IEI Technology MPCIE-LAN-R10 User manual

1
Mini PCI Express GbE LAN module, Full size, RoHs
MPCIE-LAN-R10
Quick Installation Guide
Version 1.0
May 27, 2013
Package List
MPCIE-LAN-R10 package includes the following items:
1 x MPCIE-LAN module
1 x Flat Cable (Pitch=1.25mm)
1x QIG
©2006 Copyright by IEI Technology corp.
All rights reserved.
All manuals and user guides at all-guides.com
all-guides.com

2
Features:
1. Support one GbE LAN by RTL8111E
2. Compliant with PCI Express Mini Card specification 1.2
Specifications
Form Factor:PCI Express mini card
Display Controller IC:Realtek RTL8111E
Speed:10/100/1000Mbps
External Connector:1 x 8-pin RJ-45
Power Supply:On board 3.3V
Compitable OS:
Windows 2000/ XP/ Server 2003/ Server 2008/ Vista/ 7
Linux kernel version 2.6.32 above
Operating Temperature: -10℃~ 70℃
Operating Humidity: 5% ~95%, non-condensing
Diemension (LxW): 51mm x 30mm
Weight: 70g
Ordering Information
Mini PCI Express GbE LAN module, Full size, RoHs MPCIE-LAN-R10:
All manuals and user guides at all-guides.com

3
Jumpers setting and connectors
LABEL
FUNCTION
J4 LAN connector
J5 LAN connector
J5: LAN connector (WAFER 1*12 WITH FRAME,12PIN,90D,P:1.25mm)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+V3.3MINI_LAN_R
2
LAN2_LED0_R
3
LAN2_LED3/EEDO_R
4
LAN2_LED1/EESK_R
5
LAN2_MDI0+_R
6
LAN2_MDI0-_R
7
LAN2_MDI1+_R
8
LAN2_MDI1-_R
9
LAN2_MDI2+_R
10
LAN2_MDI2-_R
11
LAN2_MDI3+_R
12
LAN2_MDI3-_R
J4: LAN connector (WAFER 1*12 WITH FRAME,12PIN,90D,P:1.25mm
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+V3.3MINI_LAN
2
LAN1_LED0
3
LAN1_LED3/EEDO
4
LAN1_LED1/EESK
5
LAN1_MDI0+
6
LAN1_MDI0-
7
LAN1_MDI1+
8
LAN1_MDI1-
9
LAN1_MDI2+
10
LAN1_MDI2-
11
LAN1_MDI3+
12
LAN1_MDI3-
All manuals and user guides at all-guides.com

4
Board Layout: Jumper and Connector Locations
（Unit: mm）
