IBM M768MR User manual

Mainboard User’s Manual
This publication, including all photographs, illustrations and
software, is protected under international copyright laws, with all
rights reserved. Neither this manual, nor any of the material
contained herein, may be reproduced without the express written
consent of the manufacturer.
The information in this document is subject to change without
notice. The manufacturer makes no representations or warranties
with respect to the contents hereof and specifically disclaims any
implied warranties of merchantability or fitness for any particular
purpose. Further, the manufacturer reserves the right to revise this
publication and to make changes from time to time in the content
hereof without obligation of the manufacturer to notify any person
of such revision or changes.
Trademarks
I M, VGA, and PS/2 are registered trademarks of International
usiness Machines.
Intel, Pentium, Pentium-II, Pentium-III, MMX, and Celeron are
registered trademarks of Intel Corporation.
Microsoft, MS-DOS and Windows 95/98/NT are registered
trademarks of Microsoft Corporation.
Sound laster is a trademark of Creative Technology Ltd.
PC-cillin and ChipAwayVirus are trademarks of Trend Micro Inc.
AMI is a trademark of American Megatrends Inc.
A3D is a registered trademark of Aureal Inc.
Gamut is a registered trademark of Formosoft International Inc.
SuperVoice is a registered trademark of Pacific Image
Communications Inc.
MediaRing Talk is a registered trademark of MediaRing Inc.
3Deep is a registered trademark of E-Color Inc.
Other names used in this publication may be trademarks and are
acknowledged.
Copyright © 2000
All Rights Reserved
M768MR, V3.2A
IBXX September 2000

M768MR Mainboard User’s Manual
Notice:
The user must find a properly compatible AGP VGA card in the
133MHz system, because the AGP clock frequency will be over
66MHz.
II

M768MR Mainboard User’s Manual
Table of Contents
Chapter 1: Introduction...................................................................1
Key Features...........................................................................2
Package Contents....................................................................5
Static Electricity Precautions..................................................6
Pre-Installation Inspection......................................................6
Chapter 2: Mainboard Installation..................................................7
Mainboard Components..........................................................8
I/O Ports..................................................................................9
Install A CPU..........................................................................9
Install Memory......................................................................11
Setting Jumper Switches.......................................................12
Install the Mainboard............................................................14
Install the Extension rackets...............................................16
Install Other Devices............................................................17
Expansion Slots....................................................................19
Add-In Card Options............................................................20
Chapter 3: IOS Setup Utility......................................................21
Introduction..........................................................................21
Running the Setup Utility.....................................................22
Standard CMOS Setup Page.................................................23
Advanced CMOS Setup Page...............................................24
Advanced Chipset Setup Page..............................................26
Power Management Setup Page............................................28
PCI / Plug and Play Setup Page............................................30
Load Optimal Settings..........................................................31
Load est Performance Settings...........................................31
Peripheral Setup Page...........................................................32
Hardware Monitor & CPU PnP Setup Page..........................34
Change Supervisor Password................................................35
Auto-Detect Hard Disks........................................................35
Save Settings and Exit..........................................................35
Exit Without Saving Option..................................................36
Chapter 4: Software & Applications.............................................37
Introduction..........................................................................37
Installing Support Software..................................................37
Auto-installing under Windows 98.......................................39
Using the PCI Audio Software..............................................41
III

M768MR Mainboard User’s Manual
The Four Speakers System....................................................42
Appendix A: Corel WordPerfect Suite 8 .................................A1
Welcome to Corel WordPerfect Suite 8 ..............................A2
Installing Corel WordPerfect Suite 8 ..................................A6
Learning how to use Corel WordPerfect Suite 8 .................A9
Support and Services .........................................................A13
Appendix B: Gamut2000 .......................................................... 1
1. GAMUT2000 Family ...................................................... 2
1.1 LifeAmp - Versatile Audio Playback System ............ 2
1.2 AudioPort - Audio Transportation System ................ 4
2. Installation ....................................................................... 5
2.1 efore eginning: System Requirements .................. 5
2.2 Uninstalling the Previous of GAMUT2000................ 5
3. Main Console .................................................................. 7
3.1 Introduction ............................................................... 7
3.2 Function and Operation ............................................. 7
3.3 Main Menu ................................................................ 9
IV

