Hytorc BTM-0250-DOC User manual

800-FOR-HYTORC
(800-367-4986)
201-512-9500
hytorc.com333 Route 17 N.
Mahwah, NJ 07430
USA
LITHIUM SERIES® Electric Torque Tool
(BTM-DOC Models)
Operations Manual
CATLITHIUM_SERIESMAN

LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual
Models
BTM-0250-DOC
BTM-0750-DOC
BTM-1000-DOC
BTM-2000-DOC
BTM-3000-DOC
Technical Certifications
Conforms to UL STDS 60745-1 & 60745-2-2
Certified to CSA STD C22.2 Nos. 60745-1 & 60745-2-2
For Hand-Held Motor-Operated Electric Tools.
5002282
EN ISO 12100-1:2011
EN ISO 12100-2:2011
EN ISO 14121-1:2007
EN ISO 11148-6:2012
Notice. The information contained in this document is subject to change without notice. HYTORC makes no warranty of any kind
with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
HYTORC shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing,
performance, or use of this material. It is further recommended that the end-user or repair technician insure they have obtained and
are familiar with the latest revision of the manual for the equipment outlined in this document.
Restricted Rights Legend. Use and duplication of the information contained within this manual is limited to the purchaser, end user,
or licensed HYTORC representative. It is recommended that proper training for the equipment outlined in this manual be conducted
by a HYTORC-authorized training representative for any person who is operating or repairing the equipment outlined in this docu-
ment. Modification of, or disclosure by any other agency or representative is strictly forbidden.
Product Modifications. HYTORC DOES NOT ALLOW any of the products listed in this manual to be modified by any end user without
exception. Should an application require a modification to the tool, or any of the standard accessories please consult with your local
HYTORC representative and they will be able to obtain the assistance for any modification that may be required.
LITHIUM SERIES® is a registered trademark of HYTORC.
Copyright © 2018 HYTORC All Rights Reserved. Reproduction, adaptation, or translation without prior written permission is prohib-
ited, except as allowed under the copyright laws.
Warranty. The LITHIUM SERIES Tool has a one-year limited warranty. Every tool is tested before leaving the factory and is warranted
to be free from defects in workmanship and materials. HYTORC will repair or replace, without charge, any tool which, upon examina-
tion, proves to be defective in workmanship or materials for one (1) year after the date of purchase. This warranty does not cover dam-
age resulting from repairs made or attempted by unauthorized repair facilities. The repair and replacement remedies described herein
are exclusive. In no event shall HYTORC be liable for any incidental, special, or consequential damages, including loss of profits. This
warranty is exclusive and in lieu of all other warranties or conditions, written or oral, expressed or implied for merchantability or fitness
for particular use or purpose. This warranty gives you specific legal rights. You may also have other rights that vary from state to state
and province to province. In those states that do not allow the exclusion of implied warranties or limitation of incidental or consequen-
tial damages, the above limitations or exclusions may not apply to you. If you have questions about the warranty, contact our customer
service center at 201-828-5270.
Printed in the USA. April 2018
TECHNICAL CERTIFICATIONS

LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual 5
LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual
1. IMPORTANT SAFETY INFORMATION 
2. TOOL DESCRIPTION 
3. SERVICE 
FREE SERVICES 
REPAIRS 
TOOL RENTALS 
HELP 11
FOLLOW US ONLINE 11
4. CARE AND HANDLING 
INSPECT TOOLS & CALIBRATION 
ENVIRONMENTAL CONSIDERATIONS 
5. CHARGE, TEST & INSTALL BATTERY 
CHARGE THE BATTERY 
CHARGING INDICATOR 
TEST THE BATTERY 
INSTALL THE BATTERY 
BATTERY RECYCLING 
6. OPERATING THE CONTROL PANEL 
PRIMARY CONTROL FEATURES 
TOGGLE TORQUE, ANGLE & RELEASE 
SET TORQUE 
SET ANGLE 
SET RELEASE 17
7. NAVIGATING THE MENUS 
MAIN MENU AND SUBMENUS 
OPERATION MENU 
JOB DATA MENU 
CONNECT USB CABLE 
SAMPLE EXCEL FILE 
SYSTEM MENU 
ADMIN MENU 
8. DUAL SPEED OPERATION 
TWOSPEED OPERATION 27
DUALSPEED JOG 
9. BOLTING WITH CONVENTIONAL REACTION ARM 
INSTALL REACTION ARM 
INSTALL SOCKET 29
CONVENTIONAL TORQUE SETUP 
CONVENTIONAL TORQUE TIGHTENING 
CONVENTIONAL TORQUE LOOSENING 
10. BOLTING WITH THE HYTORC WASHER 
INSTALL HYTORC WASHER DRIVER 
TIGHTENING WITH THE HYTORC WASHER DRIVER 
LOOSENING WITH THE HYTORC WASHER 
11. BOLTING WITH THE HYTORC NUT 
INSTALL HYTORC NUT DRIVER 
TIGHTENING THE HYTORC NUT 36
LOOSENING THE HYTORC NUT 
12. ADDENDUM IMPORTANT 
TABLE OF CONTENTS

6
Read and understand this material before operating or servicing the LITHIUM SERIES® Electronic Torque Tool. Failure to
understand how to safely operate this tool could result in an accident causing serious injury or death.
•Inspect all Tool components as they are removed from the shipping container. If damage is found to any component,
contact the shipper immediately. Do not use the tool.
•Failure to follow correct tool usage could result in personal injury, co-worker injury, and/or damaged tools and
equipment.
•Ensure your working area is clean and unobstructed before beginning work.
•Tool maintenance and repair must be performed by a qualified technician.
•Modifying a tool or tool accessory is dangerous and invalidates the warranty.
•Inspect the tool before each use. Have any obviously worn or damaged parts replaced.
•When not in use, store the tool and tool accessories in the plastic storage case supplied with the tool. Do not expose the
gun to high humidity or large temperature variations.
. IMPORTANT SAFETY INFORMATION
PERSONAL PROTECTIVE EQUIPMENT TOOL SAFETY WARNINGS
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
Always wear the appropriate personal protective equipment
when operating a tool including gloves, safety goggles,
hearing protection, hard hat, and safety shoes.
Read all safety warnings and all instruction. Failure to follow
the warnings and instructions may result in electric shock,
fire, and/or serious injury.
WORK SAFETY AREA
•Keep work area clean and well lit. Cluttered or dark areas invite accidents. Do not operate the tool in explosive
atmospheres, such as in the presence of flammable liquids, gases or dusts. The tool can create sparks which may
ignite the dusts or fumes.
•Keep children and bystanders away while operating the tool. Distractions can cause you to lose control.

LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual 7
SERVICE
•Have your tool serviced by a qualified repair person using identical replacement parts. This will ensure that the
safety of the tool is maintained.
PERSONAL SAFETY
•Stay alert, watch what you are doing and use
common sense when operating the tool. Do not use
the tool while you are tired or under the influence of
drugs, alcohol, or medication. A moment of inattention
while operating the tool may result in serious personal
injury.
•Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
•Prevent unintentional starting. Ensure the switch is
in the o-position before connecting to power source
and or battery pack, picking up or carrying the tool.
Carrying the tool with your finger on the switch or
energizing power tools that have the switch on invites
accidents.
•Remove any adjusting key or wrench before turning
the tool on. A wrench or a key left attached to a rotating
part of the tool may result in personal injury.
•Do not overreach. Keep proper footing and balance
at all times. This enables better control of the tool in
unexpected situations.
•Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from the
moving parts. Loose clothes, jewelry or long hair can be
caught in moving parts.
•If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
LITHIUM TOOL USE AND CARE
•Do not force the tool. Use the correct tool for your
application. The correct tool will do the job better and
safe rat the rate for which it is designed.
•Do not use the tool if the switch does not turn it on
and o. Any tool that cannot be controlled with the
switch is dangerous and must be repaired.
•Disconnect the plug from the power source and/
or the battery pack from the tool before making
any adjustments, changing accessories, or storing
tool. Such preventive safety measures reduce the risk of
starting the tool accidentally.
•Store idle tools out of the reach of children and do
not allow persons unfamiliar with the tool or these
instructions to operate the tool. Tools are dangerous in
the hands of untrained users.
•Maintain tools. Check the misalignment or binding
of moving parts, breakage of parts and any other
condition that may aect the power of tool’s
operation. If damaged, have the tool repaired before
use. Many accidents are caused by poorly maintained
tool.
•Use the tool, accessories in accordance with these
instructions, taking into account the working
conditions and the work to be performed.
•Using the tool for the operations dierent from those
intended could result in a hazardous situation
•Rechargeable only with the charger specified by
manufacturer. A charger that is suitable for one type of
battery pack may create as risk of fire when used with
another battery pack.
•Use the tool only with specifically designated battery
packs. Use of any other battery pack my risk injury and
fire.
•When the battery pack is not in use, keep it away
from other metal objects, like paper clips, coins, keys,
nails, screws and other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a fire.
•Under abusive conditions, liquid may be ejected from
the battery; avoid contact. if contact accidentally
occurs, flush it with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.

8
IMPORTANT BATTERY PACK INSTRUCTIONS
•Do not splash or immerse in water or other liquids.
•Do not incinerate the battery pack even if it is
severely damaged or is completely worn out. The
battery pack can explode in a fire. Toxic fumes and
materials are created when lithium ion battery packs are
burned.
•Do not charge or use the battery in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Inserting or removing the battery
from the charger may ignite dust or fumes.
•If battery contents come into contact with the skin,
immediately wash area with mild soap and water.
•If battery liquid gets into the eyes, rinse over the
open eye for 15 minutes or until irritation ceases. If
medical attention is needed, the battery electrolyte is
composed of a mixture of liquid organic carbonates and
lithium salts.
•Contents of opened battery cells may cause
respiratory irritation. Provide fresh air. If symptoms
persist, seek medical attention.
•Charge the battery packs only in battery chargers
supplied for charging this product.
•Do not pack with conductive items.
WARNING!
WARNING!
US Department of Transportation Hazardous Materials Regulations
WARNING!
Burn hazard. Battery liquid may be flammable if exposed to spark or flame.
Never attempt to open the battery pack for any reason. If battery pack case is cracked or damaged,
do not insert into charger or tool. Do not crush, drop, or damage battery pack. Do not use a battery
pack or charger that has received a sharp blow, has been dropped or has been run over or damaged
in any way (i.e. pierced with a nail, hit with a hammer, stepped on). Damaged battery packs should be
returned to an authorized HYTORC service center for recycling.
The US Department of Transportation Hazardous Materials Regulations (HMR) actually prohibit
transporting batteries in commerce or on airplanes, (i.e. packed in suitcases and carry-on luggage).
When transporting individual batteries, make sure that the battery terminals are protected and well
insulated from materials that could contact them and cause a short circuit. For any other concerns in
regarding the transportation of LI-ION batteries, consult your Transportation Carrier.
Fire hazard. Do not store or carry battery so that metal objects can contact exposed battery terminals.
For example, do not place battery in aprons, pockets, tool boxes, product kit boxes, drawers with
loose nails, screws, keys etc. Transporting batteries can possibly cause fires if the battery terminals
inadvertently come in contact with conductive materials such as keys, coins, hand tools and the like.

LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual 9
IMPORTANT BATTERY CHARGER SAFETY INSTRUCTIONS
•Before using charger, read all instructions and
cautionary markings on charger, battery pack and
product using battery pack.
•Do not attempt to charge the battery pack with any
chargers other than the one in this manual. The
charger and battery pack are specifically designed to
work together.
•These chargers are not intended for any uses other
than batteries supplied with LITHIUM SERIES Tools
as described in this manual. Any other uses may result
in risk of fire, electric shock or electrocution.
•Do not expose charger to rain or snow.
•To disconnect charger, firmly grasp plug and remove.
Do not disconnect the charger by pull-ing on the cord.
•Make sure the cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage or stress.
•Do not use an extension cord unless it is absolutely
necessary.
•An extension cord must have adequate wire size
(AWG) for safety. In general the larger the wire size the
greater the capacity of the cable.
•Do not block any ventilation slots on charger power
supply.
•DO NOT attempt to charge the battery pack with
any chargers other than the one in this manual. The
charger and battery pack are specifically designed to
work together.
•These chargers are not intended for any uses other
than batteries supplied with LITHIUM SERIES Tools
as described in this manual. Any other uses may result
in risk of fire, electric shock or electrocution.
•Do not expose charger to rain or snow.
•To disconnect charger, firmly grasp plug and remove.
Do not disconnect the charger by pull-ing on the cord.
•Make sure the cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage or stress.
•Do not use an extension cord unless it is absolutely
necessary.
•An extension cord must have adequate wire size
(AWG) for safety. In general the larger the wire size the
greater the capacity of the cable.
•Do not block any ventilation slots on charger power
supply.
WARNING!
WARNING!
CAUTION!
Burn hazard. Battery liquid may be flammable if exposed to spark or flame.
Burn hazard. To reduce the risk of injury, charge only tool batteries. Other types of batteries may burst
causing personal injury and damage.
Under certain conditions, with the charger plugged into the power supply, the charger can be
shorted by foreign material. Foreign materials of a conductive nature such as, but not limited to, steel
wool, aluminum foil, or any buildup of metallic particles should be kept away from charger cavities.
Always unplug the charger from the power supply when there is no battery pack in the cavity. Unplug
charger before attempting to clean.

10
. TOOL DESCRIPTION
The LITHIUM SERIES® Electric Torque Tool provides the following.
•High-strength planetary gear drive powered by brushed DC electric motor
•Two Speeds: Fast run-down, high powered torque.
•Electronic control and setup via push-button menu.
•Heads-Up LCD display.
•Ergonomic lightweight hand-held design with pistol-grip and trigger activation.
•Portable tool powered by rechargeable extended-life 36V lithium ion battery.
•Standard square-drive with dual-reaction spline.
•Integrated data acquisition and export capability.
Square Drive Compatible
with Standard Sockets
Cooling Vents
Brushed DC Motor and
Cooling Fans
USB Micro Port
Eyelet
Reaction Spline
Planetary Gear Box
Dual Speed Switch
Trigger
Pistol Grip Handle
Battery Lock Button
36V Rechargeable and
Interchangeable Battery
Batter Test Button and
Charge Indicator
PUSH-BUTTON CONTROL PANEL

LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual 11
FREE SERVICES*
FOLLOW US ONLINE
REPAIRS TOOL RENTALS
HELP
. SERVICE
•User safety training upon receipt of merchandise
•Semi-Annual user safety training on request
•Annual safety seminar on appointment
•Loaner tools in event of product failure within 24 hours
•Torque/Tension consultation/seminar
•Half-Day, first-use supervision
*Above services are not subject to travel expense charges.
•All repairs are guaranteed for 6 months.
•All repairs are subject to labor and part cost as outlined
in the oicial HYTORC price list.
•All repairs will be tested and calibrated to ensure the
highest quality repairs.
•All warranty repairs are free of all charges including
return-freight.
•100% of all paid rentals will be applied as a discount
towards any new purchase in that calendar year
•User training for first-time rentals is free of all cost
•Rental tools are guaranteed to perform and are subject
to the free loaner tool policy of HYTORC
If you require any further assistance, please call your local HYTORC Representative or 1-800-FOR-HYTORC
(1-800-367-4986). Please visit us at HYTORC.com.
•User training for first-time rentals
•Warranty repairs including return-freight
•Annual product inspection on request
•Product demonstrations
•12-Month no-questions-asked warranty
•Upgrades during the lifetime of the tool to enhance
safety, durability, and function

