SONATA
Car Infotainment System | Quick Reference Guide
DF7
(English | USA) D-AUDIO2Value
L0MS7-DF000

Be sure to read this Quick Reference Guide and the web manual before using the product to
ensure safety and usability.
To access the web manual for your car infotainment system,
scan the
QR code
below.

1
Accessing the web manual via QR
codes
You can view the web manual of the system by scanning QR codes with your smartphone.
Ü Warning
Park your vehicle in a safe location before scanning the QR code. For safety reasons, you are
not able to access QR codes from the system′s screen while the vehicle is moving.
1 Select one of the following methods to access a QR code.
•On the system′s Home screen, press All Menus >User′s Manual.
•On the system′s Home screen, press All Menus >Setup >General >System Info >
User′s Manual on Web (QR Code).
•Alternatively, find the QR code in the Quick Reference Guide.
2 Install a QR code reader application
from the App Store ()or the Google
Play Store ()and scan a QR code.
3 On your smartphone's screen, press
the URL for the web manual.
•You can view the web manual of the system
in the Internet browser application of your
smartphone.
•Depending on how you scan the QR code,
you may be able to open the web manual
without pressing its URL.

2
Û Note
•You can also scan QR codes with the pre-installed camera application in your iPhone
or Android smartphone. Depending on the Android smartphone type, some camera
applications may not support QR code scanning. For more information, refer to your
smartphone′s user guide.
•By scanning the QR code in each function menu, you can quickly access the information of
the current function (except for some functions).
- After starting a function in the system, press Menu >User′s Manual on Web (QR Code).
•Without scanning the QR code, you can directly enter the URL address to view the web
manual. (http://webmanual.hyundai.com/DA_GEN2_V/AV/USA/English/index.html)

3
Safety warnings
For safety, follow the instructions below. Failure to do so may increase the risk of a traffic
accident, which may result in death or personal injury.
Ü About driving
Do not operate the system while driving.
•Driving while distracted may result in a loss of vehicle control, potentially leading to an accident, severe
personal injury, or death. The driver′s primary responsibility is the safe and legal operation of a vehicle,
and any handheld devices, equipment, or vehicle systems which divert the driver′s attention from this
responsibility should never be used during operation of the vehicle.
Avoid watching the screen while driving.
•Driving while distracted may lead to a traffic accident.
•Stop your vehicle in a safe location before using functions that require multiple operations.
Stop your vehicle first before using your mobile phone.
•Using a mobile phone while driving may lead to a traffic accident.
Keep the volume low enough to hear external sounds.
•Driving without the ability to hear external sounds may lead to a traffic accident.
•Listening to a loud volume for a long time may cause hearing damage.
Ü About handling the system
Do not disassemble or modify the system.
•Doing so may result in an accident, fire, or electric shock.
Do not allow liquids or foreign substances to enter the system.
•Liquids or foreign substances may cause noxious fumes, a fire, or a system malfunction.
Stop using the system if it malfunctions, such as no audio output or display.
•If you continue using the system when it is malfunctioning, it may lead to a fire, electric shock, or system
failure.
Û Note
If you experience any problems with the system, contact your place of purchase or dealer.

4
Safety cautions
For safety, follow the instructions below. Failure to do so may result in personal injury or
damage to the system.
Ý About operating the system
Use the system with the engine running.
•Using the system for a long time when the engine is stopped may discharge the battery.
Do not install unapproved products.
•Using unapproved products may cause an error while using the system.
•System errors caused by installing unapproved products are not covered under the warranty.
Ý About handling the system
Do not apply excessive force to the system.
•Excessive pressure on the screen may damage the LCD panel or the touch panel.
When cleaning the screen or button panel, make sure to stop the engine and use a
soft, dry cloth.
•Wiping the screen or buttons with a rough cloth or using solvents (alcohol, benzene, paint thinner, etc.) may
scratch or chemically damage the surface.
If you attach a liquid-type air freshener to the fan louver, the surface of the louver may
become deformed due to the flowing air.
Û Note
If you experience any problems with the system, contact your place of purchase or dealer.

