ICT N7 Series User manual

4 - Way Acceptance
Low Maintenance
Easy Installation
Re - Programmable
Flash ROM
Auto Self -Adjusting
Sensor System
ill
ill
B
B V
V
alidator
alidator
N7 Series
Installation Guide
International Currency Technologies
43010 Osgood Rd. Fremont, CA 94539
Tel (510) 353-0289
Fax (510) 353-0399
E-mail [email protected]
Website www.ict-america.com
2003 International Currency Technologies Corporation
Vol. 1.0PartNumberH46540-R

ContentsContents
(1) N7 Bill Validator Specifications ................................. 2
(2) Bill Validator Dimensions ........................................... 2
(3) LED Display ..................... .......................................... 4
(4) LED Status ................................................................. 4
(5) Download and upgrade .............................................. 4
(6) N7 Pin-out Assignments (N.I.S.R for 117V AC) ........ 5
N.I.S.R CONNECTOR ................................................ 6
N.I.S.R PIN LOCATIONS ............................................ 6
(7) Cable ......................................................................... 7
Switch Settings ..................................................(Appendix)

(1) N7 Bill Validator Specifications
Acceptance Rate
Bill insertion
Acceptance Speed
Interfaces
Bill box Capacity
Power Sources
Weight
Environment Range
96% or greater
4-way Acceptance
Approx. 3 seconds
(including bill stacking)
N.I.S.R
117V AC 0.2Amp (60HZ)
Power Consumption
Max 50 watts
Approx. 2kg (sh ipping)
Operating Temperature 0 C~55 C
Storage Temperature -30 C~70 C
- 2 -
Humidity 30%~85% RH (no condensation)
(2) Bill Validator Dimensions
Approx.100 bills ( 8 0~120) 3MB-SBX10002
200 bills (200~300) 3MB-SBX05005
400 bills (350~450) 3MB-SBX06005
800 bills (750~850) 3MB-SBX09006
1. Horizontal (Figure 1) see page 3.
2. Vertical (Figure 2) see page 3.
Vertical
- 3 -
94.0(3.70")
235.9(9.29")
130.0(5.12") 500bills
107.0(4.21")
48.1(1.90")
13.0(0.51")
129.0(5.08")
50.8(2.00")
115.0(4.53")
115.0(4.53") 300bills
500 pcs.
300 pcs.
800 pcs.
190.0(7.48") 800bills
94.0(3.70")
245.4(9.66")
130.0(5.12') 500bills
115.0(4.53") 300bills
500 pcs.
300 pcs.
107.0(4.21")
48.1(1.90)
13.0(0.51")
132.0(5.20")
116.0(4.57")
50.8(2.00")
84.0(3.31")
800 pcs.
190.0(7.48") 800bills
Unit : :mm
( ) : in
Unit : :mm
( ) : in
Vertical
(Sliding Block)
(Push Button)

- 4 -
FLASHES STATUS
1 bill jammed
2 disabled from system
3 sensor problem
4 reserved
5 bill box is removed
6
LED ON POWER ON
LED OFF POWER OFF
bill box is full of money
The two LED lights located at the front of the unit will show the operational
status of the bill validator. The LED lights will flash ON and OFF (in 500ms
intervals) when the unit is ready to accept bills. The LED lights will be OFF
if the unit is disabled or out of service, in which case the unit will not accept
any bills.
The bill validator can only accept one bill at a time. The LED lights will be
OFF and will not accept another bill while a bill is being validated in the unit.
The LED lights will start to flash normally when the bill validator is ready to
accept the next bill.
(3) LED Display
(4) LED Status
(5) Download and Upgrade
In addition to the 30-pin connector, there is also an 8-pin RJ-45 connector
on the side of the bill validator designed for the purpose of downloading
programs and updating validation software. The connector will be kept open
under normal operation of the bill validator. It will only be used when a new
software or program need to be downloaded into the flash ROM. (Figure 1)
LED
Option Switches
COM2
COM2
PH
PH
BACK LED
Figure 1
FP-001FP-001
5
4 3 2 1
5
4 3 2 1
9 8 7 69 8 7 6
5 4 3 2 1
9 8 7 6
Option Switches

- 6 -
INTERFACE CONNECTOR :
Pin 1
Reserved
Reserved
Reserved
Pin
Pin 1
Pin 10
Pin 9
Pin 18
13
Pin 14 /SEND
Pin 15 Reserved
Pin 16 Reserved
Pin 17 Reserved
Pin 18 Reserved
Pin 2 INTERRUPT
Pin 3
Pin 4 GROUND
Pin 5 /DATA
Pin 6 Reserved
Pin 7 Reserved
Pin 8 Reserved
Pin 9 Reserved
Pin 10 /OUT-OF-SERVICE
Pin 11 /DEBUG DATA
Pin 12 /ACCEPT ENABLE
N.I.S.R CONNECTOR
N.I.S.R PIN LOCATIONS
18-pin mating connector pin-out assignments:
- 7 -
(7) Cable

- 8 -
