IBEX TS100 User manual

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
TS100 Belt Rake
IMPORTANT
READ
BEFORE
FIRST USE

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
TS100 Belt Rake
ASSEMBLY TIPS
Note: The images shown in this guide are of the smaller TX80 Belt Rake, but the steps are the same.
Inspect your rake upon arrival. Check all sides for any damage that may have
occurred during shipping. If you see any damage, take pictures and contact your
IBEX dealer. Once inspected, remove all protective plastic wrap from the rake
(Figure 1).
Figure 1

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
Cut and remove the banding and zip ties holding the hay stop, box of parts, and
PTO shaft (Figure 2 & Figure 3).
Figure 2
Figure 3
Remove the hay stop guard arm and side guard panels (Figure 4 & Figure 5).
These are secured to the pallet via wood screws and washers. Then place them
to the side.
Figure 4 Figure 5
Remove the lag bolts that are holding the main three point hitch in place (Figure
6). Then cut the banding holding the back of the belt rake frame (Figure 7).

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
Figure 6 Figure 7
Raise the lift levers to the 4th notch from the top to relieve pressure on the
frame. This will make it easier for the next step (Figure 8).
Figure 8
Now that the belt rake is no longer secured to the pallet, insert a block of wood
to support and lift the front three point hitch of the rake to allow for the tractor
to be hooked up (Figure 9).

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
Figure 9
Back your tractor up to the three point hitch of the rake and hook up to the
three point hitch of your tractor to allow for further assembly of the wheels
(Figure 10).
Figure 10

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
The rear wheels come pre-assembled, upside down, for shipping purposes and
will need to be removed and reinstalled right side up. Lift the rake up with the 3
point hitch far enough to allow for the wheels to be reinstalled after they are
removed (Figure 11). Shortening the top link can help tilt the rake further
upwards in the rear if needed to get enough clearance.
Figure 11
Remove the allen head set screws from the wheel caps on each side (Figure 12).

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
Figure 12
Slide the wheel arms out from above (Figure 13) and reinstall the wheels right
side up (Figure 14). Adjust the retaining cap so it can now sit on the top of the
wheel after being installed right side up. Apply a drop of the provided thread
locker onto the set screw threads before reinstalling into the retaining cap.
Make sure the set screw is properly seated in the groove at the top of the wheel
arm. DO NOT over-tighten the set screws as this will compress the screw against
the arm and prevent the wheel from being able to pivot.

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
Figure 13 Figure 14
Install the support stand with the wheel in the front three point hitch side of the
rake. Secure it with the provided lynch pin (Figure 15).
Figure 15
These next steps can be done either while the rake is connected to the tractor,
or you can take the rake off of the tractor and finish the assembly with the rake
on its own wheels and supported by the support stand (recommended).
Locate the bag of hardware that came in the parts box. Install the side guard
panels using the provided bolts and nylon lock nuts as shown in (Figure 16). Use
a small amount of thread locker on these bolts.

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
Figure 16
Install the tines as seen in (Figure 17), making sure the tines fit into the grooves
on the tine holders. Use a little dab of thread locker on these bolts as well.
Figure 17

QUICK START GUIDE
2022-1.0 IBEX EQUIPMENT CO
The final step is to install the hay stop guard to the hay guard arm. First, insert
the hay arm into the receiving bracket on the belt rake’s frame and tighten down
the retaining bolt. Then install the hardware for the hay stop guard, being sure
to add a little bit of thread locker to each screw (Figure 18).
Figure 18
As with any new implement, the shaft that attaches to the tractor may need to
be cut to length. Consult the included Ibex Equipment PTO Shaft Cutting Guide.
