Ingersoll-Rand ARO RM072S Series User manual

OPERATOR’S MANUAL RM072S-XXX-XX
INCLUDING: OPERATION, INSTALLATION AND MAINTENANCE.
INCLUDE MANUALS: S-635 General Information (pn 97999-635).
RELEASED: 12-14-12
REVISED: 10-27-17
(REV: D)
RM072S-XXX-XX
TWO POST LIFT / RAM
For use with 16 gallon / 60 liter drums (tapered or straight)
INGERSOLL RAND COMPANY LTD
209 NORTH MAIN STREET – BRYAN, OHIO 43506
[phone] FAX [phone] © 2017 CCN 46763785
arozone.com
READ THIS MANUAL CAREFULLY BEFORE INSTALLING,
OPERATING OR SERVICING THIS EQUIPMENT.
It is the responsibility of the employer to place this information in the hands of the operator. Keep for future reference.
SERVICE KITS
yUse only genuine ARO® replacement parts to assure compatible
pressure rating and longest service life.
y104217 for repair of P39124-120 lter / regulator.
y104453 for repair of P39344-110 lter / regulator.
y637466 for repair of lift / ram seals.
SPECIFICATIONS
Model Series ............................ RM072S-XXX-XX
Maximum Working Pressure............. 125 psig (8.6 bar)
Maximum Temperature Limits ........... 10º F to 180º F (-12º C to
82º C)
Base Dimensions........................ 19-3/4” x 24” (501.7 mm
x 609.6 mm)
Height (lowered) ........................ 43-37/64” (1106.6 mm)
(raised) ................................. 73-27/64” (1864.8 mm)
Stroke .................................. 29-55/64” (758.2 mm)
Weight ................................. 160 lbs (71.5 kgs)
Noise Level @ 125 psig (continuous duty) 82.4 dB(A)


The pump sound pressure levels published here have been updated to
an Equivalent Continuous Sound Level (LA
eq
) to meet the intent of ANSI
S1.13-1971, CAGI-PNEUROP S5.1 using four microphone locations.
GENERAL DESCRIPTION
The ARO model RM072S-XXX-XX two post lift / ram uses two 3-1/4”
air powered cylinders connected by a steel cross member and
welded to a heavy gauge base plate. It is normally used to raise and
lower a uid handling pump and follower in and out of a standard
16 gallon / 60 liter drum, or when used as a ram, it can force high
viscosity owable material into the pump inlet.
When properly secured (see “General Information - Air Operated
Lifts and Rams”), this unit has the ability to raise a pump to clear a
standard 16 gallon / 60 liter drum. The operator is then able to eas-
ily remove the pump from the drum.
This lift / ram uses a rotary 3-way control valve which controls the
air necessary to raise and lower the lift / ram. This unit includes
an auxiliary manual air valve which is used to supply a controlled
amount of air pressure to the bottom of the follower plate. When
the control valve is in the “up” position, a small amount of air pres-
sure applied under the follower plate will help raise the follower
plate, pump and lift / ram by relieving the vacuum (see page 3).
IMPORTANT
This is one of four documents which support the system. Re-
placement copies of these forms are available upon request.
RM072S-XXX-XX Model Operator’s Manual (pn 97999-1707)
S-635 General Information - Air Operated Lifts and Rams (pn
97999-635)
P391XX-XXX Piggyback Filter / Regulator Operator's Manual (pn
100400-59)
P393XX-XXX Piggyback Filter / Regulator Operator's Manual (pn
100400-69
RM072S-XXX-XX Two Post Lift / Ram
Figure 1

Page 2 of 12 RM072S-XXX-XX (en)
MODEL DESCRIPTION CHART
RM 07 2 S - X X X - X X
07 - 16 gallon
2 - Two post
S - Standard duty
B - Basic
C - Advanced controls
Blank - No Follower
Blank - No Follower
Blank - No Follower
Ram Type
Container Size
Ram Style
Ram Control Style
Pump Mounting Option
Ram Follower Style
Follower Plate Material
A - 16 gallon Container, 4.500 tie rod
B - 16 gallon Container, 14.257 tie rod
C - 16 gallon Container, 15.757 tie rod
D - 16 gallon Container, 18.507 tie rod
E - 16 gallon Container, 8.007 tie rod
A - Standard Footprint
C - Slip-On
D - Pipe Thread
A - Aluminium
E - Carbon Steel, Electroless Nickel Coating
C - Stainless Steel
D - Aluminium with PTFE Coating
Follower Seal Type and Material
Blank - No Follower
1 - Single-Lip, Nitrile (11.614") / Polyethylene
2 - Single-Lip, PTFE Coated Nitrile (11.437") / Polyethylene
3 - Single-Lip, Polyurethane (11.437") / Polyethylene
4 - Single-Lip, Polyurethane (14.500") / Polyethylene
5- Single-Lip, Nitrile (12.281") / Polyethylene
7 - Single Tube, EPR
8 - Single Tube, Nitrile
A - Double-Lip, Polyurethane
B - Double-Lip, EPR
C - Double-Lip, Nitrile

