Icom IC-M1V User manual

S-13603MZ-CD-q
' 2000 Icom Inc.
6-9-16, Kamihigashi, Hirano-ku, Osaka 547-0002, Japan
Count on us!
VHF MARINE TRANSCEIVER
im1v
im1
euro v

INTRODUCTION
This service manual describes the latest service information for
the IC-M1V/IC-M1EURO V VHF MARINE TRANSCEIVER at
the time of publication.
To upgrade quality, all electrical or mechanical parts and inter-
nal circuits are subject to change without notice or obligation.
DANGER
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 10 V. This will ruin the
transceiver.
DO NOT expose the transceiver to rain, snow or any liq-
uids.
DO NOT reverse the polarrities of the power supply when
connecting the tranceiver.
DO NOT apply an RF signal of more than 20 dBm (100
mW) to the antenna connector. This could damage the
transceiver s front end.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
1140003830 S.IC TC4W66F IC-M1V MAIN UNIT 1 piece
8930051080 2320 Key board IC-M1EURO V CHASSIS 5 pieces
Addresses are provided on the inside back cover for your
convenience.
REPAIR NOTES
1. Make sure a problem is internal before disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the transceiver is defective.
6. DO NOT transmit power into a signal generator or a sweep generator.
7. ALWAYS connect a 40 dB or 50 dB attenuator between the transceiver and a deviation meter or spectrum analyzer when
using such test equipment.
8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.
MODEL VERSION SYMBOL
S.E.Asia
IC-M1V
IC-M1EURO V
USA
SEA
U.S.A.
Italy
Europe
United Kingdom
Germany
ITA
EUR
UK
FRG
6-9-16, Kamihigashi, Hirano-ku, Osaka 547-0002, Japan
Phone : [phone]
Fax : [phone]
URL : http://www.icom.co.jp/world/index.html
Communication Equipment
Himmelgeister Str. 100, D-40225 D sseldorf, Germany
Phone: [phone] Fax : [phone]
URL : http://www.icomeurope.com
Unit 9, Sea St., Herne Bay, Kent, CT6 8LD, U.K.
Phone: [phone] Fax : [phone]
URL : http://www.icomuk.co.uk
Zac de la Plaine, Rue Brindejonc des Moulinais
BP 5804, 31505 Toulouse Cedex, France
Phone: [phone] Fax : [phone]
URL : http://www.icom-france.com
Crta. de Gracia a Manresa Km. 14,750
08190 Sant Cugat del Valles Barcelona, SPAIN
Phone: [phone] Fax : [phone]
URL : http://www.icomspain.com
<
Corporate Headquarters
>
2380 116thAvenue N.E., Bellevue, WA 98004, U.S.A.
Phone: [phone] Fax : [phone]
URL : http://www.icomamerica.com
<
Customer Service
>
Phone: [phone]
Glenwood Centre #150-6165
Highway 17 Delta, B.C., V4K 5B8, Canada
Phone: [phone] Fax : [phone]
URL : http://www.icomcanada.com
A.C.N. 006 092 575
290-294 Albert Street, Brunswick, Victoria, 3056, Australia
Phone: [phone] Fax : [phone]
URL : http://www.icom.net.au
6F No. 68, Sec. 1 Cheng-Teh Road, Taipei, Taiwan, R.O.C.
Phone: [phone] Fax : [phone]

TABLE OF CONTENTS
SECTION 1 SPECIFICATIONS
VHF MARINE CHANNEL LIST ....................................................................................... 1 - 2
SECTION 2 INSIDE VIEWS
SECTION 3 DISASSEMBLY AND OPTION INSTRUCTIONS
SECTION 4 CIRCUIT DESCRIPTION
4 - 1 RECEIVER CIRCUITS ................................................................................................... 4 - 1
4 - 2 TRANSMITTER CIRCUITS ............................................................................................ 4 - 2
4 - 3 PLL CIRCUIT................................................................................................................... 4 - 3
4 - 4 POWER SUPPLY CIRCUITS ......................................................................................... 4 - 3
4 - 5 CPU PORT ALLOCATIONS ........................................................................................... 4 - 4
SECTION 5 ADJUSTMENT PROCEDURES
5 - 1 PREPARATION................................................................................................................ 5 - 1
5 - 2 PLL AND TRANSMITTER ADJUSTMENTS.................................................................... 5 - 3
5 - 3 RECEIVER ADJUSTMENT ............................................................................................ 5 - 4
5 - 4 TRIMMER ADJUSTMENT .............................................................................................. 5 - 5
5 - 5 ATIS ADJUSTMENT ....................................................................................................... 5 - 5
SECTION 6 PARTS LIST
SECTION 7 MECHANICAL PARTS AND DISASSEMBLY
AD-95 INFORMATION .................................................................................................... 7 - 3
SECTION 8 SEMI-CONDUCTOR INFORMATION
SECTION 9 BOARD LAYOUTS
9 - 1 CHARGE UNIT (AD-95) .................................................................................................. 9 - 1
9 - 2 RF AND VR UNITS.......................................................................................................... 9 - 2
9 - 3 MAIN UNIT ..................................................................................................................... 9 - 4
SECTION 10 BLOCK DIAGRAM
SECTION 11 VOLTAGE DIAGRAM
11 - 1 RF UNIT......................................................................................................................... 11 - 1
11 - 2 MAIN UNIT .................................................................................................................... 11 - 2

1 - 1
SECTION 1 SPECIFICATIONS
All stated specifications are subject to change without notice or obligation.
Frequencycoverage
Mode
Power supply requirement
Usable temperature
Frequency stability
at 5 W
at 1 W
at maximum audio
at stand-by
Antenna impedance
Dimensions
(Projections not included)
Weight
(with antenna and BP-215)
RF output power (at 7.4 V DC)
Modulation system
Max. frequency deviation
Spurious emissions
Adjacent channel power
Residual modulation
Audio harmonic distortion
Microphone impedance
Receive system
Intermediate frequencies
Sensitivity
Squelch sensitivity
Adjacent channel selectivity
Spurious response
Intermodulation
Hum and noise
Audio output power ( at 7.4 V)
Audio frequency response
EIA-152C/204D EN301-178
RECEIVER TRANSMITTER GENERAL
Tx: 156.025 MHz–157.425 MHz Tx: 156.025 MHz–157.425 MHz
Rx: 156.025 MHz–163.275 MHz Rx: 156.025 MHz–162.025 MHz
16K0G3E (FM)
BP-215 (7.4 V DC)
–10 ˚C to +60 ˚C (+14˚F to +140˚F) –15 ˚C to +55 ˚C (+5˚F to +131˚F)
± 10 ppm ± 1.5 kHz
1.5 A max.
0.7 A max.
200 mA
20 mA
Type SMA / 50 Ω
52.5(W) ×129(H) ×30(D) mm; 21⁄16(W) ×53⁄32(H) ×13⁄16(D) inch (with BP-215)
285 g; 10.1 oz
5 W / 1 W / 0.5 W (High / Low / Extra low)
Variable reactance frequency modulation
± 5.0 kHz
65 dB 250 nW
60 dB
40 dB
Less than 10 % at 60 % deviation
2 kΩ
Double-conversion super heterodyne
1st: 21.70 MHz, 2nd: 450 kHz
0.35 µV at 12 dB SINAD 0.5 µV at 12 dB SINAD
0.35 µV 0.5 µV
70 dB (typical) 70 dB
70 dB (typical) 70 dB
70 dB (typical) 68 dB
40 dB
350 mW typical at 10 % distortion 200 mW at 10 % distortion
with an 8 Ωload with an 8 Ωload
–3 dB to +1 dB of –6 dB octave from 300 Hz to 3000 Hz
Current drain
(with BP-215)
Tx
Rx

