iDule ID1MB-CL (B/W) User manual

1.2Mega CMOS Camera
ID1MB-CL (B/W)
ID1MC-CL (COLOR)
Technical Manual
iDule Corporation

Table of Contents
PAGE
1. Product Outline ............................................................................................................................................ 3
2. Handling Precautions ................................................................................................................................... 3
3. Specification ................................................................................................................................................ 4
3.1.General Specification ....................................................................................................................................... 4
3.2.Camera Output Signal Specification .................................................................................................................. 5
3.3.Spectral Response (Representative Value) ......................................................................................................... 6
4. Connector ..................................................................................................................................................... 7
4.1.Camera Link 12226-1100-00PL(3M) ................................................................................................................. 7
4.2.Power LED ..................................................................................................................................................... 7
4.3.12pin Connector HR10A-10R-12PB(74) HIROSE ............................................................................................... 8
5. Timing Chart ................................................................................................................................................ 9
5.1.Horizontal Synchronous Signals Timing (1Tap Base Configuration ) ................................................................... 9
5.2.Vertical Synchronous Signals Timing (1Tap Base Configuration) ........................................................................ 9
5.3.Horizontal Synchronous Signals Timing (1Tap Base Configuration / Fixed trigger shutter mode) ......................... 10
5.4.Vertical Synchronous Signals Timing (1Tap Base Configuration / Fixed trigger shutter mode) ............................. 10
5.5.Horizontal Synchronous Signals Timing (2Tap Base Configuration) .................................................................. 11
5.6.Vertical Synchronous Signals Timing (2Tap Base Configuration) ...................................................................... 11
5.7. Horizontal Synchronous Signals Timing (2Tap Base Configuration / Fixed trigger shutter mode) ........................ 12
5.8.Vertical Synchronous Signals Timing (2Tap Base Configuration / Fixed trigger shutter mode)............................. 12
5.9.Horizontal Synchronous Signals Timing (Base Configuration 24bit – RGB) ........................................................ 13
5.10.Vertical Synchronous Signals Timing (Base Configuration 24bit – RGB) .......................................................... 13
5.11.Horizontal Synchronous Signals Timing (Base Configuration 24bit – RGB / Fixed trigger shutter mode) ............. 14
5.12.Vertical Synchronous Signals Timing (Base Configuration 24bit – RGB / Fixed trigger shutter mode) ................. 14
5.13.Output format ............................................................................................................................................. 15
5.14.Fixed Trigger Shutter Mode .......................................................................................................................... 16
6. Scan Mode .................................................................................................................................................. 17
6.1.Partial scan mode ......................................................................................................................................... 17
6.2.Binning mode ............................................................................................................................................... 19
6.3.VGA mode .................................................................................................................................................... 20
6.4.QVGA mode.................................................................................................................................................. 21
7. Remote Communication ............................................................................................................................ 22
7.1.Command Specifications ................................................................................................................................ 23
7.2.Control Example ............................................................................................................................................ 27
8. Dimensions................................................................................................................................................. 36
9. Initial Setting ............................................................................................................................................. 37
10. Cases for Indemnity (Limited Warranty) .................................................................................................. 38
11. CMOS Pixel Defect ..................................................................................................................................... 38
12. Product Support ......................................................................................................................................... 38