1: Introduction
Chapter 1
Introduction
This mainboard has a Socket 370, which uses an Intel PPGA
(Plastic Pin Grid Array) Celeron or FCPGA Pentium III
processor. You can install any one of these processors on the
mainboard.
The mainboard supports Socket 370 clock speeds up to 933MHz.
This mainboard supports front-side bus speeds of 66MHz,
100MHz or 133MHz.
This mainboard uses the Intel 440 X chipset which provides CPU
Plug & Play through firmware. The mainboard has a built-in PCI
3D Sound System and a V.90 Fax Modem DAA module is
shipped with the mainboard. In addition, the mainboard has a full
set of ATX I O Ports including PS/2 keyboard and mouse ports,
two US ports, a parallel port and two serial ports.
This mainboard has all the features you need to develop a powerful
multimedia workstation that is network ready, and has built-in
communications. The board is Micro ATX size and has power
connectors for an ATX power supply.
1

M768MR Mainboard User’s Manual
Key Features
The key features of this mainboard include:
Socket-370 Processor Support
Supports PPGA Celeron CPUs which provide Pentium II
performance with integrated L1 and L2 cache
FCPGA Pentium III CPUs are supported
Supports 66MHz, 100MHz or 133MHz Front-Side us
All processors are automatically configured using firmware and a
synchronous Host/DRAM Clock Scheme.
Me ory Support
Two DIMM slots for 168-pin SDRAM memory modules
Support for 66MHz, 100MHz and 133MHz memory bus
Maximum installed memory is 2 x 256 M = 512 M
Expansion Slots
One AGP Slot
Three 32-bit PCI slots
One 8/16-bit ISA slot
Onboard IDE channels
Primary and Secondary PCI IDE channels
Support for PIO (programmable input/output) modes
Support for Multiword DMA modes
Support for us Mastering and Ultra DMA 33/66 (optional)
modes
Power Supply and Power Manage ent
ATX power supply connector
ACPI and previous PMU support, suspend switch,
keyboard power on/off
Supports Wake on Modem, Wake on LAN and Wake on
Alarm
2

1: Introduction
Sound Syste
Complies with the PC98 audio specification
16-bit CODEC for full-duplex playback and recording
HRTF 3D professional audio supports both Direct Sound
3D® and A3D®-compatible interfaces plus support for 4-
channel speakers
Driver support for MS-DOS, Microsoft Windows
95/98/2000/NT 4.0
uilt-in 32ohm earphone buffer and 3D surround sound
Provides MPU-401 Game/MIDI port and legacy Sound
laster 16 support
Downloadable Wave-table Synthesizer supports Direct
Music®
Stereo Mixer supports analog mixing from CD-Audio and
Line In or digital mixing from voice, FM/Wave-table and
digital CD-Audio
Onboard I/O Ports
Provides PC99 Color Connectors for easy peripheral device
connections
Floppy disk drive connector with 1Mb/s transfer rate
Two serial ports with 16550-compatible fast UART
One parallel port with ECP and EPP support
Two US ports
Two PS/2 ports for keyboard and mouse
One infrared header for optional module
Hardware Monitoring
uilt-in hardware monitoring for CPU & System
temperatures, fan speeds and mainboard voltages
Fax/Mode DAA Module
56 Kbps Fax Modem DAA module
Supports V.90, V.34, V.32bis, V.32, V.22bis, V.22
Supports Auto Fallback and MNP 5, V.42bis data
compression with 115,200-compatible Virtual UART
Requires 16M RAM and Microsoft Windows 95/98/NT
3

M768MR Mainboard User’s Manual
Onboard Flash ROM
Automatic CPU and board configuration
Supports Plug and Play configuration of peripheral devices
and expansion cards
uilt-in virus protection using Trend’s ChipAwayVirus
provides boot process virus protection.
Bundled Software
PC-Cillin provides automatic virus protection under
Windows 95/98
SuperVoice is data, fax and voice communication software
Gamut2000 provides professional audio features included
MP3 encoding/playback
MediaRing Talk provides PC to PC or PC to Phone
internet phone communication
3Deep delivers the precise imagery and displays accurate
color in your monitor
Corel WordPerfect Suite 8 is an office application suite
under Windows® (optional)
WinDVD is a DVD playback application (optional)
Di ensions
Micro ATX form factor (24.4cm x 22cm)
4

