Hydac OffLine Filter BiDirectional OLFBD Series User manual

OLFBD
OffLine Filter
BiDirectional
Installation and Maintenance Instructions
English • (Translation of original instructions)
Document No. : 3708828a • 11/30/2018
Follow these instructions for proper and safe use.
Keep for future reference.

1 | Imprint HYDAC FILTER SYSTEMS GMBH
2 / 52 MoWa OLFBD 3708828a en-us lq
1 Imprint
Manufacturer / publisher and responsible for the content:
Address of the manufacturer Contact address
HYDAC FILTER SYSTEMS
GMBH
Industriegebiet
66280 Sulzbach / Saar
HYDAC FILTER SYSTEMS
GMBH
Justus-von-Liebig-Str., Werk
20
66280 Sulzbach / Saar
Germany Germany
E-mail: [email protected]
Homepage: www.hydac.com
Court of Registration: Saarbrücken , HRB 17216
Executive Director: Mathias Dieter ,
Dipl.Kfm. Wolfgang Haering
Tab.1: Impressum
1.1 Documentation Representative
The contact data of the person authorized with the documenta-
tion is:
Mr. Günter Harge
c/o HYDAC International GmbH, Industriegebiet, 66280
Sulzbach / Saar
Germany
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Tab.2: Documentation Representative

HYDAC FILTER SYSTEMS GMBH Table of Contents
MoWa OLFBD 3708828a en-us lq iii
Table of Contents
1 Imprint ....................................................................................................................... 2
1.1 Documentation Representative........................................................................ 2
2 General ..................................................................................................................... 5
2.1 Warranty........................................................................................................... 5
2.2 © HYDAC FILTER SYSTEMS GMBH, 2018.................................................... 5
2.3 Using this manual............................................................................................. 6
3 General Safety Information ....................................................................................... 8
3.1 Signal words and their meaning in the general safety information................... 9
3.2 Design of Warning - / General Safety Information ......................................... 10
3.3 Safety symbols / pictograms .......................................................................... 10
4 Filter housing overview ........................................................................................... 12
4.1 Proper/designated use ................................................................................... 12
4.2 Improper Use or Use Deviating from Intended Use ....................................... 14
4.3 Checking the scope of delivery ...................................................................... 15
4.4 Decoding the model code label...................................................................... 15
4.4.1 TYpe code - Filter housing ................................................................ 17
4.4.2 Type code - Filter element................................................................. 17
4.5 Technical Data ............................................................................................... 18
4.6 Dimensions .................................................................................................... 20
4.7 Hydraulic diagram .......................................................................................... 22
4.8 Components................................................................................................... 23
5 Transporting / storing the filter housing................................................................... 25
6 Installation / commissioning .................................................................................... 26
6.1 Mechanical/hydraulic installation.................................................................... 26
6.1.1 Observing/calculating pressure loss.................................................. 29
6.2 Putting the filter housing into operation.......................................................... 31
7 Operation ................................................................................................................ 32

Table of Contents HYDAC FILTER SYSTEMS GMBH
iv MoWa OLFBD 3708828a en-us lq
8 Performing maintenance ......................................................................................... 33
8.1 Changing the filter element ............................................................................ 33
9 Rectifying errors ...................................................................................................... 39
10 Removing / Disposal ............................................................................................... 41
11 Annexes .................................................................................................................. 42
11.1 Locating spare parts....................................................................................... 42
11.2 Finding a Customer Service team.................................................................. 44
Glossary .................................................................................................................. 47
Index ....................................................................................................................... 48

HYDAC FILTER SYSTEMS GMBH General | 2
MoWa OLFBD 3708828a en-us lq 5 / 52
2 General
This manual was prepared to the best of our knowledge. Nev-
ertheless and despite the greatest care, it cannot be excluded
that mistakes could have crept in. Therefore, please under-
stand that, in the absence of any provisions to the contrary
hereinafter, our warranty and liability – for any legal reasons
whatsoever – are excluded in respect of the information in this
manual. In particular, we shall not be liable for lost profit or
other financial loss.
This exclusion of liability does not apply in cases of intent and
gross negligence. Moreover, it does not apply to defects which
have been deceitfully concealed or whose absence has been
guaranteed, nor in cases of culpable harm to life, physical in-
jury and damage to health. If we negligently breach any mate-
rial contractual obligation, our liability shall be limited to fore-
seeable damage. Claims due to the Product Liability shall re-
main unaffected.
2.1 Warranty
For the warranty provided by us, please refer to the Terms of
Delivery. They are made available to you at the conclusion of
the contract at the latest. You will also find these under
www.hydac.com -> General Terms and Conditions (T&C).
2.2 © HYDAC FILTER SYSTEMS GMBH, 2018
Distributing and copying this document and utilizing and dis-
closing its content is not permitted, except where this has been
agreed upon explicitly. Any infringement will entail liability for
damages. All rights reserved in the case of a patent being
granted or a utility model or the design being registered.
We reserve the right to changes to the contents of this manual
without prior notice.