1. Product Outline
ID1MB-CL/ID1MC-CL is a Camera Link interfaced and 1.2Mega resolution camera module.
1.2Mega pixels CMOS sensor with diagonal length 6mm is utilized. Entire pixels can be read out
within 1/54s at CL Base Configuration output.
Features
□ Global Shutter CMOS sensor is utilized.
□ Camera Link Base Configuration is supported.
□ Fixed trigger shutter mode.
□ Binning mode(2x2), VGA mode, QVGA mode.
2. Handling Precautions
The camera must not be used for any nuclear equipment or aerospace equipment with which mechanical
failure or malfunction could result in serious bodily injury or loss of human life. Our warranty does not apply to
dameges or defects caused by irregular and /or abnormal use of the product.
Please observe all warnings and cautions stated below.
Our warranty does not apply to damages or malfunctions caused by neglecting these precautions.
Do not use or store the camera in the following extreme conditions :
- Extremely dusty or humid places.
- Extremely hot or cold places (operating temperature -5℃ to +45℃).
- Close to generators of powerful electromagnetic radiation such as radio or TV transmitters.
- Places subject to fluorescent light reflections.
- Places subject to unstable (flickering, etc.) lighting conditions.
- Places subject to strong vibration.
· Remove dust or dirt on the surface of the lens with a blower.
· Do not apply excessive force or static electricity that could damage the camera.
· Do not shoot direct images that are extremely bright (e.g., light source, sun, etc.), and when camera is not
in use, put the lens cap on.
· Confirm the mutual ground potential carefully and then connect the camera to monitors or computers.
AC leaks from the connected devices may cause damages or destroy the camera.
· Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply
voltage may cause damages or malfunction of the camera.
· The voltage ripple of camera power DC +12V±10% shall be within ±50mV. Improper power supply
voltage may cause noises on the video signals.
· The rising time of camera power supply voltage shall be less than +10V, Max 60ms. Please avoid
noises like chattering when rising.

3. Specification
3.1.General Specification
(1) Image Sensor Type Diagonal length 6mm Global Shutter (ON SEMICONDUCTOR AR0135)
Effective Pixel Number 1288(H) x 972(V)
Cell Size 3.75μm(H) x 3.75μm(V)
Image Circle Full : Φ 6mm
VGA mode : Φ3mm
QVGA mode : Φ1.5mm
(2) Video Output
Frequency
Pixel CLK 74.25MHz (1Tap / 24bit-RGB) / 37.125MHz (2Tap)
Output effective pixel number Full : 1284(H) x 962(V)
VGA mode : 640(H) x 480(V)
QVGA mode : 320(H) x 240(V)
Frame rate Full : 54.08fps
VGA mode : 105.51fps
QVGA mode : 200.35fps
1388(H) x 989(V) : with Blanking
1388(H) x 507(V) : with Blanking
1388(H) x 267(V) : with Blanking
(3) Video Output 1Tap Base Configuration, 2Tap Base Configuration, Base Configuration 24bit – RGB
(4) Output Format Sensor AD 12bit
Camera Link 8bit / 10bit / 12bit
(5) Sensitivity B/W F8 2000lx
Color F5.6 2000lx
(at shutter speed 1/54s(OFF), Gain 0dB)
(6) Minimum
Illumination
B/W F1.4 4lx
Color F1.4 8lx
(at shutter speed 1/54s(OFF), Gain +12dB)
(7) Power Requirements DC+12V±10% (12pin / PoCL)
(8) Power Consumption typ 0.9 W
max 1.1 W
(9) Dimensions H:29.0mm W:29.0mm D:29.0mm excluding projection
(10) Weights Approx. 50g
(11) Lens Mount C Mount
(12) Gain 0dB ～ +12dB
(13) Shutter Speed OFF(1/54s) ～ 1/54000s(Normal mode)
OFF(1/45s) ～ 1/45000s (Trigger mode)
(14) Trigger mode Fixed trigger shutter mode
(15) Scan Mode Partial scan : Full Frame ～ 4 Line （4Line/Step） Partial Area : 1area
Binning mode : 640 x 480 line
VGA mode : 640 x 480 line
QVGA mode : 320 x 240 line
(16) Safety/
Quality Standards
CE To be applied for EN61000-6-4:2007+A1:2011 for Emission
To be applied for EN61000-6-2:2005 for Immunity
RoHS: Conform to RoHS
(17) Durability Vibration 20～200 Hz, 98m/s2 (10G), X,Y and Z directions (120 min for each direction)
Shock No malfunction shall be occurred with 980m/s2 (100G) for ±X,±Y,±Z, 6 directions.
(without package)
(18) Environment Operation 0℃ ～ +45℃ Humidity 0 ～ 90%RH
Storage -25℃ ～ +65℃ Humidity 0 ～ 90%RH

