Hy-Brid Lifts SERIES II Use and care manual

BY CUSTOM EQUIPMENT LLC
OPERATIONS & SAFETY MANUAL
SELF-PROPELLED AERIAL WORK PLATFORM
SUPO-693
REV C
HB-1030
HB-1430
SERIES II

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
2
NOTES
If there is a question about application
and/or operation, contact:
Custom Equipment, LLC
2647 Hwy 175
Richfield, WI 53076
U.S.A.
P: [phone]
F: [phone]
www.hybridlifts.com

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
3
FOREWORD
Original instructions are written in English.
The purpose of this Operations and Safety manual is to provide users with the instructions and operating procedures
essential to properly and safely operate the Custom Equipment Hy-Brid Lift for its intended purpose, and to position
personnel and their necessary tools and materials.
THE OPERATION AND SAFETY MANUAL MUST BE
READ AND UNDERSTOOD PRIOR TO OPERATING THE MACHINE.
• The user/operator should not accept operating responsibility until the manual has been read and understood as well
as having operated the lift under supervision of an experienced and qualified operator.
• Because the manufacturer has no direct control over machine application and operation, proper safety practices are
the responsibility of the user and all operating personnel.
ANY MODIFICATION ON THIS MACHINE WITHOUT THE EXPRESS WRITTEN CONSENT OF THE
MANUFACTURER IS PROHIBITED.
Fall protection notice:
The guardrail system around the perimeter of the platform is the fall protection system for self-propelled elevating
work platforms per the ANSI/SIA A92.6 Standard. It is prohibited to use an Aerial Work Platform manufactured
by Custom Equipment, LLC, with any portion—or all—of the guardrails removed. Lanyard anchorage points on
this type of equipment are not required to conform to the applicable standard. However, if anchorage points for
lanyard attachments are required by site authorities or other regulations, the anchorage points on all equipment
manufactured by Custom Equipment, LLC are recommended to be used for work positioning restraints of personnel
only. Lanyard lengths are to be determined by operator/owner to restrict the operator to the confines within the
guardrail system.
USE OF FALL ARREST SYSTEMS ATTACHED TO ANCHORAGE POINTS
ON EQUIPMENT MAY CAUSE MACHINE TO TIP, RESULTING IN SERIOUS INJURY OR DEATH.
Lanyard
Attachment
Point
DANGER
WARNING
WARNING

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
4
TABLE OF CONTENTS
NOTES.......................................................................................................................................................................................... 2
FOREWORD ................................................................................................................................................................................ 3
TABLE OF CONTENTS............................................................................................................................................................... 4
INDEX OF FIGURES.................................................................................................................................................................... 5
SECTION 1 | SAFETY .................................................................................................................................................................. 6
1.1 | SAFETY SYMBOLS.......................................................................................................................................................................... 6
1.2 | GENERAL RULES AND PRECAUTIONS .................................................................................................................................. 6
1.3 | SAFETY FEATURES ........................................................................................................................................................................ 7
1.4 | SAFETY INDICATORS & INTERLOCKS ..................................................................................................................................... 7
1.5 | SAFETY CONTROLS ..................................................................................................................................................................... 7
1.6 | MAINTENANCE LOCK .................................................................................................................................................................8
1.7 | SAFETY GUIDELINES.................................................................................................................................................................... 9
1.8 | PROPOSITION 65....................................................................................................................................................................... 10
SECTION 2 | PRODUCT DESCRIPTION................................................................................................................................ 12
2.1 | GENERAL....................................................................................................................................................................................... 12
SECTION 3 | DECALS............................................................................................................................................................... 14
3.1 | DECAL LOCATION...................................................................................................................................................................... 14
3.2 | DECAL DESCRIPTIONS............................................................................................................................................................. 15
3.3 | DECAL SYMBOLS........................................................................................................................................................................ 16
SECTION 4 | TRANSPORT, HANDLING & STORAGE..........................................................................................................20
4.1 | PRELIMINARY UNPACKING INSTRUCTIONS AND DEALER INSPECTION ..................................................................20
4.2 | STORAGE......................................................................................................................................................................................20
4.3 | PREPARATION FOR TRANSPORT ..........................................................................................................................................20
4.4 | LIFTING AND TIEDOWN POINTS.........................................................................................................................................20
4.5 | FORK LIFT POCKETS ................................................................................................................................................................. 21
SECTION 5 | OPERATION ....................................................................................................................................................... 22
5.1 | BEFORE YOU OPERATE ............................................................................................................................................................22
5.2 | STARTUP/SHUT DOWN............................................................................................................................................................23
5.3 | DRIVING AND STEERING.........................................................................................................................................................24
5.4 | ELEVATING AND LOWERING..................................................................................................................................................24
5.5 | EXTENDING THE PLATFORM..................................................................................................................................................25
5.6 | DAILY MAINTENANCE...............................................................................................................................................................26
5.7 | CHARGING THE BATTERY .......................................................................................................................................................26
5.8 | BATTERY DISPLAYS .................................................................................................................................................................... 27
SECTION 6 | PRESTART INSPECTION ................................................................................................................................30
6.1 | PRESTART INSPECTION CHECKLIST...................................................................................................................................30

