Hy-Brid Lifts I Series Use and care manual

BY CUSTOM EQUIPMENT LLC
OPERATIONS & SAFETY MANUAL
PUSH-AROUND AERIAL WORK PLATFORM
SUPO-723
REV C
HB-P527
SERIES I

NOTES
If there is a question about application
and/or operation, contact:
Custom Equipment, LLC.
2647 Hwy 175
Richfield, WI 53076
U.S.A.
P: [phone]
F: [phone]
www.hybridlifts.com
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
2

Original instructions written in English.
The purpose of this Operations and Safety manual is to provide users with the instructions and operating procedures
essential to properly and safely operate the Custom Equipment Hy-Brid Lift for its intended purpose, and to position
personnel and their necessary tools and materials.
THE OPERATION AND SAFETY MANUAL MUST BE READ AND
UNDERSTOOD PRIOR TO OPERATING THE MACHINE.
• The user/operator should not accept operating responsibility until the manual has been read and understood as
well as having operated the lift under supervision of an experienced and qualified operator.
• Because the manufacturer has no direct control over machine application and operation, proper safety
practices are the responsibility of the user and all operating personnel.
ANY MODIFICATION ON THIS MACHINE WITHOUT THE EXPRESS
WRITTEN CONSENT OF THE MANUFACTURER IS PROHIBITED.
Fall protection notice:
The guardrail system around the perimeter of the platform is the fall protection system for push-around elevating
work platforms per the ANSI/SIA A92.3 Standard. It is prohibited to use an Aerial Work Platform manufactured
by Custom Equipment, LLC. With any portion—or all—of the guardrails removed. Lanyard anchorage points on
this type of equipment are not required to conform to the applicable standard. However, if anchorage points for
lanyard attachments are required by site authorities or other regulations, the anchorage points on all equipment
manufactured by Custom Equipment, LLC. Are recommended to be used for work positioning restraints of
personnel only. Lanyard lengths are to be determined by operator/owner to restrict the operator to the confines
within the guardrail system.
USE OF FALL ARREST SYSTEMS ATTACHED TO ANCHORAGE POINTS ON
EQUIPMENT MAY CAUSE MACHINE TO TIP, RESULTING IN SERIOUS INJURY OR DEATH.
FOREWORD
DANGER
WARNING
WARNING
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
3

NOTES.......................................................................................................................................................................................... 2
TABLE OF CONTENTS............................................................................................................................................................... 4
INDEX OF FIGURES.................................................................................................................................................................... 5
SECTION 1 | SAFETY .................................................................................................................................................................. 6
1.1 | SAFETY SYMBOLS.......................................................................................................................................................................... 6
1.2 | GENERAL RULES AND PRECAUTIONS ................................................................................................................................... 6
1.3 | SAFETY FEATURES ........................................................................................................................................................................ 7
1.4 | SAFETY CONTROLS ..................................................................................................................................................................... 7
1.5 | MAINTENANCE LOCK .................................................................................................................................................................8
1.6 | SAFETY GUIDELINES.................................................................................................................................................................... 9
SECTION 2 | PRODUCT DESCRIPTION................................................................................................................................ 10
2.1 | GENERAL....................................................................................................................................................................................... 10
2.2 | STANDARDS CONFORMITY .................................................................................................................................................... 10
2.3 | MACHINE SPECIFICATIONS.................................................................................................................................................... 10
SECTION 3 | DECALS............................................................................................................................................................... 12
3.1 | DECAL LOCATION...................................................................................................................................................................... 12
3.2 | DECAL DESCRIPTIONS............................................................................................................................................................. 13
SECTION 4 | TRANSPORT HANDLING & STORAGE .......................................................................................................... 14
4.1 | PRELIMINARY UNPACKING AND DEALER INSPECTION ................................................................................................. 14
4.2 | STORAGE...................................................................................................................................................................................... 14
4.3 | TRANSPORTATION .................................................................................................................................................................... 14
4.4 | LIFTING AND TIEDOWN POINTS......................................................................................................................................... 14
4.5 | FORK LIFT POCKETS ................................................................................................................................................................. 15
SECTION 5 | OPERATION ....................................................................................................................................................... 16
5.1 | PRESTART INSPECTION.......................................................................................................................................................... 16
5.2 | CONTROLS.................................................................................................................................................................................. 16
5.3 | STARTUP/SHUT DOWN ............................................................................................................................................................17
5.4 | ELEVATING AND LOWERING ...................................................................................................................................................17
SECTION 6 | DAILY MAINTENANCE...................................................................................................................................... 18
6.1 | CHARGING THE BATTERY ....................................................................................................................................................... 18
SECTION 7 | PRE-START INSPECTION CHECKLIST...........................................................................................................20
7.1 | PRESTART INSPECTION CHECKLIST ...................................................................................................................................20
NOTES........................................................................................................................................................................................22
TABLE OF CONTENTS
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
4

