IEI Technology TANK-6000-C226i-E3/4G-R10 User manual

TANK-6000-C226 Embedded System
Page i
User Manual
,
MODEL:
TANK-6000-C226
Embedded system supports 22nm LGA1155 Intel®Xeon®E3 /Core™
i3 CPU, HDMI, VGA, GbE, Two USB 2.0, Four USB 3.0,
Two COMand RoHS Compliant
Rev. 1.00 – 14 March 2014

TANK-6000-C226 Embedded System
Page ii
Revision
Date Version Changes
14 March 2014 1.00 Initial release

TANK-6000-C226 Embedded System
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

TANK-6000-C226 Embedded System
Page iv
Ta b le ofContents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 MODEL VARIATIONS ................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 TECHNICAL SPECIFICATIONS ...................................................................................... 3
1.5 FRONT PANEL............................................................................................................. 4
1.6 REAR PANEL............................................................................................................... 5
1.7 DIMENSIONS............................................................................................................... 7
2 UNPACKING................................................................................................................. 8
2.1ANTI-STATIC PRECAUTIONS........................................................................................ 9
2.2 UNPACKING PRECAUTIONS......................................................................................... 9
2.3 UNPACKING CHECKLIST........................................................................................... 10
3 INSTALLATION ......................................................................................................... 12
3.1 INSTALLATION PRECAUTIONS................................................................................... 13
3.2 INSTALLATION AND CONFIGURATION STEPS ............................................................. 13
3.3 HARD DISK DRIVE (HDD) INSTALLATION................................................................ 14
3.3.1 Serial ATA 2.0 Drive Installation..................................................................... 14
3.3.2 Serial ATA 3.0 Drive Installation..................................................................... 16
3.4 PCIE EXPANSION CARD INSTALLATION (OPTIONAL)................................................ 17
3.5AT/ATX MODE SELECTION...................................................................................... 19
3.5.1 AT Power Mode................................................................................................ 19
3.5.2 ATX Power Mode............................................................................................. 19
3.6 RESET THE SYSTEM.................................................................................................. 20
3.7 MOUNTING THE SYSTEM WITH MOUNTING BRACKETS ............................................ 20
3.8 EXTERNAL PERIPHERAL INTERFACE CONNECTORS................................................... 21
3.8.1 Audio Connection............................................................................................. 22
3.8.2 HDMI Device Connection................................................................................ 23
3.8.3 LAN Connection............................................................................................... 23
3.8.4 DB-9 Serial Port Connection........................................................................... 24

TANK-6000-C226 Embedded System
Page v
3.8.5 USB Device Connection................................................................................... 25
3.8.6 VGA Monitor Connection ................................................................................ 26
4 SYSTEM MOTHERBOARD ..................................................................................... 28
4.1 MOTHERBOARD LAYOUT.......................................................................................... 29
4.2 INTERNAL PERIPHERAL CONNECTORS ...................................................................... 30
4.2.1 12 V Power Connector (CN1).......................................................................... 30
4.2.2 Battery Connector (BAT1) ............................................................................... 31
4.2.3 BMC Debug Connector (J2_BMC).................................................................. 31
4.2.4 EC Debug Port Connector (CN2).................................................................... 31
4.2.5 Fan Connectors (CPU_FAN1, SYS_FAN2)...................................................... 32
4.2.6 Flash BIOS ROM Connector (JSPI1).............................................................. 32
4.2.7 Flash EC ROM Connector (JSPI2).................................................................. 32
4.2.8 Flash BMC ROM Connector (SPI1)................................................................ 33
4.2.9 OLED Connector (OLED1)............................................................................. 33
4.2.10 Power on Connector (CN3)........................................................................... 33
4.2.11 Serial ATA 3.0 connectors (SATA1)................................................................ 34
4.3 EXTERNAL INTERFACE PANEL CONNECTORS ............................................................ 34
4.3.1 Audio Input & Output Connectors (MIC1, AUDIO1)...................................... 35
4.3.2 DC-in Power Connector (U56)........................................................................ 35
4.3.3 Ethernet Connectors (LAN1_2) ....................................................................... 35
4.3.4 Ethernet Connectors (LAN3, LAN4)................................................................ 36
4.3.5 External Fiber Connectors (SFPLAN1, SFPLAN 2) ....................................... 36
4.3.6 HDMI Connector (HDMI1)............................................................................. 36
4.3.7 RS-232 Serial Port (COM1_2)......................................................................... 37
4.3.8 USB 3.0 Connectors (USB_CON1, USB_CON2)............................................ 37
4.3.9 USB 3.0 Connectors (USB_CON4).................................................................. 37
4.3.10 USB 2.0 Connectors (USB_CON3)................................................................ 38
4.3.11 VGA Connector (VGA1)................................................................................. 38
5 BIOS.............................................................................................................................. 39
5.1 INTRODUCTION......................................................................................................... 40
5.1.1 Starting Setup................................................................................................... 40
5.1.2 Using Setup...................................................................................................... 40
5.1.3 Getting Help..................................................................................................... 41

TANK-6000-C226 Embedded System
Page vi
5.1.4 Unable to Reboot after Configuration Changes.............................................. 41
5.1.5 BIOS Menu Bar................................................................................................ 41
5.2 MAIN........................................................................................................................ 42
5.3ADVANCED............................................................................................................... 44
5.3.1 ACPI Settings................................................................................................... 45
5.3.2 RTC Wake Settings........................................................................................... 46
5.3.3 CPU Information.............................................................................................. 47
5.3.4 SATA Configuration ......................................................................................... 50
5.3.5 Intel(R) Rapid Start Technology....................................................................... 51
5.3.6 AMT Configuration.......................................................................................... 52
5.3.7 USB Configuration........................................................................................... 53
5.3.8 F81866 Super IO Configuration...................................................................... 54
5.3.8.1 Serial Port n Configuration....................................................................... 55
5.3.9 iWDD H/W Monitor......................................................................................... 57
5.3.9.1 Smart Fan Mode Configuration................................................................ 58
5.3.10 Serial Port Console Redirection .................................................................... 59
5.3.11 iEi Feature...................................................................................................... 62
5.4 CHIPSET ................................................................................................................... 63
5.4.1 PCH-IO Configuration .................................................................................... 64
5.4.1.1 PCH Azalia Configuration........................................................................ 65
5.4.2 System Agent (SA) Configuration .................................................................... 66
5.4.2.1 Graphics Configuration............................................................................. 67
5.4.2.2 NB PCIe Configuration............................................................................. 70
5.4.2.3 Memory Configuration ............................................................................. 71
5.5 BOOT........................................................................................................................ 72
5.6 SECURITY................................................................................................................. 74
5.7 EXIT......................................................................................................................... 74
ASAFETY PRECAUTIONS......................................................................................... 76
A.1 SAFETY PRECAUTIONS ............................................................................................ 77
A.1.1 General Safety Precautions............................................................................. 77
A.1.2 Anti-static Precautions .................................................................................... 78
A.1.3 Product Disposal ............................................................................................. 79
A.2 MAINTENANCE AND CLEANING PRECAUTIONS........................................................ 79
A.2.1 Maintenance and Cleaning.............................................................................. 79

TANK-6000-C226 Embedded System
Page vii
A.2.2 Cleaning Tools................................................................................................. 80
B BIOS MENU OPTIONS............................................................................................. 81
C ONE KEY RECOVERY............................................................................................. 84
C.1 ONE KEY RECOVERY INTRODUCTION ...................................................................... 85
C.1.1 System Requirement ........................................................................................ 86
C.1.2 Supported Operating System........................................................................... 87
C.2 SETUP PROCEDURE FOR WINDOWS.......................................................................... 88
C.2.1 Hardware and BIOS Setup.............................................................................. 89
C.2.2 Create Partitions............................................................................................. 89
C.2.3 Install Operating System, Drivers and Applications....................................... 93
C.2.4 Building the Recovery Partition...................................................................... 94
C.2.5 Create Factory Default Image ........................................................................ 96
C.3AUTO RECOVERY SETUP PROCEDURE.................................................................... 101
C.4 SETUP PROCEDURE FOR LINUX.............................................................................. 105
C.5 RECOVERY TOOL FUNCTIONS ................................................................................ 109
C.5.1 Factory Restore..............................................................................................110
C.5.2 Backup System................................................................................................111
C.5.3 Restore Your Last Backup...............................................................................112
C.5.4 Manual ...........................................................................................................113
C.6 RESTORE SYSTEMS FROM A LINUX SERVER THROUGH LAN...................................114
C.6.1 Configure DHCP Server Settings...................................................................115
C.6.2 Configure TFTP Settings................................................................................116
C.6.3 Configure One Key Recovery Server Settings................................................117
C.6.4 Start the DHCP, TFTP and HTTP..................................................................118
C.6.5 Create Shared Directory.................................................................................118
C.6.6 Setup a Client System for Auto Recovery.......................................................119
C.7 OTHER INFORMATION............................................................................................ 122
C.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller ...................... 122
C.7.2 System Memory Requirement........................................................................ 124
D HAZARDOUS MATERIALS DISCLOSURE....................................................... 125
D.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 126

TANK-6000-C226 Embedded System
Page viii
List of Figures
Figure 1-1: TANK-6000-C226 .........................................................................................................2
Figure 1-2: TANK-6000-C226 Front Panel ....................................................................................5
Figure 1-3: TANK-6000-C226 Rear Panel .....................................................................................6
Figure 1-4: Physical Dimensions (mm) ........................................................................................7
Figure 3-1: HDD Cover Retention Screws..................................................................................14
Figure 3-2: HDD Bracket Retention Screws...............................................................................15
Figure 3-3: Inserting the HDD......................................................................................................15
Figure 3-4: HDD Drive Bay...........................................................................................................16
Figure 3-5: HDD Bracket Retention Screws...............................................................................16
Figure 3-6: Installing the HDD .....................................................................................................17
Figure 3-7: Unscrew the cover....................................................................................................17
Figure 3-8: Expansion Slot Retention Screw.............................................................................18
Figure 3-9: Install PCIe Card........................................................................................................18
Figure 3-10: AT/ATX Switch Location.........................................................................................19
Figure 3-11: Reset Button Location............................................................................................20
Figure 3-12: Mounting Bracket Retention Screws ....................................................................21
Figure 3-13: Audio Connector.....................................................................................................22
Figure 3-14: HDMI Connection ....................................................................................................23
Figure 3-15: LAN Connection......................................................................................................24
Figure 3-16: DB-9 Serial Port Connector....................................................................................25
Figure 3-18: USB Device Connection.........................................................................................26
Figure 3-19: VGA Connector .......................................................................................................27
Figure 4-1: Motherboard Layout Diagram..................................................................................29
Figure C-1: IEI One Key Recovery Tool Menu...........................................................................85
Figure C-2: Launching the Recovery Tool.................................................................................90
Figure C-3: Recovery Tool Setup Menu .....................................................................................90
Figure C-4: Command Prompt ....................................................................................................91
Figure C-5: Partition Creation Commands.................................................................................92
Figure C-6: Launching the Recovery Tool.................................................................................94
Figure C-7: Manual Recovery Environment for Windows........................................................94

TANK-6000-C226 Embedded System
Page ix
Figure C-8: Building the Recovery Partition..............................................................................95
Figure C-9: Press Any Key to Continue .....................................................................................95
Figure C-10: Press F3 to Boot into Recovery Mode..................................................................96
Figure C-11: Recovery Tool Menu ..............................................................................................96
Figure C-12: About Symantec Ghost Window...........................................................................97
Figure C-13: Symantec Ghost Path ............................................................................................97
Figure C-14: Select a Local Source Drive ..................................................................................98
Figure C-15: Select a Source Partition from Basic Drive .........................................................98
Figure C-16: File Name to Copy Image to ..................................................................................99
Figure C-17: Compress Image.....................................................................................................99
Figure C-18: Image Creation Confirmation..............................................................................100
Figure C-19: Image Creation Complete....................................................................................100
Figure C-20: Image Creation Complete....................................................................................100
Figure C-21: Press Any Key to Continue .................................................................................101
Figure C-22: Auto Recovery Utility...........................................................................................102
Figure C-23: Launching the Recovery Tool.............................................................................102
Figure C-24: Auto Recovery Environment for Windows ........................................................102
Figure C-25: Building the Auto Recovery Partition.................................................................103
Figure C-26: Factory Default Image Confirmation ..................................................................103
Figure C-27: Image Creation Complete....................................................................................104
Figure C-28: Press any key to continue ...................................................................................104
Figure C-29: Partitions for Linux...............................................................................................106
Figure C-30: Manual Recovery Environment for Linux ..........................................................107
Figure C-31: Access menu.lst in Linux (Text Mode)...............................................................108
Figure C-32: Recovery Tool Menu ............................................................................................108
Figure C-33: Recovery Tool Main Menu...................................................................................109
Figure C-34: Restore Factory Default.......................................................................................110
Figure C-35: Recovery Complete Window...............................................................................111
Figure C-36: Backup System.....................................................................................................111
Figure C-37: System Backup Complete Window ....................................................................112
Figure C-38: Restore Backup ....................................................................................................112
Figure C-39: Restore System Backup Complete Window......................................................113
Figure C-40: Symantec Ghost Window ....................................................................................113