RM072S-XXX-XX (en) Page 3 of 12
OPERATING AND SAFETY PRECAUTIONS
WARNING
= Hazards or unsafe practices which could
result in severe personal injury, death or
substantial property damage.
CAUTION
= Hazards or unsafe practices which could
result in minor personal injury, product or
property damage.
NOTICE
= Important installation, operation or mainte-
nance information.
yRead and heed all warnings, cautions and safety precau-
tions before operating.
WARNING
READ THE GENERAL INFORMATION MANUAL IN-
CLUDED FOR OPERATING AND SAFETY PRECAUTIONS AND
OTHER IMPORTANT INFORMATION.
WARNING
Store and operate the lift on a level surface.
WARNING
ANCHOR THE LIFT BASE OF STATIONARY UNITS
SECURELY TO A CONCRETE FLOOR. An improperly secured
lift could be unsafe. Do not attempt to use the lift until all
possible measures have been taken to insure that the lift
has been properly installed and the base has been secured.
It is the duty of the installer to provide anchor bolts / studs
(not included) and for them to be securely embedded in
concrete which is more than 2” (50.8 mm) thick.
Shock hazard.
Striking electrical
xtures can cause
injury.
Keep the area
overhead clear of
electrical devices.
WARNING
PREVENT ELECTRICAL SHOCK. Be certain the area
above the lift is clear of electrical xtures, devices and wir-
ing. Examine the working area and take necessary action to
assure adequate clearance for the lift and pump assembly
to raise to the fullest limit and function properly.
Pinch hazard.
Follower can
descend quickly,
causing injury.
Keep hands clear
when aligning with
container.
WARNING
PINCH HAZARD. Follower can descend quickly,
causing injury. Keep hands clear when aligning with con-
tainer. In the raising and lowering function, the lift could
get hung up or the descent could be temporarily restricted.
The lift could, in some situations, drop suddenly and be
hazardous. If the follower plate does not enter the drum
properly, DO NOT ATTEMPT TO RE-POSITION IT WITH YOUR
HANDS. Release the downward pressure, raise the lift, re-
align the drum and restart.
WARNING
STAND CLEAR. When raising or lowering the lift,
keep clear and operate from a safe position.
Hazardous pressure.
Can result in injury or
property damage.
Do not exceed
maximum inlet air
pressure.
WARNING
HAZARDOUS PRESSURE. Do not exceed maxi-
mum inlet air pressure of 125 psig (8.6 bar). Operating lift
at higher pressure may cause lift damage and / or personal
injury and / or property damage. Do not service or clean
pump, hoses or dispensing valve while the system is pres-
surized.
WARNING
DO NOT EXCEED DRUM PRESSURE LIMITS. Know
the pressure limitations of the drum and regulate the air
pressure within safe limits when supplying air to the fol-
lower plate.
WARNING
Place the main valve in the “neutral” (center) posi-
tion before air pressure is directly connected or turned on
to the system.
WARNING
Depressurize the lift / ram before performing
maintenance by disconnecting the main air line and rotat-
ing the main valve to relieve pressure. Replacement warn-
ing label (“Depressurize” / pn 97165) is available upon
request.
CAUTION
Be certain all operators of this equipment have
been trained for safe working practices, understand it’s
limitations and wear their safety goggles / equipment as
required.
NOTICE
To extend seal life, lubricate seals with Gadus® S2
U1000 grease upon reassembly.
NOTICE
To prevent premature failure of the piston rod
and / or seals, it is good practice to keep the piston rod
clean and free of debris and any other type of contamina-
tion.
LIFT / RAM INSTALLATION
WARNING
Failure to properly install the lift assembly can re-
sult in severe injury and property damage. Read the warn-
ings above.
1. This lift /ram assembly comes completely assembled.
2. Establish the desired location for the lift / ram and pay special
attention to the work area above. This area above the lift must
be open, without obstructions and safely away from any electri-
cal devices.
3. THE LIFT MOUNTING BASE PLATE MUST BE SECURELY AN-
CHORED TO THE CONCRETE FLOOR. The mounting plate itself
can be used as a template for establishing the proper anchor
locations.
4. Assemble the pump to the mounting plate. NOTE: The com-
bined weight of the piston pump and accessories (follower
plate, etc.) must not exceed 250 lbs (113.4 kg).
5. Install the pump air hose and follower plate air hose from the
control valve.
6. Assemble the vent plug to the follower plate.
NOTE: When assembling air line to the lift / ram air inlet, hold the
air inlet port with a wrench to eliminate possible damage to lter -
regulator connections.
NOTE: The ram was tested at the factory. The unit should be gener-
ally checked over for leakage, because the fittings on the system
may have loosened in shipment.
NOTE: Re-torque all fasteners before operation.
NOTE: If material leakage occurs around the follower plate, check
the lift / ram air pressure and check all ttings and fasteners to be
sure they are secure.

Page 4 of 12 RM072S-XXX-XX (en)
yARO® is a registered trademark of Ingersoll-Rand Company yGadus® is a registered trademark of the Shell Oil Company y
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS / INITIAL SETUP PROCEDURE.
WARNING
STAND CLEAR WHEN RAISING OR LOWERING THE
LIFT. Read the warnings on page 2.
97102 Label
D B C A E D AB C F H G E
LIFT / RAM, PUMP AND FOLLOWER PLATE AIR CONTROLS
Models RM072S-BXX-X
XM
odels RM072S-CXX-XX
OFF ON
Follower plate air supply valve
A - Air inlet
(RM072S-BXX-XX - 1/4 - 18 NPT)
(RM072S
-CXX-XX - 1/2 - 14 NPT)
B - Lif
t / ram pressure gauge
C - Lif
t / ram air lter / regulator
D - Follower plate air supply valve
E - Lift / ram control lever
F - Pump air lter / regulator
G - Pump air supply valve
H - Pump pressure gauge
Fugure 2
TO RAISE LIFT, (THE FIRST TIME):
1. Take note of the pump / drum clearance above. Be certain the
lift / ram is clear of any objects above. Also, refer to “Operating
and Safety Precautions”, found on page 2.
2. Connect the air supply (125 psig / 8.6 bar maximum) to the air
inlet. Adjust the air pressure on the lift / ram pressure regulator
(turn knob clockwise) to 20 psig (1.4 bar).
3. Shift the control valve lever to the“up”position.
4. Raise the lift / ram high enough to clear the height of the drum.
Stop the lift upward travel by moving the control valve lever to
the “neutral” (center) position.
5. Once the lift / ram assembly and pump are in the “up” position,
place and center an opened drum of material on the lift / ram
base.
6. Lubricate the lower follower wiper plate seal with grease. NOTE:
Make certain the grease is compatible with the material being
dispensed. This ensures a smooth t into the drum, as well as
prevents curing type compounds from bonding to the seal.
7. Check the vent plug on the follower plate to be sure it easily
threads in and out. It is recommended to lubricate the threads
of the plug to help prevent possible set up of the compound at
this point.
TO LOWER LIFT:
WARNING
PINCH HAZARD. Follower can descend quickly,
causing injury. Keep hands clear when aligning with con-
tainer. Read the warnings on page 2.
NOTE: Be certain the follower plate vent plug has been removed
so that the air trapped between the follower and the material is al-
lowed to escape from this vent.
NOTE: The lift / ram may hesitate momentarily before starting
downward. The air pressure inside the post air chamber must de-
crease before it will begin to descend.
1. Shift the control valve lever to the “down” position and proceed
to lower the pump.
2. Replace the vent plug once the material begins to ooze from
the vent opening.
3. Models RM072S-CXX-XX: The unit is now ready for operation.
Open the pump air supply valve. Adjust the air pressure on the
pump filter / regulator (turn the pump regulator knob clock-
wise) until the pump begins to cycle.
4. Trigger the gun to prime the pump with material.
TO RAISE LIFT, (NORMAL OPERATION):
1. Models RM072S-CXX-XX: Close the pump air supply valve.
2. Shift the control valve lever to the“up”position.
3. Raise the lift / ram high enough to clear the height of the drum.
Stop the lift upward travel by moving the control valve lever to
the “neutral” (center) position.
TO CHANGE DRUM:
NOTE: The control valve lever should be in the “neutral” position
and the pump air supply valve should be closed.
1. To avoid damage, DO NOT OVER-PRESSURIZE THE DRUM.
2. Open the follower plate air supply valve to allow air under the
follower plate.
3. Shift the control valve lever to the“up”position.
4. Place and center a new drum into position. Remove cover.

