INDCO CB Series User manual

CB(G) Series Mixers
tablEOFCONTENTS:
Safety & General ..........................................................2
Operation......................................................................5
Maintenance.................................................................5
Parts List ......................................................................6
4040 Earnings Way •New Albany, IN 47150
P: 812-941-5954 F: 812-944-9742
INDCO.COM •[email protected]
INDCO, Inc. • M-M-30107 mixer manual CB(G) Series • 05/13/05 • Page 1
Bung
Entering
Mixers
OWNERSMANUAL
Warranty
Our products are guaranteed against
defective materials and workmanship,
we will repair or replace such items
as may prove defective at our option.
Warranty period is one year on items
manufactured by INDCO, except for the
MixMaster Series Shakers which carries
a two year warranty. On items not
manufactured by INDCO, the
manufactures warranty applies. All
component parts of our products are
covered by this warranty, except for
normal wear items such as belts or
impellers. We cannot be responsible
for damage or abuse to equipment
caused by improper installation or
operation. Warranties can also be
voided by unauthorized disassembly of
equipment. For warranty repairs,
equipment is returned to INDCO at
the customer’s expense; we will repair
and return to customer at our expense.
Under no circumstances will we allow
labor charges or other expense to repair
defective merchandise. This warranty is
exclusive and is in lieu of all other
warranties, whether express or implied.
INDCO shall not be liable for any other
damages, whether consequential,
indirect, or incidental, arising from the
sale or use of its products.

INDCO, Inc. M-M-30107 mixer manual CB(G) date: 5/13/05
100 - Motor:
Part No.:
HP: RPM:
volts: cycles: phase:
frame: enclosure:
200 - Gear Box: (CBG series only)
G.Box Part No.:
RPM output
300 - Shaft:
Diameter
• Total length
• Length exposed
400 - Impellers:
Diameter
Type
Model:
Serial No.:
Date:
Order No.:
CB(G) Series Bung Entering Mixers
Air -or- Electric Motor
Direct Drive
100
300
400
Air -or- Electric Motor
Gear Drive
100
200
300
400
page 2 of 9

INDCO, Inc. M-M-30107 mixer manual CB(G) date: 5/13/05
General
• Single-phase TEFC models include cord, plug and switch.
• EP models must be wired in the field by the user.
• DC-Variable-Speed electric models have a controller
mounted to the mixer and they are pre-wired.
• Air motors include exhaust muffler.
CB - Rim Mount Series
Direct Drive Models - These direct drive mixers are ideal
for mixing and blending low to medium viscosity materials
or for resuspending settled solids. They clamp on to the
rim of a steel drum and allow the shaft to be inserted into
either a closed or open drum. All models come with 2-
blade folding impellers, which fit easily through all 2” NPT
openings.
CBG - Rim Mount Series
Gear Drive Models - The heavy duty 5:1 ratio helical gearbox
provides plenty of torque for all sorts of tough jobs. They
will quickly mix drums of higher viscosity materials like
heavy paints, resins, polymers, etc., as well as resuspend
settled materials. As the direct drive models above, they
clamp on to the rim of either closed or open steel drum.
They too, come with stainless steel folding impellers that
will fit through the bung opening of a closed drum.
Safety
Please follow the below safety precautions. If there are
any questions, please call INDCO at 800-942-4383.
Please read this complete manual before trying to operate
your mixer. Failure to follow these instructions could result
in serious bodily injury or death.
• Do not touch moving parts while mixer is operating.
Do not wear loose-fitting clothes or jewelry around an
operating mixer. Keep all hands, feet, clothes, neckties,
necklaces and other objects clear of moving parts.
• Never move the unit without a suitable lifting device.
• Have a qualified individual bring power to your unit.
• Always ground the unit. Never use an extension cord.
• Never run the unit in open air.
• Never adjust the speed without the unit running.
• Always lockout the power when working on the unit.
Electric Motor Safety:
Motors should be installed, protected and fused in
accordance with latest issue of National Electrical Code,
NEMA Standard Publication No. MG 2 and local codes.
Frames and accessories of motors should be grounded in
accordance with National Electrical Code (NEC) Article 430.
For general information on grounding refer to NEC Article
250.
Not all rotating parts are guarded. Keep hands and clothing
away from moving parts.
Trained, qualified personnel should make electrical repairs
and non-standard connections.
If environment has hazardous combustible fumes present,
use only explosion-proof electric motors.
Air Motor Safety:
The air motor is designed to be driven by compressed air
and under no circumstances be driven with any other gases.
Fluids, particles, solids or any substance mixed with air,
particularly combustible substances likely to cause
explosions, must not drive air motor.
• Do not drive with flammable or explosive gases or
operate unit in an atmosphere containing them.
• Air motor is designed for air only. Do not allow corrosive
gases or particulate material to enter motor. Water
vapor, oil-based contaminants, or other liquids must be
filtered out.
• Do not use a hammer or force coupling or drive pulley
onto shaft when installing drive onto air motor. This
causes end thrust that could damage air motor.
• Ambient temperature should not exceed 250°F.
• Beware of any exposed and/or movable parts. Proper
guards should be in place to prevent personal and/or
property damage.
• Solid or liquid material exiting unit can cause eye or
skin damage. Keep away from air stream.
• Always disconnect air supply before servicing.
• Do not allow air motor to “run free” at high speeds with
no loads. Excessive internal heat build-up, loss of
internal clearances and rapid motor damage will result.
• Some models may exceed 85dB(A) sound level.
Hearing protection should be worn when in close
proximity to these models.
Receiving
Before removing any packing, visually inspect the exterior
of the shipment for any sign of damage. Should there be
any damage, bring it to the attention of the delivering UPS
or truck line and note the same on the receiving ticket.
Should there be damage you must place a claim with the
truck line. They are the only ones who will pay for the
damage done and you are the only one who can place that
claim.
page 3 of 9

