INIM Electronics SmartLight User manual

SmartLight
Analogue Fire Alarm Control Panel
Extinguishant System Control Panel
User’s Manual
GameOver

User Manual
2Description of the Control panel
Chapter 1
Description of the Control panel
1.1 Manufacturer's name and address
INIM Electronics s.r.l.
Via Ischia Prima, 34
63013 Grottammare (AP) - Italy
Tel: [phone]
Fax: [phone]
[email protected] - www.inim.biz
1.2 Device identification details
Denomination: Fire Alarm Control Panel
Model: SmartLight
Year of Manufacture: from 2007
1.3 In-box documentation
• User Manual (this manual)
• Installation and Programming Manual
1.4 Manual details
Title: SmartLight User Manual
• Edition, Issue: 1.0.0
• Month and Year of printing: February 2007
• User Manual Code: DCMUINE0SLIGHT
1.5 Control panel user interface
Figure 1 - Control panel frontplate
DISABLE
EXTINGUISH
DISABLE
AUTO
DISABLE
MANUAL
EXTINGUISH
PRE-EXTINGUISH
FAULT
STOP EXTINGUISH
CPU FAULT
PRE-ALARM
ALARM
FAULT
CPU FAULT
ON
DISABLED
NIGHT MODE
TEST
DISABLE/FAULT
DIALLER
DISABLE/FAULT
BELLS
SILENCED
SILENCE
INHIBITED
RESET
EVACUATE
INVESTIGATE
LEV.2
LEV.1
DIALLER ON
Esc Ok
E1
B
A
G
A1
HD
I
N
M
L
K
J
E
C
O
P
Q
R
SV
T
U
Z
F
Y
X
B1
D1
C1

User Manual
Description of the Control panel 3
1.5.1 Commands
Note: For further details refer to the Installation Manual, paragraph 5.1 SmartLight panel frontplate.
1.5.2 Signaling
Name Access lev.1--public Access lev.2--security personnel
[A] 4 scroll keys
UP/DOWN/
OK/ESC
[B] SILENCE Push this button to silence
(turn OFF) the panel beeper. This button silences (turns OFF) active outputs with the silenceable attribute. The silenceable outputs will hold
silenced status until a new event occurs that will release
the outputs automatically. The SILENCE button operates
as a toggle switch, therefore, silenced outputs can be
unsilenced by pushing the button again.
[C]
RESET
Button
Push this button to clear any active events, delete the
memory and restore standby conditions.
[D]
EVACUATION
Button
If this button is pressed during
active pre-alarm conditions,
the system will override the
programmed pre-alarm time
and generate an instant alarm.
If this button is pressed when pre-alarm conditions are
not active, the system will generate a panel alarm.
[E]
INVESTIGATE
Button
If this button is pressed during active pre-alarm
conditions, the system will add the preset investigation
time to the running pre-alarm time (this operation can be
done once only).
Optional Extinguishant module commands
[F]
BYPASS
EXTINGUISH
Button
If this button is pressed once, the system will disable
Extinguish commands. If this button is pressed again,
the system will re-enable Extinguish commands.
[G]
AUTOMATIC
BYPASS
Button
If you push this button once, the system will disable
automatic extinguish commands generated by the
Extinguishant module. If you push this button again, the
system will re-enable automatic extinguish commands
generated by the Extinguishant module.
[H]
MANUAL
BYPASS
Button
If you push this button once, the system will disable
manual extinguish commands. If you push this button
again, the system will re-enable manual extinguish
commands.
Description ON Solid: ON Blinking:
[I] LCD
[J] SILENCE
LED (yellow) Indicates that the system has been silenced.
[K] INHIBIT
RESET LED
(yellow)
In the event of pre-alarm/alarm, indicates that
reset commands are not allowed. Reset will be
allowed when all outputs have been silenced and
this LED goes Off.

