Icom IC-4008A User manual

SERVICE
MANUAL
UHF FM TRANSCEIVER
LPD FM TRANSCEIVER

INTRODUCTION
DANGER
ORDERING PARTS
REPAIR NOTES
This service manual describes the latest service information
for the at the time of publication.
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 5 V. Such a connection
could cause a fire hazard and/or electric.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100mW)
to the antenna connector. This could damage the trans-
ceiver's front end.
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
0910049951 PCB B-5109B IC-4008A MAIN UNIT 5 pieces
8810009780 Screw PH BO M2x6 ZK IC-4008A Chassis 10 pieces
Addresses are provided on the inside back cover for your
convenience.
1. Make sure a problem is internal before disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the transceiver is defective.
6. DO NOT transmit power into a signal generator or a sweep generator.
7. ALWAYS connect a 30 dB to 40 dB attenuator between the transceiver and a deviation meter or spectrum analyzer when
using such test equipment.
8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.
To upgrade quality, all electrical or mechanical parts and
internal circuits are subject to change without notice or oblig-
ation.
MODEL VERSION
Italy
C.S.America
SYMBOL
ITA
ITA-1
CSA
CSA-1
BODY COLOR
BLACK
YELLOW
BLACK
YELLOW
IC-4008A
IC-4008MK

TABLE OF CONTENTS
SECTION 1 SPECIFICATIONS
SECTION 2 INSIDE VIEWS
SECTION 3 DISASEMBLY INSTRUCTION
SECTION 4 CIRCUIT DESCRIPTION
4-1 RECEIVER CIRCUITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
4-2 TRANSMITER CIRCUITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
4-3 PLL CIRCUITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
4-4 POWER SUPPLY CIRCUITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
4-5 PORT ALLOCATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
SECTION 5 ADJUSTMENT PROCEDURES
5-1 PREPARATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
5-2 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
SECTION 6 PARTS LIST
SECTION 7 MECHANICAL PARTS AND DISASSEMBLY
7-1 CABINET PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
7-2 ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
SECTION 8 SEMI-CONDUCTOR INFORMATION
SECTION 9 BOARD LAYOUTS
9-1 MAIN UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1
9-2 RF UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-5
SECTION 10 BLOCK DIAGRAM
SECTION 11 VOLTAGE DIAGRAM
11-1 MAIN UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-1
11-2 RF UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-2

SECTION 1 SPECIFICATIONS
1 - 1
All stated specifications are subject to change without notice or obligation.
Number of channels
Type of emission
Frequency stability
Frequency resolution
Power supply requirements
(negative ground)
Current drain
Operating temperature range
Number of CTCSS frequency
Dimensions
(proj. not included)
Weight (included 3 cells)
Output power
Modulation system
Max. freqequency deviation
Spurious emissions
Adjacent channel power
External mic.connector
Receiving system
Intermediate frequency
Sensitivity (12 dB SINAD)
Adjacent channel selectivity
Spurious response
Intermoduration
Audio output power
External SP connector
[ITA], [ITA-1] [CSA], [CSA-1]
RECEIVER TRANSMITTER GENERAL
69 channel (simplex; 433.075–434.775)
16K0F3E
±2500 Hz (±5.7 ppm)
25 kHz
3 ×AA(R6) dry, alkaline;or optional BP-202
less than 140 mA less than 500 mA
–10˚C to +55˚C (–14˚F to +122˚F)
38 (67.0–250.3 Hz)
55.5(W) ×102.5(H) ×26.5(D) mm
23⁄16(W) ×41⁄32(H) ×11⁄32(D) inch
180 g; 7.8 oz
10 mW 500 mW
Variable reactance frequency modulation
±5.0 kHz
0.25 µW –40 dB
50 µW
more than 47 dB
3-conductor 2.5(d) mm/2.2 kΩ
Double conversion superheterodyne
1st: 21.7 MHz
2nd: 450 kHz
0.2 µV ;–14 dBµ
more than 40 dB
more than 40 dB
more than 40 dB
100 mW at 10% distortion with an 8 Ωload
2-conductor 3.5 (d) mm (1⁄8")/8 Ω

CHANNEL FREQUENCY LIST
CTCSS FREQUENCY LIST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
433.0750
433.1000
433.1250
433.1500
433.1750
433.2000
433.2250
433.2500
433.2750
433.3000
433.3250
433.3500
433.3750
433.4000
433.4250
433.4500
433.4750
433.5000
433.5250
433.5500
433.5750
433.6000
433.6250
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
433.6500
433.6750
433.7000
433.7250
433.7500
433.7750
433.8000
433.8250
433.8500
433.8750
433.9000
433.9250
433.9500
433.9750
434.0000
434.0250
434.0500
434.0750
434.1000
434.1250
434.1500
434.1750
434.2000
Channel No. Frequency (MHz) Channel No. Frequency (MHz) Channel No. Frequency (MHz)
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
434.2250
434.2500
434.2750
434.3000
434.3250
434.3500
434.3750
434.4000
434.4250
434.4500
434.4750
434.5000
434.5250
434.5500
434.5750
434.6000
434.6250
434.6500
434.6750
434.7000
434.7250
434.7500
434.7750
1
2
3
4
5
6
7
8
9
10
11
12
13
67.0
71.9
74.4
77.0
79.7
82.5
85.4
88.5
91.5
94.8
97.4
100.0
103.5
14
15
16
17
18
19
20
21
22
23
24
25
26
107.2
110.9
114.8
118.8
123.0
127.3
131.8
136.5
141.3
146.2
151.4
156.7
162.2
Channel No. Frequency (Hz) Channel No. Frequency (Hz) Channel No. Frequency (Hz)
27
28
29
30
31
32
33
34
35
36
37
38
---
167.9
173.8
179.9
186.2
192.8
203.5
210.7
218.1
225.7
233.6
241.8
250.3
OFF
1 - 2

