IBM FlashSystem 710 User manual

IBM FlashSystem 710
User's Guide
Revision 3, 4/2014


IBM FlashSystem 710
User's Guide
Revision 3, 4/2014


Note
Before using this information and the product it supports, read the information in “Safety notices” on page v, “Notices” on
page 23, the IBM Systems Safety Notices manual, G229-9054, and the IBM Environmental Notices and User Guide, Z125–5823.
This edition applies to IBM FlashSystem and to all subsequent releases and modifications until otherwise indicated
in new editions.
© Copyright IBM Corporation 2013, 2014.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Safety notices ............v
IBM FlashSystem 710 User’s Guide . . . 1
Introduction ..............1
System components ...........1
Power requirements ...........1
Reliability functions ...........1
System management functions .......1
Reviewing your shipment ..........1
Unpacking ..............1
Rack mounting ............2
System connections ............3
Installing a host bus adapter or host channel
adapter in the host system.........3
Fibre Channel interface bandwidth .....4
Host bus adapter settings ........4
PCI bus selection and performance .....4
Processor performance factors ......5
Connecting the Fibre Channel or InfiniBand ports 5
Connecting the system to a management network 5
Connecting power to the system.......6
Getting started..............7
System initialization ...........7
Front panel display overview........8
Controlling system power with the front panel
display ...............8
Powering off the system ........9
Restarting the system .........9
Automatic shutdown .........9
Configuring the management controller port using
the front panel display ..........9
Configuring a static IP address ......10
Configuring DHCP ..........11
Additional system management options ....11
Connecting by using Telnet and SSH ....11
Connecting by using the web management
interface .............11
Monitoring by using SNMP .......12
Web interface basics ..........12
Acquiring the system IP address ......12
Accessing the web interface ........12
Configuring the management controller port by
using the web interface .........13
Terawatch ..............13
Managing security with the web interface . . . 13
Default accounts...........13
Changing passwords .........13
Adding users ............14
Lightweight Directory Access Protocol . . . 14
Storage modes ............15
Maximum capacity ..........15
Data acquisition ...........15
JBOF ..............15
Active spare ............15
Creating logical units ..........15
Logical unit access policies .......16
Adding an access policy to a logical unit . . 16
Logical unit masking .........17
Viewing the system logs with the web interface 18
Accessing the system event log ......18
Accessing the system report .......18
Configuring the mail service settings . . . 18
Clearing the system event log ......18
Statistic log .............18
Viewing statistics logs .........19
Configuring logged statistics ......19
Upgrading the system software and firmware . . 19
Saving and restoring the configuration ....20
Monitoring tasks ...........20
Troubleshooting .............20
Front panel display...........20
System event log ...........21
System report.............21
Reformatting uninitialized flashcards .....21
Monitoring battery health ........21
Parts replacement information ........22
Notices ..............23
Trademarks ..............24
Electronic emission notices .........24
Class A Notices ............25
Class B Notices ............28
Terms and conditions ...........31
© Copyright IBM Corp. 2013, 2014 iii

iv IBM FlashSystem 710: User's Guide

Safety notices
Safety notices may be printed throughout this guide:
vDANGER notices call attention to a situation that is potentially lethal or extremely hazardous to
people.
vCAUTION notices call attention to a situation that is potentially hazardous to people because of some
existing condition.
vAttention notices call attention to the possibility of damage to a program, device, system, or data.
World Trade safety information
Several countries require the safety information contained in product publications to be presented in their
national languages. If this requirement applies to your country, safety information documentation is
included in the publications package (such as in printed documentation, on DVD, or as part of the
product) shipped with the product. The documentation contains the safety information in your national
language with references to the U.S. English source. Before using a U.S. English publication to install,
operate, or service this product, you must first become familiar with the related safety information
documentation. You should also refer to the safety information documentation any time you do not
clearly understand any safety information in the U.S. English publications.
Replacement or additional copies of safety information documentation can be obtained by calling the IBM
Hotline at 1-800-300-8751.
German safety information
Das Produkt ist nicht für den Einsatz an Bildschirmarbeitsplätzen im Sinne§2der
Bildschirmarbeitsverordnung geeignet.
Laser safety information
IBM®servers can use I/O cards or features that are fiber-optic based and that utilize lasers or LEDs.
Laser compliance
IBM servers may be installed inside or outside of an IT equipment rack.
© Copyright IBM Corp. 2013, 2014 v