INDCO, Inc. M-M-30107 mixer manual CB(G) date: 5/13/05
Gear Drive, CBG Series
• The gear box is filled with oil.
• The brass plug supplied loose is a Filler-Vent Plug.
After mounting the mixer, install the Filler-Vent Plug in
the highest filler point as shown below.
Shaft & Coupler
To install mixer shaft, back off the set screws as far as
possible without removing them. Insert mixing shaft into
the coupler as far as it will go. Tighten all the set screws
firmly to secure the shaft to the coupler.
Impellers
To install the impeller, back off the set screw(s) as far as
possible without removing them. Insert mixing shaft into
the bore and tighten the set screw(s) firmly to secure the
impeller to the shaft.
Installation
Your new mixer requires some assembly. Ensure ALL set-
screws and fasteners on the unit have been tightened
completley before operating the equipment. The impeller(s)
and impeller-shaft have to be fitted to the machine before it’s
operational. For more information, see the parts list pages
for general arrangement drawings.
Impeller Placement
For mixers with ONE impeller, mount it 1 to 2 impeller
diameters distance off the bottom of mixing container.
For mixers with TWO or more impellers, mount the lowest
impeller 1 to 2 impeller diameters distance off the bottom
of mixing container. Mount the other impellers 1 to 2 impeller
diameters apart. The uppermost impeller should be
positioned approximately 1 impeller diameter under the
surface of the liquid.
The above guidelines are “rules of thumb” and may not be
the best for your situation. Experimenting with impeller
placement may provide your best results.
Filler-Vent Plug Location
• Remove Allen head plug
Mounting
Insert shaft and impellers through the drum’s 2” bung
opening. Rest mixer rim bracket on to top of drum. Adjust
the rubber tipped studs to the desired height. Gently tighten
hand-knob to side of drum. Mixer is now ready to operate.
rubber tipped studs
hand-knob
55-gallon drum
shaft
set screw
set screws
shaft
shaft coupler
page 4 of 9

