Hytera pd66x User manual

DIGITAL PORTABLE RADIO
PD66X OWNER’S MANUAL

Welcome to the world of Hytera and thank you for purchasing this product. This manual
includes a description of the functions and step-by-step procedures for use. It also includes
a troubleshooting guide. To avoid bodily injury or property loss caused by incorrect
operation, please carefully read the Safety Information Booklet before use.
This manual is applicable to the following product:
PD66X Digital Portable Radio (X may represent 2, 5, 6, or 8).

Copyright Information
Hytera is the trademark or registered trademark of Hytera Communications
Corporation Limited (the Company) in the People's Republic of China (PRC)
and/or other countries or areas. The Company retains the ownership of its
trademarks and product names. All other trademarks and/or product names
that may be used in this manual are properties of their respective owners.
The product described in this manual may include the Company's computer
programs stored in memory or other media. Laws in PRC and/or other
countries or areas protect the exclusive rights of the Company with respect
to its computer programs. The purchase of this product shall not be deemed
to grant, either directly or by implication, any rights to the purchaser
regarding the Company's computer programs. The Company's computer
programs may not be copied, modified, distributed, decompiled, or reverse-
engineered in any manner without the prior written consent of the Company.
Disclaimer
The Company endeavors to achieve the accuracy and completeness of this
manual, but no warranty of accuracy or reliability is given. All the
specifications and designs are subject to change without notice due to
continuous technological development. No part of this manual may be
copied, modified, translated, or distributed in any manner without the prior
written consent of the Company.
We do not guarantee, for any particular purpose, the accuracy, validity,
timeliness, legitimacy or completeness of the third-party products and
contents involved in this manual.
If you have any suggestions or would like to receive more information,
please visit our website at: http://www.hytera.com.
FCC Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates and can radiate radio
frequency energy. If not installed and used in accordance with the
instructions, it may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. Verification of harmful interference by this
equipment to radio or television reception can be determined by turning it
off and then on. The user is encouraged to try to correct the interference by
one or more of the following measures:
lReorient or relocate the receiving antenna. Increase the separation
between the equipment and receiver.

lConnect the equipment into an outlet on a different circuit to that of the
receiver's outlet.
lConsult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions:
lThis device may not cause harmful interference.
lThis device must accept any interference received, including
interference that may cause undesired operation.
Note: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate
the equipment.
Compliance with RF Exposure Standards
The radio complies with the following RF energy exposure standards and
guidelines:
lUnited States Federal Communications Commission, Code of Federal
Regulations; 47 CFR § 1.1307, 1.1310 and 2.1093
lAmerican National Standards Institute (ANSI) / Institute of Electrical
and Electronic Engineers (IEEE) C95. 1:2005; Canada RSS102 Issue 5
March 2015
lInstitute of Electrical and Electronic Engineers (IEEE) C95.1:2005
Edition
RF Exposure Compliance and Control
Guidelines and Operating Instructions
To control your exposure and ensure compliance with the
occupational/controlled environmental exposure limits, always adhere to the
following procedures.
Guidelines:
lDo not remove the RF Exposure Label from the device.
lUser awareness instructions should accompany device when
transferred to other users.
lDo not use this device if the operational requirements described herein
are not met.
Operating Instructions:
lTransmit no more than the rated duty factor of 50% of the time. To
transmit (talk), press the Push-To-Talk (PTT) key. To receive calls,
release the PTT key. Transmitting 50% of the time, or less, is important
because the radio generates measurable RF energy only when
transmitting (in terms of measuring for standards compliance).
lKeep the radio unit at least 2.5 cm away from the face. Keeping the
radio at the proper distance is important as RF exposure decreases with
distance from the antenna. The antenna should be kept away from the
face and eyes.

lWhen worn on the body, always place the radio in an approved holder,
holster, case, or body harness or by use of the correct clip for this
product. Use of non-approved accessories may result in exposure levels
which exceed the FCC's occupational/controlled environmental RF
exposure limits.
lUse of non-approved antennas, batteries, and accessories causes the
radio to exceed the FCC RF exposure guidelines.
lContact your local dealer for the product's optional accessories.
IC Statement
The device has been tested and complies with SAR limits, users can obtain
Canadian information on RF exposure and compliance.
Après examen de ce matériel aux conformité aux limites DAS et/ou aux
limites d’intensité de champ RF, les utilisateurs peuvent sur l’exposition aux
radiofréquences et la conformité and compliance d’acquérir les
informations correspondantes
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
lThis device may not cause harmful interference.
lThis device must accept any interference received, including
interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement
EU Regulatory Conformance
As certified by the qualified laboratory, the product is in compliance with
the essential requirements and other relevant provisions of 2014/53/EU.
Please note that the above information is applicable to EU countries only.

