Icom MR-1000RII User manual

●8-level Bright Picture on 10-inch
Monochrome Green CRT
●
Three Types of Scanner Units
MR-1000RII: 36NM range, 4kW radome scanner
MR-1000TII: 48NM range, 4kW open array scanner
MR-1000TIII: 72NM range, 6kW open array scanner
●Simplified ATA (Automatic Tracking Aid)
Function
See overleaf for details.
●External GPS and Compass Data Input
with NMEA0183, N+1, AUX Format
●English and Korean Indication
●Improved STC (Sensitivity Time Control) and
Sidelobe for Small Target Detection
●North-up, Course-up, Head-up &
True-motion
Bearing, speed and position data required, depends on dis-
play mode.
●4ft (120cm) open array scanner
for MR-1000TII/MR-1000TIII
Easy-to-See 10-inch CRT Display
with Simplied Automatic Tracking Aid Function
●10-inch Display Unit
●2ft (60cm) radome scanner
for MR-1000RII
(10-inch CRT, 4kW Radome Scanner)
(10-inch CRT, 4kW Open Array Scanner)
(10-inch CRT, 6kW Open Array Scanner)

Printed in Japan
Count on us!
Your local distributor/dealer:
2380 116th Avenue NE,
Bellevue, WA 98004, U.S.A.
Phone : [phone]
Fax : +1
[phone]
E-mail : [email protected]
URL : http://www.icomamerica.com
Unit 1 / 103 Garden Road,
Clayton, VIC 3168 Australia
Phone : [phone]
Fax : [phone]
E-mail : [email protected]
URL : http://www.icom.net.au
Ctra. Rubi, No. 88 "Edificio Can Castanyer"
Bajos A 08174, Sant Cugat del Valles,
Barcelona, Spain
Phone : [phone]
Fax : +34
(93)589 04 46
E-mail : [email protected]
URL : http://www.icomspain.com
146A Harris Road, East Tamaki,
Auckland, New Zealand
Phone : [phone]
Fax : [phone]
E-mail : [email protected]
URL : http://www.icom.co.nz
Glenwood Centre #150-6165 Highway 17,
Delta, B.C., V4K 5B8, Canada
Phone : [phone]
Fax : +1
[phone]
E-mail : [email protected]
URL : http://www.icomcanada.com
6F No. 68, Sec. 1 Cheng-Teh Road,
Taipei, Taiwan, R.O.C.
Phone : [phone]
Fax : [phone]
E-mail : [email protected]
URL : http://www.asia-icom.com
Communication Equipment
Auf der Krautweide 24
65812 Bad Soden am Taunus, Germany
Phone : [phone]
Fax : [phone]
E-mail : [e-mail]
URL : http://www.icomeurope.com
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United Kingdom, Germany, France, Spain, Russia, Japan and/or other countries.
Blacksole House, Altira Park,
Herne Bay, Kent, CT6 6GZ, U.K.
Phone : [phone]
Fax : [phone]
E-mail : [email protected].uk
URL : http://www.icomuk.co.uk
Zac de la Plaine,
1 Rue Brindejonc des Moulinais, BP 45804,
31505 Toulouse Cedex 5, France
Phone : [phone]
Fax : [phone]
E-mail : [email protected]
URL : http://www.icom-france.com
81-850 Sopot, ul. 3 Maja 54, Poland
Phone : [phone]
Fax : +48
(58)551 0484
E-mail : [email protected]
URL : http://www.icompolska.com.pl
www.icom.co.jp/world
1-1-32, Kami-minami, Hirano-ku, Osaka 547-0003, Japan Phone: [phone] Fax: [phone]
05HS014E* © 2005–2012 Icom Inc.
MARINE RADARS
OTHER FEATURES
• The MR-1000RII/TII/TIII provides many useful features : 2 EBL’s, 2 VRM’s,
SEA clutter, RAIN clutter, Off center, Interference reduction, Echo stretch,
Zoom, Trail, long pulse and automatic calibration function.
• When connected to the GPS and/or compass, the MR-1000RII/TII/TIII dis-
plays the following information: Course-up, North-up, True motion indication,
own and other vessel’s speed, position and course, waypoint and man over-
board point.
• Simplied Automatic Tracking Aid allows you to plot up to 10 targets and the
radar automatically traces the targets.
•
The CPA (Closest Point Approach) and TCPA (Time to CPA) alarm gives an au-
dible warning when the tracking targets come within the set range or time.
