Icom IC-4088A User manual

FRS FM TRANSCEIVER
●High-performance antenna extends
communication range and quality
●14 FRS channels and 38 group codes
●Enhanced conversation privacy with
built-in voice scrambler
●Convenient rechargeable Ni-Cd battery
and rapid charger available
●Charge and use at the same time either
at home or in the car with select options
●Wide selection of optional professional
headsets and microphones available
●Splash resistant construction
for outdoor use
(Equivalent to JIS
Grade 4 Water
Resistance)
LICENSE
FREE
Professional Quality
in Personal Communications
Professional Quality
in Personal Communications

1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan Phone: [phone] Fax: [phone] Count on us!
URL: http://www.icom.co.jp/world/index.html
Printed in Japan
<Corporate Headquarters>
2380 116th Avenue N.E., Bellevue,WA 98004, U.S.A.
Phone: [phone] Fax : [phone]
URL : http://www.icomamerica.com
<Customer Service>Phone : [phone]
Communication Equipment
Himmelgeister Str. 100, D-40225 Düsseldorf, Germany
Phone: [phone] Fax : [phone]
URL : http://www.icomeurope.com
A.B.N.88 006 092 575
290-294 Albert Street, Brunswick,Victoria, 3056, Australia
Phone: [phone] Fax : [phone]
URL : http://www.icom.net.au
Unit 9, Sea St., Herne Bay, Kent, CT6 8LD, U.K.
Phone: [phone] Fax : [phone]
URL : http://www.icomuk.co.uk
Zac de la Plaine, 1, Rue Brindejonc des Moulinais
BP 5804, 31505 Toulouse Cedex, France
Phone: [phone] Fax : [phone]
URL : http://www.icom-france.com
Crta. de Gracia a Manresa Km.14,750
08190 Sant Cugat del Valles Barcelona, SPAIN
Phone: [phone] Fax : [phone]
URL : http://www.icomspain.com
146A Harris Road, East Tamaki, Auckland, New Zealand
Phone: [phone] Fax : [phone]
URL : http://www.icom.co.nz
Glenwood Centre #150-6165 Highway 17,
Delta, B.C., V4K 5B8, Canada
Phone: [phone] Fax : [phone]
URL : http://www.icomcanada.com
Icom Inc. (Japan), is an ISO9001
certification acquired company.
6F No.68, Sec. 1 Cheng-Teh Road,
Taipei, Taiwan, R.O.C.
Phone: [phone] Fax : [phone]
URL : http://www.asia-icom.com
Icom America Inc. Icom (Europe) GmbH Asia Icom Inc.
1305, Wanshang Plaza, Shijingshan Road,
Beijing, China
Phone: [phone] Fax :[phone]
URL : http://www.bjicom.com
Beijing Icom Ltd.Icom Spain S.L.
Icom (UK) Ltd.
Icom France S.a
Icom Canada
Icom (Australia) Pty. Ltd.
Icom New Zealand
Your local distributor/dealer:
Certificate Number Q14190
FRS FM TRANSCEIVER
SPECIFICATIONS
03WS0060 © 2003 Icom Inc.
• Number of channels : 14 (simplex; 462.5625–467.7125MHz)
• Mode : FM (F3E)
• Frequency stability : ±1.7kHz, ±4.0ppm
• Frequency resolution : 12.5kHz (channel spacing 25kHz)
• Battery requirements : 3 ×AA(R6) alkaline cells ;
or optional BP-202
• External power supply : 6.0V DC ±5% (with BC-149Aor CP-18A)
• Current drain (at 4.5V DC) : Less than 500mA
• Operating temperature range : –10˚C to +50˚C; +14˚F to +122˚F
• Number of CTCSS frequencies : 38 (67.0–250.3Hz)
• Weight : 200g; 7oz (includes 3 alkaline cells)
• Output power : Less than 500mW ERP
• External microphone connector : 3-conductor 2.5 (d) mm/2.2kΩ
• Sensitivity (at 12dB SINAD) : 0.158µV typical
• Audio output power : More than 100mW
at 10% distortion with an 8Ωload
• External SP connector : 3-conductor 3.5 (d) mm/8Ω
• Battery life (Tx:Rx:Standby=1:1:8) :
• Communication range* : 2 miles (approx.; Wide, open space)
* Communication range may differ depending on weather conditions, etc.
All stated specifications are subject to change without notice or obligation.
52.5mm; 2
1
/
16
in
102.5mm;
4
1
/
32
in
258.7mm;
10
3
/
16
in
115.6mm;
4
9
/
16
in
26.9mm; 1
19
/
32
in
60.5mm; 2
3
/
8
in
DIMENSIONS
Battery type Battery life
3 alkaline cells approx. 28 hrs.
Optional BP-202 approx. 10 hrs.
HM-46 : Compact and lightweight. Equipped with an earphone jack.
HM-75A : Allows you to remotely select operating channels, etc.
HM-131 : Durable body. Equipped with an earphone jack and revolving clip.
HM-128 : Light weight and compact earphone-microphone with PTT switch
that clips to your lapel.
HS-85 : For hands-free operation. Includes VOX, PTTand “one-touch”PTT with a time-out timer.
VS-1 : PTT/VOX unit. Required when using the HS-94, HS-95 and HS-97 with the transceiver.
HS-94 : Earhook headset with flexible boom microphone.
HS-95 : Behind-the-head headset with flexible boom microphone.
HS-97 : Throat microphone fits around your neck comfortably.
OPTIONS
▲HS-94
▼HS-95
▲HS-97
▲HM-131 ▲HM-128▲HM-46
SPEAKER-MICROPHONES and EARPHONE-MICROPHONE ▼VS-1
▲HS-85
CP-18A CIGARETTE
LIGHTER CABLE
Rapidly charges installed Ni-Cd battery cell assembly, BP-202. The
charger adapter and the AC adapter supplied with the BC-119N de-
pending on version. Charging time: 75 to 85 min.
6V DC, 2A output from 12V cig-
arette lighter socket with internal
DC-DC converter.
BC-149A WALL CHARGER
6V DC, 1A outputAC adapter.
Charges the BP-202, while op-
erating the radio.
BP-202 Ni-Cd BATTERY
CELLASSEMBLY
Install into the battery cell space
in the transceiver.
3.6V/700mAh
BC-145A BC-119N
AD-105
BC-119N DESKTOP CHARGER + BC-145A AC ADAPTER
+ AD-105 CHARGER ADAPTER
▲HM-75A
HEADSETS