User Manual
4Description of the Control panel
[L] ALARM
LED (red) Indicates an alarm condition, that is, an input
point (detector, callpoint, input module, etc.) set
to generate alarms has detected alarm
conditions.
[M] PRE-
ALARM LED
(red)
Indicates a pre-alarm condition, that is, an input
point (detector, callpoint, input module, etc.) set
with a pre-alarm time has activated.
[N] FAULT
LED (yellow) Indicates an active system fault condition. The
display will provide the fault details. Indicates a restored fault condition in memory. To view the restored fault
condition details, consult the events log
using the Main menu (Level 1--public).
[O] CPU
FAULT LED
(yellow)
Indicates trouble with the panel CPU—the panel
must be sent back immediately to the
manufacturer for repair.
Indicates that the CPU has re-initialized
(due to control panel shutdown or fault
condition).
[P] BYPASS
(LED (yellow) Indicates that one (or more) of the system
components (loop point, zone or output) has been
bypassed.
[Q] TEST LED
(yellow) Indicates that one or more components (points or
zones) are undergoing testing.
[R] ON LED
(green) Indicates that the system is operating.
[S] DIALLER
ON LED (red) Indicates that the dialler activation output is
active.
[T]
DISABLE/
FAULT
DIALLERLED
(yellow)
Indicates that the dialler activation output is
disabled or faulty—the display will provide the
respective details.
Indicates restoral of a fault event. This
event can be cleared by RESET only
(Level 2--security personnel).
[U]
DISABLE/
FAULT
BELLS LED
(yellow)
Indicates that the sounder/flasher activation
output is disabled or faulty—the display will
provide the respective details.
Indicates restoral of a fault event. This
condition can be cleared by reset only
(level 2--security personnel).
[V] NIGHT
MODE
(yellow)
Indicates that the panel is operating in night
mode.
Extinguishant module signals (optional system enhancement tool)
[X] LED
BYPASS
EXTINGUISH
Indicates disablement of all types of extinguish
commands, via key [F] (refer to the previous
table 1.5.1 Commands)
[Y] LED
AUTOMATIC
BYPASS
Indicates disablement of automatic extinguish
commands, via key [G] (refer to the previous
table 1.5.1 Commands)
[Z] LED
MANUAL
BYPASS
Indicates disablement of manual extinguish
commands, via key [H] (refer to the previous
table 1.5.1 Commands)
[A1] LED
EXTINGUISH Indicates that the fire-extinguishing process is
running.
[B1] LED
PRE-
EXTINGUISH
Indicates activation of the pre-extinguish output.
Description ON Solid: ON Blinking:

User Manual
Description of the Control panel 5
1.6 Repeater
This control panel supports up to four Repeater panels. Connected Repeater panels replicate all the
information provided by the control panel and allow access to all Level 1 and 2 functions (View active
events, Reset, Silence, etc.), but DO NOT allow access to the Main menu.
Figure 2 - Front view of the Repeater panel
The SmartLetUSee/LCD Repeater is supported by most control panel models. However, if it is
connected to a SmartLight panel, not all the buttons are operational. The following keys/buttons are
operational:
Repeaters provide the following signals.
1.6.1 LCD
The display provides same event data as the panel. For further details refer to Signaling on the display
on page 9.
[C1] LED
FAULT Indicates trouble with the fire-extinction circuits. Indicates restoral of a fault event.
[D1] LED
STOP
EXTINCTION
Indicates that the fire-extinction process has
been interrupted by means of a remote Hold-off
unit.
Indicates restoral of a Stop extinction
event.
[E1] LED
CPU FAULT Indicates a CPU fault that requires immediate
repair. Indicates restoral of a fault event.
[A] UP/DOWN Scroll keys which allow navigation through menus, etc.
[B] EVACUATION As above Figure 1 - Control panel frontplate
[C] SILENCE As above Figure 1 - Control panel frontplate
[D] RESET As above Figure 1 - Control panel frontplate
[E] INVESTIGATE As above Figure 1 - Control panel frontplate
[F] BUZZER Turns the panel beeper Off
[G] TEST Turns On all the LEDs to verify functionality.
Description ON Solid: ON Blinking:
RESET
EVACUATE
SILENCE
INVESTIGATE
BUZZERTEST
ALARM
PRE-ALARM
TEST
DISABLED
NIGHT MODE
ON
FAULT
CPU FAULT
EARTH
BATTERY
FUSE
MAINS
ACTIVE
FAULT
DISABLED
ACTIVE
FAULT
DISABLED
FAULTS BELLSSTATUS DIALLER
LEV.1
LEV.2
Esc
2
abc
5
jkl
8
tuv
0
.,
3
def
6
mno
9
wxyz
1
4
ghi
7
pqrs
B
A
GHD
I
N
M
L
K
JEC
O
P
Q
R
S
V
T
U
F
Y
X
WZ
Z1