3.2.Camera Output Signal Specification
(1)Video Output Data Effective Video Output 1284(H) × 962(V) (at Full Frame Scan Mode)
(2)Sync Signal Output LVAL Camera Link (LVDS)
FVAL
DVA
SP(Exposure Signal)
(3)Camera Control
Signal Input
CC2・CC3・CC4 Camera Link Input(LVDS)
(4)Trigger Input Polarity Positive/Negative Selectable (Address 05)
CC1 Camera Link Input (LVDS) (Address 06)
(5)Serial
Communication
SerTC Camera Link (LVDS） (Serial to Camera)
SerTFG Camera Link (LVDS） (Serial to Frame Grabber)
(6)Video Signals White Clip Level
F
FEh (at Gain 0dB, 12bit)
Setup Level
under
0C0h
Dark Shading
Both horizontal and vertical should be
under
0FFh
(7)Trigger in CN1 CN1 : 11 pin
Low1.4V(max),High3.3V~5.0V
(Address 06)
(8)Exposure out CN1 CN1 : 6 pin
Low0.55V(max),High3
.8V(min)
(9)FVAL out CN1 CN1 : 7 pin
Low0.55V(max),High3.8V(min)
Trigger in CN1
Exposure / FVAL out CN1
5.0V
100Ω
SN74LVC1G32
(TI)
CN1 6pin,7pin
(Output)
5.0V
1KΩ
Signal
1KΩ
10KΩ
2SC4116
Delay approx 1.2μs.
5.0V
100Ω
SN74LVC1G14
(TI)
1.0KΩ
CN1 1pin
CN2 11pin
(Input)
Signal
2.2KΩ
2.2KΩ
Delay approx 50 ns.

3.3.Spectral Response (Representative Value)
ID1MB-CL (B/W)
ID1MC-CL (Color)

4. Connector
4.1.Camera Link 12226-1100-00PL(3M)
Connector (P1)
4.2.Power LED
Camera turns on LED light, when it is supplied electricity from the frame Grabber board.
PIN
NO
PIN
NO
1 +12V(PoCL) 14 GND
2 X0- 15 X0+
3 X1- 16 X1+
4 X2- 17 X2+
5 Xclk- 18 Xclk+
6 X3- 19 X3+
7 SerTC+ 20 SerTC-
8 SerTFG- 21 SerTFG+
9 CC1- (Trigger IN -) 22 CC1+ (Trigger IN +)
10 CC2+ 23 CC2-
11 CC3- 24 CC3+
12 CC4+ 25 CC4-
13 GND 26 +12V(PoCL)

4.3.12pin Connector HR10A-10R-12PB(74) HIROSE
*Do not supply power from both P1 and CN1.
PIN NO
1 GND
2 Power Input (DC+12V)
3 GND
4 NC
5 GND
6 FVAL out
7 Exposure out
8 GND
9 NC
10 NC
11 Trigger in
12 GND

5. Timing Chart
5.1.Horizontal Synchronous Signals Timing (1Tap Base Configuration )
5.2.Vertical Synchronous Signals Timing (1Tap Base Configuration)
LVAL Out
～ ～
Effective Data : 1284 CLK104 CLK
DVAL Out
1H = 1388 CLK
～ ～
Camera Link CLK : 74.25MHz
(Camera Link Port A) 1 2 ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
3 4
1
2
8
1
1
2
8
2
1
2
8
3
1
2
8
4
1
Video Out
～ ～
2
1
2
8
3
1
2
8
4
3 4
1
2
8
1
1
2
8
2
FVAL Out
1Frame = 989H (18.49ms)
Effective Line : 962H
DVAL Out
～ ～
LVAL Out
～ ～
～ ～～
～
V Blanking : 27H
9
6
2
9
6
2
1 1
1H = 18.694 us
Video Out