RM072S-XXX-XX (en) Page 5 of 12
PARTS LIST / RM072S-XXX-XX
Item Description (size) Qty Part No.
1Nut (M24 x 3 - 6h) (4) 96693
2Lock Washer (24.5 mm i.d. x 40 mm o.d.) (4) 94036746
3 Washer (25 mm i.d. x 44 mm o.d.) (2) 96705611

4 “O” Ring (3/16” x 3-1/4” o.d.) (4) Y325-336
5Piston (2) 96677

6 “O” Ring (1/8” x 1-1/4” o.d.) (2) Y325-214
7Stop (2) 96233
8 Piston Rod (2) 97009
9 Base and Cylinder Assembly (1) 97011
10 Tubing (5/16” o.d. x 36”) (1) 94980-(

)
11 Tee (1/4 - 18 NPT x 5/16” o.d. tube) (2) 59757-158
12 Pipe Tee (1/4 - 18 NPT) (1) Y43-32-C
13 Bracket Assembly (1) 97088
14 Rotary Lever Valve (1) M512LR
15 Male Elbow (1/4 - 18 NPT x 5/16” o.d. tube) (5) 59756-158
16 Tubing (5/16” o.d. x 6-3/4”) (1) 94980-(

)
17 Nipple (1/4 - 18 NPT x 1-1/2”) (1) Y27-52-C
18 Mounting Assembly (1) 96733
19 Tubing (5/16” o.d. x 45”) (1) 94980-(

)
20 Tubing (5/16” o.d. x 61”) (1) 94980-(

)
21 Clamp Spacer Kit (models RM072S-B only) (2) 104394
22 Pipe Adapter Kit (1) 104474-2
23 Cap (2) 96704

24 Wear Ring (1-1/4” i.d. x 1-3/8” o.d.) (2) 96755

25 “U” Cup (5/32” x 1-9/16” o.d.) (2) 96754
26 Tubing (5/16” o.d. x 30”) (1) 94980-(

)
29 Nipple (1/4 - 18 NPT x 2-1/2”) (models RM072S-B
only) (1) Y44-12-C
30 Shut-O Valve (1/4 - 18 NPT) (1) Y28-1
31 Cap Screw (M6 x 1 - 6g x 40 mm) (2) 96719
32 Button Head Screw (M10 x 1.5 - 6g x 18 mm) (9) 96696
33 Gauge (0 - 160 g / 0 - 11 bar) (1) 29850
34 Piggyback Filter / Regulator (1/4 - 18 NPT)(1) P39124-120
Item Description (size) Qty Part No.
35 Decal (warning)(not shown) (1) 93922
36 Muer (1/4 - 18 NPT) (1) 20313-2
Items listed below used on models RM072S-CXX-XX only
40 Male Elbow (1/4 - 18 NPT x 1/2” o.d. tube) (1) 59756-162
41 Tubing (1/2” o.d. x 33”) (1) 94978-(

)
42 Male Elbow (1/4 - 18 NPT x 5/16” o.d. tube) (2) 59756-158
43 Piggyback Filter / Regulator (1/2 - 14 NPT) (1) P39344-110
44 Self-Storing Hose (1/2” i.d. x 9’) (1) 628023-12
45 Washer (6.4 mm i.d. x 12 mm o.d.) (4) 97115
46 Street Elbow (1/2 - 14 NPT) (1) Y43-4-C
47 Manifold Block (1/2 - 14 NPT) (1) 104413-4-2
48 Pipe Plug (1/4 - 18 NPT x 13/32”) (3) Y227-3-L
49 Cap Screw (M6 x 1 - 6g x 16 mm) (4) 97105
50 Gauge (0 - 160 psig / 0 - 11 bar) (1) 29850
51 Lock-Out Valve (1/2 - 14 NPT) (1) 104392-4
52 Nipple (1/4 - 18 NPT x 7/8”) (1) Y27-12-C
53 Tubing (5/16” o.d. x 11”) (1) 94980-(