2 | General HYDAC FILTER SYSTEMS GMBH
6 / 52 MoWa OLFBD 3708828a en-us lq
2.3 Using this manual
You will find the following information on the title page of this
manual:
Short name of the product
Product name
Operating and Maintenance Instructions
12345678 ● ##.##.####
English (translation of original instructions)
Valid from: - from s/no. - ... ... - ... ...
1
5
2
4
3
Fig.1: Overview / labeling of the title page
1 Short name of the product / product name
2 Type of document
3 Language
4 Document no./Index ● Date of printing
5 Supplementary instructions regarding the validity of the
manual (optional)
Please note that you can directly access information
through the directories. However, this does not re-
lease you from the obligation to read this manual
fully before commissioning.
The document no. with the index (4) is meant for identifying
and reordering the manual. The index is incremented every
time the manual is revised or changed.

HYDAC FILTER SYSTEMS GMBH General | 2
MoWa OLFBD 3708828a en-us lq 7 / 52
The manual contains a table of contents, a list of tables and
figures, an index and a glossary.
You will find the following symbols in the manual as additional
details:
Tip for handling the product
Required tools

3 | General Safety Information HYDAC FILTER SYSTEMS GMBH
8 / 52 MoWa OLFBD 3708828a en-us lq
3 General Safety Information
The product was built according to the statutory directives, reg-
ulations and standards valid at the time of delivery and satis-
fies current safety requirements. Any residual hazards are indi-
cated by the general safety information and are described in
this manual.
Observe all safety and warning instructions attached to the
product and keep them always complete and easily legible.

HYDAC FILTER SYSTEMS GMBH General Safety Information | 3
MoWa OLFBD 3708828a en-us lq 9 / 52
3.1 Signal words and their meaning in the general
safety information
In these instructions you will find the following signal words:
DANGER
DANGER – The signal word indicates a hazardous situation
with a high level of risk, which, if not avoided, will result lethal
or serious injury.
WARNING
WARNING – The signal word indicates a hazardous situation
with a medium level of risk, which, if not avoided, can result
lethal or serious injury.
CAUTION
CAUTION – The signal word indicates a hazardous situation
with a low level of risk, which, if not avoided, can result in mi-
nor or moderate injury.
NOTICE
NOTICE – The signal word indicates a hazardous situation
with a high level of risk, which, if not avoided, will result in
damage to property.

3 | General Safety Information HYDAC FILTER SYSTEMS GMBH
10 / 52 MoWa OLFBD 3708828a en-us lq
3.2 Design of Warning - / General Safety Information
All the warning / general safety information in this manual are
highlighted with pictograms and signal words. The pictogram
and the signal word give you an indication of the severity of the
danger.
Warning / general safety information, which are placed ahead
of each activity, are represented as follows:
CAUTION
Type and source of danger
Hazard symbol
Consequence of the danger
Measures to avert danger
►
3.3 Safety symbols / pictograms
The following are the safety symbols / pictograms in this man-
ual. They indicate specific dangers to persons, property or to
the environment. Observe these safety symbols / pictograms
and act with particular caution in such cases. Always keep all
symbols / pictograms intact and legible.
Danger point warning
Follow the instructions.
Danger due to operating pressure

HYDAC FILTER SYSTEMS GMBH General Safety Information | 3
MoWa OLFBD 3708828a en-us lq 11 / 52
Specialist personnel - Mechanic
Such persons have specific specialist training
and several years' work experience. They are
able to assess and perform the work assigned to
them, they are also able to recognize potential
hazards.

4 | Filter housing overview HYDAC FILTER SYSTEMS GMBH
12 / 52 MoWa OLFBD 3708828a en-us lq
4 Filter housing overview
The OffLineFilter BiDirectional OLFBD is a small filter housing
for the fine filtration of hydraulic and lubricating fluids. The di-
rection of flow through the filter element is freely selectable
(from inside to outside or vice versa). Areas of application in-
clude for example the filtration of hydraulic and lubrication sys-
tems in industrial and mobile hydraulics.
The advantages of the OLFBD are:
– Improvement of component and system filter lifetime.
– Any direction of flow through the filter element (from inside
to outside or vice versa).
– Flow rate is drawn for the OLFBD from the cooling filtration
circuit.
– The flow rate is limited by an orifice in the filter element
(no mechanically moving parts).
4.1 Proper/designated use
Use the filter housing only for the application described in the
following:
The OffLine Filter OLFBD filter housing is a stationary sec-
ondary bypass flow filter and is used for the purpose of sepa-
rating out water and solid particles from hydraulic and lubrica-
tion fluids.
Proper or designated use of the product extends to the follow-
ing:
– Observing all instructions contained in the instruction man-
ual.
– Performing inspection and maintenance work.

