Hydac Wombat Filter WBF User manual

WBF
Wombat Filter
Pmax = 16 bar
Installation and Maintenance Instructions
English (translation of original instructions)
Keep for future reference.
Document No.: 4031149a

Imprint
Imprint
Publisher and responsible for the content:
HYDAC FILTER SYSTEMS GMBH
Postfach 1251
66273 Sulzbach / Saarland
Germany
Telephone:
[phone]
Fax:
[phone]
E-mail:
[e-mail]
Homepage:
www.hydac.com
Court of Registration:
Saarbrücken, HRB 17216
Executive director:
Mathias Dieter, Dipl.Kfm. Wolfgang
Haering
Documentation Representative
Mr. Günter Harge
c/o HYDAC International GmbH, Industriegebiet, 66280 Sulzbach / Saar
Telephone:
[phone]
Fax:
[phone]
E-mail:
[e-mail]
© HYDAC FILTER SYSTEMS GMBH
All rights reserved. No part of this work may be reproduced in any form (print,
photocopy or by other means) or processed, duplicated or distributed using
electronic systems without the written consent of the publisher.
These documents have been created and inspected with the greatest care.
However, errors cannot be ruled out completely.
WBF 16 bar en(us) Page 2 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Contents
Contents
Imprint............................................................................................................2
Documentation Representative ...................................................................2
Contents ........................................................................................................3
Preface...........................................................................................................5
Technical Support........................................................................................5
Modifications to the Product ........................................................................5
Warranty......................................................................................................5
Using the documentation.............................................................................6
General safety information ..........................................................................7
Hazard symbols...........................................................................................7
Signal words and their meaning in the safety information and
instructions ..................................................................................................8
Structure of the safety information and instructions.....................................9
Observe regulatory information ...................................................................9
Proper/Designated Use .............................................................................10
Improper Use or Use Deviating from Intended Use ...................................11
Qualifications of personnel / target group ..................................................12
Transporting the filter housing..................................................................14
Storing the filter housing ...........................................................................15
Decoding the type label..............................................................................16
Checking the scope of delivery .................................................................17
Characteristics of the filter housing..........................................................18
Filter calculation.........................................................................................18
Pressure loss curve – ΔP filter housing..................................................19
Pressure loss calculation – ΔP filter element .........................................19
Filter housing components........................................................................20
Dimensions of the filter housing ...............................................................21
Hydraulic diagram.......................................................................................23
Fastening/mounting the filter housing......................................................24
Notes on the hydraulic connection.............................................................25
Putting the filter housing into operation/operating the filter housing ...26
WBF 16 bar en(us) Page 3 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Contents
Inserting the filter element/filter bag...........................................................26
Inserting the filter element ......................................................................27
Inserting a filter bag................................................................................32
Performing maintenance............................................................................37
Filterelement / Filterbeutel wechseln .........................................................37
Changing the filter element........................................................................38
Changing the filter bag...............................................................................45
Putting the filter housing out of service ...................................................53
Disposing of the filter housing ..................................................................53
Customer Service .......................................................................................53
Filter spare parts.........................................................................................54
Filter accessories........................................................................................56
Technical data .............................................................................................57
Model Code .................................................................................................58
Index ............................................................................................................59
WBF 16 bar en(us) Page 4 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Preface
Preface
This operating manual was made to the best of our knowledge. Nevertheless
and despite the greatest care, it cannot be excluded that mistakes could have
crept in. Therefore please understand that in the absence of any provisions to
the contrary hereinafter our warranty and liability – for any legal reasons
whatsoever – are excluded in respect of the information in these operating
instructions. In particular, we shall not be liable for lost profit or other financial
loss. This exclusion of liability does not apply in cases of intent and gross
negligence. Moreover, it does not apply to defects which have been deceitfully
concealed or whose absence has been guaranteed, nor in cases of culpable
harm to life, physical injury and damage to health. In the event that we should
negligently breach any material contractual obligation, our liability shall be
limited to the foreseeable loss. Claims due to Product Liability shall remain
unaffected.
Technical Support
Contact our technical sales department if you have any questions on our
product. When contacting us, please always include the model/type
designation, serial no. and part no. of the product:
Fax:
[phone] - 9046
E-mail:
[e-mail]
Modifications to the Product
We would like to point out that changes to the product (e.g. purchasing options,
etc.) may result in the information in the operating instructions no longer being
completely accurate or sufficient.
After modification or repair work that affects the safety of the product has been
carried out on components, the product may not be returned to operation until it
has been checked and released by a HYDAC technician.
Please notify us immediately of any modifications made to the product whether
by you or a third party.
Warranty
For the warranty provided by us, please refer to the General Terms of Sale and
Delivery of HYDAC FILTER SYSTEMS GMBH.
You will find these under www.hydac.com -> Legal information.
WBF 16 bar en(us) Page 5 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Preface
Using the documentation
Note that the method described for locating specific information
does not release you from your responsibility of carefully reading
these instructions prior to starting the unit up for the first time and
at regular intervals in the future.
What do I want to know?
I determine which topic I am looking for.
Where can I find the information I’m looking for?
The documentation has a table of contents at the beginning. There, I select the
chapter I'm looking for and the corresponding page number.
de
HYDACFiltertechnikGmbH
BeWa123456ade
Se ite x
Produkt/Kapitel
200x-xx- xx
The documentation number with its index enables you to order another copy of
the operating and maintenance instructions. The index is incremented every
time the manual is revised or changed.
Chapter description
Page number
Edition date
Document language
Documentation no.
with index/
file name
WBF 16 bar en(us) Page 6 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