SECTION 2 INSIDE VIEWS
2 - 1
•MAIN UNIT
•RF UNIT
T+3 Regurator
(Q28: 2SB798)
+3 Regurator
(IC6: S-81230SG)
R+3 Regurator
(Q18: 2SA1586)
CPU
(IC1: µPD753036GK)
Audio amplifier
(IC9: NJM2070M)
EEPROM
(IC3: X24C01AS)
TOP VEIW BOTTOM VEIW
1st mixer
(Q2: 2SC4226) PLL IC
(IC1: TB31202FN)
2nd IF filter
(Fl3: CFWM450E)
1st IF amplifier
(Q1: 2SC4215)
FM IF IC
(IC2: TA31136FN)
Reference oscilletor
(X1: CR-633 21.25 MHz)
VCO circuit
RF amplifier
(Q3: 2SC5194)
1st IF filter
(Fl2: FL-298)
TOP VIEW BOTTOM VIEW

SECTION 3 DISASEMBLY INSTRUCTIONS
3 - 1
A
BB
MAIN unit
RF unit
E
CD
F
H
G
•REMOVING THE REAR PANEL
Unscrew 1 screw , and 4 screws .
Remove the rear panel in the direction of the arrow.
•REMOVING THE RF UNIT
Remove 1 knob, , and unscrew 1 nut, .
Unsolder 1 point, , and then remove the RF unit.
•REMOVING THE MAIN UNIT
Unscrew 2 screws, .
Remove the PTT rubber, .
Unsolder 2 points, , and remove the MAIN unit.

4 - 1
SECTION 4 CIRCUIT DESCRIPTION
4-1 RECEIVER CIRCUITS
4-1-1 ANTENNA SWITCHING CIRCUIT (RF UNIT)
Received signals from the antenna connector are passed
through the low-pass filter (L5, L6, C8–C12). The filtered sig-
nals are applied to the λ⁄4type antenna switching circuit (D7,
D101, D102, L4, L206, C209, C210).
The antenna switching circuit functions as a low-pass filter
while receiving. However, its impedance becomes very high
while D101 and D102 are turned ON (while transmitting).
Thus transmit signals are blocked from entering the receiver
circuits. The passed signals are then applied to the RF ampli-
fier circuit.
4-1-2 RF CIRCUIT (RF UNIT)
The RF circuit amplifies signals within the range of frequen-
cy coverage and filters out-of-band signals.
The signals from the antenna switching circuit are amplified
at the RF amplifier (Q3) and passed through the bandpass fil-
ter (FI1) to suppress out-of-band signals. The filtered signals
are applied to the 1st mixer circuit (Q2).
4-1-3 1st MIXER AND 1st IF CIRCUITS (RF UNIT)
The 1st mixer circuit converts the received signals to a fixed
frequency of the 1st IF signal with a PLLoutput frequency. By
changing the PLL frequency, only desired signals will be
passed through a crystal filter at the next stage of the 1st
mixer.
The signals from the bandpass filter are mixed at the 1st
mixer circuit (Q2) with a 1st LO signal coming from the VCO
circuit to produce a 21.7 MHz 1st IF signal.The 1st IF signal
is applied to a crystal filter (FI2) to suppress out-of-band sig-
nals. The filtered 1st IF signal is applied to the IF amplifier
(Q1), then applied to the 2nd mixer circuit (IC2, pin 16).
4-1-4 2nd MIXER AND DEMODULATOR CIRCUITS
(RF UNIT)
The 2nd mixer circuit converts the 1st IF signal to a 2nd IF
signal. A double conversion superheterodyne system (which
converts receive signals twice) improves the image rejection
ratio and obtains stable receiver gain.
The 1st IF signal from the IF amplifier (Q1) is applied to the
2nd mixer section in the FM IF IC (IC2, pin 16), and is mixed
with the 2nd LO signal to be converted into a 450 kHz 2nd IF
signal.
The FM IF IC contains a 2nd mixer, quadrature detector,
noise amplifier and a limiter amplifier, etc. The PLL reference
oscillator (X1) is used for the 2nd LO signal via the PLL IC
(IC1, pins 11, 9), and is applied to pin 1 of the FM IF IC (IC2).
The mixed 2nd IF signal is output from pin 3 and passed
through the ceramic bandpass filter (FI3) to remove unwant-
ed heterodyne frequencies. It is then amplified at the limiter
amplifier section (IC2, pin 5) and applied to the quadrature
detector section (IC2, pins 10, 11) to demodulate the 2nd IF
signal into AF signals.
4-1-5 AF CIRCUIT (RF AND MAIN UNITS)
AF signals from the FM IF IC (RF unit; IC2, pin 9) are passed
through the high-pass filter (RF unit; Q15, Q16) to remove
CTCSS signals then applied to the MAIN unit via J2 pin 10 as
the “VOL” signal.
The “VOL” signal (AF signals) from the RF unit is applied to
the [VOL] control (MAIN unit; R58) to control the audio level
via the volume mute switch (Q23). The level controlled AF
signals are applied to the AF power amplifier (IC9, pin 2) to
drive an internal speaker (SP1) via the [SP] jack (J1).
•2nd IF AND DEMODULATOR CIRCUITS
Mixer
16
Limiter
amp.
2nd IF filter
450 kHz PLL IC
IC1
X1
21.25 MHz
X2
(21.25 MHz)
RSSI
IC2 TA31136FN
14 1st IF (21.7 MHz)
from Q1
"SQL" signal to the CPU pin 59
11109
87 5 3
AF signal "AF"
R+3
1911
Active
filter
FI3
Noise
detector
FM
detector
C74
C75
C76
C67 C77
C78
R51
R52 R53
R57
R58

