IEI Technology IOVU-07F-AD User manual

IOVU-07F-AD RISC-based Panel PC
Page I
User Manual
7” RISC-Based Panel PC with Touchscreen, Android 4.2 OS,
Freescale™ i.MX6 Cortex™-A9 Quad-Core CPU, CAN 2.0B,
Wi-Fi, Bluetooth, Camera, RoHS Compliant
MODEL:
IOVU-07F-AD
Rev. 1.00 – 13 March, 2014

IOVU-07F-AD RISC-based Panel PC
Page II
Revision
Date Version Changes
13 March, 2014 1.00 Initial release

IOVU-07F-AD RISC-based Panel PC
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IOVU-07F-AD RISC-based Panel PC
Page IV
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 MODEL VARIATIONS ................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 FRONT PANEL............................................................................................................. 4
1.4.1 LED Indicators................................................................................................... 4
1.5 BOTTOM PANEL.......................................................................................................... 5
1.6 REAR PANEL............................................................................................................... 5
1.7 LEFT PANEL................................................................................................................ 6
1.8 RIGHT PANEL ............................................................................................................. 6
1.9 SYSTEM SPECIFICATIONS............................................................................................ 7
1.10 DIMENSIONS............................................................................................................. 9
2 UNPACKING............................................................................................................... 10
2.1 PACKING LIST............................................................................................................11
2.2 OPTIONAL ITEMS...................................................................................................... 12
3 INSTALLATION ......................................................................................................... 14
3.1ANTI-STATIC PRECAUTIONS...................................................................................... 15
3.2 INSTALLATION PRECAUTIONS................................................................................... 15
3.3 SD CARD INSTALLATION.......................................................................................... 16
3.4 MOUNTING THE SYSTEM .......................................................................................... 18
3.4.1 Wall Mounting.................................................................................................. 18
3.4.2 Panel Mounting................................................................................................ 21
3.4.3 Arm Mounting .................................................................................................. 22
3.4.4 Stand Mounting................................................................................................ 24
3.5 EXTERNAL I/O CONNECTORS ................................................................................... 25
3.5.1 10-pin I/O Connector....................................................................................... 25
3.5.2 DC Power Input Interfaces.............................................................................. 26
3.5.2.1 9 V ~ 30 V DC Power Jack....................................................................... 26
3.5.2.2 9 V ~ 30 V DC Power Terminal Block ..................................................... 26

IOVU-07F-AD RISC-based Panel PC
Page V
3.5.3 Ethernet Connector.......................................................................................... 27
3.5.4 Serial Interfaces............................................................................................... 29
3.5.4.1 RS-232 Serial Interface Pinouts (COM 1)................................................ 29
3.5.4.2 RS-232/422/485 Serial Interface Pinouts (COM 2).................................. 29
3.5.4.3 Connecting the Serial Port........................................................................ 30
3.5.5 USB Connectors............................................................................................... 31
3.6 SYSTEM MAINTENANCE........................................................................................... 32
4 USING THE IOVU-07F-AD ....................................................................................... 33
4.1 POWER-ON/OFF PROCEDURE ................................................................................... 34
4.1.1 Installation Checklist....................................................................................... 34
4.1.2 Power-on Procedure........................................................................................ 34
4.1.3 Power-off Procedure........................................................................................ 34
4.2 HOME SCREEN ......................................................................................................... 36
4.2.1 Switching between Home Screens.................................................................... 36
4.2.2 Favorites Tray.................................................................................................. 37
4.2.3 Adding Shortcut................................................................................................ 38
4.2.4 Arranging the Home Screen............................................................................. 39
4.3 NAVIGATION BUTTONS............................................................................................. 40
4.4 STATUS BAR ............................................................................................................. 41
4.5 SETTINGS ................................................................................................................. 43
4.5.1 WIRELESS & NETWORKS.............................................................................. 43
4.5.1.1 More Settings............................................................................................ 44
4.5.2 Sound................................................................................................................ 45
4.5.3 Display............................................................................................................. 46
4.5.4 Storage............................................................................................................. 47
4.5.5 Apps.................................................................................................................. 48
4.5.6 Users................................................................................................................ 48
4.5.7 Location Access................................................................................................ 49
4.5.8 Security ............................................................................................................ 50
4.5.9 Language & Input............................................................................................ 51
4.5.10 Backup & Reset.............................................................................................. 52
4.5.11 Add account.................................................................................................... 53
4.5.12 Date & Time................................................................................................... 53
4.5.13 Accessibility ................................................................................................... 54

