SERVICE MANUAL
ADDENDUM
CONTENTS
REPLACEMENT PAGES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . –
PARTS LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Oct. 2008
Oct. 2008 (REPLACEMENT PAGE)
4 - 1
SECTION 4 ADJUSTMENT PROCEDURES
4-1 PREPARATION
sSome versions may need the optional CS-A110 CLONING SOFTWARE and OPC-478, OPC-592 CLONING CABLE for setting the
adjustment frequency.
sAll adjustments must be performed on the [Wide] mode.
■REQUIRED TEST EQUIPMENT
■VFO CHANNEL ID LIST
sChannel spacing: 8.33/25 kHz [USA/USA-1] sChannel spacing: 25 kHz [GEN/GEN-1], [CHN]
EQUIPMENT
DC power supply
RF power meter
(terminated type)
Frequency counter
Modulation analyzer
Distortion meter
External speaker
GRADE AND RANGE
Output voltage : 13.75 V DC
Current capacity : 10 A or more
Measuring range : 1–50 W
Frequency range : 50–300 MHz
Impedance : 50 7
SWR : Less than 1.2 : 1
Frequency range : 0.1–300 MHz
Frequency accuracy : ±1 ppm or better
Sensitivity : 100 mV or better
Frequency range : DC–300 MHz
Measuring range : 0 to 100 %
Frequency range : 1 kHz±10 %
Measuring range : 1 to 100 %
Impedance : 8 7
EQUIPMENT
DC voltmeter
DC ammeter
Digital multimeter
Audio generator
Standard signal
generator (SSG)
AC millivoltmeter
Attenuator
Terminator
GRADE AND RANGE
Input impedance : 50 k
Measuring range : 0.1–1 A
7/V DC or better
Input impedance : 10 M7/V DC or better
Frequency range : 300–3000 Hz
Measuring range : 1–500 mV
Frequency range : 0.1–300 MHz
Output level : 0.1 μV–32 mV
(–127 to –17 dBm)
Measuring range : 10 mV–10 V
Power attenuation : 40 or 50 dB
Capacity : 50 W or more
Impedance : 50 7
Capacity : 50 W or more
Operating Freq.
(MHz)
118.0000
118.0000
118.0083
118.0167
118.0250
118.0250
118.0333
118.0417
118.0500
118.0500
118.0583
118.0667
118.0750
118.0750
118.0833
118.0917
118.1000
118.1000
etc
Channel spacing
(kHz)
25
8.33
8.33
8.33
25
8.33
8.33
8.33
25
8.33
8.33
8.33
25
8.33
8.33
8.33
25
8.33
Channel ID
(Displayed Freq.)
118.000
118.005
118.010
118.015
118.020
118.030
118.035
118.040
118.050
118.055
118.060
118.065
118.070
118.080
118.085
118.090
118.100
118.105
Operating Freq.
(MHz)
118.0000
118.0250
118.0500
118.0750
118.1000
etc
Channel spacing
(kHz)
25
25
25
25
25
Channel ID
(Displayed Freq.)
118.000
118.025
118.050
118.075
118.100
Oct. 2008 (REPLACEMENT PAGE)
4-2 PLL ADJUSTMENT
Vdd
DRAIN
VOLTAGE
Idd
DRAIN
CURRENT
PLL LOCK
VOLTAGE
TUNE
VOLTAGE
REFERENCE
FREQUENCY
ADJUSTMENT
ADJUSTMENT ADJUSTMENT CONDITION MEASUREMENT VALUE POINT
UNIT LOCATION UNIT ADJUST
1
1
2
1
2
1
1
sOperating frequency :
118.000 MHz
sReceiving
sOperating frequency :
127.000 MHz
sTransmitting
sOperating frequency :
118.000 MHz
sReceiving
sTransmitting
sOperating frequency :
118.000 MHz
sReceiving
sOperating frequency :
136.950 MHz
sConnect an RF power meter or a
50 7dummy load to the antenna
connector.
sTransmitting
MAIN
MAIN
MAIN
MAIN
Rear
panel
Connect a digital
1) Unsolder CP5.
multi-meter to drain
terminal of Q51.
Connect a digital
multi-meter to the
check point CP2.
Connect a digital
multi-meter to the
check point CP1.
Loosely couple the
frequency counter
to the antenna con-
nector.
13.5 V
650–750 mA
–– ––
0.5 V
0.5 V [A110]
0.3 V [A110EURO]
0.7 V
136.9500 MHz
MAIN
MAIN
MAIN
MAIN
MAIN
R392
R222
L41
L40
R59
X1
4-3 TRANSMITTER ADJUSTMENT
OUTPUT
POWER
MODULATION
DEPTH
HEAD SET
MODULATION
ADJUSTMENT
ADJUSTMENT ADJUSTMENT CONDITION MEASUREMENT VALUE POINT
UNIT LOCATION UNIT ADJUST
1
1
2
1
sOperating frequency :
127.000 MHz
sNo audio applied to the [MIC]
jack.
sTransmitting
sOperating frequecy :
127.000 MHz
sConnect an audio generator to
the [MIC] jack and set as :
1 kHz/10 mVrms
sSet a modulation analyzer as :
HPF : OFF
LPF : OFF
De-emphasis : OFF
Detector : (P–P)/2
sPre-set R110 and R121 on the
MAIN unit to the center position.
sTransmitting
sSet an audio generator as:
1 kHz/1 mVrms
sTransmitting
sOperating frequency :
127.000 MHz
sConnect an audio generator to
the [EXT MIC] jack and set as :
1 kHz/25 mVrms
sTransmitting
Rear
panel
Rear
panel
Rear
panel
Connect an RF
power meter to the
antenna connector.
Connect a modula-
tion analyzer to the
antenna connector
through an attenua-
tor.
Connect a modula-
tion analyzer to the
antenna connector
through an attenua-
tor.
9.0 W
90 %
30 %
30 %
MAIN
MAIN
MAIN
R150
R121
R110
R336
2)
Connect an am-
meter to CP5.
Recover the solder-
ing of CP5
.
4 - 3
Oct. 2008 (REPLACEMENT PAGE)
DC power supply
13.75 V/10 A
R392
Vdd voltage adjustment
Q51
Vdd check point
R336
Head set modulation
adjustment
CP1
TUNE voltage check point
R59
TUNE voltage adjustment
L40
PLL lock voltage
adjustment for TX
L41
PLL lock voltage
adjustment for RX
X1
Reference frequency
adjustment
CP2
PLL lock voltage
check point
R121
R110
Modulation depth
adjustment
R150
Output power adjustment
CP5
Unsolder&Ammeter connect
J6, pin 3
Audio input point
Audio
generator
pin 5 ( PTT)
pin 3 ( MIC)
pin 4 ( GND)
pin 2 ( MICE)
CP5
R222
Idd adjustment
4 - 4
1
PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER DESCRIPTION
NO. NO.
IC1 1140008780 S.IC HD6433823A19D Except [A110EURO]
1140009830 S.IC HD6433823A80D [A110EURO]
IC2 1110005771 S.IC S-80942CNMC-G9CT2G
IC3 1130007111 S.IC TC7W04FU
IC4 1130011321 S.IC CAT25C16VI-TE13
IC5 1130007570 S.IC BU4094BCFV-E2
Q1 1590000440 S.TR DTA143ZUA T106
Q2 1510000881 S.TR 2SA1622-6-TL-E
Q3 1530003281 S.TR 2SC4211-6-TL-E
Q4 1590001980 S.TR XP4315 (TX)
Q5 1590000440 S.TR DTA143ZUA T106
Q6 1590000680 S.TR DTC114EUA T106
Q7 1590000680 S.TR DTC114EUA T106
D5 1790001280 S.DIO MA111 (TX)
D6 1750000130 S.DIO DA204U T106
X1 6060000770 S.CER EFOP3684E5
L1 6200003960 S.COL MLF1608A 1R0K-T Except [A110EURO]
L2 6200003540 S.COL MLF1608D R22K-T Except [A110EURO]
R1 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R2 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R3 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R4 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R5 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R6 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R7 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R8 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R11 7030003370 S.RES ERJ3GEYJ 271 V (270)
R12 7030003350 S.RES ERJ3GEYJ 181 V (180)
R13 7030003350 S.RES ERJ3GEYJ 181 V (180)
R14 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R15 7030003590 S.RES ERJ3GEYJ 183 V (18 k)
R16 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R17 7030003620 S.RES ERJ3GEYJ 333 V (33 k)
R18 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R19 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R20 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R21 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R22 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R23 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R24 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R26 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R27 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R28 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R29 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R30 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R31 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R32 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R33 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R34 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R36 7030003600 S.RES ERJ3GEYJ 223 V (22 k)
R37 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R38 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R41 7030003610 S.RES ERJ3GEYJ 273 V (27 k)
R42 7030003610 S.RES ERJ3GEYJ 273 V (27 k)
R43 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R44 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R45 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R46 7030003610 S.RES ERJ3GEYJ 273 V (27 k)
R47 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
C1 4030006860 S.CER C1608 JB 1H 102K-T
C2 4030006860 S.CER C1608 JB 1H 102K-T
C3 4030007090 S.CER C1608 CH 1H 470J-T
C4 4030007090 S.CER C1608 CH 1H 470J-T
C5 4030006860 S.CER C1608 JB 1H 102K-T
C6 4030007090 S.CER C1608 CH 1H 470J-T
C7 4030006850 S.CER C1608 JB 1H 471K-T
C8 4030006850 S.CER C1608 JB 1H 471K-T
C9 4030008560 S.CER C1608 CH 1H 300J-T
C10 4030008560 S.CER C1608 CH 1H 300J-T
C11 4030008890 S.CER C1608 JB 1H 273K-T
C12 4030011600 S.CER C1608 JB 1E 104K-T
C13 4030011600 S.CER C1608 JB 1E 104K-T
C14 4030011600 S.CER C1608 JB 1E 104K-T
C15 4030007090 S.CER C1608 CH 1H 470J-T
C16 4030011600 S.CER C1608 JB 1E 104K-T
C17 4030011600 S.CER C1608 JB 1E 104K-T
S.=Surface mount
[FRONT UNIT]
REF ORDER DESCRIPTION
NO. NO.
C18 4030006860 S.CER C1608 JB 1H 102K-T
C19 4030006860 S.CER C1608 JB 1H 102K-T
C20 4030011600 S.CER C1608 JB 1E 104K-T
C21 4030006860 S.CER C1608 JB 1H 102K-T
C22 4030011600 S.CER C1608 JB 1E 104K-T
C23 4550006480 S.TAN TEESVA 1C 475M8R
C24 4030011600 S.CER C1608 JB 1E 104K-T
C25 4030011600 S.CER C1608 JB 1E 104K-T
C26 4030011600 S.CER C1608 JB 1E 104K-T
C27 4550006250 S.TAN TEESVA 1A 106M8R
C28 4030006860 S.CER C1608 JB 1H 102K-T
C29 4030006860 S.CER C1608 JB 1H 102K-T
C30 4030006890 S.CER C1608 JF 1H 103Z-T [A110EURO]
4030007090 S.CER C1608 CH 1H 470J-T Except [A110EURO]
C31 4030006860 S.CER C1608 JB 1H 102K-T
C32 4030006860 S.CER C1608 JB 1H 102K-T
C33 4030006860 S.CER C1608 JB 1H 102K-T
C34 4030006860 S.CER C1608 JB 1H 102K-T
C35 4030006860 S.CER C1608 JB 1H 102K-T
C36 4030006860 S.CER C1608 JB 1H 102K-T
C37 4030007090 S.CER C1608 CH 1H 470J-T [A110EURO] only
C38 4030006860 S.CER C1608 JB 1H 102K-T [A110EURO] only
J1 6510020511 S.CNR FH12-40S-0.5SV (55)
J2 6450001471 CNR 95003-2881
DS1 5030001740 LCD HLC7453-012400
DS2 5040002030 S.LED CL-170Y-CD-T
DS3 5040002030 S.LED CL-170Y-CD-T
DS4 5040002030 S.LED CL-170Y-CD-T
DS5 5040002030 S.LED CL-170Y-CD-T
DS6 5040002030 S.LED CL-170Y-CD-T
DS7 5040002030 S.LED CL-170Y-CD-T
S1 2250000420 ECR EVQB2CFC620B
SP1 2510000880 SP SME-45W Except [GEN], [AUS]
2510000881 SP SME-C45W0819[GEN], [AUS]
W1 7120000470 JMP ERDS2T0
W2 7120000470 JMP ERDS2T0
W3 7030003860 S.RES ERJ3GE JPW V
W4 7030003860 S.RES ERJ3GE JPW V
W6 8900007680 CBL OPC-741 (N:40 L:55)
W6 8900007682 CBL OPC-741A-1 (P0.5,N40,L55)
EP2 8930037960 LCT SRCN-1705 ZSS
Oct. 2008
2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
IC2 1130008831 S.IC TB31207AFNG(EL) 1 B 88/26.6
IC4 1110003670 S.IC BA3308F-E2 B 102.7/22.9
IC5 1110002751 S.IC TA75S01F(TE85R,F) T 109.7/21
IC6 1130004201 S.IC TC4S66F(TE85R,F) B 60.1/37.4
IC7 1110006090 S.IC XC6202P502PR B 75.4/14.3
IC11 1110002400 S.IC NJM2107F-TE1-#ZZZB B 104.6/37.8
IC13 1130011860 S.IC SM6451BT-G-E2 [GEN] B 50.8/41.2
1130011860 S.IC SM6451BT-G-E2 [GEN-1]
1130011860 S.IC SM6451BT-G-E2 [USA]
1130011860 S.IC SM6451BT-G-E2 [USA-1]
1130008370 S.IC TC9260F (HR) 2 [AUS]
1130011860 S.IC SM6451BT-G-E2 [CHN]
1130011860 S.IC SM6451BT-G-E2 [EUR]
1130011860 S.IC SM6451BT-G-E2 [EUR-1]
IC15 1110005011 S.IC MC33063ADR2G B 17.2/45.8
IC16 1130006221 S.IC TC4W53FU(TE12L,F) B 101.7/12.2
IC17 1130006221 S.IC TC4W53FU(TE12L,F) [USA] B 114/34.8
1130006221 S.IC TC4W53FU(TE12L,F) [USA-1]
1130006221 S.IC TC4W53FU(TE12L,F) [EUR]
1130006221 S.IC TC4W53FU(TE12L,F) [EUR-1]
IC18 1130006221 S.IC TC4W53FU(TE12L,F) [USA] B 127.5/18
1130006221 S.IC TC4W53FU(TE12L,F) [USA-1]
1130006221 S.IC TC4W53FU(TE12L,F) [EUR]
1130006221 S.IC TC4W53FU(TE12L,F) [EUR-1]
IC19 1110003780 S.IC NJM2902V-TE1-#ZZZB B 60.3/28.5
IC22 1130006221 S.IC TC4W53FU(TE12L,F) B 52.5/24.9
IC26 1180000421 S.IC TA78L05F(TE12R,F) B 25.6/50.1
IC28 1130004201 S.IC TC4S66F(TE85R,F) B 18.7/71.5
IC29 1180002010 S.REG BA08FP-E2 T 73.9/22.6
IC30 1130004201 S.IC TC4S66F(TE85R,F) B 36.5/66
IC31 1110002751 S.IC TA75S01F(TE85R,F) T 106/7.5
IC37 1110003250 S.IC TDA7233D (TDA7233D013TR) B 25.9/76
IC40 1110003201 S.IC TA31136FNG(EL) B 113.7/39.6
IC41 1110003091 IC LA4425A-E
IC42 1110002751 S.IC TA75S01F(TE85R,F) T 58.7/29.7
IC43 1190001211 S.IC HIP4081AIBZ-T T 21.2/37.9
IC44 1110005131 S.IC UPC311G2-E2-A B 6.5/15
IC45 1110005100 S.IC NJM072BM-TE1-#ZZZB T 7.4/25
IC46 1110005011 S.IC MC33063ADR2G B 19.8/15.8
IC47 1190001211 S.IC HIP4081AIBZ-T T 18.4/17.7
IC48 1130006221 S.IC TC4W53FU(TE12L,F) B 6.8/24.1
IC50 1110002751 S.IC TA75S01F(TE85R,F) B 86.8/79
IC51 1110002751 S.IC TA75S01F(TE85R,F) T 104.8/13.4
IC52 1190002051 S.IC SPM5001-TL-E 1 T 104.4/51.6
Q1 1580000731 S.FET 3SK293(TE85L,F) B 120.8/62
Q3 1530002601 S.TRA 2SC4215-O(TE85R,F) B 123.8/35.6
Q4 1530002601 S.TRA 2SC4215-O(TE85R,F) B 128.9/13.7
Q5 1530002601 S.TRA 2SC4215-O(TE85R,F) B 118.9/14.3
Q6 1530002601 S.TRA 2SC4215-O(TE85R,F) B 115.7/6.6
Q7 1530003281 S.TRA 2SC4211-6-TL-E B 113/16.4
Q11 1530002280 S.TRA 2SC4081 T106 S T 88.7/72.4
Q12 1530002561 S.TRA 2SC4403-3-TL-E B 99.5/33
Q14 1530002561 S.TRA 2SC4403-3-TL-E B 93.4/41.7
Q15 1530002930 S.TRA 2SC4228(M)-T1 R45 B 99.5/44.4
Q16 1530002851 S.TRA 2SC4116-BL(TE85R,F) T 98/42.5
Q20 1560001101 S.FET 2SK3074(TE12L,F) B 83.1/65.7
Q21 1560001061 S.FET 2SK3075(TE12L,Q) T 67/70.7
Q22 1530003281 S.TRA 2SC4211-6-TL-E B 67.3/18.4
Q23 1520000460 S.TRA 2SB1132 T100 R B 61.9/17.8
Q33 1590001980 S.TRA XP4315(TX) T 105/21.7
Q42 1530002920 S.TRA 2SC4226-T1 R25 B 93/55.7
Q43 1530002920 S.TRA 2SC4226-T1 R25 T 89.9/42.6
Q44 1530002920 S.TRA 2SC4226-T1 R25 T 83.5/48.4
Q51 1590002841 FET MRF137 <M/A> T 62.8/98.9
Q52 1510000881 S.TRA 2SA1622-6-TL-E B 100.5/5.9
Q53 1590000980 S.TRA DTB123EK T146 T 76/11.9
Q58 1590001810 S.TRA XP1113(TX) T 98/46.9
Q59 1530002920 S.TRA 2SC4226-T1 R25 T 82.8/39.7
Q68 1590001980 S.TRA XP4315(TX) T 111.9/52.8
Q69 1590000980 S.TRA DTB123EK T146 T 112/49.8
Q70 1590000980 S.TRA DTB123EK T146 B 60.2/49.7
Q71 1590001940 S.TRA DTC144EE TL B 62.3/44.7
Q72 1590001980 S.TRA XP4315(TX) B 71.6/11.4
Q73 1530002060 S.TRA 2SC4081 T106 R T 127.6/76.6
Q74 1520000201 S.TRA 2SB798-T2-AZ DK B 18.4/78.3
Q75 1530002060 S.TRA 2SC4081 T106 R B 14.8/81.2
Q77 1540000520 S.TRA 2SD1819A(TX)R 0 T 124.9/14.4
Q78 1540000520 S.TRA 2SD1819A(TX)R 0 T 116/15.2
Q79 1560000531 S.FET 2SK880-GR(TE85R,F) B 73.4/56.8
Q80 1590000720 S.TRA DTA144EUA T106 B 60.6/41.5
Q81 1590000430 S.TRA DTC144EUA T106 B 59.9/44.6
Q82 1530002280 S.TRA 2SC4081 T106 S B 25.7/54.9
Q83 1530002381 S.TRA 2SC4215-Y(TE85L,F) T 110.8/33.7
Q84 1530002381 S.TRA 2SC4215-Y(TE85L,F) T 106.4/31.5
Q86 1590001980 S.TRA XP4315(TX) B 18.7/87.9
Q87 1560001121 S.FET 2SK2414-Z-E1-AZ B 18.3/36.9
Q88 1560001121 S.FET 2SK2414-Z-E1-AZ B 25.3/29.8
Q89 1590001170 S.TRA XP1501-(TX).AB T 7.5/50.9
Q90 1510001020 TRA 2SA1471R
Q91 1560001121 S.FET 2SK2414-Z-E1-AZ B 36.6/31.2
Q92 1560001121 S.FET 2SK2414-Z-E1-AZ B 32.9/6
Q93 1560001121 S.FET 2SK2414-Z-E1-AZ B 32.2/17.6
Q94 1590003820 S.FET FW261-TL-E B 34.2/111.5
Q96 1590000430 S.TRA DTC144EUA T106 B 36.1/99.7
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
Q97 1590000430 S.TRA DTC144EUA T106 B 33.2/98.8
Q98 1510000771 S.TRA 2SA1586-GR(TE85L,F) T 85.4/69.5