DANGER
When working on or around the system, observe the following precautions:
Electrical voltage and current from power, telephone, and communication cables are hazardous. To
avoid a shock hazard:
vConnect power to this unit only with the IBM provided power cord. Do not use the IBM
provided power cord for any other product.
vDo not open or service any power supply assembly.
vDo not connect or disconnect any cables or perform installation, maintenance, or reconfiguration
of this product during an electrical storm.
vThe product might be equipped with multiple power cords. To remove all hazardous voltages,
disconnect all power cords.
vConnect all power cords to a properly wired and grounded electrical outlet. Ensure that the outlet
supplies proper voltage and phase rotation according to the system rating plate.
vConnect any equipment that will be attached to this product to properly wired outlets.
vWhen possible, use one hand only to connect or disconnect signal cables.
vNever turn on any equipment when there is evidence of fire, water, or structural damage.
vDisconnect the attached power cords, telecommunications systems, networks, and modems before
you open the device covers, unless instructed otherwise in the installation and configuration
procedures.
vConnect and disconnect cables as described in the following procedures when installing, moving,
or opening covers on this product or attached devices.
To Disconnect:
1. Turn off everything (unless instructed otherwise).
2. Remove the power cords from the outlets.
3. Remove the signal cables from the connectors.
4. Remove all cables from the devices.
To Connect:
1. Turn off everything (unless instructed otherwise).
2. Attach all cables to the devices.
3. Attach the signal cables to the connectors.
4. Attach the power cords to the outlets.
5. Turn on the devices.
(D005)
DANGER
vi IBM FlashSystem 710: User's Guide

Observe the following precautions when working on or around your IT rack system:
vHeavy equipment–personal injury or equipment damage might result if mishandled.
vAlways lower the leveling pads on the rack cabinet.
vAlways install stabilizer brackets on the rack cabinet.
vTo avoid hazardous conditions due to uneven mechanical loading, always install the heaviest
devices in the bottom of the rack cabinet. Always install servers and optional devices starting
from the bottom of the rack cabinet.
vRack-mounted devices are not to be used as shelves or work spaces. Do not place objects on top
of rack-mounted devices.
vEach rack cabinet might have more than one power cord. Be sure to disconnect all power cords in
the rack cabinet when directed to disconnect power during servicing.
vConnect all devices installed in a rack cabinet to power devices installed in the same rack
cabinet. Do not plug a power cord from a device installed in one rack cabinet into a power
device installed in a different rack cabinet.
vAn electrical outlet that is not correctly wired could place hazardous voltage on the metal parts of
the system or the devices that attach to the system. It is the responsibility of the customer to
ensure that the outlet is correctly wired and grounded to prevent an electrical shock.
CAUTION
vDo not install a unit in a rack where the internal rack ambient temperatures will exceed the
manufacturer's recommended ambient temperature for all your rack-mounted devices.
vDo not install a unit in a rack where the air flow is compromised. Ensure that air flow is not
blocked or reduced on any side, front, or back of a unit used for air flow through the unit.
vConsideration should be given to the connection of the equipment to the supply circuit so that
overloading of the circuits does not compromise the supply wiring or overcurrent protection. To
provide the correct power connection to a rack, refer to the rating labels located on the
equipment in the rack to determine the total power requirement of the supply circuit.
v(For sliding drawers.) Do not pull out or install any drawer or feature if the rack stabilizer brackets
are not attached to the rack. Do not pull out more than one drawer at a time. The rack might
become unstable if you pull out more than one drawer at a time.
v(For fixed drawers.) This drawer is a fixed drawer and must not be moved for servicing unless
specified by the manufacturer. Attempting to move the drawer partially or completely out of the
rack might cause the rack to become unstable or cause the drawer to fall out of the rack.
(R001)
Safety notices vii

