COOKTOP, BURNER AND GRATE PARTS
1
For Models: ICS300RQ02, ICS300RS02
(Designer White) (Stainless)
07−07 Litho in U.S.A. (amd) Part No. W10156604 Rev. A
30" GAS COOKTOP
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
3192098 Wiring Diagram
W10131955 Installation
Instructions
W10086230 Owners Manual
Safe Cooking Tips
3191638 English
9759133 French
9759440 LP Conversion
Instructions
2 Panel, Control
9759873 White
9759872 Stainless
3 Cooktop
3191243 White
3191288 Stainless
4 Cap, Burner
6K (1)
3191898 Black
3191899 Gray
9.5K (2)
3191901 Black
3191903 Gray
12.5K (1)
3191904 Black
3191905 Gray
5 Grate (4)
9761231 Black
9761232 Gray
6 Knob, Control (4)
9758788 Black
9758787 White
7 9760045 Seal, Foam
8 Holder, Orifice
(Includes 13 & 14)
4456621 Auxi
4456620 Semi Rapid
4456619 Rapid
9 Head, Burner
4455979 RF
9760037 LR, RR
4455981 LF
10 4449809 Screw
11 3368921 Screw
Following Parts Not Illustrated
Harness, Wire
Ignitor
4456626 15"
4456627 28"

BURNER BOX, GAS VALVES, AND SWITCHES
2
For Models: ICS300RQ02, ICS300RS02
(Designer White) (Stainless)
W10156604
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4455917 Bracket, (2)
Cooktop mounting
2 9759354 Pipe, Manifold
3 4456905 Harness & Switches
4 8522423 Spark Module
5 Valve, Burner
4456817 Large (3)
4456816 Small (1)
6 9763116 Power Cord
7 FE02349 Bushing, Cord
8 3177991 Screw, Ground
9 8523704 Bolt, Gas Valve
10 3191318 Tubing, Burner
RR & RF
11 3192491 Bracket, Manifold
12 3191320 Tubing, Burner
LR & LF
13
W10131956 Regulator, Pressure
14 4456780 Box, Burner
15 3196160 Screw
16 4449809 Screw
17 8286099 Rail, Burner (2)
18 3191387 Seal, (4)
Switch Cover
19 3400843 Screw
20 3400093 Screw
Following Parts Not Illustrated
and Optional Parts Not Included
3192741 Gas Conversion Kit
(Natural Gas To
LP Gas)
