I-Tech RKP1415 User manual

User
Manual
RKP1415 /1417/1419
1U15 /17 /19 Rackmount
TFTLCDMonitorKeyboardDrawer

RKP1415/ RKP1417 / RKP1419UserManual
Rev. : 1.0
P.1
1.TableofContent P.1
2.Introduction P.2
3.Features P.2
4.PackageContents P.3
5.Optional Accessories P.4
6.PeripheralProducts P.4
7.ImportantSafeguards P.5
8.StructureDiagram P.6
9.DimensionDiagram
RKP1415 P.7
RKP1417 P.8
RKP1419 P.9
10.LCD OSDMenuOperation
LCD MembraneDiagramP.10
MainMenu P.10
Sub MenuP.11-12
11.ResolutionSettings
ForWindowsP.13
ForSunServersP.14
12.TechnicalSpecification P.15
1.TableOfContent

Rev. : 1.0
P.2
RKP Seriesisacombination ofkeyboard,mouseand monitorintoadrawer,
withfeaturessuchasflip-updesign, adjustablebrackets,builtinLCD OSDto
provide effectiveassistant foran administratortocontrolPCsystem.
RKP Seriesprovidescosteffectiveforyourlimited ITbudgetoverusingCRT
and rack mounting. Also, it willbe spacesavingforyourcompact environment
rack and effectiveassistant foran administratortocontrolPCsystem.
2.Introduction
3.Features
Threemodelstochoosefrom15 , 17 or19 LCD Panel
Short depthof 440mm / 480mm only
Suitablefor600mmdeep cabinet
Twokeyboardsselectionssupportingmultiplelanguages
Uniquemechanicaldesigntomaximumrack mountablespace
Black anodized aluminumfront panel
Lock out railstoprevent movement of the keyboard
Suppliedwith12V5Aremotepoweradapter
Disclaimer
Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno
responsibilityfordamage orclaims,resulting frommisuseormisinterpretation
RKP1415/ RKP1417 / RKP1419UserManual

Rev. : 1.0
P.3
4.PackageContents
Before Unpacking
It isvery importanttolocatetheLCD KeyboardDrawerinasuitableenvironment.
The surfaceforplacingand fixing the LCDKeyboardDrawershouldbe stableand levelor
mounted intoasuitablecabinet.
Makesuretheplacehasgood ventilation,isoutofdirectsunlight,awayfromsourcesof
excessivedust, dirt,heat, water,moistureand vibration.
Convenienceforconnecting the LCD KeyboardDrawertothe related facilitiesshouldbe
well considerstoo.
Unpacking
The LCD keyboarddrawercomeswiththe standardpartsshownasabove.Checkand make
suretheyareincluded and ingood condition.Ifanything ismissing,ordamage,contactthe
supplierimmediately.
LCD Monitor1Piece
UserManual1Piece
DCPowerAdapter1Piece
PowerCord1Piece
Mounting Bracket1Pair
Fasteners4Pieces
CD-63-in-1KVMcable1Piece
RKP1415/ RKP1417 / RKP1419UserManual

Rev. : 1.0
P.4
5.OptionalAccessories
SUN-31SUN/ iMacUSBtoPS/2Adapter
12V/ 24V/ 48VDCPower
VideoInput
6.PeripheralProducts
RKP1415/ RKP1417 / RKP1419UserManual
ModelDescription
CV-401 /CV-801 /CV-16014-Port/8-port/16-PortPS/2KVMswitch
CV-160216-Port2-ConsolePS/2KVMswitch
CV-S801 /CV-S16018-Port/16-portUSBKVMswitch
CV-S160216-port2-ConsoleUSBKVMswitch
CV-101CAT.5PS/2KVMextender

Rev. : 1.0
P.5
Pleaseread allof theseinstructionscarefullybeforeyou usethe device.
Savethismanualforfuturereference.
UnplugtheLCD KeyboardDrawerfromthepoweroutletbeforecleaning.
Donotsprayliquidcleanersoraerosoldirectlyonthedevice.Wetaclothwitha
neutraldetergent(e.g.cleanwater) andsqueezeittight,then cleanthe screen
slightlywithit.
Donotexposethe LCDKeyboardDrawerdirectlytorain,water,moistureor
sunlight.
Avoidpressureonthe LCD screentopreventpermanentdamagetothedisplay.
Donotattempttoservicethe deviceyourself.Improperoperationmayvoidyour
warranty. Referall servicingtoqualifiedservicepersonnel.
Safestorage environment oftheLCD KeyboardDrawerisrangingbetween –20oC
and60oC.Permanent damagecouldoccuriftheLCD KeyboardDrawerisstored
outside thesaferange.
UnplugtheLCD KeyboardDrawerimmediatelyand call qualifiedserviceperson-
nelunderthefollowingconditions:
1.The VGAsignalcordisfrayedordamaged.
2.Ifthe monitorhasbeenexposedtorain,liquidorwater.
3. Ifthe monitorhasbeendroppedorthecasinghasbeendamaged.
Whatthewarrantydoes notcover
1.Anyproduct,onwhichtheserialnumberhasbeendefaced,modifiedor
removed.
2.Damage,deteriorationormalfunction resulting from:
a)Accident,misuse,neglect,fire,water,lightning,orotheractsofnature,
unauthorized productmodification,orfailuretofollowinstructionssupplied
withthe product.
b)Repairorattemptedrepairbyanyonenotauthorized byus.
c)Anydamageof theproductduetoshipment.
d)Removalorinstallationof the product.
e)Causesexternaltotheproduct, suchaselectricpowerfluctuation orfailure.
f)Useof suppliesorpartsnot meetingourspecifications.
g)Normalwearand tear.
h)Anyothercauseswhichdoesnotrelatetoaproduct defect.
3. Removal, installation, andset-upservicecharges.
7.Important Safeguards
RKP1415/ RKP1417 / RKP1419UserManual

•
Rev. : 1.0
P.6
8. StructureDiagram
1.PS/2keyboard
2.Aluminiumfrontpanel
3.Class AactivematrixTFT LCD panel
4.Analogtodigitalsignalconverter board
5.Rearmetalcase
6.LCD inverter
7.LCD membrane
8.Adjustablemountingbracket
RKP1415/ RKP1417 / RKP1419UserManual
‚ƒ„…†
‡ˆ

Rev. : 1.0
P.7
RKP1415 1U15 LCD KeyboardDrawer
9.Dimension Diagram
RKP1415/ RKP1417 / RKP1419UserManual
15 LCD

Rev. : 1.0
P.8
RKP1417 1U17 LCD KeyboardDrawer
9.Dimension Diagram
RKP1415/ RKP1417 / RKP1419UserManual
17 LCD

RKP1419 1U19 LCD KeyboardDrawer
9.Dimension Diagram
RKP1415/ RKP1417 / RKP1419UserManual
Rev. : 1.0
P.9
19 LCD

Rev. : 1.0
P.10
10.LCD OSDMenuOperation
LCD MembraneDiagram
Left Right Exit
Menu/SelectionPower
MAINMENU
BRIGHT/CONTRAST
AUTOADJUST
PHASE/CLOCK
H/VPOSITION
MISC
RESET
MainMenu
Bright/ Contrast
Toenterintothe Bright, Blacklevel&Contrast sub-menu
AutoAdjust
Toperformautomaticoptimisationsof allfunctions
An “Adjusting message isdisplayed duringthe process
Phase / Clock
Toenterintothe phase&clock sub menu
H/VPosition
Toenterintothe H/VPosition sub-menu
MISC
Toenterintothe MISCsub-menu
Reset
Reset tothedefaultfactorysettings
RKP1415/ RKP1417 / RKP1419UserManual

Rev. : 1.0
P.11
Bright/ Contrast
1.Brightness
Toperformbrightness adjustment of the inputRGBsignal
UsetheLeft&Rightbuttontoadjust andbuttonto “Brightness
2.Contrast
Toadjust the contrastlevelof theinput signal
Usethe Left&Right button toadjust and button to “Contrast
Phase/ Clock
1. Phase
Toadjust input videosampling clock’sphase
Usethe Left&Right button toadjust and button to “Phase
2. Clock
Toadjust input videosampling clock
Usethe Left&Right button toadjust and button to “Clock
H/VPosition
1. H.Position
Toadjust the horizontalsizeof theframe
Usethe Left &Right button toadjustand buttonto “H.position .
2.V.Position
Toadjust the verticalpositionof theframe
Usethe Left&Right button toadjust and button to “V.position .
10.LCD OSDMenuOperation
RKP1415/ RKP1417 / RKP1419UserManual

