INSTRUCTION MANUAL
UHF MOBILE TRANSCEIVER
iF6122D
VHF MOBILE TRANSCEIVER
iF5122D

i
IMPORTANT
READ ALL INSTRUCTIONS carefully and com-
pletely before using the transceiver.
SAVE THIS INSTRUCTION MANUAL — This
instruction manual contains important operating instructions
for the IC-F5122D VHF MOBILE TRANSCEIVER and IC-
F6122D UHF MOBILE TRANSCEIVER.
EXPLICIT DEFINITIONS
WORD DEFINITION
RWARNING! Personal injury, fire hazard or electric
shock may occur.
CAUTION Equipment damage may occur.
NOTE
If disregarded, inconvenience only. No risk
of personal injury, fire or electric shock.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom
Incorporated (Japan) in Japan, the United States, the United King-
dom, Germany, France, Spain, Russia and/or other countries.
All other products or brands are registered trademarks or trademarks
of their respective holders.

ii
PRECAUTIONS
RWARNING! NEVER connect the transceiver to an
AC outlet. This may pose a fire hazard or result in an electric
shock.
RWARNING! NEVER connect the transceiver to a
power source of more than 16 V DC or use reverse polarity.
This could cause a fire or damage the transceiver.
RWARNING! NEVER cut the DC power cable be-
tween the DC plug and fuse holder. If an incorrect connection
is made after cutting, the transceiver might be damaged.
RWARNING! NEVER place the transceiver where
normal operation of the vehicle may be hindered or where it
could cause bodily injury.
CAUTION: NEVER allow children to touch the trans-
ceiver.
CAUTION: NEVER expose the transceiver to rain,
snow or any liquids.
USE the specified microphone only. Other microphones
have different pin assignments and may damage the trans-
ceiver.
DO NOT use or place the transceiver in areas with tem-
peratures below –25°C or above +55°C, or in areas subject
to direct sunlight, such as the dashboard.
DO NOT operate the transceiver without running the ve-
hicle’s engine. The vehicle’s battery will quickly run out when
the transceiver transmits while the vehicle’s engine is OFF.
DO NOT place the transceiver in excessively dusty envi-
ronments.
DO NOT place the transceiver against walls. This will ob-
struct heat dissipation.
DO NOT use harsh solvents such as benzine or alcohol
when cleaning, as they will damage the transceiver sur-
faces.
BE CAREFUL! The transceiver will become hot when
operating continuously for long periods of time.

iii
TABLE OF CONTENTS
IMPORTANT.......................................................................... i
EXPLICIT DEFINITIONS....................................................... i
PRECAUTIONS.................................................................... ii
TABLE OF CONTENTS....................................................... iii
1 PANEL DESCRIPTION................................................1–7
 ■ Front panel ...................................................................1
 ■ Function display ...........................................................2
 ■ Programmable function keys........................................3
2 BASIC OPERATION..................................................8–14
 ■ Turning ON the power ..................................................8
 ■ Channel selection.........................................................8
 ■ Call procedure..............................................................9
 ■ Receiving and transmitting...........................................9
 ■ User Set mode ...........................................................12
 ■ Encryption function.....................................................13
 ■ Emergency transmission............................................13
 ■ Stun function ..............................................................14
 ■
Power OFF Emergency function........................................ 14
 ■ Priority A channel selection........................................14
3 CONNECTION AND MAINTENANCE ....................15–17
 ■ Rear panel connection ...............................................15
 ■ Supplied Accessories.................................................16
 ■ Mounting the transceiver ............................................16
 ■ Antenna......................................................................17
 ■ Fuse replacement ......................................................17
 ■ Cleaning .....................................................................17
 ■ Options.......................................................................17
4 COUNTRY CODE LIST .................................................18

