DL-100TM-ZT Quick Start
v1.0, June. 2020
Without “Quick Start”, The package includes the following items:
DL-100TMS-ZT
Technical Support
Product Website (DataSheet/Manual/Tool)
http://www.icpdas.com/root/product/solutions/remote_io/
rs-485/dl_series/dl-100tmzt.html
E-mail
[email protected]

Copyright © 2019 ICP DAS Co., Ltd. All Rights Reserved.
P2
1
Introduction to the Configuration Parameters
1) Pan ID：
group identity for a ZigBee network, and must the same for all devices
in the same ZigBee network. (Setting Range : 0x0000~0x3FFF)
2) Address/Node ID：
distinguish identity of a specific the ZigBee module, and must be
unique for each device connected the same ZigBee network.
(Setting Range : 0x01~0xFF)
3) RF Channel：
indicates the radio frequency channel, and must be set to the same
value as other modules on the same ZigBee network.
Channel
0x00
0x01
……
0x0F
Frequency(MHz)
2405
2410
……
2480
RF channels 0x04, 0x09, 0x0E or 0x0F are recommended because they
do not overlap with the Wi-Fi frequencies based.
2
Preparation
1) Before you use this Utility, please make sure you have installed the
Microsoft .NET Framework 4. If you haven’t installed .NET Framework
yet, please refer to item 2 for more information, or refer to item 3 for
more information about the installation of this Utility.
2) To download .NET Framework, refer to: http://www.microsoft.com/en-
us/download/details.aspx?id=17851
3) The Utility software is located on the web at:
4) Connect DL-100TMS-ZT.
i. Use ZT-2000 Coordinator connect Default Parameter：
Protocol
Modbus
CheckSum
Enable
PAN ID
0x0001
Node ID
0x01
RF Channel
0x00
RF Power
0x07
ii. Use RS-232
5) Power supply range：+10 ~ +30 VDC

Copyright © 2019 ICP DAS Co., Ltd. All Rights Reserved.
P3
3
Communication Test
As the ZigBee network is controlled by the ZigBee coordinator, the
ZT-2550/ZT-2570 (ZigBee coordinator) must be configured first. Please
refer to documents shown below for full details of how to configure these
devices.
Once configuration of the ZigBee coordinator has been completed.
Set the ”Pan ID” and the “RF Channel” values for the DL-100TMS-ZT
to the same values as the network, and then reboot the device. The
module will automatically start to function on the ZigBee network
using the default protocol.
※Documents
http://ftp.icpdas.com.tw/pub/cd/usbcd/napdos/zigbee/zt_series/document/zt-255x/
http://ftp.icpdas.com.tw/pub/cd/usbcd/napdos/zigbee/zt_series/document/zt-257x/
※Configuration Utility (Used to configure ZT-2000 I/O device Coordinator)
http://ftp.icpdas.com.tw/pub/cd/usbcd/napdos/zigbee/zt_series/utility/

Copyright © 2019 ICP DAS Co., Ltd. All Rights Reserved.
P4
4
An overview of the Utility
After launching the Utility, the program interface will be displayed, as
shown below:
Clicking either the“Connection->Connect->RS-232/RS-485” menu
option or the icon will create a connection from the serial port.
Clicking either the “Connection->Disconnect” menu option or the
icon will disconnect the connection between the PC and the DL-
100TMS-ZT.
Clicking either the “Functions->Get Records” menu option or the
icon will retrieve the log data which is stored on the DL-100TMS-
ZT.
Clicking either the “Functions->Configuration” menu option or the
icon will allow the DL-100TMS-ZT to be configured.
Clicking either the “File->Exit” menu option or the icon will close
the Utility software.

Copyright © 2019 ICP DAS Co., Ltd. All Rights Reserved.
P5
5
Connecting to the DL-100TMS-ZT Module
1. Clicking either the “Connection->Connect->RS-232/RS-485” menu
option or the “ ” button will open the connection selection menu, as
shown below:
2. Select your COM port number and set the Model Name selection to
the DL-100TMS-ZT. If you are connecting to a new module, the
default address will be 01. Click the “OK” button to connect to the DL-
100TMS-ZT.Note: The LCD will also indicate the module address.
3. If a connection is successfully established, the Utility willreturn to the
previous window and the message “Connection is established” will
be displayed in the status bar.The “ ” and “ ” icons will also
becomeavailable.
4. If you want retrieve records that are stored on the DL-
100TMS-ZT, click either the “ ” icon or the
“Functions->Get Records” menu option .
5. If you want to configure the DL-100TMS-ZT, either click the
“ ” icon or “Functions->Configuration” menu option.

Copyright © 2019 ICP DAS Co., Ltd. All Rights Reserved.
P6
6
Retrieving Records
After a connection has been established between the PC and the DL-
100TMS-ZT, you can retrieve log data via the Utility software. The
procedure is as follows:
1. Either click the “Functions->Get Records” menu option or the
icon and the “Load Log Data” window will be displayed.
2. Click the “Get” button and wait until the data is successfully received.
3. Press Show chart to draw the chart.

Copyright © 2019 ICP DAS Co., Ltd. All Rights Reserved.
P7
7
Configuration
1. After a connection has been established between the PCand the
DL-100TMS-ZT, the DL-100TMS-ZT can be configured by either
clicking the “”icon or the “Functions->Configuration” menu
option. The “Configuration” window will then be displayed showing
the current configuration of the module. If any of the values are
changed, click the “Set” button to update the configuration of the
module.
2. When you successfully connect to the DL-100TMS-ZT using the
Utility software, the software will automatically disable the data log
function. If the data log function is required, ensure that the data log
function enabled before closing the Utilitysoftware.
