IFM PK55 Series User manual

Operating Instructions
Electronic pressure monitor
PK55xx
704522 / 00 03 / 2020
UK


2
1 Preliminary note
1.1 Symbols used
►Instruction
> Reaction, result
[…] Designation of keys, buttons or indications
→Cross-reference
Important note
Non-compliance may result in malfunction or interference
Information
Supplementary note
2 Safety instructions
• The device described is a subcomponent for integration into a system.
- The manufacturer is responsible for the safety of the system.
- The system manufacturer undertakes to perform a risk assessment and to
create documentation in accordance with legal and normative requirements to
be provided to the operator and user of the system. This documentation must
contain all necessary information and safety instructions for the operator, the
user and, if applicable, for any service personnel authorised by the manufac-
turer of the system.
Contents
1 1 Preliminary note................................................................................................2
1.1 Symbols used ................................................................................................2
2 Safety instructions ...............................................................................................2
3 Function and features..........................................................................................3
4 Installation............................................................................................................4
5 Electrical connection............................................................................................4
6 Setting / Operation...............................................................................................5

3
UK
• Read this document before setting up the product and keep it during the entire
service life.
• The product must be suitable for the corresponding applications and environ-
mental conditions without any restrictions.
• Only use the product for its intended purpose (→ Functions and features).
• Only use the product for permissible media (→ Technical data).
• If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property may occur.
• The manufacturer assumes no liability or warranty for any consequences
caused by tampering with the product or incorrect use by the operator.
• Installation, electrical connection, set-up, programming, configuration, operati-
on and maintenance of the product must be carried out by personnel qualified
and authorised for the respective activity.
• Protect units and cables against damage.
3 Function and features
The pressure monitor detects the system pressure and generates 1 output signal.
• In case of increasing pressure the output closes when the Set1 value is rea-
ched.
• In case of decreasing pressure the output opens when the value „Set1 minus
hysteresis“ is reached.
The hysteresis is fixed (2% of value of measuring range).
Applications
Type of pressure: relative pressure
Order no. Measuring range Permissible
overload pressure
Bursting
pressure
bar PSI bar PSI bar PSI
PK5520 0...400 0...5 800 600 8 700 1 600 23 200
PK5521 0...250 0...3 625 400 5 800 1 000 14 500
PK5522 0...100 0...1 450 200 2 900 1 000 14 500
PK5523 0...25 0...363 60 870 500 7 253
PK5524 0...10 0...145 25 362 300 4 350

4
Avoid static and dynamic overpressure exceeding the given overload
pressure.
Even if the bursting pressure is exceeded only for a short time the unit can
be destroyed (danger of injuries)!
If the cable length exceeds 30 m or if used outside buildings, there is a risk
of overvoltage pulses from external sources. We recommend to use the
unit in protected operating environments and to limit overvoltage pulses to
max. 500 V.
4 Installation
Before mounting and removing the sensor, make sure that no pressure is
applied to the system.
5 Electrical connection
The unit must be connected by a suitably qualified electrician.
Voltage supply to EN50178, SELV, PELV.
►Disconnect power before connecting the unit.

5
UK
6 Setting / Operation
1: locking ring
2: setting ring (manually adjustable after unlocking)
3: green LED: supply voltage O.K.
4: process connection G¼ A; tightening torque 25 Nm
5: setting marks
6: yellow LED: Set1 value reached, output = ON
7: sealing FPM / DIN 3869-14
8: internal thread M5
• To obtain the setting accuracy: Set the ring to the minimum value, then set the
requested value.
More information at www.ifm.com