1
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
q w
t
SpeakerFunction display (p. 2)
r
e
■Front panel
qAF VOLUME CONTROL KNOB [VOL]
Rotate the knob to adjust the audio output level.
 •Minimumaudiolevelispre-programmed.(p.12)
wUP/DOWN KEYS [CH Up]/[CH Down]
Push to select an operating channel, etc.
* The desired function can be assigned by your dealer. (p. 3)
ePOWER KEY [ ]
Push to turn the power ON or OFF.
 •ThefollowingoptionalfunctionsareavailableatpowerON:
- Automatic scan start
- Password prompt
r DEALER-PROGRAMMABLE KEYS
Required functions can be independently programmed by
your dealer. (p. 3)
tMICROPHONE CONNECTOR
Connect the supplied or optional microphone.
NEVER connect non-specified microphones. The pin assign-
ments may be different and may damage the transceiver.
DMicrophone
The supplied or optional microphone has a PTT switch and a
hanger hook.
•ThefollowingfunctionsareavailablewhenthemicrophoneisONor
OFFhook(dependingonthepreprogramming):
- Automatic scan starts when you put it ON hook.
- Scan is cancelled when you take it OFF hook.
- Scan is paused when you take it OFF hook.
- Automatically selects the Priority channel when you take it OFF
hook.
- Sets to the ‘Inaudible’ mode (mute state) when you put it ON hook.
- Sets to the ‘Audible’ mode (unmute state) when you take it OFF
hook.

2
1PANEL DESCRIPTION
■Function display
q TRANSMIT ICON
Appears while transmitting a signal.
w BUSY ICON
Appears while the channel is busy (receiving).
e SIGNAL STRENGTH ICON
Shows the relative receive signal strength level.
Weak Receive Signal level Strong
r LOW POWER ICON
Appears when low output power is selected.
tAUDIBLE ICON
➥Appears when the channel is in the ‘Audible’ (unmute)
mode.
➥
Appears when a matching signal is received.
yENCRYPTION ICON
Appears when the encryption function is activated while
operating in the digital mode.
uBELL ICON
Appears/blinks when a matching 2/5-tone or Digital ID* is
received, depending on the preprogramming.
iSCAN ICON
➥Blinks during a scan.
➥Appears when a scan channel is selected.
oALPHANUMERIC DISPLAY
Displays an operating channel number, channel name,
User Set mode contents, DTMF code, etc.
* Digital operation only
See the operating guide for details of MDC and Digital
system operations. Ask your dealer for details.
q w e r t y u i
o

3
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
■Programmable function keys
The following functions can be assigned to [UP], [DOWN],
[P0], [P1], [P2] and [P3] programmable function keys.
Consult your Icom dealer or system operator for details con-
cerning your transceivers programming.
CH UP AND DOWN KEYS
As described in the following topics, after pushing a pro-
grammed key, push [CH Up] or [CH Down] to select an op-
tion, setting, etc.
ZONE KEY
Push this key, then select the desired zone using [CH Up]/
[CH Down].
What is “zone”?— Certain channels are grouped together
and assigned to a zone, according to their intended to use.
For example, ‘Staff A’ and ‘Staff B’ are assigned to a “Busi-
ness” zone, and ‘John’ and ‘Cindy’ are assigned to a “Pri-
vate” zone.
SCAN START/STOPKEY
➥Push to start and cancel scanning operation.
 •WhenascanisstartedwiththePowerONScanorAutomatic
scan function, push this key to cancel it. The cancelled scan
resumes after the pre-programmed time period.
➥Hold down this key for 1 second to display the scan group,
then push [CH Up] or [CH Down] to select the desired
one.
SCAN ADD/DEL (TAG) KEY
➥Push to add the channel to, or delete it from, the current
scan group.
1. Push to display the scan group, then push [CH Up] or
[CH Down] to select the desired one.
2. Push to add the channel to, or delete it from, the selected scan
group.
3. Hold down for 1 second to exit the scan list selection mode.
➥While a scan is paused on a non-priority channel, push this
key to delete the selected channel from the scan group.
Depending on the setting, the cleared channel is added
to the scan group again after the scan is cancelled.