HYDAC FILTER SYSTEMS GMBH Filter housing overview | 4
MoWa OLFBD 3708828a en-us lq 13 / 52
NOTICE
Impermissible operating media/conditions
The filter will be damaged.
uThe filter is to be used only with mineral oils or mineral oil-
based raffinates.

4 | Filter housing overview HYDAC FILTER SYSTEMS GMBH
14 / 52 MoWa OLFBD 3708828a en-us lq
4.2 Improper Use or Use Deviating from Intended Use
DANGER
Danger from improper use or use deviating from intended use
Bodily injury
uThe filter unit is to be used only with permissible operating
media and only under the permissible operating condi-
tions.
Any use extending beyond this or deviating therefrom shall not
be considered intended use. HYDAC FILTER SYSTEMS
GMBH will assume no liability for any damage resulting from
such use. The user alone, shall assume any and all associated
risk.
Improper use may result in hazards and/or will damage the fil-
ter unit. Examples of improper use:
– Operation in the main flow.
– Operation under non-approved operational conditions.
– Modifications to the power unit made by the user or pur-
chaser.
– Improperly performed repair work.

HYDAC FILTER SYSTEMS GMBH Filter housing overview | 4
MoWa OLFBD 3708828a en-us lq 15 / 52
4.3 Checking the scope of delivery
The filter housing is supplied without installed filter element
and without installed attachment parts. Check the scope of de-
livery for completeness.
The following items are included in the scope of delivery:
Qty Designation
1 OffLineFilter BiDirectional OLFBD
1 Installation and Maintenance Instructions (this
document)
Tab.3: Scope of delivery
4.4 Decoding the model code label
For identification details of the filter housing, see the name
plate. Always mention the part no. and the serial no. when con-
tacting HYDAC.
Fig.2: Decoding the model code label
Item Description

4 | Filter housing overview HYDAC FILTER SYSTEMS GMBH
16 / 52 MoWa OLFBD 3708828a en-us lq
(1) The type label of the filter housing
(2) Type code for the filter housing
Part No. Part number
Serial number / year of production
Pressure max. Power consumption
Weight when empty
Seals Sealing material
Temp. oil Permitted fluid temperature range
Temp. amb. Permitted ambient temperature range
Volume Content

HYDAC FILTER SYSTEMS GMBH Filter housing overview | 4
MoWa OLFBD 3708828a en-us lq 17 / 52
4.4.1 TYpe code - Filter housing
The filter housing is defined by the following model code:
Filter type
Hydraulic connection
Installation size
OLFBD - 20 - A - N - Z
OLFBD = OffLineFilter BiDirectional
20 = 20
N = NBR
F = FKM
Sealing material
A = G1/4 in accordance with ISO 228
Clogging indicator
Z = Without clogging indicator
Fig.3: TYpe code - Filter housing
4.4.2 Type code - Filter element
The filter element is defined by the following model code:
Filter element type
Filter material
Installation size
EBD - 20 - EA - 005 - Z - 4
EBD
20 = 20
N = NBR
F = FKM
Filtration rating
EA = Standard
Sealing material
005 = 5 µm (other on request)
Orifice
4 = Standard (other on request)
Fig.4: Type code - Filter element

4 | Filter housing overview HYDAC FILTER SYSTEMS GMBH
18 / 52 MoWa OLFBD 3708828a en-us lq
4.5 Technical Data
The filter unit has the following technical data:
OLFBD
Permissible flow rate ≤5l/min
Permitted operating pres-
sure
25bar / 362PSI
Permitted suction pressure
at the inlet (IN)
≤25bar / ≤362PSI
Permitted suction pressure
at the outlet (OUT)
≤20bar / ≤290PSI
Connection (IN/OUT) See TYpe code - Filter housing
[}17]
Air bleed (VENT) G1/4 according to ISO 228
Draining (DRAIN) G1/4 according to ISO 228
Sealing material For NBR or FKM, see the type la-
bel
Filter housing material EN AW-6060 / Al MgSi
Permitted operating temper-
ature range
-10…80°C / 14…176°F
Permitted storage tempera-
ture range
5…40°C / 41…104°F
Permitted air humidity dur-
ing storage
≤80% relative humidity, non-
condensing
Permitted air during storage Clean, salt-free air, not near oxi-
dizing substances (rust film)
Storage duration Indefinite.
All seals must be replaced after
a storage period of ≥2years.
Number of filter elements 1
Filter element type EBDxxEAxxx-x-x
Filter housing volume ≈1liter

HYDAC FILTER SYSTEMS GMBH Filter housing overview | 4
MoWa OLFBD 3708828a en-us lq 19 / 52
OLFBD
Design service life If the service and maintenance
intervals are followed, the design
service life of the unit is not lim-
ited.
Weight when empty ≈3.5kg
Tab.4: Technical Data

4 | Filter housing overview HYDAC FILTER SYSTEMS GMBH
20 / 52 MoWa OLFBD 3708828a en-us lq
4.6 Dimensions
The filter housing has the following dimensions:
Fig.5: Dimensions of the filter housing
All dimensions in mm.