12
. CARE AND HANDLING
ENVIRONMENTAL CONSIDERATIONS
INSPECT TOOLS & CALIBRATION
The LITHIUM SERIES Tool is a rugged industrial tool with an electric motor and electronic control. The following
environmental considerations will help maintain reliable tool operation. Pictured above, keep cooling vents clear (1), and
secure the tool per local practice (2) to protect from dropping.
•The tool will withstand light splashing but do not submerge or subject to continuous rain or extreme humidity.
•The operating temperature of the tool should be less than 150°F.
•All Cooling Vents should be kept clear of dust, dirt and debris to allow internal fans to maintain airflow to keep the motor
and electronics within temperature limits, do not subject the tool to extreme dust environments that would clog the
vents or do not cover the vents with your hand.
•The tool and electronic components are not certified or approved for explosive environments or areas containing
combustible chemical materials.
•Inspect all components; if damaged report any sign of
damage to the shipper and do not use the tool.
•Inspect the tool before each use; repair or replace any
obviously worn or damaged parts.
•Maintenance must be performed by a qualified
technician.
•Modifying any of the components invalidates the
warranty.
•Check the calibration date on the tool. HYTORC
recommends tool recalibration annually.
•If more than a year has passed since last calibration,
contact HYTORC for recalibration.
•When not in use store all tool components in the plastic
storage case.
•Save all instructions and calibration reports in the
storage case.
1 2

LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual 13
. CHARGE, TEST & INSTALL BATTERY
CHARGE THE BATTERY CHARGING INDICATOR
•The LITHIUM SERIES Tool is supplied with two long life
36 volt batteries and a charger.
•Before charging a battery verify the local voltage supply
to ensure capability with the charger; this will typically
be 110 Volts or 220 Volts AC.
•Connect the charging cradle to the power supply.
•Connect the power cord to a grounded outlet.
•If necessary connect the plug adapters for the local
power outlet.
•Insert the battery by sliding it into the charger and
locking into place. The power indicator will be
illuminated green when plugged in.
•The charging indicator flashes green while charging and
turns solid green when the battery is fully charged.
•The 36 volt battery is fully charged in approximately 90
minutes.
1. Charging Cable
2. Battery Pack
3. Charging Cradle
4. Power Supply
5. Power Supply Cord
6. Power Indicator
7. Legend
8. Charging Indicator
9. Fault Indicator
•POWER INDICATOR green when charger is plugged into
AC outlet.
•CHARGING INDICATOR is flashing green while battery
is charging.
•CHARGING INDICATOR solid green when battery is fully
charged.
•FAULT INDICATOR is flashing red for battery fault not
charging.
•Battery is charged in approximately 90 minutes.
1
2
4 5
6
7
8 9
3