4
1PANEL DESCRIPTION
■Programmable function keys (Continued)
PRIO A/B KEYS
➥Push to select the Priority A or Priority B channel.
➥Hold down [Prio A (Rewrite)] or [Prio B (Rewrite)] for
1 second to rewrite the operating channel as Priority A or
Priority B,
MR-CH 1/2/3/4 KEYS
Push to directly select memory channel 1 to 4.
MONI (AUDI) KEY
➥Push to turn the CTCSS (DTCS) or 2/5-tone squelch mute
ON or OFF.
 •OnlyduringLMR(LandMobileRadio)operation,pushtoopen
any squelch, or deactivate any mute functions.
 •OnlyduringPMR(PrivateMobileRadio)operation,pushtoacti-
vate one or two of the following functions on each channel (de-
pendingonthepreprogramming):
- Hold down to unmute the channel (‘Audible’ mode).
- Push to mute the channel (‘Inaudible’ mode).
- After the communication is finished, push to send a ‘reset
code’ (only 5-tone operation).
NOTE: The ‘Audible’ (unmute) mode may automatically
return to the ‘Inaudible’ (mute) mode, after the pre-pro-
grammed time period.
LIGHT KEY
Push to turn ON the backlight for about 5 seconds, when the
backlight function is set to “OFF” in the User Set mode.
LOCK KEY
➥Hold down this key until “LOCK ON” is displayed to elec-
tronically lock all programmable keys except the follow-
ing:
[Moni(Audi)], [Lock], [Call] (incl. Call A and Call B), [Emergency],
[Surveillance], [Siren], [Lone Worker] and [Light].
➥When the Key Lock function is ON, hold down this key
until “LOCK OFF” is displayed to turn it OFF.
LONE WORKER KEY
Push to turn the Lone Worker function ON or OFF.
•IftheLoneWorkerfunctionisturnedON,andnooperationoccurs
during the pre-programmed time period, the Emergency function is
automatically turned ON.
HIGH/LOW KEY
Push to select the transmit output power temporarily or per-
manently, depending on the preprogramming.
•Askyourdealerfortheoutputpowerlevelforeachselection.
C.TONE CH ENT KEY
Push to enter the continuous tone channel selection mode.
Then, push [CH Up] or [CH Down] to change the tone fre-
quency/code setting. The selected channel remains set as
the continuous tone channel until another channel is desig-
nated as such.

5
1
PANEL DESCRIPTION
1
TONE/RAN CH SELECT KEY
➥While in analog mode, push to enter the continuous tone
channel selection mode. Then push [CH Up] or [CH Down]
to select a desired tone frequency/code setting. After the
selection, push this key again to set it.
➥While in digital mode, push to enter the RAN channel se-
lection mode. Then push [CH Up] or [CH Down] to select a
desired RAN code. After the selection, push this key again
to set it.
➥While in mixed (digital and analog) mode, push to enter
the continuous tone channel selection mode. Then push
[CH Up] or [CH Down] to select a desired tone frequency/
code setting. After setting, push this key to set it. After
that, the RAN channel selection mode appears. Select a
desired RAN code with [CH Up] or [CH Down]. After the
selection, push this key again to set it.
TALK AROUND KEY
Push to turn the Talk Around function ON or OFF.
•TheTalkAroundfunctionequalizesthetransmitfrequencytothe
receive frequency for transceiver-to-transceiver communication.
WIDE/NARROW KEY
Push to toggle the IF bandwidth between wide and narrow.
•Thewidepassbandwidthcanbeselectedfrom25.0or20.0kHz
using the CS-F3100D/F5120D c l o n i n g s o f t w a r e . (PMR operation
only) Ask your dealer for details.
DTMF AUTODIAL KEY
➥Push to enter the DTMF channel selection mode, then
push [CH Up] or [CH Down] to select the desired DTMF
channel.
➥After selecting the DTMF channel, push again to transmit
the selected DTMF code.
RE-DIAL KEY
Push to transmit the last-transmitted DTMF code.
•TXmemoriesareclearedafterturningOFFthetransceiver.
EMERGENCY KEY
Hold down for a specified period to transmit an emergency
call.
•Ifyouwanttocanceltheemergencycall,holddownthekeyagain,
before transmitting it.