1 - 2
*1Low power only, *2Momentary high power, *3Receive only
NOTE: Channels 3, 21, 23, 61, 64, 81, 82 and 83 CANNOT be used by the general public in USA waters.
CAN
21A
22A
23
24
25
26
27
28
60
61A
62A
64
64A
65A
66A*1
67
68
69
70*3
71
72
CAN
73
74
77*1
78A
79A
80A
81A
82A
83
83A
84
85
86
87
88
CAN
01
02
03
04A
05A
06
07A
08
09
10
11
12
13*1
14
15*1
16
17*1
18A
19A
20*1
21
‘‘VHF MARINE CHANNEL LIST
USA
01A
03A
05A
06
07A
08
09
10
11
12
13*2
14
15*2
16
17*1
18A
19A
20
20A
INT
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15*1
16
17
18
19
20
21
Transmit
156.050
156.050
156.100
156.150
156.150
156.200
156.200
156.250
156.250
156.300
156.350
156.350
156.400
156.450
156.500
156.550
156.600
156.650
156.700
156.750
156.800
156.850
156.900
156.900
156.950
156.950
157.000
157.000
157.050
Receive
160.650
156.050
160.700
160.750
156.150
160.800
156.200
160.850
156.250
156.300
160.950
156.350
156.400
156.450
156.500
156.550
156.600
156.650
156.700
156.750
156.800
156.850
161.500
156.900
161.550
156.950
161.600
157.000
161.650
USA
21A
22A
23A
24
25
26
27
28
61A
63A
64A
65A
66A
67*2
68
69
70*3
71
72
INT
22
23
24
25
26
27
28
60
61
62
63
64
65
65A
66
66A
67
68
69
70*3
71
72
Transmit
157.050
157.100
157.100
157.150
157.150
157.200
157.250
157.300
157.350
157.400
156.025
156.075
156.075
156.125
156.125
156.175
156.175
156.225
156.225
156.275
156.275
156.325
156.325
156.375
156.425
156.475
156.525
156.575
156.625
Receive
157.050
161.700
157.100
161.750
157.150
161.800
161.850
161.900
161.950
162.000
160.625
160.675
156.075
160.725
156.125
160.775
156.175
160.825
156.225
160.875
156.275
160.925
156.325
156.375
156.425
156.475
156.525
156.575
156.625
USA
73
74
77*1
78A
79A
80A
81A
82A
83A
84
84A
85
85A
86
86A
87
87A
88
88A
INT
73
74
77
78
79
80
81
82
83
84
85
86
87
88
Transmit
156.675
156.725
156.875
156.925
156.925
156.975
156.975
157.025
157.025
157.075
157.075
157.125
157.125
157.175
157.175
157.225
157.225
157.275
157.275
157.325
157.325
157.375
157.375
157.425
157.425
Receive
156.675
156.725
156.875
161.525
156.925
161.575
156.975
161.625
157.025
161.675
157.075
161.725
157.125
161.775
157.175
161.825
157.225
161.875
157.275
161.925
157.325
161.975
157.375
162.025
157.425
Channel No. Frequency (MHz) Channel No. Frequency (MHz) Channel No. Frequency (MHz)
WX01
WX02
WX03
WX04
WX05
Transmit
Receive only
Receive only
Receive only
Receive only
Receive only
Receive
162.550
162.400
162.475
162.425
162.450
WX06
WX07
WX08
WX09
WX10
Transmit
Receive only
Receive only
Receive only
Receive only
Receive only
Receive
162.500
162.525
161.650
161.775
163.275
Frequency (MHz) Frequency (MHz)
Weather
channel Weather channel
‘‘WX CHANNEL LIST ([IC-M1V] only)

PLL reference crystal
(X1: CR-659, 21.25 MHz)
1st IF filter
(FI1, FI2: FL-310, 21.7 MHz)
1st mixer
(Q14: 3SK166)
IF amplifier
(Q15: 2SC2714Y)
PLL IC
(IC1: µPD3140GS)
VCO circuit
VCO
(Q4, Q5: 2SC4226)
Power amplifier
(Q11: 2SK2974)
2-1
SECTION 2 INSIDE VIEWS
• MAIN UNIT
Top view Bottom view
• RF UNIT
CPU
(IC9: HD6433835SC94H)
CPU system clock
(X2: CR-610, 7.9872 MHz)
IF filter
(FI1, FI2: SFPC450E T001, 450 kHz)
IF discreminator crystal
(X1: CDBCA450CX24, 450 kHz)
FM IF IC
(IC1:TA431136FN (D, EL))
AF analog switch
(IC5: BU4066BCFV)
Microphone amplifier
(IC4: NJM2902V)
Microphone
(MC1: KUB2823-013280)
AF amplifier
(IC2: NJM2073M)
EEROM
(IC7: HN58X2432TI)

3-1
SECTION 3 DISASSEMBLY AND OPTION INSTRUCTIONS
• Removing the Rear panel • Removing the MAIN unit
• Removing the RF unit • Install the optional unit (UT-98 or UT-112) to the
connector (MAIN unit ; J3)
Unscrew 2 screws A(2 ×20 mm), and 4 screws
B(2 ×5 mm, black) from the rear panel. qUnscrew 7 screws C(2 ×3.5 mm, silver) from
the MAIN unit.
wUnplug J1 to separate the rear panel and the
MAIN unit.
qRemove connector cap.
wRemove 2 knobs, and unscrew 3 nuts (F, G, H)
eUnscrew 3 screws D(2 ×3.5 mm, silver), and 2 screws
E(2 ×5 mm, black) from the RF unit.
rUnscrew 1 screw J(2 ×5 mm, black), and remove 1
washer I.
tTake off the RF unit in the direction of the arrow.
Front panel
Rubber
A
B
B
J2
Rear panel
CCC
Rear panel
MAIN unit
J1
J1
RF unit
VR unit
Knob
Connector cap
E
D
J
I
GF
H
MAIN unit bottom view
UT-98 or UT-112
J3
NOTE : Once the front panel is removed, grease must be
applied to areas before assembly.
Manufacture : Shin-Etsu Chemical
Type : G-501
CAUTION :
DO NOT guarantee the waterproof construction when
installing the optional unit except distributors or dealers.