CAUTION:
Removing components from the upper positions in the rack cabinet improves rack stability during
relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a
room or building:
vReduce the weight of the rack cabinet by removing equipment starting at the top of the rack
cabinet. When possible, restore the rack cabinet to the configuration of the rack cabinet as you
received it. If this configuration is not known, you must observe the following precautions:
– Remove all devices in the 32U position and above.
– Ensure that the heaviest devices are installed in the bottom of the rack cabinet.
– Ensure that there are no empty U-levels between devices installed in the rack cabinet below the
32U level.
vIf the rack cabinet you are relocating is part of a suite of rack cabinets, detach the rack cabinet from
the suite.
vInspect the route that you plan to take to eliminate potential hazards.
vVerify that the route that you choose can support the weight of the loaded rack cabinet. Refer to the
documentation that comes with your rack cabinet for the weight of a loaded rack cabinet.
vVerify that all door openings are at least 760 x 230 mm (30 x 80 in.).
vEnsure that all devices, shelves, drawers, doors, and cables are secure.
vEnsure that the four leveling pads are raised to their highest position.
vEnsure that there is no stabilizer bracket installed on the rack cabinet during movement.
vDo not use a ramp inclined at more than 10 degrees.
vWhen the rack cabinet is in the new location, complete the following steps:
– Lower the four leveling pads.
– Install stabilizer brackets on the rack cabinet.
– If you removed any devices from the rack cabinet, repopulate the rack cabinet from the lowest
position to the highest position.
vIf a long-distance relocation is required, restore the rack cabinet to the configuration of the rack
cabinet as you received it. Pack the rack cabinet in the original packaging material, or equivalent.
Also lower the leveling pads to raise the casters off of the pallet and bolt the rack cabinet to the
pallet.
(R002)
(L001)
(L002)
viii IBM FlashSystem 710: User's Guide

(L003)
or
All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class
1 laser products. Outside the U.S., they are certified to be in compliance with IEC 60825 as a class 1 laser
product. Consult the label on each part for laser certification numbers and approval information.
CAUTION:
This product might contain one or more of the following devices: CD-ROM drive, DVD-ROM drive,
DVD-RAM drive, or laser module, which are Class 1 laser products. Note the following information:
vDo not remove the covers. Removing the covers of the laser product could result in exposure to
hazardous laser radiation. There are no serviceable parts inside the device.
vUse of the controls or adjustments or performance of procedures other than those specified herein
might result in hazardous radiation exposure.
(C026)
Safety notices ix

CAUTION:
Data processing environments can contain equipment transmitting on system links with laser modules
that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical
fiber cable or open receptacle. (C027)
CAUTION:
This product contains a Class 1M laser. Do not view directly with optical instruments. (C028)
CAUTION:
Some laser products contain an embedded Class 3A or Class 3B laser diode. Note the following
information: laser radiation when open. Do not stare into the beam, do not view directly with optical
instruments, and avoid direct exposure to the beam. (C030)
CAUTION:
The battery contains lithium. To avoid possible explosion, do not burn or charge the battery.
Do Not:
v___ Throw or immerse into water
v___ Heat to more than 100°C (212°F)
v___ Repair or disassemble
Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local
regulations. In the United States, IBM has a process for the collection of this battery. For information,
call 1-800-426-4333. Have the IBM part number for the battery unit available when you call. (C003)
Power and cabling information for NEBS (Network Equipment-Building System)
GR-1089-CORE
The following comments apply to the IBM servers that have been designated as conforming to NEBS
(Network Equipment-Building System) GR-1089-CORE:
The equipment is suitable for installation in the following:
vNetwork telecommunications facilities
vLocations where the NEC (National Electrical Code) applies
The intrabuilding ports of this equipment are suitable for connection to intrabuilding or unexposed
wiring or cabling only. The intrabuilding ports of this equipment must not be metallically connected to the
interfaces that connect to the OSP (outside plant) or its wiring. These interfaces are designed for use as
intrabuilding interfaces only (Type 2 or Type 4 ports as described in GR-1089-CORE) and require isolation
from the exposed OSP cabling. The addition of primary protectors is not sufficient protection to connect
these interfaces metallically to OSP wiring.
Note: All Ethernet cables must be shielded and grounded at both ends.
The ac-powered system does not require the use of an external surge protection device (SPD).
The dc-powered system employs an isolated DC return (DC-I) design. The DC battery return terminal
shall not be connected to the chassis or frame ground.
xIBM FlashSystem 710: User's Guide

IBM FlashSystem 710 User’s Guide
Learn about setting up, configuring, and managing the IBM FlashSystem™710.
Introduction
Use this information to learn about the IBM FlashSystem and its features.
System components
The IBM FlashSystem components include data storage capacity, controller slots, a front panel display for
configuration, and Ethernet capacities.
The system components of the IBM FlashSystem 710 include the following features:
vUp to 5 TB of usable data storage capacity
vTwo controller slots that can contain a mixture of dual-ported 8 Gb Fibre Channel (FC) or Quad Data
Rate (QDR) InfiniBand controllers
vA front panel display for configuration and monitoring
vAn Ethernet monitoring port
Power requirements
A fully configured IBM FlashSystem 710 requires approximately 350 watts of power.
The system includes two hot-swappable power modules that are auto-ranging (they accept either 110 V
ac or 220 V ac).
Reliability functions
The storage system is designed to offer high reliability.
The storage system’s standard functions include modular flash memory, fully redundant, hot-swappable
power supplies, external alerts by using Simple Network Management Protocol (SNMP), and redundant
data paths.
System management functions
Basic management operations, including manual shutdown and alerts, are available from the front panel
screen.
Full monitoring and configuration capabilities are available over any browser by a password-protected
Java™applet, and through a command-line interface over Telnet or Secure Shell (SSH). The system is fully
SNMP v2c-compatible and can provide notification of system events though email.
Reviewing your shipment
Reviewing your shipment is an important first step in ensuring an accurate order.
Unpacking
Refer to the packing list when you unpack your system.
Your system is supplied with a packing list. Ensure that you received all of the components listed.
1. Examine the external chassis for any damage that might have occurred during shipping.
© Copyright IBM Corp. 2013, 2014 1

2. Inspect the interface plate for any screws that might have loosened during shipping.
3. Inspect the front panel display for damage.
4. Report any meaningful damage.
Rack mounting
The storage system is provided with the slides and hardware that is needed to install it into a standard
19-inch rack, in a 1U space.
See the rack installation documentation that is supplied with the rack kit for details on installing the
storage system in a rack.
2IBM FlashSystem 710: User's Guide

DANGER
Observe the following precautions when working on or around your IT rack system:
vHeavy equipment–personal injury or equipment damage might result if mishandled.
vAlways lower the leveling pads on the rack cabinet.
vAlways install stabilizer brackets on the rack cabinet.
vTo avoid hazardous conditions due to uneven mechanical loading, always install the heaviest
devices in the bottom of the rack cabinet. Always install servers and optional devices starting
from the bottom of the rack cabinet.
vRack-mounted devices are not to be used as shelves or work spaces. Do not place objects on top
of rack-mounted devices.
vEach rack cabinet might have more than one power cord. Be sure to disconnect all power cords in
the rack cabinet when directed to disconnect power during servicing.
vConnect all devices installed in a rack cabinet to power devices installed in the same rack
cabinet. Do not plug a power cord from a device installed in one rack cabinet into a power
device installed in a different rack cabinet.
vAn electrical outlet that is not correctly wired could place hazardous voltage on the metal parts of
the system or the devices that attach to the system. It is the responsibility of the customer to
ensure that the outlet is correctly wired and grounded to prevent an electrical shock.
CAUTION
vDo not install a unit in a rack where the internal rack ambient temperatures will exceed the
manufacturer's recommended ambient temperature for all your rack-mounted devices.
vDo not install a unit in a rack where the air flow is compromised. Ensure that air flow is not
blocked or reduced on any side, front, or back of a unit used for air flow through the unit.
vConsideration should be given to the connection of the equipment to the supply circuit so that
overloading of the circuits does not compromise the supply wiring or overcurrent protection. To
provide the correct power connection to a rack, refer to the rating labels located on the
equipment in the rack to determine the total power requirement of the supply circuit.
v(For sliding drawers.) Do not pull out or install any drawer or feature if the rack stabilizer brackets
are not attached to the rack. Do not pull out more than one drawer at a time. The rack might
become unstable if you pull out more than one drawer at a time.
v(For fixed drawers.) This drawer is a fixed drawer and must not be moved for servicing unless
specified by the manufacturer. Attempting to move the drawer partially or completely out of the
rack might cause the rack to become unstable or cause the drawer to fall out of the rack.
(R001)
System connections
You must install a host bus adapter or host channel adapter in the host system.
Installing a host bus adapter or host channel adapter in the host
system
Host bus adapters (HBAs) provide an interface from the host system’s PCI bus to Fibre Channel-attached
devices. Host channel adapters (HCAs) provide an interface from the server’s PCI bus to InfiniBand
devices.
IBM FlashSystem 710 User’s Guide 3