4 - 2
• PLL circuit
Shift register
Prescaler
Phase
detector
Loop
filter Programmable
counter
Programmable
divider
X1
21.25 MHz
to the FM IF IC
(IC2, pin 1)
VCO Buffer
Q7
6
7
8STB
IC1 (PLL IC)
CK
DATA
to transmitter circuit
to 1st mixer circuit
D2
D1
9
11
14 16
Q6, D4, D5
4-1-6 SQUELCH CIRCUIT (RF AND MAIN UNITS)
(1) NOISE SQUELCH
The noise squelch circuit cuts outAF signals when no RF sig-
nals are received. By detecting noise components in the AF
signals, the squelch circuit switches the AF mute switch.
A portion of the AF signals from the FM IF IC (RF unit; IC2,
pin 9) are applied to the active filter section (RF unit; IC2, pin
8). The active filter section amplifies and filters noise compo-
nents. The filtered signals are applied to the noise detector
section and output from pin 14 as the “SQL” signal.
The “SQL” signal from IC2 (pin 14) passes through J2 pin 9,
and is then applied to the CPU (MAIN unit; IC1, pin 59). The
CPU analyzes the noise condition and outputs the “RMUT”
and “AFON” signals to toggle the volume mute (MAIN unit;
Q23) and AF mute (MAIN unit; Q5, Q10, Q11) switches.
(2) TONE SQUELCH
The tone squelch circuit detects AF signals and opens the
squelch only when receiving a signal containing a matching
subaudible tone (CTCSS). When tone squelch is in use, and
a signal with a mismatched or no subaudible tone is
received, the tone squelch circuit mutes the AF signals even
when noise squelch is open.
A portion of the AF signals from the FM IF IC (RF unit; IC2,
pin 9) passes through the tone low-pass filter (MAIN unit; Q7,
Q12) to remove AF (voice) signals and is applied to the
CTCSS decoder inside the CPU (MAIN unit; IC1, pin 58) via
the “CTCIN” line to control the volume mute and AF mute
switches.
4-2 TRANSMITTER CIRCUITS
4-2-1 MICROPHONE AMPLIFIER CIRCUIT
(MAIN UNIT)
AF signals from the internal/external microphone are applied
to the microphone amplifier circuit (IC2b) via the microphone
switch (Q6). The amplified signals are passed through the
low-pass filter (IC2a) and applied to the modulation circuit in
the RF unit via J4 pin 5 as the MOD signal.
4-2-2 MODULATION CIRCUIT (RF UNIT)
The filtered audio signals from J4, pin 5 (On the MAIN unit)
are passed through the deviation adjustment pot (R50) then
applied to the modulation circuit (D4, D5) to modulate trans-
mit signals at the VCO circuit (Q6).
The modulated signal is applied to the drive amplifier circuit.
4-2-3 DRIVE/POWER AMPLIFIER CIRCUITS
(RF UNIT)
The amplifier circuit amplifies the VCO oscillating signal to
the output power level.
The amplified transmit signal is passed through the antenna
switching circuit (D6) and low-pass filter, and is then applied
to the antenna.
The modulated transmit signal is amplified at the pre-drive
and drive amplifiers (Q8, Q201) after being amplified at the
buffer amplifier (Q7). The amplified signal is power amplified
at the power amplifier (Q202) to obtain 500 mW or
(IC–4008A) 10 mW (IC–4008MK2) of RF power.
The power amplified signal is then applied to the antenna via
the low-pass filter circuits.
4-3 PLL CIRCUITS (RF UNIT)
A PLL circuit provides stable oscillation of the transmit fre-
quency and receive 1st LO frequency. The PLL output com-
pares the phase of the divided VCO frequency to the refer-
ence frequency. The PLL output frequency is controlled by
the divided ratio (N-data) of a programmable divider.
The PLL circuit consists of the VCO circuit (Q6, D4, D5). An
oscillated signal from the VCO passes through the buffer
amplifier (Q7) is applied to the PLL IC (IC1, pin16) and is
prescaled in the PLL IC based on the divided ratio (N-data).
The reference signal is generated at the reference oscillator
(X1) and is also applied to the PLLIC. The PLLIC detects the
out-of-step phase using the reference frequency and outputs
it from pin 14. The output signal is passed through the loop
filter (R45, C68) and is then applied to the VCO circuit as the
lock voltage.
If the oscillated signal drifts, its phase changes from that of
the reference frequency, causing a lock voltage change to
compensate for the drift in the oscillated frequency.