INDCO, Inc. M-M-30107 mixer manual CB(G) date: 5/13/05
Maintenance
Maintaining your mixer is not difficult if you follow these
guidelines:
- Keep the mixer clean.
- Check all wiring on a regular basis and repair as needed.
- Air motor powered units:
• Keep air supply dry and oil in the lubricator.
Lubrication:
CBG Series
The gear box contains oil from the factory.
The recommended replacement oil is:
- All CBG models, gearbox model #RPQ1:
• Mobil Extra Hecla
• Shell Oil Omala 680
• Texaco Meropa 680
• or equivalent to above
For 50°F to 125°F ambient.
Oil capacity is 11 ounces.
Operation
Electric Power: Once the electric motor has been wired,
check rotation to be sure the mixer shaft is rotating in a
clockwise direction, looking downward into the container.
Air Power: Check to ensure the air valve is in the closed
position, then connect air supply. Check rotation to be
sure the mixer shaft is rotating in a clockwise direction,
looking downward into the container.
Once the mixer is in the container, it is now safe to
operate.
CAUTION:
9Never run mixer without a propeller.
9Never run the propeller in open air.
9Never run propeller outside a container.
page 5 of 9

INDCO, Inc. M-M-30107 mixer manual CB(G) date: 5/13/05
Air Motors
Parts List - Drive Motors
3/4 HP1.5 HP4 HP
Item 100 Part No. Description
MTR-1/3-56C-1-EP 56C, fixed speed 1/3 HP Explosion-Proof 115/230VAC 1-phase
MTR-1/3-56C-1-TEFC 56C, fixed speed 1/3 HP TEFC 115/230VAC 1-phase
CPG-INLINE-18/3 Cord 18/3 - 6’, plug and in-line ON-OFF switch
MTR-098004 56C, variable speed 1/3 HP TEFC 115VAC to 90VDC 1-phase
MTR-DC-CONTROL DC motor controller, variable speed - 1/3 thru 2HP
CPG-18/3 Cord 18/3 - 6’ with plug
MET-VSO-BRACKET Angle brackets, mounts v.s. controller to motor (2 req’d)
1/3
HP
Electric Motors
MTR-3/4-FOOT-AIR-CCW Foot Mount - 3/4 HP (2AM-FCC-1) CCW rotation only
N-K202 Repair Kit* (2AM-FCC-1)
MTR-3/4-56C-AIR 56C Mount - 3/4 HP (2AM-NRV-90) bi-rotational
N-K510 Repair Kit* (2AM-NRV-90)
HDW-1/4-VALVE Needle valve, brass - 1/4”
HDW-2502-SNB Pipe nipple, steel - 1/4” X 2”
N-AL445 Muffler, plastic
N-AC980 Muffler, metal
MTR-1.5-FOOT-AIR Foot Mount - 1.5HP (4AM-FRV-13C) bi-rotational
N-K205 Repair Kit* (4AM-FRV-13C)
MTR-1.5-56C-AIR 56C Mount - 1.5 HP (4AM-NRV-50C) bi-rotational
N-K206A Repair Kit* (4AM-NRV-50C)
HDW-1/4-VALVE Needle valve, brass - 1/4”
HDW-25-CNG Pipe nipple, steel - 1/4” X 7/8”
N-AL445 Muffler, plastic
N-AC980 Muffler, metal
MTR-4-FOOT-AIR Foot Mount - 4 HP (6AM-FRV-5A) bi-rotational
N-K208 Repair Kit* (6AM-FRV-5A)
HDW-1/2-VALVE Needle valve, brass - 1/2”
HDW-50-CNG Pipe nipple, steel - 1/2” X 1-1/8”
N-AC990 Muffler, metal
* Repair Kits include: Vanes, shaft seal, o-rings, DE & NDE bearings,
body & end cap gaskets.
page 6 of 9