IOVU-07F-AD RISC-based Panel PC
Page VI
4.5.14 About Tablet ................................................................................................... 55
4.6 FILE MANAGEMENT ................................................................................................. 56
4.7 CAMERA................................................................................................................... 58
4.8 CONFIGURING THE RS-232/422/485 SERIAL PORT AND DIGITAL I/O ....................... 58
5 INTERFACE CONNECTORS................................................................................... 60
5.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 61
5.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 62
5.2.1 Boot Mode Setting Switches (SW1, SW2) ........................................................ 63
5.2.2 Camera Connector (CAMERA1) ..................................................................... 63
5.2.3 Debug Connector (CN5).................................................................................. 63
5.2.4 Downloader Mode Switch (SW3)..................................................................... 64
5.2.5 HP-out Connector (CN3)................................................................................. 64
5.2.6 JATG Interface for Wi-Fi Module (CN6)......................................................... 64
5.2.7 LCD Connector (LCD1) .................................................................................. 64
5.2.8 Microphone Connector (MIC1) ....................................................................... 65
5.2.9 Power Button Connector (CN9)....................................................................... 65
5.2.10 RFID Connector (CN11)................................................................................ 66
5.2.11 SD Card Slot (CN10)...................................................................................... 66
5.2.12 Speaker Connector (CN4).............................................................................. 67
5.2.13 Touchscreen Connector (CN2)....................................................................... 67
A SAFETY PRECAUTIONS......................................................................................... 68
A.1 SAFETY PRECAUTIONS ............................................................................................ 69
A.1.1 General Safety Precautions............................................................................. 69
A.1.2 Anti-static Precautions .................................................................................... 70
A.1.3 Product Disposal............................................................................................. 71
A.2 MAINTENANCE AND CLEANING PRECAUTIONS........................................................ 71
A.2.1 Maintenance and Cleaning.............................................................................. 71
A.2.2 Cleaning Tools................................................................................................. 72
B HAZARDOUS MATERIALS DISCLOSURE ......................................................... 73
B.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ....................................... 74

IOVU-07F-AD RISC-based Panel PC
Page VII
List of Figures
Figure 1-1: IOVU-07F-AD Panel PC...............................................................................................2
Figure 1-2: Front Panel ..................................................................................................................4
Figure 1-3: LED Indicators.............................................................................................................4
Figure 1-4: Bottom Panel...............................................................................................................5
Figure 1-5: Rear Panel....................................................................................................................5
Figure 1-6: Left Panel.....................................................................................................................6
Figure 1-7: Right Panel ..................................................................................................................6
Figure 1-8: Dimensions (unit: mm)...............................................................................................9
Figure 3-1: Retention Screws on the Rear Cover......................................................................16
Figure 3-2: Hex Nuts on the Bottom Panel ................................................................................17
Figure 3-3: SD Card Installation..................................................................................................17
Figure 3-4: Wall-mounting Bracket.............................................................................................19
Figure 3-5: Chassis Support Screws..........................................................................................20
Figure 3-6: Secure the IOVU-07F-AD..........................................................................................21
Figure 3-7: Panel Mounting Clamps ...........................................................................................22
Figure 3-8: Arm Mounting Retention Screw Holes....................................................................23
Figure 3-9: Arm Mounting............................................................................................................24
Figure 3-10: Stand Mounting.......................................................................................................25
Figure 3-11: I/O Connector Pinouts Location............................................................................25
Figure 3-12: 9 V ~ 30 V DC Power Jack Location......................................................................26
Figure 3-13: 9 V ~ 30 V DC Power Terminal Block Location....................................................26
Figure 3-14: Power Terminal Block.............................................................................................27
Figure 3-15: LAN Connection......................................................................................................27
Figure 3-16: Ethernet Connector.................................................................................................28
Figure 3-17: Serial Device Connector.........................................................................................30
Figure 3-18: USB Connector........................................................................................................31
Figure 4-1: Power Switch.............................................................................................................34
Figure 4-2: Power-off Menu .........................................................................................................35
Figure 4-3: Power-off Confirmation Screen...............................................................................35
Figure 4-4: Multiple Home Screens.............................................................................................36