4 - 3
LINE
BATT
3V
+3V
R+3
T+3
DESCRIPTION
The voltage from the connected battery pack.
Common 3 V converted from the BATT line at
the 3V regulator circuit (IC6). The circuit outputs
the voltage regardless of the power ON/OFF
condition.
Common 3 V converted from the BATT line at
the +3V regulator circuit (Q25, D4).
Receive 3 V cotrolled by the R+3 regulator circuit
(Q18) using the “RXV” signal from CPU (IC1).
Transmit 3 V converted from the BATT line at the
T+3 regulator circuit (Q27, Q28, D5, etc.) using
the “TXV” signal coming from CPU (IC1).
Outputs data signals to the PLL IC (RF
unit; IC1).
Outputs strobe signals for the PLL IC
(RF unit; IC1).
Outputs control signal for the +3V reg-
ulator circuit (MAIN unit; Q25, D4).
Output port for the CTCSS signals.
Outputs control signal for the MIC
amplifier (IC2).
Low : While microphone amplifier is
ON.
Input port for the CTCSS decode sig-
nals.
Input port for squelch level signal.
Input ports for the control signal from
the external remote microphone.
Input port form the connected battery
pack for low battery indication.
Input port for the RSSI signal from the
FM IF IC (RF unit; IC2) to detect receiv-
ing signal strength level.
Outputs clock signal to the EEPROM
(IC3).
Outputs data signals to the EEPROM
(IC3).
Output port for power save function,
applied to VCO regurator circuit (RF
unit; Q13, Q14, D8, D9).
Outputs the R+3 regulator control sig-
nal (Q18).
Outputs the T+3 regulator control sig-
nal (Q27, Q28, D5, etc.).
Outputs control signal for LCD back-
light.
Low : While LCD backlight is ON.
Outputs internal microphone control
signal.
High : While internal PTT switch is
pushed.
Outputs MIC mute signal for RING
function.
High : While RING signals are out-
put, etc.
51
52
53
54–56
57
58
59
60
61
62
73
74
75
76
77
78
79
80
PLLDA
PLLST
POWER
CTCO0–
CTCO2
TXMOD
CTCIN
SQLIN
REMIN
BATIN
SENIN
EEPCK
EEPDA
PSC
RXV
TXV
LAMPC
MICSW
MMUTE
Pin Port Description
number name
Input port for the PTT switch from the
external mic jack (MAIN unit; J1).
Low : External PTT switch is ON.
Input port for the internal PTT switch.
Low : While PTT switch is pushed.
Input port for the [DOWN] switch.
Input port for the [UP] switch.
Input port for the [MODE] switch.
Input port for the POWER switch.
Low : While POWER switch is
pushed.
Input port for PLL unlock signal from
the PLL IC (RF unit; IC1).
Low : During unlock.
Outputs beep audio signal.
Outputs volume mute switch (Q23)
control signal.
High : While squelched
Outputs control signal for theAF ampli-
fier regulator circuit (Q5, Q10, Q11).
High: When squelch is open.
Outputs clock signal to the PLL IC (RF
unit; IC1).
31
34
35
36
37
38
45
46
48
49
50
PTT2
PTT1
DOWN
UP
MODE
POWSW
UNLK
BEEP
RMUTE
AFON
PLLCK
Pin Port Description
number name
4-4 POWER SUPPLY CIRCUITS
VOLTAGE LINE
4-5 PORT ALLOCATIONS
4-5-1 CPU (MAIN unit; IC1)

5 - 1
SECTION 5 ADJUSTMENT PROCEDURES
5-1 PREPARATION
REQUIRED TEST EQUIPMENT
EQUIPMENT
DC power supply
RF power meter
(terminated type)
Frequency counter
FM deviation meter
DC voltmeter
GRADE AND RANGE
Output voltage : 4.5 V DC
Current capacity : 1 A or more
Measuring range : 1 mW–1 W
Frequency range : 300–600 MHz
Impedance : 50 Ω
SWR : Less than 1.2 : 1
Frequency range : 0.1–600 MHz
Frequency accuracy: ±1 ppm or better
Sensitivity : 100 mV or better
Frequency range : 30–600 MHz
Measuring range : 0 to ±10 kHz
Input impedance : 50 kΩ/V DC or better
EQUIPMENT
Audio generator
Standard signal
generator (SSG)
Oscilloscope
AC millivoltmeter
External speaker
Attenuator
GRADE AND RANGE
Frequency range : 300–3000 Hz
Measuring range : 1–500 mV
Frequency range : 0.1–600 MHz
Output level : 0.1 µV–32 mV
(–127 to –17 dBm)
Frequency range : DC–20 MHz
Measuring range : 0.01–10 V
Measuring range : 10 mV–10 V
Input impedance : 8 Ω
Capacity : 300 mW or more
Power attenuation : 30 or 40 dB
Capacity : 1 W or more
CAUTION:
DO NOT transmit while SSG is
connected to the antenna connector.
to the RF test port J1
Standard signal
generator
–17 to –125 dBm
(32 mV to 0.1 µV)
Frequency
counter
FM deviation
meter Attenuator 30 dB or 40 dB
RF power meter
50 Ω/ 1–500 mW
DC power supply
4.5 V /1.0 A –
+
ENTERING THE ADJUSTMENT MODE
Turn the transceiver power OFF.
While connecting the “TEST” on the RF board to “GND”, then turn power ON.
(See location at page 5-3)
CONNECTIONS

