Hydac MRFD1 User manual

MRFD1
MultiRheo Filter
Installation and Maintenance Instructions
English (translation of original instructions)
Keep for future reference.
Document No.: 4113517a

Imprint
MRFD1 en(us) Page 2 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Imprint
Publisher and responsible for the content:
HYDAC FILTER SYSTEMS GMBH
Postfach 1251
66273 Sulzbach / Saarland
Germany
Phone:
[phone]
Fax:
[phone]
E-mail:
[e-mail]
Homepage:
www.hydac.com
Court of Registration:
Saarbrücken, HRB 17216
Executive director:
Mathias Dieter, Dipl.Kfm. Wolfgang Haering
Documentation Representative
Mr. Günter Harge
c/o HYDAC International GmbH, Industriegebiet, 66280 Sulzbach / Saar
Telephone:
[phone]
Fax:
[phone]
E-mail:
[e-mail]
© HYDAC FILTER SYSTEMS GMBH
All rights reserved. No part of this work may be reproduced in any form (print,
photocopy or by other means) or processed, duplicated or distributed using
electronic systems without the written consent of the publisher.
These documents have been created and inspected with the greatest care.
However, errors cannot be ruled out completely.

Content
MRFD1 en(us) Page 3 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Content
MRFD1 ...........................................................................................................1
MultiRheo Filter.............................................................................................1
Imprint............................................................................................................2
Documentation Representative ...................................................................2
Content ..........................................................................................................3
Preface...........................................................................................................5
Technical Support........................................................................................5
Product modification ....................................................................................5
Warranty......................................................................................................5
Using the documentation.............................................................................6
Safety information ........................................................................................7
Hazard symbols...........................................................................................7
Signal words and their meaning in the safety information and
instructions ..................................................................................................8
Structure of the safety information and instructions.....................................8
Proper/Designated Use ...............................................................................9
Improper Use or Use Deviating from Intended Use ...................................10
Qualifications of personnel / target group ..................................................11
Wear suitable clothing ...............................................................................12
Observe regulatory information .................................................................12
Unpacking the product...............................................................................12
Transporting / storing the product ............................................................13
Decoding the name plate ...........................................................................14
Checking the scope of delivery .................................................................15
Product features .........................................................................................16
Filter components.......................................................................................17
Filter dimensions ........................................................................................19
Filter hydraulic diagram .............................................................................20
Calculating the pressure loss of the filter housing / filter element ........21
Housing
p∆
: Pressure loss curve, housing...............................................21
Filter element-
p∆
: pressure loss calculation, filter element.......................21
R (Resistance) Factors..............................................................................22
Filter material..........................................................................................22
Maximum differential pressure at the filter element ................................22
Filter elements - Flexmicron P (Premium) ..............................................22
Filter elements - Flexmicron S (Standard)..............................................23

Content
MRFD1 en(us) Page 4 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Filter elements - Flexmicron E (Economy) .............................................23
Mounting the filter housing........................................................................24
Notes on pipes and hoses .........................................................................25
Filter housing switchover ..........................................................................26
Starting up the filter....................................................................................28
Observe the clogging indicator ..................................................................29
Viewing and resetting the optical clogging indicator...............................29
Observing electrical clogging indicator...................................................29
Performing maintenance...........................................................................30
Changing filter element..............................................................................30
Spare parts list............................................................................................35
Decommissioning the filter........................................................................37
Stopping the Filter ......................................................................................37
Disposing of the Filter ................................................................................37
Customer Service / Service........................................................................37
Technical data .............................................................................................38
Model code ..................................................................................................39
Index ............................................................................................................40

Preface
MRFD1 en(us) Page 5 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Preface
These operating instructions were made to the best of our knowledge.
Nevertheless and despite the greatest care, it cannot be excluded that mistakes
could have crept in. Therefore please understand that, in the absence of any
provisions to the contrary hereinafter, our warranty and liability – for any legal
reasons whatsoever – are excluded in respect of the information in these
operating instructions. In particular, we shall not be liable for lost profit or other
financial loss. This exclusion of liability does not apply in cases of intent and
gross negligence. Moreover, it does not apply to defects which have been
deceitfully concealed or whose absence has been guaranteed, nor in cases of
culpable harm to life, physical injury and damage to health. If we negligently
breach any material contractual obligation, our liability shall be limited to
foreseeable damage. Claims due to Product Liability shall remain unaffected.
Technical Support
Contact our technical sales department if you have any questions on our
product. When contacting us, please always include the model code, serial no.
and part no. of the product:
Fax:
[phone]
E-mail:
[e-mail]
Product modification
We would like to point out that changes to the product (e.g. purchasing
additional options, etc.) may mean that the information in the operating
instructions is no longer applicable or adequate.
After modification or repair work that affects the safety of the product has been
carried out on components, the product may not be returned to operation until it
has been checked and released by a HYDAC technician.
Please notify us immediately of any modifications made to the product whether
by you or a third party.
Warranty
For the warranty provided by us, please refer to the General Terms of Sale and
Delivery of HYDAC FILTER SYSTEMS GMBH.
You will find these under www.hydac.com -> General Terms and Conditions.

