Hybrid+ HMH 150 User manual

User Manual
Please read the instructions carefully before use

Please read the instructions carefully which includes important information about
the installation, usage and maintenance.
Safety Instructions
WARNING
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
will not accept liability for any resulting defects or problems.
Unpack and check carefully that there is no transportation damage before using the unit.
The unit is for indoor use only. Use only in a dry location.
DO install and operate by qualified operator.
DO NOT allow children to operate the fixture.
Use safety chain when fixing the unit. Handle the unit by carrying its base instead of headonly.
The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces.
Be sure that no ventilation slots are blocked, otherwise the unit willoverheat.
Before operating, ensure that the voltage and frequency of the power supply match the power
requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
The maximum ambient temperature is TA: 40℃. DO NOT operate it when the temperature is higher.
DO NOT connect the device to any dimmer pack.
During initial start-up some smoke or a smell may arise. This is a normal process and does not
necessarily mean that the device is defective. It will decrease gradually within 15 minutes.
Make sure there are no flammable materials close to the unit while operating to avoid a fire hazard.
Examine the power wires carefully; replace them immediately if there is any damage.
The Unit’s surface temperature may reach up to 85℃. DO NOT touch the housing bare-handed
during its operation. Allow about 15 minutes for cooling the unit down before replacing bulb or
maintenance as it could be very hot.
Avoid any flammable liquids, water or metal objects entering the unit. If this happens, cut off

the main power suppy immediately.
DO NOT operate in dirty or dusty environments. Clean fixtures regularly.
DO NOT touch any wire during operation as there might be a hazard of electric shock.
DO NOT let cables twist together.
The minimum distance between light output and the illuminated surface must be more than 12
meters.
Disconnect main power supply before fuse/lamp replacement or servicing.
Replace fuse/lamp only with the same type.
In the event of serious operating problem, stop using the unit immediately.
Never turn the unit on and off repeatedly .
The housing, the lenses, or the ultraviolet filter must be replaced if they are visiblydamaged.
DO NOT open the unit as there are no user serviceable parts inside.
Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage
or malfunction. Please contact the nearest authorized technical assistance center ifneeded.
Disconnect the main power supply if the fixture is has not been used for a long time.
Use the original packing materials before transporting it again.
Cautions:
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
Hot lamp explosion hazard. DO NOT open the unit within 15 minutes after switching off.
Replace the bulb once it is damaged, deformed or life-expired.
DO NOT look directly at the light while the bulb is on.
Never touch bulb with bare fingers, as it is very hot after use.
DO NOT turn on the unit without bulb enclosure or when housing is damaged.
Installation:
The unit is fully operational in three different mounting positions, hanging upside-down from a ceiling
or set on a flat level surface. To avoid internal damage to the unit, never mount the unit on its side as
illustrated above. Be sure this fixture is kept at least 0.5m away from any flammable materials
(decoration etc.). Always use and install the supplied safety cable as a safety measure to prevent
accidental damage and/or injury in the event the clamp fails.

Technical Specifications
Power supply
- AC 100~240V 50/60Hz
Power Consumption
- 200W
Light Source
- 1 X 150W LED
Angle
Rotating Gobo: 12°23°(with zoom lens)
Movement
- Pan: 540°
- Tilt: 270°
-Pan/Tilt moving speed adjustable.
-Automatic Pan/Tilt correction.
-Easy calibration and maintenance by magnetic home positioning.
Dimmer/Shutter
-Blackout, 0~100% smooth dimming, independent shutter and various strobe effect.
Colour wheel
-8 fixed colours plus white
-Rainbow effect in both directions.
Gobo wheel
1 Rotating gobo wheel with 7 gobos plus open
Prism
-Prism : 6 facet prism and comet prism rotating in both directions
Focus
-Motorized focus
Zoom
-Motorized linear zoom system
Protocols
-DMX 512
-Date input/output: 3/5 Pin XLR socket
-Weight 12 Kg

