Goldair PLATINUM GPTF480 User manual

100cm Multi Season 3n1 Bladeless Tower
Heater & Fan with Wifi
Operating Instructions
Model: GPTF480

CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
•This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they are supervised or have been given instruction
concerning the use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the
appliance.
•If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING: You must not cover this appliance. Covering this appliance
presents fire risk and will activate the safety fuse; permanently disabling the
unit.
WARNING: Do not use this appliance in small rooms when they are
occupied by persons not capable of leaving the room on their own, unless
constant supervision is provided.
WARNING: To reduce the risk of fire, keep textiles, curtains, or any
flammable material a minimum distance of 1 metre from the air outlet.
General Care and Safety Guide
•Use only the voltage specified on the rating label of the appliance.
•Keep all objects at least 1 metre from the front, sides and rear of the appliance.
•This appliance is intended for household use only and not for commercial or
industrial use.
•Indoor use only.
•This appliance incorporates an earth connection for functional purposes.
•Use this appliance only as described in this manual. Any other use is not
recommended by the manufacturer and may cause fire, electric shock or injury.
•Do not use the appliance if it has been dropped or damaged.
•The common cause of overheating is deposits of dust or fluff in the appliance.
Ensure these deposits are removed regularly by unplugging the appliance and
vacuum cleaning the air vents and grills.
•Never use the appliance to dry clothes.
•Always unplug appliance when not in use.
YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE
INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.

•When the appliance has been unpacked, check it for transport damage and ensure
all parts have been delivered. If parts are missing or the appliance has been
damaged, contact the Customer Services Team.
•Do not use if there are visible signs of damage to the appliance.
•Do not connect the appliance to mains supply until completely assembled and
adjusted.
•Ensure hands are dry before handling the plug or main unit.
•Ensure appliance is on a flat, stable, heat-resistant surface.
•Do not operate with cord set coiled up as a heat build up is likely, which could be
sufficient to become a hazard.
•Carry out regular checks of the supply cord to ensure no damage is evident
•Do not operate this appliance with a damaged cord, plug or after the appliance
malfunctions or has been dropped or damaged in any manner. Take to a qualified
electrical person for examination, electrical service or repair.
•Do not twist, kink or wrap the cord around the appliance, as this may cause the
insulation to weaken and split. Always ensure that all cord has been removed from
any cord storage area and is unrolled before use.
•It is recommended that this appliance is plugged directly into the wall socket.
Power boards are not rated to supply power to high wattage appliances.
•A correctly specified, undamaged extension cord may be used with this appliance
provided it is used in a safe manner.
•Do not remove plug from power socket until the appliance has been switched off.
•Do not remove plug from power socket by pulling cord; always grip plug.
•Do not place cord under carpet or cover with rugs or furniture. Arrange the cord so
it cannot be tripped over.
•Don’t place appliance on bedding or on thick & long carpet where the openings may
get blocked.
•Switch off and use handle provided when moving
•Do not place appliance close to radiant heat source.
•Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as
this may cause an electric shock, fire or damage to the appliance.
•Do not sit on the appliance.
•Do not use abrasive cleaning products on this appliance. Clean with a damp cloth
(not wet) rinsed in hot soapy water only. Always remove plug from the mains supply
before cleaning.
•Do not operate in areas where petrol, paint or other flammable liquids are used or
stored.
•Do not use this appliance in the immediate surrounds of a bath, a shower, or a
swimming pool or other liquids.
•The appliance must not be immersed in any liquids.
•There are no user serviceable parts installed in the unit.
•Do not place the unit in wardrobes or other enclosed spaces as this may cause fire
hazards.
General Care and Safety Guide

