General
• Single-phase TEFC models include cord, plug and switch.
• EP models must be wired in the field by the user.
• DC-Variable-Speed electric models have a controller
mounted to the mixer and they are pre-wired.
• Air motors include exhaust muffler.
BM - Bracket Mount Series
Gear Drive Models - The versatile mounting bracket
straddles the top of the drum or tank. Adjusts easily to fit
any container from 18” to 31” diameter. Sturdy steel
construction for heavy duty use. These models are sized
to fit 30 and 55-gallon drums, and small tanks up to about
100-gallons. Standard shafts are stainless steel and impellers
are 3-blade stainless steel.
Receiving
Before removing any packing, visually inspect the exterior of
the shipment for any sign of damage. Should there be any
damage, bring it to the attention of the delivering UPS or
truck line and note the same on the receiving ticket. Should
there be damage you must place a claim with the truck line.
They are the only ones who will pay for the damage done and
you are the only one who can place that claim.
Safety
Please follow the below safety precautions. If there are
any questions, please call INDCO at 800-942-4383.
Please read this complete manual before trying to operate
your mixer. Failure to follow these instructions could result
in serious bodily injury or death.
• Do not touch moving parts while mixer is operating.
Do not wear loose-fitting clothes or jewelry around an
operating mixer. Keep all hands, feet, clothes, neckties,
necklaces and other objects clear of moving parts.
• Never move the unit without a suitable lifting device.
• Have a qualified individual bring power to your unit.
• Always ground the unit. Never use an extension cord.
• Never run the unit in open air.
• Never adjust the speed without the unit running.
• Always lockout the power when working on the unit.
Electric Motor Safety:
Motors should be installed, protected and fused in
accordance with latest issue of National Electrical Code,
NEMA Standard Publication No. MG 2 and local codes.
Frames and accessories of motors should be grounded in
accordance with National Electrical Code (NEC) Article 430.
For general information on grounding refer to NEC Article
250.
Not all rotating parts are guarded. Keep hands and clothing
away from moving parts.
Trained, qualified personnel should make electrical repairs
and non-standard connections.
If environment has hazardous combustible fumes present,
use only explosion-proof electric motors.
Air Motor Safety:
The air motor is designed to be driven by compressed air
and under no circumstances be driven with any other gases.
Fluids, particles, solids or any substance mixed with air,
particularly combustible substances likely to cause
explosions, must not drive air motor.
• Do not drive with flammable or explosive gases or
operate unit in an atmosphere containing them.
• Air motor is designed for air only. Do not allow corrosive
gases or particulate material to enter motor. Water
vapor, oil-based contaminants, or other liquids must be
filtered out.
• Do not use a hammer or force coupling or drive pulley
onto shaft when installing drive onto air motor. This
causes end thrust that could damage air motor.
• Ambient temperature should not exceed 250°F.
• Beware of any exposed and/or movable parts. Proper
guards should be in place to prevent personal and/or
property damage.
• Solid or liquid material exiting unit can cause eye or
skin damage. Keep away from air stream.
• Always disconnect air supply before servicing.
• Do not allow air motor to “run free” at high speeds with
no loads. Excessive internal heat build-up, loss of
internal clearances and rapid motor damage will result.
• Some models may exceed 85dB(A) sound level.
Hearing protection should be worn when in close
proximity to these models.
page 2 of 7