1: Introduction
Package Contents
Your mainboard package ships with the following items:
The mainboard
This User’s Guide
1 UDMA/66 IDE cable
1 Floppy disk drive cable
1 Fax/Modem DAA module
Support software on CD-ROM disk
5

M768MR Mainboard User’s Manual
Static Electricity Precautions
Components on this mainboard can be damaged by static
electricity. Take the following precautions when unpacking the
mainboard and installing it in a system.
1. Keep the mainboard and other components in their original
static-proof packaging until you are ready to install them.
2. During installation, wear a grounded wrist strap if possible. If
you don’t have a wrist strap, discharge static electricity by
touching the bare metal of the system chassis.
3. Handle the mainboard carefully by the edges. Avoid touching
the components unless it is absolutely necessary. During
installation put the mainboard on top of the static-protection
packaging it came in with the component side facing up.
Pre-Installation Inspection
1. Inspect the mainboard for damage to the components and
connectors on the board.
2. If you suspect that the mainboard has been damaged, do not
connect power to the system. Contact your mainboard vendor
and report the damage.
6

2: Mainboard Installation
Chapter 2
Mainboard Installation
To install this mainboard in a system, follow the procedures in this
chapter:
Identify the mainboard components
Install a CPU
Install one or more system memory modules
Verify that any jumpers or switches are set correctly
Install the mainboard in a system chassis (case)
Connect any extension brackets or cables to the mainboard
connector headers
Install any other devices and make the appropriate connections
to the mainboard connector headers.
Note:
1. efore installing this mainboard, make sure jumper JP1 is set
to Normal, the default setting is set to Clear CMOS. See this
chapter for information on locating JP1 and the setting options.
2. Never connect power to the system during installation. Doing
so may damage the mainboard.
7

M768MR Mainboard User’s Manual
Mainboard Components
Use the diagram below to identify the major components on the
mainboard.
Note: Any jumpers on your mainboard that do not appear in
this illustration are for testing only.
8

2: Mainboard Installation
I/O Ports
The illustration below shows a side view of the built-in I/O ports
on the mainboard.
Install CPU
This mainboard has a Socket-370 which supports Celeron PPGA
and FCPGA Pentium III processors.
Do not try to install a Socket 7 processor in the Socket-370. A
Socket 7 processor such as the Pentium-MMX, or the AMD K5/K6
does not fit in the Socket 370.
The following list notes the processors that are currently supported
by this mainboard.
FCPGA Pentium III: 500~933MHz, FS : 100MHz, 133MHz
PPGA Celeron: 300~600MHz, FS : 66 MHz
9

M768MR Mainboard User’s Manual
Installing a Socket-370 Processor
A processor installs into the ZIF (Zero Insertion Force) Socket-370
on the mainboard.
1. Locate the Socket-370 and CPUFAN1. Pull the locking lever
out slightly from the socket and raise it to the upright position.
2. On the processor, identify the Pin-1 corner by its beveled edge.
3. On the Socket-370, identify the Pin-1 corner. The Pin-1 corner
is at the end of the locking lever when it is locked.
4. Match the Pin-1 corners and insert the processor into the
socket. No force is required and the processor should drop into
place freely.
5. Swing the locking lever down and hook it under the catch on
the side of the socket. This secures the CPU in the socket.
6. All processors should be installed with a combination heatsink/
cooling fan, connect the cable from the fan to the CPU fan
power connector CPUFAN1.
10
CPUFAN1
Pin-1 Corner
Socket-370

2: Mainboard Installation
Install Memory
The mainboard has two DIMM sockets for system memory
modules. You must install at least one memory module in order to
use the mainboard.
For this mainboard, you must use 168-pin, 3.3V unbuffered
SDRAM memory modules. If the installed CPU uses a 100MHz
system bus, you must use PC100 or PC133 memory. If the
installed CPU uses a 66MHz system bus, you must use PC66
memory. You can install any size memory module from 8 M to
256M , so the maximum memory size is 2 x 256M = 512 M .
The edge connectors on the memory modules have cut outs, which
coincide with spacers in the DIMM sockets so that memory
modules can only be installed in the correct orientation.
To install a module, push the retaining latches at either end of the
socket outwards. Position the memory module correctly and insert
it into the DIMM socket. Press the module down into the socket so
that the retaining latches rotate up and secure the module in place
by fitting into notches on the edge of the module.
11
DIMM1
DIMM2