•This unit is not supposed to be used in or around locations where foodstuffs, works
of art or delicate articles of science, etc. are stored.
•If your appliance does not work, or is not working properly, contact the place of
purchase or the Customer Services Team.
General Care and Safety Guide
The remote control supplied with this device uses a CR2032 coin type battery.
DANGER IF SWALLOWED
Keep batteries out of reach of children. Swallowing may lead to serious injury or death in
as little as 2 hours due to internal burns.
If swallowed, go straight to a hospital emergency room.
Dispose of used batteries immediately.
WARNING!
Keep batteries out of reach of
children. Swallowing may lead to
serious injury or death in as little as 2
hours due to internal burns.
If swallowed, go straight to a
hospital emergency room.
Dispose of used batteries
immediately.
DANGER IF
SWALLOWED

WARNING: In order to avoid overheating or fire, do not cover the heater.
WARNING: Keep all objects at least 1 metre from the front, sides and
rear of the appliance.
WARNING: Do not use this heater with a programmer, separate timer,
remote-control system or any other device that switches the heater on
automatically, since a fire risk exists if the heater is covered or positioned
incorrectly.
WARNING: Never leave this heater unattended when in use.
Ensure heater is on a flat, stable, heat-resistant surface.
Once the heater is in a safe operating position and all switches are in the off
position, insert the power plug into the mains outlet and switch on. The unit
will now be in stand-by mode.
CAUTION: Ensure the power cord is not tight because if pulled it may
partially pull the plug from the socket. A partially inserted plug will overheat
the plug and socket and could result in fire.
Operating your Appliance
Always choose a safe location for the fan, keeping in mind the safety precautions
outlined. Ensure all packaging has been removed from the unit before use. This
appliance requires no installation, it should be used solely as a portable appliance.

Operating your Appliance
1
Display
8
Remote Control: Speed Settings (up)
2
Power Button
9
Remote Control: Mode
3
Air Grill
10
Remote Control: Oscillation
4
HEPA or Carbon Filter
11
Remote Control: Speed Settings (down)
5
HEPA or Carbon Filter
12
Remote Control: Air
Purifiy Mode
6
Air Grill
13
Remote Control: Power Button
7
Remote Control: Timer
8+11
Remote Control: Child Lock
THIS APPLIANCE CAN ONLY BE OPERATED FROM THE REMOTE CONTROL OR WIFI INTERFACE
Power
Press to turn the unit ON/OFF
Mode
Press to change the device between Heating & Cooling mode
Fan Speed
Press the + and –buttons on the remote to adjust the speed settings. In cooling mode, there are
12 fan speed settings. In heating mode there are 7 heat settings.
Note: when in heating mode the unit will only run continuously for 6 hours. You will need to
switch the unit off to reset.
Oscillation
Press to turn horizontal oscillation ON/OFF
Timer
If the unit is ON, you can set a countdown timer for the device to switch OFF. If the device is in
stand-by mode, then you can set a timer for the device to switch ON.
Press the timer button and use the + and –buttons to adjust the length of time in 1hr
increments. Choose between 1-12 hours.
Air Purify
Press to turn on Air Purification mode . Using the included HEPA filter and UV lights, this will draw
in and remove unwanted allergens from the air.

Operating your Appliance
The remote control supplied with this device uses a CR2032 coin
type battery.
DANGER IF SWALLOWED
Please store your remote on the magnetic remote control holder on the back
of the appliance.
Child Lock
Press the + and –buttons at the same time to turn on Child Lock. A lock symbol will appear on
the display and no functions can be operated. To turn off Child Lock, hold down the + and –
buttons.
Filter Replacement
The HEPA filter will need replacing after 600 hours use.
The indicator light will flash when the filters need replacing.

WiFi –Downloading and Setting up APP
This APP is supported only on 2.4GHz Wi-Fi channels. Please ensure your phone is 2.4GHz
capable
Note this device will only work within your home WIFI system.
This does not operate on 3G or 4G internet connections.
You will need a connection to your home Wi-Fi.
•Tap REGISTER near the bottom of the screen.
•Read and agree to the Privacy Policy.
•Add your email address.
•Tap 'Obtain verification code'
You will then receive an email with a verification
code.
Download Goldair mobile APP
•Open the APP Store or Google Play on your mobile phone.
•Open 'Search' and enter 'Goldair'
•Click 'GET' and begin to download and install.
Once downloaded to your phone open the APP
•Enter the verification code from your email.
•Create a password.
•Then tap confirm.
If you haven't received a verification code via
email, tap the resend button and when the
verification code is received follow above steps.
Your APP is now registered and ready for pairing
to your device.