TANK-6000-C226 Embedded System
Page x
List of Tables
Table 1-1: Model Variations...........................................................................................................2
Table 1-2: Technical Specifications..............................................................................................4
Table 2-1: Package List Contents...............................................................................................11
Table 4-1: Peripheral Interface Connectors...............................................................................30
Table 4-2: 12 V Power Connector (CN1) Pinouts.......................................................................30
Table 4-3: Battery Connector (BAT1) Pinouts ...........................................................................31
Table 4-4: BMC Debug Connector (J2_BMC) Pinouts ..............................................................31
Table 4-5: EC Debug Port Connector (CN2) Pinouts ................................................................31
Table 4-6: Fan Connectors (CPU_FAN1, SYS_FAN2) Pinouts.................................................32
Table 4-7: Flash BIOS ROM Connector (JSPI1) Pinouts...........................................................32
Table 4-8: Flash EC ROM Connector (JSPI2) Pinouts ..............................................................32
Table 4-9: Flash BMC ROM Connector (SPI1) Pinouts.............................................................33
Table 4-10: OLED Connector (OLED1) Pinouts.........................................................................33
Table 4-11: Power on Connector (CN3) Pinouts........................................................................33
Table 4-12: Serial ATA 3.0 connectors (SATA1) Pinouts..........................................................34
Table 4-13: Rear Panel Connectors............................................................................................35
Table 4-14: Audio Input & Output Connectors (MIC1, AUDIO1) Pinouts ................................35
Table 4-15: DC-in Power Connector (U56) Pinouts...................................................................35
Table 4-16: Ethernet Connector (LAN1_2) Pinouts...................................................................35
Table 4-17: Ethernet Connector (LAN3, LAN4) Pinouts............................................................36
Table 4-18: External Fiber Connectors (SFPLAN1, SFPLAN 2) Pinouts.................................36
Table 4-19: HDMI Connector (HDMI1) Pinouts...........................................................................37
Table 4-20: RS-232 Serial Port (COM1_2) Pinouts ....................................................................37
Table 4-21: USB 3.0 Connector (USB_CON1, USB_CON2) Pinouts........................................37
Table 4-22: USB 3.0 Connector (USB_CON4) Pinouts..............................................................38
Table 4-21: USB 3.0 Connector (USB_CON3) Pinouts..............................................................38
Table 4-23: VGA Connector (VGA1) Pinouts .............................................................................38
Table 5-1: BIOS Navigation Keys................................................................................................41

TANK-6000-C226 Embedded System
Page 1
Chapter
1
1Introduction

TANK-6000-C226 Embedded System
Page 2
1.1 Overview
Figure 1-1: TANK-6000-C226
The TANK-6000-C226 embedded system is with one VGA port and one HDMI port for
dual display. It accepts an Intel® Xeon® E3 / Core™ i3 CPU and supports four 240-pin
DDR3 U-DIMM modules up to 64 GB. The TANK-6000-C226 supports one 2.5” SATA
HDD with up to 3 Gb/s data transfer rate and two 2.5” SATA HDDs with up to 6 Gb/s data
transfer rate. Two serial ports, two external USB 2.0 ports and four external USB 3.0 ports
ensure simplified connectivity to a variety of external peripheral devices.
1.2 ModelVariations
The model variations of the TANK-6000-C226 series are listed below.
Models CPU
TANK-6000-C226i-E3/4G-R10 Intel® quad-core Xeon® E3-1225 v3 3.2GHz (TDP 84W)
TANK-6000-C226i-i3/4G-R10 Intel® dual-core Core™ i3- 4330 3.5GHz (TDP 54W)
Table 1-1: Model Variations

