Welcome to the Lily Electronic Cigarette
Thank you for purchasing this Lily Electronic Cigarette and Welcome to the Future.
The Lily Electronic Cigarette is the result of years of Research and Development in both
technology and design.
First of all, please ensure that your Innokin Lily is a Real Innokin product.
To do this:
1) Find your Lily’s Unique Authorization number which is included on the packaging.
2) Visit the Ocial Innokin website at http://www.Innokin.com.
3) Enter the Authentication number in the Authentication eld.
4) Verify your Lily is a Real Innokin.
If you have any questions or suggestions we invite you to please write to us at [email protected].
We will be happy to hear from you.
Prepare yourself for the Beautiful Intelligence of the Innokin Lily.
1

WARNING:
Please read this secon carefully to ensure you enjoy maximum benefits from your Lily and Vape
with it in the most safe and effecve way possible.
1. The Lily Electronic Cigaree is only intended for use by people of legal smoking age (18+). The Lily
Electronic Cigaree is NOT to be used by non-smokers, children, pregnant or breaseeding women,
people with or at risk of heart disease or people taking medicaon for depression or asthma. The Lily
Electronic Cigaree is neither intended for use nor marketed as a smoking cessaon device.
2. The Lily Vacap cartridges may contain Nicone. Nicone is a poisonous chemical and should never be
ingested or come into contact with the skin or eyes.
Please be very cauous of using and storing the Lily Vacaps.
The Vacaps must be stored out of the reach of children and pets.
All empty Lily Vacaps must also be disposed of properly and out the reach of children and pets.
If a child or pet ingests a Lily Vapecap, or any product which contains Nicone: you must seek
immediate professional medical aenon.
If you are In America:
If ingeson or contact with Nicone does occur, please call the Poison Help Line at 1-800-222-1222,
contact the American Associaon of Poison Control Centers (hp://www.aapcc.org/), or call your
local Emergency Contact Number (911).
3. This Lily electronic cigaree includes small parts such as the mouth piece. Always keep any small
parts out of reach of children and pets to prevent swallowing or other harm.
4. Do not misuse, mishandle or store your Lily Electronic Cigaree improperly. Even though it is made
of stainless steel it may become damaged when dropped or otherwise mishandled.
5. Do not aempt to repair the unit by yourself as damage or personal injury may occur.
6. In order to guarantee the normal funconing of your Lily Electronic Cigaree, and maximize the
pleasure of vaping, we strongly advise that you charge your baery when the power level drops
below 10 percent.
7. In order to prolong the operaon of your Lily Electronic Cigaree, please do not place or store this
Lily Electronic-Cigaree in excessively hot or cold environments.
8. Obey local laws or regulaons regarding Electronic Cigarees when vaping. If you are in an area
where there are any bans or potenal dangers, please do not use your Lily Electronic Cigaree.
32

The Primary Features of the Lily Electronic Cigaree:
9. Your Lily Electronic Cigaree is not waterproof. Please keep it dry at all mes.
10. Keep your Lily Electronic Cigaree away from sources of excessive heat as damage may occur.
11. Please do not drop, throw, or mishandle your Lily Electronic Cigaree as the outer shell or inner
components may become damaged.
12. Innokin is not responsible for baery and charger explosions, or malfuncons, due to the use of a
low-quality charger. Please use the original Lily Electronic Cigaree starter kit charger to charge
your Lily. We recommend you always use a high quality 5V 500mA USB wall charger (CE/UL
Cerfied).
13. The Lily Electronic Cigaree Vacap cartridges are prefilled, single use only and disposable.
Each Vacap cartridge normally holds between 50-60 puffs, though the number of puffs will depend
on each individual user.
14. The Lily Electronic Cigaree cartridges are not designed to be refilled. Do not aempt to refill a
Vacap cartridge aer it has been used.
WARNING: It is very important that all empty Vacap cartridges be disposed of properly and out of
the reach of children and pets.
Baery Level Indicator:
The Lily Electronic Cigaree baery capacity is displayed via green, yellow and red LED lights.
Green = Fully Charged
Yellow = Half Power.
Red = Low Power. Please Charge.
Large baery capacity:
The Lily Electronic Cigaree has a built-in 350 mAh polymer Li-Ion rechargeable baery.
ON/OFF baery switch:
Please press the power buon“ ”three mes in rapid succession to turn on the Lily Electronic
Cigaree. Once the Lily is On please hold down the power buon to acvate the atomizer and vape.
When the Lily is not in use please press the power buon “ ” three mes in succession to turn off the
Lily Electronic Cigaree. Always power off the Lily Electronic Cigaree when it is not going to be used,
or when it is going to be stored in a pocket, bag or purse.
54