INDEX OF FIGURES
FIGURE 1: E-Down Location .................................................................................................................................................................. 7
FIGURE 2: E-Down Symbol .................................................................................................................................................................... 7
FIGURE 3: Maintenance lock use..........................................................................................................................................................8
FIGURE 4: Maintenance lock storage.................................................................................................................................................. 8
FIGURE 5: Decal Locations................................................................................................................................................................... 12
FIGURE 6: Rear Brakes........................................................................................................................................................................... 14
FIGURE 7: Tie-Down Points.................................................................................................................................................................. 14
FIGURE 8: Center of gravity ................................................................................................................................................................. 15
FIGURE 9: Base Controls....................................................................................................................................................................... 16
FIGURE 10: Platform Controls ............................................................................................................................................................. 16
FIGURE 11: Master Power Switch.........................................................................................................................................................17
FIGURE 12: Battery Charger LED Display.......................................................................................................................................... 19
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
5

SECTION 1 | SAFETY
1.1 | SAFETY SYMBOLS
Warnings and instructions that have a direct impact on safety are identified with the following signals:
FAILURE TO FOLLOW THIS WARNING WILL CAUSE
DEATH OR PERSONAL INJURY.
“DANGER” indicates an imminently hazardous situation,
which, if not avoided, will result in death or serious
injury.
FAILURE TO FOLLOW THIS WARNING MAY CAUSE
DEATH OR PERSONAL INJURY.
“WARNING” indicates a potentially hazardous situation,
which, if not avoided, could result in death or serious
injury.
FAILURE TO FOLLOW THIS WARNING MAY CAUSE
INJURY OR DAMAGE TO EQUIPMENT
“CAUTION” indicates a potentially hazardous situation
which, if not avoided, could result in minor or moderate
injury or damage to equipment.
1.2 | GENERAL RULES AND PRECAUTIONS
Custom Equipment, LLC designed the Hy-Brid Lift push-around scissor lift to be safe and reliable. It is intended for
elevating personnel, along with their necessary tools and materials to overhead work locations. Vibration does not
create significant hazards on this machine.
An operator of any type of work platform is subject to certain hazards that cannot be protected by mechanical
means. It is therefore essential that operators be competent, careful, physically and mentally fit, and thoroughly
trained in safe operation of this machine. Although Custom Equipment, LLC conforms to specified ANSI & OSHA
requirements, it is the responsibility of the owner to instruct operators with the safety requirements made not only
by Custom Equipment, LLC, but by the various safety boards in your area, as well as additional requirements set
forth by ANSI & OSHA If you come across a situation that you think might be unsafe, stop the platform and request
further information from qualified sources before proceeding.
NEVER REACH BETWEEN SCISSOR LINKS OR PROP UP PLATFORM
DANGER
CAUTION
WARNING
WARNING
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
6