5.3.Horizontal Synchronous Signals Timing (1Tap Base Configuration / Fixed trigger shutter mode)
5.4.Vertical Synchronous Signals Timing (1Tap Base Configuration / Fixed trigger shutter mode)
LVAL Out
～ ～
Effective Data : 1284 CLK366 CLK
DVAL Out
1H = 1650 CLK
～ ～
Camera Link CLK : 74.25MHz
(Camera Link Port A) 1 2 ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
3 4
1
2
8
1
1
2
8
2
1
2
8
3
1
2
8
4
1
Video Out
～ ～
2
1
2
8
3
1
2
8
4
3 4
1
2
8
1
1
2
8
2
FVAL Out
1Frame = Exposure Time + 1015.5H (22.57ms)
Effective Line : 962H
DVAL Out
～ ～
LVAL Out
～ ～
～ ～～
～
8H
9
6
2
9
6
2
1 1
1H = 22.222 us
Video Out
TRIG IN
(Exposure
Time)
Number of
set lines
18.5H V Blanking : 27H

5.5.Horizontal Synchronous Signals Timing (2Tap Base Configuration)
5.6.Vertical Synchronous Signals Timing (2Tap Base Configuration)
LVAL Out
～ ～
Effective Data : 642 CLK52 CLK
DVAL Out
1H = 694 CLK
～ ～
Camera Link CLK : 37.125MHz
(Camera Link Port A) 1・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
31281 1283
1
Video Out
～ ～
2
1
2
8
3
1
2
8
4
3 4
1
2
8
1
1
2
8
2
(Camera Link Port B) 2 4 1282 1284
FVAL Out
1Frame = 989H (18.49ms)
Effective Line : 962H
DVAL Out
～ ～
LVAL Out
～ ～
～ ～～
～
V Blanking : 27H
9
6
2
9
6
2
1 1
1H = 18.694 us
Video Out

5.7. Horizontal Synchronous Signals Timing (2Tap Base Configuration / Fixed trigger shutter mode)
5.8.Vertical Synchronous Signals Timing (2Tap Base Configuration / Fixed trigger shutter mode)
LVAL Out
～ ～
Effective Data : 642 CLK183 CLK
DVAL Out
1H = 825 CLK
～ ～
Camera Link CLK : 37.125MHz
1
Video Out
～ ～
2
1
2
8
3
1
2
8
4
3 4
1
2
8
1
1
2
8
2
(Camera Link Port A) 1・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
31281 1283
(Camera Link Port B) 2 4 1282 1284
FVAL Out
1Frame = Exposure Time + 1015.5H (22.57ms)
Effective Line : 962H
DVAL Out
～ ～
LVAL Out
～ ～
～ ～～
～
8H
9
6
2
9
6
2
1 1
1H = 22.222 us
Video Out
TRIG IN
(Exposure
Time)
Number of
set lines
18.5H V Blanking : 27H

5.9.Horizontal Synchronous Signals Timing (Base Configuration 24bit – RGB)
5.10.Vertical Synchronous Signals Timing (Base Configuration 24bit – RGB)
LVAL Out
～ ～
Effective Data : 1284 CLK104 CLK
DVAL Out
1H = 1388 CLK
～ ～
Camera Link CLK : 74.25MHz
R
1
Video Out
～ ～
G
1
G
1
2
8
4
B
1
2
8
4
B
1
R
2
B
1
2
8
3
R
1
2
8
4
(Camera Link Port A) R1 R2 R1283 R1284
(Camera Link Port B) G1 G2 ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ G1283 G1284
(Camera Link Port C) B1 B2 B1283 B1284
G
2
B
2
G
1
2
8
3
R
1
2
8
3
FVAL Out
1Frame = 989H (18.49ms)
Effective Line : 962H
DVAL Out
～ ～
LVAL Out
～ ～
～ ～～
～
V Blanking : 27H
9
6
2
9
6
2
1 1
1H = 18.694 us
Video Out