)
54 T - Type Wall Mount (2) 104401
55 Button Head Screw (M10 x 1.5 - 6g x 18 mm) (1) 96696
56 Bulkhead Bracket (1) 97093
57 Bulkhead Connector (1/2 - 14 NPT x 1/2” o.d.
tube) (1) 96713
58 Reducing Bushing (3/4 - 14 NPT male x 1/2 -
14 NPT female) (1) Y45-9-C
59 Male Elbow (1/2 - 14 NPT x 1/2” o.d. tube)(not
shown) (1) 59756-362

Bulk Tubing (5/16” o.d. x 100’) (1) 94980-100

Bulk Tubing (1/2” o.d. x 100’) (1) 94978-100

Gadus S2 U1000 grease packet (1) 94833

Items included in service kit (1) 637466
DISASSEMBLY
1. Raise the pump, follower and ram out of the drum.
2. Disconnect the air supply and depressurize the ram by rotating
the (14) valve into the“up” and “down”positions.
3. Models RM072S-CXX-X: Disconnect (44) hose from (51) lock-out
valve and (41) hose from (40) male elbow.
4. Disconnect (26) tubing from follower and remove pump from
ram.
5. Unthread (1) nut and remove (2) washer.
6. Remove (18) mounting assembly and components.
7. Disconnect (10, 16, 19 and 20) tubing.
8. Remove (32) screws, releasing (13) bracket assembly and ram
air control components.
9. Remove (23) cap from (9) base and cylinder assembly and (8)
piston rod.
10. Remove (8) piston rod and components from (9) base and cylin-
der assembly.
11. Remove (1) nut, releasing (2 and 3) washers, (5) piston and (7)
stop.
REASSEMBLY
1. Grease and assemble (4 and 6) “O” rings to (5) piston.
2. Assemble (7) stop, (5) piston and (3) washer to (8) piston rod,
securing with (2) lock washer and (1) nut. NOTE: Tighten (1) nut
to 75 ft lbs (101.7 Nm).
3. Carefully slide piston rod and components into (9) base and
cylinder assembly.
4. Grease and assemble (4)“O” ring, (25)“U” cup (note the lip direc-
tion) and (24) wear strip to (23) cap.
5. Assemble (23) cap over the end of (8) piston rod and into (9)
base and cylinder assembly, being careful not to damage (25)“U”
cup.
6. Place (13) bracket assembly and ram air control components
into place and secure with (32) screws. NOTE: Tighten (32)
screws to 20 ft lbs (27.1 Nm)
7. Assemble (18) mounting assembly to (8) piston rods.
8. Assemble (2) lock washer and (1) nut. NOTE: Tighten (1) nut to
75 ft lbs (101.7 Nm).
9. Reconnect all tubing.

Page 6 of 12 RM072S-XXX-XX (en)
PARTS LIST / RM072S-XXX-XX
View A
View B

NOTE: DO NOT OVERTIGHTEN FASTENERS.
(1) nut, 75 ft lbs (101.7 Nm).

Lubricate all “O” rings, “U” cups and mating parts with
Gadus S2 U1000 grease.
4 
25 
24 
4 
3
6 
5
2
1

1 
2
18
8
23
7
9
see view B
see view A
ASSEMBLY TORQUE REQUIREMENTS
LUBRICATION / SEALANTS
Figure 3

RM072S-XXX-XX (en) Page 7 of 12
PARTS LIST / RM072S-XXX-XX
(21) screw, 4 in. lbs (0.45 Nm).
(31) cap screw, 95 - 100 in. lbs (10.7 - 11.3 Nm).
(32) button head screw, 20 ft lbs (27.1 Nm).
(49) cap screw, 95 - 100 in. lbs (10.7 - 11.3 Nm).
(54) screw, 17 in. lbs (1.9 Nm).
(55) button head screw, 20 ft lbs (27.1 Nm).
ASSEMBLY TORQUE REQUIREMENTS 
NOTE: DO NOT OVERTIGHTEN FASTENERS. LUBRICATION / SEALANTS
Apply anaerobic pipe sealant to male pipe threads at assembly
.
29
21
22
49
11
31
17
11
46 
45
42
53
Figure 4

Page 8 of 12 RM072S-XXX-XX (en)
PARTS LIST / RM072S-XXX-XX
40
58
16
36
14
47
48
52
33
13 50 54 51 32 
57 55 
43
34