General safety information
General safety information
The device was built according to the statutory provisions valid at the time of
delivery and satisfies current safety requirements.
Any residual hazards are indicated by safety information and instructions and
are described in the operating instructions.
Observe all safety and warning instructions attached to the filter housing. They
must always be complete and legible.
Do not operate the unit unless all the safety devices are present.
Secure the hazardous areas which may arise between the filter housing and
other equipment.
Maintain the unit inspection intervals prescribed by law.
Document the results in an inspection certificate and keep it until the next
inspection.
Hazard symbols
These symbols are listed for all safety information and instructions in these
operating instructions which indicate particular hazards to persons, property or
the environment.
Observe these instructions and act with particular caution in such cases.
Pass all safety information and instructions on to other users.
General hazard
Danger due to operating pressure
WBF 16 bar en(us) Page 7 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

General safety information
Signal words and their meaning in the safety information and instructions
DANGER
DANGER indicates a hazard with a high risk which will lead to death or
serious injury if not avoided.
WARNING
WARNING indicates a hazard with a medium risk which can lead to death or
serious injury if not avoided.
CAUTION
CAUTION indicates a danger with a low risk which can lead to minor injury if
not avoided.
NOTICE
NOTICE indicates a danger which will lead to damage to property if not
avoided.
WBF 16 bar en(us) Page 8 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

General safety information
Structure of the safety information and instructions
All warning instructions in this manual are highlighted with pictograms and
signal words. The pictogram and the signal word indicate the severity of the
danger.
Warning instructions listed before an activity are laid out as follows:
HAZARD SYMBOL
SIGNAL WORD
Type and source of danger
Consequence of the danger
►Measures to avert danger
Observe regulatory information
Observe the following regulatory information and guidelines:
•Legal and local regulations for accident prevention
•Legal and local regulations for environmental protection
•Country-specific regulations, organization-specific regulations
WBF 16 bar en(us) Page 9 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

General safety information
Proper/Designated Use
Use the unit only for the application described in the following.
The Wombat Filter WBF is a filter for separating solid particles from hydraulic
fluid, diluted cleaning liquids or cooling lubricants.
Proper or designated use of the product extends to the following:
•Filtration in main flow and bypass flow.
•Maintaining adherence to all the instructions contained herein.
•Performing requisite inspection and maintenance work.
Only use the filter with the following media:
NOTICE
Unpermitted operating media
The filter housing will be damaged.
►Only use the filter with mineral oils or mineral oil-
based raffinates, diluted
cleaning fluids or cooling lubricants.
WBF 16 bar en(us) Page 10 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

General safety information
Improper Use or Use Deviating from Intended Use
DANGER
Hazard due to use of the filter housing other
than that intended
Bodily injury and damage to property will result
when operated improperly.
►Only use the filter in the permitted operating
conditions.
►Only use the filter with the permitted media.
Any use extending beyond or deviating therefrom shall not be considered
intended use. HYDAC Filter Systems GmbH will assume no liability for any
damage resulting from such use. The user alone shall assume any and all
associated risk
Improper use may result in hazards and/or will damage the device. Examples of
improper use:
•Operation with a non-approved medium.
•Operation under impermissible operating conditions.
•Device modifications without authorization.
•Inadequate monitoring of parts that are subject to wear and tear.
•Improperly performed repair work.
WBF 16 bar en(us) Page 11 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

General safety information
Qualifications of personnel / target group
Persons who work on the filter housing must be aware of the associated
hazards when using the filter housing.
Auxiliary and specialist personnel must have read and understood the operating
instructions, in particular the safety information and instructions, and applicable
regulations before beginning work.
The operating instructions and applicable regulations are to be kept so they are
accessible for operating and specialist personnel.
These operating instructions are intended for:
Auxiliary personnel: such persons have been instructed about the filter housing
and are aware of potential hazards due to its improper use.
Specialist personnel: such persons have corresponding specialist training and
several years' work experience. They are able to assess and perform the work
assigned to them and they are also able to recognize potential hazards.
WBF 16 bar en(us) Page 12 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