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
5
INDEX OF FIGURES
Revisions:
REV A: Initial Release Reference 2015-2583 .............................................................................................................JANUARY 2016
REV B: Reference 2017-3206,3215 ..............................................................................................................................JANUARY 2018
REV C:......................................................................................................................................................................................MARCH 2019
FIGURE 1: Pothole Guard........................................................................................................................................................................ 7
FIGURE 2: Emergency Lowering Valve................................................................................................................................................ 8
FIGURE 3: Down Instruction Decal No. DE600-29 .........................................................................................................................8
FIGURE 4: Maintenance Lock Pin use ................................................................................................................................................. 9
FIGURE 5: Maintenance Lock Pin storage.......................................................................................................................................... 9
FIGURE 6: Decal Locations .................................................................................................................................................................. 14
FIGURE 7: Brake Release.......................................................................................................................................................................20
FIGURE 8: Fork Pockets......................................................................................................................................................................... 21
FIGURE 9: Tie-Down Points ................................................................................................................................................................. 21
FIGURE 10: Center of Gravity............................................................................................................................................................... 21
FIGURE 11: Base Controls .....................................................................................................................................................................22
FIGURE 12: Platform Controls..............................................................................................................................................................22
FIGURE 13: Main power switch ...........................................................................................................................................................23
FIGURE 14: Main power switch o.....................................................................................................................................................23
FIGURE 15: Main power switch knob removed...............................................................................................................................23
FIGURE 16: Secure Location ................................................................................................................................................................23
FIGURE 17: Slide Lock ............................................................................................................................................................................25
FIGURE 18: Lester Prime Battery Charge Indicator Location ...................................................................................................... 27
FIGURE 19: Lester SLM Battery Charge Indicator Location .........................................................................................................28
FIGURE 20: Signet Battery Charge Indicator Location..................................................................................................................29
FIGURE 21: PCS/Dual Pro Battery Charge Indicator Location ....................................................................................................29