Contents
Documentation Conventions 3
Packing List 4
Product Overview 5
Product Controls 5
Programmable Keys 5
Before Use 6
Charging the Battery 6
Attaching the Battery 6
Attaching the Antenna 7
Attaching the Belt Clip 7
Attaching the Audio Accessories 7
Basic Operations 8
Turning the Radio On or Off 8
Adjusting the Volume 8
Checking the Battery Power 9
Locking or Unlocking Keys and Knobs 9
Switching the Operation Mode 9
Selecting a Zone and Channel 9
Status Indications 10
LCD Icons 10
LED Indications 12
Call Services 13
Group Call 13
Private Call 15
Phone Call 16
All Call 18
Broadcast Call (Trunking Only) 19
Include Call (Trunking Only) 20
Call on Analog Channel 20
Message Services 21
Viewing Messages 21
Sending Messages 21
Deleting Messages 21
Supplementary Features 22
1

Basic Settings 23
Contact Management 24
Audio Optimization 25
MIC & SPK 26
One Touch Call/Menu 27
Scan 27
Hunt 28
Roam 29
Talk Around 30
Time-out Timer 30
VOX 30
Call Priority 30
DGNA 30
GPS 31
Work Order 32
Control Services 32
Analog Services 33
Personal Safety Services 34
Communication Security Services 35
Troubleshooting 37
Care and Cleaning 39
Product Care 39
Product Cleaning 39
Optional Accessories 39
Abbreviations 39
2

Documentation Conventions
Icon Conventions
Icon Description
Indicates references that can further describe the related
topics.
Indicates situations that could cause data loss or equipment
damage.
Notation Conventions
Item Description Example
Boldface
Denotes menus, tabs,
parameter names, window
names, dialogue names, and
hardware buttons.
To save the configuration, click
Apply.
The Log Level Settings dialogue
appears.
Press the PTT key.
Item Description Example
" "
Denotes messages,
directories, file names,
folder names, and
parameter values.
The screen displays "Invalid
Battery!".
Open "PDT_PSS.exe".
Go to "D:/opt/local".
In the Port text box, enter "22".
>Directs you to access a
multi-level menu. Go to File >New.
Italic Denotes document titles.
For details about using the DWS,
refer to Dispatch Workstation User
Guide.
Courier
New
Denotes commands and
their execution results.
To set the IP address, run the
following command:
vos-cmd - m name IP
3

Packing List
Please unpack carefully and check that all items listed below are received. If any item is missing or damaged, please contact your dealer.
Item Quantity (PCS) Item Quantity (PCS)
Radio 1 Antenna 1
Battery 1 Belt Clip 1
Charger 1 Strap 1
Power Adapter 1 Documentation Kit 1
Check whether the frequency band marked on the antenna label matches that on the radio label. If not, please contact your dealer.
4

Product Overview
Product Controls
Programmable Keys
You can request your dealer to program the following keys as shortcuts to radio features: SK1,Up key, Down key, P1 key, P2 key, P3 key, P4 key, and P5
key. Please consult your dealer for assignable radio features.
5

Before Use
Charging the Battery
lUse the approved charger to charge the battery.
lRead the Safety Information Booklet before charging.
Before initial use, fully charge the battery to ensure optimum performance.
To charge the battery, do as follows:
1. Insert the output connector of the power adapter into the port on the
back of the charger.
2. Plug the power adapter into a power outlet that is off.
3. Place the battery into the charger, and then switch the power outlet on.
To determine the charging status, check the light-emitting diode (LED)
indicator on the charger according to the following table:
LED Indicator Charging Status
Flashes red slowly The battery fails to make proper contact with the
charger.
Glows red The battery is charging.
LED Indicator Charging Status
Glows orange The battery is charged to 90% or above.
Glows green The battery is fully charged.
Flashes red rapidly The battery fails to be charged.
If the LED indicator flashes red slowly, take the battery out of the charger,
and then place it into the charger for proper contact.
If the LED indicator flashes red rapidly, please contact your dealer to
check whether the battery or power adapter is damaged.
You can also charge the radio with battery attached. It is
recommended that your radio remain powered off during charging.
Attaching the Battery
6