Q99 1530002851 S.TRA 2SC4116-BL(TE85R,F) T 91.5/72.4
Q100 1590003820 S.FET FW261-TL-E B 16.7/111.1
Q101 1590000430 S.TRA DTC144EUA T106 B 16.6/99.7
Q102 1530002280 S.TRA 2SC4081 T106 S B 17.7/23.1
D1 1750000510 S.DIO UM9401F 2 [GEN] B 121/83
1750000511 S.DIO UX9401F-STD/TR [GEN-1]
1750000511 S.DIO UX9401F-STD/TR [USA]
1750000511 S.DIO UX9401F-STD/TR [USA-1]
1750000510 S.DIO UM9401F 2 [AUS]
1750000760 S.DIO MA4PH224 (MA4P1250-1072TL)
[CHN]
1750000510 S.DIO UM9401F 2 [EUR]
1750000511 S.DIO UX9401F-STD/TR [EUR-1]
D2 1750000510 S.DIO UM9401F 2 [GEN] B 118.3/75.1
1750000511 S.DIO UX9401F-STD/TR [GEN-1]
1750000511 S.DIO UX9401F-STD/TR [USA]
1750000511 S.DIO UX9401F-STD/TR [USA-1]
1750000510 S.DIO UM9401F 2 [AUS]
1750000760 S.DIO MA4PH224 (MA4P1250-1072TL)
[CHN]
1750000510 S.DIO UM9401F 2 [EUR]
1750000511 S.DIO UX9401F-STD/TR [EUR-1]
D3 1750000510 S.DIO UM9401F 2 [GEN] T 110/82.4
1750000511 S.DIO UX9401F-STD/TR [GEN-1]
1750000511 S.DIO UX9401F-STD/TR [USA]
1750000511 S.DIO UX9401F-STD/TR [USA-1]
1750000510 S.DIO UM9401F 2 [AUS]
1750000760 S.DIO MA4PH224 (MA4P1250-1072TL)
[CHN]
1750000510 S.DIO UM9401F 2 [EUR]
1750000511 S.DIO UX9401F-STD/TR [EUR-1]
D4 1790001670 S.DIO RB706F-40T106 B 94.2/90.5
D5 1790001670 S.DIO RB706F-40T106 B 88.3/90.4
D6 1720000781 S.VAR HVU350BTRF-E B 133.5/65.7
D7 1720000781 S.VAR HVU350BTRF-E B 110.6/65
D8 1720000781 S.VAR HVU350BTRF-E B 107.2/65.6
D10 1790000620 S.DIO MA77(TX) 0 B 99.5/51.7
D11 1790000620 S.DIO MA77(TX) 0 B 98.7/54.4
D14 1790001330 S.ZEN MA8036-L(TX) 0 B 96.3/23.5
D15 1790001280 S.DIO MA111(TX) 0 B 65.3/15.8
D26 1790001341 S.DIO DE5SC6M-7061 B 30.5/38.9
D27 1790001280 S.DIO MA111(TX) 0 B 100.5/9.5
D28 1750000581 S.DIO 1SV307(TPH3,F) [USA] B 114.7/52
1750000581 S.DIO 1SV307(TPH3,F) [USA-1]
1750000581 S.DIO 1SV307(TPH3,F) [EUR]
1750000581 S.DIO 1SV307(TPH3,F) [EUR-1]
D29 1750000581 S.DIO 1SV307(TPH3,F) B 114.7/50.1
D30 1750000581 S.DIO 1SV307(TPH3,F) B 126.3/48.6
D31 1750000581 S.DIO 1SV307(TPH3,F) [USA] B 126/51
1750000581 S.DIO 1SV307(TPH3,F) [USA-1]
1750000581 S.DIO 1SV307(TPH3,F) [EUR]
1750000581 S.DIO 1SV307(TPH3,F) [EUR-1]
D35 1730002460 S.ZEN MA8330-M(TX) 0 B 31.4/55.6
D36 1790000700 DIO DSA3A1
D37 1720000781 S.VAR HVU350BTRF-E B 128.2/65.7
D38 1750000531 S.DIO 1SV271(TPH3,F) B 126.4/76.2
D43 1750000261 S.DIO 1SS352(TPH3,F) B 18/82.1
D44 1730002320 S.ZEN MA8051-M(TX) 0 B 107.9/41.7
D50 1750000531 S.DIO 1SV271(TPH3,F) B 123.4/43.5
D51 1750000531 S.DIO 1SV271(TPH3,F) B 132.8/12.1
D52 1750000531 S.DIO 1SV271(TPH3,F) B 120.3/10
D53 1790001250 S.DIO MA2S111-(TX) 0 T 120.6/74.3
D54 1790001250 S.DIO MA2S111-(TX) 0 T 123.3/74.3
D55 1790000671 S.DIO SB07-03C-TB-E T 29.7/42.4
D56 1790001341 S.DIO DE5SC6M-7061 B 32.1/24.1
D57 1750000051 S.DIO 1SS193(TE85R,F) T 27/17.5
D62 1790000671 S.DIO SB07-03C-TB-E B 33.7/103
D64 1720000781 S.VAR HVU350BTRF-E T 78.4/45.4
D65 1720000781 S.VAR HVU350BTRF-E T 77.5/42
D66 1790000671 S.DIO SB07-03C-TB-E B 15.8/103.2
FI1 2010002400 S.MON DSF753SB 38.850 MHz(FL-306) T 121.2/48
FI2 2010002410 S.MON DSF753SB 38.850 MHz(FL-307L)
[USA] T 121.2/55.2
2010002410 S.MON DSF753SB 38.850 MHz(FL-307L)
[USA-1]
2010002410 S.MON DSF753SB 38.850 MHz(FL-307L)
[EUR]
2010002410 S.MON DSF753SB 38.850 MHz(FL-307L)
[EUR-1]
FI3 2020001540 CER CFWLB450KDFA-B0 (CFWM450D)
FI4 2020001660 CER CFG450H [USA]
2020001660 CER CFG450H [USA-1]
2020001660 CER CFG450H [EUR]
2020001660 CER CFG450H [EUR-1]
FI5 4580000110 S.FIL ACF321825-223-T B 15.5/16.8
FI6 2040000500 LC BNX-002-01
Oct. 2008
3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
X1 6050010831 S.XTA
CR-657A TCXO GS41130 12.8 MHz
[GEN] T 89.2/24.9
6050010831 S.XTA
CR-657A TCXO GS41130 12.8 MHz
[GEN-1]
6050010831 S.XTA
CR-657A TCXO GS41130 12.8 MHz
[USA]
6050010831 S.XTA
CR-657A TCXO GS41130 12.8 MHz
[USA-1]
6050010831 S.XTA
CR-657A TCXO GS41130 12.8 MHz
[AUS]
6050010831 S.XTA
CR-657A TCXO GS41130 12.8 MHz
[CHN]
6050010841 S.XTA CR-658A TCXO 12.800 MHz[EUR]
6050010841 S.XTA CR-658A TCXO 12.800 MHz
[EUR-1]
L2 6110001670 COI LA-253
L3 6110001740 COI LA-263
L4 6110001610 COI LA-244
L5 6110001610 COI LA-244
L6 6110001550 COI LA-235
L7 6170000230 COI LW-25
L9 6150005001 S.COI LS-527-LF T 130.8/65.1
L10 6150005001 S.COI LS-527-LF T 113.7/65.1
L11 6150005001 S.COI LS-527-LF T 106.4/65.1
L14 6200001630 S.COI ELJNC R10K-F B 96.3/41.2
L15 6200003300 S.COI ELJNC R22K-F B 99.1/46.9
L17 6200003290 S.COI ELJNC R12K-F B 90.1/58.3
L19 6200005731 S.COI ELJRE 39NGFA B 86.4/62.8
L20 6200002380 S.COI LQW31HN56NJ03L B 80.5/61.7
L21 6200013030 S.COI 0.35-1.6-6TL 31.0N <COMO> T 54.1/73.8
L22 6200005741 S.COI ELJRE 47NGFA T 77.3/69
L23 6200012870 S.COI 0.30-1.4-5TR 23.5N <COMO> T 55.2/77.2
L26 6200003590 S.COI EXCCL3225U1 B 75.6/61.3
L27 6200001920 S.COI ELJNC R15K-F T 133.6/74.6
L31 6200007001 S.COI ELJRE 82NGFA T 89.9/40.4
L33 6200004480 S.COI MLF1608D R82K-T T 73.4/43.5
L35 6200012520 S.COI 0.26-1.0-5TL 12N <COMO> T 49.3/88.8
L36 6140000670 COI LR-89
L39 6200004480 S.COI MLF1608D R82K-T T 89.2/48.8
L40 6200009081 S.COI #E558CN-100025=P3 T 71.9/47.5
L41 6200004851 S.COI #E558CN-100024=P3 T 71.8/36.9
L42 6200004480 S.COI MLF1608D R82K-T T 74.3/42
L43 6200004480 S.COI MLF1608D R82K-T T 86.3/44.4
L48 6110001600 COI LA-243
L49 6150005001 S.COI LS-527-LF T 122.6/65.1
L50 6110001730 COI LA-262
L52 6200004480 S.COI MLF1608D R82K-T T 127.6/78.8
L53 6190001500 COI HK-08S070-1310
L54 6200007001 S.COI ELJRE 82NGFA B 102.4/52.1
L55 6200003310 S.COI ELJFC R33M-F T 110.7/41.4
L56 6200003310 S.COI ELJFC R33M-F T 113.6/36.1
L57 6200003310 S.COI ELJFC R33M-F T 110.4/28.6
L60 6200005011 S.COI NLV25T-100J T 8.9/37.5
L61 6190001510 COI HK-10S080-1210
L62 6190001500 COI HK-08S070-1310
L63 6190001500 COI HK-08S070-1310
L64 6190001500 COI HK-08S070-1310
L65 6200005011 S.COI NLV25T-100J T 3.1/31.1
L67 6200013050 S.COI 0.26-0.9-9TR 23.0N <COMO> T 50.6/82.9
L68 6200012860 S.COI 0.20-0.7-4TR 6.5N <COMO> T 49.9/94.6
L69 6200012520 S.COI 0.26-1.0-5TL 12N <COMO> T 50.5/98.8
L70 6110001520 COI LA-232
L71 6110002110 COI LA-382
L72 6200002041 S.COI NLV25T-101J B 125.8/12.4
L73 6200002041 S.COI NLV25T-101J B 112.3/6.6
L74 6200002710 S.COI ELJFC 1R8K-F B 120.6/36.7
L75 6200004480 S.COI MLF1608D R82K-T B 92/85.8
L77 6200009141 S.COI NLV25T-6R8J B 84.8/31.4
L78 6190001690 S.COI ZBFS5105-PT-01 B 42.7/46.2
L79 6190001690 S.COI ZBFS5105-PT-01 B 22.2/44.5
L80 6190001690 S.COI ZBFS5105-PT-01 B 55.2/16.8
L81 6190001690 S.COI ZBFS5105-PT-01 B 44.4/13.1
L82 6200004450 S.COI ELJFC 6R8M-F T 76.2/47.1
L83 6200004880 S.COI ELJFC 3R3K-F T 83.2/45.5
L84 6200004880 S.COI ELJFC 3R3K-F T 85.7/36.9
L85 6200004450 S.COI ELJFC 6R8M-F T 77.4/38.9
L86 6190001690 S.COI ZBFS5105-PT-01 B 13.7/115.6
L87 6200006991 S.COI ELJRE 56NGFA B 97.2/49.5
L88 6200004480 S.COI MLF1608D R82K-T [EUR] B 95.8/7.1
6200004480 S.COI MLF1608D R82K-T [EUR-1]
L89 6130002961 S.COI #617DB-1327=P3 T 100.7/56.3
L90 6130003000 S.COI #617DB-1714=P3 B 108.6/52.9
L91 6130003000 S.COI #617DB-1714=P3 B 109.7/48
R1 7030006070 S.RES ERJ12YJ101U (100) B 105.4/74.2
R2 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 92.8/88.1
R3 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 88.4/88.1
R9 7030003720 S.RES ERJ3GEYJ 224 V (220K) B 130.1/61.9
R11 7030003720 S.RES ERJ3GEYJ 224 V (220K) B 123.4/62.2
R12 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 126.4/62.2
R13 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 118.3/62.1
R14 7030003770 S.RES ERJ3GEYJ 564 V (560K) B 115.5/62.1
R15 7030003320 S.RES ERJ3GEYJ 101 V (100) B 123.3/65.7
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
R17 7030003280 S.RES ERJ3GEYJ 470 V (47) B 118.6/66.5
R18 7030003720 S.RES ERJ3GEYJ 224 V (220K) B 112.3/62.1
R19 7030003720 S.RES ERJ3GEYJ 224 V (220K) B 108.9/62.1
R20 7030003720 S.RES ERJ3GEYJ 224 V (220K) B 107.2/62.1
R25 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 103.9/50.9
R30 7030003590 S.RES ERJ3GEYJ 183 V (18K) B 120.4/41
R31 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) B 125.1/37.9
R34 7030003470 S.RES ERJ3GEYJ 182 V (1.8K) B 133.3/19.2
R35 7030003320 S.RES ERJ3GEYJ 101 V (100) B 132.5/16.8
R36 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 131.9/14.5
R37 7030003650 S.RES ERJ3GEYJ 563 V (56K) B 129/15.6
R38 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) B 129/11.8
R40 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 122.7/11.7
R41 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 121.9/9.6
R42 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) B 118.6/10.1
R43 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 115.9/14.3
R45 7030003650 S.RES ERJ3GEYJ 563 V (56K) B 115.7/8.7
R46 7030003320 S.RES ERJ3GEYJ 101 V (100) B 115.7/4.5
R48 7030003650 S.RES ERJ3GEYJ 563 V (56K) B 110.7/12.7
R49 7030003750 S.RES ERJ3GEYJ 394 V (390K) B 112.9/14.3
R50 7030003430 S.RES ERJ3GEYJ 821 V (820) B 111.3/21.6
R59 7310004660 S.TRI EVM-2WSX80 B54 (503) T 81.2/57.9
R61 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [GEN] B 68.1/42.1
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [GEN-1]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [USA]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [USA-1]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [AUS]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [CHN]
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [EUR]
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [EUR-1]
R62 7030003440 S.RES ERJ3GEYJ 102 V (1K) [GEN] B 76.2/25
7030003440 S.RES ERJ3GEYJ 102 V (1K) [GEN-1]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [USA-1]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [AUS]
7030003440 S.RES ERJ3GEYJ 102 V (1K) [CHN]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [EUR]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [EUR-1]
R63 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 98/40.5
R64 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 81.9/25.8
R65 7030003220 S.RES ERJ3GEYJ 150 V (15) B 96.3/36.6
R66 7030003220 S.RES ERJ3GEYJ 150 V (15) B 96.3/38.1
R67 7030003220 S.RES ERJ3GEYJ 150 V (15) B 99.5/38.1
R68 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [GEN] B 96.3/35.1
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [GEN-1]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [USA]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [USA-1]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [AUS]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [CHN]
7030003320 S.RES ERJ3GEYJ 101 V (100) [EUR]
7030003320 S.RES ERJ3GEYJ 101 V (100) [EUR-1]
R69 7030003700 S.RES ERJ3GEYJ 154 V (150K) B 99.5/35.1
R70 7030003400 S.RES ERJ3GEYJ 471 V (470) B 96.3/33
R71 7030003280 S.RES ERJ3GEYJ 470 V (47) B 96.3/28.4
R72 7030003660 S.RES ERJ3GEYJ 683 V (68K) B 93.4/39.6
R73 7030003370 S.RES ERJ3GEYJ 271 V (270) B 93.4/45.5
R74 7030003630 S.RES ERJ3GEYJ 393 V (39K) B 99.5/42.5
R75 7030003340 S.RES ERJ3GEYJ 151 V (150) B 96.3/44.1
R76 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 96.4/52.7
R77 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 96.3/60.2
R78 7030003290 S.RES ERJ3GEYJ 560 V (56) B 97.1/54.8
R79 7030003400 S.RES ERJ3GEYJ 471 V (470) B 97.4/58.3
R80 7030003290 S.RES ERJ3GEYJ 560 V (56) B 95.5/56.2
R85 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 93.1/60.5
R86 7030003360 S.RES ERJ3GEYJ 221 V (220) B 90.8/61.5
R87 7030003330 S.RES ERJ3GEYJ 121 V (120) B 92.1/58.4
R95 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 87.2/65.1
R99 7030003270 S.RES ERJ3GEYJ 390 V (39) T 75/68.2
R101 7030003560 S.RES ERJ3GEYJ 103 V (10K) [GEN] T 86.2/67.1
7030003560 S.RES ERJ3GEYJ 103 V (10K) [GEN-1]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [USA]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [USA-1]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [AUS]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [CHN]
7030003510 S.RES ERJ3GEYJ 392 V (3.9K) [EUR]
7030003510 S.RES ERJ3GEYJ 392 V (3.9K) [EUR-1]
R108 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 106.4/13.5
R110 7310004530 S.TRI EVM-2WSX80 B14 (103) T 98.5/17.8
R111 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 99.6/28.2
R112 7030003270 S.RES ERJ3GEYJ 390 V (39) B 107.1/28.3
R113 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 104.2/28.3
R114 7510001571 S.THE NTCG16 4LH 104JT T 105/26
R115 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 108.7/24.1
R116 7030003770 S.RES ERJ3GEYJ 564 V (560K) T 111.3/17.3
R117 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 96.3/25.2
R118 7030003690 S.RES ERJ3GEYJ 124 V (120K) T 112.1/20.7
R119 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 112.1/23.6
R120 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 107.3/20.7
R121 7310004610 S.TRI EVM-2WSX80 B15 (104) T 28.1/29.3
R122 7030003630 S.RES ERJ3GEYJ 393 V (39K) T 112.7/14.3
R123 7030003630 S.RES ERJ3GEYJ 393 V (39K) T 112.7/9.3
R124 7030003630 S.RES ERJ3GEYJ 393 V (39K) T 110.6/6.5
R126 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 74.8/17.8
R127 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 70.1/17.5
R128 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 65.3/18.9
R131 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 53/37.6
R132 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 49.8/35.6
Oct. 2008
4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
R148 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 87.6/84.2
R149 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 84.3/79
R150 7310004530 S.TRI EVM-2WSX80 B14 (103) T 85.3/78.9
R151 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 84.6/82.7
R152 7030003320 S.RES ERJ3GEYJ 101 V (100) B 89.8/85
R153 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) B 85.4/86.5
R174 7030003650 S.RES ERJ3GEYJ 563 V (56K) B 122.7/14.3
R181 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 56.4/36.5
R182 7030003760 S.RES ERJ3GEYJ 474 V (470K) B 106.3/34.8
R183 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 104.4/34.9
R184 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 104.9/40.8
R186 7030003700 S.RES ERJ3GEYJ 154 V (150K) B 56.1/35.6
R187 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 57.5/35.6
R188 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 105/24.7
R192 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 89.9/45
R193 7030003400 S.RES ERJ3GEYJ 471 V (470) T 89.2/37.2
R194 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) T 86.2/48.8
R208 7030003320 S.RES ERJ3GEYJ 101 V (100) B 8.9/72.5
R209 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 8.9/69.7
R211 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) B 16.8/54.7
R212 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 16.8/56.1
R218 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 82.3/29.5
R219 7030000210 S.RES MCR10EZHJ 39 (390) T 47.2/106.4
R220 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 46.8/102.3