General safety information
Activity
Person
Knowledge
Transport / storage
Forwarding
agent
Specialist
personnel
•Proof of knowledge of cargo
securing instructions
•Safe handling/operation of
hoisting and lifting equipment
Hydraulic / electrical
installation,
first commissioning,
maintenance,
troubleshooting,
repair,
decommissioning,
Disassembly
Specialist
personnel
•Safe handling/use of tools
•Fitting and connection of
hydraulic lines and
connections
•Fitting and connection of
electrical lines, electrical
machinery, sockets, etc.
•Product-specific knowledge
Operation
Specialist
personnel
•Product-specific knowledge
•Knowledge about how to
handle operating media
Operations control
Auxiliary
personnel
•Product-specific knowledge
•Check for leaks
Disposal
Specialist
personnel
•Proper and environmentally
friendly disposal of materials
and substances
•Decontamination of
contaminants
•Knowledge about reuse
WBF 16 bar en(us) Page 13 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Transporting the filter housing
Transporting the filter housing
Completely drain the filter housing prior to transport and remove the filter
element(s). Clean and flush the filter housing. Transport the filter housing on
one side on a pallet.
Use a strap to lift the filter housing.
WBF 16 bar en(us) Page 14 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Storing the filter housing
Storing the filter housing
Completely drain the filter housing prior to storage and remove the filter
element(s). Clean and flush the filter housing. Store the filter housing upright or
on one side.
Storage temperature:
–30 … 100 °C / –22 … 212 °F
Humidity:
up to 80% relative humidity
Storage duration:
Indefinitely
Exchange all seals after a storage period of >2
years.
WBF 16 bar en(us) Page 15 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Decoding the type label
Decoding the type label
Details for identifying the filter housing can be found on the type label on the
filter housing and the components.
Item
->
Description
(1)
->
The type label of the filter housing
(2)
->
Model code; for details, see page 58
The following information can be found on the type label of the filter housing:
Row
->
Description
Part No.
->
Part number
S/N
->
Serial number / year of production
Pressure max.
->
Operating pressure, maximum
Weight
->
Weight when empty
Seals
->
Sealing material
Temp. max.
->
Permitted maximum fluid temperature
Temp. amb.
->
Permitted ambient temperature range
Volume
->
Vessel volume
WBF 16 bar en(us) Page 16 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Checking the scope of delivery
Checking the scope of delivery
Upon receiving the filter housing check it for any damage in transit. Do not put
the filter housing into operation unless it is in perfect condition. Report any
damage to the forwarding agent immediately.
The connections are all sealed with plastic plugs to prevent the intrusion of
contaminants into the filter during transport.
The following items are supplied:
Qty.
Designation
1 Wombat Filter WBF
1 Installation and Maintenance Instructions (this document)
WBF 16 bar en(us) Page 17 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Characteristics of the filter housing
Characteristics of the filter housing
The Wombat Filter provides excellent protection for components and systems in
industrial part washers and hydraulic and lubrication systems.
Depending on the design, you can use either Wombat filter elements or
commercial filter bags in the Wombat Filter.
The option of using these different types of filter element provides a high level of
flexibility in system planning and in operation.
The star-folded Wombat filter elements offer high contaminant retention with low
pressure loss, as well as a very high filtering rate of more than 99.8% in various
grain sizes.
Filter calculation
The total pressure loss of the filter at a certain flow rate is the sum of the
housing Δp and the element Δp. The pressure loss of the housing can be
determined from the following pressure loss curves. The pressure loss of the
elements is calculated using the R-factors (see further below).
WBF 16 bar en(us) Page 18 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Characteristics of the filter housing
Pressure loss curve – ΔP filter housing
The upper housing curves apply to mineral oil with a density of 0.86 kg/dm³ and
a cinematic viscosity of 30 mm²/s. The lower housing curves apply to water at
20 °C. For turbulent flow, the differential pressure will change proportionally to
the density; for laminar flow, it will change proportionally to the density and
viscosity.
The flow velocity should not exceed 3 m/s at the filter inlet for oil and 4 m/s for
water.
∆P [bar]
Flow rate [l/min]
Pressure loss calculation – ΔP filter element
The following calculation is based on a clean filter element.
1000*][*
min]/[*]/²[*
][ inchLn
lQsmmVR
barp =∆
R
=
R-factor
V
=
Viscosity [mm²/s]
Q
=
Flow rate [l/min]
n
=
Number of elements
L
=
Length of element [inch]
WBF 16 bar en(us) Page 19 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25

Filter housing components
Filter housing components
Item
Designation
10
Filter housing
12
Type label
13.0
Drain plug
DRAIN
13.1
Air bleed screw
BLEED
13.2
Connection
100
Mounting base
101
Screw, disc, nut
102
Screw, disc, nut
103
Fitting
104
Lid, hinged
200
Inlet
INLET
201
Outlet
OUTLET
WBF 16 bar en(us) Page 20 / 64
MoWa WBF 16bar 4031149a en-us 2016-02-25.doc 2016-02-25