6
1PANEL DESCRIPTION
■Programmable function keys (Continued)
CALL KEYS
Push to transmit a 2/5-tone ID code.
•Tonecalltransmissionmaybenecessarybeforeyoucallanother
station, depending on your signalling system.
•[CallA]and/or[CallB]maybeselectablewhenyoursystemem-
ploys selective ‘Individual/Group’ calls. Ask your dealer which call
is assigned to each key.
SURVEILLANCE KEY
Push to turn the surveillance function ON or OFF.
When a signal is received, or a key is pushed, while this
function is turned ON, the beeps do not sound and the LCD
backlight does not light.
SIREN
Hold down for 1 second to sound the siren.
This function can be used for situations other than an emer-
gency alert, such as a security alarm for example.
•Thesirencanonlybe stopped by turningOFFthetransceiver
power.
TX CODE ENTER KEY (PMR operation only)
Push to enter the TX code edit mode, then push [CH Up] or
[CH Down] to set a desired digit. (p. 11)
TX CODE CHANNEL SELECT KEY
➥Push to enter the TX code channel selection mode, then
push [CH Up] or [CH Down] to set a desired channel.
(p. 10)
➥While in the TX code channel selection mode, hold down
this key for 1 second to enter the TX code edit mode. Then
push [CH Up] or [CH Down] to set a desired digit. (p. 11)
TX CODE CHANNEL UP/DOWN KEYS
Push to select a TX code channel.
ID-MR SELECT KEY (PMR operation only)
➥Push to recall the received ID code.
 •Push this key, then select the ID code using [CH Up]/
[CH Down].
 •Upto5codescanbememorized.
➥ Hold down this key for 1 second to clear the selected ID
code.
ENCRYPTION KEY
While operating in the digital mode, push to turn the encryp-
tion function ON or OFF.

7
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
USER SET MODE KEY
➥Hold down for 1 second to enter the User Set mode.
 •WhileintheUserSetmode,pushthiskeytoselectanitem*,
and change the value or setting using [CH Up] or [CH Down].
*Selectable items may differ, depending on the preprogram-
ming.
➥ Hold down this key for 1 second again to exit the User Set
mode.
The User Set mode is also available via the ‘Power ON’ func-
tion. In this case, all set mode items are available. See page
12.
HOOK SCAN
When the Hook Scan function is pre-programmed, push this
key to temporarily disable the function. Push this key again to
enable the function.
Ext. CH Sel Mode KEY
Push to turn the Ext. CH Select function ON or OFF.
When the function is turned ON, memory channels can be
selected with only and external input.
When the function is turned OFF, memory channels can be
selected by pushing [CH Up] or [CH Down], and cannot be
externally controlled.
•Thisfunctionisavailablewhentheexternalunit,suchasadimmer
control is connected to the transceiver with an optional OPC-1939
or OPC-2078 cable (p. 17).
•Askyourdealerformoredetailsonexternalinputoperation.
POWER OFF EMERGENCY
While holding down this key, turn OFF the transceiver to
activate the Power OFF Emergency function. This function
makes the transceiver transmit emergency calls, even though
it appears to be powered OFF. (p. 14)

8
2BASIC OPERATION
■Turning ON the power
qPush [ ] to turn ON the power.
wIf the transceiver is programmed for a start up password,
input the digit codes as directed by your dealer.
 •Thekeysshownbelowcanbeusedforpasswordinput:
The transceiver detects numbers in the same block as identical.
Therefore “01234” and “56789” are the same.
eIf the “PASSWORD” indication does not clear after input-
ting 6 digits, the input code number may be incorrect. Turn
OFF the power and re-enter your password.
■Channel selection
There are several methods to select channels, and they may
differ, depending on your system set up.
NON-ZONE TYPE:
Toselectthedesiredoperatingchannel:
•Push[CHUp]or[CHDown].
•Pushoneof[MR-CH1]to[MR-CH4].
ZONE TYPE:
Toselectthedesiredoperatingchannel:
Push [Zone], then push [CH Up] or [CH Down].
AUTOMATIC SCAN TYPE:
Channel setting is not necessary for this type. When turning
ON the power, the transceiver automatically starts scanning.
Scanning stops when a signal is detected.
KEY
NUMBER 0
5
4
9
3
8
2
7
1
6