R221 7030000490 S.RES MCR10EZHJ 8.2K (822) B 47.8/101.6
R223 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 103.9/6.6
R224 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 103.9/3.9
R225 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 103.9/5.2
R226 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 100.5/7.9
R228 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 129.2/51
R229 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 115.7/47.7
R230 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [USA] B 122.4/51.1
7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [USA-1]
7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [EUR]
7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [EUR-1]
R231 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [USA] B 117.9/52
7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [USA-1]
7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [EUR]
7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [EUR-1]
R232 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 123.1/48.6
R233 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 118/49.6
R234 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 70.8/21.9
R235 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 65.8/23.6
R236 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 63.1/23.6
R237 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 63.8/25.7
R238 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 65.1/27.3
R239 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 63.4/33.1
R240 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 61.3/33.4
R241 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 55.9/31.8
R242 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 56.8/29.6
R243 7030003320 S.RES ERJ3GEYJ 101 V (100) T 96.8/29.5
R251 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 98/44.7
R256 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) T 85.5/41.8
R267 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 29.8/54.6
R273 7030003760 S.RES ERJ3GEYJ 474 V (470K) B 29.2/71.8
R280 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 26.1/28.6
R281 7030003750 S.RES ERJ3GEYJ 394 V (390K) T 113.4/16.5
R288 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 114.6/40.2
R289 7030003720 S.RES ERJ3GEYJ 224 V (220K) B 128.2/61.9
R295 7030003350 S.RES ERJ3GEYJ 181 V (180) B 129/75.4
R297 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 127.4/74.3
R301 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 49.3/29.7
R321 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 27/71.3
R322 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) B 44.4/77.3
R323 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 14.9/87.1
R325 7030003370 S.RES ERJ3GEYJ 271 V (270) B 18/83.7
R327 7030003340 S.RES ERJ3GEYJ 151 V (150) B 107.6/43.4
R328 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 118/16.8
R329 7030003690 S.RES ERJ3GEYJ 124 V (120K) T 119.3/10.7
R330 7510001000 S.THE TBPS1R154K475H5Q T 118/10.7
R331 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 116.7/12.3
R332 7030003690 S.RES ERJ3GEYJ 124 V (120K) T 118/13.9
R333 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 122.1/12.1
R334 7030003770 S.RES ERJ3GEYJ 564 V (560K) T 124.9/12.1
R336 7310004590 S.TRI EVM-2WSX80 B13 (102) T 31.8/98.6
R338 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 101.2/14.1
R340 7030003410 S.RES ERJ3GEYJ 561 V (560) B 29.3/88.7
R342 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 48.8/26
R355 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 125/16.8
R356 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 114.2/19.5
R357 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 66/42.1
R358 7030003670 S.RES ERJ3GEYJ 823 V (82K) B 75.9/56.6
R359 7030003320 S.RES ERJ3GEYJ 101 V (100) B 64.5/48.1
R361 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 25.8/67.8
R362 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) B 57.9/44.7
R363 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 59.7/24.5
R364 7030003810 S.RES ERJ3GEYJ 125 V (1.2M) T 61.1/29.7
R365 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 56.2/29.7
R366 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 56.2/26.8
R367 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 62.4/29.7
R368 7030003590 S.RES ERJ3GEYJ 183 V (18K) B 124.3/39.2
R369 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 120.2/42.3
R370 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 130.4/10.4
R371 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 122.3/13
R372 7030003320 S.RES ERJ3GEYJ 101 V (100) T 116.1/27.5
R373 7030003320 S.RES ERJ3GEYJ 101 V (100) T 114/29.6
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
R374 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 112.3/31.5
R375 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 113.2/27.5
R376 7030003770 S.RES ERJ3GEYJ 564 V (560K) T 105.8/28.7
R377 7030003240 S.RES ERJ3GEYJ 220 V (22) B 119.4/64.4
R379 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 58.3/35.7
R380 7030006060 S.RES ERJ12YJ100U (10) B 38/81.7
R383 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 15.7/89.3
R386 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 16.6/45.3
R387 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 20.7/44.6
R388 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 17.5/50.3
R389 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) B 18.5/41.2
R390 7030003410 S.RES ERJ3GEYJ 561 V (560) B 18.9/54.1
R391 7030003400 S.RES ERJ3GEYJ 471 V (470) B 16.8/51.9
R392 7310004670 S.TRI EVM-2WSX80 B55 (504) T 12.2/28
R393 7030003580 S.RES ERJ3GEYJ 153 V (15K) T 6.9/17.1
R394 7030003580 S.RES ERJ3GEYJ 153 V (15K) T 5.8/20.1
R395 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 6.6/31.5
R396 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 5.8/30.2
R397 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 8.5/30.2
R398 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 3.9/45.5
R399 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 5.2/45.5
R400 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 8.2/48
R401 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 3.7/48.1
R403 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 15.8/21
R404 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 18.9/20.2
R405 7030003650 S.RES ERJ3GEYJ 563 V (56K) B 23.8/14.8
R406 7030003470 S.RES ERJ3GEYJ 182 V (1.8K) B 22.9/10.6
R407 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 13/24.5
R408 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 14.9/25.2
R409 7030004890 S.RES ERJ3GEYF 434 V (430K) T 16.3/27.9
R410 7030004860 S.RES ERJ3GEYF 184 V (180K) T 14.8/27.9
R411 7030005260 S.RES ERJ3GEYF 394 V (390K) T 13/25.8
R412 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 5/16.7
R413 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 6.4/14.6
R414 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 8/15.9
R415 7030003410 S.RES ERJ3GEYJ 561 V (560) B 99.5/41
R417 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 39.3/109.1
R418 7030003760 S.RES ERJ3GEYJ 474 V (470K) B 29/113
R419 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 29/111.7
R420 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 39.6/112.4
R422 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 9.8/26.5
R423 7030003320 S.RES ERJ3GEYJ 101 V (100) B 85/76.2
R424 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 89.3/79
R425 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 88.6/76.3
R426 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 90.8/75.5
R427 7030003620 S.RES ERJ3GEYJ 333 V (33K) T 88.7/74.6
R428 7030003380 S.RES ERJ3GEYJ 331 V (330) T 87.9/70.4
R429 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 85.4/71.8
R430 7030003570 S.RES ERJ3GEYJ 123 V (12K) T 91.6/70.5
R431 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [GEN] T 75.8/64.8
7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [GEN-1]
7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [USA]
7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [USA-1]
7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [AUS]
7030003540 S.RES ERJ3GEYJ 682 V (6.8K) [CHN]
7030003490 S.RES ERJ3GEYJ 272 V (2.7K) [EUR]
7030003490 S.RES ERJ3GEYJ 272 V (2.7K) [EUR-1]
R432 7030003650 S.RES ERJ3GEYJ 563 V (56K) B 6.9/27.9
R433 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 37.6/97.5
R434 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 36.1/102.8
R435 7030000410 S.RES MCR10EZHJ 1.8K (182) T 70.5/68.1
R436 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 89.3/30.5
R437 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 120.6/39.7
R438 7030003400 S.RES ERJ3GEYJ 471 V (470) [USA] T 128.9/53.9
7030003400 S.RES ERJ3GEYJ 471 V (470) [USA-1]
7030003400 S.RES ERJ3GEYJ 471 V (470) [EUR]
7030003400 S.RES ERJ3GEYJ 471 V (470) [EUR-1]
R439 7030003400 S.RES ERJ3GEYJ 471 V (470) [USA] B 116.5/53.9
7030003400 S.RES ERJ3GEYJ 471 V (470) [USA-1]
7030003400 S.RES ERJ3GEYJ 471 V (470) [EUR]
7030003400 S.RES ERJ3GEYJ 471 V (470) [EUR-1]
R440 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 31.3/102.8
R441 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 37.8/107.8
R442 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 6.7/12.3
R443 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 10.3/15.8
R444 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 31.1/93.5
R445 7030003430 S.RES ERJ3GEYJ 821 V (820) B 9.5/83.6
R446 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) B 9.5/79.4
R447 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 128.9/48.1
R448 7030003420 S.RES ERJ3GEYJ 681 V (680) B 117/47.5
R450 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 83.6/50.3
R451 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 80.5/49
R452 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 80/47.1
R453 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 80.6/43.9
R454 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 107.9/17.2
R455 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 107.9/14.4
R456 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 105.1/11
R457 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 107.9/11.6
R458 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 83.5/34.8
R459 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 80.9/39.6
R460 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 81.7/37.5
R461 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 77.2/35.8
R462 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 21.8/112.9
R463 7030003760 S.RES ERJ3GEYJ 474 V (470K) B 21.8/111.5
R464 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 12.3/110.6
R465 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 14.7/100
R466 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 18.2/103.3
Oct. 2008
5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
R467 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 43.6/63.7
R468 7030006120 S.RES ERJ1WYJ4R7U (4.7)0 T 50.3/105.4
R469 7030006120 S.RES ERJ1WYJ4R7U (4.7)0 B 51.3/105.4
R470 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 15.8/23.7
R471 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 10.2/10.5
R472 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 19.7/22.3
R473 7030001160 S.RES MCR50JZHJ 180 (181) T 73.7/101.4
R474 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 72.9/69
R475 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 79.7/30
R476 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 98.1/10
R478 7030003670 S.RES ERJ3GEYJ 823 V (82K) T 106.3/34.1
R479 7510001571 S.THE NTCG16 4LH 104JT T 104.4/34.9
R484 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) B 112.2/19.3
R485 7030003440 S.RES ERJ3GEYJ 102 V (1K) [EUR] B 76.2/23.6
7030003440 S.RES ERJ3GEYJ 102 V (1K) [EUR-1]
R486 7030003420 S.RES ERJ3GEYJ 681 V (680) B 46.7/45.4
R487 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 45.8/39.5
R488 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 47.1/36.2
R489 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 46.7/37.6
R490 7030003610 S.RES ERJ3GEYJ 273 V (27K) B 48.6/44.6
R491 7030003610 S.RES ERJ3GEYJ 273 V (27K) B 47.2/34.4
R492 7030003610 S.RES ERJ3GEYJ 273 V (27K) B 48.5/34.4
R493 7030003320 S.RES ERJ3GEYJ 101 V (100) T 103.8/56.8
R494 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 107/54
R498 7030003280 S.RES ERJ3GEYJ 470 V (47) T 109.1/49.8
R499 7030003320 S.RES ERJ3GEYJ 101 V (100) T 106.3/52.1
R500 7030003320 S.RES ERJ3GEYJ 101 V (100) T 107.6/52.1
R501 7030003240 S.RES ERJ3GEYJ 220 V (22) B 126.3/46.8
W15 7030003860 S.RES ERJ3GE JPW V T 22.1/91.8
W25 7030003860 S.RES ERJ3GE JPW V [GEN] B 114/32.2
7030003860 S.RES ERJ3GE JPW V [GEN-1]
7030003860 S.RES ERJ3GE JPW V [AUS]
7030003860 S.RES ERJ3GE JPW V [CHN]
W28 7030003860 S.RES ERJ3GE JPW V [GEN] B 127.5/20.4
7030003860 S.RES ERJ3GE JPW V [GEN-1]
7030003860 S.RES ERJ3GE JPW V [AUS]
7030003860 S.RES ERJ3GE JPW V [CHN]
W29 7030007150 S.RES MCR50JZHJ JPW (000) [GEN] T 66.4/28.3
7030007150 S.RES MCR50JZHJ JPW (000) [GEN-1]
7030007150 S.RES MCR50JZHJ JPW (000) [USA]
7030007150 S.RES MCR50JZHJ JPW (000) [USA-1]
7030007150 S.RES MCR50JZHJ JPW (000) [AUS]
7030007150 S.RES MCR50JZHJ JPW (000) [CHN]
W32 7030003860 S.RES ERJ3GE JPW V T 86.5/74.4
W33 7030003860 S.RES ERJ3GE JPW V B 6.9/26.5
W34 7030003970 S.RES MCR18EZHJ JPW T 30.5/28.7
W35 7030007150 S.RES MCR50JZHJ JPW (000) B 45.1/52.1
W38 7030000010 S.RES MCR10EZHJ JPW (000) [GEN] B 78.5/22.9
7030000010 S.RES MCR10EZHJ JPW (000) [GEN-1]
7030000010 S.RES MCR10EZHJ JPW (000) [USA]
7030000010 S.RES MCR10EZHJ JPW (000) [USA-1]
7030000010 S.RES MCR10EZHJ JPW (000) [AUS]
7030000010 S.RES MCR10EZHJ JPW (000) [CHN]
W39 7030003970 S.RES MCR18EZHJ JPW T 108.1/43.7
W40 7030003970 S.RES MCR18EZHJ JPW T 115.7/51.3
W41 7030003860 S.RES ERJ3GE JPW V T 111/57.8
W42 7030003860 S.RES ERJ3GE JPW V T 116.8/41
W43 7030003860 S.RES ERJ3GE JPW V B 26.7/37.9
W44 7030003860 S.RES ERJ3GE JPW V T 23.4/31.4
W47 7030000010 S.RES MCR10EZHJ JPW (000) B 81.9/27.4
W48 7030003970 S.RES MCR18EZHJ JPW B 92.9/31.2
W49 7030007150 S.RES MCR50JZHJ JPW (000) [GEN] B 67.7/30.4
7030007150 S.RES MCR50JZHJ JPW (000) [GEN-1]
7030007150 S.RES MCR50JZHJ JPW (000) [USA]
7030007150 S.RES MCR50JZHJ JPW (000) [USA-1]
7030007150 S.RES MCR50JZHJ JPW (000) [AUS]
7030007150 S.RES MCR50JZHJ JPW (000) [CHN]
W51 7030003860 S.RES ERJ3GE JPW V T 104.4/43.6
W52 7030003970 S.RES MCR18EZHJ JPW [EUR] only T 32.7/28.7
W53 7030003970 S.RES MCR18EZHJ JPW [EUR] only T 34.9/28.7
W54 7030003970 S.RES MCR18EZHJ JPW [EUR] only T 37.1/28.7
C1 4030011210 S.CER GRM31M2C2H330JV01L
(GRM42-6 CH) B 116.4/103.5
C2 4030011070 S.CER GRM31M2C2H5R0CY21L
(GRM42-6 CH) B 122.2/99.4
C3 4030011230 S.CER GRM31M2C2H390JV01L
(GRM42-6 CH) B 113.2/95
C4 4030011030 S.CER GRM31M4C2H1R5CY21L
(GRM42-6 CK) B 120.7/94.1
C5 4030011180 S.CER GRM31M2C2H220JV01L
(GRM42-6 CH) B 117.5/90.6
C6 4030017200 S.CER GRM31BR32J102KY01L
(GHM1030 R) B 117.5/87.1
C7 4030011180 S.CER GRM31M2C2H220JV01L
(GRM42-6 CH) B 113.7/78.6
C8 4030007080 S.CER C1608 CH 1H 390J-T B 118.2/83.3
C9 4030007040 S.CER C1608 CH 1H 180J-T B 118.4/77.3
C10 4030007090 S.CER C1608 CH 1H 470J-T T 131.7/77.8
C11 4030017200 S.CER GRM31BR32J102KY01L
(GHM1030 R) T 97.7/90.7
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
C12 4030011180 S.CER GRM31M2C2H220JV01L
(GRM42-6 CH) B 97.7/102.6
C13 4030011020 S.CER GRM31M4C2H1R0CY21L
(GRM42-6 CK) B 96.1/96.1
C14 4030011020 S.CER GRM31M4C2H1R0CY21L
(GRM42-6 CK) B 88.5/100.6
C15 4030011180 S.CER GRM31M2C2H220JV01L
(GRM42-6 CH) B 93.3/104.9
C16 4030011120 S.CER GRM31M2C2H100JV01L
(GRM42-6 CH) B 96.1/93.4
C17 4030011120 S.CER GRM31M2C2H100JV01L
(GRM42-6 CH) B 87.1/93.2
C18 4030006860 S.CER C1608 JB 1H 102K-T B 90.6/87.3
C19 4030006860 S.CER C1608 JB 1H 102K-T B 94.2/86.6
C20 4030017200 S.CER GRM31BR32J102KY01L
(GHM1030 R) B 90.8/100.6
C22 4030007050 S.CER C1608 CH 1H 220J-T B 131.7/64.8
C23 4030009560 S.CER C1608 CH 1H R75B-T B 130.9/66.9
C24 4030006860 S.CER C1608 JB 1H 102K-T B 124.8/65.7
C25 4030006860 S.CER C1608 JB 1H 102K-T B 116.9/62.1
C26 4030006860 S.CER C1608 JB 1H 102K-T B 121.8/65.7
C27 4030006860 S.CER C1608 JB 1H 102K-T B 119.4/68.6
C28 4030006860 S.CER C1608 JB 1H 102K-T T 113.2/59.5
C29 4030007060 S.CER C1608 CH 1H 270J-T B 108.9/65
C30 4030006860 S.CER C1608 JB 1H 102K-T B 105.6/62.1
C31 4030009500 S.CER C1608 CH 1H 0R5B-T B 112.3/65
C32 4030007060 S.CER C1608 CH 1H 270J-T B 105.6/65.6
C33 4030009920 S.CER C1608 CH 1H 050B-T T 103.8/59.5
C34 4030006860 S.CER C1608 JB 1H 102K-T B 105/52.9
C37 4030006860 S.CER C1608 JB 1H 102K-T B 103.8/60.9
C39 4030006900 S.CER C1608 JB 1H 103K-T B 124.3/40.5
C40 4030006860 S.CER C1608 JB 1H 102K-T B 120.2/43.6
C41 4030006900 S.CER C1608 JB 1H 103K-T B 123.4/41.9
C42 4030006900 S.CER C1608 JB 1H 103K-T B 120.7/34.8
C43 4030006860 S.CER C1608 JB 1H 102K-T T 122.5/33.3
C44 4030011600 S.CER C1608 JB 1E 104K-T B 108.2/40.2
C46 4030006900 S.CER C1608 JB 1H 103K-T B 131.2/18.4
C47 4030011600 S.CER C1608 JB 1E 104K-T B 131.2/12.3
C48 4030011600 S.CER C1608 JB 1E 104K-T B 125.8/10.4
C50 4030011600 S.CER C1608 JB 1E 104K-T B 119.4/12.4
C51 4030006900 S.CER C1608 JB 1H 103K-T B 115.7/10.9
C52 4030011600 S.CER C1608 JB 1E 104K-T B 115.7/3
C53 4030006900 S.CER C1608 JB 1H 103K-T B 112.3/10.2
C54 4030006900 S.CER C1608 JB 1H 103K-T B 114.9/19.3
C55 4030006900 S.CER C1608 JB 1H 103K-T B 110.6/19.3
C56 4550007390 S.TAN F931C225MAABMA T 121.1/15.3
C58 4510008550 S.ELE EEE1HA010SR T 115.2/23.3
C59 4550000530 S.TAN TEESVA 1V 104M8R T 70.4/41.8
C60 4550007670 S.TAN F931C105MAABMA [GEN] B 77/27.1
4550007670 S.TAN F931C105MAABMA [GEN-1]
4550007670 S.TAN F931C105MAABMA [USA]
4550007670 S.TAN F931C105MAABMA [USA-1]
4550007670 S.TAN F931C105MAABMA [AUS]
4550007670 S.TAN F931C105MAABMA [CHN]
4550007610 S.TAN F931E474MAABMA [EUR]
4550007610 S.TAN F931E474MAABMA [EUR-1]
C61 4030006860 S.CER C1608 JB 1H 102K-T B 77.4/56.6
C62 4030006860 S.CER C1608 JB 1H 102K-T T 85.1/1.7
C63 4030006860 S.CER C1608 JB 1H 102K-T B 81.9/24.2
C68 4030006860 S.CER C1608 JB 1H 102K-T B 99.5/36.6
C69 4030006860 S.CER C1608 JB 1H 102K-T B 96.3/31.5
C70 4030006860 S.CER C1608 JB 1H 102K-T B 96.3/30
C71 4030006860 S.CER C1608 JB 1H 102K-T B 99.6/29.5
C72 4030009990 S.CER C1608 CH 1H 200J-T B 93.4/38.1
C73 4030006860 S.CER C1608 JB 1H 102K-T B 93.4/44.1
C74 4030007040 S.CER C1608 CH 1H 180J-T B 99.5/39.6
C75 4030006860 S.CER C1608 JB 1H 102K-T T 87.9/37.2
C77 4030006860 S.CER C1608 JB 1H 102K-T B 96.3/45.5
C78 4030009990 S.CER C1608 CH 1H 200J-T B 99.5/50.1
C82 4030006860 S.CER C1608 JB 1H 102K-T B 94.7/58.3
C85 4030006860 S.CER C1608 JB 1H 102K-T B 93.1/62.1
C87 4030007030 S.CER C1608 CH 1H 150J-T B 88/58.2
C91 4030006860 S.CER C1608 JB 1H 102K-T B 87.2/60.5
C92 4030006860 S.CER C1608 JB 1H 102K-T B 88.9/62.4
C95 4030007060 S.CER C1608 CH 1H 270J-T B 86.4/58.2
C96 4030006860 S.CER C1608 JB 1H 102K-T B 87.2/66.6
C97 4030006860 S.CER C1608 JB 1H 102K-T B 80.2/59.8
C98 4030007030 S.CER C1608 CH 1H 150J-T T 81.1/68.2
C99 4030006860 S.CER C1608 JB 1H 102K-T T 75.8/66.1
C100 4030006860 S.CER C1608 JB 1H 102K-T T 53.7/71.3
C101 4030007070 S.CER C1608 CH 1H 330J-T T 79.6/69.8
C102 4030007050 S.CER C1608 CH 1H 220J-T T 63/74.6
C103 4030007100 S.CER C1608 CH 1H 560J-T T 54.4/80.6
C110 4030012600 S.CER C2012 JB 1A 105M-T B 106.4/11.9
C112 4550006220 S.TAN TEESVA 0J 156M8R B 109.4/26.5
C113 4510008540 S.ELE EEE1CA100SR T 101.3/21.9
C114 4550007610 S.TAN F931E474MAABMA B 96.3/21.4
C115 4030006860 S.CER C1608 JB 1H 102K-T B 96.3/26.7
C116 4030006900 S.CER C1608 JB 1H 103K-T T 107.9/26
C117 4030009970 S.CER C1608 JB 1H 182K-T T 113.4/11.9
C118 4030009630 S.CER C1608 JB 1H 822K-T T 110.6/8.5
C119 4030007130 S.CER C1608 CH 1H 101J-T T 108.5/5.7
C120 4030012610 S.CER C2012 JB 1C 474K-T B 6.8/21.4
C121 4030006900 S.CER C1608 JB 1H 103K-T T 103.5/5.7
C122 4030006860 S.CER C1608 JB 1H 102K-T T 98/38.7
C123 4550006220 S.TAN TEESVA 0J 156M8R T 100.6/39.8
C124 4030006860 S.CER C1608 JB 1H 102K-T T 101.4/44.7
Oct. 2008
6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
C126 4030011600 S.CER C1608 JB 1E 104K-T B 51.2/37
C127 4030006900 S.CER C1608 JB 1H 103K-T B 56.5/44.8
C128 4030011600 S.CER C1608 JB 1E 104K-T B 42.3/66.8
C129 4510007980 S.ELE 16SVP22M-AIC T 80.4/16.5
C130 4030006860 S.CER C1608 JB 1H 102K-T T 83.8/1.7
C131 4030006860 S.CER C1608 JB 1H 102K-T B 72.8/18.6
C132 4550007360 S.TAN F931A226MBABMA T 73.4/15.3
C133 4550007610 S.TAN F931E474MAABMA T 65.3/15.6
C134 4550007360 S.TAN F931A226MBABMA T 60.5/20
C135 4030006860 S.CER C1608 JB 1H 102K-T T 61.3/16.3
C138 4510008540 S.ELE EEE1CA100SR T 98.7/76.7
C139 4030006860 S.CER C1608 JB 1H 102K-T B 85.4/85
C140 4030006860 S.CER C1608 JB 1H 102K-T B 86.8/81.9
C141 4030006860 S.CER C1608 JB 1H 102K-T T 82.3/73.6
C148 4030006860 S.CER C1608 JB 1H 102K-T B 108.8/77.3
C153 4030012600 S.CER C2012 JB 1A 105M-T T 59.9/34.2
C154 4030007050 S.CER C1608 CH 1H 220J-T B 125.8/15.6
C156 4030011600 S.CER C1608 JB 1E 104K-T B 111.2/44.3
C164 4030006860 S.CER C1608 JB 1H 102K-T T 131.7/76.5
C165 4030011770 S.CER C1608 CH 1H 060B-T T 130.9/73.8
C167 4030006860 S.CER C1608 JB 1H 102K-T B 72.4/59.7
C168 4510008750 S.ELE EEE1HA0R1SR T 74.9/57.3
C170 4030012600 S.CER C2012 JB 1A 105M-T T 105.3/45.8
C175 4550007260 S.TAN F931C475MAABMA B 115.4/66.4
C177 4550007270 S.TAN F931A475MAABMA B 57.2/39.9
C188 4030007070 S.CER C1608 CH 1H 330J-T T 90.7/37.2
C189 4030006860 S.CER C1608 JB 1H 102K-T T 87.9/42.7
C190 4030009500 S.CER C1608 CH 1H 0R5B-T T 87/46.5
C192 4030007010 S.CER C1608 CH 1H 100D-T [GEN] T 80.6/45.2
4030007010 S.CER C1608 CH 1H 100D-T [GEN-1]
4030007010 S.CER C1608 CH 1H 100D-T [USA]
4030007010 S.CER C1608 CH 1H 100D-T [USA-1]
4030007010 S.CER C1608 CH 1H 100D-T [AUS]
4030007010 S.CER C1608 CH 1H 100D-T [CHN]
4030007030 S.CER C1608 CH 1H 150J-T [EUR]
4030007030 S.CER C1608 CH 1H 150J-T [EUR-1]
C193 4030006860 S.CER C1608 JB 1H 102K-T T 87.7/48.8
C195 4030007050 S.CER C1608 CH 1H 220J-T [GEN] T 78.3/48.4
4030007050 S.CER C1608 CH 1H 220J-T [GEN-1]
4030007050 S.CER C1608 CH 1H 220J-T [USA]
4030007050 S.CER C1608 CH 1H 220J-T [USA-1]
4030007050 S.CER C1608 CH 1H 220J-T [AUS]
4030007050 S.CER C1608 CH 1H 220J-T [CHN]
4030009990 S.CER C1608 CH 1H 200J-T [EUR]
4030009990 S.CER C1608 CH 1H 200J-T [EUR-1]
C206 4510008510 S.ELE EEE1CA471P T 10.3/98.5
C208 4030007130 S.CER C1608 CH 1H 101J-T B 8.9/71.1
C209 4030012610 S.CER C2012 JB 1C 474K-T B 8.3/68.7
C211 4510007320 ELE 50 YXG 470M
C212 4510007320 ELE 50 YXG 470M
C213 4030006860 S.CER C1608 JB 1H 102K-T B 82.4/29.3
C214 4030006860 S.CER C1608 JB 1H 102K-T T 99.4/32.2
C217 4030007080 S.CER C1608 CH 1H 390J-T T 48.5/86.4
C218 4030006860 S.CER C1608 JB 1H 102K-T B 45.7/104.9
C220 4030006860 S.CER C1608 JB 1H 102K-T T 74.3/78.6
C224 4030011600 S.CER C1608 JB 1E 104K-T B 122.5/33.4
C226 4550005980 S.TAN TEESVA 1A 475M8R T 96.8/33.4
C228 4030006900 S.CER C1608 JB 1H 103K-T B 121.1/31.9
C229 4030006900 S.CER C1608 JB 1H 103K-T B 55.7/24
C230 4030006900 S.CER C1608 JB 1H 103K-T B 123.5/19.3
C231 4030006860 S.CER C1608 JB 1H 102K-T B 35.2/52.1
C232 4030010210 S.CER C3216 JB 1C 105M-T B 37/51.7
C233 4030012600 S.CER C2012 JB 1A 105M-T B 112.2/4.2
C234 4030012600 S.CER C2012 JB 1A 105M-T B 116.1/12.7
C235 4030006900 S.CER C1608 JB 1H 103K-T B 126.2/8.3
C241 4030011190 S.CER GRM31M2C2H270JV01L
(GRM42-6 CH) B 82.9/104
C242 4030018330 S.CER ERF22X 6C2H 820J D01L B 76.8/102
C249 4030006860 S.CER C1608 JB 1H 102K-T B 45.3/100.6
C250 4030006860 S.CER C1608 JB 1H 102K-T T 73.3/66.7
C251 4030006860 S.CER C1608 JB 1H 102K-T B 91.6/67.7
C253 4030006860 S.CER C1608 JB 1H 102K-T B 103.1/78.6
C255 4030006860 S.CER C1608 JB 1H 102K-T B 114.4/47.7
C256 4030008880 S.CER C1608 JB 1H 223K-T B 65.8/24.9
C257 4030009970 S.CER C1608 JB 1H 182K-T B 60.4/23.6
C258 4030006900 S.CER C1608 JB 1H 103K-T B 68.7/23.6
C259 4030008860 S.CER C1608 JB 1H 153K-T B 63.8/28.6
C260 4030006860 S.CER C1608 JB 1H 102K-T B 65.1/30
C261 4030008880 S.CER C1608 JB 1H 223K-T B 61.3/34.8
C262 4030011340 S.CER C1608 CH 1H 471J-T B 58.3/33.4
C263 4030012660 S.CER C1608 JB 1E 683K-T B 55.2/29.6
C264 4030007120 S.CER C1608 CH 1H 820J-T B 55.4/26.7
C265 4030011600 S.CER C1608 JB 1E 104K-T B 54.7/34
C266 4030011600 S.CER C1608 JB 1E 104K-T T 113.2/18.1
C267 4030011600 S.CER C1608 JB 1E 104K-T T 111.9/54.7
C268 4030011600 S.CER C1608 JB 1E 104K-T T 53.4/19.1
C277 4030006860 S.CER C1608 JB 1H 102K-T T 101.4/46.2
C279 4030007000 S.CER C1608 CH 1H 090D-T T 83.8/36.7
C286 4030009500 S.CER C1608 CH 1H 0R5B-T T 85.3/39.2
C288 4030006860 S.CER C1608 JB 1H 102K-T T 87.9/40
C289 4030011600 S.CER C1608 JB 1E 104K-T B 71.6/27.9
C290 4030011600 S.CER C1608 JB 1E 104K-T B 64.5/46.7
C292 4030008920 S.CER C1608 JB 1H 473K-T B 49.7/61
C293 4030010760 S.CER C1608 CH 1H 331J-T B 50.6/54.5
C295 4030006860 S.CER C1608 JB 1H 102K-T T 6.5/45.5
C298 4510008740 S.ELE EEE1HA330P T 26.1/49.2
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
C299 4030006890 S.CER C1608 JF 1H 103Z-T B 25.3/46.6
C300 4030011600 S.CER C1608 JB 1E 104K-T B 28.8/46
C301 4510008580 S.ELE EEE0JA470SR T 18.8/49.4
C308 4030006900 S.CER C1608 JB 1H 103K-T B 91/12.4
C309 4030011600 S.CER C1608 JB 1E 104K-T B 103.9/7.9
C312 4030006860 S.CER C1608 JB 1H 102K-T B 28.1/83.8
C313 4030011600 S.CER C1608 JB 1E 104K-T B 21.2/71.8
C314 4030011600 S.CER C1608 JB 1E 104K-T B 22.6/71.8
C315 4030006900 S.CER C1608 JB 1H 103K-T B 104.5/45.6
C316 4030011180 S.CER GRM31M2C2H220JV01L
(GRM42-6 CH) B 89.2/96.8
C317 4030006900 S.CER C1608 JB 1H 103K-T T 75.9/8
C318 4030006900 S.CER C1608 JB 1H 103K-T B 123.1/46.8
C319 4030006900 S.CER C1608 JB 1H 103K-T [USA] B 120.7/52.9
4030006900 S.CER C1608 JB 1H 103K-T [USA-1]
4030006900 S.CER C1608 JB 1H 103K-T [EUR]
4030006900 S.CER C1608 JB 1H 103K-T [EUR-1]
C320 4030006900 S.CER C1608 JB 1H 103K-T T 112.5/47.2
C321 4030006860 S.CER C1608 JB 1H 102K-T T 69.8/16.8
C322 4510008690 S.ELE EEE1EA330SP T 66.4/20.9
C323 4030006860 S.CER C1608 JB 1H 102K-T B 78.7/31.4
C324 4030006860 S.CER C1608 JB 1H 102K-T B 93.4/35.1
C325 4030011600 S.CER C1608 JB 1E 104K-T T 57.7/33
C326 4550007390 S.TAN F931C225MAABMA B 91.4/10.7
C327 4030006900 S.CER C1608 JB 1H 103K-T B 128.3/9.6
C328 4030006900 S.CER C1608 JB 1H 103K-T B 123.2/9.6
C329 4030006900 S.CER C1608 JB 1H 103K-T B 114.1/62.1
C330 4030011110 S.CER GRM31M2C2H9R0DV01L
(GRM42-6 CH) B 123.8/105.8
C331 4030011160 S.CER GRM31M2C2H150JV01L
(GRM42-6 CH) B 119.2/109.5
C332 4030006900 S.CER C1608 JB 1H 103K-T [USA] T 128.9/52.3
4030006900 S.CER C1608 JB 1H 103K-T [USA-1]
4030006900 S.CER C1608 JB 1H 103K-T [EUR]
4030006900 S.CER C1608 JB 1H 103K-T [EUR-1]
C333 4030006900 S.CER C1608 JB 1H 103K-T T 128.9/49.5
C337 4030011600 S.CER C1608 JB 1E 104K-T B 28.8/67.4
C338 4030011600 S.CER C1608 JB 1E 104K-T B 33.9/62.6
C339 4030008470 S.CER C1608 JB 1H 272K-T B 68.7/24.9
C340 4030011600 S.CER C1608 JB 1E 104K-T B 63.2/36.1
C341 4030006900 S.CER C1608 JB 1H 103K-T B 100.5/3.9
C342 4030006860 S.CER C1608 JB 1H 102K-T T 131.7/68.9
C343 4510008500 S.ELE EEE1CA101WP T 41.6/72.7
C344 4030009500 S.CER C1608 CH 1H 0R5B-T T 126.4/47.5
C346 4030006960 S.CER C1608 CH 1H 050C-T [USA] T 114.9/56.4
4030006960 S.CER C1608 CH 1H 050C-T [USA-1]
4030006960 S.CER C1608 CH 1H 050C-T [EUR]
4030006960 S.CER C1608 CH 1H 050C-T [EUR-1]
C347 4030011600 S.CER C1608 JB 1E 104K-T B 71.6/14.3
C348 4030006900 S.CER C1608 JB 1H 103K-T B 61/52.6
C349 4030008650 S.CER C1608 JB 1H 332K-T B 48.5/31.8
C353 4030011600 S.CER C1608 JB 1E 104K-T B 27/69.9
C354 4030011600 S.CER C1608 JB 1E 104K-T B 44.4/60.6
C358 4030006990 S.CER C1608 CH 1H 080D-T B 124.9/62.2
C359 4030007050 S.CER C1608 CH 1H 220J-T B 130.1/64.8
C360 4030006860 S.CER C1608 JB 1H 102K-T B 133.5/62.2
C361 4030006950 S.CER C1608 CH 1H 040C-T [USA] T 126.4/54.7
4030006950 S.CER C1608 CH 1H 040C-T [USA-1]
4030006950 S.CER C1608 CH 1H 040C-T [EUR]
4030006950 S.CER C1608 CH 1H 040C-T [EUR-1]
C362 4030006860 S.CER C1608 JB 1H 102K-T B 122.6/74.5
C366 4030006860 S.CER C1608 JB 1H 102K-T T 127.6/80.3
C374 4030006860 S.CER C1608 JB 1H 102K-T B 41.6/72.8
C378 4030006870 S.CER C1608 JB 1H 222K-T B 27/72.6
C379 4550007270 S.TAN F931A475MAABMA B 32.5/73.5
C380 4550007670 S.TAN F931C105MAABMA B 30.8/78.2
C381 4030011600 S.CER C1608 JB 1E 104K-T B 41.5/77.3
C382 4030006900 S.CER C1608 JB 1H 103K-T B 14.9/84.3
C383 4550006390 S.TAN TEESVA 1C 335M8R B 13.9/90.5
C384 4030011600 S.CER C1608 JB 1E 104K-T B 21.6/78.8
C385 4030008900 S.CER C1608 JB 1H 333K-T B 51.4/28.9
C387 4510008510 S.ELE EEE1CA471P T 23.3/73.2
C388 4510008680 S.ELE EEE1EA220SP T 14.5/89.3
C389 4030006860 S.CER C1608 JB 1H 102K-T T 1.8/94.8
C390 4030011600 S.CER C1608 JB 1E 104K-T B 109.1/38.2
C391 4030009500 S.CER C1608 CH 1H 0R5B-T T 89.9/46.5
C392 4030007020 S.CER C1608 CH 1H 120J-T [USA] T 122.1/59.7
4030007020 S.CER C1608 CH 1H 120J-T [USA-1]
4030007020 S.CER C1608 CH 1H 120J-T [EUR]
4030007020 S.CER C1608 CH 1H 120J-T [EUR-1]
C395 4030006950 S.CER C1608 CH 1H 040C-T T 122/43.6
C403 4030012600 S.CER C2012 JB 1A 105M-T B 96.3/9.3
C404 4030012610 S.CER C2012 JB 1C 474K-T B 31.1/88.7
C405 4030009520 S.CER C1608 CH 1H 020B-T B 131.7/68.2
C406 4030006960 S.CER C1608 CH 1H 050C-T B 128.3/68.2
C407 4030009910 S.CER C1608 CH 1H 040B-T B 111.5/67.4
C409 4030006860 S.CER C1608 JB 1H 102K-T B 93.4/46.9
C410 4030006860 S.CER C1608 JB 1H 102K-T B 94.2/85
C413 4550007540 S.TAN F931C155MAABMA B 47.6/107.6
C415 4030007060 S.CER C1608 CH 1H 270J-T B 101.7/53.9
C416 4030007030 S.CER C1608 CH 1H 150J-T B 103.2/53.9
C417 4030006860 S.CER C1608 JB 1H 102K-T B 76.2/53.8
C418 4030006860 S.CER C1608 JB 1H 102K-T T 55.2/82.5
C419 4030017200 S.CER GRM31BR32J102KY01L