IOVU-07F-AD RISC-based Panel PC
Page VIII
Figure 4-5: Favorites Tray............................................................................................................37
Figure 4-6: Launcher Button .......................................................................................................38
Figure 4-7: Launcher Page ..........................................................................................................38
Figure 4-8: Move and Trash Item on Home Screen...................................................................39
Figure 4-9: Navigation Buttons...................................................................................................40
Figure 4-10: Status Bar ................................................................................................................41
Figure 4-11: Status Bar – Setting Shortcut................................................................................41
Figure 4-12: Status Bar – Notification ........................................................................................42
Figure 4-13: Wireless and Networks Settings ...........................................................................43
Figure 4-14: More Settings Menu................................................................................................44
Figure 4-15: Sound Menu.............................................................................................................45
Figure 4-16: Display Menu...........................................................................................................46
Figure 4-17: Storage Menu ..........................................................................................................47
Figure 4-18: Apps Menu...............................................................................................................48
Figure 4-19: Users Menu..............................................................................................................48
Figure 4-20: Location Access Menu...........................................................................................49
Figure 4-21: Security Menu..........................................................................................................50
Figure 4-22: Language & Input Menu .........................................................................................51
Figure 4-23: Backup & Reset Menu ............................................................................................52
Figure 4-24: Add Account Menu .................................................................................................53
Figure 4-25: Date & Time Menu...................................................................................................53
Figure 4-26: Accessibility Menu..................................................................................................54
Figure 4-27: About Tablet Menu..................................................................................................55
Figure 4-28: ES File Explorer Screen..........................................................................................56
Figure 4-29: Possible Storage Devices ......................................................................................57
Figure 4-30: Camera Application ................................................................................................58
Figure 4-31: RS-232/422/485 Serial Port Settings......................................................................58
Figure 4-32: Digital I/O Settings..................................................................................................59
Figure 5-1: Main Board Layout Diagram (Front Side)...............................................................61
Figure 5-2: Main Board Layout Diagram (Solder Side).............................................................61

IOVU-07F-AD RISC-based Panel PC
Page IX
List of Tables
Table 1-1: Model Variations...........................................................................................................2
Table 1-2: Technical Specifications..............................................................................................8
Table 2-1: Packing List.................................................................................................................12
Table 2-2: Optional Items.............................................................................................................13
Table 3-1: I/O Connector Pinouts................................................................................................26
Table 3-2: 9 V ~ 30 V Power Terminal Block Pinouts................................................................27
Table 3-3: Ethernet Connector Pinouts......................................................................................28
Table 3-4: Ethernet Connector LEDs..........................................................................................28
Table 3-5: RS-232 Serial Port Pinouts ........................................................................................29
Table 3-6: RS-232/422/485 Serial Port Pinouts..........................................................................29
Table 3-7: USB Connector Pinouts.............................................................................................31
Table 4-1: Navigation Buttons.....................................................................................................40
Table 5-1: Peripheral Interface Connectors...............................................................................62
Table 5-2: Boot Mode Setting Switches (SW1, SW2) Pinouts..................................................63
Table 5-3: Camera Connector (CAMERA1) Pinouts..................................................................63
Table 5-4: Debug Connector (CN5) Pinouts...............................................................................63
Table 5-5: Downloader Mode Switch (SW3) Pinouts.................................................................64
Table 5-6: HP-out Connector (CN3) Pinouts..............................................................................64
Table 5-7: JATG Interface for Wi-Fi Module (CN6) Pinouts......................................................64
Table 5-8: LCD Connector (LCD1) Pinouts ................................................................................65
Table 5-9: Microphone Connector (MIC1) Pinouts....................................................................65
Table 5-10: Power Button Connector (CN9) Pinouts ................................................................65
Table 5-11: RFID Connector (CN11) Pinouts .............................................................................66
Table 5-12: SD Card Slot (CN10) Pinouts...................................................................................66
Table 5-13: Speaker Connector (CN4) Pinouts..........................................................................67
Table 5-14: Touchscreen Connector (CN2) Pinouts .................................................................67