5
HYUNDAI VEHICLE OWNER PRIVACY
POLICY
Your Hyundai vehicle may be equipped with technologies and services that use information
collected, generated, recorded or stored by the vehicle. Hyundai has created a Vehicle
Owner Privacy Policy to explain how these technologies and services collect use and share
this information.
You may read our Vehicle Owner Privacy Policy on the Hyundaiusa.com website at:
https://www.hyundaiusa.com/owner-privacy-policy.aspx
If you would like to receive a hard copy of our Vehicle Owner Privacy Policy, please contact
our Customer Connect Center at:
Hyundai Customer Care
P.O. Box 20850
Fountain Valley, CA 92728
800-633-5151
[email protected]
Hyundai′s Customer Connect Center representatives are available Monday through Friday,
between the hours of 5:00 AM and 7:00 PM PST and Saturday and Sunday between 6:30 AM
and 3:00 PM PST (English).
For Customer Connect Center assistance in Spanish or Korean, representatives are available
Monday through Friday between 6:30 AM and 3:00 PM PST.

6
Component names and functions
Control panel
Note: Depending on the vehicle model and specifications, the illustration shown may
differ in appearance and layout.
a Radio button
•Turn on the radio. While listening to the radio, press repeatedly to change the radio
mode.
b Media button
•Play content from a media storage device. If you have multiple media storage devices,
select one from the media selection window.
•Press and hold to display the media selection window.
c Custom button
•Use a custom function.
•Press and hold to access the Custom Button settings screen.
d Power button/Volume knob
•Turn the radio/media function on or off.
•Press and hold to turn off the screen and the sound.
•Turn to the left or right to adjust the system sound volume.
e Reset button
•Restart the system.
1
2
3
4
5

7
f Search backward/forward button (SEEK/TRACK)
•While using the radio/media function, change the station/track/file.
•While listening to the radio, press and hold to change the station quickly.
•While playing media, press and hold to rewind or fast forward (except for the Bluetooth
audio mode).
g Setup button
•Access the settings screen.
•Press and hold to access the System Info screen.
h Search knob (TUNE FILE)
•While listening to the radio, adjust the frequency or change the station.
•While playing media, search for a track/file (except for the Bluetooth audio mode).
•During a search, press to select the current track/file.
6
6
7
8

8
Steering wheel remote control
Note: Depending on the vehicle model and specifications, the illustration shown may
differ in appearance and layout.
1
2
34
5 6
a Voice recognition button
•Start or end voice recognition of a connected smartphone via phone projection. (The
button′s operation may vary depending on smartphone specifications.)
b Mode button
•Change the mode (radio, media, etc.).
•Press and hold to access the Steering Wheel MODE Button settings screen.
c Volume lever/Mute button
•Adjust the sound volume.
•Press to mute or unmute the system.
•While playing media, press to pause or resume playback.
d Search lever
•While using the radio/media function, change the station/track/file.
•While listening to the radio, press and hold to change the station quickly.
•While playing media, press and hold to rewind or fast forward (except for the Bluetooth
audio mode).
e Call/Answer button
•Start connecting a mobile phone via Bluetooth.
•After a Bluetooth phone connection is made, access your call history. Press and hold to
dial the most recent phone number. When a call comes in, answer the call.
•During a call, switch between the active call and the held call. Press and hold to switch
the call between the system and the mobile phone.
f Call end button
•When a call comes in, reject the call.
•During a call, end the call.

9
Turning the system on or off
Turning on the system
1 To turn on the system, start the engine.
2 When the safety warning appears, read it and press Confirm.
•To change the system language, press Language.
Ü Warning
•Driving while distracted can result in a loss of vehicle control that may lead to an accident,
severe bodily injury, or death. The driver′s primary responsibility is the safe and legal
operation of the vehicle, and the use of any vehicle systems, including the touch screen
and steering wheel controls, which take the driver′s eyes, attention, and focus away from
the safe operation of the vehicle, or which are not permissible by law, should never be
used during the operation of the vehicle.
•Some functions may be disabled for safety reasons while the vehicle is moving. They work
only when the vehicle stops. Park your vehicle in a safe location before using any of them.
In a manual transmission vehicle, apply the parking brake to use the functions. In an
automatic transmission vehicle, shift to "P" (Park) or apply the parking brake.
•Stop using the system if it malfunctions, such as no audio output or display. If you
continue using the system when it is malfunctioning, it may lead to a fire, electric shock, or
system failure.
Ý Caution
•You can turn on the system when the key ignition switch is placed in the "ACC" or "ON"
position. Using the system for an extended period without the engine running drains the
battery. If you plan on using the system for a long time, start the engine.
•If you turn on your system without starting the engine, a battery warning will appear.
Once the engine starts, the battery warning will disappear.