SECTION 1 | SAFETY
WHEELS EXTENDING BEYOND THE SIDES OF THE BASE MAY OCCUR IN TIGHT TURNING SITUATIONS.
1.3 | SAFETY FEATURES
• Puncture-proof wheels.
• Guardrails—43.83 in height with 6 in kick plates
• Non-slip deck.
• Entrance gate.
• Automatic brake when elevated
• Free descent protection. A pressure compensated flow control valve is installed in the hydrau-lic circuit to
prevent the platform from descending in case of a ruptured hydraulic hose. The platform is hydraulically locked
with a check valve and has controlled descent when valve activates.
• Decals. Danger, Caution, and Warning decals are displayed at various locations on this unit
• Key Switch Security. A key switch is required to prevent unauthorized use.
1.4 | SAFETY CONTROLS
Descent — Manual Override
For manually lowering the scissors, a manual valve is provided. To lower the scissors, pull the cable located near the
front of the machine.
FIGURE 1: E-Down Location FIGURE 2: E-Down Symbol
CAUTION
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
7

SECTION 1 | SAFETY
IF PLATFORM SHOULD FAIL TO LOWER, DO NOT ATTEMPT TO
CLIMB DOWN THE BEAM ASSEMBLY. SERIOUS INJURY MAY
RESULT. HAVE AN EXPERIENCED OPERATOR USE THE EMERGENCY
LOWERING PROCEDURE TO SAFELY LOWER THE PLATFORM.
Emergency Stop
This lift is equipped with two emergency stop switches, one at the platform control and one at the base control,
that when activated, will render the unit inoperable until reset. To reset, pull the button out.
PUSHING THE EMERGENCY STOP BUTTON WILL STOP
MOVEMENT IMMEDIATELY. THIS MAY CAUSE UNEXPECTED
PLATFORM MOVEMENT AS THE MACHINE COMES TO A SUDDEN
STOP. BRACE YOURSELF AND SECURE OBJECTS ON THE
PLATFORM DURING OPERATION OF THE MACHINE.
1.5 | MAINTENANCE LOCK
The maintenance lock must be placed into position whenever the machine is being serviced in a partially raised
position. Serious injury and/or death could result if maintenance lock is not used properly.
FIGURE 3: Maintenance lock use FIGURE 4: Maintenance lock storage
WARNING
WARNING
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
8

SECTION 1 | SAFETY
1.6 | SAFETY GUIDELINES
Only qualified operators may operate this unit.
• All operators must read and understand the Operation and Safety Manual. They must understand all decals and
warning labels on unit.
• Do not work on platform if your physical condition is such that you feel dizzy or unsteady in any way.
• Do not neglect/misuse machine. Report any misuse of equipment to proper personnel.
• Prevent unauthorized use; when unit is not in use, remove key.
• It is recommended all personnel on unit wear approved personal protective equipment (PPE), i.e. head gear.
Use machine only for purposes for which it was intended.
• Lift should never be used as a crane.
• Do not exceed the load capabilities of the platform.
• Distribute load evenly over platform floor area.
• Never use unit as electrical grounds for arc welding.
• Do not override any hydraulic, mechanical, or electrical safety devices.
Check job site for unsafe working conditions.
• Watch out for others. Keep others clear of operating platform. Never allow others to pass under a raised
platform or position the platform over someone.
• Avoid contact with fixed (buildings, etc.) or moving (vehicles, cranes, etc.) objects. Check work area for
overhead obstructions or possible hazards.
• Follow any applicable national trac regulations.
• Use indoors only. Lift is not designed for windy conditions or electrical storms.
• Unit must be on hard level surface before elevating. Do not operate on incline or uneven surface.
• You must maintain a clearance between any part of the machine, or its load, and any electrical line or apparatus.
Follow local power line clearance regulations.
• You must maintain a clearance between any part of the machine, or its load, and any electrical line or apparatus.
Follow local power line clearance regulations.
•
DO NOT OPERATE MACHINE NEAR POWER-LINES. THE
PLATFORM AND ENCLOSURES ARE NOT INSULATED.
EQUIPMENT IS ONLY AS SAFE AS OPERATOR.
Do not use ladders or scaolding on the platform to obtain greater height.
• Do not enter or exit platform while machine is in motion.
• Never mount or dismount a raised platform.
• Make sure entry gate is secured before operating machine from the platform.
• Never belt or tie o to an adjacent structure.
• Secure tools and materials.
• Personnel must maintain a firm footing on the platform floor and work only within the platform area.
• Before operation, ensure that the machine is properly serviced.
• Do not use machine if it is not working properly.
• Make sure platform rails and pins are secured.
• Operator shall use the maintenance lock when performing all types of maintenance procedures.
• Do not smoke while charging the battery.
DANGER
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
9