4 - 1
SECTION 4 CIRCUIT DESCRIPTION
4-1 RECEIVER CIRCUITS
4-1-1 ANTENNA SWITCHING CIRCUIT (RF UNIT)
The antenna switching circuit functions as a low-pass filter
while receiving and as resonator circuit while transmitting.
The circuit does not allow transmit signals to enter receiver
circuits.
Received signals from the antenna connector pass through
the low-pass fileter (L15–L17, C72–C77, C79) and antenna
switching circuit (D11, D12). The filtered signals are then
applied to the RF amplifier circuit (Q13).
4-1-2 RF AND 1ST MIXER CIRCUITS (RF UNIT)
The 1st mixer circuit converts the received signals to a fixed
frequency of the 1st IF signal with a PLL output frequency.
By changing the PLL frequency, only the desired frequency
will be passed through a pair of crystal filters at the next
stage of the 1st mixer.
The signals from the antenna switching circuit are passed
through the tunable bandpass filter (D13, D14) and amplified
at the RF amplifier (Q13). The amplified signals are passed
through another tunable bandpass fileter (D15–D18), and
then applied to the 1st mixer circuit (Q14).
The filtered signals are mixed at the 1st mixer (Q14) with a
1st LO signal coming from the PLL circuit to produce a 21.7
MHz 1st IF signal. The 1st IF signal is passed through a pair
of crystal filters (FI1, FI2) and is then amplified at the IF
amplifier (Q15).
4-1-3 2ND IF AND DEMODULATOR CIRCUITS
(MAIN AND RF UNITS)
The 2nd mixer circuit converts the 1st IF signal to a 2nd IF
signal. A double convertion superheterodyne system (which
converts receive signal twice) improves the image rejection
and obtain stable receiver gain.
The 1st IF signal is applied to a 2nd mixer section of the FM
IF IC (MAIN unit; IC1, pin 16). The signal is then mixed with
a 2nd LO signal for conversion into a 450 kHz 2nd IF signal.
IC1 contains the 2nd mixer, limiter amplifier, quadrature
detector and active filter circuits.A 21.25 MHz 2nd LO signal
is produced at the PLL circuit using the reference frequency.
The 2nd IF signal from the 2nd mixer (MAIN unit; IC1, pin 3)
passes through ceramic filters (MAIN unit; FI1 and FI2) to
remove unwanted heterodyned frequencies. It is then ampli-
fied at the limiter amplifier section (MAIN unit; IC1, pin 5)
and applied to the quadrature detector section (MAIN unit;
IC1, pin 10 and 11) to demodulate the 2nd IF signal into AF
signals.
4-1-4 AF CIRCUIT (MAIN UNIT)
AF signals from the FM IF IC (IC1, pin 9) are fed to the
optional voice scrambler unit to demodulate scrambled
audio or are bypassed around the unit via the analog switch
(IC5).
The AF signals (detected signals) are passed through the
analog switch (IC5, pins 8 and 9) and are then applied to the
active low-pass filter (IC4c, pins 9 and 8).
The filtered AF signals are applied to and adjusted audio
level at the [VOL] control (VR unit; R1). The level controlled
signals are passed through another analog switch (IC3, Q3)
which is controlled by “SPSEL” signal from the CPU (IC9,
pin 83). The passed signals are applied to the AF power
amplifier (IC2), and then output to the internal speaker or
[EXT SP] jack.
Mixer
16
IF amp.
2nd IF filter
450 kHz
PLL IC
IC1
X1
21.25 MHz
RF unitMAIN unit
RSSI
IC1 TA31136FN(D)
14 "IF" (1st IF signal: 21.7 MHz)
from RF unit, Q15
"SD" signal to the CPU (pin 98)
11
10
9
87 5 3
217 16
Active
filter
FI1, FI2
Noise
detector
FM
detector Noise
comp.
"NOIS" signal to the CPU (pin 99)
12
C10
C12
R7
C13
C4 C3
C2
R3
R4 R5
AF signal "DET"
2nd
R6
X1
450 kHz R4V
R1
2ND IF AND DEMODULATOR CIRCUITS

4 - 2
4-1-5 SQUELCH CIRCUIT (MAIN UNIT)
The noise squelch circuit cuts out AF signals when no RF
signals are received. By detecting noise components in the
AF signals, the squelch circuit switches the AF mute switch.
Aportion of theAF signals from the FM IF IC (IC1, pin 9) are
applied to the active filter section (IC1, pin 8). The active fil-
ter section amplifies and filters noise components. The fil-
tered signals are applied to the noise detector section and
output from IC1 (pin 14) as the “NOIS” signal.
The “NOIS” signal from IC1 (pin 14) is applied to the CPU
(IC9, pin 99) to analyze the noise condition. The “SQLV” sig-
nal from R1 (VR unit) is applied to the CPU (IC9, pin 95) to
detect squelch level. The CPU detects the receiving signal
strength and cut the AF signal line.
4-2 TRANSMITTER CIRCUITS
4-2-1 MICROPHONE AMPLIFIER CIRCUIT
(MAIN UNIT)
The microphone amplifier circuit amplifies audio signals with
+6 dB/octave pre-emphasis characteristics from the micro-
phone to a level needed for the modulation circuit.
TheAF signals from the microphone are passed through the
pre-emphasis circuit (R31, C36) and are then applied to the
microphone amplifier (IC4d). The amplified AF signals are
applied to the optional voice scrambler unit to scramble the
audio via the “MICOUT” signal, or are bypassed around the
unit via an analog switch (IC5, pin 4).
TheAF signals which bypassed or passed through the voice
scrambler unit are amplified again at the limiter-amplifier
(IC4a) and then passed through the low-pass filter (IC4b,
pins 6 and 7). The filtered audio is applied to the RF unit as
the “MOD” signal.
4-2-2 MODULATION CIRCUIT (RF UNIT)
The modulation circuit modulates the VCO oscillating signal
(RF signal) using the microphone audio signals.
The audio signals “MOD” change the reactance of D4 to
modulate an oscillated signal at the transmitter VCO (Q4,
Q5). The oscillated signal is amplified at the buffer-amplifiers
(Q6, Q8).
4-2-3 DRIVE/POWER AMPLIFIER CIRCUITS
(RF UNIT)
The signal from the VCO circuit passes through the trans-
mit/receive switching circuit (D7, D8) and is applied to the
buffer-amplifier (Q9). The amplified signal is amplified by the
pre-driver (Q10) and the power amplifier (Q11) to obtain 5 W
of RF power (at 7.4 V). The amplified signal passes through
the antenna switching circuit (D9), and low-pass filter
(L15–L17, C72–C77, C79) and is then applied to the anten-
na connector.
The bias current of the power amplifier (Q11) is controlled by
the APC circuit to stabilize the output power.
4-2-4 APC CIRCUIT (RF AND MAIN UNITS)
The APC circuit provides stable output power from the
power amplifier even when the input voltage or temperature
changes, and, selects HIGH, LOW or EXTRA LOW output
power. The APC circuit consists of an APC sensor and APC
control circuits.
• APC SENSOR CIRCUIT (RF UNIT)
The APC sensor circuit (D10, C80, C81, R53, R54) detects
the transmit output power level and converts it to DC voltage
as an “TXDET” signal. The detected signal is applied to the
APC control circuit on the MAIN unit.
• APC CONTROL CIRCUIT (MAIN UNIT)
The “TXDET” signal from the APC sensor circuit is applied
to the CPU (IC9, pin 96) to control the input voltage of the
pre-driver (RF unit; Q10) and the power amplifier (RF unit;
Q11). When the output power changes, the CPU (IC9) out-
puts “POWCON” signal to the D/A converter (RF unit; IC2).
And then “POWCON” signal controls the APC controller (RF
unit; IC3) to provide stable output power.
I. sens
Q10
IC3
APC ctrl
To 1st IF circuit
PWR amp.
Pre-Drive
D10, C80
Q11 D9
D11
Ant SW
Ant
D12
+
"POWCON" signal
from IC2 (pin 6)
"TXDET" signal
to CPU (pin 96)
"HV"
"T4V"
PWR det.
TX
RX
APC CIRCUIT