User Manual
6Description of the Control panel
1.6.2 LEDs
Denomination ON Solid: ON Blinking:
[H] SILENCE As above Figure 1 - Control panel frontplate
[I] RESET
DISABLED As above Figure 1 - Control panel frontplate
[J]
INVESTIGATE As above Figure 1 - Control panel frontplate
[K] ALARM As above Figure 1 - Control panel frontplate
[L] PRE-ALARM As above Figure 1 - Control panel frontplate
[M] FAULT As above Figure 1 - Control panel frontplate
[N] CPU FAULT Indicates that the Repeater CPU is faulty—
it must be sent back to the manufacturer for
immediate repair.
Indicates that the control panel
CPU has been reset.
[O] BYPASS As above Figure 1 - Control panel frontplate
[P] TEST As above Figure 1 - Control panel frontplate
[Q] NIGHT As above Figure 1 - Control panel frontplate
[R] BATTERY Indicates that the panel batteries are low or
inefficient. Indicates restoral of the low/ inefficient battery event.
[S] EARTH Indicates voltage dispersion to earth. Indicates restoral of the voltage
dispersion to earth event.
[T] FUSE Indicates protection fuse intervention due to short-
circuit on the “AUX” output. Indicates restoral of the short- circuit on “AUX” output event.
[U] MAINS Indicates Mains failure. Indicates restoral of the Mains
failure event.
[V] BELLS -
ACTIVE Indicates that the “ALARM NAC” output is active.
[W] BELLS -
FAULT Indicates an “ALARM NAC” output fault.
[X] BELLS -
BYPASSED Indicates that the “ALARM NAC” output has been
disabled.
[Y] DIALLER -
ACTIVE Indicates that the “Dialler” output is active.
[Z] DIALLER -
FAULT Indicates “Dialler” output fault. Indicates restoral of a “Dialler”
output fault event.
[Z1] DIALLER -
BYPASSED Indicates that the “Dialler” output has been
disabled.

User Manual
Using the Control Panel 7
Chapter 2
Using the Control Panel
2.1 For authorized persons
Attention: Insert and turn the key. The panel will enable access level 2. The panel will hold level 2
status for 20 seconds without receiving a command (no key/button pressed).
2.2 Danger signaling
In the event of fire hazard, always follow the fire department approved fire drill.
2.2.1 For building occupants
2.2.2 For authorized persons
1. To force the panel into alarm status, regardless of its status, press EVACUATE.
Alarm LED On Evacuate the building immediately.
Pre-alarm LED
On In the event of real danger, press the EVACUATE button to broadcast the alarm and evacuate the building immediately. Or, if you consider evacuation to be an unnecessary
measure, inform the person/s in charge of the safety of the building (security personnel)
immediately. To silence the beeper, press SILENCE.
Alarm/Pre-
alarm/Reset
LED On
At least one zone is in alarm/pre-alarm status:
1. If there is no intervention during a pre-alarm, the panel will generate an
alarm when the pre-set pre-alarm time expires.
1. To request INVESTIGATION time, press INVESTIGATE and check the
building. INVESTIGATION time cannot be refreshed.
1. In the event of a false alarm, press SILENCE. The panel beeper and the
silenceable outputs will be silenced until a new event occurs. If the panel is
operating in Night mode, the panel beeper and the silenceable outputs will
be unsilenced automatically after the pre-set time, and the panel will
generate pre-alarm status.
1. If you wish to re-activate pre-alarm/alarm status after pressing the SILENCE
button, press the SILENCE button again: pre-alarm/alarm signaling and the
outputs will re-activate.
1. To clear all alarm/fault signaling and the memory, press RESET. If the
conditions persist, the panel will generate another alarm.
SILENCE LED On Indicates that the control panel has been silenced but has not yet been reset.
RESET LED On The control panel is in alarm or pre-alarm status, you must press SILENCE before
pressing RESET.