SECTION 2 | PRODUCT DESCRIPTION
2.1 | GENERAL
Custom Equipment’s Hy-Brid Scissor Lift is an aerial work platform designed to be safe and reli-able. The purpose
of the machine is to elevate personnel, along with their necessary tools and materials. The machine is intended for
indoor use (no wind load). Manufacturer approval is required for any use other than the intended use.
2.2 | STANDARDS CONFORMITY
Model HB-P527 S1 has been assessed, tested and approved in accordance with the requirements of ANSI/SIA A92.3-
2006 and CAN-SCA B354.1-04-2005.
Manufacturer:
Custom Equipment, LLC
2647 Hwy 175
Richfield, WI 53076
USA
Phone: [phone]
Fax: [phone]
www.hybridlifts.com
2.3 | MACHINE SPECIFICATIONS
Working Height (maximum) 11.3 ft. 3.4 m
Platform Height (maximum) 5.3 ft. 1.6 m
Platform Height (minimum) 20.3 in. 51.5 cm
Stowed Height 63.6 in. 161.5 cm
Ground Clearance Lowered 2.5 in. 6.4 cm
Overall Length 41.0 in. 104.1 cm
Overall Width 26.6 in. 67.6 cm
Platform Length (Retracted, Inside) 37.0 in. 94.0 cm
Platform Width (Retracted, Inside) 22.0 in. 55.9 cm
Platform Extension N/A in. N/A cm
Guard Rail Height 43.8 in. 111.3 cm
Step Height 20.3 in. N/A cm
Wheel Base 33.1 in. 84.1 cm
Wheel Track 22.1 in. 56.2 cm
Tire Size -Front 8.0 in. 20.3 cm
Tire Size -Rear 8.0 in. 20.3 cm
Turning Radius (Inside) ZERO IN. ZERO CM
Turning Radius (Outside) 39.4 IN. 100 CM
Gradeability (Stowed Position) N/A N/A N/A N/A
Drive Speed Max (Platform Elevated) N/A N/A N/A N/A
Drive Speed Max (Platform Lowered) N/A N/A N/A N/A
Lift/Lower Speed 9/12 SEC 9/12 SEC
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
10

Power System-Voltage 12V DC
Batteries-Deep Cycle Marine (1) 12V GROUP 24 AGM
Hydraulic Pressure (max) 650.0 psi 4481.6 kPa
Hydraulic Fluid Capacity 0.3 gal 1.2 L
Platform Capacity 500.0 lb. 226.8 kg
Rated Occupancy 1.0 Persons 1.0 Persons
Extension Capacity N/A N/A N/A N/A
Horizontal/Manual Force 45.0 LB 200 N
Wind INDOOR USE ONLY/NO WINDY CONDITIONS
Rated Slope LEVEL SURFACE
Tilt Sensor Activated N/A
Temperature -4°F to -104°F -20°C to 40°C
Vibration 8.2 ft / s2 max 2.5 m / s2 max
Sound 86 dB Normal Use/100 dB Alarms
Machine Weight (Unloaded) (Approx.) 575.0 lb. 260.8 kg
Minimum Wheel Load-Contact
Pressure 115.0 psi 792.9 kPa
Maximum Wheel Load-Contact
Pressure 215.0 psi 1482.4 kPa
Minimum Machine Loading-Floor
Pressure 75.8 psf 3.6 kPa
Maximum Machine Loading-Floor
Pressure 141.9 psf 6.8 kPa
SECTION 2 | PRODUCT DESCRIPTION
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
11