To remove the battery, make sure that the radio is turned off, and then
slide the battery latch upwards to unlock the battery.
Attaching the Antenna
Do not hold the radio by the antenna, as it may reduce the radio
performance and life span of the antenna.
Attaching the Belt Clip
1. Use a Phillips screwdriver to turn the screws counter-clockwise on the
back of the radio and remove them.
2. Align the screw holes on the belt clip with those on the back of the
radio.
3. Put the screws back in place as shown below, and use the Phillips
screwdriver to turn them clockwise until hand tight.
Attaching the Audio Accessories
For optimal waterproof and dustproof performance, do close the
accessory connector cover and fasten the screw when no accessory is
attached.
7

1. Loosen the screw fixing the accessory connector cover as shown
below, and open the cover.
2. Align the accessory plug with the accessory connector, and then tighten
the screw on the accessory plug as shown below.
Basic Operations
Turning the Radio On or Off
Adjusting the Volume
8

Checking the Battery Power
To check the battery power, press and hold the preprogrammed Battery
Power Indicator key. The following table lists the battery power
indications. The icon indicates that the battery runs low. In this case,
please recharge or replace the battery.
Icon LED Indication/Tone
The LED indicator glows green.
The LED indicator glows orange.
The LED indicator glows red.
The LED indicator glows red and an alert tone sounds.
Locking or Unlocking Keys and Knobs
When the keypad is not in use, it is recommended that you lock it to avoid
unintended operations.
To lock or unlock the keypad, press the preprogrammed Keypad Lock key.
To allow the keypad to be locked automatically, enable the Keypad Lock
feature as follows:
1. Go to Menu >Settings >Radio Set >Keypad Lock..
2. Select Enable, and then set Delay Time by pressing the Up or Down
key.
In addition, you can go to Menu >Settings >Radio Set >Optional Key to
set whether the corresponding keys and knobs still work when the keypad is
locked.
Switching the Operation Mode
The radio can operate in conventional mode or trunking mode. In
conventional mode, you can receive and transmit voice and data after
selecting the required channel. In trunking mode, you can receive and
transmit voice and data after the radio registers successfully.
To switch the operation mode, do one of the following:
lGo to Menu >Mode >Manual Switch, select the required mode, and
then press the OK/Menu key.
lPress the preprogrammed Operation Mode Switch key.
To allow the radio to automatically switch to a mode based on signal
strength in trunking mode, go to Menu >Mode >Auto Switch, and then
select Enable.
Selecting a Zone and Channel
In conventional mode, the radio receives and transmits data and voice on
the selected channel. A zone is a group of channels within the same
operational area. Before selecting a channel, make sure that the current
zone contains the channel.
To select a zone, do one of the following:
9

lGo to Menu >Zone, and then select the required zone.
lPress the preprogrammed Zone Up or Zone Down key.
To select a channel, do one of the following:
lRotate the Channel Selector knob.
lPress the preprogrammed Channel Up or Channel Down key.
Status Indications
LCD Icons
The following tables list icons that may appear on the radio's liquid-crystal
display (LCD).
Operation Mode Icons
Icon Radio Status
DM Direct Mode: The radio transmits and receives directly.
RM Repeater Mode: The radio transmits and receives through a
repeater.
TDMA TDMA Direct Mode: If one time slot is occupied, the radio
can transmit and receive through the other time slot.
TM-DW Trunking Mode - Digital Wide: The radio operates under
multiple BSs connected through the network.
Icon Radio Status
TM-DL Trunking Mode - Digital Local: The radio operates under a
single BS.
The Mode Automatic Switch feature is enabled.
Basic Status Icons
Icon Radio Status
The Dual-Tone Multi-Frequency (DTMF) keypad is enabled.
The number of bars indicates the charge left in the battery.
There is no signal in conventional or TM-DW mode.
The number of bars indicates the signal strength in conventional
or TM-DW mode.
There is no signal in TM-DL mode.
The number of bars indicates the signal strength in TM-DL
mode.
The radio is set at high power.
The radio is set at low power.
10

Icon Radio Status
An accessory is connected.
The Global Positioning System (GPS) feature is enabled, and
the radio receives GPS data.
The GPS feature is enabled, but the radio receives no GPS data.
The radio is in emergency mode.
The radio is roaming.
The Scrambler or Encrypt feature is enabled.
The radio is scanning or hunting.
The radio stays on a non-priority channel.
The radio stays on priority channel 1.
The radio stays on priority channel 2.
The Voice Operated Transmit (VOX) feature is enabled.
The Monitor feature is enabled.
The speaker is turned on.
The radio operates in silent mode.
The Loudness and Quality Optimizer (LQO) feature is enabled.
Short Data Icons
Icon Radio Status
There is/are unread short message(s).
The Inbox is full.
There is/are unread status message(s).
There is/are unread work order(s).
The work order list is full.
Call Icons
Icon Radio Status
There is/are alert call(s).
There is/are missed call(s).
The Call Divert feature is enabled.
A private call is in progress or a private contact is on the
contact list.
A group call is in progress or a group contact is on the contact
list.
11