4 - 3
4-3 PLL CIRCUIT (RF UNIT)
A PLL circuit provides stable oscillation of the transmit fre-
quency and receive 1st LO frequency. The PLL output com-
pares the phase of the divided VCO frequency to the refer-
ence frequency. The PLL output frequency is controlled by
the divided ratio (N-data) of a programmable divider.
The PLL circuit contains a VCO (Q4, Q5, D4, D6). The oscil-
lated signal is amplified at the buffer-amplifiers (Q6, Q7) and
then applied to the PLL IC (IC1, pin 2).
The PLL IC contains the prescalers, programmable counter,
programmable divider, phase selector and etc. The entered
signal is divided at the prescaler and programmable counter
sections by the N-data ratio from the CPU. The divided sig-
nal is detected on phase at the phase detector using the ref-
erence frequency.
If the oscillated signal drifts, the phase of its frequency
changes from the reference frequency, causing a lock volt-
age changes to compensate for the drift in the oscillated fre-
quency.
A portion of the VCO signal is amplified at buffer-amplifiers
(Q6, Q8) and is then applied to the receive 1st mixer (Q14)
or transmit driver via the TX/RX switching diode (D7, D8).
The lock voltage is also used for the receiver tunable band-
pass filter to match the filter’s center frequency to the
desired receive frequency. The lock voltage is amplified at
the buffer-amplifier (Q1) and then applied to the CPU (MAIN
unit; IC9, pin 93).
The amplified signal is controlled by the CPU (MAIN unit;
IC9), and is then applied to bandpass filters (D13–D18) as
“T1”, “T2”, “T3”, “T4” signals via the D/A converter (IC2).
Shift register
Prescaler
Phase
detector
Loop
filter
Programmable
counter
Programmable
divider
X1
21.25 MHz
"2nd LO" signal (21.25 MHz)
to the FM IF IC (MAIN unit; IC1)
Q4, Q5, D5, D6
VCO
Buffer
Buffer
Buffer Q8
D8
D7
Q7
Q6
3
4
5PLST
IC1 (PLL IC)
SCK
SO
to transmitter circuit
to 1st mixer circuit
17
16
82
Buffer "LVIN" signal to the CPU
(MAIN unit; IC9)
Q1
PLL CIRCUIT
LINE
HV
VCC
4V
R4V
T4V
S4V
DESCRIPTION
The voltage from the attached battery pack.
The same voltage as the HV line (battery volt-
age) which is controlled by the power switch
([OFF/VOL] control).
Common 4V converted from the VCC line by the
4V regulator circuit (MAIN unit; Q8–Q10).
The output voltage is applied to the D/A convert-
er (RF unit; IC2) and PLL IC (RF unit; IC1), etc.
Receive 4V converted from the 4V line by the R4
regulator circuit (MAIN unit; Q5).
The regulated voltage is applied to the MOD
MUTE circuit (RF unit; Q2, D2) and receiver cir-
cuit.
Transmit 4V converted from the 4V line by the T4
regulator circuit (MAIN unit; Q6).
The regulated voltage is applied to the transmit-
ter circuit.
Common 4V converted from the 4V line by the
S4V regulator circuit (MAIN unit; Q7).
The regulated voltage is applied to the optional
scrambler unit, limiter amplifier (MAIN unit; IC4),
etc.
4-4 POWER SUPPLY CIRCUITS
VOLTAGE LINES

4 - 4
4-5 PORT ALLOCATIONS
4-5-1 CPU (MAIN UNIT; IC9)
Pin
number
1
11
12
13
14
15
16
17
18
19
20
21
23
24
25
77
78
79
80
81
Port
name
BATT
RM
SRM
SMM
MM
AFON
OPST
DST
PLST
SCK
UNLK
SO
OPTIN
MONI
16CH
LIGHT
BEEP
4VC
R4C
T4C
Description
Input port for the low battely detection.
Outputs the AF mute swtich control
signal when the voice scrambler is
OFF.
Low : While squelched.
Outputs the AF mute switch control
signal when the voice scrambler is
ON.
Low : While squelched.
Outputs the MIC mute switch control
signal when the voice scrambler is
ON.
Low : While muted.
Outputs the MIC mute switch control
signal when the voice scrambler is
OFF.
Low : While muted.
Outputs control signal for the AF
amplifier regulator circuit.
High : Activates the AF amplifier cir-
cuit (MAIN unit; Q2).
Outputs strobe signals to the optional
voice scrambler unit
Outputs strobe signals to the D/A con-
verter IC (RF unit; IC2, pin 2).
Outputs strobe signals to the PLL IC
(RF unit; IC1, pin 3).
Outputs serial clock.
Input port for unlock signal.
High : PLL is unlocked.
Low : PLL is locked.
Outputs serial data.
Input port for the optinal voice scram-
bler unit connection.
Low : The optional voice scrambler
unit is connected.
Input port for the [MONI] switch.
Low : While [MONI] switch is
pushed.
Input port for the [16/9] switch.
Low : While [16/9] switch is pushed.
Outputs back light control signal.
High : Light ON.
Outputs beep audio signals.
Outputs 4V regulator control signal.
Outputs R4 regulator control signals.
Low : While receiving.
Outputs T4 regulator control signals.
Low : While transmitting.
Pin
number
82
83
85
86
87
88
90
91
92
93
94
95
96
97
98
99
100
Port
name
S4C
SPSEL
ESDA
CLIN
CLOUT
PTT
MKEY
SWA
SWB
LVIN
TEMPS
SQLV
TXDET
TONE
SD
NOIS
BTYPE
Description
Outputs S4 regulator control signals.
Outputs speaker select signal
Low : The internal speaker is
selected.
Input port for EEPROM serial data.
Outputs serial data to the EEPROM.
Input port for the cloning signal.
Outputs the cloning signal.
Input port for the [PTT] switch.
High : While [PTT] switch is pushed.
Input port for [MIC/SP] connector
detection.
Input port for the [CH/WX], [UP],
[DOWN] switches.
Input port for the [H/L], [DW], [SCN]
switches.
Input port for the PLL lock voltage
detection.
Input port for the transceiver’s internal
temperature detection.
Input port to adjust the squelch level.
Input port for the TX power detection.
Input port for the WX tone detection.
Input port fot the receive signal
strength detection.
Input port for noise signals (pulse-
type) for squelch operation.
Input port for the battely’s type detec-
tion.
4-5-2 D/A converter IC (RF UNIT; IC2)
Pin
number
5
6
11, 12, 13
14
Port
name
FRQCON
POWCON
T1–T3
T4
MODCON
Description
Output signal to adjust the reference
frequency.
Output signal to adjust TX power.
Output tunable bandpass filter control
signals.
Output tunable bandpass filter control
signals while receiving.
Output signal to adjust modulation
while transmitting.