INDCO, Inc. M-M-30112 mixer manual BM date: 7/26/05
Shaft & Coupler
To install mixer shaft, back off the set screws as far as
possible without removing them. Insert mixing shaft into the
coupler as far as it will go. Tighten the set screws firmly to
secure the shaft to the coupler.
Impellers, mounting
To install the impeller, back off the set screw(s) as far as
possible without removing them. Insert mixing shaft into
the bore and tighten the set screw(s) firmly to secure the
shaft to the impeller.
Installation
Your new mixer requires some assembly. Ensure ALL set-
screws and fasteners on the unit have been tightened
completley before operating the equipment. The impeller(s)
and impeller-shaft have to be fitted to the machine before it’s
operational. For more information, see the parts list pages
for general arrangement drawing.
Gear Drive, BM Series
• The gear box is filled with oil.
• The brass plug supplied loose is a Filler-Vent Plug. After
mounting the mixer, install the Filler-Vent Plug in the highest
filler point as shown below.
Impellers, placement
For mixers with ONE impeller, mount it 1 to 2 impeller
diameters distance off the bottom of mixing container.
For mixers with TWO or more impellers, mount the lowest
impeller 1 to 2 impeller diameters distance off the bottom
of mixing container. Mount the other impellers 1 to 2 impeller
diameters apart. The uppermost impeller should be
positioned approximately 1 impeller diameter under the
surface of the liquid.
The above guidelines are “rules of thumb” and may not be
the best for your situation. Experimenting with impeller
placement may provide your best results.
Operation
Electric Power: Once the electric motor has been wired,
check rotation to be sure the mixer shaft is rotating in a
clockwise direction, looking downward into the container.
Air Power: Check to ensure the air valve is in the closed
position, then connect air supply. Check rotation to be
sure the mixer shaft is rotating in a clockwise direction,
looking downward into the container.
Once the mixer is in the container, it is now safe to
operate.
CAUTION:
9Never run mixer without a propeller.
9Never run the propeller in open air.
9Never run propeller outside a container.
shaft
set screws
Filler-Vent Plug Location
• Remove Allen head plug
Drain Plug Location
Maintenance
Maintaining your mixer is not difficult if you follow these
guidelines:
- Keep the mixer clean.
- Check all set-screws and fasteners, tighten as needed.
- Check all wiring on a regular basis and repair as needed.
- Air motor powered units:
• Keep air supply dry and oil in the lubricator.
Lubrication:
Gear Reducer:
The gear box contains oil from the factory.
The recommended replacement oil is:
- Gearbox models #RPQ1 and RPQ2:
• Mobil Extra Hecla
• Shell Oil Omala 680
• Texaco Meropa 680
• or equivalent to above
- For 50°F to 125°F ambient.
- RPQ1 Oil capacity is 11 ounces.
- RPQ2 Oil capacity is 14 ounces.
page 3 of 7
set screws
shaft
shaft coupler

INDCO, Inc. M-M-30112 mixer manual BM date: 7/26/05
MTR-3/4-56C-AIR 56C Mount - 3/4 HP (2AM-NRV-90) bi-rotational
N-K510 Repair Kit* (2AM-NRV-90)
HDW-1/4-VALVE Needle valve, brass - 1/4”
HDW-2502-SNB Pipe nipple, steel - 1/4” X 2”
N-AL445 Muffler, plastic
N-AC980 Muffler, metal
MTR-1.5-56C-AIR 56C Mount - 1.5 HP (4AM-NRV-50C) bi-rotational
N-K206A Repair Kit* (4AM-NRV-50C)
HDW-1/4-VALVE Needle valve, brass - 1/4”
HDW-25-CNG Pipe nipple, steel - 1/4” X 7/8”
N-AL445 Muffler, plastic
N-AC980 Muffler, metal
MTR-4-56C-AIR 56C Mount - 4 HP (6AM-NRV-11A) bi-rotational
N-K208 Repair Kit* (6AM-NRV-11A)
HDW-1/2-VALVE Needle valve, brass - 1/2”
HDW-50-CNG Pipe nipple, steel - 1/2” X 1-1/8”
N-AC990 Muffler, metal
* Repair Kits include: Vanes, shaft seal, o-rings, DE & NDE bearings,
body & end cap gaskets.
Air Motors
Parts List - Drive Motors
3/4 HP1.5 HP4 HP
Item 100 Part No. Description
page 4 of 7