14
TEST THE BATTERY
INSTALL THE BATTERY
•The Lithium-Ion battery has a long run life and will
power the tool at full speed until the battery is depleted,
so there is no gradual drop in power during use.
•For continuous use, have one or more spare battery
packs charging while the tool is in use. When need
simply swap batteries from the charger to the tool.
•Batteries can be charged hundreds of times without any
noticeable loss in capacity
•Batteries can be returned at no charge for recycling at
HYTORC locations or local recycling centers.
1. Push the TEST button on the side of the battery and
the LED’s will provide an approximate indicator of
remaining battery life:
1 LED On ≤ 25% Battery Charge Left
2 LEDs On ≤ 50% Battery Charge Left
3 LEDs On ≤ 75% Battery Charge Left
4 LEDs On ≤ 100% Battery Charge Left
The battery easily slides onto the tool
body and snaps into place.
1. Press the release button on the
battery and slide battery pack o
the charger.
2. Align the base of the tool with the
rails in the battery and slide the
battery pack firmly into the handle
until you hear (or see) the lock
snap in place.
3. To remove the battery pack from
the tool, press the release button
on the battery and firmly pull the
battery pack out of the tool.
BATTERY RECYCLING
The RBRC (Rechargeable Battery Recycling Corporation) Seal on the lithium ion battery (or battery pack) indicates that the
costs to recycle the battery (or battery pack) at the end of its useful life have already been paid by HYTORC The RBRC, in
cooperation with HYTORC and other battery users, has established programs in the United States to facilitate the collection
of spent lithium ion batteries. Help protect our environment and conserve natural resources by returning the spent lithium
ion battery to an authorized HYTORC service center for recycling. You may also contact your local recycling center for
information on where to drop o the spent battery. RBRC is a registered trademark of the Rechargeable Battery Recycling
Corporation.

LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual 15
. OPERATING THE CONTROL PANEL
PRIMARY CONTROL FEATURES
•Press Any Button to Power-On Tool (the tool automatically turns o after 5 min)
•A new tool shows the factory default settings
•A tool that has been used before displays the last settings used on the tool before it was powered o.
•Left Button Increases the Torque Value
•Right Button Decreases the Torque Value
•Screen Features; Torque, Angle, Release, Direction, Battery Status, Fastener Type, Data Record Indicator
•Push and hold center button to cycle; TORQUE, ANGLE and RELEASE
•Hold 2 Left Buttons to display main and sub-menu options

16
TOGGLE TORQUE, ANGLE & RELEASE
The tool provides simple access to set Torque, Angle and Release by toggling the center button. The torque setup screen is
the home screen for operating the tool.
2. ANGLE: Press and hold the center button for
approximately 3-seconds and release it to access the
Release screen.
3. RELEASE: Press and hold the center button for
approximately 3-seconds and release it to access the
Torque screen.
1. TORQUE: Press and hold the center button for
approximately 3-seconds and release it to access the
Angle screen.

LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual 17
SET TORQUE
SET ANGLE
SET RELEASE
•Set the Torque Value is set by simply pushing the left button fto increase the torque or by pushing the right button ito
decrease the torque.
•Torque may be set to any value from the minimum to the maximum capability of the tool (or MAX MIN Torque Limits set
in the ADMIN menu).
•Output units may be displayed in lb-ft, N-m, kgf-m or %. (See output unit settings under the ADMIN menu)
•The Torque rotational direction arrow and the rotating nut icon reflect the fastener clockwise or counter clockwise
rotation associate with the specific fastener type. (The fastener type may be set under the Operation – Fastener Type
menu: Right-Hand, Left-Hand, HYTORC NUT and HYTORC Washer).
•Certain bolt tightening specifications may require an Angle Value in-addition to or instead of a Torque Value.
•The tool provides the ability to set an Angle value anywhere from 0 degrees to 360 degrees.
•The Angle Value is increased simply by pushing the left button fto increase the angle or by pushing the right button i
to decrease the angle.
•If an Angle Value is set the gun will add the desired angle of rotation by applying additional torque after the completed
torque operation up to the maximum output of the tool.
•The angle feature is actuated by continuing to hold the trigger after the tool successfully completes the TORQUE.
•The angle force is applied after a time delay set in the Angle Delay menu – typical ½ second to 3 seconds.
•When the tool achieves the TORQUE value (and ANGLE if set) the motor automatically stalls and the gear box continues
to exert force (and reaction force) essentially locking the tool onto the nut.
•The gun provides a feature to release the tool from the nut by setting a RELEASE Angle to reverse the motor slightly thus
taking the applied force o the gear box and reaction point and releasing the tool from the nut without loosening the nut.
•The RELEASE Angle Setting may vary depending on the application and may need to be developed iteratively by testing
the value on the application; the objective is to set the minimum RELEASE angle required to release the tool without
applying a force in the opposite direction that would turn or loosen the nut.
•While the tool has a capability to set the RELEASE between 0 and 359 degrees, the RELEASE is typically set on the lower
end and less than 10 degrees (1-to-3 degrees for HYTORC Washer, or 3-to-7 degrees for reaction arms) so that nut is not
loosened. Under certain conditions the operator may need higher RELEASE Angle settings and these should be verified
to make sure that the nut is not being loosened by the higher setting.
•The automatic release feature is actuated by continuing to hold the trigger after the tool successfully completes TORQUE
(and ANGLE if set).
•During the operation the screen will change to show the release angle and direction, the tool motor will reverse by the
desired release angle and then stall again to allow the tool to be removed from the nut.
•The RELEASE Angle is applied following application of TORQE (and ANGLE if set) and after an additional time delay set
in the Angle Delay menu – typical ½ second to 3 seconds.