enter standby mode. The final color of the LED will indicate the current power level.
When the Lily Electronic Cigaree has been powered on, hold the buon down to acvate the unit.
Low Voltage Warning
The Red LED will keep blinking for eight seconds when baery capacity is lower than 3.3V and the Lily
Electronic Cigaree will automacally power off.
Baery Capacity Display
The main LED light will display green to indicate full baery charge, yellow to indicate half capacity and
red to indicate immediate charging is required.
OPERATION GUIDE
SAFETY:
10 second cutoff:
If the acvaon buon is held for 10 seconds or longer, the Lily Electronic Cigaree will stop firing unl
the buon is released and pressed again.
Short Circuit/Atomizer Protecon:
Short Circuit/Atomizer Protecon protects the Lily Electronic Cigaree against shorted atomizers, and
will stop the unit from funconing in unsafe condions.
Over-Discharge Protecon:
The Lily Electronic Cigaree monitors the baery voltage and will automacally power off when the
baery is discharged.
To POWER ON the Lily:
Pressing the power buon “ ” three mes in rapid succession will power on the Lily Electronic
Cigaree. The main LED light will blink from red to yellow to green, aer which the Lily Electronic
76

To POWER OFF the Lily:
Press the “ ” buon three mes in succession to power off your Lily Electronic Cigaree.
Short Circuit
The Red LED light will stay lit for five seconds if a load short circuit is detected, aer which no vapor will
be produced. Please check the device carefully to determine the cause of the short circuit.
Lily Electronic Cigaree Atomizer & Vacap Cartridges (Vacap Cartridge System) V.C.S.
The internal components of the Lily combine an atomizer (the heang element), a Vacap juice cartridge
and an internal wicking system. The clear cartridge allows for the remaining juice level to be clearly
seen. Each Vacap cartridge is inially empty and is disposable aer use. When using your Lily Electronic
Cigaree for the first me always use a new empty Vacap cartridge.
Vacap Cartridge
Your Lily Electronic Cigaree includes four packaged atomizers with four empty Vacap cartridges. To fill the
Vacap with your favorite ejuice:
1) Detach the Vacap from the atomizer.
2) Open the Vacap by holding the top and boom and pulling firmly to separate the two parts.
3) Fill the boom secon of the Vacap with your favorite ejuice*. Do not overfill.
If the e-juice comes into contact with skin please wash immediately with soap and water. If the e-juice is
ingested or comes into contact with nose or eyes, please seek immediate professional medical aenon.
4) Place the top of the Vacap into the boom of the Vacap and press firmly to close and connect the
two parts. Ensure that the Vacap is firmly sealed before using.
WARNING:
Ejuice may contain Nicone. Nicone is a poisonous chemical and should never be ingested or come into
contact with the skin or eyes. Please be very cauous of using and storing the Lily Vacaps. The Vacaps must
be stored out of the reach of children and pets.
All empty Lily Vacaps must also be disposed of properly and out the reach of children and pets.
If a child or pet ingests a filled Lily Vapecap, or any product which contains Nicone: you must seek
immediate professional medical aenon.
*Ejuice sold separately.
3x
PRESS
98

To Charge The Lily Electronic Cigaree
To Charge the Lily Electronic Cigaree baery, gently screw the baery into the USB Charger and plug
the USB Cable into a USB wall charger or computer. The Lily will begin charging.
To assemble your Lily Electronic Cigaree:
1) Unscrew and remove the Top Secon and
the Mouthpiece.
2) Correctly place the new, filled Vacap cartridge
into the atomizer (see previous secon for Vacap
filling instrucons). Aach the atomizer to the
baery and turn unl it is firmly in place.
Do not over ghten the atomizer or damage may
3) Carefully re-aach the mouth piece to the
baery and turn it unl it is firmly in place.
Please wait 2-3 seconds to allow for the atomizer
wicks to absorb the e-juice from the Vacap.
Congratulaons! Your Lily Electronic Cigaree is
now ready to be vaped and enjoyed.
1110

The main Lily LED power light will blink from red to yellow to green, aer which the Lily Electronic
Cigaree will enter standby mode. The final LED color will indicate the current power level.
The main LED light will display green to indicate a full baery charge, yellow to indicate power is at half
capacity and red to indicate immediate charging is required.
When the Lily Electronic Cigaree is fully charged the LED light will turn green and power off.
Red LED light = baery voltage is lower than 3.6V
Yellow LED light = baery voltage is around 3.6V-3.75V
Green LED light = baery voltage is higher than 3.75V
PLEASE NOTE:
The Red LED will blink for eight seconds when baery capacity is lower than 3.3V and the Lily Electronic
Cigaree will automacally power off.
If a load short circuit is detected the Red LED light will stay lit for five seconds, aer which no vapor will
be produced. If the RED light remains lit for more than five seconds, and your device is within the 3
month warranty period, please contact your official vendor.
1312

Technical Specificaons:
Standby current: 10uA max
Maximum output voltage: 3.5V (unloaded)
Clearomizer Resistance: 1.5 ohm (minimum)
Baery: Built-in 350 mAh polymer Li-Ion rechargeable baery.
Charging: 4.2V 350 mA
Short Circuit Protecon: 0.6 +/-0.2 ohm
WARRANTY INFORMATION
Innokin provides a three month aer sales service warranty to all of our authorized vendors.
Please consult your Authorized Innokin Vendor for more informaon and terms of service.
Innokin’s warranty does not apply to products purchased through third-party vendors.