10
Turning off the system
If you do not want to use the system while driving, press and hold the
Power button on the control panel.
•The screen and the sound will turn off.
•To use the system again, press the Power button.
After you have turned off the engine, the system will automatically turn off
after a while or as soon as you open the driver's door.
•Depending on the vehicle model or specifications, the system may turn off as soon as you
turn off the engine.
Product specifications
Common specifications
Item Specifications
Dimensions (W x H x L) 441.8 x 148.6 x 201 mm
Weight •With a built-in amplifier: 2.04 kg
•With a built-in amplifier and Blue Link support: 2.08 kg
•With an external amplifier and Blue Link support: 2.07 kg
Display
Item Specifications
Size (W x H) 8 inch (176.4 x 99.36 mm)
Pixel number 384,000 pixels (resolution: 800 x 480)
Operating method Thin Film Transistor (TFT) Active Matrix
Viewing angle Left/Right, Top/Bottom: 89°
Internal lighting LED

11
Disclaimers
•Driving while distracted is dangerous and should be avoided. Drivers should remain
attentive to driving and always exercise caution when using the steering-wheel-mounted
controls while driving.
•Driving while distracted can result in a loss of vehicle control that may lead to an accident,
severe personal injury and death. The driver′s primary responsibility is in the safe and
legal operation of a vehicle, and use of any handheld devices, other equipment or vehicle
systems which take the driver′s eyes, attention and focus away from the safe operation of
a vehicle or that are not permissible by law should never be used during operation of the
vehicle.
•SiriusXM®: SiriusXM Satellite Radio, SiriusXM Traffic and SiriusXM Travel Link each require
a subscription sold separately, or as a package, by SiriusXM Radio Inc. If you decide
to continue your service at the end of your trial subscription, the plan you choose will
automatically renew and bill at then-current rates until you call 1-866-635-2349 to cancel.
See SiriusXM Customer Agreement for complete terms at www.siriusxm.com. Other fees
and taxes will apply. All fees and programming are subject to change. Not all vehicles
or devices are capable of receiving all services offered by SiriusXM. Data displays and
individual product availability vary by vehicle hardware. Current information and features
may not be available in all locations, or on all receivers. Weather Forecast, Current
Conditions may not be available in all locations. Images above are for representative
purposes only and are not real products. For actual features and images of real products,
consult the vehicle manufacturer. SiriusXM is not responsible for any errors or inaccuracies
in the data services or their use in the vehicle. Travel Link Stocks displays current price and
daily delta of around 7,000 actively reported securities traded on the NYSE®, NASDAQ®
and AMEX®. The service is delayed approximately 20 minutes. SiriusXM satellite service is
available only to those at least 18 years of age in the 48 contiguous USA, DC, and Puerto
Rico (with coverage limitations). SiriusXM Internet Radio service is available throughout
our satellite service area and in AK and HI. ©2018 SiriusXM Radio Inc.
•Android Auto: Vehicle user interface is a product of Google and its terms and privacy
statements apply. Requires the Android Auto app on Google Play and an Android
compatible smartphone running Android™5.0 Lollipop or higher. Data plan rates apply.

12
FCC Certification
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with minimum 20 cm between the radiator
and your body. This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter unless authorized to do so by the FCC.

