Bosch AMAX panel 2100 User manual

AMAX panel
AMAX panel 2100 | AMAX panel 3000 |
AMAX panel 3000 BE | AMAX panel 4000
en User Manual

Table of contents
1Safety 5
2Short information 6
2.1 Introduction 6
2.2 Keypads 6
2.3 Keypad Indicators 8
2.4 Quick Keypad Operations Instructions 10
2.5 User Menu 15
3Arming and Disarming the System 16
3.1 Arming the System 16
3.1.1 Arming in AWAY Mode 16
3.1.2 Arming in STAY Mode 18
3.1.3 Forced Arming 19
3.2 Disarming the System 21
3.2.1 Disarming with a Keypad 21
3.2.2 Disarming with a Master Keypad 21
3.2.3 Disarming with Key Switch 21
3.2.4 Disarming with RADION RF Keyfob 21
4Changing the Menu Language 23
5System Test 24
5.1 Siren Test 24
5.2 Communication Test 24
5.3 Walk Test Mode 24
6Bypassing 26
6.1 Bypassing/Unbypassing Zones 26
6.1.1 How to Bypass/Unbypass a Zone via Text Keypad 26
6.1.2 How to Bypass/Unbypass a Zone via LED/LCD Keypad 26
6.2 Bypassing Faults or Tamper Conditions 27
7Schedules 28
8Macros 29
8.1 Recording Macros 29
8.2 Playing Macros 31
AMAX panel Table of Contents | en 3
Bosch Sicherheitsysteme GmbH 2015.05 | 04 | F.01U.295.569

9Codes 32
9.1 Add/Change User Codes 32
9.2 Change Individual Code 34
10 Keypad Alarm Operation Commands 35
10.1 Keypad Panic Alarm 35
10.2 Keypad Fire Alarm 35
10.3 Keypad Medical Alarm 35
11 Domestic Dialing 36
11.1 Domestic Dialing Alarm 36
11.2 Confirming the Domestic Call 36
12 Event Log Recall Mode 37
12.1 How to Select All Event Log Recall Mode 37
12.2 How to Select EN Event Log Recall Mode 37
12.3 How to Select Dialer Event Log Recall Mode 37
13 Faults and Tamper Conditions 38
13.1 System Fault or Tamper Analysis Mode via Text Keypad 38
13.2 System Fault or Tamper Analysis Mode via LED/LCD
Keypad
38
14 Resetting the Control Panel 44
15 Troubleshooting 45
4en | Table of Contents AMAX panel
2015.05 | 04 | F.01U.295.569 Bosch Sicherheitsysteme GmbH

Safety
Danger!
Electricity
Injuries due to electricity are possible if the system is not
operated correctly or if the system is opened or modified.
– Never open or modify the system.
–Please contact your installer if you want to get your system
modified.
!
Caution!
Sensitive components
Damage of sensitive components is possible if the system is not
handled carefully or if the system is opened or modified.
– Always handle the system carefully.
–Never open or modify the system.
– Please contact your installer if you want to get your system
modified.
1
AMAX panel Safety | en 5
Bosch Sicherheitsysteme GmbH 2015.05 | 04 | F.01U.295.569

Short information
Introduction
This manual contains information on how to operate the system
easily and quickly. It describes the main steps required for
operation of the AMAX panel 2100/3000/4000 together with a
text and/or a LED/LCD keypad described in Keypads, page 6.
It is possible to add an optional text keypad as a master keypad.
Detailed information about the installation of this and other
modules and devices, advanced settings and programming can
be found in the installation manual. Information on the main
steps required for basic system installation and setup can be
found in the quick start manual.
Keypads
The following text keypad can be used for operating AMAX panel
2100/3000/4000.
IUI-AMAX4-TEXT
The following LED/LCD keypads can be used for operating AMAX
panel 2100/3000/4000.
2
2.1
2.2
6en | Short information AMAX panel
2015.05 | 04 | F.01U.295.569 Bosch Sicherheitsysteme GmbH

IUI-AMAX3-LED8 IUI-AMAX3-LED16
IUI-AMAX-LED8 IUI-AMAX-LCD8
Notice!
Only a text keypad can be used as a master keypad.
AMAX panel Short information | en 7
Bosch Sicherheitsysteme GmbH 2015.05 | 04 | F.01U.295.569