User Manual
8Using the Control Panel
2.3 Fault signaling
2.3.1 For all building occupants
2.3.2 For authorized personnel
You must always ensure that faults are dealt with and cleared as soon as possible. However, in the
meantime, you can bypass the zone/point/output concerned.
2.4 Informative signaling
Signaling that does not require specific action.
Viewing Events
The events represent the various conditions signaled by the panel and have the following order of
importance: alarm, pre-alarm, fault, early warning, bypass, test and monitor. The system displays
information regarding real-time events of major importance and disregards those of minor importance
(e.g.: if the system is dealing with three fault events when a pre-alarm event occurs, the fault events
will be disregarded and cleared from the display and the pre-alarm will take priority). All events are
saved to the log and can be viewed.
FAULT LED Inform security personnel immediately.
FAULT LED On Indicates at least one system fault condition. View the fault details on the display
and ensure that it is dealt with and cleared.
LED ON Off Indicates no mains or battery power supply. The system is not working, ensure that
power is restored as soon as possible.
CPU LED On The control panel is not operating properly and must be sent back to the
manufacturer for repair.
DISABLE/FAULT
DIALLER LED On The dialler output is disabled or faulty. View the details on the display. Press RESET to turn Off the LED.
DISABLE/FAULT
BELLS LED On The Alarm NAC is disabled or faulty. View the log details on the display. Press RESET to turn Off the LED.
NIGHT MODE
LED ON The control panel is operating in Night mode. WARNING: The panel may have been programmed to generate instant alarms. During Night mode,
SILENCE will be held for the pre-set silence time only.
FAULT LED Blinking Restoral of a system fault. View the log details on the display. Press
RESET to turn Off the LED.
DISABLE/
FAULT BELLS
LED
Blinking The “Alarm NAC” output has signaled a fault and has restored. View the
log details on the display. Press RESET to turn Off the LED
DISABLE/
FAULT
DIALLER LED
Blinking The Dialler output has signaled a fault and has restored. View the log
details on the display. Press RESET to turn Off the LED
CPU LED Blinking The CPU has reset (due to control panel shutdown or jamming). Check
the efficiency of the entire system. Press RESET to turn Off the LED.
BYPASS LED ON A zone, point or output has been bypassed. View the details on the
display.
TEST LED ON A zone or point is undergoing tests. View the details on the display.
Dialler LED ON The control panel has activated the dialler in response to an alarm
condition.
DIALLER ON
LED ON CONTROL PANEL ON.

User Manual
Using the Control Panel 9
2.5 Signaling on the display
If several events of the same type occur, only the first will be shown on the display. If several alarms
occur, the first alarm will remain on the first line of the display and the most recent alarm will be
shown on the line below.
Use the <UP> and <DOWN> keys to scroll the events on the display.
2.5.1 Alarm signaling
Example of first alarm: a detector belonging to zone 02 goes into alarm status.
1st line: number of the first zone to go into alarm status
2nd line: description of the first zone in alarm status
3rd line: -
4th line: total numbers of alarm events and total number of
zones in alarm status.
Example of a successive alarm event: a detector belonging to zone 29 goes into
alarm status.
The total number of alarm events and zones involved will increase, however, the display will still show
the details of the first alarm.
1st line: unchanged
2nd line: unchanged
3rd line: number of the zone in alarm status
4th line: total number of alarm events and total number of zones
in alarm status
Example of several alarm events on the same zone: another detector belonging to
zone 29 goes into alarm status.
1st line: unchanged
2nd line: unchanged
3rd line: number of the zone in alarm status
4th line: total number of alarm events and total number of zones
in alarm status
To view the alarm event details:
Press the <UP> or <DOWN> key: the details of the most recent alarm (in this case zone 29) will be
shown.
1st line: number of the zone in alarm status
2nd line: description of the zone in alarm status
3rd line: description of the point in alarm status
4th line: number of the last zone and total zones in alarm status
If no key is pressed within 20 seconds, the display will restore to the initial screen.
2.5.2 Pre-alarm, Early Warning and Monitor signaling
Signaling is the same for these three event types, however, “Monitor” signals are not associated with
zones.
Fire alarm Z02
<Zone Descr. 02>
TOT. 01 ON 1 Z
Fire alarm Z02
<Zone Descr. 02>
Alarm Z29
TOT. 02 ON 2 Z
Fire alarm Z02
<Zone Descr. 02>
Alarm Z29
TOT. 03 ON 2 Z
Fire alarm Z29
<Zone Descr. 29>
<Point Descr. 123>
TOT. 03 ON 2 Z