5 - 1
SECTION 5 ADJUSTMENT PROCEDURES
5-1 PREPARATION
IC-M1V/M1EURO V can be adjusted by sending adjustment data to the RS-232C port via a PC. When you adjust the IC-
M1V/M1EURO V, the optional CS-M1V ADJ ADJUSTMENT SOFTWARE (Rev. 1.0 or later), * OPC-973 CLONING AND ADJUSTMENT
CABLE are required.
NOTE: * OPC-973 is a modified optional OPC-973 CLONING AND ADJUSTMENT CABLE (see illustration at CLONING AND ADJUST-
MENT CABLE MODIFICATION).
EQUIPMENT
DC power supply
RF power meter
(terminated type)
Frequency counter
Spectrum analyzer
GRADE AND RANGE
Output voltage : 7.4 V DC
Current capacity : 2 A or more
Measuring range : 0.1–10 W
Frequency range : 100–300 MHz
Impedance : 50 Ω
SWR : Less than 1.2 : 1
Frequency range : 0.1–300 MHz
Frequency accuracy: ±1 ppm or better
Sensitivity : 100 mV or better
Frequency range : at least 400 MHz
Spectrum bandwidth: ±100 MHz or more
EQUIPMENT
FM deviation meter
Audio generator
Standard signal
generator (SSG)
Attenuator
GRADE AND RANGE
Frequency range : 30–300 MHz
Measuring range : 0 to ±10 kHz
Frequency range : 300–3000 Hz
Measuring range : 1–500 mV
Frequency range : 100–300 MHz
Output level : 0.1 µV–32 mV
(–127 to –17 dBm)
Power attenuation : 40 dB or more
Capacity : 10 W or more
■SYSTEM REQUIREMENTS
• IBM PC compatible computer with an RS -232C serial port
(38400 bps or faster).
• Microsoft Windows 95 or Windows 98
• Intel i486DX processor or faster (Pentium 100 MHz or
faster recommended)
• At least 16 MB RAM and 10 MB of hard disk space
• 640×480 pixel display (800×600 pixel display recommend-
ed)
■ADJUSTMENT SOFTWARE INSTALLATION
NOTE: Before using the program, make a backup copy of
the original disk. After making a backup copy, keep
the original disk in a safe place.
qBoot up Windows.
- Quit all applications when Windows is running.
wInsert the backup disk1 into the appropriate floppy drive.
eSelect ‘Run’ from the [Start] menu.
rType the setup program name using the full path name,
then push the [Enter] key. (A:\ setup)
tFollow the prompts.
yProgram group ‘CS-M1V ADJ’ appears in the ‘Programs’
folder of the [Start] menu.
■STARTING THE PROGRAM
qConnect IC-M1V/M1EURO V and PC with the optional
cables OPC-478, * OPC-973.
wBoot up Windows.
eClick the program group ‘CS-M1V ADJ’ in the ‘Programs’
folder of the [Start] menu, then CS-M1V ADJ’s window is
appeared.
rClick ‘Connect’ on the CS-M1V’s window, then appears
IC-M1V’s/M1EURO V’s up-to-date condition.
tSet or modify adjustment data as desired. See illustration
at ADJUSTMENT SOFTWARE’S SCREEN DISPLAY
EXAMPLE on page 5-2.
IBM is a registered trademark of International Bussiness
Machines Corporation in the U.S.A. and other countries.
Microsoft and Windows are registered trademarks of
Microsoft Corporation in U.S.A. and other countries.
Screen shots produced with permission from Microsoft
Corporation. All other products or brands are registered
trademarks or trademarks of their respective holders.
OPC-478
a netted line (GND)
a white color line (MIC) a black color line (CLONE)
a red color line (EXT SP)
+
( MIC)
( MICE) +
( CLONE)
( GND)
INFORMATION: When ordering OPC-973
Part Name: OPC-973
Order Number: 8900009890
CLONING AND ADJUSTMENT CABLE MODIFICATION