Keypad Indicators
The following table shows an overview and a description of the
keypad indicator icons.
Keypad
Indicator
Icons
Status Definition
1 2 3 ….
ZONE (1-8)
on Zone is triggered.
off Zone is normal.
Fast flash (0.25
seconds lights on/0.25
seconds lights off)
Zone was alarmed or is
in alarm status.
Slow flash (1 second
lights on/1 second
lights off)
Zone is manually
bypassed or interior
Zone is in STAY arm
mode.
AWAY
on System is armed in
AWAY mode.
off System not armed in
AWAY mode.
Slow flash (1 second
lights on/1 second
lights off)
Exit time.
Fast flash (0.25
seconds lights on/0.25
seconds lights off)
Programming mode or
code function mode.
STAY indicator flashes
simultaneously.
on System is armed in
STAY mode.
2.3
8en | Short information AMAX panel
2015.05 | 04 | F.01U.295.569 Bosch Sicherheitsysteme GmbH

STAY off System not armed in
STAY mode.
Slow flash (1 second
lights on/1 second
lights off)
Exit time.
Fast flash (0.25
seconds lights on/0.25
seconds lights off)
Programming mode or
code function mode.
AWAY indicator flashes
simultaneously. When
bypass function is
performed, only the
STAY indicator flashes.
MAINS
on AC main power is
normal.
Slow flash (1 second
lights on/1 second
lights off)
AC main power supply
failed.
FAULTS
on System fault or Tamper
condition is present.
off System is in normal
status.
Flashes System fault or tamper
condition must be
acknowledged.
on System is disarmed.
All icons Flashing No communication to
the keypad.
AMAX panel Short information | en 9
Bosch Sicherheitsysteme GmbH 2015.05 | 04 | F.01U.295.569

The following table shows an overview and a description of the
keypad sound icons.
Sound Indicator Definition
Short beep A keypad button has been pressed.
Short beep, followed by a
one-second beep
The requested operation is refused.
Incorrect operation signal.
Two short beeps The system accepted the code. The
system executed the requested
function.
One short beep every
minute
Fault tone, unacknowledged system
failure.
One short beep every two
seconds
Exit time started.
Continued sound – Last 10 seconds on exit time
–Keypad fault or tamper sound
(fault or tamper to be
acknowledged)
– Keypad alarm sound
Continuous 0.5 second
beep, stops for 0.5
seconds
– Entry delay time (until alarm
ends or system is disarmed)
–Exit delay time (stops 10
seconds before exit delay
stops)
Quick Keypad Operations Instructions
The following table shows an overview of the quick keypad
operations and the corresponding user permissions. For
information on changing codes and defining user permission
levels, please refer to Codes, page 32.
2.4
10 en | Short information AMAX panel
2015.05 | 04 | F.01U.295.569 Bosch Sicherheitsysteme GmbH

Function Command
Default User Code =
2580 / 2581
D A B S M
1
M
2
I
N
Arm/Disarm
AWAY Arm [code] + [#] / [#] for 3 sec.
(quick arm)
√√√√√√√
AWAY Arm All
Areas (only on
master keypad)
[code] + [0] [0] + [#] √ √ √ √ √ √ √
Direct AWAY Arm
(only on master
keypad
[code] + [2-digit area no.] +
[#]
√√√
STAY Arm [code] + [*] / [*] for 3 sec.
(quick arm)
√√√√√√√
STAY Arm All
Areas (only on
master keypad)
[code] + [0] [0] + [*] √ √ √ √ √ √ √
Direct STAY Arm
(only on master
keypad
[code] + [2-digit area no.] +
[*]
√√√
Disarm [code] + [#] √ √ √ √ √ √
Disarm One Area
(only on a master
keypad)
[code] + [2-digit area no.] +
[#]
√ √√√√√
Disarm All Areas
(only on master
keypad)
[code] + [#] √ √ √ √ √ √
AMAX panel Short information | en 11
Bosch Sicherheitsysteme GmbH 2015.05 | 04 | F.01U.295.569

Display
Display Info
(Fault/Tamper
Analysis)
[code] + [2] [1] + [#] √ √ √
Bypass
Bypass/Unbypass
Zone
[code] + [3] [1] + [#] + [2-
digit zone no.] + [#]
√√√√√
Bypass Fault/
Tamper
[code] + [3] [4] + [#] √ √ √
Reset
Reset Fault/
Tamper (In some
country versions
only the installer
can reset a
tamper alarm)
[code] + [6] + [#] √ √ √ √
Macros
Record Macro 1 [code] + [8] [1] + [#] +
sequence to be recorded +
[#] for 3 sec.
√ √ √ √
Record Macro 2 [code] + [8] [2] + [#] +
sequence to be recorded +
[#] for 3 sec.
√ √ √ √
Record Macro 3 [code] + [8] [3] + [#] +
sequence to be recorded +
[#] for 3 sec.
√ √ √ √
Play Macro 1 [code] + long press [1] /
[1] for 3 sec. (quick macro)
******√
12 en | Short information AMAX panel
2015.05 | 04 | F.01U.295.569 Bosch Sicherheitsysteme GmbH

