Icron RG2204 User manual

90-01004-A03
USB 2.0 RG2204
4-port USB 2.0 100m Cat 5e Extender System
Quick
Start
Guide
12
34
Before you get started, ensure that all the drivers required for your USB device(s) are installed.
Connect the remote extender to the AC
adapter and plug it into a power source.
Connect the local extender to the
computer using the included
USB cable.
Attach USB device(s) to the remote
extender.
Computer
Note: Power adapter is not required
at local extender for normal operation.
Host
Activity
Link
Power
Link
Link
Max 100m (Cat 5e cable not included)
1Place extenders where desired and
connect the Cat 5e extension link cable
to the Link ports (RJ45) on the local and
remote extender.
Link
Link
Local Extender (back view)
Remote Extender (back view)
Remote Extender (front view)
▪Transparent USB extension
▪True plug and play; no software drivers required
▪Works with all major operating systems: Windows®,
Mac OS X®, and Linux®
Includes the ExtremeUSB® suite of features:
