PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 1
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 2
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
Chapter 1 Introduction .................................... 3
1.1. PM-2133D introduction..... 3
1.2. Caution............................. 4
1.2.1. Danger.............................. 4
1.3. Warning............................ 4
1.4. Product Warranty &
Customer Support............. 4
1.4.1. Limitation of Warranty....... 5
Chapter 2 Specifications................................. 6
2.1 Specifications.................... 6
Chapter 3 Installation...................................... 8
3.1 Inspection......................... 8
3.2 Safety ............................... 8
3.2.1 Dimension and Latch........ 8
3.2.2 Mounting and Dismounting
....................................... 10
3.2.3 CT’s installation steps..... 12
Chapter 4 Wiring Diagrams...........................13
4.1 Connection......................13
4.2 Wiring..............................15
Chapter 5 Keypad, LED Indicator & Display..17
5.1 Function of LED Display,
Indicator and Keypad ......17
5.2 Operation of LED Display,
Indicator and Keypad ......18
5.2.1 Normal Mode...................18
5.2.2 Setup Mode.....................19
Chapter 6 Modbus-RTU communication........23
6.1 RS-485 setting ................23
6.2 Modbus-RTU setting .......23
6.2.1 Specifications..................23
6.2.2 Modbus Register.............25
Appendix 1: Questions & Answers ................31

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 3
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
Chapter 1 Introduction
1.1. PM-2133D introduction
ICP DAS brings the most powerful, cost-effective, advanced Smart Power Meters
PM-2133D series that gives you access to real-time electric usage for three-phase power
measurement. With its high accuracy (<0.5%, PF=1 ), the PM-2133D series can be applied
to both low voltage primary side and/or medium/high voltage secondary side and enables
the users to obtain reliable and accurate energy consumption readings from the monitored
equipments in real time under operation. These compact size and cost-effective power
meters are equipped with revolutionary wired clip-on CT (various types, support input current
up to 400 A). It operates over a wide input voltages range 10 ~ 500 VAC which allows
worldwide compatibility. This meter has LED display shows power.
Features：
True RMS Power Measurements
Energy Analysis for 3P4W-3CT, 3P3W-2CT, 3P3W-3CT, 1P2W-1CT, 1P3W-2CT
Current Measurements Up to 400 A with Different CT Ratio
Voltage Measurements Up to 500 V
Clip-on CT for Easy Installation
W Accuracy Better than 0.5% (PF=1)
8 - Digit LED Display
Supports RS-485, Ethernet Interface (PoE)
Supports Modbus RTU, Modbus TCP protocols.
Bi-directional Energy
Total Harmonic Distortion (THD)

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 4
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
1.2. Caution
1.2.1.Danger
The meter contains hazardous voltages, and should never be disassembled. Failing to
follow this practice will result in serious injury or death. Any work on or near energized
meters, meter sockets, or other metering equipment could induce a danger of electrical
shock. It is strongly recommended that all work should be performed only by qualified
industrial electricians and metering specialist. ICP DAS assumes no responsibility if
your electrical installer does not follow the appropriate national and local electrical
codes.
1.3. Warning
ICP DAS assumes no liability for any damage resulting from the use of this product. ICP
DAS reserves the right to change this manual at any time without notice. The
information furnished by ICP DAS is believed to be accurate and reliable. However, no
responsibility is assumed by ICP DAS for its use, not for any infringements of patents or
other rights of third parties resulting from its use.
1.4. Product Warranty & Customer Support
ICP DAS warrants all products free from defects in material and workmanship for a
period of one year from the date of shipping. During the warranty period, we will, at our
position, either repair or replace any product that proves to be defective. To report any
defect, please contact ：[phone] or [e-mail].
Please have the model, serial number and a detailed problem description available
when you call. If the problem concerns a particular reading, please have all meter
readings available. When returning any merchandise to ICP DAS, a return SN. is
required.

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 5
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
1.4.1.Limitation of Warranty
This warranty does not apply to defects resulting from unauthorized modification,
misuse, or use for reason other than electrical power monitoring. The supplied meter is
not a user-serviceable product.

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 6
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
Chapter 2 Specifications
2.1 Specifications
Model PM-2133D PM-2133D-MTCP
AC Power Measurement
Wiring 1P2W-1CT, 1P3W-2CT, 3P3W-2CT, 3P3W-3CT and 3P4W-3CT
Measurement Voltage 10 ~ 500 V (CAT III)
Measurement Current CTØ10 mm (0.05 A~60 A); CTØ16 mm (0.1 A~100 A); CTØ24 mm (0.15
A~200 A); CTØ36 mm (0.3 A~300 A); CTØ36 mm (0.3 A~400 A)
Measurement Frequency 50 Hz (Range 45 ~ 55 Hz)/60 Hz (Range 55 ~ 65 Hz)
W Accuracy Better than 0.5% (PF:1)
Power Parameter
Measurement
True RMS voltage (Vrms), True RMS current (Irms), Active Power (kW),
Active Energy (kWh), Apparent Power (kVA), Apparent Energy (kVAh),
Reactive Power (kVAR), Reactive Energy (kVARh), Power Factor (PF),
Frequency (45 ~ 65 Hz)
Data Update Rate 1 Second
Communication
RS-485
Protocol Modbus-RTU -
Baud rate 9600,19200 (default), 38400,
115200; -
Data
format
N,8,1 (default); N,8,2; E,8,1; E,8,2;
O,8,1; O,8,2
Isolation 3000 VDC -
Bias
Resistor
No (Usually supplied by the
RS-485 Master. Altern
atively, add
a tM-SG4 or SG-785)
Ethernet Protocol - Modbus TCP

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 7
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
Aux Power
Input Range +85 ~ +264 VAC (277 VAC available)
Power Consumption 6 W
Dimensions (W x L x H) 110 mm x 50 mm x 115 mm
Environment
Operating Temperature -20 ~ +70 °C
Storage Temperature -25 ~ +80 °C

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 8
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
Chapter 3 Installation
3.1 Inspection
The instrument is no longer safe when,
a) Shows clear signs of damage
b) Does not work
c) Long storage under extreme conditions
d) Damage during shipment
3.2 Safety
Please use the soft dry clothes to clean the instrument.
Please do not use any chemical or detergent or volatile solvents to clean the instrument,
in order to avoid any possibility of the cover damage.
3.2.1 Dimension and Latch
The diagrams below provide the dimensions of the PM-2133D to use in defining your
enclosure specifications. Remember to leave room for potential expansion if you are
using other components in your system.

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 9
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
Products come with external split type clip-on CT’s. Disconnect the CT’s or use
other CT’s is highly prohibited.
Please read this operation manual carefully before using.
Please re-confirm the measure position.
Meter auxiliary power is +85 ~ +264 VAC (277 VAC available).
Wire Disconnection:
1. Open the CT clip to detach the CT, do not remove the CT terminal lines if
possible
Note: if you need to remove the terminal lines, always detach the CT before
removing the CT terminal lines. Otherwise the CT may develop open-circuit
secondary voltages which may be hazardous to personnel or damaging to the
CT or equipment connected in the secondary circuit.
2. Disconnect the voltage input wires from terminals and wrap the wire tips with
plastic tape.
3. Disconnect the communication wires from terminal.
4. Disconnect the auxiliary power from terminal and wrap the wire tip with plastic
tape.

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 10
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
3.2.2 Mounting
1. Prepare a panel and cut a hole to
the specified size (unit: mm).
2. Remove the latch assembly.
i. Press the protruding pin of the latch assembly.
92.0
46.0±1
Panel thickness: 1 to 5 mm
The protruding pin

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 11
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
The protruding pin The protruding pin
Keep on pressing the protruding pin to slide
the latch assembly to the groove
The groove
3. Attach the PM-2133D to the cut-out hole.
4. Attach the latch assembly, and then
slide the latch assembly toward the panel.

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 12
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
3.2.3 CT’s installation steps
At the bottom of the CT, there is a
“K→L” mark.
Open the CT clip.
Make sure the power current
direction follow the “K→L” mark on
the CT and then close the CT clip.
Installation steps finished.

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 13
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
Chapter 4 Wiring Diagrams
4.1 Connection
Please firstly check the current input terminal, and then in white black, white black,
white black wire sequences (CT1-K, CT1-L, CT2-K, CT2-L, CT3-K, CT3-L). Then
connect the CT’s, and close the CT clip. Make sure the arrow direction sign on CT’s
follows current flow direction K (W)→L(B).
Note: it must be in the same direction.
Connect the voltage input terminal N C BA. for PM-2133D, in the three phase order
as follows on N C B A.
Attention please!! For 3P3W-2CT, connect in N C A phase sequence, do not
connect phase B (Check the diagram).

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 14
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
Voltage Input
1. PM-2133D series: Input Voltage up to 500V.
For any higher Input Voltage large than 500V, please add the PT (power
transformer), and Change PT RATIO setup.
2. Confirm the RST (ABC) phase sequence.
Current Input
1. The external CT’s are fragile, please handle with care.
2. The current input of PM-2133D series is in mA range. Only the ex-factory attached
CT’s can be used. The other CT’s, for example, from panel will damage the
instrument due to its large current (around 5A)
3. When more than one smart meter (PM-2133D series) are installed, please do not
disconnect the CT with its original meter and mix use with each other. Since each set
of smart meter (PM-2133D series) and its attached split type clip-on CT are
calibrated set by set. The mix use may cause wrong measurements.
4. To install CT’s correctly, please ensure the CT lines sequences is right before clip
the CT’s onto the power cable of the monitoring equipment. (Detail will be found in
next section)
5. When measuring the current, the secondary circuit of a CT should
never be opened when a load is passing through its primary. Make
sure you always open the CT clip to detach the CT before removing the
terminal lines. Otherwise, it will cause severe injury.
6. Please handle with extra care, especially when the operation space of CT’s is
limited.
7. The current direction must follow K-L marked on CT’s.
8. Please select the right size CT’s for different size of monitoring equipment cables:
power cable diameter ＜Φ10 use 60A CT，Φ10～Φ16 use 100A CT，Φ16～Φ24
use 200A CT,
，Φ36 use 300A CT，Φ36 use 400A CT
9. The maximum current value cannot exceed the CT rating

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 15
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
4.2 Wiring
1P2W-1CT(PM-2133D)
1P3W-2CT(PM-2133D)
3P3W-2CT(PM-2133D)

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 16
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
3P3W-3CT(PM-2133D)
3P4W-3CT(PM-2133D)

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 17
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
Chapter 5 Keypad, LED Indicator &
Display
5.1 Function of LED Display, Indicator and Keypad
PM-2133D has a built-in 8-Digit LED Display to display the power data measured by
the meters. The 7 LED Indicators are used to indicate the type of the power data which
are currently shown on the 8-Digit LED Display, and the status of RS-485
communication(Tx/Rx).
PM-21333D also has a built-in four buttons of keypad which is used to adjust the
power data which is currently shown on the LED Display or the parameters setting of
PM-2133D.
Keypad Function
▲Move to next item be shown or decrease the settings of parameters
▼Move to previous item be shown or increase the settings of parameters
Enter Change LED Display to "Setup Mode" or enable the modification of
parameters
Exit Change LED Display to "Normal Mode" or disable the modification of
parameters

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 18
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
5.2 Operation of LED Display, Indicator and Keypad
With the built-in LED Display, Indicator and Keypad, PM-2133D can display the real-time
power data it measures. User can also change the setting of the power meter. The
following sections describe the features provided.
5.2.1 Normal Mode
After power up PM-2133D, the default power data shown is power data of I_a (Phase
A Current). User can press the "▲" button and "▼" button of the Keypad to select the
desired power data to be displayed on PM-2133D. The corresponding LED Indicator
of the power data selected will also be in "ON" status - lights up in red.
The power data provided by PM-2133D will be displayed circularly in the sequence as
below:

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 19
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
5.2.2 Setup Mode
User can press the buttons of Keypad to enter the Setup Mode to adjust the
parameters setting of PM-2133D. The steps are as below:
i. Press the "Enter" button to enter the Setup mode, all the LED Indicators of
PMD-2133D will be in "ON" status, and the LED Display panel will display
.

PM-2133D User’s Manual v1.00 Last Revised: Feb. 2020 Page: 20
Copyright © ICP DAS Co., Ltd. All Rights Reserved. www.icpdas.com E-mail: [e-mail]
ii. Press the "▲" button and "▼" button of the Keypad to select the parameter of
PM-2133D to be modified. The settings of parameters provided by PM-2133D will be
shown in sequence as below:.
: LED Segment check (read only, cannot be modified)
: Firmware version (read only, cannot be modified).
: Modbus Address setting.
Press the "Enter" button, the current address setting will blink.
Press the "▲" button and "▼" button to adjust the setting of address. The
range is from 1 to 64.
: Modbus Baudrate setting.
Press the "Enter" button, the current Baudrate setting will blink.
Press the "▲" button and "▼" button to adjust the Baudrate setting. There are
4 options : 9600( ), 19200( ), 38400( ) and
115200( ) for selection.
: Modbus Data Format setting.
Press the "Enter" button, the current Data Format setting will blink.
Press the "▲" button and "▼" button to adjust the Data Format setting. There
are 6 options: 8N1( ; 8 data bits, None Parity, 1 stop bits), 8O1 ( ; 8 data
bits, Odd Parity, 1 stop bits;), 8E1( ; 8 data bits, Even Parity, 1 stop bits),
8N2( ; 8 data bits, None Parity, 2 stop bits), 8O2 ( ; 8 data bits, Odd
Parity, 2 stop bits;) and 8E2( ; 8 data bits, Even Parity, 2 stop bits) for
selection.
: PT ratio setting. The range is from 0.01 to 655.35.
Press the "Enter" button, the hundreds digit of the PT ratio will blink. Press the
"▲" button and "▼" button to adjust the setting of hundreds digit.
After completing the setting of hundreds digit, press the "Enter" button, the tens
digit of the PT ratio will blink. Press the "▲" button and "▼" button to adjust
the setting of tens digit.
After completing the setting of tens digit, press the "Enter" button, the units
digit of the PT ratio will blink. Press the "▲" button and "▼" button to adjust
the setting of units digit.