(GHM1030 R) B 75.8/81.9
C420 4030006900 S.CER C1608 JB 1H 103K-T T 55.9/23.7
C421 4030007050 S.CER C1608 CH 1H 220J-T T 112.7/39.4
Oct. 2008
7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
C422 4030007070 S.CER C1608 CH 1H 330J-T T 110/39.4
C423 4030006970 S.CER C1608 CH 1H 060D-T T 110.8/37.2
C424 4030007100 S.CER C1608 CH 1H 560J-T T 113.5/34.1
C425 4030006900 S.CER C1608 JB 1H 103K-T T 113.5/32.8
C426 4030009990 S.CER C1608 CH 1H 200J-T T 109.4/31.5
C427 4030007080 S.CER C1608 CH 1H 390J-T T 108.4/28.7
C428 4030006900 S.CER C1608 JB 1H 103K-T T 107.1/28.7
C429 4030009550 S.CER C1608 CH 1H 2R5B-T B 82.1/31.8
C430 4030006900 S.CER C1608 JB 1H 103K-T T 115.3/29.6
C433 4510009280 S.ELE EEE1EA4R7SR T 129.4/15.4
C434 4030006960 S.CER C1608 CH 1H 050C-T B 118.5/47.5
C436 4510008540 S.ELE EEE1CA100SR T 30.3/37.6
C437 4510008540 S.ELE EEE1CA100SR T 11.1/33.8
C438 4030006900 S.CER C1608 JB 1H 103K-T T 12.8/36.9
C439 4030007170 S.CER C1608 CH 1H 221J-T B 15.5/41.2
C441 4510008500 S.ELE EEE1CA101WP T 12.4/50.8
C442 4030006900 S.CER C1608 JB 1H 103K-T T 16.7/53.8
C443 4030011600 S.CER C1608 JB 1E 104K-T B 3/13.6
C444 4030006900 S.CER C1608 JB 1H 103K-T T 16.6/25.2
C445 4510008500 S.ELE EEE1CA101WP T 21.4/27.2
C446 4030010760 S.CER C1608 CH 1H 331J-T T 5.8/18.8
C447 4030012600 S.CER C2012 JB 1A 105M-T T 8.8/18.7
C448 4510008500 S.ELE EEE1CA101WP T 10.7/43
C449 4030006900 S.CER C1608 JB 1H 103K-T T 12.9/38.8
C450 4030010040 S.CER C1608 JB 1H 561K-T [GEN] B 21/21
4030010040 S.CER C1608 JB 1H 561K-T [GEN-1]
4030010040 S.CER C1608 JB 1H 561K-T [USA]
4030010040 S.CER C1608 JB 1H 561K-T [USA-1]
4030010040 S.CER C1608 JB 1H 561K-T [AUS]
4030010040 S.CER C1608 JB 1H 561K-T [CHN]
4030007120 S.CER C1608 CH 1H 820J-T [EUR]
4030007120 S.CER C1608 CH 1H 820J-T [EUR-1]
C452 4510007230 ELE 50 YXG 1000M
C453 4510009060 S.ELE EEE1HA3R3SR T 31.2/17.5
C454 4550003210 S.TAN TEESVD21D226M12R T 22.2/9.2
C455 4030006900 S.CER C1608 JB 1H 103K-T T 17.2/10.2
C456 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2 R) B 48.8/6.8
C457 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2 R) B 48.8/3.7
C458 4030006860 S.CER C1608 JB 1H 102K-T B 44.3/7.9
C459 4030006860 S.CER C1608 JB 1H 102K-T B 40.9/7.9
C460 4030006860 S.CER C1608 JB 1H 102K-T B 44.3/5
C461 4030006860 S.CER C1608 JB 1H 102K-T B 41.2/5
C462 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2 R) B 54/9.9
C463 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2 R) B 55.7/6.8
C468 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2 R) B 57.2/13.5
C472 4030006860 S.CER C1608 JB 1H 102K-T B 97.9/56.7
C500 4030009650 S.CER C1608 CH 1H 240J-T T 53.6/82.5
C501 4030007050 S.CER C1608 CH 1H 220J-T T 48.5/84.8
C502 4030007110 S.CER C1608 CH 1H 680J-T T 48.5/92.8
C503 4030006980 S.CER C1608 CH 1H 070D-T T 48.5/91.2
C504 4030007150 S.CER C1608 CH 1H 151J-T T 49.7/96.4
C505 4510007320 ELE 50 YXG 470M
C506 4510009130 S.ELE EEEHB0J330R T 80.9/25.2
C507 4030008960 S.CER C2012 JB 1C 104K-T B 9.3/29
C508 4030010020 S.CER C1608 JB 1H 122K-T B 125.8/14.3
C509 4030010020 S.CER C1608 JB 1H 122K-T B 112.3/8.7
C512 4030006860 S.CER C1608 JB 1H 102K-T B 86.6/74.7
C513 4510008540 S.ELE EEE1CA100SR T 90.4/78.6
C514 4030006860 S.CER C1608 JB 1H 102K-T T 91.4/74.6
C515 4030006860 S.CER C1608 JB 1H 102K-T T 82.3/71.8
C516 4030011600 S.CER C1608 JB 1E 104K-T T 93.8/72.6
C517 4030006860 S.CER C1608 JB 1H 102K-T T 91.6/69
C518 4030016990 S.CER GRM32RR11H105KA01L
(GRM42-2 R) B 33.9/107.2
C519 4030017190 S.CER GRM31AR32J471KW01D T 67/65.9
C520 4030011280 S.CER C1608 CH 1H 271J-T T 52.9/100.4
C521 4510009280 S.ELE EEE1EA4R7SR [GEN] T 79.5/64.3
4510009280 S.ELE EEE1EA4R7SR [GEN-1]
4510009280 S.ELE EEE1EA4R7SR [USA]
4510009280 S.ELE EEE1EA4R7SR [USA-1]
4510009280 S.ELE EEE1EA4R7SR [AUS]
4510009280 S.ELE EEE1EA4R7SR [CHN]
4510008530 S.ELE EEE1HA2R2SR [EUR]
4510009280 S.ELE EEE1EA4R7SR [EUR-1]
C522 4030007050 S.CER C1608 CH 1H 220J-T B 56.8/26.7
C523 4030006870 S.CER C1608 JB 1H 222K-T T 26.9/26.5
C524 4030008550 S.CER C2012 JF 1H 473Z-T B 24.7/18
C525 4030006860 S.CER C1608 JB 1H 102K-T T 10.4/20.3
C529 4030008920 S.CER C1608 JB 1H 473K-T B 8.7/81.5
C530 4030008770 S.CER C1608 JB 1H 562K-T B 8.7/77.3
C531 4510007390 ELE 50 YK 220M
C533 4030009520 S.CER C1608 CH 1H 020B-T B 107.6/68.1
C535 4510005520 ELE 50 ME 330 HC
C536 4030011600 S.CER C1608 JB 1E 104K-T B 11.6/23.2
C537 4030006860 S.CER C1608 JB 1H 102K-T T 76.4/44.9
C538 4030007140 S.CER C1608 CH 1H 121J-T [GEN] T 78.9/50.3
4030007140 S.CER C1608 CH 1H 121J-T [GEN-1]
4030007140 S.CER C1608 CH 1H 121J-T [USA]
4030007140 S.CER C1608 CH 1H 121J-T [USA-1]
4030007140 S.CER C1608 CH 1H 121J-T [AUS]
4030007140 S.CER C1608 CH 1H 121J-T [CHN]
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
C538 4030009650 S.CER C1608 CH 1H 240J-T [EUR]
4030009650 S.CER C1608 CH 1H 240J-T [EUR-1]
C539 4030007010 S.CER C1608 CH 1H 100D-T [GEN] T 81.3/47.1
4030007010 S.CER C1608 CH 1H 100D-T [GEN-1]
4030007010 S.CER C1608 CH 1H 100D-T [USA]
4030007010 S.CER C1608 CH 1H 100D-T [USA-1]
4030007010 S.CER C1608 CH 1H 100D-T [AUS]
4030007010 S.CER C1608 CH 1H 100D-T [CHN]
4030007030 S.CER C1608 CH 1H 150J-T [EUR]
4030007030 S.CER C1608 CH 1H 150J-T [EUR-1]
C540 4030006860 S.CER C1608 JB 1H 102K-T T 85.1/46.5
C541 4030011600 S.CER C1608 JB 1E 104K-T T 107.9/18.5
C542 4030011600 S.CER C1608 JB 1E 104K-T T 107.9/15.9
C543 4030011600 S.CER C1608 JB 1E 104K-T T 107.9/12.9
C544 4030007150 S.CER C1608 CH 1H 151J-T T 74.3/40.7
C545 4030007020 S.CER C1608 CH 1H 120J-T T 79.3/39.5
C546 4030007000 S.CER C1608 CH 1H 090D-T T 81.7/36.2
C547 4030009650 S.CER C1608 CH 1H 240J-T T 79.3/36.6
C548 4030006860 S.CER C1608 JB 1H 102K-T T 80.7/41.5
C549 4030016990 S.CER GRM32RR11H105KA01L
(GRM42-2 R) B 16.5/106.7
C550 4030006860 S.CER C1608 JB 1H 102K-T T 14.4/113.5
C551 4030007090 S.CER C1608 CH 1H 470J-T T 15.9/113.5
C552 4030007030 S.CER C1608 CH 1H 150J-T T 105.1/59.5
C553 4550007260 S.TAN F931C475MAABMA B 14.1/22.4
C554 4030017190 S.CER GRM31AR32J471KW01D T 59.2/112.1
C555 4030009650 S.CER C1608 CH 1H 240J-T B 95.1/49.5
C556 4030009650 S.CER C1608 CH 1H 240J-T B 96.4/51.4
C557 4030004750 S.CER C2012 JB 1H 103K-T B 33.7/58.5
C558 4030006860 S.CER C1608 JB 1H 102K-T B 93.5/26.4
C559 4030007070 S.CER C1608 CH 1H 330J-T [EUR] B 33.6/60.1
4030007070 S.CER C1608 CH 1H 330J-T [EUR-1]
C560 4030006850 S.CER C1608 JB 1H 471K-T [EUR] B 27.3/57.9
4030006850 S.CER C1608 JB 1H 471K-T [EUR-1]
C561 4030006860 S.CER C1608 JB 1H 102K-T [EUR] B 26/57.9
4030006860 S.CER C1608 JB 1H 102K-T [EUR-1]
C562 4030007070 S.CER C1608 CH 1H 330J-T [EUR] B 41.2/100.8
4030007070 S.CER C1608 CH 1H 330J-T [EUR-1]
C563 4030006850 S.CER C1608 JB 1H 471K-T [EUR] B 42.2/99.8
4030006850 S.CER C1608 JB 1H 471K-T [EUR-1]
C564 4030006860 S.CER C1608 JB 1H 102K-T [EUR] B 43.2/98.8
4030006860 S.CER C1608 JB 1H 102K-T [EUR-1]
C565 4030007070 S.CER C1608 CH 1H 330J-T [EUR] B 56.4/82.9
4030007070 S.CER C1608 CH 1H 330J-T [EUR-1]
C566 4030006850 S.CER C1608 JB 1H 471K-T [EUR] B 57.8/82.9
4030006850 S.CER C1608 JB 1H 471K-T [EUR-1]
C567 4030006860 S.CER C1608 JB 1H 102K-T [EUR] B 59.2/82.9
4030006860 S.CER C1608 JB 1H 102K-T [EUR-1]
C568 4030006850 S.CER C1608 JB 1H 471K-T [EUR] B 72/82.9
4030006850 S.CER C1608 JB 1H 471K-T [EUR-1]
C569 4030004720 S.CER C2012 JB 1H 102K-T [EUR] B 40.2/97.2
4030004720 S.CER C2012 JB 1H 102K-T [EUR-1]
C570 4030004710 S.CER C2012 JB 1H 471K-T [EUR] B 41.5/95.9
4030004710 S.CER C2012 JB 1H 471K-T [EUR-1]
C571 4030005030 S.CER C2012 CH 1H 221J-T [EUR] B 42.8/94.6
4030005030 S.CER C2012 CH 1H 221J-T [EUR-1]
C572 4030007170 S.CER C1608 CH 1H 221J-T [EUR] T 71.6/77.2
4030007170 S.CER C1608 CH 1H 221J-T [EUR-1]
C573 4030007130 S.CER C1608 CH 1H 101J-T [EUR] T 71.6/78.6
4030007130 S.CER C1608 CH 1H 101J-T [EUR-1]
C574 4030007090 S.CER C1608 CH 1H 470J-T [EUR] T 74.3/77.2
4030007090 S.CER C1608 CH 1H 470J-T [EUR-1]
C575 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2 R) B 27.1/17.2
C577 4030006860 S.CER C1608 JB 1H 102K-T [EUR] B 95.3/11.5
4030006860 S.CER C1608 JB 1H 102K-T [EUR-1]
C578 4030018910 S.CER C1608 JB 0J 475K-T B 55.2/42.4
C579 4030006860 S.CER C1608 JB 1H 102K-T B 54.5/44.6
C580 4510008490 S.ELE EEE1CS100SR T 53.8/43.8
C581 4030008880 S.CER C1608 JB 1H 223K-T B 49.3/37.6
C582 4030006900 S.CER C1608 JB 1H 103K-T T 100/60.3
C583 4030006900 S.CER C1608 JB 1H 103K-T T 97.6/58.1
C586 4030006900 S.CER C1608 JB 1H 103K-T B 112.5/51.7
C587 4030006900 S.CER C1608 JB 1H 103K-T T 107.3/49.2
C712 4030017200 S.CER GRM31BR32J102KY01L
(GHM1030 R) B 26.5/11.3
C713 4030017200 S.CER GRM31BR32J102KY01L
(GHM1030 R) B 40.8/2.7
C714 4030006860 S.CER C1608 JB 1H 102K-T B 23.2/17.4
J5 6510020511 S.CON FH12-40S-0.5SV(55) T 89.2/9.5
J6 6510009401 CON B7B-ZR(LF)(SN)
J7 6450000140 CON HSJ0807-01-010
T1 5920000751 TRA ST-82(P)FL
W1 8900016080 CAB OPC-905A
W2 7120000470 JUM ERDS2T0
W3 7120000470 JUM ERDS2T0
W4 7120000470 JUM ERDS2T0
EP2 6910013270 BEA 2643-625002
EP3 9040901901 TUB 0.7 L=12MM
Oct. 2008
8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
EP4 9040901901 TUB 0.7 L=12MM
EP5 6910010220 BEA HF70BB3.5X5X1.3 [EUR]
6910010220 BEA HF70BB3.5X5X1.3 [EUR-1]
EP6 9025608001 TUB 1 L=7MM
S.=Surface mount
Oct. 2008
GND
GND
SPE
SPE
SP
SP
8V
VCC
5V
TRC
TMUT
PSWC
CPU5V
MICE
MIC
PTT
PTTS
GND
GND
GND
GND
GND
RMUT
AFMUT
SMUT
VCS
SCK
SO
BEEP
FISW
UNLK
PLSTB
SO
SCK
R/T
NC
SQLI
GND
GND
GND
2 40
1 39
J5
from/to FRONT unit J1
• MAIN UNIT (A110/A110EURO)
(TOP VIEW)
• FRONT UNIT (A110)
(TOP VIEW)
• FRONT UNIT (A110EURO)
(TOP VIEW)
(Jun. 2008)
HANG
MIC
PTT
CLON
GND
MICE
AFO
8V
V/M SCAN PRI SQL
I
MP2
HANG
MIC
PTT
CLON
GND
MICE
AFO
8V
V/M SCAN PRI SQL
I
MP2
C10
C11
C28
C33
C43
C56
C58
C59
C62
C75
C98
C99
C100
C101
C102
C103
C113
C116
C117
C118
C119
C121
C122
C123
C124
C129
C130
C132
C133
C134
C135
C138
C141
C153
C164
C165
C168
C170
C188
C189
C190
C192
C193
C195
C206
C211
C212
C214
C217
C220
C226
C250
C266
C267
C268
C277
C279
C286
C288
C295
C298
C301
C317
C320
C321
C322
C325
C332
C333
C342
C343
C344
C346
C361
C366
C387
C388
C389
C391
C392
C395
C418
C420
C421C422
C423
C424
C425
C426
C427
C428
C430
C433
C436
C437
C438
C441
C442
C444
C445
C446 C447
C448
C449
C452
C453
C454
C455
C500
C501
C502
C503
C504
C505
C506
C513
C514
C515
C516
C517
C519
C520
C521
C523
C525
C531
C535
C537
C538
C539
C540
C541
C542
C543
C544
C545
C546
C547
C548
C550
C551
C552
C554
C572
C573
C574
C580
C582
C583
C587
D3
D36
D53 D54
D55
D57
D64
D65
FI1
FI2
FI3
FI4
FI6
IC5
IC29
IC31
IC41
IC42
IC43
IC45
IC47
IC51
IC52
J5
J6
J7
L2
L3
L4
L5
L6
L7
L9
L10
L11
L21
L22
L23
L27
L31
L33
L35
L36
L39
L40
L41
L42
L43
L48
L49
L50
L52
L53
L55
L56
L57
L60
L61
L62
L63
L64
L65
L67
L68
L69
L70
L71
L82
L83
L84
L85
L89
MP4
MP5
MP6
MP7
MP8
MP13
MP19
Q11
Q16
Q21
Q33
Q43
Q44
Q51
Q51
Q53
Q58
Q59
Q68
Q69
Q73
Q77
Q78
Q83
Q84
Q89
Q90
Q98
Q99
R59
R63
R99
R101
R110
R114
R115
R116
R118 R119
R120
R121
R122R123
R124
R150
R181
R188
R192
R193
R194
R209
R218
R219
R220
R222
R243
R251
R256
R280
R281
R288
R297
R328
R329
R330
R331
R332
R333 R334
R336
R338
R355
R356
R363
R364
R365R366
R367
R372
R373
R374
R375
R376
R379
R386
R387
R392
R393
R394
R395
R396 R397
R398
R399
R400
R401
R407
R408
R409
R410
R411
R412
R413
R414
R427
R428
R429
R430
R431
R435
R438
R442
R443
R447
R450
R451
R452
R453
R454
R455
R456 R457
R458
R459
R460
R461
R468
R473
R474
R478
R479
R493
R494
R498
R499
R500
T1
W2
W3W4
W15
W29
W32
W34
W39
W40
W41
W42
W44
W51
W52
W53
W54
X1
RED
MP1
CP1
CP2
B5531E
BLACK
CP5
H0H5H10H15H20H25H30H35H40H45H50H55H60H65H70H75H80H85H90H95H100H105H110H115H120H125H130H135
V0 V5 V10 V15 V20 V25 V30 V35 V40 V45 V50 V55 V60 V65 V70 V75 V80 V85 V90 V95 V100 V105 V110 V115
9
SECTION 9 BOARD LAYOUTS
Oct. 2008
10
1
3
4
5
80
1
61
60
41
4021
20
1
45
8
14
58
1
89
16
SPE SP
1
3
4
5
80
1
61
60
41
4021
20
1
45
8
14
58
1
89
16
SPE SP
C1
C2
C3
C4
C5
C6
C7
C8
C9
C12
C13
C14
C15
C16 C17
C18
C19
C20
C22
C23
C24
C25
C26
C27
C29
C30
C31
C32
C34
C37
C39
C40
C41
C42
C44
C46 C47
C48
C50
C51
C52
C53
C54
C55
C60
C61
C63
C68
C69
C70
C71
C72
C73
C74
C77
C78
C82
C85
C87
C91
C92
C95
C96
C97
C110
C112
C114
C115
C120
C126
C127
C128
C131
C139
C140
C148
C154
C156
C167
C175
C177
C208
C209
C213
C218
C224
C228
C229
C230
C231
C232
C233
C234
C235
C241
C242
C249
C251
C253
C255
C256
C257C258
C259
C260
C261
C262
C263 C264
C265
C289
C290
C292
C293
C299
C300
C308
C309
C312
C313
C314
C315
C316
C318
C319
C323
C324
C326
C327
C328
C329
C330
C331
C337
C338
C339
C340
C341
C347
C348
C349
C353
C354
C358
C359
C360
C362
C374
C378
C379
C380
C381
C382
C383
C384
C385
C390
C403
C404
C405 C406
C407
C409
C410
C413
C415
C416
C417
C419
C429
C434
C439
C443
C450
C456
C457
C458
C459
C460
C461
C462
C463
C468
C472
C507
C508
C509
C512
C518
C522
C524
C529
C530
C533
C536
C549
C553
C555
C556
C557
C558
C559
C560
C561
C562
C563
C564
C565
C566
C567
C568
C569
C570
C571
C575
C576
C577
C578
C579
C581
C586
C712
C713
C714
D1
D2
D4 D5
D6
D7
D8
D10
D11
D14
D15
D26
D27
D28
D29
D30
D31
D35
D37
D38
D43
D44
D50
D51
D52
D56
D62 D66
FI5
IC2
IC4
IC6
IC7
IC11
IC13
IC15
IC16
IC17
IC18
IC19
IC22
IC26
IC28
IC30
IC37
IC40
IC44
IC46
IC48
IC50
L14
L15
L17
L19
L20 L26
L54
L72
L73
L74
L75
L77
L78
L79
L80
L81
L86
L87
L88
L90
L91
MP3
Q1
Q3
Q4
Q5
Q6
Q7
Q12
Q14
Q15
Q20
Q22 Q23
Q42
Q52
Q70
Q71
Q72
Q74
Q75
Q79
Q80
Q81
Q82
Q86
Q87
Q88
Q91
Q92
Q93
Q94
Q96
Q97
Q100
Q101
Q102
R1
R2 R3
R9
R11
R12
R13
R14
R15
R17
R18
R19
R20
R25
R30
R31
R34
R35
R36
R37
R38 R40
R41
R42
R43
R45
R46
R48
R49
R50
R61
R62
R64
R65
R66R67
R68
R69
R70
R71
R72
R73
R74
R75
R76
R77
R78
R79
R80
R85
R86
R87
R95
R108
R111
R112 R113
R117
R126 R127
R128
R131
R132
R148
R149
R151
R152
R153
R174
R182
R183
R184
R186
R187
R208
R211
R212
R221
R223
R224
R225
R226
R228
R229
R230
R231
R232
R233
R234
R235 R236
R237
R238
R239
R240
R241
R242
R267
R273
R289
R295
R301
R321
R322
R323
R325
R327
R340
R342
R357
R358
R359
R361
R362
R368
R369
R370
R371
R377
R380
R383
R388
R389
R390
R391
R403
R404
R405
R406
R415
R417
R418
R419
R420
R422
R423
R424
R425
R426
R432
R433
R434
R436
R437
R439
R440
R441
R444
R445 R446
R448
R462
R463
R464
R465
R466
R467
R469
R470
R471
R472
R475
R476
R484
R485
R486
R487
R488
R489
R490
R491
R492
R501
W20
W25
W28
W33
W35
W38
W43
W47
W48
W49
G
G
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80 H85 H90 H95 H100 H105 H110 H115 H120 H125 H130 H135
V0V5V10V15V20V25V30V35V40V45V50V55V60V65V70V75V80V85V90V95V100V105V110V115
• MAIN UNIT (A110/A110EURO)
(BOTTOM VIEW)
• FRONT UNIT (A110)
(BOTTOM VIEW)
• FRONT UNIT (A110EURO)
(BOTTOM VIEW)
GND
GND
SPE
SPE
SP
SP
8V
VCC
5V
TRC
TMUT
PSWC
CPU5V
MICE
MIC
PTT
PTTS
GND
GND
GND
GND
GND
RMUT
AFMUT
SMUT
VCS
SCK
SO
BEEP
FISW
UNLK
PLSTB
SO
SCK
R/T
PDET
SQLI
GND
GND
GND
2
40
1
39
J1
from/to MAIN
N
unit J5
GND
GND
SPE
SPE
SP
SP
8V
VCC
5V
TRC
TMUT
PSWC
CPU5V
MICE
MIC
PTT
PTTS
GND
GND
GND
GND
GND
RMUT
AFMUT
SMUT
VCS
SCK
SO
BEEP
FISW
UNLK
PLSTB
SO
SCK
R/T
PDET
SQLI
GND
GND
GND
2
40
1
39
J1
from/to MAIN
unit J5
W1 W2
W1 W2
Oct. 2008
11
SECTION 11
.