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
6
1.1 | SAFETY SYMBOLS
FAILURE TO FOLLOW THIS WARNING WILL CAUSE
DEATH OR PERSONAL INJURY.
“DANGER” indicates an imminently hazardous situation,
which, if not avoided, will result in death or serious
injury.
FAILURE TO FOLLOW THIS WARNING MAY CAUSE
DEATH OR PERSONAL INJURY.
“WARNING” indicates a potentially hazardous situation,
which, if not avoided, could result in death or serious
injury.
FAILURE TO FOLLOW THIS WARNING MAY CAUSE
INJURY OR DAMAGE TO EQUIPMENT.
“CAUTION” indicates a potentially hazardous situation
which, if not avoided, could result in minor or
moderate injury or damage to equipment.
1.2 | GENERAL RULES AND PRECAUTIONS
An operator of any type of work platform is subject to certain hazards that cannot be protected by mechanical
means. It is therefore essential that operators be competent, careful, physically and mentally fit and thoroughly
trained in safe operation of this machine.
Although Custom Equipment, LLC conforms to specified ANSI & OSHA, it is the responsibility of the owner to
instruct operators with the safety requirements made not only by Custom Equipment, LLC, but by the various safety
boards in your area, as well as additional requirements set forth by ANSI and OSHA. If you come across a situation
that you think might be unsafe, stop the platform and request further information from qualified sources before
proceeding.
NEVER REACH BETWEEN SCISSORS LINKS OR PROP UP PLATFORM.
STEERING BRACKETS EXTENDING BEYOND THE SIDES OF
THE BASE MAY OCCUR IN TIGHT TURNING SITUATIONS.
Potential damage to walls, etc., may occur in tight turning situations due to the steering brackets extending beyond
the sides of the base.
SECTION 1 | SAFETY
DANGER
CAUTION
WARNING
CAUTION
WARNING

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
7
SECTION 1 | SAFETY
1.3 | SAFETY FEATURES
• Puncture-Proof Wheels.
• Guardrails—42 in (1.07 m) height with 4 in (10.16 cm) kick plates.
• Non-Slip Deck.
• Entrance Gate.
• Automatic Parking Brake.
• Free Descent Protection. A velocity fuse is installed in the hydraulic circuit to prevent the platform from
descending in case of a ruptured hydraulic hose. The platform is hydraulically locked until hose has been
replaced.
• Decals: Danger, Caution, and Warning decals are displayed at various locations on this unit.
• Key Switch Security. A key switch is required to prevent unauthorized use.
1.4 | SAFETY INDICATORS & INTERLOCKS
Tilt Alarm
An audible alarm sounds when the machine is tilted more than 2°. Lower the platform and move to a level surface.
Descent/Motion Alarm
An audible alarm sounds when the machine is lowering. Some models also sound an alarm when the machine is
elevating or driving.
Pothole Protection
Pothole guards are required to be in place when the lift is in the elevated position. If the guards are blocked or not
functioning properly, elevating functions will be inhibited. Lower the machine and do not operate until the problem
is repaired or the obstruction is removed.
1.5 | SAFETY CONTROLS
Descent - Manual Override
For manually lowering the scissors, a manual valve on the pump is provided. Lift the panel on the side cover and
locate valve on the hydraulic pump. Push and turn the knob located on down valve counterclockwise to open.
Knob will pop up. To reset, push and turn counterclockwise direction.
FIGURE 1: Pothole Guard

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
8
SECTION 1 | SAFETY
IF PLATFORM SHOULD FAIL TO LOWER, DO NOT ATTEMPT TO CLIMB DOWN THE BEAM ASSEMBLY.
SERIOUS INJURY MAY RESULT. HAVE AN EXPERIENCED OPERATOR USE THE EMERGENCY LOWERING
PROCEDURE TO SAFELY LOWER THE PLATFORM.
BEFORE LOWERING PLATFORM, RETRACT THE DECK EXTENSION.
Emergency Stop
This lift is equipped with two emergency stop switches, one at the platform control and one at the base control,
that when activated, will render the unit inoperable until reset. To reset, pull the button out.
PUSHING THE EMERGENCY STOP BUTTON WILL APPLY BRAKES IMMEDIATELY.
THIS MAY CAUSE UNEXPECTED PLATFORM MOVEMENT AS THE MACHINE COMES TO A SUDDEN STOP.
BRACE YOURSELF AND SECURE OBJECTS ON THE PLATFORM DURING OPERATION OF THE MACHINE.
1.6 | MAINTENANCE LOCK
The maintenance lock pins must be placed into position whenever the machine is being serviced in the raised or
partially raised position. Serious injury and/or death could result if maintenance lock is not used properly.
FIGURE 2: Emergency Lowering Valve
EMERGENCY
LOWERING
PUSH, TURN
AND PULL
KNOB
FIGURE 3: Down Instruction Decal No. DE600-29
WARNING
WARNING
WARNING