5 - 2
5-2 ADJUSTMENT
REFERENCE
FREQUENCY
OUTPUT
POWER
FM
DEVIATION
SQUELCH
ADJUSTMENT
ADJUSTMENT ADJUSTMENT CONDITION MEASUREMENT VALUE POINT
UNIT LOCATION UNIT ADJUST
433.925000 MHz
9 mW [ITA/–1]
470 mW [CSA/–1]
±4.8 kHz
10 mV ±3 dB
Audio signal
disappears.
1
1
1
2
1
2
• Operating channel : Ch 35
• Transmitting
• Operating channel : Ch 35
• Transmitting
• Operating channel : Ch 01
• Connect an audio generator to the
[MIC] jack and set as:
1 kHz/100 mV rms
• Set an FM deviation meter as:
HPF : OFF
LPF : 20 kHz or 15 kHz
De-emphasis : OFF
Detector : (P–P)/2
• Set group No. : 01
• Transmitting
• Set group No. : OFF (– –)
• Set an audio generator output level
until the deviation is ±3.5 kHz.
• Transmitting
• Operating channel : Ch 35
• Connect an SSG to J1 on the RF unit
and set as:
Level : 0.14 µV*
(–124 dBm)
Modulation : OFF
• Receiving
• Set an SSG as :
Level : OFF
• Receiving
Top
panel
RF
RF
Front
panel
Loosely couple a fre-
quency counter to the
antenna.
Connect an RF power
meter to the RF test
port J1.
Connect an FM devia-
tion meter to the RF
test port J1.
Internal speaker
RF
RF
RF
Front
panel
C63
R206
R50
Verify
Push
and hold
[MODE]
and
[DOWN]
Verify

5 - 3
RF
GND J1
RF test por
R50
FM deviati
Reference frequency
adjustment
R206
Output power
adjustment
TEST
C63
ENTERING THE ADJUSTMENT MODE

qTurn the transceiver power OFF.
wWhile connecting the "TEST" to GND,
then turn power ON.

SECTION 6 PARTS LIST
6 - 1
IC1 1140006881 S.IC µPD753036GK-524-BE9
IC2 1110002820 S.IC NJM2100M-T1
IC3 1140004450 S.IC X24C01AS-3.0T6
IC5 1110004710 S.IC S-80928ANMP-DDR-T2
IC6 1180001150 S.IC S-81230SG-QB-T1
IC9 1110002810 S.IC NJM2070M-T1
Q1 1590000720 S.TRANSISTOR DTA144EUA T106
Q2 1590001860 S.TRANSISTOR UN9215 (TX)
Q3 1590000800 S.TRANSISTOR UN5119 (TX)
Q5 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R)
Q6 1560000840 S.FET 2SK1829 (TE85R)
Q7 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q10 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q11 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q12 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q14 1590001330 S.TRANSISTOR DTA114EUA T106
Q18 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R)
Q23 1590001390 S.FET 2SJ144-Y (TE85R)
Q25 1590002490 S.TRANSISTOR UMZ2N TR
Q27 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q28 1520000200 S.TRANSISTOR 2SB798-T2 DK
Q29 1590000680 S.TRANSISTOR DTC114EUA T106
Q101 1590002630 S.TRANSISTOR UMZ1N TR[CSA], [CSA-1] only
D2 1750000550 S.DIODE 1SS355 TE-17
D4 1750000550 S.DIODE 1SS355 TE-17
D5 1750000550 S.DIODE 1SS355 TE-17 [CSA], [CSA-1]
1790001250 S.DIODE MA2S111-(TX) [ITA], [ITA-1]
D101 1750000550 S.DIODE 1SS355 TE-17 [CSA], [CSA-1]
1790001250 S.DIODE MA2S111-(TX) [ITA], [ITA-1]
D303 1790001250 S.DIODE MA2S111-(TX)
[ITA], [ITA-1] only
X1 6050010450 S.XTAL CR-627 (5.8368 MHz)
R2 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R4 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R5 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 MΩ)
R6 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R7 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R9 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R10 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω)
R12 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R13 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R14 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R22 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R23 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R24 7030003820 S.RESISTOR ERJ3GEYJ 155 V (1.5 MΩ)
R25 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R26 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R27 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R30 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R31 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R32 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R33 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R34 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R35 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R36 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R37 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R38 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R39 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R40 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R41 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R42 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R43 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R45 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R46 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R49 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R50 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R51 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
REF ORDER DESCRIPTION
NO. NO. R52 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R53 7030003820 S.RESISTOR ERJ3GEYJ 155 V (1.5 MΩ)
R54 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R55 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R56 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R57 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R58 7210001970 VARIABLE RV-244 (RK0971110) 10KA
R60 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R61 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R62 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R63 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R64 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R65 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R66 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R67 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R68 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R69 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R70 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R71 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R72 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R74 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R76 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R77 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R78 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R79 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R80 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R81 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R86 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R87 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R88 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R89 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R90 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R94 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R95 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R96 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R97 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R98 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R99 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R100 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R101 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R102 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R103 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R105 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R106 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R108 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R110 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R112 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
[CSA], [CSA-1]
7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
[ITA], [ITA-1]
R114 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
[ITA], [ITA-1]
7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
[CSA], [CSA-1]
R115 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
[CSA], [CSA-1]
R118 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R119 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
[CSA], [CSA-1] only
R200 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
[CSA], [CSA-1] only
R201 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
[CSA], [CSA-1] only
R202 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R301 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
[ITA], [ITA-1] only
R302 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
[ITA], [ITA-1] only
C1 4030009980 S.CERAMIC C1608 JB 1H 152K-T-A
C3 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C4 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C5 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C6 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C7 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
REF ORDER DESCRIPTION
NO. NO.
S.=Surface mount
[MAIN UNIT] [MAIN UNIT]