5.11.Horizontal Synchronous Signals Timing (Base Configuration 24bit – RGB / Fixed trigger shutter mode)
5.12.Vertical Synchronous Signals Timing (Base Configuration 24bit – RGB / Fixed trigger shutter mode)
LVAL Out
～ ～
Effective Data : 1284 CLK366 CLK
DVAL Out
1H = 1650 CLK
～ ～
Camera Link CLK : 74.25MHz
R
1
Video Out
～ ～
G
1
G
1
2
8
4
B
1
2
8
4
B
1
R
2
B
1
2
8
3
R
1
2
8
4
(Camera Link Port A) R1 R2 R1283 R1284
(Camera Link Port B) G1 G2 ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ G1283 G1284
(Camera Link Port C) B1 B2 B1283 B1284
G
2
B
2
R
1
2
8
3
G
1
2
8
3
FVAL Out
1Frame = Exposure Time + 1015.5H (22.57ms)
Effective Line : 962H
DVAL Out
～ ～
LVAL Out
～ ～
～ ～～
～
8H
9
6
2
9
6
2
1 1
1H = 22.222 us
Video Out
TRIG IN
(Exposure
Time)
Number of
set lines
18.5H V Blanking : 27H

5.13.Output format
1Tap Base Configuration
ID1MB-CL ID1MC-CL
2Tap Base Configuration
ID1MB-CL ID1MC-CL
Base Configuration 24bit – RGB
Only ID1MC-CL
～
～～ ～
962 Line
1284pixel
・・・G2B1
G
1283
R
1284
G
1284
B
1283
G
1284
D
1283
D
1284
・・・D2
～
～～ ～
962 Line
1284pixel
D1
～
～～ ～
962 Line
1284pixel
・・・G2B1
G
1283
R
1284
G
1284
B
1283
D
1283
D
1284
・・・D2
～
～～ ～
962 Line
1284pixel
D1 D4D3 D
1281
D
1282 G4B3 G 1282
B
1281
G
1281
R
1282
R
1284
B1 G
1284
B
1284
・・・G1
～
～ ～
～
962 Line
1284pixel
R1 B2G2R2

5.14.Fixed Trigger Shutter Mode
□ This is the mode to start exposure with external input trigger signals, and set the exposure time with serial
commands.
□ Delay time (Exposure Time Delay) from detecting trigger edge in the camera to starting exposure is as below.
Exposure time delay (A)
178 us (8H) *1H = 22.22us
□ Do not input a trigger signal with an exposure setting that will start the next image output during
the exposure period and before the image output is completed.
Possible trigger input interval = Exposure Time Delay + Exposure Time + Effective Line + 18.5H + 27H
Example: Exposure time 1 / 1000s (45H), effective line 962H
Exposure Time Delay 8H + Exposure Time 45H + Effective Line 962H + 45.5H
= 23.57ms (1060.5H)
* 1H = 22.22us
□ Trigger inputs during the exposure period (B) and during image output (C) are ignored in the camera.
TRIG IN
(A)
Exposure Time
Effective Line : 962H
～ ～
Exposure Time
(Exposure Out)
9
6
2
1
TRIG IN
LVAL Out
FVAL Out
Video Out
DVAL Out
Exposure Time(A)
Exposure Time
Delay
(B)
18.5H 27H
(C)
(Trigger input ignore period)