IOVU-07F-AD RISC-based Panel PC
Page 1
Chapter
1
1 Introduction

IOVU-07F-AD RISC-based Panel PC
Page 2
1.1 Overview
Figure 1-1: IOVU-07F-AD Panel PC
The IOVU-07F-AD is a 7” RISC-based panel PC with Android 4.2 OS. At the heart of the
system is the Freescale™ i.MX6 Cortex™-A9 quad-core processor, offering low power in
a powerful package. The IOVU-07F-AD provides rich input capabilities utilizing the
projected capacitive touchscreen. Other peripherals include one SD card slot, two
USB 2.0 host ports, one RS-232 port, one RS-232/422/485 port, one 10/100/1000 Mbps
LAN port and one I/O connector which supports CAN 2.0B and digital I/O.
1.2 Model Variations
Model Camera Wi-Fi Bluetooth
IOVU-07F-AD-WBC-R10 Yes Yes Yes
IOVU-07F-AD-ET-R10 No No No
Table 1-1: Model Variations

IOVU-07F-AD RISC-based Panel PC
Page 3
1.3 Features
The IOVU-07F-AD features the following:
Freescale™ i.MX6 Cortex™-A9 quad-core processor
On-board 1 GB DDR3 memory
Android 4.2 OS
7” color active-matrix TFT LCD with LED backlight
Projected capacitive touchscreen
Wi-Fi 802.11b/g/n (IOVU-07F-AD-WBC-R10 only)
Bluetooth v4.0 + HS (IOVU-07F-AD-WBC-R10 only)
2-megapixel CMOS front-facing camera (IOVU-07F-AD-WBC-R10 only)
Supports CAN 2.0B and four digital I/O (software configurable)
One DB-9 RS-232/422/485 port (software configurable)
One DB-9 RS-232 port (full function)
One internal SD card slot
Two USB 2.0 host ports
One 10/100/1000 Mbps Ethernet LAN port
RoHS compliant

IOVU-07F-AD RISC-based Panel PC
Page 4
1.4 Front Panel
The front panel of the IOVU-07F-AD has a 7” color active-matrix TFT LCD with a plastic
frame. The front panel also contains an optional 2-megapixel camera, a microphone and
LED indicators.
Figure 1-2: Front Panel
1.4.1 LED Indicators
The LED indicators on the front panel show the status of power, Bluetooth and Wi-Fi.
Figure 1-3: LED Indicators

IOVU-07F-AD RISC-based Panel PC
Page 5
1.5 Bottom Panel
The bottom panel contains the I/O interfaces as shown in Figure 1-4.
Figure 1-4: Bottom Panel
1.6 Rear Panel
The rear panel has four VESA 75 mounting screw holes.
Figure 1-5: Rear Panel

