IN-COMMAND NCSP60CM User manual

RV CONTROL SYSTEM
Installation and Operation Manual
™
™
Patent # US 9,679,735
NCSP60CM NCSP60SP

Read the iN-Command Manual, and these warnings and instructions carefully before using this product. Failure to follow
the use instructions in this owner’s manual, or improper use of the Mobile Application, Display Commander and/or Body
Control Module, could result in personal injury, including death.
Do not operate while vehicle is being driven. The Mobile Application, Display Commander and/or Body Control Module
should not be used while the vehicle is being driven. Use of the Mobile Application, Display Commander and/or Body
Control Module while the vehicle is being driven is dangerous and may cause personal injury or property damage.
For adult use only. The Mobile Application, Display Commander and Body Control Module are intended for adult use only,
and are not to be used by persons under the age of 18. Use by children may cause personal injury or property damage.
Operate only when you have a clear line of sight. Do not operate any moving parts (including, but not limited to,
awnings, jacks and slides), unless you have a clear line of sight to the moving part. The Mobile Application, Display
Commander or Body Control Module may be used only if you are giving instructions to, and receiving instructions from,
another person at least age 18 or older who can clearly see the moving part. Failure to follow these instructions may result
in serious personal injury or property damage.
Do not operate under the inuence of alcohol or drugs. Do not operate the Mobile Application, Display Commander
or Body Control Module while under the inuence of alcohol or drugs. Doing so may result in personal injury or property
damage.
Avoid moisture. To reduce the risk of re or electric shock, do not expose this equipment to rain or moisture.
Use recommended accessories. To reduce the risk of re or electric shock and annoying interference, use only the
recommended accessories.
Important Safety Information

3
TABLE OF CONTENTS ..................................... 3
INTRODUCTION ................................................ 4
Thank You! .................................................... 4
Features ........................................................ 4
Precautions ................................................... 4
Packing List................................................... 4
INSTALLATION .................................................. 5
Tools and Supplies ........................................ 5
Disconnecting the Battery ............................. 5
Selecting the Mounting Location ................... 5
Mounting Switch Plate................................... 5
WIRING (NCSP60CM) ....................................... 6
WIRING (NCSP60SP) ........................................ 7
SYSTEM LAYOUT(NCSP60SP) ........................ 8
SWITCH PLATE BUTTONS ............................. 10
TRAVEL LOCKOUT (SAFETY) * ..................... 10
MOBILE DEVICES: ...........................................11
Paring a Mobile Device ............................... 12
iOS Pairing instructions............................... 12
Pairing Android Mobile Device to DC .......... 14
Passcode Protection ................................... 15
App conguration ..........................................16
Adding 3rd Party Apps. ...................................16
Home Page Operation...................................17
TROUBLE SHOOTING ......................................18
SPECIFICATIONS .............................................19
FEDERAL COMMUNICATIONS COMMISSION
(FCC) STATEMENT .......................................19
• TABLE OF CONTENTS

4
• Thank You!
Thank you for choosing iN-Command. We hope you will
find the instructions in this owner’s manual clear and easy
to follow. If you take a few minutes to look through it, you’ll
learn how to use all the features of your new iN-Command
system for maximum enjoyment.
• Features
Features of iN-Command system:
• Control by either one Android Device or one iOS Device
• Control 3 Light zones
• Control 2 Awnings
• Control 4 Electric Slides
• Control 2 Jacks (non-automatic function)
• Monitor Battery Voltage with Low Voltage Alert
• Precautions
• Use the Proper Power Supply.
This product is designed to operate with a 12 volt DC,
negative ground battery system (the standard system in
a North American vehicle).
• Use Authorized Service Centers.
Do not attempt to disassemble or adjust this precision
product contact a professional for assistance.
• Avoid Moisture.
To reduce the risk of fire or electric shock, do not expose
this equipment to rain or moisture.
(1) Cover(NCSP60CM)
(1) Body Control Module (NCSP60CM)
• Packing List
(1) Switch Plate (NCSP60SP)
• Avoid Cleaning Products.
The front of this unit should only be cleaned with a slightly
damp cloth. Do not use cleaning products.
• Use Recommended Accessories.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
AND ANNOYING INTERFERENCE, USE ONLY THE
RECOMMENDED ACCESSORIES.
• INTRODUCTION

5
It’s a good idea to read all of the instructions before
beginning the installation. We recommend having your
iN-Command system installed by a reputable RV dealership
• Tools and Supplies
You will need the following:
• Phillips screwdriver
• Wire cutters and strippers
• Electrical tape
• Volt meter/test light
• Crimping tool
• 10 gauge wire for power and slide connections
• 14 and 18 gauge wire for all other connections
• Four #8 PH (0.164” x 0.5”) screws for the CM
• Four #8 FH (0.164” x 0.5”) screws for the SP
• Disconnecting the Battery
To prevent a short circuit, be sure to turn off 12V power
and remove the negative (-) battery cable prior to instal-
lation.
• Selecting the Mounting Location
Select a mounting location, taking care to avoid the
following:
• Places exposed to heat-radiating appliances such as
electric heaters
• Adjacent to other equipment that radiates heat
• Under thermostats
• Poorly-ventilated or dusty places
• Moist or humid locations
Wall For Reference
HOLE SIZES
Switch Plate (SP) 2.5"
Recommended Cutout
CUTOUT
2.5"
• INSTALLATION
• Mounting Switch Plate
• Cut/Drill hole, allowing space below for future
programming and behind for ventilation
• Route wires through the hole and connect
• Check and ensure correct operation
• Mount the unit using four #8 FH (0.164” x 0.5”) screws

6
• WIRING (NCSP60CM)
The wiring diagram depicts all the wiring connections required for proper operation of the unit.
BODY CONTROL MODULE (BCM) CONNECTIONS
Slide 1 Extend
Slide 1 Retract
Slide 2 Extend
Slide 2 Retract
Slide 3 Extend
Slide 3 Retract
Slide 4 Extend
Slide 4 Retract
Awning 1 Extend
Awning 1 Retract
Awning 2 Extend
Awning 2 Retract
Stabilizer Front Extend
Stabilizer Front Retract
Stabilizer Rear Extend
Stabilizer Rear Retract
Interior Lights ON/OFF
Awning Lights 1 ON/OFF
Awning Lights 2 ON/OFF
Travel Lock Input ON/OFF
12 Volts Input
Ground
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
PIN 6
PIN 7
PIN 8
PIN 9
PIN 10
PIN 11
PIN 12
PIN 13
PIN 14
PIN 15
PIN 16
PIN 17
PIN 18
PIN 19
PIN 20
PIN 21
PIN 22
OUT
RESET BUTTON
(Max Output 500mA)

7
• WIRING (NCSP60SP)
BLUETOOTH PAIRING
INDICATOR LIGHT(BLUE)
POWER INDICATOR
LIGHT (RED)
BLUETOOTH PAIRING
BUTTON
TRAVEL LOCK
BUTTON
+
-
1
3
4
2
+12VDC
GND
3
1
4
2PIN 1 CAN BUS H
PIN 3 NC
PIN 2 CAN BUS L
PIN 4 NC
INPUT
The wiring diagram depicts all the wiring connections required for proper operation of the unit.
SWITCH PLATE (SP) CONNECTIONS

8
• SYSTEM LAYOUT(NCSP60SP)
NCSP60CM
NCSP60SP

9
CAN +
-
CAN
NCSP60CM
12VDC
500mAOutput Max
FAN
FANFAN
ACACAC
ROOM
SENSOR
ROOM
SENSOR
ROOM
SENSOR
EOL (END OF LINE)
TERMINATOR RESISTOR
REQUIRED AT END OF CAN BUS*
EOL TERMINATOR RESISTOR
DISPLAY COMMANDER
BODY CONTROL MODULE
EOL (END OF LINE)
TERMINATOR RESISTOR
REQUIRED AT END OF CAN BUS*
OPTIONAL SYSTEM UPGRADE:
AN NCSP3DCCT WITH NCSP3DCCTR
CAN REPLACE NCSP60SP
ZONE 1 ZONE 2 ZONE 3
GATEWAYGATEWAYGATEWAY

10
• TRAVEL LOCKOUT (SAFETY) *
iN-Command is equipped with a Travel Lockout feature to
ensure certain system functions are unavailable during transit.
When the Brake on the vehicle is activated, iN-Command
will lock out (disable) all motorized functions. The Travel
Lock LED will be solid red if the brake is actively engaged or
ashing red when the brake signal is removed. Mobile devices
will display "Travel Lock Engaged" and the affected motor
functions will not be availabe.
The light controls will continue to function.
To turn the Travel Lock off press the “Travel Lock” button on
the Switch Plate inside the RV.
Travel Lock on the Switch Plate
Travel Lock on a handheld device app
• SWITCH PLATE BUTTONS
The SP (Switch Plate) has 2 buttons on the front of it.
From left to right, they are:
• Travel Lock
• Bluetooth Pairing
The Travel Lock button turns off the Travel Lock function
when the light is ashing red. The Bluetooth Pairing
button is used to pair and unpair the mobile app to and
from the SP.

