Operating Manual
D-TEK Stratus®
Refrigerant Leak Detector and Portable Monitor
English · Español · Deutsch · Français · Italiano · 中文 ·日本語 · Pyccĸий·
Polski · Svenska · Türkçe · Nederlands · 한국어
074-708-P16B

INFICON
2 074-708-P16B D-TEK Stratus Operating Manual
English .................................................................................................................... 3
Español................................................................................................................... 34
Deutsch................................................................................................................... 66
Français.................................................................................................................. 99
Italiano .................................................................................................................... 132
中文 ......................................................................................................................... 163
日本語 ..................................................................................................................... 190
Pyccĸий .................................................................................................................. 218
Polski....................................................................................................................... 251
Svenska.................................................................................................................. 282
Türkçe..................................................................................................................... 312
Nederlands............................................................................................................. 343
한국어 ..................................................................................................................... 375

INFICON Table of Contents
074-708-P16B D-TEK Stratus Operating Manual 3
Table of Contents
1 Declaration of Conformity.................................................................................................................................4
2 Cautions and Warnings ....................................................................................................................................5
3 Specifications ...................................................................................................................................................6
4 D-TEK Stratus ................................................................................................................................................10
5 What is Cloud Hunting?..................................................................................................................................12
6 Charging the Battery.......................................................................................................................................13
7 Turning On the Instrument and Preparing for Use .........................................................................................14
8 Screen Layout and Symbols...........................................................................................................................15
9 Cloud Hunting (Portable Monitor) Mode.........................................................................................................17
10 Pinpoint Mode.................................................................................................................................................19
11 Manual Zero Mode .........................................................................................................................................20
12 Earbuds and Volume Control .........................................................................................................................21
13 Removing and Installing the Lithium Ion Battery ............................................................................................22
14 Removing and Installing the Sensor...............................................................................................................23
15 Replacing Filters.............................................................................................................................................24
16 Extra-long Probe.............................................................................................................................................25
17 Needle Probe Extension.................................................................................................................................26
18 Optional Sensors............................................................................................................................................27
19 Cleaning and Storage.....................................................................................................................................28
20 Replacement Parts and Accessories..............................................................................................................29
21 Troubleshooting Guide ...................................................................................................................................30
22 Warranty and Liability-Limitation ....................................................................................................................32
23 Returning the Instrument for Warranty or Repair ...........................................................................................33

1 | Declaration of Conformity INFICON
4 / 405 074-708-P16B D-TEK Stratus Operating Manual
1 Declaration of Conformity
English
English

INFICON Cautions and Warnings | 2
074-708-P16B D-TEK Stratus Operating Manual 5 / 405
2 Cautions and Warnings
Cautions:
• Only use a certified charger/cord with an output of 5 V (dc) ±5%, 1 A ±5%.
• Keep the device out of extremely high or low temperature locations.
• Do not expose the battery to liquid.
• Do not use the device if you notice any damage to the battery.
• Do not disassemble or modify the battery.
• Handle and dispose of the battery per local regulations.
• If the recharging operation fails to complete, even when the specified recharging
time has elapsed, immediately stop further recharging.
• Do not leave the battery unattended while charging.
• Unplug the charger when the battery is fully charged.
• Improper use or disposal of lithium ion batteries can cause a fire.
• High RF environments may cause a false alarm.
WARNING
This symbol alerts the user to the presence of important operating and
maintenance (servicing) instructions.
WARNING
Exposure to high concentrations of CO2 or refrigerants is dangerous and can
be life-threatening.
The instrument is not for use in toxic or hazardous environments. It is not a personal
protection or life-saving device. Always exercise extreme caution in potentially toxic or
hazardous environments.
WARNING
This product is not intrinsically safe and should not be used in the presence of
explosive fumes, explosive dust, or other explosive chemicals. Use in an
environment with flammable refrigerant concentration approaching the LEL
could cause an explosion or fire resulting in serious injury, death, or damage
to property.
English
English