6 - 2
C8 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C9 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C10 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C11 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C15 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C17 4550006880 S.TANTALUM TEMSVD2 0J 157M-12R
C18 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C20 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C21 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C24 4030008900 S.CERAMIC C1608 JB 1C 333K-T-A
C25 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C26 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C27 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C28 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C29 4030011280 S.CERAMIC C1608 CH 1H 271J-T-A
C31 4030008880 S.CERAMIC C1608 JB 1C 223K-T-A
C32 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C34 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C35 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C36 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C40 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C42 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C44 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C45 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C46 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C47 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C48 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C49 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C50 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C51 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C52 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C53 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C54 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C55 4510005870 S.ELECTROLYTIC ECEV1HA3R3SR
C56 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C57 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C59 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C60 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C61 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C62 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C63 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C64 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C65 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C67 4030009590 S.CERAMIC C2012 JF 1C 225Z-T-A
C71 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C72 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C73 4030008650 S.CERAMIC C1608 JB 1H 332K-T-A
C74 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C75 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C79 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C80 4510005900 S.ELECTROLYTIC ECEV0GA101SR
C81 4030008900 S.CERAMIC C1608 JB 1C 333K-T-A
C82 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C83 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C85 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C86 4030009590 S.CERAMIC C2012 JF 1C 225Z-T-A
C87 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C88 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C89 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C90 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C91 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C92 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C93 4030010760 S.CERAMIC C1608 CH 1H 331J-T-A
C94 4030010760 S.CERAMIC C1608 CH 1H 331J-T-A
C95 4030010760 S.CERAMIC C1608 CH 1H 331J-T-A
C96 4030010760 S.CERAMIC C1608 CH 1H 331J-T-A
C97 4030010760 S.CERAMIC C1608 CH 1H 331J-T-A
C98 4030010760 S.CERAMIC C1608 CH 1H 331J-T-A
J1 6450000130 CONNECTOR HSJ1102-01-540
J3 6450001060 CONNECTOR HSJ1493-01-010
J4 6510017950 S.CONNECTOR 4-175638-4
DS1 5010000120 S.LED LN1371G-(TR)
DS2 5030001580 LCD LD-BU10185J (E-10185-1)
MC1 7700002160 MICROPHON KUC3523-040245
S1 2260001900 SWITCH SW-149
REF ORDER DESCRIPTION
NO. NO.
S.=Surface mount
[MAIN UNIT]
W1 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030003860 S.JUMPER ERJ3GE JPW V
W4 7030003860 S.JUMPER ERJ3GE JPW V
W5 9001502002 WIRE 72/98/030/X98/X98
W6 7120000470 JUMPER ERDS2T0
W7 7030003860 S.JUMPER ERJ3GE JPW V
EP1 8930045510 LCD CONTACT SRCN-2045-SP-N-W
EP2 0910050341 PCB B 5161A [ITA], [ITA-1]
0910050792 PCB B 5109B [CSA], [CSA-1]
IC1 1110004150 S.IC TB31202FN (ER)
IC2 1110003200 S.IC TA31136FN (EL)
Q1 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q2 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q3 1530003620 S.TRANSISTOR 2SC5194-T1
Q6 1530003320 S.TRANSISTOR 2SC5108-Y (TE85R)
Q7 1530003320 S.TRANSISTOR 2SC5108-Y (TE85R)
Q8 1530002940 S.TRANSISTOR 2SC4228-T2 R44
Q12 1530003260 S.TRANSISTOR 2SC5006-T1
Q13 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q14 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R)
Q15 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q16 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q201 1530000372 S.TRANSISTOR 2SC3356 R24-T2B
Q202 1590002600 S.FET MRF9745 T1
D1 1790000620 S.DIODE MA77 (TX)
D2 1790000620 S.DIODE MA77 (TX)
D4 1720000640 S.VARICAP 1SV284 (TPH3)
D5 1720000640 S.VARICAP 1SV284 (TPH3)
D7 1790001260 S.DIODE MA2S077-(TX)
D8 1750000550 S.DIODE 1SS355 TE-17
D9 1750000550 S.DIODE 1SS355 TE-17
D101 1790001260 S.DIODE MA2S077-(TX)
D102 1790001260 S.DIODE MA2S077-(TX)
D103 1790001240 S.DIODE MA2S728-(TX)
FI1 2040001330 S.SAW NSVA468 (433.92MHZ)
FI2 2010002330 MONOLITH FL-298 (21.700 MHz)
FI3 2020001270 CERAMIC CFWM450E
X1 6050010480 S.XTAL CR-633 (21.250 MHz)
X2 6070000210 S.DISCRIMINATOR CDBCA450CX24
L1 6200002240 S.COIL ELJFC 2R2K-F
L3 6200004380 S.COIL LL1608-F18NK
L4 6200005670 S.COIL ELJRE 12NG-F
L5 6200008270 S.COIL 0.26-1.0-5TL 17N
L6 6200008270 S.COIL 0.26-1.0-5TL 17N
L10 6200005700 S.COIL ELJRE 22NG-F
L11 6200003640 S.COIL MLF1608K 100K-T
L12 6200003640 S.COIL MLF1608K 100K-T
L13 6200002350 S.COIL LQN 1A 27NJ04
L14 6200005720 S.COIL ELJRE 33NG-F
L15 6200007000 S.COIL ELJRE 82NG-F
L19 6200005710 S.COIL ELJRE 27NG-F
L21 6200005700 S.COIL ELJRE 22NG-F
L23 6200008430 S.COIL 0.20-1.0-4TL 15N
L25 6200002190 S.COIL MLF2012A 4R7K-T
L105 6200007000 S.COIL ELJRE 82NG-F
L201 6200005700 S.COIL ELJRE 22NG-F
L202 6200005720 S.COIL ELJRE 33NG-F
L203 6200008440 S.COIL LQN21A 8N2D04
L204 6200008440 S.COIL LQN21A 8N2D04
L205 6200006670 S.COIL ELJRE 68NG-F
REF ORDER DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER DESCRIPTION
NO. NO.
[RF BOARD]