VOLTAGE DIAGRAM
L33
0.82U
47
R498
L55
0.33U
0.001
C91
D10
MA7 7
LS-527
L9
22
C129
0.001
C75
R374
100K
R368
18K
L60
10U
R122
39K
27P
C415
470 YXG
C212
R2
2.2K
IC51
TA75S01F
1
2
3
4
5
Q53
DTB123EK
HK-08S070
L62
D44
MA8051
R364
1.2M
4.7
C177
0.001
C131
R371
10K
22P
C359
W3 5
0
R108
1K
0.1
C313
L56
0.33U
Q77
2SD1819A
L42
0.82U
W4 0
0
IC42
TA75S01F
1
2
3
4
5
0.47
C575
R327
150
CP24VR
CP4
L61
HK-10S080
R386
150K
R473
180
NJM2902V
IC19
9
10
8
0.001
C366
L14
0.1U
4.7
C433
0.001
C342
0.022
C261
R153
6.8K
15P
C552
R408
150K
0.1
C390
0.001
C96
TC4W53FU
IC17
1
2
3
4
5
6
7
8
22P
C501
470 YXG
C505
R43
3.3K
100P
C208
Q93
2SK2414
R375
5.6K
33P
C1
100P
C573
XP4315
Q33
1
2
34
5
6
0.001
C115
10
C138
R295
180
R414
8.2K
0.022
C581
R403
2.2K
R119
100K
TC4W53FU
IC16
1
2
3
4
5
6
7
8
R241
22K
Q7
2SC4211
MP 4
1
2
3
4
5
6
R183
1M
15P
C416
10
C113
B7B-ZR
J6
1
12
23
34
45
56
6
77
R460
4.7
0.5P
C344
2.2
C56
4.7
C175
CFWM450D
FI3
IO
1000 YXG
C452
R394
15K
C192*
R356
68K
0.1
C340
R239
22K
R236
22K
0.001
C540
Q70
DTB123EK
R401
2.2K
R221
8.2K
33P
C562
R112
39
R478
82K
0.47
C468
R297
1M
R470
22K
R64
100K
0.001
C295
Q22
2SC421 1
0.001
C324
4.7 MSVA
C226
D64
HVU350B
BA3308F
IC4
1
OUT 1 2
GND 3
NC 4
ALC 5
VCC 6
NC 7
OUT 2
8NC
9IN2
10 NF2
11 NF1
12 NC
13 INI
14 NC
R355
2.2K
39P
C427
Q82
2SC408
1
0.01
C228
L88
0.82U
L43
0.82U
R85
33K
CP06S
CP2
R209
47K
D4
RB706F
270P
C520
D31
1SV307
33
C322
R452
5.6K
4.7
C553
L52
0.82U
R224
1K
39P
C3
R181
150K
R1
100
0.001
C18
0.1
C267
R113
33K
Q101
D TC144EU
0.047
C529
CP06S
CP12
R439
470
R442
10K
100
R500
R63
2.2K
27P
C241
R461
5.6K
0.001
C419
1
C233
R212
1K
100
R499
R66
15
R446
8.2K
0.01
C51
HK-08S070
L63
L40
#E558CN
R243
100
R474
4.7
10
C580
D56
DE5SC6M
R429
10K
1.5
C413
0.01
C46
4.7
C379
0.001
C85
0.47
C404
Q52
2SA1622
R379
100K
R426
47K
R373
100
0.001
C62
L48
LA-243
FW261
Q100
5D2
6D2
7D1
8D1 1
S1 2
G1 3
S2 4
G2
0.1
C50
0.001
C576
R46
100
D53
MA2S111
330
IC50
TA75S01F
1
2
3
4
5
R471
22K
0.1
C289
R456
220K
TC4S66F
IC28
1
2
34
5
0.0027
C339
R223
33K
D8
HVU350B
617DB
L91
R208
100
D43
1SS352
R193
470
R87
120
TA31136FNG
IC40
1OSCIN
2OSCOUT
3MIXOUT
4VCC
5IFIN
6DEC
7FILOUT
8FILIN 9
AFOUT
10
QUAD
11
IFOUT
12
RSSI
13
N-DET
14
N-REC
15
GND
16
MIXIN
0.01
C327
0.01
C54
CP24VR
CP3
0.001
C255
R62*
R455
1.2K
5P
C346
NJM2902V
IC19
6
5
7
0.1
C443
BNX-002
FI6
1B
2CB
3
PSG 4
CG
5
6
15P
C98
Q21
CP5
2SK3075
100
C445
0.001
C558
24P
C500
W2 9
0
L27
0.15U
R447
1.2K
MP 3
1
2
R117
1M
R453
1K
0.01
C449
CR-658A
X1
1NC
2GND 3
OUT
4
VCC
1
C549
7P
C503
Q75
2SC408 1
Q23
2SB1132
33P
C422
L87
56N
R152
100
0.1
C156
L3
LA-263
D26
DE5SC6M
12P
C545
R342
10K
ERDS2T0
W4
6P
C423
1P
C13
9P
C330
0.01
C442
R427
33K
R409
430K
FW261
Q94
5
D2
6
D2
7
D1
8
D1
1S1
2G1
3S2
4G2
0.1
C290
L7
LW-25
15P
C87
0.47
C463
HR75
8.2K
R331
220K
500K
R392
R220
R42
1.5K
0.01
C55
NJM2902V
IC19
V+
4
GND
11
8P
C358
Q69
DTB123EK
ACF321825
FI5
R363
100K
Q92
2SK2414
Q87
2SK2414
R463
470K
22
C132
W54
0
R75
150
20P
C426
0.01
C299
W4 3
0
L69
12N
0.001
C213
R451
4.7
0.01
C328
18P
C9
0.001
C525
R192
68K
MC33063ADG
IC15
1SWC
2SW E
3TIM
4GND 5
INV
6
VCC
7
IPK
8
DRV
0.0082
C118
R38
1.5K
0.001
C253
R370
10K
R369
10K
0.01
C235
0.001
C148
R330
TBPS1R154K475H5 Q
J7
HSJ0807-01-010
0.001
C218
R432
56K
R425
22K
470P
C568
D65
HVU350B
22 MSVD2
C454
R50
820
TB31207AFNG
IC2
1
FIN1 2
GND 3
CLK 4
DATA 5
STB 6
BS1 7
BS2 8
FIN2
9CP2
10 GND
11 LD
12 BO
13 XOUT
14 XIN
15 VCC
16 CP1
L39
0.82U
0.5P
C31
0.001
C567
D3
MA4PH22 4
0.01
C42
0.001
C577
R418
470K
R436
33K
0.001
C68
Q81
D TC144EU
L80
ZBFS5105
0
W2 0
TA75S01F
IC31
1
2
3
4
5
L41
#E558CN
0.001
C564
D30
1SV307
50K
R59
0.001
C550
LS-527
L10
470 YXG
C211
R149
4.7K
R424
100K
4P
C361
L79
ZBFS5105
1P
C14
R441
3.3K
0.01
C39
0.01
C315
Q99
2SC411 6
0.1
C338
2.2
C326
NJM2902V
IC19
2
3
1
R79
470
R229
2.2K
0.01
C121
0.0018
C117
0.0033
C349
R485
1K
R395
56K
0.001
C537
5P
C434
FL-307
FI2
1
IN
2OUT 3
GND
4GND
56
L73
100U
MRF137
Q51
0.01
C229
0.1
C48
0.001
C135
TC4W53FU
IC48
1
2
3
4
5
6
7
8
15P
C331
R182
470K
R174
56K
0.0012
C509
TDA7233D
IC37
1GND
2MUT E
3GND
4+VS 5
O UTPUT
6
SVR
7
-INPUT
8
+INPUT
0.001
C220
R132
10K
R329
120K
R445
820
1.5P
C4
0.1
C309
R462
10K
0.001
C141
R41
22K
L17
0.12U
22P
C316
0.001
C77
1
C234
LA4425A
IC41
1
2
3
4
5
100K
R494
D62
SB07-03C
R450
10K
R12
100K
0.01
C438
2P
C533
0.47
C133
R37
56K
R127
10K
R225
10K
0.001
C73
0.001
C99
4P
C395
L82
6.8U
D38
1SV271
R35
100
R25
10K
R419
10K
W4 7
0
D7
HVU350B
0.001
C409
0.001
C43
82P
C242
R36
22K
100
C448
D15
MA111
1K
R336
0.001
C193
R399
1K
Q74
2SB798
R99
39
R400
1K
0.001
C548
R235
22K
R48
56K
R454
4.7K
0.1
C44
L57
0.33U
Q20
2SK3074
3.3
C453
0.01
C332
R465
10K
220P
C439
0.1
C47
R71
47
0.001
C69
R323
10K
R390
560
L19
39N
470
C206
CP06S
CP11
R396
47K
C60*
0.001
C250
0.1
C268
Q91
2SK2414
IC11
NJM2107F
1
2
3
4
5
Q15
2SC422 8
9P
C546
R20
220K
R438
470
0.001
C579
20P
C72
0.001
C189
D52
1SV271
0.047
C292
R388
4.7K
W4 1
0
R457
150K
0.01
C308
L74
1.8U
0.001
C63
0.1
C325
R219
39
10K
R489
0.0022
C378
R114
N TCG16
R434
10K
R128
10K
L50
LA-262
47
C301
R14
560K
0.01
C41
L67
23N
22P
C22
L77
6.8U
R412
10K
R376
560K
XP4315
Q86
1
2
34
5
6
D2
MA4PH22 4
W3 3
0
W3 8
0
R222
EVM-2W B24 20K
100K
R469
4.7
XP4315
Q68
1
2
34
5
6
0.1
C52
SPM5001
IC52
1G1
2D1
3D2 4
S2
5
S1
6
G2
R111
100K
R234
22K
R359
100
R280
10K
0.1
C59
0.001
C418
0
W2 8
R321
47K
33
C506
0.0012
C508
L6
LA-235
Q80
DTA144EU
R435
1.8K
0.01
C329
TC4W53FU
IC22
1
2
3
4
5
6
7
8
TA78L05 F
IC26
IO
G
0.001
C515
Q44
2SC4226
R393
15K
0.001
C214
H IP4081AIBZ
IC47
1
BHB 2
BHI 3
DIS 4
VSS 5
BLI 6
ALI 7
AHI 8
HDEL 9
LDE L 10
AHB
11 AHO
12 AHS
13 ALO
14 ALS
15 VCC
16 VDD
17 BLS
18 BLO
19 BHS
20 BHO
Q98
2SA1586
W3 2
0
R322
4.7
0.1
C543
68P
C502
L78
ZBFS5105
0.01
C317
R443
10K
0.001
C6
0.001
C277
R69
150K
TC4S66 F
IC30
1
2
34
5
22
R501
0.75P
C23
L81
ZBFS5105
R440
10K
0.001
C374
10K
R110
CP06S
CP13
22P
C154
R148
22K
MC33063ADG
IC46
1SWC
2SW E
3TIM
4GND 5
INV
6
VCC
7
IPK
8
DRV
L15
0.22U
R433
47K
R466
10K
H IP4081AIBZ
IC43
1
BHB 2
BH I 3
DIS 4
VSS 5
BLI 6
ALI 7
AHI 8
HDE L 9
LDE L 10
AHB
11 AHO
12 AHS
13 ALO
14 ALS
15 VCC
16 VDD
17 BLS
18 BLO
19 BHS
20 BHO
R78
56
0.01
C428
1
C58
33P
C188
10
C437
R115
100K
0.01
C557
R226
100K
D29
1SV307
0.1
C381
220 YK
C531
0.1
C353
R15
100
18P
C74
Q5
2SC421 5
R410
180K
R289
220K
C539*
470P
C519
R40
2.2K
10
C436
R231
4.7K
R366
100K
R65
15
C521*
R406
1.8K
L54
82N
R459
10K
R77
10K
R365
100K
FH12-40S-0.5SV
J5 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
R68*
W4 2
0
R448
680
R325
270
0.001
C28
R413
8.2K
D37
HVU350B
R218
4.7K
LS-527
L49
FL-306
FI1
1
IN
2OUT 3
GND
4GND
5
6
R444
10K
R372
100
Q16
2SC4116
D14
MA8036
NJM2902V
IC19
13
12
14
27P
C29
0.068
C263
Q73
2SC4081
27K
R491
150P
C544
CFG450H
FI4
IO
0.001
C19
D55
SB07-03C
R328
56K
470P
C560
680
R486
0.0018
C257
1
C380
0.001
C30
9P
C279
0.1
C128
27K
R490
0.1
C126
L83
3.3U
Q14
2SC4403
R118
120K
0.001
C27
R186
150K
L31
36N
R211
6.8K
0.001
C20
XC6202P502PR
IC7
IO
G
CP06S
CP14
W34
0
0.001
C417
470P
C563
0.001
C92
R70
470
1
C170
39P
C217
Q90
2SA1471R
R228
2.2K
L72
100U
L84
3.3U
R423
100
0.001
C323
R116
560K
22P
C421
R242
22K
R45
56K
R475
4.7K
0.001
C561
L85
6.8U
22P
C15
0.5P
C190
470P
C262
150P
C504
0.001
C25
Q6
2SC421 5
R380
10
5P
C406
0.01
C230
R67
15
0.001
C70
10K
R487
0.1
C542
OPC-905A
W1
R281
390K
0.015
C259
T1
ST-82
R476
1K
0.47
C456
L65
10U
R387
150K
56P
C103
Q84
2SC421 5
15 MSVA
C123
Q59
2SC4226
R230
4.7K
100P
C119
D51
1SV271
R357
1M
D6
HVU350B
10
C513
0.1
C266
2.5P
C429
0.001
C61
R80
56
L68
6.5N
56P
C424
0.001
C124
D1
MA4PH22 4
0.1
C168
R377
22
33P
C565
L20
56N
0.01
C348
SM6451B
IC13
1RSTN
2ADRS 1
3ADRS 2
4DVDD
5LOUT
6LIN
7AVDD
8VRL 9
VRR
10
AVSS
11
RIN
12
ROUT
13
DVSS
14
MLEN
15
MCK
16
MDT
Q79
2SK880
0.001
C122
R34
1.8K
R468
4.7
R431*
4P
C407
Q43
2SC4226
Q97
DTC144EU
0.001
C26
HK-08S070
L53
R417
2.2K
R404
2.2K
R479
NTCG16
R232
4.7K
R61*
R484
3.9K
0.033
C385
Q4
2SC4215
R9
220K
R383
10K
R18
220K
0.001
C389
TC4W53FU
IC18
1
2
3
45
6
7
8
R120
100K
R73
270
R251
4.7K
0.1
C516
L70
LA-232
0.01
C320
0.5P
C391
MR-DSE-01
J1
1
2
0.01
C382
D28
1SV307
R472
100K
IC45
NJM072BM
1
2
3
45
6
7
8
R74
39K
0.1
C224
33
C298
82P
C264
HR58
2.2K
24P
C555
0.001
C249
0.001
C140
R437
10K
Q1
3SK293
R19
220K
R397
47K
L5
LA-244
0.01
C586
C538*
R126
10K
R184
1M
0.001
C288
W3 9
0
2P
C405
3.3 MSVA
C383
R340
560
4.7
C578
R415
560
R430
12K
10P
C16
0.001
C130
0.1
C337
0.01
C116
R334
560K
1
C447
1
C403
R240
22K
D57
1SS193
Q12
2SC440 3
R86
220
0.001
C40
D11
MA7 7
330P
C293
0.001
C82
D36
DSA3A1
XP4315
Q72
1
2
34
5
6
0.01
C582
0.01
C444
15 MSVA
C112
TC4S66 F
IC6
1
2
34
5
0.1
C507
0.1
C347
0.47
C114
0.001
C410
47P
C574
R95
22K
0.001
C71
0.001
C11
0
W25
0.0022
C523
27P
C32
0.1
C265
R17
47
0.01
C333
10K
R488
220P
C571
CP06S
CP1
R273
470K
L71
LA-382
0.001
C24
0.001
C512
22P
C522
R391
470
XP1501
Q89
1
2
34
5
R367
10K
R358
82K
27K
R492
R31
1.5K
0.1
C314
R361
1M
100
C343
W48
0
R3
3.3K
R467
1M
W51
0
22
C388
R422
1M
22
C134
0.001
C167
D66
SB07-03C
0.001
C312
0.47
C457
0.001
C458
0.001
C459
0.001
C460
0.001
C461
0.001
C712
0.001
C713
1
C518
W49
0
R30
18K
470P
C570
20P
C78
47P
C551
0.001
C251
0.01
C420
W1 5
0
470P
C554
56P
HC534
R288
1K
D50
1SV271
0.001
C37
R332
120K
27P
C95
617DB
L90
D5
RB706F
R407
150K
L86
ZBFS5105
0.01
C258
0.001
C231
1
C232
0.01
C341
ERDS2T0
W2
R49
390K
Q42
2SC4226
Q3
2SC4215
XP1113
Q58
1
2
34
5
Q78
2SD1819A
0.001
C321
22P
C12
Q96
DTC144EU
100
R493
R411
390K
0.1
C536
0.001
C100
HK-08S07 0
L64
0.01
C127
0.001
C97
LR-89
L36
100K
R121
R123
39K
0.1
C384
0.001
C164
R188
47K
R233
4.7K
R124
39K
UPC311G 2
IC44
1
2
3
45
6
7
8
R458
1K
0.01
C319
0.0056
C530
0.1
C300
0.01
C587
L2
LA-253
BA08FP
IC29
IO
G
R428
330
R101*
33P
C101
R11
220K
R194 2.7K
R333
10K
470P
C566
0.001
C362
24P
C547
R338
10K
5P
C33
0.001
C514
C195*
R72
68K
0.47
C209
33P
C559
39P
C8
24P
C556
100
C441
L23
23.5N
Q11
2SC408 1
22P
C5
C450*
5P
C2
L31
82N
#617DB
L89
D27
MA11 1
0.001
C139
L35
12N
W52
0
0.01
C583
Q83
2SC4215
0.01
C425
0.022
C256
220P
C572
D54
M A2S111
0.001
C260
470
C387
0.47
C120
R420
2.2K
0.01
C53
W53
0
0.001
C34
IC5
TA75S01F
1
2
3
4
5
330P
C446
L22
47N
R187
100K
D35
MA8330
0.01
C430
LS-527
L11
12P
C392
Q71
DTC144EE
1
C153
1
C110
R238
22K
R256
2.7K
R301
22K
0.1
C541
L26
EXCCL3225U
ERDS2T0
W3
Q102
2SC4081
0.001
C360
R237
22K
0.001
C569
10K
R150
0.5P
C286
R405
56K
L4
LA-244
10P
C17
0.47
C462
0.001
C517
R131
1K
0.001
C472
L75
0.82U
0.047
C524
0.001
C714
R76
10K
R13
100K
R464
3.3K
22P
C7
22P
C102
R362
1.2K
R267
10K
Q88
2SK2414
0.01
C455
W44
0
6P
C165
0.1
C354
R389
2.7K
R398
2.2K
47P
C10
0.01
C318
R151
3.3K
EPTT
EMIC
PTTS
PTT
MIC
TRC
SP
AFMUT
AFMUT
TMUT
FISW
SQLI
BEEP
R/T
RMUT
RMUT
TRC
AFMUT
MICE
SMUT
TRC
CPU5V
TMUT
UNLK
SCK
SO
PLSTB
SCK
VCS
RMUT
AFMUT
SMUT
VCS
SCK
SO
BEEP
TRC
FISW
TMUT
UNLK
PSWC
PLSTB
CPU5V
SO
MICE
SCK
MIC
R/T
PTT
PTTS
SQLI
PSWC
VCC
SO
R8
5V
8V
8V
SPE
W3 6W3 7
C:13.72VC:10.1V
C:10.45V
T:7.95V
R:0V
T:0V
R:7.93V
C:10.44V
C:5.00V
C:5.00V
T:0V
R:6.04V R:2.96V
T:0V
R:7.09V
T:0V
R:0.54V
T:7.05V
R:0V
T:1.03V
C:39.7V
C:5.03V
C:13.53V
T:1.69V
C:0V
R:5.9V
T:0V
T:0V
R:3.77V
T:0V
R:2.14V
R:2.13V
T:0V R:4.83V
T:0V
R:0.93V
T:0V
T:0V
R:0.52V
• Power supply voltage: 13.75 V
• Frequency: 127.100 MHz
• RX signal level: 54 dBµ
*; Refer to “PARTS LIST” for the value or component name.
• MAIN UNIT
Oct. 2008
SERVICE MANUAL
ADDENDUM
CONTENTS
PARTS LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
VOLTAGE DIAGRAM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Jun. 2008
1
PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER DESCRIPTION .
NO. NO.
IC1 1140008780 S.IC HD6433823A19D
except[A110EURO]
IC1 1140009830 S.IC HD6433823A80D [A110EURO]
IC2 1110005771 S.IC S-80942CNMC-G9CT2G
IC3 1130007111 S.IC TC7W04FU
IC4 1130011321 S.IC CAT25C16VI-TE13
IC5 1130007570 S.IC BU4094BCFV-E2
Q1 1590000440 S.TR DTA143ZUA T106
Q2 1510000881 S.TR 2SA1622-6-TL-E
Q3 1530003281 S.TR 2SC4211-6-TL-E
Q4 1590001980 S.TR XP4315 (TX)
Q5 1590000440 S.TR DTA143ZUA T106
Q6 1590000680 S.TR DTC114EUA T106
Q7 1590000680 S.TR DTC114EUA T106
D5 1790001280 S.DIO MA111 (TX)
D6 1750000130 S.DIO DA204U T106
X1 6060000770 S.CER EFOP3684E5
L1 6200003960 S.COL MLF1608A 1R0K-T
except [A110EURO]
L2 6200003540 S.COL MLF1608D R22K-T
except [A110EURO]
R1 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R2 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R3 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R4 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R5 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R6 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R7 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R8 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R11 7030003370 S.RES ERJ3GEYJ 271 V (270)
R12 7030003350 S.RES ERJ3GEYJ 181 V (180)
R13 7030003350 S.RES ERJ3GEYJ 181 V (180)
R14 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R15 7030003590 S.RES ERJ3GEYJ 183 V (18 k)
R16 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R17 7030003620 S.RES ERJ3GEYJ 333 V (33 k)
R18 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R19 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R20 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R21 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R22 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R23 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R24 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R26 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R27 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R28 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R29 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R30 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R31 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R32 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R33 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R34 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R36 7030003600 S.RES ERJ3GEYJ 223 V (22 k)
R37 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R38 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R41 7030003610 S.RES ERJ3GEYJ 273 V (27 k)
R42 7030003610 S.RES ERJ3GEYJ 273 V (27 k)
R43 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R44 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R45 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R46 7030003610 S.RES ERJ3GEYJ 273 V (27 k)
R47 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
C1 4030006860 S.CER C1608 JB 1H 102K-T
C2 4030006860 S.CER C1608 JB 1H 102K-T
C3 4030007090 S.CER C1608 CH 1H 470J-T
C4 4030007090 S.CER C1608 CH 1H 470J-T
C5 4030006860 S.CER C1608 JB 1H 102K-T
C6 4030007090 S.CER C1608 CH 1H 470J-T
C7 4030006850 S.CER C1608 JB 1H 471K-T
C8 4030006850 S.CER C1608 JB 1H 471K-T
C9 4030008560 S.CER C1608 CH 1H 300J-T
C10 4030008560 S.CER C1608 CH 1H 300J-T
C11 4030008890 S.CER C1608 JB 1H 273K-T
C12 4030011600 S.CER C1608 JB 1E 104K-T
C13 4030011600 S.CER C1608 JB 1E 104K-T
C14 4030011600 S.CER C1608 JB 1E 104K-T
C15 4030007090 S.CER C1608 CH 1H 470J-T
C16 4030011600 S.CER C1608 JB 1E 104K-T
S.=Surface mount
[FRONT UNIT]
REF ORDER DESCRIPTION .