9
2
BASIC OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
■Call procedure
When your system employs tone signaling (excluding CTCSS
and DTCS), a call procedure may be necessary prior to voice
transmission. The tone signalling employed may be a selective
calling system which allows you to call only specific station(s),
and prevents unwanted stations from contacting you.
qSelect the desired TX code channel or 2/5-tone code, ac-
cording to your System Operator’s instructions.
 •Thismaynotbenecessary,dependingonthe preprogram-
ming.
 •Refertopages10and11forselection.
wPush [Call] (assigned to one of the dealer programmable
keys).
eAfter transmitting, the remainder of your communication
can be carried out in the normal fashion.
Selective calling Non-selective calling
■Receiving and transmitting
Receiving:
qHold down [ ] for 1 second to turn ON the power.
wPush [CH Up] or [CH Down] to select a channel.
eWhen receiving a call, rotate [VOL] to adjust the audio out-
put level to a comfortable listening level.
NOTE: Depending on the preprogramming, the transceiver
automatically transmits the microphone audio for the specified
time period*, when a matched RX code signal is received.
•HM-148GorHM-152h a n d m i c r o p h o n e is required.
* Depending on the preprogramming. Ask your dealer for details.
Transmitting:
Wait for the channel to become clear to avoid interference.
qTake the microphone OFF hook.
 •The‘Audible’modeisselected.
 •Aprioritychannelmaybeautomaticallyselected.
wWait for the channel to become clear.
 • The channel is busy when the BUSY icon appears on the LCD.
eWhile holding down [PTT], speak into the microphone at
your normal voice level.
rRelease [PTT] to return to receive.
IMPORTANT: To maximize the readability of your signal;
1. Pause briefly after pushing [PTT].
2. Hold the microphone 5 to 10 cm (2 to 4 inches) from
your mouth, then speak into the microphone at a normal
voice level.

10
2BASIC OPERATION
■Receiving and transmitting (Continued)
DTransmitting notes
•Transmitinhibitfunction
The transceiver has several inhibit functions which restrict
transmissionunderthefollowingconditions:
- The channel is in the ‘Inaudible’ (mute) mode; “ ” (Audible
icon) does not appear.
- The channel is busy. However, depending on the prepro-
grammed settings, you can transmit when the call includes
an unmatching (or matching) CTCSS (DTCS), RAN code,
or Individual or Talkgroup ID.
- The selected channel is a ‘receive only’ channel.
•Time-outtimer
If continuous transmission exceeds the pre-programmed
time-out timer limit, the transmission is cut off.
•Penaltytimer
After the transmission is cut off by the time-out timer, trans-
mission is further inhibited for the pre-programmed penalty
timer period.
•PTTIDcall
The transceiver automatically sends the 5-tone, DTMF, BIIS
or digital ANI ID code when [PTT] is pushed (at the begin-
ning of the transmission), and/or when it is released (at the
end of transmission), depending on the preprogramming.
A PTTID call also be made with the MDC 1200 signaling
system.
DTX code channel selection
If the transceiver has a key assigned to [TX Code CH Select],
the dysplay can be toggled between the operating channel
number (or name) and TX code channel number (or name).
When the TX code channel number (or name) is displayed,
[CH Up] or [CH Down] selects the TX code channel.
USING [TX CODE CH SELECT] KEY:
qPush [TX Code CH Select]— a TX code channel number
(or name) appears.
wPush [CH Up] or [CH Down] to select the desired TX code
channel.
eAfter selecting, push [TX Code CH Select] to set.
 •Returntothestand-bymode.
rPush [Call] to transmit the selected TX code.
USING [TX CODE CH UP]/[TX CODE CH DOWN] KEY:
If the transceiver has a key assigned to [TX Code CH Up] or
[TX Code CH Down], the programmed TX code channel can
be directly selected when pushed.