6 - 3
L206 6200005690 S.COIL ELJRE 18NG-F
L207 6200005690 S.COIL ELJRE 18NG-F
L208 6200003640 S.COIL MLF1608K 100K-T
R1 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R2 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R3 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R4 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R5 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R6 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R7 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R10 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R12 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R16 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R19 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R25 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R27 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R29 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R30 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R31 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R32 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R33 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R34 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R35 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R36 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R37 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R45 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R50 7310003630 S.TRIMMER EVM-1XSX50 BQ4 (473)
R51 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ)
R52 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R53 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R54 7510000930 S.THERMISTOR NTCCF2012 3NH 103KC-T
R55 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R56 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R57 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R58 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R59 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R60 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R61 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R62 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω)
R64 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R65 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R66 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R67 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R68 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R69 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R70 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R71 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R72 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R73 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R74 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R75 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R76 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R83 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R86 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω)
R88 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R93 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R202 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R205 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
[ITA], [ITA-1]
7510001180 S.THERMISTOR NTCCM1608 3NH 221KC
[CSA], [CSA-1]
R206 7310003610 S.TRIMMER EVM-1XSX50 B14 (103)
R207 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R208 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R209 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R210 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R211 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω)
R212 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R213 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R301 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
[CSA], [CSA-1]
7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
[ITA], [ITA-1]
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C2 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C3 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C4 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C5 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
REF ORDER DESCRIPTION
NO. NO.
S.=Surface mount
C6 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C7 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C8 4030006970 S.CERAMIC C1608 CH 1H 060D-T-A
C9 4030010780 S.CERAMIC C1608 CH 1H 1R5C-T-A
C10 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C11 4030009470 S.CERAMIC C1608 CH 1H R75C-T-A
C12 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C15 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C16 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C17 4030008880 S.CERAMIC C1608 JB 1C 223K-T-A
C18 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C20 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C21 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C23 4030006940 S.CERAMIC C1608 CH 1H 030C-T-A
C26 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C28 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C30 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C31 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C32 4030006970 S.CERAMIC C1608 CH 1H 060D-T-A
C35 4030006910 S.CERAMIC C1608 CH 1H 0R5C-T-A
C36 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C42 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C43 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C44 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C45 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C46 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C48 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C50 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C51 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C52 4030006930 S.CERAMIC C1608 CH 1H 020C-T-A
C53 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A
C54 4030009350 S.CERAMIC C1608 CH 1H 3R5B-T-A
C55 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C56 4030006910 S.CERAMIC C1608 CH 1H 0R5C-T-A
C57 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A
C60 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C61 4030006960 S.CERAMIC C1608 CH 1H 050C-T-A
C62 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C63 4610002150 S.TRIMMER CTZ3S-10A-W1-AF
C64 4030009660 S.CERAMIC C1608 JF 1C 224Z-T-A
C65 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C67 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C68 4550006150 S.TANTALUM ECST1CY105R
C69 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
C70 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C72 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C73 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C74 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C75 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C76 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C77 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C78 4030007110 S.CERAMIC C1608 CH 1H 680J-T-A
C79 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C80 4030009660 S.CERAMIC C1608 JF 1C 224Z-T-A
C81 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C82 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C83 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C84 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C85 4510004650 S.ELECTROLYTIC ECEV1EA4R7SR
C86 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C87 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C88 4510004650 S.ELECTROLYTIC ECEV1EA4R7SR
C89 4030009880 S.CERAMIC C1608 JB 1H 682K-T-A
C90 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C91 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C92 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C93 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C95 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C96 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C100 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C102 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A
C201 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C202 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C203 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C204 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
C205 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C206 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C207 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
C208 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
C209 4030006970 S.CERAMIC C1608 CH 1H 060D-T-A
C210 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
REF ORDER DESCRIPTION
NO. NO.
[RF UNIT] [RF UNIT]

6 - 4
C211 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
J1 6910007660 CONNECTOR IMSA-9210B-1-02T
J2 6510018170 S.CONNECTOR 4-175643-4
W4 7030003860 S.JUMPER ERJ3GE JPW V
W5 7030003860 S.JUMPER ERJ3GE JPW V
W6 7030003860 S.JUMPER ERJ3GE JPW V
W8 7030003860 S.JUMPER ERJ3GE JPW V
W201 7030003860 S.JUMPER ERJ3GE JPW V
W202 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910050351 PCB B 5162A [ITA], [ITA-1]
0910050781 PCB B 5162A [CSA], [CSA-1]
REF ORDER DESCRIPTION
NO. NO.
[RF UNIT]
S.=Surface mount