NO. NO.
C17 4030011600 S.CER C1608 JB 1E 104K-T
C18 4030006860 S.CER C1608 JB 1H 102K-T
C19 4030006860 S.CER C1608 JB 1H 102K-T
C20 4030011600 S.CER C1608 JB 1E 104K-T
C21 4030006860 S.CER C1608 JB 1H 102K-T
C22 4030011600 S.CER C1608 JB 1E 104K-T
C23 4550006480 S.TAN TEESVA 1C 475M8R
C24 4030011600 S.CER C1608 JB 1E 104K-T
C25 4030011600 S.CER C1608 JB 1E 104K-T
C26 4030011600 S.CER C1608 JB 1E 104K-T
C27 4550006250 S.TAN TEESVA 1A 106M8R
C28 4030006860 S.CER C1608 JB 1H 102K-T
C29 4030006860 S.CER C1608 JB 1H 102K-T
C30 4030006890 S.CER C1608 JF 1H 103Z-T
[A110EURO]
C30 4030007090 S.CER C1608 CH 1H 470J-T
except [A110EURO]
C31 4030006860 S.CER C1608 JB 1H 102K-T
C32 4030006860 S.CER C1608 JB 1H 102K-T
C33 4030006860 S.CER C1608 JB 1H 102K-T
C34 4030006860 S.CER C1608 JB 1H 102K-T
C35 4030006860 S.CER C1608 JB 1H 102K-T
C36 4030006860 S.CER C1608 JB 1H 102K-T
C37 4030007090 S.CER C1608 CH 1H 470J-T
[A110EURO]
C38 4030006860 S.CER C1608 JB 1H 102K-T
[A110EURO]
J1 6510020511 S.CNR FH12-40S-0.5SV (55)
J2 6450001470 CNR 95003-2881
DS1 5030001740 LCD HLC7453-012400
DS2 5040002030 S.LED CL-170Y-CD-T
DS3 5040002030 S.LED CL-170Y-CD-T
DS4 5040002030 S.LED CL-170Y-CD-T
DS5 5040002030 S.LED CL-170Y-CD-T
DS6 5040002030 S.LED CL-170Y-CD-T
DS7 5040002030 S.LED CL-170Y-CD-T
S1 2250000420 ECR EVQB2CFC620B
SP1 2510000880 SP SME-45W except [GEN], [AUS]
SP1 2510000881 SP SME-C45W0819 [GEN], [AUS]
W1 7120000470 JMP ERDS2T0
W2 7120000470 JMP ERDS2T0
W3 7030003860 S.RES ERJ3GE JPW V
W4 7030003860 S.RES ERJ3GE JPW V
W6 8900007680 CBL OPC-741 (N:40 L:55)
W6 8900007682 CBL OPC-741A-1 (P0.5,N40,L55)
EP2 8930037960 LCT SRCN-1705 ZSS
Jun. 2008
2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
IC2 1130008831 S.IC TB31207AFNG (EL) B 88/26.6
IC4 1110003670 S.IC BA3308F-E2 B 102.7/22.9
IC5 1110002751 S.IC TA75S01F (TE85R,F) T 109.7/21
IC6 1130004201 S.IC TC4S66F (TE85R,F) B 60.1/37.4
IC7 1110006090 S.IC XC6202P502PR B 75.4/14.3
IC11 1110002400 S.IC NJM2107F-TE1 B 104.6/37.8
IC13 1130011860 S.IC SM6451BT-G-E2 B 50.8/41.2
IC15 1110005011 S.IC MC33063ADR2G B 17.2/45.8
IC16 1130006221 S.IC TC4W53FU (TE12L,F) B 101.7/12.2
IC17 1130006220 S.IC TC4W53FU (TE12L) B 114/34.8
IC18 1130006220 S.IC TC4W53FU (TE12L) B 127.5/18
IC19 1110003780 S.IC NJM2902V-TE1-#ZZZB B 60.3/28.5
IC22 1130006221 S.IC TC4W53FU (TE12L,F) B 52.5/24.9
IC26 1180000421 S.IC TA78L05F (TE12R,F) B 25.6/50.1
IC28 1130004201 S.IC TC4S66F (TE85R,F) B 18.7/71.5
IC29 1180002010 S.REG BA08FP-E2 T 73.9/22.6
IC30 1130004201 S.IC TC4S66F (TE85R,F) B 36.5/66
IC31 1110002751 S.IC TA75S01F (TE85R,F) T 106/7.5
IC37 1110003250 S.IC TDA7233D (TDA7233D013TR) B 25.9/76
IC40 1110003201 S.IC TA31136FNG (EL) B 113.7/39.6
IC41 1110003091 IC LA4425A-E
IC42 1110002751 S.IC TA75S01F (TE85R,F) T 58.7/29.7
IC43 1190001211 S.IC HIP4081AIBZ-T T 21.2/37.9
IC44 1110005131 S.IC uPC311G2-E2-A B 6.5/15
IC45 1110005100 S.IC NJM072BM-TE1 T 7.4/25
IC46 1110005011 S.IC MC33063ADR2G B 19.8/15.8
IC47 1190001211 S.IC HIP4081AIBZ-T T 18.4/17.7
IC48 1130006221 S.IC TC4W53FU (TE12L,F) B 6.8/24.1
IC50 1110002751 S.IC TA75S01F (TE85R,F) B 86.8/79
IC51 1110002751 S.IC TA75S01F (TE85R,F) T 104.8/13.4
IC52 1190002051 S.IC SPM5001-TL-E T 104.4/51.6
Q1 1580000731 S.FET 3SK293 (TE85L,F) B 120.8/62
Q3 1530002601 S.TR 2SC4215-O (TE85R,F) B 123.8/35.6
Q4 1530002601 S.TR 2SC4215-O (TE85R,F) B 128.9/13.7
Q5 1530002601 S.TR 2SC4215-O (TE85R,F) B 118.9/14.3
Q6 1530002601 S.TR 2SC4215-O (TE85R,F) B 115.7/6.6
Q7 1530003281 S.TR 2SC4211-6-TL-E B 113/16.4
Q11 1530002280 S.TR 2SC4081 T106 S T 88.7/72.4
Q12 1530002561 S.TR 2SC4403-3-TL-E B 99.5/33
Q14 1530002561 S.TR 2SC4403-3-TL-E B 93.4/41.7
Q15 1530002930 S.TR 2SC4228 (M) -T1 R45 B 99.5/44.4
Q16 1530002851 S.TR 2SC4116-BL (TE85R,F) T 98/42.5
Q20 1560001101 S.FET 2SK3074 (TE12L,F) B 83.1/65.7
Q21 1560001061 S.FET 2SK3075 (TE12L,Q) T 67/70.7
Q22 1530003281 S.TR 2SC4211-6-TL-E B 67.3/18.4
Q23 1520000460 S.TR 2SB1132 T100 R B 61.9/17.8
Q33 1590001980 S.TR XP4315 (TX) T 105/21.7
Q42 1530002920 S.TR 2SC4226-T1 R25 B 93/55.7
Q43 1530002920 S.TR 2SC4226-T1 R25 T 89.9/42.6
Q44 1530002920 S.TR 2SC4226-T1 R25 T 83.5/48.4
Q51 1590002841 FET MRF137 (M/A COM) T 62.8/98.9
Q52 1510000881 S.TR 2SA1622-6-TL-E B 100.5/5.9
Q53 1590000980 S.TR DTB123EK T146 T 76/11.9
Q58 1590001810 S.TR XP1113 (TX) T 98/46.9
Q59 1530002920 S.TR 2SC4226-T1 R25 T 82.8/39.7
Q68 1590001980 S.TR XP4315 (TX) T 111.9/52.8
Q69 1590000980 S.TR DTB123EK T146 T 112/49.8
Q70 1590000980 S.TR DTB123EK T146 B 60.2/49.7
Q71 1590001940 S.TR DTC144EE TL B 62.3/44.7
Q72 1590001980 S.TR XP4315 (TX) B 71.6/11.4
Q73 1530002060 S.TR 2SC4081 T106 R T 127.6/76.6
Q74 1520000201 S.TR 2SB798-T2-AZ DK B 18.4/78.3
Q75 1530002060 S.TR 2SC4081 T106 R B 14.8/81.2
Q77 1540000520 S.TR 2SD1819A (TX) R T 124.9/14.4
Q78 1540000520 S.TR 2SD1819A (TX) R T 116/15.2
Q79 1560000531 S.FET 2SK880-GR (TE85R,F) B 73.4/56.8
Q80 1590000720 S.TR DTA144EUA T106 B 60.6/41.5
Q81 1590000430 S.TR DTC144EUA T106 B 59.9/44.6
Q82 1530002280 S.TR 2SC4081 T106 S B 25.7/54.9
Q83 1530002381 S.TR 2SC4215-Y (TE85L,F) T 110.8/33.7
Q84 1530002381 S.TR 2SC4215-Y (TE85L,F) T 106.4/31.5
Q86 1590001980 S.TR XP4315 (TX) B 18.7/87.9
Q87 1560001121 S.FET 2SK2414-Z-E1-AZ B 18.3/36.9
Q88 1560001121 S.FET 2SK2414-Z-E1-AZ B 25.3/29.8
Q89 1590001170 S.TR XP1501-(TX) .AB T 7.5/50.9
Q90 1510001020 TR 2SA1471R
Q91 1560001121 S.FET 2SK2414-Z-E1-AZ B 36.6/31.2
Q92 1560001121 S.FET 2SK2414-Z-E1-AZ B 32.9/6
Q93 1560001121 S.FET 2SK2414-Z-E1-AZ B 32.2/17.6
Q94 1590003820 S.FET FW261-TL-E B 34.2/111.5
Q96 1590000430 S.TR DTC144EUA T106 B 36.1/99.7
Q97 1590000430 S.TR DTC144EUA T106 B 33.2/98.8
Q98 1510000771 S.TR 2SA1586-GR (TE85L,F) T 85.4/69.5
Q99 1530002851 S.TR 2SC4116-BL (TE85R,F) T 91.5/72.4
Q100 1590003820 S.FET FW261-TL-E B 16.7/111.1
Q101 1590000430 S.TR DTC144EUA T106 B 16.6/99.7
Q102 1530002280 S.TR 2SC4081 T106 S B 17.7/23.1
D1 1750000511 S.DIO UX9401F-STD/TR B 121/83
D2 1750000511 S.DIO UX9401F-STD/TR B 118.3/75.1
D3 1750000511 S.DIO UX9401F-STD/TR T 110/82.4
D4 1790001670 S.DIO RB706F-40T106 B 94.2/90.5
D5 1790001670 S.DIO RB706F-40T106 B 88.3/90.4
D6 1720000781 S.VCP HVU350BTRF-E B 133.5/65.7
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
D7 1720000781 S.VCP HVU350BTRF-E B 110.6/65
D8 1720000781 S.VCP HVU350BTRF-E B 107.2/65.6
D10 1790000620 S.DIO MA77 (TX) B 99.5/51.7
D11 1790000620 S.DIO MA77 (TX) B 98.7/54.4
D14 1790001330 S.ZEN MA8036-L (TX) B 96.3/23.5
D15 1790001280 S.DIO MA111 (TX) B 65.3/15.8
D26 1790001341 S.DIO DE5SC6M-7061 B 30.5/38.9
D27 1790001280 S.DIO MA111 (TX) B 100.5/9.5
D28 1750000580 S.DIO 1SV307 (TPH3)
B 114.7/52
D29 1750000581 S.DIO 1SV307 (TPH3,F) B 114.7/50.1
D30 1750000581 S.DIO 1SV307 (TPH3,F) B 126.3/48.6
D31 1750000580 S.DIO 1SV307 (TPH3)
B 126/51
D35 1730002460 S.ZEN MA8330-M (TX) B 31.4/55.6
D36 1790000700 DIO DSA3A1
D37 1720000781 S.VCP HVU350BTRF-E B 128.2/65.7
D38 1750000531 S.DIO 1SV271 (TPH3,F) B 126.4/76.2
D43 1750000261 S.DIO 1SS352 (TPH3,F) B 18/82.1
D44 1730002320 S.ZEN MA8051-M (TX) B 107.9/41.7
D50 1750000531 S.DIO 1SV271 (TPH3,F) B 123.4/43.5
D51 1750000531 S.DIO 1SV271 (TPH3,F) B 132.8/12.1
D52 1750000531 S.DIO 1SV271 (TPH3,F) B 120.3/10
D53 1790001250 S.DIO MA2S111-(TX) T 120.6/74.3
D54 1790001250 S.DIO MA2S111-(TX) T 123.3/74.3
D55 1790000671 S.DIO SB07-03C-TB-E T 29.7/42.4
D56 1790001341 S.DIO DE5SC6M-7061 B 32.1/24.1
D57 1750000051 S.DIO 1SS193 (TE85R,F) T 27/17.5
D62 1790000671 S.DIO SB07-03C-TB-E B 33.7/103
D64 1720000781 S.VCP HVU350BTRF-E T 78.4/45.4
D65 1720000781 S.VCP HVU350BTRF-E T 77.5/42
D66 1790000671 S.DIO SB07-03C-TB-E B 15.8/103.2
FI1 2010002400 S.MLH FL-306 (38.850 MHz) T 121.2/48
FI2 2010002410 S.MLH FL-307 (38.850 MHz) T 121.2/55.2
FI3 2020001540 CER CFWLB450KDFA-B0
FI4 2020001660 CER CFG450H
FI5 4580000110 S.FIL ACF321825-223-T B 15.5/16.8
FI6 2040000500 LC BNX-002-01
X1 6050010831 S.XTL CR-657A (12.8 MHz) T 89.2/24.9
L2 6110001670 COL LA-253
L3 6110001740 COL LA-263
L4 6110001610 COL LA-244
L5 6110001610 COL LA-244
L6 6110001550 COL LA-235
L7 6170000230 COL LW-25
L9 6150005001 S.COL LS-527-LF T 130.8/65.1
L10 6150005001 S.COL LS-527-LF T 113.7/65.1
L11 6150005001 S.COL LS-527-LF T 106.4/65.1
L14 6200001630 S.COL ELJNC R10K-F B 96.3/41.2
L15 6200003300 S.COL ELJNC R22K-F B 99.1/46.9
L17 6200003290 S.COL ELJNC R12K-F B 90.1/58.3
L19 6200005731 S.COL ELJRE 39NGFA B 86.4/62.8
L20 6200002380 S.COL LQW31HN56NJ03L B 80.5/61.7
L21 6200013030 S.COL 0.35-1.6-6TL 31.0N <COMO> T 54.1/73.8
L22 6200005741 S.COL ELJRE 47NGFA [AUS] only T 77.3/69
L23 6200012870 S.COL 0.30-1.4-5TR 23.5N <COMO> T 55.2/77.2
L26 6200003590 S.COL EXCCL3225U1 B 75.6/61.3
L27 6200001920 S.COL ELJNC R15K-F T 133.6/74.6
L31 6200007001 S.COL ELJRE 82NGFA [AUS] only T 89.9/40.4
L33 6200004480 S.COL MLF1608D R82K-T T 73.4/43.5
L35 6200012520 S.COL 0.26-1.0-5TL 12N <COMO> T 49.3/88.8
L36 6140000670 COL LR-89
L39 6200004480 S.COL MLF1608D R82K-T T 89.2/48.8
L40 6200009081 S.COL #E558CN-100025=P3 T 71.9/47.5
L41 6200004851 S.COL #E558CN-100024=P3 T 71.8/36.9
L42 6200004480 S.COL MLF1608D R82K-T T 74.3/42
L43 6200004480 S.COL MLF1608D R82K-T T 86.3/44.4
L48 6110001600 COL LA-243
L49 6150005001 S.COL LS-527-LF T 122.6/65.1
L50 6110001730 COL LA-262
L52 6200004480 S.COL MLF1608D R82K-T T 127.6/78.8
L53 6190001500 COL HK-08S070-1310
L54 6200007001 S.COL ELJRE 82NGFA [AUS] only B 102.4/52.1
L55 6200003310 S.COL ELJFC R33M-F T 110.7/41.4
L56 6200003310 S.COL ELJFC R33M-F T 113.6/36.1
L57 6200003310 S.COL ELJFC R33M-F T 110.4/28.6
L60 6200005011 S.COL NLV25T-100J T 8.9/37.5
L61 6190001510 COL HK-10S080-1210
L62 6190001500 COL HK-08S070-1310
L63 6190001500 COL HK-08S070-1310
L64 6190001500 COL HK-08S070-1310
L65 6200005011 S.COL NLV25T-100J T 3.1/31.1
L67 6200013050 S.COL 0.26-0.9-9TR 23.0N <COMO> T 50.6/82.9
L68 6200012860 S.COL 0.20-0.7-4TR 6.5N <COMO> T 49.9/94.6
L69 6200012520 S.COL 0.26-1.0-5TL 12N <COMO> T 50.5/98.8
L70 6110001520 COL LA-232
L71 6110002110 COL LA-382
L72 6200002041 S.COL NLV25T-101J B 125.8/12.4
L73 6200002041 S.COL NLV25T-101J B 112.3/6.6
L74 6200002710 S.COL ELJFC 1R8K-F B 120.6/36.7
L75 6200004480 S.COL MLF1608D R82K-T B 92/85.8
L77 6200009141 S.COL NLV25T-6R8J B 84.8/31.4
Jun. 2008
3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
L78 6190001690 S.COL ZBFS5105-PT-01 B 42.7/46.2
L79 6190001690 S.COL ZBFS5105-PT-01 B 22.2/44.5
L80 6190001690 S.COL ZBFS5105-PT-01 B 55.2/16.8
L81 6190001690 S.COL ZBFS5105-PT-01 B 44.4/13.1
L82 6200004450 S.COL ELJFC 6R8M-F T 76.2/47.1
L83 6200004880 S.COL ELJFC 3R3K-F T 83.2/45.5
L84 6200004880 S.COL ELJFC 3R3K-F T 85.7/36.9
L85 6200004450 S.COL ELJFC 6R8M-F T 77.4/38.9
L86 6190001690 S.COL ZBFS5105-PT-01 B 13.7/115.6
L87 6200006991 S.COL ELJRE 56NGFA [AUS] only B 97.2/49.5
L88 6200004480 S.COL MLF1608D R82K-T
[A110EURO] only B 95.8/7.1
L89 6130002961 S.COL #617DB-1327=P3 T 100.7/56.3
L90 6130003000 S.COL #617DB-1714=P3 , [EUR-1] only B 108.6/52.9
L91 6130003000 S.COL #617DB-1714=P3 , [EUR-1] only B 109.7/48
R1 7030006070 S.RES ERJ12YJ101U (100) B 105.4/74.2
R2 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 92.8/88.1
R3 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 88.4/88.1
R9 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 130.1/61.9
R11 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 123.4/62.2
R12 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 126.4/62.2
R13 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 118.3/62.1
R14 7030003770 S.RES ERJ3GEYJ 564 V (560 k) B 115.5/62.1
R15 7030003320 S.RES ERJ3GEYJ 101 V (100) B 123.3/65.7
R17 7030003280 S.RES ERJ3GEYJ 470 V (47) B 118.6/66.5
R18 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 112.3/62.1
R19 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 108.9/62.1
R20 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 107.2/62.1
R25 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 103.9/50.9
R30 7030003590 S.RES ERJ3GEYJ 183 V (18 k) B 120.4/41
R31 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) B 125.1/37.9
R34 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) B 133.3/19.2
R35 7030003320 S.RES ERJ3GEYJ 101 V (100) B 132.5/16.8
R36 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 131.9/14.5
R37 7030003650 S.RES ERJ3GEYJ 563 V (56 k) B 129/15.6
R38 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) B 129/11.8
R40 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 122.7/11.7
R41 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 121.9/9.6
R42 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) B 118.6/10.1
R43 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 115.9/14.3
R45 7030003650 S.RES ERJ3GEYJ 563 V (56 k) B 115.7/8.7
R46 7030003320 S.RES ERJ3GEYJ 101 V (100) B 115.7/4.5
R48 7030003650 S.RES ERJ3GEYJ 563 V (56 k) B 110.7/12.7
R49 7030003750 S.RES ERJ3GEYJ 394 V (390 k) B 112.9/14.3
R50 7030003430 S.RES ERJ3GEYJ 821 V (820) B 111.3/21.6
R59 7310004660 S.TRI EVM-2WSX80 B54 (503) T 81.2/57.9
R61 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k)
[A110EURO] B 68.1/42.1
7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) [A110] B 68.1/42.1
R62 7030003440 S.RES ERJ3GEYJ 102 V (1 k) [A110] B 76.2/25
7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
[A110EURO] B 76.2/25
R63 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 98/40.5
R64 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 81.9/25.8
R65 7030003220 S.RES ERJ3GEYJ 150 V (15) B 96.3/36.6
R66 7030003220 S.RES ERJ3GEYJ 150 V (15) B 96.3/38.1
R67 7030003220 S.RES ERJ3GEYJ 150 V (15) B 99.5/38.1
R68 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 96.3/35.1
R69 7030003700 S.RES ERJ3GEYJ 154 V (150 k) B 99.5/35.1
R70 7030003400 S.RES ERJ3GEYJ 471 V (470) B 96.3/33
R71 7030003280 S.RES ERJ3GEYJ 470 V (47) B 96.3/28.4
R72 7030003660 S.RES ERJ3GEYJ 683 V (68 k) B 93.4/39.6
R73 7030003370 S.RES ERJ3GEYJ 271 V (270) B 93.4/45.5
R74 7030003630 S.RES ERJ3GEYJ 393 V (39 k) B 99.5/42.5
R75 7030003340 S.RES ERJ3GEYJ 151 V (150) B 96.3/44.1
R76 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 96.4/52.7
R77 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 96.3/60.2
R78 7030003290 S.RES ERJ3GEYJ 560 V (56) B 97.1/54.8
R79 7030003400 S.RES ERJ3GEYJ 471 V (470) B 97.4/58.3
R80 7030003290 S.RES ERJ3GEYJ 560 V (56) B 95.5/56.2
R85 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 93.1/60.5
R86 7030003360 S.RES ERJ3GEYJ 221 V (220) B 90.8/61.5
R87 7030003330 S.RES ERJ3GEYJ 121 V (120) B 92.1/58.4
R95 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 87.2/65.1
R99 7030003270 S.RES ERJ3GEYJ 390 V (39) T 75/68.2
R101 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k)
[A110EURO] T 86.2/67.5
7030003560 S.RES ERJ3GEYJ 103 V (10 k) [A110] T 86.2/67.5
R108 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 106.4/13.5
R110 7310004530 S.TRI EVM-2WSX80 B14 (103) T 98.5/17.8
R111 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 99.6/28.2
R112 7030003270 S.RES ERJ3GEYJ 390 V (39) B 107.1/28.3
R113 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 104.2/28.3
R114 7510001571 S.TMR NTCG16 4LH 104JT T 105/26
R115 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 108.7/24.1
R116 7030003770 S.RES ERJ3GEYJ 564 V (560 k) T 111.3/17.3
R117 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 96.3/25.2
R118 7030003690 S.RES ERJ3GEYJ 124 V (120 k) T 112.1/20.7
R119 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 112.1/23.6
R120 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 107.3/20.7
R121 7310004610 S.TRI EVM-2WSX80 B15 (104) T 28.1/29.3
R122 7030003630 S.RES ERJ3GEYJ 393 V (39 k) T 112.7/14.3
R123 7030003630 S.RES ERJ3GEYJ 393 V (39 k) T 112.7/9.3
R124 7030003630 S.RES ERJ3GEYJ 393 V (39 k) T 110.6/6.5
R126 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 74.8/17.8
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
R127 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 70.1/17.5
R128 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 65.3/18.9
R131 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 53/37.6
R132 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 49.8/35.6
R148 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 87.6/84.2
R149 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 84.3/79
R150 7310004530 S.TRI EVM-2WSX80 B14 (103) T 85.3/78.9
R151 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 84.6/82.7
R152 7030003320 S.RES ERJ3GEYJ 101 V (100) B 89.8/85
R153 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 85.4/86.5
R174 7030003650 S.RES ERJ3GEYJ 563 V (56 k) B 122.7/14.3
R181 7030003700 S.RES ERJ3GEYJ 154 V (150 k) T 56.4/36.5
R182 7030003760 S.RES ERJ3GEYJ 474 V (470 k) B 106.3/34.8
R183 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 104.4/34.9