M768MR Mainboard User’s Manual
Setting Jumper Switches
Jumpers are sets of pins which can be connected together with
jumper caps. The jumper caps change the way the mainboard
operates by changing the electronic circuits on the mainboard. If a
jumper cap connects two pins, we say the pins are SHORT. If a
jumper cap is removed from two pins, the pins are OPEN.
Ju per JP1: Clear CMOS Me ory
Use this jumper to clear the contents of the CMOS memory. You
may need to clear the CMOS memory if the settings in the Setup
Utility are incorrect and prevent your mainboard from operating.
To clear the CMOS memory, disconnect all the power cables from
the mainboard and then move the jumper cap into the CLEAR
setting for a few seconds.
Function Ju per Setting
Normal Operation Short Pins 1-2
Clear CMOS Memory Short Pins 2-3
Ju per JP2: Keyboard Power On Selector
If you enable the keyboard power on feature, you can use hot keys
on your keyboard as a power on/off switch for the system.
Note: The system must provide 1A on the +5VSB (+5V Standby)
signal before using the Keyboard ower On function.
Function Ju per Setting
Enable Keyboard Power On Short Pins 1-2
Disable Keyboard Power On Short Pins 2-3
12
JP5
JP3
JP1
JP2
1
1
1
1

2: Mainboard Installation
Ju per JP3: Audio Syste Enable/disable Ju per
This 3-pin jumper can be used to enable or disable the onboard
audio system. If you prefer to install a different audio system on a
third party expansion card, you must disable the onboard audio in
order to free up resources for the alternate sound card.
Function Ju per Cap
Enable audio system Short pins 1-2
Disable audio system Short pins 2-3
Ju per JP5: 133 MHz Syste Bus Selector
Use this jumper to set the 133 MHz system bus frequency or not.
Function Ju per Setting
/100 MHz Short Pins 1-2
133 MHz Short Pins 2-3
13

M768MR Mainboard User’s Manual
Install the Mainboard
Install the mainboard in a system chassis (case). The board is a
micro-ATX size mainboard with a twin-tier of I/O ports. You can
install this mainboard in any ATX case. Special micro-ATX cases
are also available with a reduced number of expansion slot bays
and a smaller power supply unit. Ensure that your case has an I/O
cover plate that matches the ports on this mainboard.
Install the mainboard in a case. Follow the instructions provided by
the case manufacturer using the hardware and internal mounting
points on the chassis.
1. Connect the power connector from the power supply to the
ATX1 connector on the mainboard.
2. If there is a cooling fan installed in the system chassis, connect
the cable from the cooling fan to the CASFAN1 fan power
connector on the mainboard.
3. Connect the case switches and indicator LEDs to the PANEL1
switch and LED connector header.
14
CASFAN1
ATX1
PANEL1
1

2: Mainboard Installation
See the illustration below for a guide to the PANEL1
connector pin assignments.
15
22
21
Power LED
Pins 2-4-6
S eaker
Pins 1-3-5-7
Keylock
Pins 8-10
HDD LED
Pins 15-16
2
1
Reset Switch
Pins 17-18
Power Button Pins 21-
22
Sus end LED
Pins 13-14
Sus end Switch
Pins 19-20

M768MR Mainboard User’s Manual
Install the Extension Brackets
The extension brackets are used to connect features on the
mainboard to external connectors that can be attached to the
system chassis. Follow the steps below to install the extension
brackets.
Note: All the ribbon cables used on the extension brackets have a
red stripe on the in-1 side of the cable.
Fax/Mode Module
The Fax/Modem DAA module plugs directly into the mainboard in
line with to an expansion slot opening in the system chassis. When
you remove the slot cover from the system chassis, you can access
the LINE and TEL RJ11 connectors on the metal edge of the Fax/
Modem DAA module.
1. Locate the MDM1 modem header on the mainboard.
2. Plug the Fax/Modem DAA module into the header.
3. Remove the modem header slot cover.
16
Modem DAA Module
Modem Header
Line & Tel
RJ11 Sockets
MDM1-Modem Header
1
