Refer to Maintenance Manual
• Only qualified service personnel may service the machine. Failure to
comply with listed safety precautions may result in machine damage,
personnel injury, or death.
• Replace designated items with manufacturer’s specified equipment only.
Failure to use these items may cause instability of platform.
• Batteries produce explosive gas. Only charge batteries in a well-ventilated
area.
• Do not expose sparks or flames.
• Do not smoke while charging battery.
• Battery Charger Cord
SECTION 3 | DECALS
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
16

Symbol Meaning
• Tip Hazard
• Tip Hazard
• Do not elevate platform on an incline or step.
• Tip Hazard
• Do not elevate platform on a slope.
• Tip Hazard
• Do not elevate platform on uneven or soft surfaces.
• Indoor Use Only: No Wind Load
• Electrocution Hazard
• This machine is not insulated.
• Maintain safe clearance from electrical lines and apparatus. You must allow
for machine sway, rock or sag and electrical lines swaying.
• This machine does not provide protection from contact with or proximity
to an electrically charged conductor.
• You must maintain a clearance between any part of this machine or its
load and any electrical apparatus. Follow local power line regulations.
• Death or serious injury will result from contact or inadequate clearance.
• Brake Release
SECTION 3 | DECALS
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
B Y C U S TO M EQUIPME NT LLC
17

Symbol Meaning
• Emergency Lowering
• Battery disconnect
• Fork pocket
• Hydraulic oil level
• Engaging mechanical Action: Enable Switch
SECTION 3 | DECALS
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
18

4.1 | PRELIMINARY UNPACKING INSTRUCTIONS AND DEALER INSPECTION
Maintenance locks must be engaged prior to inspecting or servicing the unit when the platform is elevated.
Inspect machine for any possible damage during shipment; perform pre-delivery inspection. See checklist in the
Maintenance Manual. Reset emergency stop switches, if necessary.
4.2 | STORAGE
After periods of storage or exposure to extremes of ambient conditions (heat, cold, moisture, dust etc.) inspect the
machine. Refer to the Pre-Delivery/Frequent Inspection Checklist of the Maintenance Manual.
4.3 | PREPARATION FOR TRANSPORT
Lower the work platform to the down position. Bring the platform slide-out extension into the retracted position
and lock in place. Turn the key switch to o position. Check the entire machine for loose or unsecured items.
Remove any loose items from machine.
To limit caster swivel when loading or unloading, the maintenance lock pins may be placed in the designated hole
to lock the casters when the casters are turned straight.
The machine can be pushed by releasing the parking brake at the rear of the machine. Pull both levers away from
the floor. To resume normal operation, make sure both levers are down. Do not attempt to push or tow unit with
the brakes applied. Do not push at speeds more than 2 mph (0.9 m/s). Severe gear damage will occur. Towing is
not recommended.
NOTE: The drive system will not function if the parking brake is in the up release position.
SECTION 4 | TRANSPORT, HANDLING & STORAGE
DO NOT OVERLOAD BINDERS WHEN SECURING
LOAD FOR TRANSPORT
D
C
FIGURE 7: Brake Release
C
FIGURE 8: Caster Lock
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
B Y C U S TO M EQUIPME NT LLC
19

SECTION 4 |TRANSPORT, HANDLING, AND STORAGE
4.4 | LIFTING AND TIEDOWN POINTS
Tie-down/lift points are provided for securing the machine on a trailer or truck bed for transport between places of
use. They may also be used as lift points.
4.5 | FORK LIFT POCKETS
Fork lift pockets are provided from the back of the unit for loading and unloading. A forklift from the side of the
machine is not recommended. Do not use a forklift underneath the machine from the back. When moving
machine with a forklift, do not let machine slide along floor. Bring forklift to a stop and then gently lower the
machine.
Center of gravity
X Axis Y Axis
HB-1230 26.3 in (66.8 cm) 13.2 in (33.5 cm)
E
FIGURE 9: Lift/Tie-Down Points, Front FIGURE 10: Lift/Tie Down Points, Rear
E
X
Y
FIGURE 11: Center of Gravity
B Y C U S TO M EQUIPME NT LLC
OPERATIONS & SAFETY
HB-1230
SUPO-645
REV A
20