INDCO, Inc. M-M-30112 mixer manual BM date: 7/26/05
MTR-1/3-56C-1-EP 56C, fixed speed 1/3 HP Explosion-Proof 115/230VAC 1-phase
MTR-1/3-56C-1-TEFC 56C, fixed speed 1/3 HP TEFC 115/230VAC 1-phase
CPG-INLINE-18/3 Cord 18/3 - 6’, plug and in-line ON-OFF switch
MTR-098004 56C, variable speed 1/3 HP TEFC 115VAC to 90VDC 1-phase
MTR-DC-CONTROL DC motor controller, variable speed - 1/3 thru 2HP
CPG-18/3 Cord 18/3 - 6’ with plug
MET-VSO-BRACKET Angle brackets, mounts v.s. controller to motor (2 req’d)
MTR-1/2-56C-1-EP 56C, fixed speed 1/2 HP Explosion-Proof 115/230VAC 1-phase
MTR-1/2-56C-1-TEFC 56C, fixed speed 1/2 HP TEFC 115/230VAC 1-phase
CPG-INLINE-18/3 Cord 18/3 - 6’, plug and in-line ON-OFF switch
MTR-098000 56C, variable speed 1/2 HP TEFC 115VAC to 90VDC 1-phase
MTR-DC-CONTROL DC motor controller, variable speed - 1/3 thru 2HP
CPG-18/3 Cord 18/3 - 6’ with plug
MET-VSO-BRACKET Angle brackets, mounts v.s. controller to motor (2 req’d)
MTR-3/4-56C-1-EP 56C, fixed speed 3/4 HP Explosion-Proof 115/230VAC 1-phase
MTR-3/4-56C-1-TEFC 56C, fixed speed 3/4 HP TEFC 115/230VAC 1-phase
CPG-14/3 Cord 14/3 - 5’ with plug
SWT-TOGGLE ON - OFF switch
SWT-GUARD Switch guard
MTR-108018 56C, variable speed 3/4 HP TEFC 115VAC to 90VDC 1-phase
MTR-DC-CONTROL DC motor controller, variable speed - 1/3 thru 2HP
CPG-14/3 Cord 14/3 - 5’ with plug
MET-VSO-BRACKET Angle brackets, mounts v.s. controller to motor (2 req’d)
MTR-1-56C-1-EP 56C, fixed speed 1 HP Explosion-Proof 115/230VAC 1-phase
MTR-1-56C-1-TEFC 56C, fixed speed 1 HP TEFC 115/230VAC 1-phase
CPG-14/3 Cord 14/3 - 5’ with plug
SWT-DP-TOGGLE ON - OFF switch
SWT-GUARD Switch guard
MTR-108022 56C, variable speed 1 HP TEFC 115VAC to 90VDC 1-phase
MTR-DC-CONTROL DC motor controller, variable speed - 1/3 thru 2HP
CPG-14/3 Cord 14/3 - 5’ with plug
MET-VSO-BRACKET Angle brackets, mounts v.s. controller to motor (2 req’d)
Electric Motors
Parts List - Drive Motors (continued)
1 HP 3/4 HP
Item 100 Part No. Description
1/3 HP1/2 HP
page 5 of 7

INDCO, Inc. M-M-30112 mixer manual BM date: 7/26/05
Parts List: BM Series
100
220
300
400
500
vent
201
401
200
509
508 505503 504
502501
110
111
507
506
page 6 of 7

INDCO, Inc. M-M-30112 mixer manual BM date: 7/26/05
Item Description Part No. Qty.
100. Motor, air see ‘Parts List - Drive Motors’ 1
100. Motor, electric see ‘Parts List - Drive Motors’ 1
110. Bolt, 3/8”-16 x 1” N-HARDWARE 4
111. Lock washer, 3/8” N-HARDWARE 4
200. Gear Box, 5:1 ratio, All except shown below. HDW-GB-56C 1
200. Gear Box, 5:1 ratio for: BM-4A only HDW-GB-56C-LG 1
201. Vent, 1/4” MNPT - brass (for HDW-GB-56C only) HDW-4704-0004 1
220. Coupling - shaft, 5/8” x 5/8” CPL-6262 1
300. Shaft - impeller, 5/8” dia. x 30” long - stainless SS630 1
400. Turbine, 9” diameter, 3-blade with 5/8” bore - 316SS STI-9 1~2
400. Turbine, 10” diameter, 3-blade with 5/8” bore - 316SS STI-10 1
401. Set screw, 1/4”-20 x 1/4” long - stainless N-HARDWARE 2~4
Bracket Assembly:
500. Bracket Ass’y Complete, consisting of: DTB 1
501. Adjustable bracket frame (set) HDW-DT-BRACKET 1
502. Motor mount plate - 8” x 8” with 56C hole pattern HDW-BT403-MM 1
503. Swivel pad HDW-CSP-1 1
504. Threaded rod, 1/2” x 4” long SHF-TR124 1
505. Hand knob, cast aluminum HDW-HK42 1
506. Drive screw pin, #14 X 3/4” N-HARDWARE 1
507. Spring pin, 3/16” x 1-1/4” N-HARDWARE 1
508. Bolt, 1/4”-20 x 1” N-HARDWARE 2
508. Lock washer, 1/4” N-HARDWARE 2
508. Nut, 1/4”-20 N-HARDWARE 2
509. Bolt, 5/16”-18 x 1” N-HARDWARE 2
509. Lock washer, 5/16” N-HARDWARE 2
509. Nut, 5/16”-18 N-HARDWARE 2
Parts List: BM Series
page 7 of 7