Pairing APP to Device
Details for pairing this heater to the Goldair App can be found at the below website link.
Either scan the QR code below or enter the website into your browser.
https://www.goldair.co.nz/
goldair-app
New Zealand Products
https://www.goldair.com.au/
goldair-app
Australia Products
Pairing Mode
To connect to the Goldair app you must ensure that your device is in
pairing mode which is where the Wifi Icon is flashing.
The device will be in pairing mode when you first switch it on, if it is
not then:
- Put device in STAND-BY mode (ON at the wall but device is OFF)
- Press and HOLD the POWER BUTTON for around 5 seconds or
until the Wifi icon begins to flash.
Quick Connection
-Turn your phone’s Bluetooth ON
- Ensure your device is in Pairing Mode (see instructions above)
- Tap the + on the top right corner to navigate to the main device
screen. Tap ‘Auto Scan’ – your device will appear. Tap the device
and follow the instructions.
- If Quick Connection does not work, follow the manual via the QR
Code above

Goldair –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
Goldair –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
SUPPORT AND TECHNICAL ADVICE
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase. (Refer to back of booklet).
SAFETY DEVICES
This appliance has three protection devices:
•Tilt switch - this will automatically turn the appliance off if the appliance is not in
the correct operating position.
•Resettable thermal link - this will automatically disconnect the power to the
appliance at a pre-set overheat temperature. To Reset Unit -
•Unplug the unit and wait 10 minutes for the unit to cool down.
•After the unit has cooled down, plug the unit into the electrical outlet and
follow the operation instructions described in this manual.
If this occurs again, investigate what is causing the appliance to overheat.
•Thermal fuse - this disconnects the appliance permanently in case of overheating.
(It is non resettable).
CAUTION: The appliance generates heat during use. Precautions must be
taken to prevent the risk of burns, scalds, fires or other damage to persons.
CARE AND CLEANING
The appliance requires regular cleaning to ensure trouble free operation:
•Unplug the appliance from the mains supply before cleaning.
•Ensure that the appliance has been allowed to cool down completely before
cleaning.
•The common cause of overheating is deposits of dust or fluff in the appliance.
Ensure these deposits are removed regularly by unplugging the appliance and
vacuum cleaning the air vents and grills.
•Use a damp cloth (not wet) to wipe the exterior of the heater to remove dust and
dirt.
•Never use solutions such as petrol, thinners or polishing agents.
•Ensure the appliance is dry before plugging back into the mains supply.
•Do not attempt to dismantle the appliance.
•There are no user serviceable parts. For service or repair, contact an authorised
electrical service technician.
Operating your Appliance

Thank you for purchasing this Goldair Platinum product. Your product is warranted against faults and manufacture when used in
normal domestic use for a period of three years. In non-domestic use Goldair limits the voluntary warranty to three months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the
warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone
other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in relation to the
goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
Three Year Warranty
Goldair Three Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
Goldair –New Zealand
CDB Goldair
PO Box 100-707
N.S.M.C
Auckland
Phone [phone]
Phone [phone]
www.goldair.co.nz
Goldair –Australia
CDB Goldair Australia Pty
PO Box 574
South Morang
Victoria, 3752
Phone [phone]
Phone 1300 GOLDAIR (1300 465 324)
www.goldair.com.au

New Zealand
PO Box 100707,
North Shore Mail Centre,
Auckland, 0745
www.goldair.co.nz
Australia
PO Box 574,
South Morang,
Victoria, 3752
www.goldair.com.au