SECTION 7 MECHANICAL PARTS AND DISASSEMBLY
7 - 1
Screw abbreviations A, B0, BT: Self-tapping
PH: Pan head
FH: Flat head
BiH: Bind head
NI: Nickel
SUS: Stainless
ZK: Black
SP1 2510000960 Speaker K036NA500-26A27 1
EP1 3310002090 Antenna 2045ANT 1
MP1 8210015181 Panel 2045 Front Panel-1 [ITA], [CSA] 1
8210016101 Panel 2045 Front Panel (A)-1 1
[ITA-1], [CSA-1]
MP2 8210015191 Panel 2045 Rear Panel-1 [ITA], [CSA] 1
8210016111 Panel 2045 Rear Panel (A)-1 1
[ITA-1], [CSA-1]
MP3 8110006400 Cover 2045 Rear Cover [ITA], [CSA] 1
8110006720 Cover 2045 Rear Cover (A)[ITA-1], [CSA-1] 1
MP4 8110006410 Cover 2045 Lock Cover [ITA], [CSA] 1
8110006730 Cover 2045 Lock Cover (A) [ITA-1], [CSA-1] 1
MP5 8310042680 Plate 2045 Window Plate 1
MP7 8210015220 Panel 2045 Reflector 1
MP8 8610010570 Knob N-265 1
MP9 8930045192 Seal 2045 Top Seal-2 1
MP10 8930045230 Key 2045 4-Key 1
MP11 8930045200 Button 2045 PTT Button 1
MP12 8930046990 Seal 2045 Main Seal (A) 1
MP13 8930045220 Seal 2045 BATT Seal 1
MP14 8930046280 Terminal 2045 ANT Termainal 1
MP20 8830001370 Screw 2045 VR Nut 1
MP22 8930045750 Seal O-ring (X) 1
MP23 8830000110 Screw Nut M4 1
MP24 8810009560 Screw PH BO 2x6 ZK (BT) 4
MP25 8810008640 Screw FH BO 2x4 NI-ZU (BT) 2
MP30 8810008990 Screw PH BO 2x10 ZK (BT) 1
REF. NO. ORDER NO. DESCRIPTION QTY.
7-1 CABINET PARTS
[CHASSIS PARTS]
REF. NO. ORDER NO. DESCRIPTION QTY.
[MAIN UNIT]
DS2 5030001580 LCD LD-BU10185J 1
EP1 8930045510 LCD contact SRCN-2045-SP-N-W 1
MP1 8930045331 2045 Belt clip-1 1
MP2 8820001040 2045 Screw 1
REF. NO. ORDER NO. DESCRIPTION QTY.
REF. NO. ORDER NO. DESCRIPTION QTY.
[RF UNIT]
MP1 8510011570 Case 2045 VCO Case 1
7-2 ACCESSORIES
MP1 MP2

7 - 2
UNIT abbreviation (C): CHASSIS PARTS, (RF): RF UNIT, (M): MAIN UNIT
MP1 (C)
SP1 (C)
MP10 (C)
MP12 (C)
EP1 (M)
DS2 (M)
MP7 (C)
MP5 (C)
MAIN unit
MP20 (C)
MP25 (C)
MP14 (C)
MP23 (C)
MP11 (C)
MP13 (C)
MP4 (C) MP2 (C)
MP25 (C)
MP9 (C)
MP8 (C)
RF unit
MP24 (C)
MP30 (C)
MP24 (C)
MP22 (C)
EP1 (C)
MP3 (C)
MP1 (RF)

SECTION 8 SEMI-CONDUCTOR INFORMATION
8 - 1
• DIODES
• TRANSISTOR AND FET’S
2SA1362 GR
(Symbol: AEG)
2SC4213 B
(Symbol: AB) 2SC5108 Y
(Symbol: MC)
DTA114 EU
(Symbol: 16)
UN5119
(Symbol: 6K)
UN9215
(Symbol: 8E)
DTC114 EU
(Symbol: 14) MRF9745
(Symbol: M745) UMZ1N
(Symbol: Z1) UMZ2N
(Symbol: Z2)
2SC5194
(Symbol: T88) 2SJ144 Y (Symbol: VX) 2SK1829 (Symbol: K1)
2SC4215 O
(Symbol: QO) 2SC4226 R25 (Symbol: R25) 2SC4228 R44 (Symbol: R44)
2SA1586 GR
(Symbol: SG) 2SB798 DK (Symbol: DK) 2SC3356 R24 (Symbol: R24) 2SC4081 S (Symbol: BS)
B
E
C
DTA144 EU
(Symbol: 16)
B
E
C
B
E
C
EC
B
EC
B
B
EC
S
DG
B
ECEC
B
EC
B
EC
B
EC
B
E
C
B
E
E1
B1
C2
C1
B2
E2
E1
B1
B2
C1
E2
C2
B
E
C
B
E
C
B
C
E
C
E
C
B
E
1SS355
(Symbol: A) MA2S111
(Symbol: A)
1SV284
(Symbol: TL ) MA77 (Symbol: 4B) MA2S077 (Symbol: S)
AK
MA2S728
(Symbol: B)