Icon Radio Status
An all call is in progress.
An include call is in progress.
LED Indications
LED Indicator Radio Status
Flashes green Being turned on.
Flashes green slowly Standby in trunking mode.
Glows green Receiving.
Glows red Transmitting.
Flashes red Establishing a call in trunking mode. This indication
is applicable to the calling radio.
Flashes orange slowly Scanning, hunting, or roaming.
Flashes orange rapidly
lConventional mode: Working in emergency
mode.
lTrunking mode: Establishing a Full Off Air Call
Set-Up (FOACSU) call. This indication is
applicable to the called radio.
Glows orange Call hang time: No voice is being transmitted or
received on the channel during a call. Within such
LED Indicator Radio Status
a period, you can press and hold the PTT key and
speak.
12

Call Services
When you are speaking during a call, keep the microphone about 2.5 to 5
cm away from your mouth. This ensures optimal voice quality on the
receiving radio.
Group Call
A group call is a call from an individual user in a group to all the other
members in the group.
Initiating a Group Call
The following table describes how to initiate a group call in conventional
mode and trunking mode.
Mode Manner Operation
Conventional
Preset Contact
1. Rotate the Channel
Selector knob to select the
channel associated with the
target group contact.
2. Press and hold the PTT
key.
Contact List /
Favorites
1. Go to Menu >Contact >
Contact List /Favorites.
2. Select the target group
contact.
3. Press and hold the PTT
key.
Trunking
Preset Contact
1. Rotate the Group Selector
knob to select the target
group contact.
2. Press and hold the PTT
key.
Favorites
1. Go to Menu >Contact >
Favorites.
2. Select the target group
contact.
3. Press or press and hold
13

Mode Manner Operation
the PTT key.
Subgroup
1. Press the preprogrammed
Subgroup key or go to
Menu >Subgroup.
2. Select the required
subgroup, and then select
Member.
3. Select the target group
contact.
4. Press or press and hold
the PTT key.
ReDial/BackDial
Call Log
1. From the home screen,
press or (if
preprogrammed as the
ReDial or BackDial key).
2. Select the target group
contact from the list.
3. Press or press and hold
the PTT key.
Mode Manner Operation
Call Log
1. Go to Menu >Call Logs >
Outgoing/Incoming/Missed
>Outgoing List /Incoming
List /Missed List.
2. Select the target group
contact.
3. Press or press and hold
the PTT key.
Receiving a Group Call
When you receive a group call, the radio displays . The call is
established automatically. In trunking mode, the radio displays after the
call is established successfully.
Ending a Group Call
A group call automatically ends when the call hang time expires.
In trunking mode, a group call also ends in any of the following cases:
lThe calling party ends the call by pressing the End key or
preprogrammed Clear Down key.
lThe call duration exceeds the period preset by your dealer.
lA preemptive or emergency call interrupts the call.
lThe base station signal is lost.
14

Private Call
A private call is a call from an individual user to another individual user.
Initiating a Private Call
The following table describes how to initiate a private call in conventional
mode and trunking mode.
Mode Manner Operation
Conventional
Preset Contact
1. Rotate the Channel
Selector knob to select the
channel associated with
the target private contact.
2. Press and hold the PTT
key.
Contact List /
Favorites
1. Go to Menu >Contact >
Contact List /Favorites.
2. Select the target private
contact.
3. Press and hold the PTT
key.
Mode Manner Operation
Trunking
Preset Contact
1. Rotate the Group Selector
knob to select the target
private contact.
2. Press and hold the PTT
key to initiate the call.
Favorites /
Private Contact
1. Go to Menu >Contact >
Favorites /Private
Contact.
2. Select the target private
contact.
3. Press or press and hold
the PTT key.
ReDial/BackDial
Call Log
1. From the home screen,
press or (if
preprogrammed as the
ReDial or BackDial key).
2. Select the target private
contact from the list.
3. Press or press and hold
the PTT key.
Conventional/
Trunking Call Log 1. Go to Menu >Call Logs >
Outgoing
15