User Manual
10 Using the Control Panel
Example of first pre-alarm event: a detector belonging to zone 02 goes into alarm
status.
1st line: progressive number of the pre-alarm event and total
number of pre-alarm events
2nd line: number of the point in pre-alarm status
3rd line: description of the point in pre-alarm status
4th line: description of the zone in pre-alarm status
Example of successive pre-alarm event:
The total number of pre-alarm events will increase but the display will still show the details of the first
pre-alarm event.
1st line: progressive number of the pre-alarm event and total
number of pre-alarm events
2nd line: unchanged
3rd line: unchanged
4th line: unchanged
To view the pre-alarm events:
Press <DOWN> for the successive pre-alarm event. Press <UP> for the previous pre-alarm event.
1st line: progressive number of the pre-alarm event and total
number of pre-alarm events
2nd line: number of the point in pre-alarm status
3rd line: description of the point in pre-alarm status
4th line: description of the zone in pre-alarm status
2.5.3 Fault signaling
Fault signaling can be generated by loop points (if duly programmed) or the Dialler outputs, Alarm
NAC, Fault NAC or 24V loads.
Example of first fault: fault on NAC output.
1st line: progressive number of the fault event and total number
of fault events
2nd line: fault type
3rd line: -
4th line: output description
Example of a successive fault:
The total number of faults will increase but the display will still show the details of the first fault event.
1st line: progressive number of the fault event and total number
of fault events
2nd line: unchanged
3rd line: -
4th line: unchanged
To view the fault events:
Press <DOWN> for the successive fault event. Press <UP> for the previous fault event.
Pre-Alarm 01/01
Point 05
<Point Descr. 005>
<Zone Descr. 02>
Pre-Alarm 01/02
Point 05
<Point Descr. 005>
<Zone Descr. 02>
Pre-Alarm 02/02
Point 70
<Point Descr. 070>
<Zone Descr. 20>
Fault 01/01
I/O short
NAC output
Fault 01/02
I/O short
NAC output

User Manual
Using the Control Panel
1st line: progressive number of the fault event and total number
of fault events
2nd line: fault type
3rd line: number of the point that signaled the fault
4th line: description of the point
2.5.4 Bypassed and Test Signaling
Bypassed status can be signaled by loop points, zones or outputs. Test status can be signaled by
points and zones only.
Example of first bypassed zone event: zone 12 bypassed.
1st line: number of the first bypassed zone and total number of
bypassed zones
2nd line: -
3rd line: -
4th line: description of the bypassed zone
Example of a successive bypassed zone:
The total number of bypassed zones will increase but the display will still show the details of the first
bypassed zone event.
1st line: number of the first bypassed zone and total number of
bypassed zones
2nd line: -
3rd line: -
4th line: unchanged
To view all bypassed zones:
Press <DOWN> for the successive bypassed zone. Press <UP> for the previous bypassed zone.
1st line: number of the first bypassed zone and total number of
bypassed zones
2nd line: address of the bypassed point
3rd line: description of the bypassed point
4th line: -
2.6 Logged Events
Press <key>, Log, <OK>: all the recorded events will be shown in chronological order (maximum
100 events).
1st line: progressive number of the last event
2nd line: zone description
3rd line: point description
4th line: date and time
Press <UP> or <DOWN> to scroll the log.
Test LEDs from Panel
Press <key>, Test LED, <OK>: all the panel LEDs will go ON briefly.
Fault 02/02
Missing
Point 126
<Point Descr. 126>
Disable 01/01
<Zone Descr. 12>
Disable 01/02
<Zone Descr. 20>
Disable 02/02
POINT 123
<Descr. POINT 123>
100 Fire alarm
<Point Descr. nnn>
<Zone Descr. nn>
29/03/07 08:00

DCMUINE0SLIGHT-R1.0.0-20070218
Copyright
The information contained in this
document is the sole property of Inim
Electronics s.r.l. No part may be copied
without written authorization from Inim
Electronics s.r.l.
All rights reserved
INIM Electronics s.r.l.
Via Ischia Prima, 34
63013 Grottammare, AP - Italy
Tel. [phone]
Fax. [phone]
email: [e-mail]
www.inim.biz