1
Car Infotainment System
User's Manual
[ This guide covers specifications for
all vehicle models, including optional
specifications, and is based on the latest
version of system software.
[ Your system's functions and
specifications are subject to change
without prior notice for performance
improvement.
[ The functions and services described
in this guide are subject to change
without prior notice for performance
improvement. If the system software is
updated, the screenshots in this guide
may appear different than the actual
images on the system.
[ You can view the up-to-date information
about changed functions and services
from the web manual.
[ The functions and services described
in this guide may differ from those
provided in your vehicle. For precise
information related to your vehicle,
refer to the owner's manual or catalog
of your vehicle.
[ Your system is not compatible with the
system software for regions outside of
the country of purchase.
Available
information for
users
Car Infotainment
System Quick
Reference Guide (Print)
This guide contains basic information to
use your system including component
names and functions. To use your
system correctly and safely, read this
guide before use.
Car Infotainment
System User's Manual
(Web)
This guide is a web manual you can
access by scanning a QR code in the
Quick Reference Guide or on your
system′s screen. This guide introduces
your system's functions and explains
how to use them.

2
Symbols used in
this guide
Warning
Indicates important information
related to user safety. Failure to follow
warnings may result in death or serious
personal injury.
Caution
Indicates important information related
to user safety. Failure to follow cautions
may result in personal injury, or
damage or malfunction your vehicle.
Note
Indicates helpful information for
convenient use.
(if equipped)
Indicates descriptions for optional
features, which may not be available on
your specific vehicle depending on the
model or trim level.
This guide covers specifications
for all vehicle models, including
optional specifications. It may include
descriptions for features that are
not equipped in your vehicle or are
unavailable for your vehicle model.
Safety warnings
For safety, follow the instructions below.
Failure to do so may increase the risk of a
traffic accident, which may result in death
or personal injury.
Ü About driving
Do not operate the system while
driving.
•Driving while distracted may result in a loss
of vehicle control, potentially leading to an
accident, severe personal injury, or death. The
driver′s primary responsibility is the safe and
legal operation of a vehicle, and any handheld
devices, equipment, or vehicle systems
which divert the driver′s attention from this
responsibility should never be used during
operation of the vehicle.
Avoid watching the screen while driving.
•Driving while distracted may lead to a traffic
accident.
•Stop your vehicle in a safe location before using
functions that require multiple operations.
Stop your vehicle first before using your
mobile phone.
•Using a mobile phone while driving may lead to
a traffic accident.
Keep the volume low enough to hear
external sounds.
•Driving without the ability to hear external
sounds may lead to a traffic accident.
•Listening to a loud volume for a long time may
cause hearing damage.

3
Ü About handling the system
Do not disassemble or modify the
system.
•Doing so may result in an accident, fire, or
electric shock.
Do not allow liquids or foreign
substances to enter the system.
•Liquids or foreign substances may cause
noxious fumes, a fire, or a system malfunction.
Stop using the system if it malfunctions,
such as no audio output or display.
•If you continue using the system when it is
malfunctioning, it may lead to a fire, electric
shock, or system failure.
Û Note
If you experience any problems with the
system, contact your place of purchase or
dealer.
Safety cautions
For safety, follow the instructions below.
Failure to do so may result in personal
injury or damage to the system.
Ý About operating the system
Use the system with the engine
running.
•Using the system for a long time when the
engine is stopped may discharge the battery.
Do not install unapproved products.
•Using unapproved products may cause an error
while using the system.
•System errors caused by installing unapproved
products are not covered under the warranty.
Ý About handling the system
Do not apply excessive force to the
system.
•Excessive pressure on the screen may damage
the LCD panel or the touch panel.
When cleaning the screen or button
panel, make sure to stop the engine
and use a soft, dry cloth.
•Wiping the screen or buttons with a rough
cloth or using solvents (alcohol, benzene, paint
thinner, etc.) may scratch or chemically damage
the surface.
If you attach a liquid-type air freshener
to the fan louver, the surface of the
louver may become deformed due to
the flowing air.
Û Note
If you experience any problems with the
system, contact your place of purchase or
dealer.

4
HYUNDAI
VEHICLE OWNER
PRIVACY POLICY
Your Hyundai vehicle may be equipped
with technologies and services that
use information collected, generated,
recorded or stored by the vehicle. Hyundai
has created a Vehicle Owner Privacy
Policy to explain how these technologies
and services collect use and share this
information.
You may read our Vehicle Owner Privacy
Policy on the Hyundaiusa.com website at:
https://www.hyundaiusa.com/owner-
privacy-policy.aspx
If you would like to receive a hard copy of
our Vehicle Owner Privacy Policy, please
contact our Customer Connect Center at:
Hyundai Customer Care
P.O. Box 20850
Fountain Valley, CA 92728
800-633-5151
[email protected]
Hyundai′s Customer Connect Center
representatives are available Monday
through Friday, between the hours of 5:00
AM and 7:00 PM PST and Saturday and
Sunday between 6:30 AM and 3:00 PM PST
(English).
For Customer Connect Center assistance
in Spanish or Korean, representatives are
available Monday through Friday between
6:30 AM and 3:00 PM PST.