Ensure that the adapter that you select for use with the storage system provides a driver for the
operating system version that you are using.
Note: In subsequent sections, the term HBA is used to represent HCA or HBA interchangeably.
Before you install the HBA, consult your server documentation to determine which one of its PCI slots is
on the fastest and least congested PCI bus. Follow the instructions that are provided with the HBA to
install the card and driver. Obtain the latest drivers and firmware for the HBA. Updated drivers might
include new functions, improved performance, and minor bug fixes.
The speed of the server and network interface ultimately determine the storage system's capabilities.
Some components that can affect the maximum performance of the storage system include FC or
InfiniBand interfaces, host bus adapters, PCI buses, and server processor resources.
Fibre Channel interface bandwidth
Your storage system supports Fibre Channel (FC) communication speeds of 2 Gbps, 4 Gbps, or 8 Gbps.
Accounting for encoding and overhead, the maximum 8 Gbps transfer rate allows data to be transmitted
to the system at a half duplex rate of approximately 800 MBps. Fibre Channel interfaces have separate
read and write connections that allow a maximum data rate of twice the half-duplex rate. To sustain the
maximum full duplex rate, the data usage pattern of the system must be 50% read and 50% write. This
requirement is because of the individual half duplex limits. To find the maximum for other data usage
patterns, use the following formula (given an 8 Gb HBA):
[(smaller usage percentage/larger percentage) ×800 MBps] + 800 MBps
For example, to calculate a data usage pattern with 66% reads and 33% writes,
[(33/66) ×800] + 800 = 1200 MBps
Many applications require storage bandwidth that exceeds what a single FC connection can provide. To
accommodate this situation, up to 4 FC ports are available per system, each of which can supply the
bandwidth described here. Using multiple FC connections requires one of the following solutions:
multipathing software to a single logical unit, using software to stripe across multiple logical units,
accessing multiple logical units concurrently, or connecting multiple servers to the storage system.
Host bus adapter settings
You can modify some host bus adapter (HBA) settings to increase performance.
For information specific to your HBA, consult the HBA documentation. Many settings are intended to
increase the performance of slow storage devices and are not applicable to this high performance system.
In particular, it is always advisable to check the frame size. The amount of overhead for each Fibre
Channel frame is fixed, so larger frames have lower overhead. Set the frame size to the maximum setting,
generally 2048 bytes. For InfiniBand devices, also set the frame size to the maximum setting, generally
4096 bytes.
PCI bus selection and performance
High-bandwidth host bus adapter (HBA) traffic can quickly inundate slower PCI buses. When a PCI bus
reaches its limit, you can do little to improve performance.
Many servers, however, provide different PCI buses with different speeds, and placing the HBA on a
faster PCI bus can improve performance. When you install an 8 Gb, 2-port HBA in the server, allocate at
least an entire PCI-X bus or a PCI Express (PCIe) slot.
4IBM FlashSystem 710: User's Guide

Processor performance factors
At a certain point, processor performance can limit data transfer rates. Determine whether the server’s
processor resources are the limiting factor in performance while you benchmark the storage system as a
raw physical device.
Otherwise, an improperly tuned file system or application can make the processor seem to be the limiting
factor when it is not. Complete raw device testing after you set up any multipathing.
There are a few ways to decrease processor usage without increasing processor resources. Certain data
usage patterns can be processor-intensive and fully use the processor. These usually involve small
transfer sizes. When possible, increasing the average transfer size decreases processor usage and offers
better performance.
Another way to decrease processor usage is by enabling interrupt coalescing. Interrupt coalescing is an
HBA-dependent function that decreases processor usage at the expense of latency. This function delays
the calling of the HBA transfer interrupt until several transfers are ready. However, in general, do not
enable interrupt coalescing because the storage system performance benefits from low latency. For more
information, see your HBA documentation.
Connecting the Fibre Channel or InfiniBand ports
Connect the Fibre Channel (FC) ports on the storage system to your server or to an FC switch. If your
storage system has InfiniBand ports, connect them to an InfiniBand switch or host channel adapter (HCA)
in your server.
The following figure shows the port layout for the storage system. Each controller has two FC ports: A
and B, on the left and right respectively. The FC ports on the system can connect to Point-to-Point
(N-Port), Arbitrated Loop (NL-port), or Switched Fabric (F-Port) topologies at 2 Gb, 4 Gb, or 8 Gb speeds.
Although Figure 1 shows FC controller cards, an InfiniBand controller card can occupy either of the same
slots as the FC controller cards. The InfiniBand controller card has two x4 InfiniBand ports: A and B, on
the top and bottom respectively. The InfiniBand ports can connect to Quad Data Rate (QDR), Double
Data Rate (DDR), or Single Data Rate (SDR) HCAs. This connection uses the Small Computer System
Interface (SCSI) remote direct memory access (RDMA) Protocol (SRP).
vOn an FC controller card, the FC port LED is green if the speed is set to 8 Gb. If the speed is set to 4
Gb, the LED for the FC port is amber.
vOn an InfiniBand controller card, the port LED is green when the link is established.
Connecting the system to a management network
Your system includes a Gigabit Ethernet management controller port (MCP) connection for remote
management over a network.
You use this connection to configure the system's storage and management functions.
Figure 1. Fibre Channel or InfiniBand port locations
IBM FlashSystem 710 User’s Guide 5