5 - 2
to an RS-232C port
Personal
computer
OPC-478
*OPC-973
to the antenna connector
to [MIC] Audio generator
Frequency
counter
DB9 female plug
(incl. level converter circuit)
CAUTION:
DO NOT transmit while
SSG is connected to the
antenna connector.
AD-92SMA
Optional SMA-BNC
adapter
Attenuator
40 dB or 50 dB FM deviation meter
Spectrum analyzer
CONNECTION
RF power meter
0.1 10 W/50
Standard signal generator
0.1 V to 32 mV
( 127 dBm to 17 dBm)
DC POWER
SUPPLY
7.4 V/2A
Soldering DC
power cable here
(MP1, MP3)
MAIN unit bottom view
+
DC POWER CABLE CONNECTION
NOTE: The above values for settings are example only. Each transceiver has its own specific values for each setting.
CS-M1V ADJ Rev.1.0
File
COM 1: OPEN
Option
Connect Reload (F5) Disp para
[A / D]
MKEY : : :255 FFh 4 . 30V
SW A : : :255 FFh 4 . 30V
SW B : : :255 FFh 4 . 30V
BTYPE : : :255 FFh 4 . 30V
BATT : : :153 99h 8 . 26V
Dial Mode : USA
RF Power : High
TXF : [ Enter] to Start
SQL : [ Enter] to Start
ATIS : [ Enter] to Start
BPF ALL : [ Enter] to Start
Power (Hi) : 145 [ # # # # # # # # # # # — — — — — — ]
Power (LO) : 100 [ # # # # # # # # — — — — — — — — — ]
MOD : 110 [ # # # # # # # # # — — — — — — — — ]
BPF T1 : 0 [ # # # # # # # # # # — — — — — — — ] [ Enter ] to Sweep
BPF T2 : 0 [ # # # # # # # # # # — — — — — — — ] [ Enter ] to Sweep
BPF T3 : 0 [ # # # # # # # # # # — — — — — — — ] [ Enter ] to Sweep
BPF T4 : —1 [ # # # # # # # # # # — — — — — — — ] [ Enter ] to Sweep
Power (EL) : 90 [ # # # # # # # — — — — — — — — — — ]
CH No. : 01A (RX Freq = 156.050, TX Freq = 156.050)
LVIN : : :163 A3h 2 . 75V
SQLV : : :220 DCh 3 . 71V
TXDET : : :0 00h 0 . 00V
SD : : :0 00h 0 . 00V
NOIS : : :0 00h 0 . 00V
TEMPS : : :187 BBh 30 . 10’C
FRQCON : : :128 80h 2 . 16V
T1 : : :164 A4h 2 . 77V
T2 : : :164 A4h 2 . 77V
T3 : : :164 A4h 2 . 77V
T4 : : :163 A3h 2 . 75V
POWCON: : :0 00h 0 . 00V
[D / A]
: 17
OPEN : 34CLOSE
[SQL Calced]
1
4
2
5
3
6
7
10
8
11
9
12
13
1
4
2
5
3
6
7
10
8
11
9
12
: Connect IC-M1V/M1EURO V
with PC via an RS-232C serial cable
: Renew adjustment data
: PLL lock voltage measurement
: Connected DC voltage measurement
: Version select
: Operating channel select
: RF output power adjustments
: Reference frequency adjustment
: FM deviation adjustment
: Receive sensitivity adjustment
(automatically)
: Receive sensitivity adjustments
(manually)
: Squelch level adjustment
: ATIS adjustment ([FRG] only)
: Receive sensitivity measurement
14
13
14
ADJUSTMENT SPFTWARE’S SCREEN DISPLAY EXAMPLE

5 - 3
1
2
1
1
2
3
1
• Operating channel : ch 16
• Receiving
• Operating channel : ch 16
• Connect the RF power meter or 50 Ω
dummy load to the antenna connector.
• Transmitting
• Operating channel : ch 16
• Connect the RF power meter or 50 Ω
dummy load to the antenna connector.
• Transmitting
• Operating channel : ch 16
• [H/L] switch : High
• Transmitting
• [H/L] switch : Low
• Transmitting
• [H/L] switch : Extra low
• Transmitting
• Operating channel : ch 16
• [H/L] switch : High
• Connect the audio generator to the
[MIC] jack and set as:
1.0 kHz/40 mV rms.
• Set the FM deviation meter as:
HPF : OFF
LPF : 20 kHz
De-emphasis : OFF
Detector : (P–P)/2
• Transmitting
PLL
LOCK
VOLTAGE
REFERENCE
FREQUENCY
OUTPUT
POWER
FM
DEVIATION
Top
panel
Top
panel
Top
panel
Use the adjustment program.
(see page 5-2)
Loosely couple the frequnecy
counter to the antenna connec-
tor.
Connect the RF power meter to
the antenna connector.
Connect the FM deviation meter
to the antenna connector
through the attenuator.
2.3–3.3 V
Verify on the com-
puter display (LVIN)
156.800000 MHz
5.0 W (except [FRG])
1.0 W ([FRG] only)
1.0 W (except [FRG])
0.5 W ([FRG] only)
0.5 W (except [FRG])
±4.3 kHz
ADJUSTMENT ADJUSTMENT CONDITION MEASUREMENT VALUE
UNIT LOCATION
5-2 PLL AND TRANSMITTER ADJUSTMENTS
Select an operation using [↑] / [↓] keys, then set specified value using [←] / [→] keys on the connected computer keyboard.

5 - 4
*The output level of the standard signal generator (SSG) is indicated as the SSG’s open circuit.
1
1
2
• Operating channel : ch 16
• Connect a standard signal generator to
the antenna connector and set as:
Frequency : 156.800 MHz
Level :
3.2 µV* (–97 dBm )
[IC-M1V]
: 4.5 µV* (–94 dBm )
[IC-M1EURO V]
Modulation : 1 kHz
Deviation : ±3.5 kHz
• Receiving
• Operating channel : ch 16
• No RF signals are applied to the anten-
na connector.
• Receiving
• Set the cursol to “SQL” on the adjust-
ment program and push [ENTER] key,
then push [ENTER] key again.
• Operating channel : ch 16
• Connect a standard signal generator to
the antenna connector and set as :
Level :
0.71 µV* (–110 dBm)
[IC-M1V]
: 1 µV* (–107 dBm)
[IC-M1EURO V]
Modulation : 1 kHz
Deviation : ±3.5 kHz
• Receiving
• Push [ENTER] key on the keyboard.
RX
SENSITIVITY
SQUELCH
LEVEL
Maxmun level on the computer display (T1–T4) respectively.
ADJUSTMENT ADJUSTMENT CONDITION VALUE
5-3 RECEIVER ADJUSTMENT
Select an operation using [↑] / [↓] keys, then set specified value using [←] / [→] keys on the connected computer keyboard.
CONVENIENT: The BPF T1–BPF T4 can be adjusted automatically.
q-1: Set the cursol to “BPF ALL” on the adjustment program and then push [ENTER]
key.
q-2: The connected PC tunes BPF T1–BPF T4 to peak levels.
or
w-1: Set the cursol to one of BPF T1, T2, T3, or T4 as desired.
w-2: Push [ENTER] key to start tuning.
w-3: Repeat w-1 and w-2 to perform additional BPF tuning.
NOTE: Squelch level adjustment is adjusted automatically by
the adjustment program.

5 - 5
TX
SPURIOUS
( [M1EURO V]
only)
ADJUSTMENT
ADJUSTMENT ADJUSTMENT CONDITION MEASUREMENT VALUE POINT
UNIT LOCATION UNIT ADJUST
1• Operating channel : ch 16
• [H/L] switch : High
• No signal apply to the [MIC] jack
.
• Transmitting
Top
panel Connect the spec- trum analyzer to the
antenna connector
through the attenua-
tor.
High-harmonics com-
ponents are minimum
value.
RF L15
5-4 TRIMMER ADJUSTMENT
1
2
• Operating channel : ch 16
• [H/L] switch : High
• Connect the audio generator to the
[MIC] jack and set as:
1.0 kHz/40 mV rms.
• Set the FM deviation meter as:
HPF : OFF
LPF : 20 kHz
De-emphasis : OFF
Detector : (P–P)/2
• Set the cursol to “ATIS” on the adjust-
ment program and push [ENTER] key.
• Transmitting
• Set the cursol to “ATIS” on the adjust-
ment program and push [ENTER] key.
• Transmitting
ATIS
MODULATION
([FRG] only)
Top
panel Connect the FM deviation meter to the antenna connector
through the attenuator.
±1.3 kHz (1300 Hz)
±2.1 kHz (2100 Hz)
ADJUSTMENT ADJUSTMENT CONDITION MEASUREMENT VALUE
UNIT LOCATION
5-5 ATIS ADJUSTMENT
Select an operation using [↑] / [↓] keys, then set specified value using [←] / [→] keys on the connected computer keyboard.