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
9
1.7 | SAFETY GUIDELINES
Only qualified operators may operate this unit.
• All operators must read and understand the Operation and Safety Manual. They must understand all decals and
warning labels on unit.
• Do not work on platform if your physical condition is such that you feel dizzy or unsteady in any way.
• Do not neglect/misuse machine. Report any misuse of equipment to proper personnel.
• Prevent unauthorized use; when unit is not in use, remove key.
• It is recommended all personnel on unit wear approved personal protective equipment (PPE), i.e. head gear.
Use machine only for purposes for which it was intended.
• Lift should never be used as a crane.
• Do not exceed the load capabilities of the platform.
• Distribute load evenly over platform floor area.
• Never use unit as electrical grounds for arc welding.
• Do not override any hydraulic, mechanical, or electrical safety devices.
Check job site for unsafe working conditions.
• Watch out for others. Keep others clear of operating platform. Never allow others to pass under a raised
platform or position the platform over someone.
• Avoid contact with fixed objects (walls, buildings, or other machinery, etc) or moving vehicles (automobiles,
cranes, etc).
• Follow any applicable national trac regulations.
• Use indoors only. Lift is not designed for windy conditions or electrical storms.
• Unit must be on hard level surface before elevating. Do not operate on incline or uneven surface.
• You must maintain a clearance between any part of the machine, or its load, and any electrical line or apparatus.
Follow local power line clearance regulations.
SECTION 1 | SAFETY
FIGURE 4: Maintenance Lock Pin use FIGURE 5: Maintenance Lock Pin storage

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
10
WARNING
DO NOT OPERATE MACHINE NEAR POWER LINES.
THE PLATFORM AND ENCLOSURES ARE NOT INSULATED.
Equipment is only as safe as the operator.
• Do not use ladders or scaolding on the platform to obtain greater height.
• Do not enter or exit platform while machine is in motion.
• Never mount or dismount a raised platform.
• Make sure entry gate is secured before operating machine from the platform.
• Never belt or tie o to an adjacent structure.
• Secure tools and materials.
• Personnel must maintain a firm footing on the platform floor and work only within the platform area.
• It is recommended to avoid sudden braking or steering. Go slowly and leave more maneuvering room during
cold weather operation
Before operation, ensure that the machine is properly serviced.
• Do not use machine if it is not working properly.
• Make sure platform rails and pins are secured.
• Operator shall use the maintenance lock when performing all types of maintenance procedures.
• Do not smoke while charging the battery.
1.8 | PROPOSITION 65
THIS PRODUCT CONTAINS CHEMICALS KNOWN TO
THE STATE OF CALIFORNIA TO CAUSE CANCER,
AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM
For more information about Proposition 65 visit: http://www.p65warnings.ca.gov/
SECTION 1 | SAFETY
DANGER

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
11
THIS PAGE WAS INTENTIONALLY LEFT BLANK