11
• MOBILE DEVICES:
iN-Command is able to pair to Android and iOS devices
via the mobile App.
Visit the Google Play and Apple App stores on your mobile
device to download and use the iN-Command App.
Only One mobile device is able to be paired with
iN-Command.
Download iN-Command
Android App
Download iN-Command
iOS App

12
• Paring a Mobile Device
Press and hold the "Bluetooth pairing" button for
5 seconds to enter discovery mode. The blue LED
will start to ash.
• iOS Pairing instructions
1. Enable "Bluetooth" in the system settings of the mobile
device.

13
2. The Swicth Plate (NCSP60SP) will be displayed on the
mobile device list in the format NCSP60XXXXX.
Select the Swicth Plate on the mobile device to pair with it.
3. The mobile device now shows that the Switch Plate is
connected. The Blue LED on the Switch Plate will stop
ashing.

14
• Pairing Android Mobile Device to DC
1. From the App Home Page select
Settings.
2. Select the "Bluetooth" tab.
3. Press Scan to start scanning for Unpaired
devices. Locate the SP in the Unpaired
Device list. Select the device by pressing it.

15
4. A Bluetooth pairing request will
appear on the mobile device.
4.1 Press "Pair" on the mobile device.
5. The Switch Plate will be displayed
in the "Paired devices" list on the
mobile App.
• Passcode Protection
A passcode is required to access the
system. The rst time the App is opened,
the user is required to enter and conrm
a new passcode.

16
• App conguration
The iN-Command app is congurable. The user can select
which functions are populated. Select the Settings icon at the
bottom of the home page, then press the Conguration tab.
To select or deselect an item, press on the box next to the
function. When an item is selected, a check mark will appear
in the box.
• Adding 3rd Party Apps.
3rd party apps can be added to the home page to provide a
quick link to the apps. In the Settings page, select the Apps
tab. Once in the App page, there are info icons that provides
description of the app function and a link to the app on the
app store. To add the app icon, press the box next to app
title. A check mark will appear in the box indicationg that it is
selected. The app icon will now appear on the home page.

17
• Home Page Operation
From the home page, you can check the battery voltage,
operate light controls, slide out functions, awning functions
and jack functions.

18
• TROUBLE SHOOTING
Symptom Solution
No power to the Switch
Plate (SP).
Check +12V and Ground input connections on back of the Switch Plate.
Verify power wires are connected to the 2-pin connector on the Body Control Module (BCM)
Body Control Module (BCM)
is not powering on.
Check if the red power LED is off.
Check the fuse in the distribution panel.
Verify +12V on wire at pin 21. Verify Ground on wire at pin 22
Functions not operating
from mobile app and battery
voltage is displaying 0V. Check to ensure RVC cable (4 pin connector) is connected properly at the SP and BCM.
If an issue is unable to be resolved using the above methods, contact ASA Electronics Technical Support at 800-688-3135
or email them at [email protected]

19
• SPECIFICATIONS
NSCP60CM (Body Control Module)
Operating Voltage . . . . . . . . . .. . . . . . . . . . . . . 12VDC
Maximum Current Draw . . . . . . . .. .. 500mA@12VDC
NCSP60SP(Switch Plate)
Operating Voltage . . . . . . . . . . . . . . . . . . . . . . 12VDC
Maximum Current Draw . . . . . . . . . . . 500mA@12VDC
System
EPROM Non-Volatile Memory . . .. . . . . . . . . . . . . YES
Bluetooth Version . . . . . . . . . . . . . . ... . . . . . . 4.0 BLE
General
Body Control Module ... . 8.5” (W) x 5.8” (D) x 2.0” (H)
Switch Plate…….... .. . . . . 4.0” (W) x 3.0” (D) x 1.1” (H)
15.21
You are cautioned that changes or modications not
expressly approved by the part responsible for compliance
could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
• FEDERAL COMMUNICATIONS COMMISSION
(FCC) STATEMENT
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference and
2) this device must accept any interference received,
including interference that may cause undesired operation
of the device.
FCC RF Radiation Exposure Statement:
1.This Transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
2.This equipment complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment.
3.This equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator
and your body.

600-2100020-001