42
12

30
15

26
10
15
44
32 
19
20
15 
41
Figure 5

RM072S-XXX-XX (en) Page 9 of 12
MODEL DESCRIPTION / FOLLOWER PLATE OPTIONS
Model Description Follower Plate
Material Seal Type Seal Material Seal Diameter Follower Asm.
RM072S-XXA-A7
Standard
Footprint
“A”
Aluminum
Single Tube
EPR
11.440” (290.6 mm)
67347-2
RM072S-XXA-A8 Nitrile 67347-1
RM072S-XXA-T7 Aluminum with
PTFE Coating
EPR 67347-12
RM072S-XXA-T8 Nitrile 67347-11
RM072S-XXA-E1
Carbon Steel,
Electrloess Nickel
Coating
Single Lip
Nitrile / Polyethylene 11.614” (295.0 mm) 67485-2
RM072S-XXA-E3 Polyurethane/Polyethylene 11.437” (290.5 mm) 67485-1
RM072S-XXA-E5 Nitrile/Polyethylene 12.281” (311.9 mm) 67485-3
RM072S-XXA-E4 Polyurethane/Polyethylene 14.500” (368.3 mm) 67485-4
RM072S-XXA-EA
Double Lip
Polyurethane
11.609” (294.9 mm)
66732-1
RM072S-XXA-EB EPR 66732-2
RM072S-XXA-EC Nitrile 66732
RM072S-XXC-E1
Slip-On
“C”
Carbon Steel,
Electroless Nickel
Coating
Single Lip
Nitrile/Polyethylene 11.614” (295.0 mm) 67486-2
RM072S-XXC-E3 Polyurethane/Polyethylene 11.437” (290.5 mm) 67486-1
RM072S-XXC-E5 Nitrile/Polyethylene 12.281” (311.9 mm) 67486-3
RM072S-XXC-E4 Polyurethane/Polyethylene 14.500” (368.3 mm) 67486-4
RM072S-XXC-EA
Double Lip
Polyurethane
11.609” (294.9 mm)
66731-1
RM072S-XXC-EB EPR 66731-2
RM072S-XXC-EC Nitrile 66731
RM072S-XXC-S2 Stainless Steel Single Lip PTFE Coated Nitrile / Polyethylene 11.437” (290.5 mm) 67487-1
RM072S-XXD-S2 Pipe Thread “D” PTFE Coated Nitrile / Polyethylene 67518-1
(BOLTED CONNECTION)
"A" FOOTPRINT
(SLIP FIT CONNECTION)
"C" FOOTPRINT
(2" - 11 1/2 NPTF-1
CONNECTION)
"D" FOOTPRINT
PN 67134 (316 SST)
Adapts "A" follower to "C" pump
PN 67136 (316 SST)
Adapts "A" follower to "D" pump
Ø 11.437
(290.5 mm)
Ø 11.614
(295.0 mm)
Ø 12.281
(311.9 mm)
Ø 11.609
(294.9 mm)
Ø 11.440
67485-1 67485-2 67485-3 67485-4 66732-X
67486-1 (CS)
67518-1
67487-1 (SST)
67486-2 67486-3 66731-X
67347-X
(290.6 mm)
Ø 11.437
(290.5 mm)
Ø 11.614
(295.0 mm)
Ø 12.281
(311.9 mm)
Ø 11.609
(294.9 mm)
Ø 11.437
(290.5 mm)
Ø 14.500
(368.3 mm)
67486-4
Ø 14.500
(368.3 mm)
FOLLOWER PLATES
Figure 6

Page 10 of 12 RM072S-XXX-XX (en)
Ø 10.302
Ø 10.901
(277 mm)
Ø 9.511
(262 mm)
(242 mm)
Ø 10.901
(277 mm)
Ø 9.511
Ø 10.302
(262 mm)
(242 mm)
OPTIONS
CONFIGURATION
Available on the following models: 67485-X, 67486-X, 67487-X, 67518-X.
Ideal for tapered pails
Ideal for various
straight sided pails
Ideal for various
straight sided pails
Ideal for 16G drum
67485-4 & 67486-4 only
Ø 12.250
(311 mm)
Ø 12.250
(311 mm)
MODULAR BACKUP RING
Figure 7

RM072S-XXX-XX (en) Page 11 of 12
DIMENSIONAL DATA
22.000”
24.000”
1.000”
28.223”
24.884”
(for RM072S-C only)
16.750”
∅0.562”
4 PLA
CES
1.500”
19.750”
16.375”
43.568”
29.85”
TRAVEL
Figure 8

Page 12 of 12 RM072S-XXX-XX (en)
PN 97999-1707
NOTES