Turn on the unit, press the MENU button, and press the UP/DOWN button until the required function
is shown on the monitor. Select the function by the ENTER button. Use the UP/DOWN button to
choose the submenu, press the ENTER button to store and automatically return to the last menu.
The main functions are shown below (the grey boxes are preset settings）:
Home Position Adjustment
Address
001
DMX address set
Run Mode
DMX 15CH/9CH
9/15 channels select
Slave
Slave 1-Slave 4
Auto
Auto mode
Sound
Sound mode
IR
None
Manual
-----Pan----------------0~255
Pan movement 0-540 degrees
-----Pan Fine-----------0~255
Tilt movement 0-270 degrees
-----Color--------------0~255
Select Colour options
-----Gobo---------------0~255
Select Gobo options
-----Gobo Rotate------0~255
Rotate gobo
-----Prism---------------0~255
Select prism and rotate
-----Focus---------------0~255
Manual adjust focus
-----Zoom--------------0~255
Manual adjust Zoom
-----Dimmer--------------0~255
Set dimmer value
-----Shutter----------0~255
Set shutter and strobe
Setup
Pan Reverse---------------YES/NO
Pan normal or Reverse
Tilt Reverse--------------YES/NO
Tilt normal or Reverse
Screen Reverse------------YES/NO
Display normal or Reverse
Pan Angle------------540/360/180
Pan angle selection
Tilt Angle------------270/180/90
Tilt angle selection
Totem mode----------
OFF/UP/DOWN
Set pan/tilt angle
Sensitivity--------0-100
Set sound sensitivity
Reset---------YES/NO
Reset the device
Factory Set---------YES/NO
Load factory default
SysInfo
Ver: V1.0
Software version
Running Mode: DMX
Current running mode
DMX Address: 001
Current dmx address
Temperature: Open
None

Press the MENU button for about 3 seconds into offset mode to adjust the home position. Press the
UP/DOWN button to select the password <2323>, press the ENTER button to confirm
.
Connection
D MX 51 2 CO NT RO LL ER
DMX OUT
PARAMETER
DEFAULT
FUNCTION
PAN
128
PAN MOTOR
TILT
128
TILT MOTOR
COLOUR
128
COLOUR WHEEL
GOBO
128
GOBO WHEEL
GOBO ROTATE
128
GOBO ROTATION
PRISM
128
PRISM SELECTION
PRISM I
128
PRISM ROTATION
FOCUS
128
FOCUS SELECTION
ZOOM
128
ZOOM SELECTION
DIMMER
128
DIMMER SELECTION

ATTENTION
Termination reduces signal errors and to avoid signal transmission problems and
interference. It is always advisable to connect a DMX terminal (Resistance 120 ohm 1/4W
between pin2 (DMX-) and pin3 (DMX+) of the last fixture).
1.At the last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W
resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output
of the last unit.
2.Connect the unit together in a “daisy chain” plug the XLR cable from the output of the unit to the
input of the next unit. The cable cannot be branched or split to a “Y” cable. DMX 512 is a very high-
speed signal. Inadequate or damaged cables, soldered joints or corroded connectors can easily
distort the signal and shut down the system.
3.The DMX output and input connectors are pass-through to maintain the DMX circuit, when one of
the units’ power is disconnected.
4.Each lighting unit needs to have a DMX address to receive the data by the controller. The address
number is between 0-511 (usually 0 & 1 are equal to 1).
5.The end of the DMX 512 system should be terminated to reduce signal errors.
6. 3 pin XLR connectors are more popular than 5 pins XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin4, Pin5 not used.
Address Setting
If you use a universal DMX controller to control the units, you have to set the DMX address from 1 to
512 so that the units can receive DMX signal.
Press the MENU button to enter menu mode, select DMX Functions. Press the ENTER button to
confirm, use the UP/DOWN button to select DMX Address. Press the ENTER button to confirm, the
present address will blink the display, use the UP/DOWN button to adjust the address from 001 to 512,

press the ENTER button to store. Press the MENU button to go back to the last menu or idling let the
unit idle for one minute to exit menu mode.
Please refer to the following diagram to address your DMX512 channel for the first 4 units.
Channel mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
9 channels
1
10
19
28
15 channels
1
16
31
46
DMX 512 Configuration
Please refer to below configurations to control the fixtures
Attentions:
1. The unit will maintain the last condition until reset if you cut-off the DMX signal.
2. For the channel Function, keep the value for about 5 seconds, then the corresponding function
will take into effect.
9 Channels :
Channel
Function
Value
1
Pan
0-255
0-540°
2
Tilt
0-255
0-270°
3
Colour
wheel
0-7
White
8-15
Colour 1
16-23
Colour 2
24-31
Colour 3
32-39
Colour 4
40-47
Colour 5
48-55
Colour 6
56-63
Colour 7
64
White
65-189
Colour wheel index
190-221
Counter-Clockwise rotation, fast to slow
222-223
Stop
224-255
Clockwise rotation, slow to fast
4
Gobo
wheel
0-7
Open
8-15
Gobo 1
16-23
Gobo 2
24-31
Gobo 3
32-39
Gobo 4
40-47
Gobo 5

48-55
Gobo 6
56-63
Gobo 7
64-71
Gobo 7 shake,slow to fast
72-79
Gobo 6 shake,slow to fast
80-87
Gobo 5 shake,slow to fast
88-95
Gobo 4 shake,slow to fast
96-103
Gobo 3 shake,slow to fast
104-111
Gobo 2 shake,slow to fast
112-119
Gobo 1 shake,slow to fast
120-127
Open
128-189
Counter-Clockwise rotation, fast to slow
190-193
Stop
194-255
Clockwise rotation, slow to fast
5
Gobo
Rotation
0-63
Index
64-145
clockwise rotation slow to fast
146-149
Stop
150-231
Counter-clockwise rotation slow to fast
232-255
Bounce slow to fast
6
Prism &
Prism
rotation
0-3
None
4-6
6 facet prism
7-65
6 facet prism clockwise rotation slow to fast
66-123
6 facet prism Counter-clockwise rotation slow to fast
124-127
6 facet prism
128-131
None
132-134
Comet prism effect
135-193
Comet prism clockwise rotation slow to fast
194-251
Comet prism Counter-clockwise rotation slow to fast
252-255
Comet prism effect
7
Focus
0-255
From far to near
8
Shutter
0-3
Closed
4-7
Open
8-76
slow to fast strobe
77-145
Pulse slow to fast
146-215
Random slow to fast
216-255
Open
9
Zoom
0-255
From narrow to wide

15 Channels :
Channel
Function
Value
1
Pan
0-255
0-540°
2
Pan 16bit
0-255
Pan fine 16bit
3
Tilt
0-255
0-270°
4
Tilt 16bit
0-255
Tilt fine 16bit
5
P/T Speed
0-255
Pan/Tilt speed from fast to slow
6
Colour
wheel
0-7
White
8-15
Colour 1
16-23
Colour 2
24-31
Colour 3
32-39
Colour 4
40-47
Colour 5
48-55
Colour 6
56-63
Colour 7
64
White
65-189
Color wheel index
190-221
Counter-Clockwise rotation, fast to slow
222-223
Stop
224-255
Clockwise rotation, slow to fast
7
Gobo
wheel
0-7
Open
8-15
Gobo 1
16-23
Gobo 2
24-31
Gobo 3
32-39
Gobo 4
40-47
Gobo 5
48-55
Gobo 6
56-63
Gobo 7
64-71
Gobo 7 shake,slow to fast
72-79
Gobo 6 shake,slow to fast
80-87
Gobo 5 shake,slow to fast
88-95
Gobo 4 shake,slow to fast
96-103
Gobo 3 shake,slow to fast
104-111
Gobo 2 shake,slow to fast
112-119
Gobo 1 shake,slow to fast
120-127
Open
128-189
Counter-Clockwise rotation, fast to slow
190-193
Stop
194-255
Clockwise rotation, slow to fast
8
Gobo
Rotation
0-63
Index
64-145
clockwise rotation slow to fast
146-149
Stop
150-231
Counter-clockwise rotation slow to fast

232-255
Bounce slow to fast
9
Prism &
Prism
rotation
0-3
None
4-6
6 facet prism
7-65
6 facet prism clockwise rotation slow to fast
66-123
6 facet prism Counter-clockwise rotation slow to fast
124-127
6 facet prism
128-131
None
132-134
Comet prism effect
135-193
Comet prism clockwise rotation slow to fast
194-251
Comet prism Counter-clockwise rotation slow to fast
252-255
Comet prism effect
10
Focus
0-255
From far to near
11
Dimmer
0-255
0-100%
12
Shutter
0-3
Closed
4-7
Open
8-76
slow to fast strobe
77-145
Pulse slow to fast
146-215
Random slow to fast
216-255
Open
13
Special
function
0-7
None
8-15
blackout while Pan/Tilt Moving
16-23
blackout while Colour changing
24-31
blackout while Gobo changing
32-39
blackout while Pan/Tilt Colour Moving
40-47
blackout while Pan/Tilt Gobo Moving
48-55
blackout while Pan/Tilt Colour Gobo Moving
56-87
None
96-103
Pan reset
104-111
Tilt reset
112-119
Colour wheel reset
120-127
Gobo wheel reset
136-143
Prism reset
144-151
Focus and Zoom reset
152-159
All reset
160-255
None
14
Pan&Tilt
Marco
0-7
None
8-23
Pan&Tilt Marco 1
24-39
Pan&Tilt Marco 2
40-55
Pan&Tilt Marco 3
56-71
Pan&Tilt Marco 4
72-87
Pan&Tilt Marco 5
88-103
Pan&Tilt Marco 6
104-119
Pan&Tilt Marco 7
120-135
Pan&Tilt Marco 8

136-151
Sound actived Pan&Tilt Marco 1
152-167
Sound actived Pan&Tilt Marco 2
168-183
Sound actived Pan&Tilt Marco 3
184-199
Sound actived Pan&Tilt Marco 4
200-215
Sound actived Pan&Tilt Marco 5
216-231
Sound actived Pan&Tilt Marco 6
232-247
Sound actived Pan&Tilt Marco 7
248-255
Sound actived Pan&Tilt Marco 8
15
Zoom
0-255
From narrow to wide

Troubleshooting
The following are a few common problems that may occur during operation. Here are some
suggestions for easy troubleshooting:
A. The unit does not work, it has no light and the fan does not work
1. Check the power cable is connected and main fuse.
2. Measure the main power supplys voltage on the main connector.
3. Check the power on LED to see if it can be lit up or not.
B. Not responding to DMX controller
1. The DMX LED should be on. If not, check DMX connectors, and the cables to see if they are linked
properly.
2. If the DMX LED is on and there is no response to the channel, check the address settings and
DMX polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the unit
or the previous one.
4. Try to use another DMX controller.
5. Check to see if the DMX cables run near or run alongside to high voltage cables, this may cause
damage or interference to DMX interface order.
C. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to the PCB is broken.
2. The motor’s drive IC on the PCB might be out of condition.
D. The lamp is cutting out intermittently
1. If the lamp is not working well, check to see if the main power supplys voltage is either too high or too
low.
2. Internal temperature may be too high. Check if replacement of fan is needed on the head.

Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically
to optimize light output. Cleaning frequency depends on the environment in which the fixture
operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the
unit’s optics.
Clean with soft cloth and use normal glass cleaning liquid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every30/60 days.