11
2
BASIC OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
DTX code number edit (PMR operation only)
If the transceiver has a key assigned to [TX Code CH Select]
or [TX Code Enter], TX code contents can be edited within
the allowable digits.
USING [TX CODE CH SELECT] KEY:
qPush [TX Code CH Select] to enter the TX code channel
selection mode.
 •SelectthedesiredchannelbeforeenteringtheTXcodechannel
selection mode, if necessary.
wHold down [TX Code CH Select] for 1 second to enter the
TX code edit mode.
 •Thedigittobeeditedblinks.
ePush [TX Code CH Select] to select the desired digit to be
edited.
rPush [CH Up] or [CH Down] to select the desired digit.
tPush [TX Code CH Select] to set. The digit to the right will
automatically blink.
yRepeat rand tto edit all allowable digits.
uAfter editing, push [TX Code CH Select] to set.
 •Returntothestand-bymode.
iPush [Call] to transmit.
USING [TX CODE ENTER] KEY:
qPush [TX Code Enter] to enter the TX code edit mode.
 •Thedigittobeeditedblinks.
wPush [TX Code Enter] to select the desired digit to be ed-
ited.
ePush [CH Up] or [CH Down] to select the desired digit.
rPush [TX Code Enter] to set. The digit to the right will au-
tomatically blink.
tRepeat eand rto edit all allowable digits.
yAfter editing, push [TX Code Enter] to set.
 •Returntothestand-bymode.
uPush [Call] to transmit.
DDTMF transmission
If the transceiver has a key assigned to [DTMF Autodial], the
automatic DTMF transmission function is available. Up to 8
DTMF channels are selectable.
qPush [DTMF Autodial]— a DTMF channel appears.
wPush [CH Up] or [CH Down] to select the desired DTMF
channel.
ePush [DTMF Autodial] to transmit the DTMF code.

12
2BASIC OPERATION
■User Set mode
The User Set mode can be accessed with the ‘Power ON’
function. In this case, all set mode items are selectable.
The User Set mode allows you to set seldom-changed set-
tings, and you can “customize” the transceiver operation to
suit your preferences and operating style.
NOTE: While in the User Set mode, [Up], [Down] and [P0]
activate regardless of the assigned key functions.
Entering the User Set mode:
qPush [ ] to turn OFF the power.
wWhile holding down [P1] and [P2], push [ ] to turn ON the
power.
 •Holddown[P1]and[P2]continuouslyuntil“SETMODE”ap-
pears on the display.
[P1] [P2] [ ]
eHold down [P0] for 1 second to enter the User Set mode.
 •ToexittheUserSetmode,holddown[P0]for1secondagain.
[P0]
rPush [P0] several times to select the appropriate item,
then push [Up] or [Down] to set the desired level or set-
ting.
 •SelectableSetmodeitemsareBacklight, Beep ON/OFF, Beep
Level, Ringer Level, SQL Level, AF Min Level, Mic Gain, Bat-
tery Voltage, Horn, Signal Moni, Lone Worker and System
Info.
[P0] [Up]/[Down]
tHold down [ ] for 1 second to turn OFF the power, then
ON again to return to the normal operating mode.
[ ]
The User Set mode can also be selected using a program-
mable key. Please refer to the [User Set Mode] section on
page 6 for instructions on how to use the key assigned to the
User Set mode.
[User Set Mode] can be used for the quick item selection.
Set “Enable” for the often used items with the CS-F3100D/
F5120D c l o n i n g s o f t w a r e .

13
2
BASIC OPERATION
2
■Emergency transmission
When [Emergency] is held down for the specified time pe-
riod*, the emergency signal is transmitted on the specified
emergency channel once or repeatedly.
When no emergency channel is specified, the call is transmit-
ted on the operating channel.
The repeat emergency signal is automatically transmitted
until you turn OFF the power.
Depending on the preprogramming, receiving a matching
5-tone code cancels the transmission.
If you want to cancel the Emergency function, hold down
[Emergency] for the pre-programmed time period again be-
fore transmitting the call.
If your transceiver is programmed for Silent operation, you
can transmit emergency calls without the beep sounding and
the LCD indication change.
IMPORTANT: It is recommended to set an emergency
channel individually to provide the certain emergency call
operation.
DNOTES
Depending on the preprogramming, the following functions
are automatically activated. Ask your dealer for details.
•AutoTXfunction
After the emergency call transmission, audio from the micro-
phone is automatically transmitted for a specified time pe-
riod.*
•TheHM-148GorHM-152handmicrophoneisrequired.
•AutoRXfunction
After the emergency call transmission, the transceiver stands
by in the audible mode for the specified time period.*
* Depending on the preprogramming. Ask your dealer for de-
tails.
■Encryption function
The encryption function provides private communication be-
tween stations while operating in the digital mode.
qPush [Encryption] to turn ON the encryption function.
 •“ ” (Encryption icon) appears.
wPush [Encryption] again to turn OFF the encryption func-
tion.
 •“ ” disappears.