3 | Specifications INFICON
6 / 405 074-708-P16B D-TEK Stratus Operating Manual
3 Specifications
Usage indoor/outdoor
Sensor type infrared
Compatible refrigerants
• Refrigerant sensor (standard, PN
724-701-G1)
All CFCs, HCFCs, HFCs, HFOs, and
blends (including A2Ls)
• CO2 sensor (PN 724-701-G2) R744 (carbon dioxide)
• Flammable refrigerant (HC) sensor
(PN 724-701-G3)
R290, R600a, R441a (see safety
warnings)
Minimum sensitivity (Pinpoint mode,
Super sensitivity)
0.03 oz/yr (1 g/yr)1
Display resolution (Cloud Hunting mode) 1 ppm
Display range (Cloud Hunting mode) 0 to 9999 ppm
Accuracy (Cloud Hunting mode, with
clean air reference, R134a)
±1 ppm ±10% of reading
Battery type lithium ion
Charging input type micro USB
Charging time (starting at 0%) approximately 3 hours
Battery life approximately 8 hours (Cloud Hunting)
approximately 10 hours (Pinpoint)
Input voltage 5 V (dc) ±5%
Input current 1 A ±5%
Warm-up period 45–90 seconds
Temperature ranges and humidity
• Storage -20–60°C (-4–140°F)
• Operating2-20–50°C (-4–122°F)
• Charging 0–45°C (32–113°F)
• Humidity 95% RH NC maximum
Altitude 2000 m (6500 ft.)
Pollution degree 2
Overvoltage category 2
Weight (with battery; not including
carrying case or accessories)
1.10 lb. (0.50 kg)
1 To achieve optimal performance and the specified sensitivities, it is recommended to
allow D-TEK Stratus to run for 15 minutes prior to use.
English
English

INFICON Specifications | 3
074-708-P16B D-TEK Stratus Operating Manual 7 / 405
2 Use in temperatures below 0°C (32°F) should be limited. Extended warm-up time is
recommended before use in low temperature environments.
Specification table in accordance with EN 14624
R134a R1234yf
Minimum sensitivity, fixed (static) 1 g/yr. 0.5 g/yr.
Maximum sensitivity, fixed (static)3>50 g/yr. >50 g/yr.
Minimum sensitivity, moving (dynamic) 1 g/yr. 1 g/yr.
Maximum sensitivity, moving (dynamic)3>50 g/yr. >50 g/yr.
Minimum response/detection time < 1 s < 1 s
Zeroing time 1–4 s 1–4 s
Recovery time for 50 g/yr exposure47.6 s 6.4 s
Minimum sensitivity in contaminated
environment
>2 g/yr. 1 g/yr.
Calibration frequency Check annually with calibrated leak
standard
3 The upper leak detection limit is not specified by INFICON as there is no upper limit
to the size of the leak the detector is able to detect.
4As no 50 g/yr. leak standard was available during testing, a 32 g/yr leak standard was
substituted.
SAE Applications SAE standards J2791 (R-134a) and J2913 (R-1234yf) specify sensitivity to the
following leak sizes for the corresponding settings below. Super sensitivity is more
sensitive than what is required by SAE for leak checking in a clean environment (free
of background refrigerant). If leak checking in a contaminated environment (high
background refrigerant), switch to Super sensitivity.
R-134a leak rate (g/yr) R-1234yf leak rate (g/yr) Sensitivity Setting
14 14 low
7 7 medium
4 4 high
The following table lists some common under-hood chemicals and indicates whether
or not they will cause a false-trigger from D-TEK Stratus.
Chemical False-Trigger
Windshield washer solvent (methanol base) yes
Ford® spot and stain remover yes
Ford rust penetrant and inhibitor yes
Ford gasket and trim adhesive yes
Permatex® natural blue cleaner and degreaser yes
English
English

3 | Specifications INFICON
8 / 405 074-708-P16B D-TEK Stratus Operating Manual
Chemical False-Trigger
Ford brake parts cleaner yes
Ford spray carburetor tune-up cleaner yes
Ford clear silicon rubber yes
Motorcraft® G-05 antifreeze/coolant no
Gunk® liquid wrench no
Ford pumice/lotion hand cleaner no
Ford Motorcraft DOT3 brake fluid no
Ford silcon lubricant no
Dexron® automatic transmission fluid no
Mineral engine oil no
SAE recommended
leak test procedure
Always leak test with the engine off.
1.
Charge the system with sufficient refrigerant to have a gauge pressure of at
least 340 kPa (50 psi) with the system off. At ambient temperatures below 15 °C
(59 °F) leaks may not be measurable because the pressure may not be
reached.
2.
Visually trace the entire refrigerant system, and look for signs of air conditioning
lubricant leakage, damage and corrosion on all lines, hoses and components.
Check each questionable area with the detector probe, as well as all fittings,
hose-to-line couplings, refrigerant controls, service valves with caps in place,
brazed or welded areas, and areas around attachment points and hold-downs
on lines and components. If looking for an apparently larger leak, check first at
the medium (7 g/year) or low (14 g/year) sensitivity setting.
3.
Always follow the refrigerant system around in a continuous path so that no
areas of potential leaks are missed. If a leak is found, always continue to test
the remainder of the system.
4.
Recheck the service valves with the caps removed. Blow shop air over the
service valve to clear the immediate area. Check with a detector on the medium
sensitivity setting (7 g/year).
5.
Move the detector at a rate of no more than 75 mm/s (3 in./s) and as close as
possible to 9.5 mm (3/8 in.) from the surface, completely encircling each test
position (switch, sensor, refrigerant tubing connection, etc.).
English
English