INDCO, Inc. M-M-30107 mixer manual CB(G) date: 5/13/05
MTR-1/2-56C-1-EP 56C, fixed speed 1/2 HP Explosion-Proof 115/230VAC 1-phase
MTR-1/2-56F-1-EP 56F, fixed speed 1/2 HP Explosion-Proof 115/230VAC 1-phase
MTR-1/2-56C-1-TEFC 56C, fixed speed 1/2 HP TEFC 115/230VAC 1-phase
MTR-1/2-56F-1-TEFC 56F, fixed speed 1/2 HP TEFC 115/230VAC 1-phase
CPG-INLINE-18/3 Cord 18/3 - 6’, plug and in-line ON-OFF switch
MTR-098000 56C, variable speed 1/2 HP TEFC 115VAC to 90VDC 1-phase
MTR-DC-CONTROL DC motor controller, variable speed - 1/3 thru 2HP
CPG-18/3 Cord 18/3 - 6’ with plug
MET-VSO-BRACKET Angle brackets, mounts v.s. controller to motor (2 req’d)
MTR-3/4-56F-1-EP 56F, fixed speed 3/4 HP Explosion-Proof 115/230VAC 1-phase
MTR-3/4-56F-1-TEFC 56F, fixed speed 3/4 HP TEFC 115/230VAC 1-phase
CPG-14/3 Cord 14/3 - 5’ with plug
SWT-TOGGLE ON - OFF switch
SWT-GUARD Switch guard
MTR-108018 56C, variable speed 3/4 HP TEFC 115VAC to 90VDC 1-phase
MTR-DC-CONTROL DC motor controller, variable speed - 1/3 thru 2HP
CPG-14/3 Cord 14/3 - 5’ with plug
MET-VSO-BRACKET Angle brackets, mounts v.s. controller to motor (2 req’d)
MTR-1-56F-1-EP 56F, fixed speed 1 HP Explosion-Proof 115/230VAC 1-phase
MTR-1-56F-1-TEFC 56F, fixed speed 1 HP TEFC 115/230VAC 1-phase
CPG-14/3 Cord 14/3 - 5’ with plug
SWT-DP-TOGGLE ON - OFF switch
SWT-GUARD Switch guard
MTR-108022 56C, variable speed 1 HP TEFC 115VAC to 90VDC 1-phase
MTR-DC-CONTROL DC motor controller, variable speed - 1/3 thru 2HP
CPG-14/3 Cord 14/3 - 5’ with plug
MET-VSO-BRACKET Angle brackets, mounts v.s. controller to motor (2 req’d)
Electric Motors
Parts List - Drive Motors (continued)
1 HP 3/4 HP
Item 100 Part No. Description
1/2 HP
page 7 of 9

INDCO, Inc. M-M-30107 mixer manual CB(G) date: 5/13/05
Parts List: CB(G) Series
vent
Air -or- Electric Motor
Gear Drive
100
300
400
401
220
200
504
500
503502501
201
Air -or- Electric Motor
Direct Drive
300
400
401
220
100
500
504 503502501
page 8 of 9

INDCO, Inc. M-M-30107 mixer manual CB(G) date: 5/13/05
Item Qty. Part No. Description
100. 1 see ‘Parts List - Drive Motors’ Motor, air
100. 1 see ‘Parts List - Drive Motors’ Motor, electric
200. 1 HDW-GB-56C Gear Box, 5:1 ratio
201. 1 HDW-4704-0004 Vent, 1/4” MNPT - brass (for HDW-GB-56C only)
210. 1 HDW-GB-56C-FEET Mounting feet (set) gearbox to rim bracket.
220. 1 CPL-5062 Coupling - shaft, 1/2” bore x 5/8” bore - stainless
220. 1 CPL-6262 Coupling - shaft, 5/8” bore x 5/8” bore - stainless
300. 1 SS632 Shaft - impeller, 5/8” dia. x 32” long - stainless
300. 1 SS636 Shaft - impeller, 5/8” dia. x 36” long - stainless
400. 1,2,3 FP334 Folding Impeller, 4” diameter, 2-blade with 5/8” bore - stainless
400. 1,2,3 FP762 Folding Impeller, 7” diameter, 2-blade with 5/8” bore - stainless
401. 2,4,6 N-HARDWARE Set screw, 1/4”-20 x 1/4” long - stainless
Rim Bracket Assembly:
500. 1 CLP-N Rim ~ Clamp mount - painted steel
501. 1 HDW-CSP-1 Swivel pad
502. 1 SHF-TR124 Threaded rod, 1/2” x 4” long
503. 1 HDW-HK42 Hand knob - cast aluminum
504. 2 HDW-CL518208FC Rubber tipped stud with nuts
Parts List: CB(G) Series
page 9 of 9