Connect the Ethernet MCP to the network.
Connecting power to the system
Although the system operates when only one power supply is connected, this set up is not
recommended.
Using the ac power cords that are provided, connect each power supply to a power source. As a best
practice, connect each of the power cords to separate circuits.
Figure 2. Ethernet management port location
Figure 3. Power supplies
6IBM FlashSystem 710: User's Guide

DANGER
When working on or around the system, observe the following precautions:
Electrical voltage and current from power, telephone, and communication cables are hazardous. To
avoid a shock hazard:
vConnect power to this unit only with the IBM provided power cord. Do not use the IBM
provided power cord for any other product.
vDo not open or service any power supply assembly.
vDo not connect or disconnect any cables or perform installation, maintenance, or reconfiguration
of this product during an electrical storm.
vThe product might be equipped with multiple power cords. To remove all hazardous voltages,
disconnect all power cords.
vConnect all power cords to a properly wired and grounded electrical outlet. Ensure that the outlet
supplies proper voltage and phase rotation according to the system rating plate.
vConnect any equipment that will be attached to this product to properly wired outlets.
vWhen possible, use one hand only to connect or disconnect signal cables.
vNever turn on any equipment when there is evidence of fire, water, or structural damage.
vDisconnect the attached power cords, telecommunications systems, networks, and modems before
you open the device covers, unless instructed otherwise in the installation and configuration
procedures.
vConnect and disconnect cables as described in the following procedures when installing, moving,
or opening covers on this product or attached devices.
To Disconnect:
1. Turn off everything (unless instructed otherwise).
2. Remove the power cords from the outlets.
3. Remove the signal cables from the connectors.
4. Remove all cables from the devices.
To Connect:
1. Turn off everything (unless instructed otherwise).
2. Attach all cables to the devices.
3. Attach the signal cables to the connectors.
4. Attach the power cords to the outlets.
5. Turn on the devices.
(D005)
Getting started
There are several tasks that you can perform to set up your initial configuration.
To initially configure your new storage system, complete the following tasks:
vUse the front panel display to set up the network (see **** MISSING FILE ****).
vSet up the web management interface (see “Web interface basics” on page 12).
vUse the web interface to set the date and time (see Setting the date and time by using the web
interface).
vUse the web interface to configure advanced network settings (see **** MISSING FILE ****.
vUse the web interface to configure security (see “Managing security with the web interface” on page
13).
System initialization
When ac power is connected, the storage system powers-up and the front panel display shows the
power-on sequence.
IBM FlashSystem 710 User’s Guide 7

When the system is fully ready, the front panel displays Status: OK and the system performance
statistics, including the system bandwidth in Mbps and total input/output operations per second.
Front panel display overview
The front panel display provides a quick and easy way to view the status of the storage system.
The following figure shows the front panel display and selection buttons.
Use this display to complete the following tasks:
vInspect the state of the system.
vChange the method of IP address assignment.
vRestart or shut down the system.
The following buttons are located to the left of the display and are used to make selections:
(M)enu
This button has two functions. On any of the status or performance displays, pressing this button
starts the Main Menu. This button is also used as an escape function. When the menu system is
open, pressing it returns to the prior screen.
(S)elect
When a menu item is displayed, pressing this button will either run that menu option or proceed
to the next level in the menu.
↑This button scrolls up through the menu. It is also used to cancel certain commands as indicated
on the display. If the menu is not selected, this button is disabled.
↓This button scrolls down through the menu. It is also used to confirm certain commands as
indicated on the display. If the menu is not selected, this button is disabled.
To scan through the first level of options, press the Menu key.
vSelecting System Info displays status information.
vSelecting System Status displays messages. You can view the system informational, warning, or error
messages. These messages are the same messages that scroll across the status screen.
vSelecting Net Config to configure the connection to your network. For more information, see ****
MISSING FILE ****.
vSelecting LED Config gives you various options for controlling the LEDs to the left of the display.
vSelecting Restart restarts the storage system.
vSelecting Poweroff turns off the storage system. For more information, see “Powering off the system”
on page 9.
Controlling system power with the front panel display
The storage system has functions that allow the administrator to safely power down the system.
Figure 4. Front panel display and selection buttons
8IBM FlashSystem 710: User's Guide