Play Macro 2 [code] + long press [2] /
[2] for 3 sec. (quick macro)
******√
Play Macro 3 [code] + long press [3] /
[3] for 3 sec. (quick macro)
******√
Alarm commands
Keypad
Emergency Alarm
long press [1] and [3] or
[*] and [#]
√√
Keypad Fire long press [4] and [6] √ √
Keypad Medical
Alarm
long press [7] and [9] √ √
Other Commands
Switch to Master
Keypad
[code] + [0] [0] [0] + [#]
(only on text keypad)
√ √ √ √
Switch to Area
01-16
[code] + [0] [2-digit area
no.] + [#] (only on text
keypad)
√ √ √ √
Display all Event
Log
[code] + [2] [2] + [#] (only
on text keypad)
√ √
Display EN Event
Log
[code] + [2] [3] + [#] (only
on text keypad)
√ √
Display Dialer
Event Log
[code] + [2] [4] + [#] (only
on text keypad)
√ √
Siren Test [code] + [4] [1] + [#] √ √ √
Communication
Test
[code] + [4] [2] + [#] √ √ √
Walk Test [code] + [4] [3] + [#] √ √ √
AMAX panel Short information | en 13
Bosch Sicherheitsysteme GmbH 2015.05 | 04 | F.01U.295.569

Daylight Saving
Time (+1h)
[code] + [5] [2] + [#] √ √ √
Daylight Saving
Time (-1h)
[code] + [5] [3] + [#] √ √ √
Add/Change User
Code
[code] + [5] [4] + [#] √ √ √
Change Individual
Code
[code] + [5] [5] + [#] √ √ √
Call Back [code] + [5] [7] + [#] √ √ √
Change Language [code] + [5] [8] + [#] + [2-
digit no. for available
languages] + [#]
01=EN; 02=DE; 03=ES;
04=FR ; 05=PT; 06=PL;
07=NL; 08=SE; 09=TR
√√√
Installer Access [code] + [7] [1] + [#]
(enable)
[code] + [7] [2] + [#]
(disable)
√√
System Reset [code] + [9] [9] [8] [9] +
[#]
√√√
D = Duress User
A = Arming User
B = Basic User
S = Super User
M1 = Master User 1
M2 = Master User 2
IN = Installer
* This function can be enabled/disabled individually for every
user. For further information, please refer to Add/Change User
Codes, page 32.
14 en | Short information AMAX panel
2015.05 | 04 | F.01U.295.569 Bosch Sicherheitsysteme GmbH

User Menu
The following table shows an overview of the user menu.
FAULT/TAMP INQUIRE
[ / ]USER MENU
ARM/DISARM
ARM AWAY
ARM STAY
DISARM
ZN/FLT/TAMP BYPASS
ZONE BYPASS
BYPASS INQUIRE
BYPASS FLT./ TAMP.
INQUIRE
ALL EVENT RECALL
EN EVENT RECALL
DIAL EVENT RECALL
EVENT PRINT
PRINTER ENABLE
RESET
SYSTEM TEST
SIREN TEST
COMMUNICATIN TEST
WALK TEST
RECORD :END # 3s
AREA SWITCH
SYSTEM SETTINGS
DAYL.SAV.TIME +1h
DAYL.SAV.TIME -1h
ADD/CHG USER CODE
CHANGE INDIV CODE
INITIATE CALL BACK
CHANGE LANGUAGE
MACRO START
INPUT MACRO No 1-3
START PLAY
SCHEDULE ENABLE
INSTALLER ACCESS
ENABLE INSTALLER
DISABLE INSTALLER
2.5
AMAX panel Short information | en 15
Bosch Sicherheitsysteme GmbH 2015.05 | 04 | F.01U.295.569

Arming and Disarming the System
Arming the System
Notice!
When the number of incorrect code entries on the keypad
reaches a specified limit (configured by the installer), the
keypad will automatically lock for 180 seconds and an alarm is
reported. If the keypad is idle for one minute, the system will
automatically exit from any operational mode.
Arming in AWAY Mode
The AWAY Mode is used to arm the premises to detect a would-
be intruder, when you leave the premises and require that all
zones are activated in a ready state.
Keypad Arming
There are two methods to arm your system in AWAY mode.
Method 1:
4Enter your code and press [#].
PThe system beeps twice, the AWAY indicator flashes slowly
and exit time starts. After the exit time, the AWAY indicator
is lit.
Method 2 (Quick Arm):
4Press and hold [#] until the system beeps twice.
PThe AWAY indicator flashes slowly and exit time starts.
After the exit time, the AWAY indicator is lit.
Please contact your installer to enable/disable this function.
Master Keypad Arming
With a master keypad, either all areas or a single area can be
armed in AWAY mode.
3
3.1
3.1.1
16 en | Arming and Disarming the System AMAX panel
2015.05 | 04 | F.01U.295.569 Bosch Sicherheitsysteme GmbH