Preface
MRFD1 en(us) Page 6 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Using the documentation
Note that the method described for locating specific information
does not release you from your responsibility of carefully reading
all these instructions prior to starting the unit up for the first time
and at regular intervals in the future.
What do I want to know?
I determine which topic I am looking for.
WHERE can I find the information I’m looking for?
The documentation has a table of contents at the beginning. There, I select the
chapter I'm looking for and the corresponding page number.
de
HYDACFiltertechnikGmbH
BeWa123456ade
Se ite x
Produkt/Kapitel
200x-xx- xx
The documentation number with its index enables you to order another copy of
the operating and maintenance instructions. The index is incremented every
time the manual is revised or changed.
Chapter description
Page number
Edition date
Document language
Documentation No.
with Index /
File name

Safety information
MRFD1 en(us) Page 7 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Safety information
The filter was built according to the statutory provisions valid at the time of
delivery and satisfies current safety requirements.
Any residual hazards are indicated by safety information and instructions and
are described in the operating instructions.
Observe all safety and warning instructions attached to the filter. They must
always be complete and legible.
Do not operate the filter unless all the safety devices are present.
Secure the hazardous areas which may arise between the filter and other
equipment.
Maintain the unit inspection intervals prescribed by law.
Document the results in an inspection certificate and keep it until the next
inspection.
Hazard symbols
These symbols are listed for all safety information and instructions in these
operating instructions which indicate particular hazards to persons, property or
the environment.
Observe these instructions and act with particular caution in such cases.
Pass all safety information and instructions on to other users.
General hazard
Danger due to operating pressure
Risk of burns due to hot surfaces

Safety information
MRFD1 en(us) Page 8 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Signal words and their meaning in the safety information and instructions
The following signal words are to be found in these instructions.
DANGER
DANGER – The signal word indicates a hazardous situation with a high level
of risk, which, if not avoided, will result lethal or serious injury.
WARNING
WARNING – The signal word indicates a hazardous situation with a medium
level of risk, which, if not avoided, can result lethal or serious injury.
CAUTION
CAUTION – The signal word indicates a hazardous situation with a low level
of risk, which, if not avoided, can result in minor or moderate injury.
NOTICE
NOTICE – The signal word indicates a hazardous situation with a high level
of risk, which, if not avoided, will result in damage to property.
Structure of the safety information and instructions
All warning instructions in this manual are highlighted with pictograms and
signal words. The pictogram and the signal word indicate the severity of the
danger.
Warning instructions listed before an activity are laid out as follows:
HAZARD SYMBOL
SIGNAL WORD
Type and source of danger
Consequence of the danger
►Measures to avert danger

Safety information
MRFD1 en(us) Page 9 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Proper/Designated Use
Only use the filter for the application described in the following.
The MultiRheo Filter (MRF) is a stationary filtration unit used for the full-flow and
bypass filtration of low-viscosity fluids.
The filter is intended hold Flex Micron filter elements.
Making sure that the pressure equipment is operated within the permitted usage
ranges is to be guaranteed by suitable monitoring and safety equipment. Please
see: Pressure Equipment Directive (2014/68/EU).
NOTICE
Impermissible operating media/conditions
The filter housing will be damaged.
►The filter may only be used in connection with mineral oils, mineral-oil-
based raffinates or coolants.
Proper or designated use of the product extends to the following:
•Observing all instructions contained in the instruction manual.
•Adhering to maintenance work.
•Operation only reciprocal, this means the switching lever always has to
be in an end position.

Safety information
MRFD1 en(us) Page 10 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Improper Use or Use Deviating from Intended Use
Any use extending beyond or deviating therefrom shall not be considered
intended use. HYDAC Filter Systems GmbH will assume no liability for any
damage resulting from such use. The owner alone, shall assume any and all
associated risk
Improper use or deviating from intended use may result in hazards and/or will
damage the filter. Examples of improper use:
•Operation with switching lever in an interim position
•Operation with an impermissible fluid.
•Operation under non-approved operational conditions.
•Operation when the safety devices are defective.
•Modifications to the filter made by the user or purchaser.
•Inadequate monitoring of parts that are subject to wear and tear
•Improperly performed repair work.