R184 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 104.9/40.8
R186 7030003700 S.RES ERJ3GEYJ 154 V (150 k) B 56.1/35.6
R187 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 57.5/35.6
R188 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 105/24.7
R192 7030003660 S.RES ERJ3GEYJ 683 V (68 k) T 89.9/45
R193 7030003400 S.RES ERJ3GEYJ 471 V (470) T 89.2/37.2
R194 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) T 86.2/48.8
R208 7030003320 S.RES ERJ3GEYJ 101 V (100) B 8.9/72.5
R209 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 8.9/69.7
R211 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 16.8/54.7
R212 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 16.8/56.1
R218 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 82.3/29.5
R219 7030000210 S.RES MCR10EZHJ 39 (390) T 47.2/106.4
R220 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 46.8/102.3
R221 7030000520 S.RES MCR10EZHJ 15 k B 47.8/101.6
R223 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 103.9/6.6
R224 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 103.9/3.9
R225 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 103.9/5.2
R226 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 100.5/7.9
R228 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 129.2/51
R229 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 115.7/47.7
R230 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 122.4/51.1
R231 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 117.9/52
R232 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 123.1/48.6
R233 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 118/49.6
R234 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 70.8/21.9
R235 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 65.8/23.6
R236 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 63.1/23.6
R237 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 63.8/25.7
R238 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 65.1/27.3
R239 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 63.4/33.1
R240 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 61.3/33.4
R241 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 55.9/31.8
R242 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 56.8/29.6
R243 7030003320 S.RES ERJ3GEYJ 101 V (100) T 96.8/29.5
R251 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 98/44.7
R256 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) T 85.5/41.8
R267 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 29.8/54.6
R273 7030003760 S.RES ERJ3GEYJ 474 V (470 k) B 29.2/71.8
R280 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 26.1/28.6
R281 7030003750 S.RES ERJ3GEYJ 394 V (390 k) T 113.4/16.5
R288 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 114.6/40.2
R289 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 128.2/61.9
R295 7030003350 S.RES ERJ3GEYJ 181 V (180) B 129/75.4
R297 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 127.4/74.3
R301 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 49.3/29.7
R321 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 27/71.3
R322 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) B 44.4/77.3
R323 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 14.9/87.1
R325 7030003370 S.RES ERJ3GEYJ 271 V (270) B 18/83.7
R327 7030003340 S.RES ERJ3GEYJ 151 V (150) B 107.6/43.4
R328 7030003650 S.RES ERJ3GEYJ 563 V (56 k) T 118/16.8
R329 7030003690 S.RES ERJ3GEYJ 124 V (120 k) T 119.3/10.7
R330 7510001000 S.TMR TBPS1R154K475H5Q T 118/10.7
R331 7030003720 S.RES ERJ3GEYJ 224 V (220 k) T 116.7/12.3
R332 7030003690 S.RES ERJ3GEYJ 124 V (120 k) T 118/13.9
R333 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 122.1/12.1
R334 7030003770 S.RES ERJ3GEYJ 564 V (560 k) T 124.9/12.1
R336 7310004590 S.TRI EVM-2WSX80 B13 (102) T 31.8/98.6
R338 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 101.2/14.1
R340 7030003410 S.RES ERJ3GEYJ 561 V (560) B 29.3/88.7
R342 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 48.8/26
R355 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 125/16.8
R356 7030003660 S.RES ERJ3GEYJ 683 V (68 k) T 114.2/19.5
R357 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 66/42.1
R358 7030003670 S.RES ERJ3GEYJ 823 V (82 k) B 75.9/56.6
R359 7030003320 S.RES ERJ3GEYJ 101 V (100) B 64.5/48.1
R361 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 25.8/67.8
R362 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k) B 57.9/44.7
R363 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 59.7/24.5
R364 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M) T 61.1/29.7
R365 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 56.2/29.7
R366 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 56.2/26.8
R367 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 62.4/29.7
R368 7030003590 S.RES ERJ3GEYJ 183 V (18 k) B 124.3/39.2
R369 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 120.2/42.3
R370 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 130.4/10.4
R371 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 122.3/13
R372 7030003320 S.RES ERJ3GEYJ 101 V (100) T 116.1/27.5
R373 7030003320 S.RES ERJ3GEYJ 101 V (100) T 114/29.6
R374 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 112.3/31.5
R375 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 113.2/27.5
R376 7030003770 S.RES ERJ3GEYJ 564 V (560 k) T 105.8/28.7
R377 7030003240 S.RES ERJ3GEYJ 220 V (22) B 119.4/64.4
Jun. 2008
4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
R379 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 58.3/35.7
R380 7030006060 S.RES ERJ12YJ100U (10) B 38/81.7
R383 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 15.7/89.3
R386 7030003700 S.RES ERJ3GEYJ 154 V (150 k) T 16.6/45.3
R387 7030003700 S.RES ERJ3GEYJ 154 V (150 k) T 20.7/44.6
R388 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 17.5/50.3
R389 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) B 18.5/41.2
R390 7030003410 S.RES ERJ3GEYJ 561 V (560) B 18.9/54.1
R391 7030003400 S.RES ERJ3GEYJ 471 V (470) B 16.8/51.9
R392 7310004670 S.TRI EVM-2WSX80 B55 (504) T 12.2/28
R393 7030003580 S.RES ERJ3GEYJ 153 V (15 k) T 6.9/17.1
R394 7030003580 S.RES ERJ3GEYJ 153 V (15 k) T 5.8/20.1
R395 7030003650 S.RES ERJ3GEYJ 563 V (56 k) T 6.6/31.5
R396 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 5.8/30.2
R397 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 8.5/30.2
R398 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 3.9/45.5
R399 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 5.2/45.5
R400 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 8.2/48
R401 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 3.7/48.1
R403 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 15.8/21
R404 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 18.9/20.2
R405 7030003650 S.RES ERJ3GEYJ 563 V (56 k) B 23.8/14.8
R406 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) B 22.9/10.6
R407 7030003700 S.RES ERJ3GEYJ 154 V (150 k) T 13/24.5
R408 7030003700 S.RES ERJ3GEYJ 154 V (150 k) T 14.9/25.2
R409 7030004890 S.RES ERJ3GEYF 434 V (430 k) T 16.3/27.9
R410 7030004860 S.RES ERJ3GEYF 184 V (180 k) T 14.8/27.9
R411 7030005260 S.RES ERJ3GEYF 394 V (390 k) T 13/25.8
R412 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 5/16.7
R413 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 6.4/14.6
R414 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 8/15.9
R415 7030003410 S.RES ERJ3GEYJ 561 V (560) B 99.5/41
R417 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 39.3/109.1
R418 7030003760 S.RES ERJ3GEYJ 474 V (470 k) B 29/113
R419 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 29/111.7
R420 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 39.6/112.4
R422 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 9.8/26.5
R423 7030003320 S.RES ERJ3GEYJ 101 V (100) B 85/76.2
R424 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 89.3/79
R425 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 88.6/76.3
R426 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 90.8/75.5
R427 7030003620 S.RES ERJ3GEYJ 333 V (33 k) T 88.7/74.6
R428 7030003380 S.RES ERJ3GEYJ 331 V (330) T 87.9/70.4
R429 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 85.4/71.8
R430 7030003570 S.RES ERJ3GEYJ 123 V (12 k) T 91.6/70.5
R431 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k)
[A110EURO] T 75.8/64.8
7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) [A110] T 75.8/64.8
R432 7030003650 S.RES ERJ3GEYJ 563 V (56 k) B 6.9/27.9
R433 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 37.6/97.5
R434 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 36.1/102.8
R435 7030000410 S.RES MCR10EZHJ 1.8 k T 70.5/68.1
R436 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 89.3/30.5
R437 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 120.6/39.7
R438 7030003400 S.RES ERJ3GEYJ 471 V (470) T 128.9/53.9
R439 7030003400 S.RES ERJ3GEYJ 471 V (470) B 116.5/53.9
R440 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 31.3/102.8
R441 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 37.8/107.8
R442 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 6.7/12.3
R443 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 10.3/15.8
R444 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 31.1/93.5
R445 7030003430 S.RES ERJ3GEYJ 821 V (820) B 9.5/83.6
R446 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) B 9.5/79.4
R447 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k) T 128.9/48.1
R448 7030003420 S.RES ERJ3GEYJ 681 V (680) B 117/47.5
R450 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 83.6/50.3
R451 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 80.5/49
R452 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 80/47.1
R453 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 80.6/43.9
R454 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 107.9/17.2
R455 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k) T 107.9/14.4
R456 7030003720 S.RES ERJ3GEYJ 224 V (220 k) T 105.1/11
R457 7030003700 S.RES ERJ3GEYJ 154 V (150 k) T 107.9/11.6
R458 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 83.5/34.8
R459 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 80.9/39.6
R460 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 81.7/37.5
R461 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 77.2/35.8
R462 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 21.8/112.9
R463 7030003760 S.RES ERJ3GEYJ 474 V (470 k) B 21.8/111.5
R464 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 12.3/110.6
R465 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 14.7/100
R466 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 18.2/103.3
R467 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 43.6/63.7
R468 7030006120 S.RES ERJ1WYJ4R7U (4.7) [EUR-1] only T 50.3/105.4
R469 7030006120 S.RES ERJ1WYJ4R7U (4.7) [EUR-1] only B 51.3/105.4
R470 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 15.8/23.7
R471 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 10.2/10.5
R472 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 19.7/22.3
R473 7030001160 S.RES MCR50JZHJ 180 (181) T 73.7/101.4
R474 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 72.9/69
R475 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 79.7/30
R476 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 98.1/10
R478 7030003670 S.RES ERJ3GEYJ 823 V (82 k) T 106.3/34.1
R479 7510001571 S.TMR NTCG16 4LH 104JT T 104.4/34.9
R484 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) B 112.2/19.3
R485 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
[A110EURO] only B 76.2/23.6
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION M. H/V
NO. NO.
LOCATION
R486 7030003420 S.RES ERJ3GEYJ 681 V (680) B 46.7/45.4
R487 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 45.8/39.5
R488 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 47.1/36.2
R489 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 46.7/37.6
R490 7030003610 S.RES ERJ3GEYJ 273 V (27 k) B 48.6/44.6
R491 7030003610 S.RES ERJ3GEYJ 273 V (27 k) B 47.2/34.4
R492 7030003610 S.RES ERJ3GEYJ 273 V (27 k) B 48.5/34.4
R493 7030003320 S.RES ERJ3GEYJ 101 V (100) T 103.8/56.8
R494 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 107/54
R498 7030003280 S.RES ERJ3GEYJ 470 V (47) T 109.1/49.8
R499 7030003320 S.RES ERJ3GEYJ 101 V (100) T 106.3/52.1
R500 7030003320 S.RES ERJ3GEYJ 101 V (100) T 107.6/52.1
R501 7030003240 S.RES ERJ3GEYJ 220 V (22) B 126.3/46.8
C1 4030011210 S.CER GRM31M2C2H330JV01L B 116.4/103.5
C2 4030011070 S.CER GRM31M2C2H5R0CY21L B 122.2/99.4
C3 4030011230 S.CER GRM31M2C2H390JV01L B 113.2/95
C4 4030011030 S.CER GRM31M4C2H1R5CY21L B 120.7/94.1
C5 4030011180 S.CER GRM31M2C2H220JV01L B 117.5/90.6
C6 4030017200 S.CER GRM31BR32J102KY01L
[A110EURO] only B 117.5/87.1
C7 4030011180 S.CER GRM31M2C2H220JV01L B 113.7/78.6
C8 4030007080 S.CER C1608 CH 1H 390J-T B 118.2/83.3
C9 4030007040 S.CER C1608 CH 1H 180J-T B 118.4/77.3
C10 4030007090 S.CER C1608 CH 1H 470J-T T 131.7/77.8
C11 4030017200 S.CER GRM31BR32J102KY01L
[A110EURO] only T 97.7/90.7
C12 4030011180 S.CER GRM31M2C2H220JV01L B 97.7/102.6
C13 4030011020 S.CER GRM31M4C2H1R0CY21L B 96.1/96.1
C14 4030011020 S.CER GRM31M4C2H1R0CY21L B 88.5/100.6
C15 4030011180 S.CER GRM31M2C2H220JV01L B 93.3/104.9
C16 4030011120 S.CER GRM31M2C2H100JV01L B 96.1/93.4
C17 4030011120 S.CER GRM31M2C2H100JV01L B 87.1/93.2
C18 4030006860 S.CER C1608 JB 1H 102K-T B 90.6/87.3
C19 4030006860 S.CER C1608 JB 1H 102K-T B 94.2/86.6
C20 4030017200 S.CER GRM31BR32J102KY01L
[A110EURO] only B 90.8/100.6
C22 4030007050 S.CER C1608 CH 1H 220J-T B 131.7/64.8
C23 4030009560 S.CER C1608 CH 1H R75B-T B 130.9/66.9
C24 4030006860 S.CER C1608 JB 1H 102K-T B 124.8/65.7
C25 4030006860 S.CER C1608 JB 1H 102K-T B 116.9/62.1
C26 4030006860 S.CER C1608 JB 1H 102K-T B 121.8/65.7
C27 4030006860 S.CER C1608 JB 1H 102K-T B 119.4/68.6
C28 4030006860 S.CER C1608 JB 1H 102K-T T 113.2/59.5
C29 4030007060 S.CER C1608 CH 1H 270J-T B 108.9/65
C30 4030006860 S.CER C1608 JB 1H 102K-T B 105.6/62.1
C31 4030009500 S.CER C1608 CH 1H 0R5B-T B 112.3/65
C32 4030007060 S.CER C1608 CH 1H 270J-T B 105.6/65.6
C33 4030009920 S.CER C1608 CH 1H 050B-T T 103.8/59.5
C34 4030006860 S.CER C1608 JB 1H 102K-T B 105/52.9
C37 4030006860 S.CER C1608 JB 1H 102K-T B 103.8/60.9
C39 4030006900 S.CER C1608 JB 1H 103K-T B 124.3/40.5
C40 4030006860 S.CER C1608 JB 1H 102K-T B 120.2/43.6
C41 4030006900 S.CER C1608 JB 1H 103K-T B 123.4/41.9
C42 4030006900 S.CER C1608 JB 1H 103K-T B 120.7/34.8
C43 4030006860 S.CER C1608 JB 1H 102K-T T 122.5/33.3
C44 4030011600 S.CER C1608 JB 1E 104K-T B 108.2/40.2
C46 4030006900 S.CER C1608 JB 1H 103K-T B 131.2/18.4
C47 4030011600 S.CER C1608 JB 1E 104K-T B 131.2/12.3
C48 4030011600 S.CER C1608 JB 1E 104K-T B 125.8/10.4
C50 4030011600 S.CER C1608 JB 1E 104K-T B 119.4/12.4
C51 4030006900 S.CER C1608 JB 1H 103K-T B 115.7/10.9
C52 4030011600 S.CER C1608 JB 1E 104K-T B 115.7/3
C53 4030006900 S.CER C1608 JB 1H 103K-T B 112.3/10.2
C54 4030006900 S.CER C1608 JB 1H 103K-T B 114.9/19.3
C55 4030006900 S.CER C1608 JB 1H 103K-T B 110.6/19.3
C56 4550007390 S.TAN F931C225MAABMA T 121.1/15.3
C58 4510008550 S.ELE EEE1HA010SR T 115.2/23.3
C59 4550000530 S.TAN TEESVA 1V 104M8R [AUS] only T 70.4/41.8
C60 4550006140 S.TAN ECST1EY474R B 77/27.1
C61 4030006860 S.CER C1608 JB 1H 102K-T B 77.4/56.6
C62 4030006860 S.CER C1608 JB 1H 102K-T T 85.1/1.7
C63 4030006860 S.CER C1608 JB 1H 102K-T B 81.9/24.2
C68 4030006860 S.CER C1608 JB 1H 102K-T B 99.5/36.6
C69 4030006860 S.CER C1608 JB 1H 102K-T B 96.3/31.5
C70 4030006860 S.CER C1608 JB 1H 102K-T B 96.3/30
C71 4030006860 S.CER C1608 JB 1H 102K-T B 99.6/29.5
C72 4030009990 S.CER C1608 CH 1H 200J-T B 93.4/38.1
C73 4030006860 S.CER C1608 JB 1H 102K-T B 93.4/44.1
C74 4030007040 S.CER C1608 CH 1H 180J-T B 99.5/39.6
C75 4030006860 S.CER C1608 JB 1H 102K-T T 87.9/37.2
C77 4030006860 S.CER C1608 JB 1H 102K-T B 96.3/45.5
C78 4030009990 S.CER C1608 CH 1H 200J-T B 99.5/50.1
C82 4030006860 S.CER C1608 JB 1H 102K-T B 94.7/58.3
C85 4030006860 S.CER C1608 JB 1H 102K-T B 93.1/62.1
C87 4030007030 S.CER C1608 CH 1H 150J-T B 88/58.2
C91 4030006860 S.CER C1608 JB 1H 102K-T B 87.2/60.5
C92 4030006860 S.CER C1608 JB 1H 102K-T B 88.9/62.4
C95 4030007060 S.CER C1608 CH 1H 270J-T B 86.4/58.2
C96 4030006860 S.CER C1608 JB 1H 102K-T B 87.2/66.6
C97 4030006860 S.CER C1608 JB 1H 102K-T B 80.2/59.8
C98 4030007030 S.CER C1608 CH 1H 150J-T T 81.1/68.2
C99 4030006860 S.CER C1608 JB 1H 102K-T T 75.8/66.1
C100 4030006860 S.CER C1608 JB 1H 102K-T T 53.7/71.3
C101 4030007070 S.CER C1608 CH 1H 330J-T T 79.6/69.8
C102 4030007050 S.CER C1608 CH 1H 220J-T T 63/74.6
C103 4030007100 S.CER C1608 CH 1H 560J-T T 54.4/80.6