IOVU-07F-AD RISC-based Panel PC
Page 6
1.7 Left Panel
The left panel has a 1.5 W speaker.
Figure 1-6: Left Panel
1.8 Right Panel
The right panel has a 10-pin I/O connecter which supports CAN 2.0B and four digital I/O.
Figure 1-7: Right Panel

IOVU-07F-AD RISC-based Panel PC
Page 7
1.9 System Specifications
The IOVU-07F-AD technical specifications are listed in Table 1-2.
System
CPU Freescale™ i.MX6 Cortex™-A9 quad-core, 1.2 GHz
Memory On-board 1 GB DDR3 SDRAM
OS Android 4.2
Boot Flash 4 GB eMMC NAND flash
Storage One SD card slot (max. 32 GB)
Audio 1 x Speaker (1.5 W)
1 x Microphone
Camera 2-megapixel CMOS front-facing camera (IOVU-07F-AD-WBC-R10 only)
Real-time Clock Battery backup RTC
Display
LCD 7” color active-matrix TFT LCD with LED backlight
Max. Resolution 1024 (W) x 600 (H), WSVGA
Brightness (cd/m2) 350
Viewing Angle 75/75/70/75 degree
Touchscreen Projected capacitive
Communication
Wireless LAN Wi-Fi 802.11b/g/n (IOVU-07F-AD-WBC-R10 only)
Bluetooth Bluetooth v4.0 + HS (IOVU-07F-AD-WBC-R10 only)
Indicators and Buttons
Buttons and Keys 1 x Power switch
1 x Reset key
LED Indicators
1 x Power LED
1 x Bluetooth status LED (IOVU-07F-AD-WBC-R10 only)
1 x Wi-Fi connection LED (IOVU-07F-AD-WBC-R10 only)
I/O Interface
CAN 2.0B and
Digital I/O
1 x 10-pin connector, supporting one CAN 2.0B and
four Digital I/O (software configurable)
LAN 1 x 10/100/1000 Mbps RJ-45

IOVU-07F-AD RISC-based Panel PC
Page 8
Power Input 1 x 2-pin power terminal block (9 V ~ 30 V DC)
1 x Power jack (9 V ~ 30 V DC)
RS-232/422/485 1 x DB-9 RS-232, full function (COM 1)
1 x DB-9 RS-232/422/485, software configurable (COM 2)
USB 2.0 2 x USB 2.0 host ports
Environment
Operating
Temperature 0ºC ~ 50ºC
Storage Temperature -10ºC ~ 60ºC
Humidity 5% ~ 90%, non-condensing
Physical Characteristics
Mounting VESA 75 mm x 75 mm
Dimensions
(W x H x D) 210.0 mm x 154.0 mm x 40.1 mm
Net Weight 945 g
Table 1-2: Technical Specifications

IOVU-07F-AD RISC-based Panel PC
Page 9
1.10 Dimensions
The dimensions are shown below.
Figure 1-8: Dimensions (unit: mm)

IOVU-07F-AD RISC-based Panel PC
Page 10
Chapter
2
2 Unpacking

IOVU-07F-AD RISC-based Panel PC
Page 11
To unpack the panel PC, follow the steps below:
WARNING!
The front side LCD screen has a protective plastic cover stuck to the
screen. Only remove the plastic cover after the system has been
properly installed. This ensures the screen is protected during the
installation process.
Step 1: Carefully cut the tape sealing the box. Only cut deep enough to break the tape.
Step 2: Open the box.
Step 3: Lift the IOVU-07F-AD out of the box.
Step 4: Remove both polystyrene ends, one from each side.
Step 5: Pull the plastic cover off the IOVU-07F-AD.
Step 6: Make sure all the components listed in the packing list are present. Step 0:
2.1 Packing List
NOTE:
If any of the components listed in the checklist below are missing, do
not proceed with the installation. Contact the IEI reseller or vendor the
IOVU-07F-AD was purchased from or contact an IEI sales
representative directly by sending an email to 31[email protected].
The IOVU-07F-AD is shipped with the following components:
