MODEL# BBF22L
BOX/FILE PEDESTAL W/ LOCK
ASSEMBLY INSTRUCTIONS
X2
• Remove all wrapping materials, including staples & packing straps before you start
Note:
• Place all laminated parts on a clean and smooth surface such as a rug or carpet to avoid the parts
from being scratched.
• Check to be sure that you have all parts and hardware.
to assemble
• Do not tighten all screw/bolts until completely assembled.
• Keep all hardware parts out of reach of children.
Step 1:
Step 2:
Remove Drawers
Turn over the desk. If there are existing
L brackets attached, remove them so that
the pedestal can be added.
Tightening
X2
Tightening
A D
Bolt
4 pcs.
B
File Clip
2 pcs.
Washer
4 pcs.
C E
Wood Screw
20 pcs.
F
L Bracket
2 pcs.
G
Keys
1 set
J
300 x 16 x 3mm
Metal Bar
1 pc.
A D B
File Clip
2 pcs.
Washer
4 pcs.
C E
Wood Screw
20 pcs.
F
L Bracket
2 pcs.
G
Keys
1 set
J
300 x 16 x 3mm
Metal Bar
1 pc.
Bolt
4 pcs.
B
Metal Handle 3 Sets

Step 3:
Attached pedestal to top
return, desk or credenza
Add L brackets (G).
Step 4:
For added strength attach
pedestal to desk leg panel
from inside pedestal using
bolts (D) x 4.
DO NOT OVER TIGHTEN
Step 5:
Turn over the desk
with the hanging pedestal
and push in the drawers
Maximum loading weight:
Top & Middle drawer: 17 lbs
Bottom drawer: 52 lbs
MODEL# BBF22L
BOX/FILE PEDESTAL W/ LOCK
ASSEMBLY INSTRUCTIONS
X2
Tighten x4
A D
Bolt
4 pcs.
B
File Clip
2 pcs.
Washer
4 pcs.
C E
Metal Handle 2 Sets
Wood Screw
20 pcs.
F
L Bracket
2 pcs.
G
Keys
1 set
J
300 x 16 x 3mm
Metal Bar
1 pc.
B
Metal Handle 3 Sets