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
12
Custom Equipment’s Hy-Brid Scissors Lift is an aerial work platform designed to be safe and reliable. The purpose of
the machine is to elevate personnel, along with their necessary tools and materials to overhead work locations.
Manufacturer approval is required for any use other than the intended use.
Before operation, the operator must read and understand the manufacturer’s operating instructions and user’s safety
rules, or have them explained, understand all labels, warnings, and instructions displayed on the aerial platform or
have them explained, ensure that all occupant of the aerial platform wear appropriate protective equipment for the
conditions, including the environment in which the aerial platform will be operated.
The operator must inspect the workplace for environmental hazards such as, but not limited to drop-os, holes,
slopes, debris, floor or overhead obstructions, surface, wind and weather conditions, or presence of unauthorized
persons. Vibration does not create significant hazards on this machine.
HB-1030 HB-1430
Working Height (maximum) 16 ft 4.87 m 20 ft 6.1 m
Platform Height (maximum) 10 ft 3 m 14 ft 4.26 m
Stowed Height 65.63 in 1.67 m 70 in 1.78m
Ground Clearance (Pothole Guard
Stowed) 2 in 5.1 cm 3 in 7.6 cm
Ground Clearance (Pothole Guard
Engaged) 0.375 in 0.95 cm 0.375 in 0.95 cm
Overall Width 30 in 0.76 m 30 in 0.76 m
Overall Length 63.5 in 1.61 m 69.5 in 1.77 m with
step
Platform (Retracted, Inside) 25 in x 60 in 0.64 m x 1.52 m 25 in x 60 in 0.64 m x 1.52
m
Slide-Out Deck Length 30 in 0.76 m 30 in 0.76 m
Guard Rail Height 42 in 1 m 42 in 1 m
Platform Entrance 21.0 in 0.53 m 25.34 in 0.64 m
Step Height N/A N/A 12.42 in 0.32 m
Wheel Base 51 in 1.3 m 51 in 1.3 m
Wheel Track 23.63 in 0.6 m 23.63 in 0.6 m
Turning Radius (Inside) 21 in 0.53 m 21 in 0.53 m
Tire Size (Solid, Non-Marking) - Front
/ Rear 8 in / 10 in 20.3 cm / 25.4 cm 10 in / 10 in 25.4 cm / 25.4 cm
RATED LOAD
Lift Capacity (Evenly Distributed): 750 lb / 2 Persons 340.2 kg / 2
Persons
670 lb. / 2
Persons
304 kg. /2
Persons
Slide-Out Deck Capacity 250 lb / 1 Person 113.4 kg / 1 Person 250 lbs / 1
Person
113.4 kg / 1
Person
Horizontal/Manual Force 112.5 lb 500 N 100.5 lb 447 N
SECTION 2 | PRODUCT DESCRIPTION
2.1 | GENERAL

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
13
SECTION 2 | PRODUCT DESCRIPTION
FLOOR LOADING HB-1030 HB-1430
Machine Weight (Unloaded) (Approx.) 1273 lb 577.4 kg 1645 lb 746 kg
Minimum Wheel Load-Contact
Pressure 62.7 psi 432.5 kPa 80.9 psi 557.6 kPa
Maximum Wheel Load-Contact
Pressure 99.3 psi 684.8 kPa 113.6 psi 783.0 kPa
Minimum Machine Loading-Floor
Pressure 97.2 psf 4.54 kPa 125.3 psf 6.00 kPa
Maximum Machine Loading-Floor
Pressure 153.9 psf 7.37 kPa 180.0 psf 8.43 kPa
ENVIRONMENTAL LIMITATIONS
Wind No Windy Conditions/Indoor Use Only
( C )
No Windy Conditions/Indoor Use
Only ( C )
Rated Slope Level Surface Level Surface
Tilt Sensor Activated 2° 2°
Gradeability (Stowed Position) 25% ( 14° Unloaded); 20% ( 11° Loaded) 25% ( 14° Unloaded); 20% ( 11°
Loaded)
Temperature -4°F to 104°F -20°C to 40°C -4°F to 104°F -20°C to 40°C
Vibration 8.2 ft/s2max 2.5 m/s2max 8.2 ft/s2max 2.5 m/s2max
Sound - Normal Use, Alarms 86 dB, 100 dB 86 dB, 100 dB 86 dB, 100 dB 86 dB, 100 dB
POWER SYSTEMS - Drive System (Proportional Electric):
Drive Speed (Platform Elevated) 0-0.7 mph 0-.31 m/s 0-0.7 mph 0-.31 m/s
Drive Speed (Platform Lowered) 0-2.5mph 0-1.18 m/s 0-2.5mph 0-.1.18m/s
Lift/Lower Speed 15/14 sec 15/14 sec 21/16 sec 21/16 sec
Hydraulic Pressure (max) 1300 psi 8963 kPa 1300 psi 8963 kPa
Hydraulic Fluid Capacity 1.325 gal 5.38 L 1.325 gal 5.38 L
Power System-Voltage 24V DC 24V DC 24V DC 24V DC
Batteries-Deep Cycle Marine (2) 12V, Group 27 (2) 12V, Group 27 (2) 12V, Group 27 (2) 12V, Group
27

