IEI Technology TANK-760 User manual

TANK-760 Embedded System
Page i
User Manual
MODEL:
TANK-760
High Performance Fanless Embedded System with Intel® Core i5-4400E/
Celeron 2000E processor, VGA, HDMI, DisplayPort,
9-36V DC input and RoHS Compliant
Rev. 1.01 – 5 December 2014

TANK-760 Embedded System
Page ii
Revision
Date Version Changes
5 December, 2014 1.01 Update Section 3.7.4: CAN-bus Terminal Blocks Pinouts
22 August, 2014 1.00 Initial release

TANK-760 Embedded System
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

TANK-760 Embedded System
Page iv
Ta b le of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 MODEL VARIATIONS ................................................................................................... 2
1.3 FEATURES................................................................................................................... 2
1.4 TECHNICAL SPECIFICATIONS ...................................................................................... 3
1.5 CONNECTOR PANEL.................................................................................................... 5
1.5.1 Front Panel ........................................................................................................ 5
1.5.2 Rear Panel ......................................................................................................... 6
1.6 LED INDICATORS ....................................................................................................... 8
1.7 DIMENSIONS............................................................................................................... 9
2 UNPACKING............................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 UNPACKING CHECKLIST........................................................................................... 12
3 INSTALLATION ......................................................................................................... 14
3.1 INSTALLATION PRECAUTIONS................................................................................... 15
3.2 HARD DISK DRIVE (HDD) INSTALLATION................................................................ 15
3.3 SO-DIMM INSTALLATION ....................................................................................... 18
3.4 PLUGGABLE DC-IN TERMINAL BLOCK INSTALLATION ............................................. 19
3.5 FOOT PAD INSTALLATION ......................................................................................... 20
3.6 MOUNTING THE SYSTEM WITH MOUNTING BRACKETS ............................................ 21
3.7 EXTERNAL PERIPHERAL INTERFACE CONNECTORS................................................... 22
3.7.1 ACC Mode Switch............................................................................................ 23
3.7.2 AT/ATX Power Mode Switch............................................................................ 23
3.7.3 Audio Connector.............................................................................................. 24
3.7.4 CAN-bus Terminal Blocks................................................................................ 24
3.7.5 Digital I/O Connector...................................................................................... 25
3.7.6 HDMI Connector ............................................................................................. 25
3.7.7 LAN Connectors............................................................................................... 26

TANK-760 Embedded System
Page v
3.7.8 Power Input, 4-pin Terminal Block.................................................................. 28
3.7.1 Power Input, 4-pin DIN Connector ................................................................. 28
3.7.2 RS-232 Serial Port Connectors........................................................................ 29
3.7.3 RS-232/422/485 Serial Port Connectors ......................................................... 31
3.7.4 USB Connectors............................................................................................... 32
3.7.5 VGA Connector................................................................................................ 33
3.8 POWERING ON/OFF THE SYSTEM ............................................................................. 35
4 BIOS.............................................................................................................................. 36
4.1 INTRODUCTION......................................................................................................... 37
4.1.1 Starting Setup................................................................................................... 37
4.1.2 Using Setup...................................................................................................... 37
4.1.3 Getting Help..................................................................................................... 38
4.1.4 Unable to Reboot after Configuration Changes.............................................. 38
4.1.5 BIOS Menu Bar................................................................................................ 38
4.2 MAIN........................................................................................................................ 40
4.3ADVANCED............................................................................................................... 41
4.3.1 ACPI Settings................................................................................................... 42
4.3.2 RTC Wake Settings........................................................................................... 43
4.3.3 CPU Configuration.......................................................................................... 45
4.3.4 SATA Configuration ......................................................................................... 47
4.3.5 Intel(R) Rapid Start Technology....................................................................... 48
4.3.6 USB Configuration........................................................................................... 49
4.3.7 F81866 Super IO Configuration...................................................................... 50
4.3.7.1 Serial Port n Configuration....................................................................... 51
4.3.8 F81866 H/W Monitor....................................................................................... 56
4.3.9 Serial Port Console Redirection ...................................................................... 56
4.3.10 iEi Feature ..................................................................................................... 60
4.4 CHIPSET ................................................................................................................... 61
4.4.1 PCH-IO Configuration .................................................................................... 62
4.4.1.1 PCH Azalia Configuration........................................................................ 63
4.4.2 System Agent (SA) Configuration .................................................................... 64
4.4.2.1 Graphics Configuration............................................................................. 64
4.4.2.2 Memory Configuration ............................................................................. 67
4.5 BOOT........................................................................................................................ 68

TANK-760 Embedded System
Page vi
4.6 SECURITY................................................................................................................. 70
4.7 SAVE &EXIT............................................................................................................ 71
ASAFETY PRECAUTIONS......................................................................................... 72
A.1 SAFETY PRECAUTIONS ............................................................................................ 73
A.1.1 General Safety Precautions............................................................................. 73
A.1.2 Anti-static Precautions .................................................................................... 73
A.1.3 Product Disposal............................................................................................. 74
A.2 MAINTENANCE AND CLEANING PRECAUTIONS........................................................ 75
A.2.1 Maintenance and Cleaning.............................................................................. 75
A.2.2 Cleaning Tools................................................................................................. 75
B HAZARDOUS MATERIALS DISCLOSURE ......................................................... 77
B.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY....................................... 78

TANK-760 Embedded System
Page vii
List of Figures
Figure 1-1: TANK-760 .....................................................................................................................2
Figure 1-2: TANK-760 Front Panel................................................................................................6
Figure 1-3: TANK-760 Rear Panel .................................................................................................7
Figure 1-4: TANK-760 LED Indicators...........................................................................................8
Figure 1-5: Physical Dimensions (mm)........................................................................................9
Figure 3-1: Bottom Panel Retention Screws..............................................................................16
Figure 3-2: HDD Bracket Retention Screws...............................................................................16
Figure 3-3: HDD Installation ........................................................................................................17
Figure 3-4: HDD Retention Screws.............................................................................................17
Figure 3-5: SO-DIMM Socket .......................................................................................................18
Figure 3-6: SO-DIMM Installation ................................................................................................19
Figure 3-7: Pluggable DC-in Terminal Block Installation .........................................................20
Figure 3-8: Foot Pad Installation.................................................................................................21
Figure 3-9: Mounting Bracket Retention Screws ......................................................................21
Figure 3-10: ACC Mode Switch ...................................................................................................23
Figure 3-11: AT/ATX Power Mode Switch ..................................................................................23
Figure 3-12: Audio Connector.....................................................................................................24
Figure 3-13: CAN-bus Terminal Blocks Pinouts........................................................................24
Figure 3-14: Digital I/O Connector Pinout Location..................................................................25
Figure 3-15: LAN Connection......................................................................................................27
Figure 3-16: RJ-45 Ethernet Connector......................................................................................27
Figure 3-17: 4-pin Terminal Block Pinout Location ..................................................................28
Figure 3-18: Power Input Connector...........................................................................................29
Figure 3-19: Serial Device Connector.........................................................................................30
Figure 3-20: Serial Port Pinout Location....................................................................................30
Figure 3-21: Serial Device Connector.........................................................................................31
Figure 3-22: Serial Port Pinout Location....................................................................................32
Figure 3-23: USB Device Connection.........................................................................................33
Figure 3-24: VGA Connector .......................................................................................................34
Figure 3-25: VGA Connector .......................................................................................................34

TANK-760 Embedded System
Page viii
Figure 3-26: Power Button...........................................................................................................35

TANK-760 Embedded System
Page ix
List of Tables
Table 1-1: Technical Specifications..............................................................................................5
Table 3-1: CAN-bus Terminal Blocks Pinouts ...........................................................................24
Table 3-2: Digital I/O Connector Pinouts....................................................................................25
Table 3-3: HDMI Connector Pinouts ...........................................................................................26
Table 3-4: LAN Pinouts ................................................................................................................27
Table 3-5: RJ-45 Ethernet Connector LEDs...............................................................................28
Table 3-6: Power Input Pinouts...................................................................................................29
Table 3-7: Serial Port Pinouts......................................................................................................30
Table 3-8: DB-9 Connector Pinouts............................................................................................32
Table 3-9: USB Port Pinouts........................................................................................................33
Table 3-10: VGA Connector Pinouts...........................................................................................35
Table 4-1: BIOS Navigation Keys................................................................................................38
TANK-760

TANK-760 Embedded System
Page 1
Chapter
1
1Introduction

TANK-760 Embedded System
Page 2
1.1 Overview
Figure 1-1: TANK-760
The TANK-760 is a platform based on the 4th generation Intel® Core™ i5 or Celeron®
processor and the Intel® HM86 chipset.
The TANK-760 contains VGA, DisplayPort and HDMI video outputs, which can be applied
to multi-display application and support high Full HD video quality. The TANK-760 is
equipped with an abundant of I/O ports and supports a wide range of operating
temperature. Four USB 3.0 and two USB 2.0 ports provide flexible expansion options.
Serial device connectivity is provided by four RS-232 and two RS-232/422/485 ports.
The TANK-760 can be used as a control center for in-vehicle application, such as buses or
trucks. With dual CAN-bus port, more peripheral devices can be connected for vehicle
applications.
1.2 ModelVariations
The model variations of the TANK-760 Series are listed below.
ModelNo. Processor
TANK-760-HM86i-i5/4G-R10 Intel® Core™ i5 dual-core i5-4400E 2.7 GHz,
TANK-760-HM86i-C/4G-R10 Intel® Celeron® dual-core 2000E 2.2 GHz
1.3 Features
The TANK-760 features are listed below:
Intel® Core™ i5-4400E 2.7 GHz dual-core processor