5
1
System overview
Component names and functions 1-2
Control panel 1-2
Steering wheel remote control 1-4
Turning the system on or off 1-5
Turning on the system 1-5
Turning off the system 1-6
Using the touch screen 1-6
Getting to know the Home screen 1-8
Getting familiar with the Home screen
layout 1-8
Changing the Home screen widgets 1-9
Changing the Home screen menu
icons 1-9
Getting to know the All Menus
screen 1-10
Getting familiar with the All Menus
screen layout 1-10
Rearranging the All Menus screen 1-11
2
Useful functions
Using phone projection 2-2
Connecting your Android smartphone
via Android Auto 2-3
Connecting your iPhone via Apple
CarPlay 2-5
Getting to know the driving
assistance screen 2-7
Rear view screen 2-7
Surround view monitor (if equipped) 2-8
Viewing driving information (if
equipped) 2-10
Viewing Blue Link notices (if
equipped) 2-11
3
Radio
Listening to the radio 3-2
Turning on the radio 3-2
Changing the radio mode 3-3
Scanning for available radio stations 3-4
Searching for radio stations 3-4
Saving radio stations 3-5
Listening to saved radio stations 3-5
Rearranging the preset list 3-5
Deleting saved radio stations 3-5
Changing the number of radio stations
on the preset list 3-6
Listening to HD Radio™ (if equipped) 3-6
Listening to SiriusXM™ radio (if
equipped) 3-7
Starting SiriusXM radio 3-7
Searching for SiriusXM radio channels 3-9
Selecting radio channels by using
channel numbers 3-9
Viewing the program schedule 3-10
Listening to Featured Favorites
channels 3-10
4
Media
Using the media 4-2
Listening to music from a USB device 4-2
Listening to music via Bluetooth 4-6
Contents

6
5
Phone
Connecting Bluetooth devices 5-2
Pairing devices with your system 5-2
Connecting a paired device 5-3
Disconnecting a device 5-4
Deleting paired devices 5-5
Making a call via Bluetooth 5-5
Dialing from your call history 5-6
Dialing from your favorites list 5-7
Dialing from your contacts list 5-9
Dialing from the keypad 5-10
Answering a call via Bluetooth 5-12
Accepting or rejecting a call 5-12
Using functions during a call 5-13
Switching between calls 5-14
6
Voice functions
Using Voice Memo 6-2
Starting Voice Memo 6-2
Recording voice memos 6-3
Playing voice memos 6-3
7
Blue Link (if equipped)
Blue Link services 7-2
Service limitations 7-2
Activating Blue Link services 7-3
Using the Blue Link menu 7-3
Starting the Blue Link menu 7-3
Diagnosing your vehicle 7-4
Checking maintenance service
intervals 7-5
Configuring the Blue Link settings 7-5
Using safety and security services 7-6
Auto Collision Notification 7-6
SOS 7-6
Stolen Vehicle Recovery 7-7
Contacting the Blue Link Center 7-7
8
Settings
Configuring the vehicle settings (if
equipped) 8-2
Drive Mode (if equipped) 8-2
Seat Position Change Alert (if
equipped) 8-3
Heated/Ventilated Features (if
equipped) 8-3
Climate (if equipped) 8-4
Configuring the device connection
settings 8-5
Bluetooth 8-5
Android Auto 8-6
Apple CarPlay 8-6
Configuring the advanced system
settings 8-6
Custom Button ☆ 8-6
Steering Wheel MODE Button 8-7
Home Screen 8-7
Media Change Notifications 8-7
Extend Rear Camera Use (if equipped) 8-7
Configuring the general system
settings 8-8
Date/Time 8-8
Language 8-8
Keyboard 8-9
Screen Saver 8-9
System Info 8-9