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
14
SECTION 3 | DECALS
16
9
21
21
7
5
11 8
4
3
2
4
12
15
14
13
12
4
3
2
4
21
9
22
5
11 7 21
17
18
23
27
A
B
C
D
99 25
6
20
24
9
19
26
99 10
14
15
1
ITEM
NO.
ServiceListing
DESCRIPTION
Comments
QTY.
SupersededBy
SN START SN END
UM
PART NUMBER
1 112-21-218-55-K DECALS,HB-1430 1 EA 112-21-218
2 DE707 DECAL,KEEP 2 EA DE707
3 DE708 DECAL,CLEAR 2 EA DE708
4 DE717-62 DECAL,SAFETY STRIPE (12.00) 4 EA DE717-62
5 DE822 DECAL,WEBSITE 2 EA DE822
6 DE600E-10 DECAL,MANUAL BOX 1 EA DE600E-10
7 DE709 DECAL, LWR 2 EA DE709
8 DE600-28 DECAL,E-DOWN LOCATION 1 EA DE600-28
9 DE600E-14 DECAL,MAINT LOCK 3 EA DE600E-14
10 DE600-29 DECAL,E-DOWN 1 EA DE600-29
11 DE717-61 DECAL,SAFETY STRIPE (24.00) 2 EA DE717-61
12 DE603-1 DECAL,MODEL HB-1430 2 EA DE603-1
13 DE706 DECAL,UPR HB 1 EA DE706
14 DE733 DECAL,CAPACITY,670#,2P,I,W/SO 2 EA DE733
15 DE746 DECAL,LANYARD ATTACHMENT 2 EA DE746
16 DE821 DECAL,LOGO HY-BRID 1 EA DE821
17 DE747 DECAL,BRAKE RELEASE/NO TOW 1 EA DE747
18 DE753 DECAL,CHARGER CORD 1 EA DE753
19 DE679 DECAL,HYDR FLUID 1 EA DE679
20 DE777 DECAL,BATT CHARGE DAILY 1 EA DE777
21 DE663 DECAL,WHEEL LOAD HB-1430 S2 4 EA DE663
22 DE770 DECAL,CTL LWR HBLG-ANSI 1 EA DE770
23 DE772 DECAL,CTL UPR 1 EA DE772
24 DE649 DECAL,CAPACITY, TOOL TRAY 1 EA DE649
25 DE782 DECAL,MADE IN USA 1 EA DE782
26 DE797 DECAL,BATT/CHR COMPATABILITY 1 EA DE797
27 DE1230 DECAL, PROP 65 1 EA DE1230
28 DE805 DECALS,HB2 1 112-21-008-55-K EA DE805
29 DE624A DECAL,CTL UPR 1 EA DE624A
30 DE623A DECAL,CTL LWR HBLG-ANSI 1 EA DE623
31 DE600-01 DECAL,WARNINGS 2 DE706 EA DE600-01
32 DE600-02 DECAL,DANGERS 1 DE600-02-KIT-55 EA DE600-02
33 DE600-03A DECALCAPACITY,670#,2P,I,W/SO 3 DE733 EA DE600-03A
34 DE600-04 DECAL,PLAT EXT & GATE 1 DE706 EA DE600-04
35 DE600-07 DECAL,DO NOT POWERWASH 1 N/A EA DE600-07
36 DE600-08 DECAL,BATT GAS WARNING 1 DE709 EA DE600-08
37 DE600-09 DECAL, ELECTROCUTION HAZARD 1 DE706 EA DE600-09
38 DE600-16A DECAL,KEEP 2 DE707 EA DE600-16A
39 DE600-16B DECAL.CLEAR 2 DE708 EA DE600-16B
40 DE600-17 DECAL,SAFETY STRIPE (24.00) 4 DE717-61 EA DE600-17
41 DE600-21 DECAL,BRAKE RELASE/NO TOW 1 DE747 EA DE600-21
42 DE600-22 DECAL,BRAKE RELEASE/NO TOW 1 DE747 EA DE600-22
43 DE600E-02 DECAL,DANGERS INDOOR ONLY 1 VARIES EA DE600E-02
44 DE600E-05 DECAL,DANGER TIP 1 DE706 EA DE600E-05
45 DE600E-06 REPLACE OEM ONLY DECAL 2 DE709 EA DE600E-06
46 DE600E-18 DECAL,BATT WEIGHT 2 DE709 EA DE600E-18
47 DE600E-30 DECAL,MAINT LOCK USE 2 DE708 EA DE600E-30
48 DE613 DECAL,LANYARD ATTACHMENT 1 DE746 EA DE613
49 DE619 DECAL,CHARGER CORD 1 DE753 EA DE619
50 DE626 DECAL,PH WARNING 2 DE709 EA DE626
51 DE627 DECAL,HOLE COVER 2 N/A EA DE627
52 DE600-02-KIT-55 DECAL,DANGERS RETROFIT,1430 1 EA DE600-02-KIT
53 DE601 DECAL,LOGO HY-BRID 1 DE821 EA
DE601
54 DE652 DECAL,WEBSITE 2 DE822 EA DE652
1 112-21-008-55-K DECALS,HB-1430 1 EA 112-21-008
99 N/A SERIAL NUMBER REFERENCE EA
3.1 | DECAL LOCATION
FIGURE 6: Decal Locations