18
. NAVIGATING THE MENUS
MAIN MENU AND SUBMENUS
MAIN MENU
The Main Menu provides Operations, Job Data, System, Admin and the Exit and
Power O options.
Press and hold the left and center buttons simultaneously for approximately
three seconds, release buttons when the Main Menu is displayed.
•The green bar highlights the current position
•Press left button fto scroll down, right button to scroll up
•Press the center button ito select and display a sub-menu

LITHIUM SERIES® Electric Torque Tool (BTM-DOC Models) Operations Manual 19
OPERATION MENU
The Operation menu contains most functions for everyday operation.
•The green bar highlights the current position
•Press left button fto scroll down, right button to scroll up
•Press the center button ito select and display a sub-menu
(Continued on following page)
In order to save or load a job profile the
user must first enter the 4-digit code to
unlock the tool. To enter the code press
button to increase the digit or ito
decrease the digit, press to advance
to the next digit until the correct code
is entered (default 0000). When the
4-digit code is entered correctly press
again to JOB PROFILES.
NOTE: Wrong code returns user to
previous screen. There is no limit on
number of attempts. See administrator
for correct code.
Allows the user to save tool parameters
to memory as a Saved Job Profile (SJP),
or to load previously saved parameters
(SJPs) from memory.
The tool can save up to 8 job profiles;
each profile includes saved values for
TORQUE (T), ANGLE (A), RELEASE (R)
and fastener type. Scroll and select the
desired setup values – then select ,
or if saving new setup values select 
to access submenu to either SAVE or
LOAD settings.
The user can SAVE the settings
currently on the home display – now
shown in SAVE settings - by pushing
the left button ialso adds the profile to
the top of JOB PROFILES.
Alternatively, the user can LOAD the
selected profile – now shown in LOAD
settings - by pushing the right button
. Exit without load or save by hitting
the center button X. Return to the
OPERATION Menu upon completion.

20
Press appropriate button i to scroll
up or down, push to select fastener
type:
RH RIGHT HAND bolts tightened
clockwise.
LH LEFT HAND bolts tightened
counterclockwise.
HN HYTORC NUT tightened
counterclockwise.
HW HYTORC WASHER tightened
clockwise.
Any selection returns users to
OPERATION menu.
NOTE: When using the HYTORC
Washer or HYTORC Nut the safety
feature requiring a push of the button
before operation is disabled. Tool
should never be used with a reaction
arm in this setting.
Allows the operator to select the
preferred units of the torque display.
Press buttons to scroll ior to
highlight the desired units, press to
select desired units and return to the
OPERATION menu.
The user can adjust the time delay for
applying the ANGLE and RELEASE
following the TORQUE operation – the
delay can range from 0ms to 3000ms.
The time delay is applied after the
TORQUE value by continuing to hold
the trigger.
Push up button to increase the delay
or down button ito decrease the delay.
Select to return to the OPERATION
menu.
(OPERATION MENU continued from previous page)
