IBM Power System IC922 User manual

IBM Power System IC922 (9183-22X)
Quick Install Guide
IBM

This 2021-04-12 edition applies to IBM® Power Systems servers that contain the POWER9™ processor and to all
associated models.
© Copyright International Business Machines Corporation 2020, 2021.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with
IBM Corp.

IBM Power® System IC922 (9183-22X) Quick Install
Guide
Read all precautions and instructions before you start working on the system and its parts.
Use normal electrostatic discharge (ESD) procedures when working on the system and parts. IBM
recommends wearing gloves and an ESD wrist strap to avoid possible damage to the equipment.
The information about the 9183-22X system is available online in the IBM Knowledge Center: http://
www.ibm.com/support/knowledgecenter/9183-22X
© Copyright IBM Corp. 2020, 2021 1

2 IBM Power System IC922 (9183-22X) Quick Install Guide

Parts
Figure 1. Rack nal assembly
Table 1. Rack nal assembly part numbers
Index
number
Part number Units per
assembly
Description
1 1 Top access-cover assembly
2 01EM868 1 Slide rail kit - contains left and right slide rails and
attaching screws
3 1 Side channel
4 2 Screws
5 01EM895 1 Power switch and cables kit (includes power switch,
power switch cable, USB cable, left Electronic
Industries Association (EIA) bracket and right EIA
bracket)
© Copyright IBM Corp. 2020, 2021 3

Table 1. Rack nal assembly part numbers (continued)
Index
number
Part number Units per
assembly
Description
6 2 Screws
7 01EM895 1 Left EIA bracket
8 2 Screws
9 01EM868 1 Slide rail kit - contains left and right slide rails and
attaching screws
10 01EM869 1 Cable management arm assembly
Figure 2. System parts
4 IBM Power System IC922 (9183-22X) Quick Install Guide

Table 2. System parts
Index number Part number Units per
assembly
Description
11 0-4 PCI adapters. Use the feature type of the adapter to nd
the FRU number in PCIe adapter information by feature
type for the 9183-22X system.
12 01EM888 1 PCIe riser (riser 1 for PCIe adapter slots 8, 9, and 10)
Note: For more information about riser locations, see
9183-22X locations.
13 01EM906 1 PCIe riser (riser 0 for PCIe adapter slots 3, 4, and 5)
Note: For more information about riser locations, see
9183-22X locations.
14 01EM841 1 Air baffle
15 0-6 PCI adapters. Use the feature type of the adapter to nd
the FRU number in PCIe adapter information by feature
type for the 9183-22X system.
16 01EM892 1 Power distribution board
17 01EM899 1 Cable holder (left)
18 01EM839 6 Fan
19 01EM838 1 Fan cage assembly
20 01EM891 0-3 SAS and SATA drive backplane (each supports 8 SAS or
SATA drives)
21 01EM852 0-3 8-bay ller for drives
22 01EM843 0-24 Drive holder (carrier and ller)
22 01LU995 0-24 600 GB SAS disk drive
22 01LU996 0-24 1.2 TB SAS disk drive
22 01LU997 0-24 2.4 TB SAS disk drive
22 02YC527 0-24 240 GB SATA solid-state drive
22 02YC528 0-24 960 GB SATA solid-state drive
22 02YC529 0-24 1.92 TB SATA solid-state drive
22 02YC530 0-24 3.84 TB SATA solid-state drive
22 02YC531 0-24 3.84 TB SAS solid-state drive
23 01EM900 1 Cable holder (right)
24 01EM867 2 Power supply
Parts 5

Figure 3. Additional system parts
6 IBM Power System IC922 (9183-22X) Quick Install Guide

Table 3. Additional system parts
Index
number
Part number Units per
assembly
Description
25 78P4197 4, 8, 12, 16, 24, or
32
16 GB, 2666 Mbps DDR4 RDIMM
25 78P4198 4, 8, 12, 16, 24, or
32
32 GB, 2666 Mbps DDR4 RDIMM
25 78P4199 4, 8, 12, 16, 24, or
32
64 GB, 2666 Mbps DDR4 RDIMM
26 01EM317 2 System processor heat sink kit (includes heat sink and
TIM)
27 01EM896 2 12 core 3.8 GHz system processor module kit (includes
system processor module, processor tray, 4 mm hex
driver, module replacement tool, air pump, TIM)
27 01EM897 2 16 core 4.0 GHz system processor module kit (includes
system processor module, processor tray, 4 mm hex
driver, module replacement tool, air pump, TIM)
27 01EM898 2 20 core 3.8 GHz system processor module kit (includes
system processor module, processor tray, 4 mm hex
driver, module replacement tool, air pump, TIM)
28 00RY544 1 Time-of-day battery (CR2032)
29 00VK865 1 Trusted platform module
30 01EM894 1 System backplane kit (includes system backplane on a
sheet, module removal tool, 4 mm hex key, air pump,
TIM, tweezers, CPU socket covers)
Table 4. Miscellaneous system parts
Description Part number Units per assembly
External USB DVD drive 01LU635 1
Parts 7

8 IBM Power System IC922 (9183-22X) Quick Install Guide

Rear ports
Figure 4. Rear view of the system with ports displayed
Table 5. Port descriptions
Identier Description
1 Video Graphics Array (VGA)
Note: Cables up to 3 meters are supported.
2 Serial
Note: Cables up to 3 meters are supported.
3 Dedicated BMC Ethernet. Use this port for the BMC/IPMI interface (eth1).
4 Shared BMC Ethernet. (eth0)
5 USB 3.0
Note: Cables up to 3 meters are supported. The USB 3.0 port on the front of the system has
the same restriction.
© Copyright IBM Corp. 2020, 2021 9

10 IBM Power System IC922 (9183-22X) Quick Install Guide

Installing and removing parts
Figure 5. Locating the Power-on switch and Power-
on LED
Figure 6. Removing the power cords from the system
Figure 7. Placing the system into the service position Figure 8. Placing the system into the operating
position
© Copyright IBM Corp. 2020, 2021 11

Figure 9. Removing the power supplies from the
system
Figure 10. Loosening the cover screw
Figure 11. Removing a drive
Figure 12. Removing the air baffle
12 IBM Power System IC922 (9183-22X) Quick Install Guide

Figure 13. Disconnecting the cables from the SAS/
SATA drive backplane
Figure 14. Removing the drive backplane
Figure 15. Removing a fan Figure 16. Removing the fan cage assembly
Installing and removing parts 13

Figure 17. Removing a memory module
Figure 18. Locating the memory modules
Figure 19. Removing a PCIe adapter
Figure 20. Removing the PCIe riser
14 IBM Power System IC922 (9183-22X) Quick Install Guide

Figure 21. Removing a PCIe adapter from a PCIe
riser
Figure 22. Disconnecting the cables from the SAS/
SATA drive backplane
Figure 23. Removing the power distribution board
Figure 24. Removing the side channel
Installing and removing parts 15

Figure 25. Disconnecting the power switch and front
USB cables
Figure 26. Removing the power switch
Figure 27. Retracting the retaining pin and removing
the left cable holder
Figure 28. Retracting the retaining pin and removing
the right cable holder
16 IBM Power System IC922 (9183-22X) Quick Install Guide

Figure 29. Removing the system backplane
Installing and removing parts 17

Figure 30. Removing the heat sink Figure 31. Removing the TIM from the system
processor module
Figure 32. Removing dust and debris from the
system processor module area
Figure 33. Opening the processor removal tool
latches
18 IBM Power System IC922 (9183-22X) Quick Install Guide