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
15
SECTION 3 | DECALS
3.2 | DECAL DESCRIPTIONS
ITEM # PART # DECAL MEANING OR DESIGNATION QTY
1
112-21-218-50-K
OR
112-21-218-55-K
DECALS,HB-1030
OR
DECALS,HB-1430
1
2 DE707 DECAL,KEEP 2
3 DE708 DECAL,CLEAR 2
4 DE717-62 DECAL,SAFETY STRIPE (12.00) 4
5 DE822 DECAL,WEBSITE 2
6 DE600E-10 DECAL,MANUAL BOX 1
7 DE709 DECAL, LWR 2
8 DE600-28 DECAL,E-DOWN LOCATION 1
9 DE600E-14 DECAL,MAINT LOCK 3
10 DE600-29 DECAL,E-DOWN 1
11 DE717-61 DECAL,SAFETY STRIPE (24.00) 2
12
DE603
OR
DE603-1
DECAL,MODEL HB-1030
OR
DECAL,MODEL HB-1430
2
13 DE706 DECAL,UPR HB 1
14
DE732
OR
DE733
DECAL,CAPACITY,670#,2P,I,W/SO
OF
DECAL,CAPACITY,670#,2P,I,W/SO
2
15 DE746 DECAL,LANYARD ATTACHMENT 2
16 DE821 DECAL,LOGO HY-BRID 1
17 DE747 DECAL,BRAKE RELEASE/NO TOW 1
18 DE753 DECAL,CHARGER CORD 1
19 DE679 DECAL,HYDR FLUID 1
20 DE777 DECAL,BATT CHARGE DAILY 1
21 DE663 DECAL,WHEEL LOAD HB-1430 S2 4
22 DE770 DECAL,CTL LWR HBLG-ANSI 1
23 DE772 DECAL,CTL UPR 1
24 DE649 DECAL,CAPACITY, TOOL TRAY 1
25 DE782 DECAL,MADE IN USA 1
26 DE797 DECAL,BATT/CHR COMPATABILITY 1
27 DE1230 DECAL,PROP 65 1
99 N/A SERIAL NUMBER REFERENCE 0