SECTION 3 | DECALS
3.1 | DECAL LOCATION
FIGURE 5: Decal Locations
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
12

SECTION 3 | DECALS
3.2 | DECAL DESCRIPTIONS
Item # Part # Decal Meaning or Designation Comments Qty Superseded By
1 143-21-006-50-K DECALS,HB-P527 DECAL SET 1
2 DE674 DECAL,HYDR FLUID 1
3 DE673 DECAL,HYDR FLUID 1
4 DE727 DECAL,KEEP 2
5 DE728 DECAL,CLEAR 2
6 DE600E-14 DECAL,MAINT LOCK 1
7 DE600E-29 DECAL,E-DOWN Superseded; 1 DE751
7 DE751 DECAL,E-DOWN CABLE 1
8 DE613 DECAL,LANYARD ATTACHMENT Superseded; 1 DE746
8 DE746 DECAL,LANYARD ATTACHMENT 1
9 DE666 DECAL, LWR 1
10 DE675 DECAL,NO FORK 1
11 DE706 DECAL,UPR HB 1
12 DE726 DECAL,CAPACITY,500#,1P,I,WO/SO 1
13 DE730 DECAL,OL ALARM 1
14 DE603-14 MODEL# DECAL-HB-P527 2
15 DE760 DECAL,E-STOP HANDLE 1
16 DE601 DECAL,LOGO HY-BRID Superseded; 1 DE821
16 DE821 DECAL,LOGO HY-BRID 1
17 DE851 DECAL,PF HOLE WARNING 2
18 DE669 DECAL, CONTROL UPR D04-10024-D04-19999 1
18 DE738 DECAL, CONTROL UPR D04-10000-D04-10023 1
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
13

SECTION 4 | TRANSPORT HANDLING & STORAGE
4.1 | PRELIMINARY UNPACKING AND DEALER INSPECTION
Maintenance locks must be engaged prior to inspecting or servicing the unit when the platform is elevated.
Inspect machine for any possible damage during shipment; perform a pre-delivery inspection. See checklist in the
Maintenance Manual. Reset emergency stop switches, if necessary.
4.2 | STORAGE
After periods of storage, exposure to extremes of ambient conditions-heat, cold, moisture, dust etc., inspect the
machine. Refer to the Pre-Delivery/ Frequent Inspection Checklist in the Maintenance Manual.
4.3 | TRANSPORTATION
Lower the work platform to the down position. Turn key switch to o position. For safety and controlled handling,
it is not recommended to move the unit on a slope greater than 5°. Check entire machine for loose or unsecured
items. Remove any loose items from machine. Apply manual brake lock on rear wheels.
B
FIGURE 6: Rear Brakes
4.4 | LIFTING AND TIE-DOWN POINTS
Lower the work platform to the down position. Turn key switch to o position. For safety and controlled handling,it
is not recommended to move the unit on a slope greater than 5°. Check entire machine for loose or unsecured
items. Remove any loose items from machine. Apply manual brake lock on rear wheels. Tie-down points are
provided in the front and rear of the machine for securing the machine on a trailer or truck bed for trans-port
between places of use. They may also be used as lift points.
FIGURE 7: Tie-Down Points
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
14

SECTION 4 | TRANSPORT HANDLING & STORAGE
4.5 | FORK LIFT POCKETS
Fork lift pockets are provided on the side of the unit for loading and unloading. Do not use a forklift under-neath the
machine from the back. When moving machine with a forklift, do not let machine slide along floor. Bring forklift to
a stop and then gently lower the machine.
Center of gravity
FIGURE 8: Center of gravity
Center Of Gravity X Axis Y AXIS
HB-P527 21.5 in. 15 in.
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
15

5.1 | PRE-START INSPECTION
Before use each day or at the beginning of each shift, the machine shall be given a visual inspection and functional
test. Repairs (if any) must be made prior to operating the machine, as it is critical to ensure safe operation of the
machine. A checklist for pre-start inspection can be found in the back of this manual.
5.2 | CONTROLS
SECTION 5 | OPERATION
Item # Control/Indicator
1 Master Power Switch/Emergency Stop
FIGURE 9: Base Controls
Item # Control/Indicator
1Up/Down Rotary Switch
Operation described as follows
2Emergency Stop
Operation described in Section 2.4
3 Overload Indicator Light
4 Battery Voltage Meter
5Lift Enable Button
Operation described as follows
6 Alarm Sounds for descent, overload
FIGURE 10: Platform Controls
1
2
3
45
6
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
16

SECTION 5 | OPERATION
5.3 | STARTUP/SHUT DOWN
• Check that the work area is safe.
• It is not recommended to maneuver the unit on a slope greater than 5°.
• Check that master power switch is in “ON” position.
• Ensure that the key in the lower control panel is in the “ON” position for the chassis or platform control.
• Machine must be on a hard, level, surface before operation.
• Check that bubble level is centered.
• Engage the manual brakes on the rear casters before elevating the platform.
• Enter the work platform in the stowed position using the constant three point contact method.
• Follow all general rules and precautions stated in this manual.
• When finished with the machine, place the platform in the stowed position.
• Carefully exit the platform using the constant three point contact method.
• NEVER JUMP OFF THE PLATFORM
• Park the machine on a level surface.
• Turn master power switch to o position.
• To prevent unauthorized use, remove the key from the master power switch.
• The key may be placed in the manual pouch and the cabinet padlocked to secure the machine in the isolated
position.
THE OPERATOR MUST BE AWARE OF THE ENVIRONMENT.
DO NOT RAISE THE PLATFORM IF THE MACHINE IS NOT ON
A FIRM, LEVEL SURFACE.
5.4 | ELEVATING AND LOWERING
Using Upper Platform Controls
Make sure the platform controls are selected with the selector switch at the base controls. To raise or lower the
platform, press the Elevate/Lower Enable Button. While holding down the Enable Button, rotate and hold the
Elevate/Lower switch until the platform is in the desired position.
FIGURE 11: Master Power Switch
DANGER
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
17

SECTION 6 | DAILY MAINTENANCE
FAILURE TO PERFORM INSPECTIONS AND PREVENTATIVE MAINTENANCE AT RECOMMENDED
INTERVALS MAY RESULT IN THE UNIT BEING OPERATED WITH A DEFECT THAT MAY RESULT IN
INJURY OR DEATH OF THE OPERATOR. REGULAR INSPECTION AND CONSCIENTIOUS MAINTENANCE
IS IMPORTANT TO EFFICIENT ECONOMICAL OPERATION OF THIS MACHINE. IT WILL HELP TO
ASSURE THAT EQUIPMENT WILL PERFORM SATISFACTORILY WITH A MINIMUM OR SERVICE AND
REPAIR. MAKE CHECKS AT THE STATED INTERVALS OR MORE FREQUENTLY IF REQUIRED BY LOCAL
OPERATING CONDITIONS. A PRE-START INSPECTION CHECKLIST IS INCLUDED IN THIS MANUAL.
Additional maintenance for use by trained personnel is included in a separate Maintenance Manual. Refer to the
Maintenance Manual for Pre-Delivery/Frequent and Monthly Checklists and replace-ment part information.
6.1 | CHARGING THE BATTERY
This unit is equipped with a deep cycle 12-volt battery. The care and maintenance of your battery has much to do
with how well this unit functions. Battery wiring should be checked monthly.
NOTE: The surrounding temperature greatly aects the power reserve within a battery.
EXAMPLE: A battery that is 100% charged at 80° F (27°C) drops to 65% at 32°F (0°C). At 0°F (-18°C), this battery will
drop to 40% eciency.
LEAD-ACID BATTERIES GENERATE EXPLOSIVE GASES. KEEP
SPARKS AND FLAME AWAY FROM BATTERIES. DO NOT
SMOKE WHILE CHARGING.
Do not operate unit while charging. Shortened battery life will result.
To Charge:
• Park the machine on a level surface.
• Plug charger into AC outlet until charged.
• For best battery life, leave charger plugged in until machine will be used again. The charger will maintain the
battery charge.
• The charger will not begin the charging cycle on severely discharged batteries.
DO NOT OPERATE UNITE WHILE CHARGING
NEVER ADD ACID TO THE BATTERY
DANGER
CAUTION
WARNING
WARNING
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
18

