PulM Series
PulM-10G4T-AQC107
Networking Module Quick Installation Guide
Torx Screws x 2 Torx Wrench x 1
PulM-10G4T-AQC107
Package Contents PulM-10G4T-AQC107 Block Diagram
LAN LED Status
A32 A19
B
A32 A19
A
Slot A
PCIe Conguration
x4
x8
x4
Slot B
PCIe Conguration
x4
x2 x2 x2 x2
x4
A19 A32 PCIe Cong. Slot
0 0 4x2 B
0 1 2x4 A & B
1 0 1x8 A
PCH
CPU
Hardware Installation
Install the PulM-10G4T-AQC107 networking module into the slot
of the PUZZLE series. The Slot A supports 8 lanes from CPU (1 PCIe
x8 or 2 PCIe x4); the Slot B supports 8 lanes from PCH (2 PCIe x4 or
4 PCIe x2). When the PulM-10G4T-AQC107 is installed into the slot
A, only two LAN ports (port 1 & port 3 ) are active.
Four PCIe x2 or
Two PCIe x4
One PCIe x8 or
Two PCIe x4
DMI GEN3 x4
Slot A Slot B
Ethernet 10G
Ethernet 10G
Ethernet 10G
Ethernet 10G
PCIe 3.0
A19
A32
4 PCIe 3.0 x2
A19
0
A32PCIe CONF. MODE
0Four x2
AQC107
AQC107
AQC107
AQC107
RJ-45
RJ-45
RJ-45
RJ-45
LAN Port
Link
LED
Speed
LED
LED State Description
Yellow Active
Speed (Right)
Link (Left)
Orange 10 Gbps date rate
Green 5 Gbps/1 Gbps/ 100 Mbps

Networking Module Installation
Use the Torx wrench to remove the two Torx screws. Remove the slot cover. Save the slot cover screws.
Slide an IEI networking module into the slot until the module
is seated in the slot correctly and securely.
1
Step 2 Step
3
Step
Install the previously-removed Torx screws to secure the module
to the chassis.
4
Step