Arming all areas
4Enter your code, press [0] [0] and [#].
PThe system beeps twice, the AWAY indicator flashes slowly
and exit time starts. After the exit time, the AWAY indicator
is lit and all areas are displayed as armed.
Arming a single area (direct AWAY arm)
Arming a single area with a master keypad is only possible for
users with the permission level master 1 or master 2.
4Enter your code, press the 2-digit area number of the area
to be armed and press [#].
PThe AWAY indicator flashes slowly and exit time starts.
After the exit time, the AWAY indicator is lit and the
selected area is displayed as armed.
4Repeat if you want to arm multiple areas.
Please contact your installer to enable/disable this function.
Telephone Remote Arming
Notice!
Telephone remote arming is only possible when the system has
only one assigned area.
Users can use a telephone to arm the system.
1. Dial the control panel number.
The control panel answers the call and issues a long beep.
2. Press [#].
PWhen the panel receives the signal it confirms the arming of
the control panel with a high tone.
Please contact your installer to enable/disable this function.
Key Switch Arming
Users can use a key switch to arm the system.
4Activate the key switch.
PThe AWAY indicator flashes slowly and exit time starts.
After exit time, the AWAY indicator is lit.
AMAX panel Arming and Disarming the System | en 17
Bosch Sicherheitsysteme GmbH 2015.05 | 04 | F.01U.295.569

Please contact your installer to enable/disable this function.
RADION RF Keyfob Arming
Users can use a RADION RF keyfob to arm the system.
4Press the arming button of the RADION RF keyfob.
PThe AWAY indicator flashes slowly and exit time starts.
After exit time, the AWAY indicator is lit.
Please contact your installer to enable/disable this function.
Arming in STAY Mode
The STAY Mode is used to arm the perimeter and unused areas
of the premises to detect a would-be intruder, while at the same
time being able to move freely within an area that is
automatically isolated.
Keypad Arming
There are two methods to arm your system in STAY mode.
Method 1:
4Enter your code and press [*].
PThe system beeps twice, the STAY indicator flashes slowly
and exit time starts. After the exit time, the STAY indicator
is lit.
PThe lights corresponding to all zones programmed as
automatically isolated zones (Interior Instant Zone) begin to
flash and continue until the exit time is finished.
Method 2 (Quick Arm):
4Press and hold [*] until the system beeps twice.
PThe STAY indicator flashes slowly and exit time starts. After
the exit time, the STAY indicator is lit.
Please contact your installer to enable/disable this function.
Master Keypad Arming
With a master keypad, either all areas or a single area can be
armed in AWAY mode.
3.1.2
18 en | Arming and Disarming the System AMAX panel
2015.05 | 04 | F.01U.295.569 Bosch Sicherheitsysteme GmbH

Arming all areas
4Enter your code, press [0] [0] and [*].
PThe system beeps twice, the STAY indicator flashes slowly
and exit time starts. After the exit time, the STAY indicator
is lit and all areas are displayed as armed.
Arming a single area (direct AWAY arm)
Arming a single area with a master keypad is only possible for
users with the permission level master 1 or master 2.
4Enter your code, press the 2-digit area number of the area
to be armed and press [*].
PThe STAY indicator flashes slowly and exit time starts. After
the exit time, the STAY indicator is lit and the selected area
is displayed as armed.
4Repeat if you want to arm multiple areas.
Please contact your installer to enable/disable this function.
Key Switch Arming
Users can use a key switch to arm the system.
4Activate the key switch.
PThe STAY indicator flashes slowly and exit time starts. After
exit time, the STAY indicator is lit.
Please contact your installer to enable/disable this function.
RADION RF Keyfob Arming
Users can use a RADION RF four button keyfob to arm the
system via the third button.
4Press the third button of the RADION RF four button
keyfob.
PThe STAY indicator flashes slowly and exit time starts. After
the exit time, the STAY indicator is lit.
Please contact your installer to enable/disable this function.
Forced Arming
Arming the system when a zone is not sealed is known as forced
arming.
3.1.3
AMAX panel Arming and Disarming the System | en 19
Bosch Sicherheitsysteme GmbH 2015.05 | 04 | F.01U.295.569

If the AWAY indicator is not lit and a long beep sounds when you
attempt to arm the system in AWAY mode, then forced arming is
not permitted. In this case, you have to seal all zones or
manually isolate them before you can arm the system.
Please contact your installer to enable/disable this function.
20 en | Arming and Disarming the System AMAX panel
2015.05 | 04 | F.01U.295.569 Bosch Sicherheitsysteme GmbH