6. Scan Mode
6.1.Partial scan mode
□ It is possible to increase the frame rate by limiting the vertical scan area.
□ Set the partial area with the communication command.
Vertical start position address: 40 --41
Partial scan number of valid lines Address: 50 – 51
□ Does not work in VGA mode or QVGA mode.
Setting Example
Normal shutter mode
① : V blanking ： 27H
② : Vertical start position ： 120H
③ : Partial scan effective line number ： 480H
④ : Total frame line number ： 507H(①＋③)
Fixed trigger shutter mode *Example : Exposure time : 1/1000s(45H)
① : V blanking ： 53.5H
② : Vertical start position ： 120H
③ : Partial scan effective line number ： 480H
④ : Exposure line number ： 45H
⑤ : Total frame line number ： 578.5H(①＋③＋④)
FVAL
LVAL
①
④
③
Video Out
ｽﾀｰﾄﾎﾟｼﾞｼｮﾝ
②
有効ライン数
FVAL
LVAL
④
⑤
③
Video Out
ｽﾀｰﾄﾎﾟｼﾞｼｮﾝ
②
有効ライン数
Exposure Time
TRIG IN
① (a+b+c)
a b c

□ Set the start position to 2 x n and the number of valid lines to 4 x n based on 0 (maximum is fixed at 962).
However, the vertical start position + number of effective lines <= 962 must be satisfied.
□ Total number of frames for several hours
Normal shutter mode
= Number of V blanking lines (27H) + Number of valid lines
Fixed trigger shutter mode
= Exposure time + Number of V blanking lines (53.5H) + Number of effective lines
□ Frame Rate = 1 / (Total lines x Time for 1 line)
Time for 1 line = 18.69us (Normal shutter mode) / 22.22us (Fixed trigger shutter mode)
□ Example
Normal shutter mode
Effective lines Frame rate (Total lines)
4H (min) 1725.6fps (31H)
240H, QVGA mode 200.3 (267)
320H 154.1 (347)
480H, VGA mode 105.5 (507)
640H 80.201 (667)
720H 71.61 (747)
962H (max:Full frame) 54.08 (989)
Fixed trigger shutter mode (*Exposure time : 1/1000s (45H))
Effective lines
Exposure
lines
Frame rate (Total lines)
4H (min) 45H 439.02fps (102.5H)
240H, QVGA mode 45H 132.93 (338.5)
320H 45H 107.52 (418.5)
480H, VGA mode 45H 77.78 (578.5)
640H 45H 60.93 (738.5)
720H 45H 54.97 (818.5)
962H (max:Full frame) 45H 42.43 (1060.5)
The frame rate of the fixed shutter trigger mode varies depending on the input trigger signal.
This is an example of the MAX frame rate that can be set.

6.2.Binning mode
□ 2 horizontal pixels and 2 vertical pixels are added (averaged) to 1 pixel and output.
□ The number of pixels is 640 x 480, and the amount of transferred data can be reduced without changing the angle of view.
□ The frame rate is the same as the output of all pixels.
□ Set to binning mode with a communication command.
962 Line
640pixel
B
1284pixel
480 Line

6.3.VGA mode
□ VGA mode 640 x 480 pixels are cut out from all pixels and output.
□ There are fewer lines and the frame rate goes up to 105.51fps.
□ Set to VGA mode with a communication command.
□ The start position can be set by communication command both horizontally and vertically.
Horizontal start position address: 42 – 43 h
Vertical start position address: 40 – 41 h * Similar to partial scan mode
□ Set the start position to 2 x n.
However,
Satisfy the horizontal start position + 640 <= 1284.
Satisfy the vertical start position + 480 <= 962.
* The initial data of the horizontal start position is 0000 h and the center position is 0140 h (320).
□ The shutter mode operates as follows.
Address: 01 h
Normal shutter mode
Data 00-02 h: 1/105s (OFF)
Subsequent data is the same as in full frame scan mode
Fixed shutter trigger mode
Data 00-01 h: 1 / 89s (OFF)
Subsequent data is the same as in full frame scan mode
Data: 0F h Manual shutter,
Address: 24 – 25 h, data (set value) 01E2 h (482) or higher
962 Line
1284pixel
480 Line
640pixel