INFICON Specifications | 3
074-708-P16B D-TEK Stratus Operating Manual 9 / 405
6.
Slower movement and closer approach of the probe normally improves the
likelihood of finding a leak. However, detectors made to meet this standard are
based on air sampling from the 9.5 mm (3/8 in) distance. A retest is advisable
when a leak appears to be found at the most sensitive settings, particularly if the
probe was in a static position on a joint, or making physical contact with a joint,
as it was moving. Repeat with a moving probe test at that location, taking care
to maintain the small gap (9.5 mm or 3/8 in.) to confirm that the leak is of
repairable size. Checking with the medium sensitivity setting (7 g/year) after
finding an apparent leak with the high sensitivity setting (4 g/year) also may be
helpful.
Patents (Pending) • Application #10 2018 206 877.1
• Application #18171080.7
• Application # 10 2018 208 826.8
English
English

4 | D-TEK Stratus INFICON
10 / 405 074-708-P16B D-TEK Stratus Operating Manual
4 D-TEK Stratus
MODE button
SENS/ZERO
button
eject button
exhaust port (do not block)
battery door
English
English

INFICON D-TEK Stratus | 4
074-708-P16B D-TEK Stratus Operating Manual 11 / 405
power button micro USB
power input
volume button headphone jack
English
English

5 | What is Cloud Hunting? INFICON
12 / 405 074-708-P16B D-TEK Stratus Operating Manual
5 What is Cloud Hunting?
When refrigerant leaks from a system, it does not disperse evenly in the air. The
concentration of refrigerant is usually higher near the source of the leak. The density
of refrigerants is also different than that of air, so it tends to form “clouds” in the air,
typically closer to the floor. These clouds are colorless and odorless for most
refrigerants. When leak checking with a traditional leak detector, it will likely alarm
when walking into a refrigerant cloud. This does not help you find the leak, because
the cloud may not be near the leak source.
D-TEK Stratus uses patent-pending technology to display the refrigerant concentration
in the air in parts per million (ppm). This allows you to read the display and follow the
number to find areas of higher concentration, leading you straight to the leak source.
English
English

INFICON Charging the Battery | 6
074-708-P16B D-TEK Stratus Operating Manual 13 / 405
6 Charging the Battery
D-TEK Stratus uses a rechargeable lithium ion battery that comes partially charged.
INFICON recommends charging the battery before its first use. Using the supplied
charger or charging cradle accessory, a dead battery can be charged to 80% in
approximately 2 hours and 100% in approximately 3 hours. A full charge typically lasts
about 8 to 10 hours of operation, depending on the mode used and the operating
temperature. An on-screen indicator displays the remaining battery percentage.
D-TEK Stratus can be used while charging.
English
English

7 | Turning On the Instrument and Preparing for Use INFICON
14 / 405 074-708-P16B D-TEK Stratus Operating Manual
7 Turning On the Instrument and
Preparing for Use
If the screen does not turn on, the battery is low and needs to be charged. D-TEK
Stratus can be used while charging.
1.
Long press the power button (located on the left side of the body of the
instrument) to turn D-TEK Stratus On or Off.
ðD-TEK Stratus begins a variable-time warm-up for 45 to 90 seconds. When
warm-up is complete, D-TEK Stratus is ready to use.
2.
To switch modes, press the MODE button. This toggles between Cloud Hunting,
Pinpoint and Manual Zero modes.
D-TEK Stratus always starts in the last mode that was used.
WARNING
Do not block the exhaust port.
Blocking exhaust air can cause false alarms or readings.
English
English

INFICON Screen Layout and Symbols | 8
074-708-P16B D-TEK Stratus Operating Manual 15 / 405
8 Screen Layout and Symbols
D-TEK Stratus uses the display screen for all indicators and information. The display
consists of a top bar, main display, and a bottom bar.
top bar
main display
bottom bar
Top bar: The top bar includes the battery symbol, the percentage, the sensor indicator
(when a non-standard sensor type is used), and the sound indicator.
Symbol Description
battery charge is 75–100%
battery charge is 50–74%
battery charge is 30–49%
battery charge is 10–29%
battery charge is <10%
battery is charging
volume is set to 100% (default)
volume is set to 50%
volume is muted
CO2 sensor is installed
Main display: The main display shows the information needed for leak checking. The
main display includes the ppm reading for Cloud Hunting mode and leak indicators for
Pinpoint and Manual Zero modes.
Bottom bar: The bottom bar displays the current mode and the mode indicator symbol.
It also includes the sensitivity for Pinpoint mode.
English
English

8 | Screen Layout and Symbols INFICON
16 / 405 074-708-P16B D-TEK Stratus Operating Manual
Symbol Description
indicates Cloud Hunting mode
indicates Pinpoint mode
indicates Manual Zero mode
sensitivity = Super (only displayed in Pinpoint mode)
sensitivity = High (only displayed in Pinpoint mode)
sensitivity = Medium (only displayed in Pinpoint mode)
sensitivity = Low (only displayed in Pinpoint mode)
English
English

INFICON Cloud Hunting (Portable Monitor) Mode | 9
074-708-P16B D-TEK Stratus Operating Manual 17 / 405
9 Cloud Hunting (Portable Monitor) Mode
ppm reading
max reading
side bar
Cloud Hunting
symbol
Cloud Hunting mode is identified by a large ppm reading on the display and the words
Cloud Hunting on the bottom, along with a cloud symbol. The side bar increases and
decreases with changes in the ppm reading.
There is no sensitivity setting in Cloud Hunting mode.
1.
Slowly move through the suspect areas and observe the ppm reading.
2.
Follow the ppm reading to find areas of higher refrigerant concentration. The
higher the number, the higher the concentration.
3.
Press the SENS/ZERO button to enable and disable the MAX feature. When
enabled, the highest ppm level observed is shown below the main ppm display.
To reset the MAX reading, long-press the SENS/ZERO button or toggle the
feature off and back on again.
D-TEK Stratus uses a patent-pending switching valve in Cloud Hunting mode to
constantly compare the sample from the tip of the probe with the air inside the body of
the leak detector (the reference sample). This technology is what allows D-TEK
Stratus to work without the use of a carbon filter. Lingering for several minutes in an
area with a high concentration of refrigerant may cause the reference sample to
English
English

9 | Cloud Hunting (Portable Monitor) Mode INFICON
18 / 405 074-708-P16B D-TEK Stratus Operating Manual
become contaminated with refrigerant, which causes the ppm reading to settle back
toward zero. If this occurs, move back to an area with clean air (while in Cloud Hunting
mode) for a few minutes to allow the reference sample to become clean again.
English
English

INFICON Pinpoint Mode | 10
074-708-P16B D-TEK Stratus Operating Manual 19 / 405
10 Pinpoint Mode
leak indicator
(showing full
alarm)
sensitivity Pinpoint symbol
Pinpoint mode is identified by a large leak indicator on the display and a Pinpoint
symbol on the bottom bar. The current sensitivity is also indicated on the bottom bar.
This mode works like a standard leak detector with auto-zeroing, where the indicator
bars illuminate to indicate when a leak is detected.
1.
Place the tip of D-TEK Stratus as close as possible to the suspected leak (do
not block the air flow).
2.
Slowly move the probe past each possible leak point.
ðIf a leak is detected, D-TEK Stratus alarms and the on-screen indicator
illuminates.
3.
When a leak is identified, pull the probe away from the leak for a few seconds
and then recheck the spot to verify the leak.
In Pinpoint mode, D-TEK Stratus automatically zeros to the background refrigerant
and only alarms again with a higher concentration of refrigerant. When this occurs,
either continue looking for a higher concentration of refrigerant or move the probe to
an area of lower concentration for a few seconds to reset the zero point.
Press the SENS/ZERO button to switch the sensitivity setting. When working with a
large leak, it can be easier to pinpoint the leak location using a lower sensitivity
setting. The current sensitivity is displayed on the bottom bar.
English
English

11 | Manual Zero Mode INFICON
20 / 405 074-708-P16B D-TEK Stratus Operating Manual
11 Manual Zero Mode
leak indicator
(showing full
alarm)
Manual Zero
symbol
Manual Zero mode looks and operates similar to Pinpoint mode, but is identified by
the text Manual Zero and the Manual Zero symbol on the bottom bar. Manual Zero
mode allows the user to manually zero to the background refrigerant by pressing the
SENS/ZERO button. Once the new zero point is set, D-TEK Stratus will not alarm
unless a higher concentration of refrigerant is detected.
Manual Zero mode beeps faster at the zero point than other modes. If the
concentration is lower than the current zero point, the beeping slows. This allows the
user to know if they are moving away from the leak by listening to a change in the
beep rate.
There is no sensitivity setting in Manual Zero mode.
Manual Zero mode requires an extra warm-up time of up to 15 minutes for optimal
performance.
English
English