TANK-6000-C226 Embedded System
Page 3
1.3 Features
The TANK-6000-C226 features are listed below:
LGA1155 socket supports Intel® Xeon® E3 / Core™ i3 CPU (up to 95W
CPU )
4 x 240-pin DDR3 U-DIMM (system max: 64GB)
Extended temperature design supports -20°C to 55°C
Easy to install Hard Disk Drive (HDD)
USB 3.0 for high super speed data transfer
Programmable OLED display
RoHS compliant
1.4 TechnicalSpecifications
The TANK-6000-C226 technical specifications are listed in 331HTable 1-2.
Chassis
Color Black
Dimensions (WxHxD) 310 mm x 199.5 mm x 112 mm
System Fan 92 x 92 mm Fan
Chassis Construction Extruded aluminum alloy
Heavy duty steel sheet
Motherboard
CPU LGA1155 socket supports Intel® Xeon® E3 / Core™ i3 CPU (up to
95W CPU )
Chipset Intel® C226
Memory 4 x 240-pin DDR3 U-DIMM (system max: 64GB)
Storage
SATA 3 x 2.5'' HDD/SSD storage
(1 x SATA 3Gb/s, 2 x SATA 6Gb/s)

TANK-6000-C226 Embedded System
Page 4
I/O interfaces
USB 4 x USB 3.0
2 x USB 2.0
Ethernet 1 x RJ-45 for Intel® i217 PHY with AMT 8.0 supported
3 x RJ-45 for Intel® i210
RS-232 2 x RS-232 (DB-9 connector)
Display 1 x HDMI
1 x VGA
Audio 1 x Line out
1 x Mic
Other SFP Fiber, COMBO with LAN1 & LAN2
Expansions
PCIe 2 x PCIe by 8
Power
Power Supply 19V/24V DC
Reliability
Mounting Wall mount
Operating Temperature -20°C ~ 55°C with air flow (SSD)
Operating Humidity 10% ~ 90%, non-condensing
Operating Shock Half-sine wave shock 5G, 11ms, 3 shocks per axis
Operating Vibration MIL-STD-810F 514.5C-2 (with SSD)
Safety/EMC CE/FCC
Supported OS Microsoft® WES7E
Microsoft® Windows® XP Embedded
Table 1-2: Technical Specifications
1.5 Front Panel
The front panel of the TANK-6000-C226 has the following features (Figure 1-2):

TANK-6000-C226 Embedded System
Page 5
2 x HDD/SSD bay
1 x OLED display
1 x Power button
2 x USB 3.0 connectors
Figure 1-2: TANK-6000-C226 Front Panel
1.6 Rear Panel
The rear panel of the TANK-6000-C226 has the following features (Figure 1-3):
1 x 4-pin power jack for 19V/24V power input
1 x 4-pin terminal block for 19V/24V power input
1 x AT/ATX Switch
1 x HDMI port
1 x Line-out port (green)
1 x Mic-in port (pink)
1 x Reset button
2 x RJ-45 combo Gigabit LAN ports
2 x RJ-45 LAN connectors
2 x RS-232 (DB-9 connector)
2 x SFP Fiber combo Gigabit LAN ports
2 x USB 2.0 connectors
2 x USB 3.0 ports
1 x VGA port

TANK-6000-C226 Embedded System
Page 6
Figure 1-3: TANK-6000-C226 Rear Panel

TANK-6000-C226 Embedded System
Page 7
1.7 Dimensions
The physical dimensions are shown below:
Figure 1-4: Physical Dimensions (mm)

TANK-6000-C226 Embedded System
Page 8
Chapter
2
2Unpacking

TANK-6000-C226 Embedded System
Page 9
2.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during installation may result in
permanent damage to the TANK-6000-C226 and severe injury to the
user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the TANK-6000-C226. Dry climates are especially susceptible to ESD. It is
therefore critical that whenever the TANK-6000-C226 or any other electrical component is
handled, the following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board, touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the TANK-6000-C226, place it on
an antic-static pad. This reduces the possibility of ESD damaging the
TANK-6000-C226.
2.2 Unpacking Precautions
When the TANK-6000-C226 is unpacked, please do the following:
Follow the anti-static precautions outlined in Section 333H2.1.
Make sure the packing box is facing upwards so the TANK-6000-C226 does
not fall out of the box.
Make sure all the components shown in Section 334H2.3 are present.

TANK-6000-C226 Embedded System
Page 10
2.3 Unpacking Checklist
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the TANK-6000-C226 from or contact an IEI
sales representative directly. To contact an IEI sales representative,
please send an email to 165Hs[email protected].tw.
The TANK-6000-C226 is shipped with the following components:
Quantity Item and Part Number Image
1 TANK-6000-C226 embedded system
1 Power adapter
(P/N: 63040-010220-000-RS)
1 Power cord
(P/N:32702-000200-100-RS)
2 Mounting brackets
(P/N: 41020-0378C2-00-RS)
2 Keys