5 - 6
L15
TX sprious adjustment
([IC-M1EURO V] only)
IC-M1EURO V RF UNIT TOP VIEW

S.=Surface mount
IC1 1110003490 S.IC TA31136FN (D,EL)
IC2 1110002420 S.IC NJM2073M-T1
IC3 1130007300 S.IC TC4W66FU (TE12L)
IC4 1110003780 S.IC NJM2902V-TE1
IC5 1130008090 S.IC BU4066BCFV-E1
IC6 1180001990 S.IC XC62FP4302MR
IC7 1130009680 S.IC HN58X2432TI
IC8 1130009110 S.IC S-80942ANMP-DD6-T2
IC9 1140008950 S.IC HD6433835SD05H
Q1 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q2 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q3 1590000430 S.TRANSISTOR DTC144EUA T106
Q4 1590002530 S.TRANSISTOR UN911H (TX)
Q5 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q6 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q7 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q8 1590000430 S.TRANSISTOR DTC144EUA T106
Q9 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q10 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q11 1590000660 S.TRANSISTOR DTC144TU T107
Q12 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q13 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q14 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q15 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q16 1590001920 S.TRANSISTOR UN911F (TX)
D1 1750000130 S.DIODE DA204U T107
FI1 2020001490 S.CERAMIC SFPC450E-TC01
FI2 2020001490 S.CERAMIC SFPC450E-TC01
X1 6070000210
S.DISCRIMINATOR CDBCA450CX24
X2 6050010290 S.XTAL CR-610 (7.9872 MHz)
R1 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R2 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R3 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R4 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R5 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R6 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R7 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R8 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R9 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R10 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R11 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R12 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R13 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R14 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R17 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R18 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R19 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R20 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R21 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R23 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R24 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R25 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R26 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R27 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R28 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R29 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R30 7030003790 S.RESISTOR ERJ3GEYJ 824 V (820 kΩ)
R31 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R32 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R33 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R34 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R35 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R36 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R37 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R38 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R39 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R40 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R41 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R42 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R43 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R44 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R45 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R46 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R48 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R49 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R50 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R51 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R52 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R53 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R54 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R55 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R56 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R57 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R58 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R59 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R60 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R61 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R62 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R63 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R64 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R65 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R66 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R67 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R68 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R69 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R70 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R71 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R72 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R73 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R74 7030005520 S.RESISTOR RR0816R-334-D (330 kΩ)
R75 7030005630 S.RESISTOR RR0816R-154-D (150 kΩ)
R76 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R77 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R78 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R79 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R81 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R82 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R83 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R84 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R85 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R86 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R87 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R88 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R89 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R90 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R91 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R92 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R93 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R94 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R95 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R96 7030004120 S.RESISTOR ERJ3GEYJ 203 V (20 kΩ)
R97 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R98 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R99 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R100 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R101 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R102 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R103 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R104 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R105 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R106 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R107 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R108 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R109 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R110 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R111 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R113 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R114 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R115 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R117 7030005320 S.RESISTOR RR0816P-103-D (10 kΩ)
R118 7030006560 S.RESISTOR RR0816P-223-D (22 kΩ)
R119 7030005330 S.RESISTOR RR0816P-562-D (5.6 kΩ)
6 - 1
SECTION 6 PARTS LIST
REF ORDER DESCRIPTION
NO. NO.
[MAIN UNIT] REF ORDER DESCRIPTION
NO. NO.
[MAIN UNIT]

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
R120 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R121 7030005320 S.RESISTOR RR0816P-103-D (10 kΩ)
R122 7030006560 S.RESISTOR RR0816P-223-D (22 kΩ)
R123 7030005330 S.RESISTOR RR0816P-562-D (5.6 kΩ)
R124 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R125 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R126 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R127 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R128 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω)
R129 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω)
R130 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R131 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R132 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R134 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R135 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R136 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
C1 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C3 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C4 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C5 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C6 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C7 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C8 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C9 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C10 4030007120 S.CERAMIC C1608 CH 1H 820J-T-A
C11 4030008900 S.CERAMIC C1608 JB 1C 333K-T-A
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C14 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C15 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C16 4550006210 S.TANTALUM ECST1CX106R
C17 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C18 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C19 4510005960 ELECTROLYTIC 10 MV 220 HC
C20 4510005370
S.ELECTROLYTIC ECEV1AA221P
C21 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C22 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C23 4550006390 S.TANTALUM TEMSVA 1C 335M-8L
C24 4550006390 S.TANTALUM TEMSVA 1C 335M-8L
C25 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C26 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C27 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C28 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C29 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C30 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C31 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C33 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C34 4550006200 S.TANTALUM ECST0JY106R
C35 4030008860 S.CERAMIC C1608 JB 1C 153K-T-A
C36 4030011330 S.CERAMIC C1608 CH 1H 391J-T-A
C37 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C38 4030008890 S.CERAMIC C1608 JB 1C 273K-T-A
C39 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C40 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C41 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C42 4030009490 S.CERAMIC C1608 JB 1H 821K-T-A
C43 4030010770 S.CERAMIC C1608 JB 1H 392K-T-A
C45 4030007160 S.CERAMIC C1608 CH 1H 181J-T-A
C46 4030008890 S.CERAMIC C1608 JB 1C 273K-T-A
C47 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C48 4030008770 S.CERAMIC C1608 JB 1H 562K-T-A
C50 4030007150 S.CERAMIC C1608 CH 1H 151J-T-A
C51 4030008890 S.CERAMIC C1608 JB 1C 273K-T-A
C52 4550006200 S.TANTALUM ECST0JY106R
C53 4550006200 S.TANTALUM ECST0JY106R
C54 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C55 4550006200 S.TANTALUM ECST0JY106R
C56 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C57 4550006200 S.TANTALUM ECST0JY106R
C58 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C59 4550006200 S.TANTALUM ECST0JY106R
C60 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C61 4550006950 S.TANTALUM ECST0JX476R
C62 4510005600
S.ELECTROLYTIC ECEV1CS100SR
C63 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C64 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C65 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C66 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C67 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C68 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C69 4030008650 S.CERAMIC C1608 JB 1H 332K-T-A
C71 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C72 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C73 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C74 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C75 4030008890 S.CERAMIC C1608 JB 1C 273K-T-A
C76 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C77 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C78 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C79 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C80 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C81 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C82 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C83 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C84 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C85 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C86 4550006200 S.TANTALUM ECST0JY106R
C87 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C88 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C89 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C90 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C91 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C92 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C93 4030010020 S.CERAMIC C1608 JB 1H 122K-T-A
C94 4030008860 S.CERAMIC C1608 JB 1C 153K-T-A
J1 6510021960 S.CONNECTOR AXN430C040P
J2 6510010960 CONNECTOR PI28E-02M
J3 6510016430 S.CONNECTOR 53307-1491
DS1 5030001810 LCD A0081A
DS2 5010000120 S.LED LN1371G-(TR)
DS3 5010000120 S.LED LN1371G-(TR)
DS4 5010000120 S.LED LN1371G-(TR)
DS5 5010000120 S.LED LN1371G-(TR)
DS6 5010000160 S.LED LNJ310M6URA
DS7 5010000160 S.LED LNJ310M6URA
DS8 5010000160 S.LED LNJ310M6URA
DS9 5010000160 S.LED LNJ310M6URA
MC1 7700002440 MICROPHONE KUB2823-013280
EP1 0910051885 PCB B 5389E
EP2 8930051120 LCD CONTACT SRCN-2320-SP-N-W
IC1 1130007610 S.IC µPD3140GS-E1 (DS8)
IC2 1110004530 S.IC M62368GP 70ED
IC3 1120002830 S.IC NJM2125F-TE1
Q1 1560000540 S.FET 2SK880-Y (TE85R)
Q2 1590000430 S.TRANSISTOR DTC144EUA T106
Q4 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q5 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q6 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q7 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q8 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q9 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q10 1560001020 S.FET 2SK2973 (MTS101P)
Q11 1560001050 S.FET 2SK2974
Q13 1580000720 S.FET 3SK239AXRTL
Q14 1580000490 S.FET 3SK166A-2-T7
Q15 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R)
Q16 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q17 1590002160 S.TRANSISTOR XP6401-(TX)
6 - 2
REF ORDER DESCRIPTION
NO. NO. REF ORDER DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER DESCRIPTION
NO. NO.