Safety information
MRFD1 en(us) Page 11 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Qualifications of personnel / target group
Persons who work on the power unit must be aware of the associated hazards
when using the power unit.
Operating and specialist personnel must have read and understood the
operating instructions, in particular the safety information and instructions, and
applicable regulations before beginning work.
The operating instructions and applicable regulations are to kept so they are
accessible for operating and specialist personnel.
These operating instructions are intended for:
Auxiliary personnel: such persons have no specialized knowledge and perform
work as instructed.
Operating personnel: such persons have been instructed in power unit
operation and are aware of potential hazards due to improper use.
Specialist personnel: such persons have corresponding specialist training and
several years' work experience. They are able to assess and perform the work
assigned to them, they are also able to recognize potential hazards.
Activity
Person
Knowledge
Transport / storage
Auxiliary
personnel
No specialist knowledge
required
Startup operation
Operations control
Operating
Personnel
Product-specific knowledge
Knowledge about how to handle
operating media.
troubleshooting,
maintenance,
decommissioning,
Disassembly
Specialist
personnel
Safe handling/use of tools
Product-specific knowledge
Disposal
Specialist
personnel
Proper and environmentally-
friendly disposal of materials
and substances
Decontamination of
contaminants
Knowledge about reuse

Unpacking the product
MRFD1 en(us) Page 12 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Wear suitable clothing
Loose-fitting clothing increases the risk of getting caught on protruding parts.
You can be severely injured or killed.
•Wear close-fitting clothing.
•Do not wear any rings, chains or any other jewelry.
•Wear work safety shoes.
•Wear gloves.
•Observe the information relating to personal protection equipment in the
safety data sheet of the operating fluid.
Observe regulatory information
Observe the following regulatory information and guidelines:
•Legal and local regulations for accident prevention
•Legal and local regulations for environmental protection
•Country-specific regulations, organization-specific regulations
Unpacking the product
Prior to delivery, the product is function- and leak-tested in the factory.
When unpacking the product, check it for damage in transit.

Transporting / storing the product
MRFD1 en(us) Page 13 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Transporting / storing the product
Remove the filter element and completely discharge the filter housing before
transport/storage. Close all connections.
Permitted storage temperature
range
See chapter “Technical data“, page 38.
Permitted air humidity
See chapter “Technical data“, page 38.
Air
Clean, salt-free air, not near oxidizing
substances (danger of rust film).
Storage duration
Indefinite.
After a storage period of greater than 2
years, replace all seals before
commissioning.
Storage position
Lying on its side

Decoding the name plate
MRFD1 en(us) Page 14 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Decoding the name plate
For identification details of the filter housing, see the name plate.
Item
->
Description
(1)
->
The type label of the filter housing
(2)
->
Model code; for details, see page 39
The following information can be found on the name plate of the unit:
Row
->
Description
Part No.:
->
Part number
S/N:
->
Serial number / year of production
Pressure max.:
->
Maximum permitted operating pressure
Weight:
->
Voltage / power supply
Seals:
->
Frequency
Temp. Oil:
->
Permitted fluid temperature range
Temp. amb.:
->
Permitted ambient temperature range
Volume:
->
Fluid volume in unit

Checking the scope of delivery
MRFD1 en(us) Page 15 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Checking the scope of delivery
Upon receiving the filter, check it for any damage in transit. Do not put the filter
into operation unless it is in perfect condition. Report any damage to the
forwarding agent immediately.
The filter is factory-tested for leakage and proper functioning and is properly
packed.
The connections are all sealed with plastic plugs to prevent the intrusion of
contaminants into the filter during transport.
The following items are supplied:
Qty
Description
1 MultiRheo Filter MRFD1 (without filter element)
1
Installation and Maintenance Instructions (this document)

Product features
MRFD1 en(us) Page 16 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Product features
The MultiRheo Filter is a stationary filtration unit used for the full-flow and
bypass filtration of low-viscosity fluids. The MRF is used for the separation of
particles 100 µm to 1 µm (absolute) in size.

Filter components
MRFD1 en(us) Page 17 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Filter components
The filter housing has the following components:

Filter components
MRFD1 en(us) Page 18 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Item
Designation
a
Inlet
IN
B
Outlet
OUT
C
Ventilation / bleeding
VENT
D
Drain
DRAIN
E
Change-over
F
Clogging indicator (optional)
10
Filter housing
40
Coupling nut

Filter dimensions
MRFD1 en(us) Page 19 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Filter dimensions
The filter housing has the following dimensions:
Filter Size
Length A
10“
348 mm
20“
602 mm
30“
856 mm
40“
1110 mm

Filter hydraulic diagram
MRFD1 en(us) Page 20 / 44
MoWa MRFD1 4113517a en-us 2016-08-10.docx
2016-08-10
Filter hydraulic diagram
The filter has the following hydraulic diagram:
C C
D D
A
B
F
a
=
Inlet
IN
B
=
Outlet
OUT
C
=
Ventilation / bleeding
VENT
D
=
Drain
DRAIN
E
=
Change-over valve
F
=
Clogging indicator (optional)