• Power saver function pauses the scanning for a preset time and conserves
battery consumption. When used with the zone alarm function, the CRT dis-
play is turned off until an object enters the programmed alarm zone.
OPC-1077A 20m (65.6ft) SYSTEM CABLE
OPC-1078A 30m (98.4ft) SYSTEM CABLE
OPTIONS
OPC-1077A
• Display type : 10-inch monochrome green CRT
• Resolution : 640×480 dots
• Minimum range : 25m (1⁄8 NM range)
• Maximum range :
MR-1000RII 36NM
MR-1000TII 48NM
MR-1000TIII 72NM
• Measurement range : (unit:NM)
1⁄8, 1⁄4, 1⁄2, 3⁄4,1, 1.5, 2, 3, 4, 6, 8, 12, 16,
24, 32, 36, 48*1, 64*2, 72*2
(*1MR-1000TII/III only *2MR-1000TIII only)
• Preheat time : 90 seconds
• Power supply : 10.2–42V DC
• Power consumption :
MR-1000RII 60W (approx.)
MR-1000TII 70W (approx.)
MR-1000TIII 80W (approx.)
•
Usable Temp. range : –15˚C to +55˚C; +5˚F to +131˚F
• Unit of distance : NM (nautical mile), km
• Input data format : NMEA 0183, N+1, AUX
• Output data format : NMEA 0183
SPECIFICATIONS
MOB
POWER
TX
SAVE
TARGET TRAILS
ZOOM
ALM MODE
OFF CENT
EBL1
VRM1
PI
RAIN
SEA
GAIN
BRILL MENU
HL OFF
EBL2
VRM2
MARINE RADAR
287 (11.3)
132 (5.2)
264 (10.39)
269 (10.59)
1200 (47.24)
98
(3.86)
281 (11.06)
381 (15)
258 (10.16)
248 (9.76)
190 (7.48)
399 (15.71)
302 (11.89)
48 (1.89)
132 (5.2)
Ship’s bow direction
Unit:mm (inch)
45.5 (1.79)
640 (25.2)
150.5 (5.93)
601 (23.66)
256 (10.08)
90.5 (3.56)
90.5 (3.56)
Ship’s bow direction
17kg; 37.5lb
(without cable)
8kg; 17.6lb
(without cable)
6.5kg; 14.3lb
DISPLAY UNIT
• Model Name : MR-1000RII MR-1000TII/MR-1000TIII
• Type : 2ft (60cm) radome scanner 4ft (120cm) open array scanner
• Rotation speed : 24, 36rpm typ. 22*, 24, 36rpm typ. (* MR-1000TIII only)
• Beamwidth Horizontal beam : 4˚ typ. 2˚ typ.
Vertical beam : 22˚ typ. 25˚ typ.
• Sidelobe : –22dB typ. –24dB typ.
•
Usable temperature range : –25˚C to +70˚C; –13˚F to +158˚F –25˚C to +70˚C; –13˚F to +158˚F
•
Usable humidity range : Less than 95% (at 40˚C) Less than 95% (at 40˚C)
• Frequency : 9410MHz ±30MHz 9410MHz ±30MHz
• Modulation : P0N P0N
• Peak output power : 4kW 4kW (MR-1000TII)
6kW (MR-1000TIII)
• Pulse-width/Reception rate : 80nS/2160Hz, 80nS/1440Hz, 80nS/2160Hz, 80nS/1440Hz,
250nS/1440Hz, 350nS/1440Hz, 250nS/1440Hz, 350nS/1440Hz,
350nS/720Hz, 900nS/720Hz 350nS/720Hz, 900nS/720Hz,
900nS/660Hz* (* MR-1000TIII only)
• Modulator : FET switching FET switching
• Intermediate frequency : 60MHz 60MHz
• IF passband width : 10MHz, 3MHz 10MHz, 3MHz
• Tuning : Auto or manual Auto or manual
• System cable : 15m (49.2ft); OPC-1188A 20m (65.6ft); OPC-1189A
SCANNER UNIT
All stated specications are subject to change without notice or obligation.
DIMENSIONS
Power supply
10.2 to 42 V DC
Open array scanner
MR-1000TII /TIII
Radome scanner
MR-1000RII
NMEA1:
Bearing data input
NMEA2:
NMEA 0183 data input
Speed sensor input
SYSTEM CONNECTION