FIGURE 12: Battery Charger LED Display
Battery solution is at its proper strength when the battery is manufactured. Use distilled water and keep fluid up to
proper level. When required, water should be added to battery after charging, unless water level is below the plates.
Reading the battery displays
This display indicates that the power is on but there is no connection to a
battery. The charger must see approximately five (5) volts on a battery to
deliver D/C current.
This display indicates that power is on and that both outputs are delivering
D/C current to the batteries
This display indicates that power is on and that the output is finished
charging and is in a float maintenance model.
SECTION 6 | DAILY MAINTENANCE
POWER BATTERY 1 STATUS
CHARGING READY
Green LED
(ON)
Red LED
(OFF)
Green LED
(ON)
Green LED
(ON)
Red LED
(ON)
Green LED
(OFF)
Green LED
(ON)
Red LED
(OFF)
Green LED
(ON)
POWER BATTERY 1 STATUS
CHARGING READY
POWER BATTERY 1 STATUS
CHARGING READY
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
19

SECTION 7 | PRE-START INSPECTION CHECKLIST
7.1 | PRE-START INSPECTION CHECKLIST
Y-Yes/Acceptable N-No/Unacceptable R-Repaired Y N R
VISUAL INSPECTIONS
Check that there are no damaged, dented, or bent structural members □ □ □
There are no loose or missing parts. □ □ □
Check that warning and instructional labels are legible and secure. Ensure the load capacity is clearly
marked.
□ □ □
Check the platform rails and safety gate for damage. □ □ □
Platform and base controls are not missing, damaged, frayed, or disconnected. □ □ □
Hydraulic hoses are not torn or loose, and there are no leaks. Check that hoses and cables have no
worn areas or chafing. □ □ □
Check the tires for damage. □ □ □
Check that all snap rings are secure in grooves on pivot pins. □ □ □
FUNCTIONAL TESTS
Gate closes automatically and latches (alignment can be adjusted with screw-on toe board or railing). □ □ □
Platform Controls: Check all switches and push buttons for proper operation.
Emergency Stop (Stops all movement) □ □ □
Up/Down Controls (Elevates, Lowers, Enable button must be pressed). □ □ □
Base Controls: Check all switches and push buttons for proper operation.
Emergency Stop (Stops all movement) □ □ □
Key Switch (Selects Platform Control, Ground Control, or O). □ □ □
Alarm (Not damaged, sounds for descent). □ □ □
Up/Down Rocker Switch (Elevates/Lowers). □ □ □
Wheels: Front and rear wheels rotate freely. □ □ □
Brakes engage and hold when platform is elevated. □ □ □
Date: Inspected by:
Model: Serial Number:
• Keep inspection records up-to-date.
• Record and report all discrepancies to your supervisor.
• A dirty machine cannot be properly inspected.
THIS CHECKLIST MUST BE USED AT THE BEGINNING OF EACH SHIFT OR
AFTER EVERY SIX TO EIGHT HOURS OF USE. FAILURE TO DO SO COULD
AFFECT THE SAFETY OF THE OPERATOR.
Pre-start Inspection (Push-Around Models)
WARNING
OPERATIONS & SAFETY
HB-P527
SUPO-723
REV C
B Y C U S TO M EQUIPME NT LLC
20