[RF UNIT][RF UNIT]
S.=Surface mount
D1 1720000670 S.VARICAP HVU17TRF
D2 1790000620 S.DIODE MA77 (TX)
D4 1790001650 S.DIODE MA77 (TX) -AB
D5 1720000370 S.VARICAP HVU350TRF
D6 1720000370 S.VARICAP HVU350TRF
D7 1790000620 S.DIODE MA77 (TX)
D8 1790000620 S.DIODE MA77 (TX)
D9 1790000620 S.DIODE MA77 (TX)
D10 1790000490 S.DIODE HSM88AS-TR
D11 1790000620 S.DIODE MA77 (TX)
D12 1790000620 S.DIODE MA77 (TX)
D13 1720000370 S.VARICAP HVU350TRF
D14 1720000370 S.VARICAP HVU350TRF
D15 1720000370 S.VARICAP HVU350TRF
D16 1720000370 S.VARICAP HVU350TRF
D17 1720000370 S.VARICAP HVU350TRF
D18 1720000370 S.VARICAP HVU350TRF
D19 1730002300 S.ZENER MA8082-M (TX)
FI1 2010002420 MONOLITH 21R15AB (FL-310)
FI2 2010002420 MONOLITH 21R15AB (FL-310)
X1 6050010800 S.XTAL CR-659 (21.25 MHz)
L1 6200007000 S.COIL ELJRE 82NG-F
L2 6200008070 S.COIL MLF1608E 6R8K 6.8U
L3 6200003090 S.COIL NL 322522T-2R7J-3
L5 6200006980 S.COIL ELJRE R10G-F
L6 6200006980 S.COIL ELJRE R10G-F
L7 6200006980 S.COIL ELJRE R10G-F
L8 6200006980 S.COIL ELJRE R10G-F
L9 6200006670 S.COIL ELJRE 68NG-F
L10 6200002320 S.COIL LQN 1A 8N8J04
L11 6200009240 S.COIL 0.20-1.0-7TL 31N
L12 6200008460 S.COIL 0.26-0.9-5TR 15N
L13 6200002370 S.COIL LQN 1A 39NJ04
L14 6200003090 S.COIL NL 322522T-2R7J-3
L15 6200008450 S.COIL 0.35-1.6-5TL 28N
L16 6200008450 S.COIL 0.35-1.6-5TL 28N
L17 6200008400 S.COIL 0.35-1.6-6TL 36N
L18 6200002820 S.COIL LQN 1A 47NJ04
L19 6200002820 S.COIL LQN 1A 47NJ04
L20 6200007160 S.COIL LQN 1H 54NK04
L21 6200007160 S.COIL LQN 1H 54NK04
L22 6200002360 S.COIL LQN 1A 33NJ04
L23 6200002360 S.COIL LQN 1A 33NJ04
L24 6200005740 S.COIL ELJRE 47NG-F
L25 6200006980 S.COIL ELJRE R10G-F
L26 6200004790 S.COIL MLF1608D R47K-T
L27 6200003590 S.COIL EXCCL3225U1
L28 6200003590 S.COIL EXCCL3225U1
L29 6200008190 S.COIL 0.25-1.9-8TL 80N
R1 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R2 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R3 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R4 7510001160 S.THERMISTOR NTCCM1608 4LH 473KC
R5 7030005870 S.RESISTOR RR0816R-104-D (100 kΩ)
R6 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R7 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R8 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R9 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R10 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R11 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R12 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R13 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R14 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R15 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R16 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R17 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R19 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R20 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R22 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R23 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R24 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R26 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R27 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω)
R28 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R29 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R30 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R31 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R32 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R33 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R34 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R35 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R36 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R37 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R38 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R39 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R40 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω)
R41 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R42 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R43 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R44 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R46 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R47 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R48 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R49 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R51 7030000280 S.RESISTOR MCR10EZHJ 150 Ω(151)
R52 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R53 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R54 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R56 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω)
[M1EURO V] only
R57 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R58 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R59 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R60 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R61 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R62 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R63 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ)
R64 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R65 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R67 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R68 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R69 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R70 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R71 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R72 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R73 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R74 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R78 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R80 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R82 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R83 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R86 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R87 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R88 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R89 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R90 7030005320 S.RESISTOR RR0816P-103-D (10 kΩ)
R91 7030008120 S.RESISTOR RR0816P-682-D (6.8 kΩ)
R92 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R95 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R96 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R97 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R98 7030007330 S.RESISTOR ERJ1WRSJR15U (0.15 Ω)
R99 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R100 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R101 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R102 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R103 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R104 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R105 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
C1 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C2 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C3 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C4 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C5 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C6 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C7 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C8 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
C9 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
C10 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C11 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C13 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C15 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C16 4550000510 S.TANTALUM TESVA 1V 473M1-8L
C17 4550006140 S.TANTALUM ECST1EY474R
6 - 3
REF ORDER DESCRIPTION
NO. NO. REF ORDER DESCRIPTION
NO. NO.