Rev. : 1.0
P.12
10.LCD OSDMenuOperation
MISC
1.Information
The firstheaderrowshowsthe current resolution setup
The second headerrowshowsthe horizontalfrequency ofthecurrent
input signal
The thirdheaderrowshowsthe verticalfrequency ofthecurrentinput
signal
2.OSDTimer
Tomodifythe durationof theOSDtime-out
3.Color
a) 5500K
Select ColourTempat 5500K
b)6500K
Select ColourTempat 6500K
c) 9500K
Select ColourTempat 9500K
d)User
Change ColourTempbymanual
4.Language
Toselectthelanguageof OSDmenu 7Languages:
(1)English
(2)Japanese(日本語)
(3)Chinese(中文)
(4)German
(5)Francais
(6)Espanol
(7)Italiano
RKP1415/ RKP1417 / RKP1419UserManual

Rev. : 1.0
P.13
11.ResolutionSettings
ForMicrosoftWindows
Step 1 –Press rightclickon thedesktop
Step2 –Choose “Properties
Step3 –Change the “Screen Resolution
Step4 –Change the “Screen refreshrate
RKP1415/ RKP1417 / RKP1419UserManual

Rev. : 1.0
P.14
11.ResolutionSettings
ForSUN Servers
ResolutionconfigurationproceduresshouldberunbyqualifiedSUN
serveradministrator
Sun Serversareusing resolution at 1152 x900x76Hz.
Supported resolutionmode for15 LCD:
1024 x768 x70/75Hz
Supported resolutionmode for17 LCD:
1280 x1024 x75Hz
You needtochange the SunServerresolution beforeyouconnectto
LCD Display.
Pleasedothe following procedurestochangethe resolution settings:
1.Asroot:
You mayfind the followingcomment “/user/sbin/m64config .
2.Toviewcurrentresolution:
Type “/user/sbin/m64config –prconf .
3. Tochange to1024x768 @70MHz:
Type “/user/sbin/m64config –res1024x768x70 now .
4.The screen willbe rubbish.
5. Then type “pkillXsun .
And Type “pkillXsession torestart theXsession.
UnderCommon Desktop Environment (CDE).
TochangetheOpenBootresolution,youcantypethefollowing
command inOKprompt.
1.InOKprompt, type “setenvoutput-devicescreen:r1024x768x70 .
2.Type “printenv toconfirmthe resolutionhasbeen changed
to1024x768x70Hz.
3. Then type, “reset torestartthe system.
Note:RemembertoRESTARTthe serveraftertheseprocesses.
Note: RemembertoRESTARTthe serveraftertheseprocesses
RKP1415/ RKP1417 / RKP1419UserManual

Rev. : 1.0P.15 Printat8/2004
12.Technical Specification
RKP1415/ RKP1417 / RKP1419UserManual
Item
LCDScreen
Manufacturer
LCDOrigin
Panel 15 TFT17 TFT19 TFT
Resolution 1,024x7681,280x1,0241,280x1,024
Brightness 300 cd/m2350 cd/m2500 cd/m2
Color 16.2Million16.2Million16.7Million
ContrastRatio 450:1350:1500:1
ViewingAngle 140°x125°140°x120°170°x170°
DisplayArea 304x228mm337x270mm376x301mm
Pixel Pitch 0.297mm0.264mm0.294mm
ResponseTime(Tr) 15ms
ResponseTime(Tf) 10ms
BackLight
HorizontalSync. 48.4kHz64~80kHz64kHz
VerticalSync. 65 MHz60~75Hz60Hz
InputSignal
PowerManagement
PowerInput
VideoInput
Dimension
Weight
Description
5ms
15 TFT
SouthKorea
20ms
4xColdCathodeFluorescentTube
AnalogRGB 0.7Vp-p
VESA DPMS
OSDControl
Brightness, Contract, Colour,Clock
H.Position, V.Position,Phase, Scaling
AutoConfig.,Input Select,Multi-Window
ClearEEPROM, OSDadjust
RKP1415: 9kg/1417 : 10kg/ 1419: 12kg
12VDCAdapter
15-pinD-SubConnector
RKP1415/ 1417:44.2Wx4.45Hx44Dcm
RKP1419:44.2Wx4.45Hx48Dcm
*All brand names, logoregisteredtrademarksarepropertiesoftheirrespectiveowners