TANK-760 Embedded System
Page 3
Intel® Celeron® 2000E 2.2 GHz dual-core processor
One CFast socket
Support three independent video outputs
Built-in two 2.5" SATA 6Gb/s HDD bays
9 V~36 V DC input
Support IEI iRIS-2400 (IPMI 2.0 compliant)
1.4 TechnicalSpecifications
The TANK-760 technical specifications are listed in Table 1-1.
Specifications
Chassis
Color Black C + Silver
Dimensions (WxDxH) 310 x 200 x 69.8mm
System Fan Fanless
Chassis Construction Extruded aluminum alloy
Heavy duty steel sheet
Motherboard
CPU Intel® Core i5-4400E/ Celeron 2000E
Chipset Intel® HM86
Memory 2 x 204-pin DDR3 SDRAM SO-DIMM
iRIS Module
iRIS Solution iRIS-2400
Storage
Hard Drive 2 x 2.5'' SATA HDD Bay
CFast 1 x CFast
SD card N/A
I/O Interfaces
USB 4 x USB 3.0 ports
2 x USB 2.0 ports

TANK-760 Embedded System
Page 4
Specifications
Ethernet 2 x RJ-45
1 x PCIe GbE by Intel® I210
1 x PCIe GbE by Intel® I217LM
RS-232 4 x DB-9 with isolation
RS-232/422/485 2 x DB-9 RS-232/422/485 with isolation
Digital I/O 8-bit digital I/O, 4-bit input/4-bit output
CAN-bus 2 x Phoenix terminal block with isolation
Display 1 x VGA, 1 x HDMI, 1 x DisplayPort
Resolution VGA: Up to 1920 x 1200@60Hz
HDMI: Up to 2500 x 1600@60Hz
DisplayPort: Up to 2500 x 1600@60Hz
Audio 1 x Line-out, 1 x Mic-in
Other Optional 4-channel audio/video input PCIe Mini Card
Wireles s 1 x 802.11 a/b/g/n ( optional)
Expansions
PCIe Mini 3 x Full Size (one support mSATA)
Power
Power Input Terminal Block: 9 (+/- 0.3v) V~36 V DC
DC Jack: 9 (+/- 0.3v) V~36 V DC
Power Consumption 19 [email protected] A (Intel® Core™ i5 i5-4400E with 4 GB memory)
Reliability
Mounting Wall mount
Operating Temperature -20°C ~ 70°C with air flow (SSD)
Storage Temperature -30°C ~ 80°C
Humidity 5% ~ 95%, non-condensing
Operating Shock Half-sine wave shock 5G, 11ms, 3 shocks per axis

TANK-760 Embedded System
Page 5
Specifications
Operating Vibration MIL-STD-810F 514.5C-2 (with SSD)
Weight (Net/Gross) 3.8Kg/6.5Kg
Safety &EMC CE/FCC E-mark
OS
Supported OS Microsoft® Windows 8E
Microsoft® WES7E
Table 1-1: Technical Specifications
1.5 Connector Panel
1.5.1 Front Panel
The TANK-760 front panel contains:
2 x CAN-bus terminal blocks with isolation
1 x CFast
1 x DisplayPort
1 x OLED indicators
1 x Power button
2 x RS-232/422/485 serial ports with isolation
2 x USB 2.0 ports
2 x Wi-Fi antenna connectors
An overview of the front panel is shown in Figure 1-2.

TANK-760 Embedded System
Page 6
Figure 1-2: TANK-760 Front Panel
1.5.2 Rear Panel
The TANK-760 rear panel contains:
1 x ACC switch
1 x AT/ATX switch
1 x DIO port
1 x HDMI port
1 x Line-out port (green)
1 x Mic-in port (pink)
1 x 4-pin power jack for 9 (+/- 0.3v) V ~ 36V power input
1 x 4-pin terminal block for 9 (+/- 0.3v) V ~ 36V power input
1 x Reset button
2 x RJ-45 LAN ports
4 x RS-232 serial ports with isolation
4 x USB 3.0 ports
1 x VGA port

TANK-760 Embedded System
Page 7
An overview of the rear panel is shown in Figure 1-3 below.
Figure 1-3: TANK-760 Rear Panel

TANK-760 Embedded System
Page 8
1.6 LED Indicators
There are several indicators on the front panel of the TANK-760 as shown in Figure 1-4.
Figure 1-4: TANK-760 LED Indicators
WARNING:
The CPU Temperature Alert LED turns red when the CPU temperature
is too high. If this situation occurs, lower the environment temperature
or close some running applications to cool down the CPU.

TANK-760 Embedded System
Page 9
1.7 Dimensions
The physical dimensions are shown below:
Figure 1-5: Physical Dimensions (mm)

TANK-760 Embedded System
Page 10
Chapter
2
2Unpacking

TANK-760 Embedded System
Page 11
2.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during installation
may result in
permanent damage to the TANK-760 and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the TANK-760. Dry climates are especially susceptible to ESD. It is therefore
critical that whenever the TANK-760 or any other electrical component is handled, the
following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Touch any grounded conducting material before handling
the board. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the TANK-760, place it on an
antic-static pad. This reduces the possibility of ESD damaging the TANK-760.
2.2 Unpacking Precautions
When the TANK-760 is unpacked, please do the following:
Follow the anti-static precautions outlined in Section 2.1.
Make sure the packing box is facing upwards so the TANK-760 does not fall
out of the box.
Make sure all the components shown in Section 2.3 are present.