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
16
SECTION 3 | DECALS
3.3 | DECAL SYMBOLS
• No Unauthorized Use
• Do not operate this machine unless you have been trained in safe
operation.
• Training includes complete knowledge of the safety and operating
instructions contained in the manufacturer’s manual, your employer’s
work rules, and applicable government regulations.
• An untrained operator subjects himself and others to death or serious
injury.
• Read and understand all dangers and warnings in the operator’s manual
before operating this machine.
• Improper use of this machine could cause death or serious injury.
• Inspect machine and make sure that it is operating properly, that all
name plate and hazard signs are in place and legible, and that the
machine is in accordance with the manufacturer’s maintenance
requirements contained in the operating and maintenance
requirements contained in the operation and maintenance manual and
the daily safety checklist.
• Crushing Hazard
• Do not enter the space beneath the work platform or scissor structure
unless the maintenance lock is in place.
• Refer to Maintenance Manual
• Only qualified service personnel may service the machine. Failure to
comply with listed safety precautions may result in machine damage,
personnel injury, or death.
• Replace designated items with manufacturer’s specified equipment
only. Failure to use these items may cause instability of platform.
• Batteries produce explosive gas. Only charge batteries in a well-
ventilated area.
• Do not expose to sparks or flames.
• Do not smoke while charging battery.
• Battery Charger Cord

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
17
SECTION 3 | DECALS
• Tip Hazard
• Tip Hazard
• Do not elevate platform on an incline or step.
• Tip Hazard
• Do not elevate platform on a slope.
• Tip Hazard
• Do not elevate platform on uneven or soft surfaces.
• Indoor Use Only: No Wind Load
• Electrocution Hazard
• This machine is not insulated.
• Maintain safe clearance from electrical lines and apparatus. You must
allow for machine sway, rock or sag and electrical lines swaying.
• This machine does not provide protection from contact with or
proximity to an electrically charged conductor.
• You must maintain a clearance between any part of this machine or its
load and any electrical apparatus. Follow local power line regulations.
• Death or serious injury will result from contact or inadequate clearance.
• Brake Release

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
18
SECTION 3 | DECALS
• Emergency Lowering
• Battery disconnect
• Fork pocket
• Hydraulic oil level
• Engaging mechanical Action: Enable Switch
x 1 • Lanyard anchorage point location: Capacity 1 Person
• Lanyard anchorage points are for work positioning restraints only, not
for fall
• protection.
• Use of fall arrest systems attached to anchorage points on mobile
equipment may cause machine to tip, resulting in serious injury or
death.

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
19
THIS PAGE WAS INTENTIONALLY LEFT BLANK

OPERATIONS & SAFETY
HB-1030/HB-1430
SUPO-693
REV C
B Y C U S TO M EQUIPME NT LLC
20
SECTION 4 | TRANSPORT, HANDLING & STORAGE
4.1 | PRELIMINARY UNPACKING INSTRUCTIONS AND DEALER INSPECTION
Maintenance locks must be engaged prior to inspecting or servicing the unit when the platform is elevated.
Inspect machine for any possible damage during shipment; perform pre-delivery inspection. See checklist in the
Maintenance Manual. Reset emergency stop switches, if necessary.
4.2 | STORAGE
After periods of storage or exposure to extremes of ambient conditions (heat, cold, moisture, dust etc.) inspect the
machine. Refer to the Pre-Delivery/Frequent Inspection Checklist of the Maintenance Manual.
4.3 | PREPARATION FOR TRANSPORT
Lower the work platform to the down position. Bring the platform slide-out extension into the retracted position
and lock in place. Turn the key switch to o position. Check the entire machine for loose or unsecured items.
Remove any loose items from machine.
The machine can be pushed by releasing the parking brake at the rear of the machine. Push both levers toward the
floor. To resume normal operation, make sure both levers are up.
Do not attempt to push or tow unit with the brakes applied. Severe gear damage will occur. Towing is not
recommended.
To release brake for winching or pushing, rotate brake handles. Do not push at speeds more than 2 mph (0.9 m/s).
NOTE: The drive system will not function if the parking brake is in the down release position.
4.4 | LIFTING AND TIEDOWN POINTS
Tie-down points are provided for securing the machine on a trailer or truck bed for transport between places of use.
They may also be used as lift points.
DO NOT OVERLOAD BINDERS WHEN SECURING
LOAD FOR TRANSPORT
FIGURE 7: Brake Release
WARNING