14
2BASIC OPERATION
■Stun function
The dispatcher can send a 2/5-tone signal that will stun, kill
or revive your transceiver.
When the Stun ID is received, a beep sounds*, and the trans-
ceiver becomes unusable. Receiving a Revive command or
entering password* (p. 8) is necessary to operate the trans-
ceiver again in this case.
When the Kill ID is received, a beep sounds*, and the trans-
ceiver becomes unusable (the transceiver switches to the
cloning required condition). Cloning the transceiver is neces-
sary to operate the transceiver again in this case.
* Depending on the preprogramming. Ask your dealer for de-
tails.
See the operating guide for details of the Stun function
with the MDC and Digital system operations. Ask your
dealer for details.
■ Power OFF Emergency function
When the transceiver has a key assigned to Power OFF
Emergency, you can use the function.
This function makes the transceiver transmit emergency
calls, even though it appears to be powered OFF.
To activate the Power OFF Emergency function, turn the
power OFF while holding down [Power OFF Emergency].
When the function is activated, any key operation, the ON/
OFF Hook and Lone Worker functions become invalid. The
beep, display and speaker are turned OFF as well.
On the other hand, the transceiver can transmit emergency
calls according to the pre-programmed emergency settings.
Depending on the pre-programmed settings, the Remote
Monitor function can also be used (digital operation only).
To cancel the Power OFF Emergency function and restore
the transceiver, turn the power ON.
■Priority A channel selection
When one of the following operations is performed, the trans-
ceiver automatically selects the Priority A channel.
•TurningONthepower
The Priority A channel is selected each time the transceiver
power is turned ON.
•AutoReset
The Priority A channel is selected when the Auto Reset
timer ends.
•OFFhook
The Priority A channel is selected when you take the micro-
phone OFF hook.

15
3
CONNECTION AND MAINTENANCE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
e
r
Antenna
Black
Red
12V
Battery
Solder
Crimp
NOTE: Use the terminals as shown
for the cable connections.
qANTENNA CONNECTOR
Connect to an antenna. Ask your
dealer about antenna selection
and placement.
qw
wEXTERNAL SPEAKER JACK
Connect to a 4 to 8 øexternal speaker.
eMICROPHONE HANGER
Connect the supplied micro-
phone hanger to the vehicle’s
ground for microphone ON/OFF
hook functions. (See page 1)
r
OPTIONAL CABLE (OPC-1939, OPC-2078 )
t
tDC POWER RECEPTACLE
Connect to a 12 V DC battery.
Pay attention to polarities.
Optional speaker
Connect an external modem, dimmer
control, etc.
NOTE: No Digital Modulation “IN” using
accessory cables.
RWARNING! NEVER connect
to a 24 V battery. This could
damage the transceiver.
RWARNING! NEVER remove the
fuse-holders from the DC power cable.
■Rear panel connection

16
3CONNECTION AND MAINTENANCE
■Supplied Accessories ■Mounting the transceiver
The universal mounting bracket supplied with your trans-
ceiver allows overhead mounting.
•Mountthetransceiversecurelywiththefoursuppliedscrews
to a thick surface which can support more than 1.5 kg.
Flat washer
Felt*
Spring washer
When using
self-tapping screws *Felt reduces the effects of vibration.
Microphone Microphone hanger
and screw set
Microphone
hanger cable
DC power cable
Flat washers
Spring washers Bracket bolts
Mounting screws
(5×12)
Self-tapping screws
(5×20)
Nuts
Function name
stickers*
Used for labelling the programmable function
keys according to their assinged functions.
*
Mounting bracket
