INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 1 of 16
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
96-03996-00-01
Revision H
GUIDANCE TO AUTHORIZED SERVICE AND REPAIR CENTERS
This Manual applies to the following Inogen, Inc. products:
•Inogen One G3 Oxygen Concentrator, model # IO-300
•Inogen One AC Power supply, model # BA-301
•Battery, model # BA-300
•Battery, model # BA-316

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 2 of 16
TABLE OF CONTENTS
1. INFORMATION FOR PROVIDERS OF THE INOGEN ONE G3.....................................3
1.1. CAUTION AND WARNING STATEMENTS.............................................................................3
2. SETTING UP A PATIENT ON INOGEN ONE G3...........................................................4
2.1. RECOMMENDATIONS FOR USE.........................................................................................4
2.2. SYSTEM COMPONENTS...................................................................................................4
2.3. USING THE INOGEN ONE G3...........................................................................................4
2.4. SELECTING THE PROPER FLOW SETTING .........................................................................5
3. SERVICING THE INOGEN ONE G3...............................................................................6
3.1. MAINTENANCE BY THE PROVIDER ....................................................................................6
3.2. MAINTENANCE BY THE PATIENT.....................................................................................11
3.3. EXPECTED SERVICE REQUIREMENTS.............................................................................13
4. INOGEN ONE G3 SYSTEM SPECIFICATIONS...........................................................14
5. INOGEN ONE G3 ERROR CODE TABLE ...................................................................15
6. ERROR RECALL..........................................................................................................16
7. CONTACTS FOR MORE INFORMATION....................................................................16

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 3 of 16
1. INFORMATION FOR PROVIDERS OF THE INOGEN ONE G3
Thank you for choosing to provide your patients with the Inogen One G3 oxygen concentrator.
We are pleased to offer you and your patients one solution for your many oxygen needs.
This Technical Manual will familiarize you with provider-specific information regarding the
Inogen One G3 Oxygen Concentrator and its accessories. Before reading this Technical
Manual, please read and review the Inogen One G3 Patient Manual for description and
indications for use of the device.
Be sure to thoroughly read all of the information in this manual in its entirety. If you have any
additional questions, please see the list of contacts at the end of this Technical Manual.
Instructions included in this Technical Manual are intended to help assure that patients are
given proper guidance in the use and function of the Inogen One G3 and its accessories.
Proper care in relaying this information will not only enhance the user’s experience with the
Inogen One G3, but will also protect the patient, prolong the life of the device, and help you
avoid unnecessary service calls and complaints from users.
1.1.Caution and Warning Statements
You will see Warnings and Cautions throughout this Technical Manual. To ensure effective
Oxygen Therapy and proper operation of the Inogen One G3 Oxygen Concentrator, you
must observe them carefully.
WARNING
A WARNING indicates that the personal SAFETY of the Patient may be
involved. Disregarding a WARNING could result in a significant injury. Be
sure that patients understand all WARNING statements.
CAUTION
A CAUTION indicates that a precaution or a service procedure must be
followed. Disregarding a caution could lead to a minor injury or damage to
the equipment. Be sure that patients understand all CAUTION statements.
NOTE
A NOTE indicates specific information to improve ease of use or
maintenance of the equipment.
DESIGN
NOTE
A DESIGN NOTE indicates specific information regarding the design of the
Inogen One G3 and/or accessories. This information is included in this
manual to provide you with a greater working understanding of the device.
This information is not required to operate or maintain the Inogen One G3.
In many cases, warnings and cautions have been included in the Inogen One G3 User
Manual.

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 4 of 16
2. SETTING UP A PATIENT ON INOGEN ONE G3
2.1.Indications for Use
The Inogen One G3 Oxygen Concentrator is used on a prescriptive basis by patients
requiring supplemental oxygen. It supplies a high concentration of oxygen and is used
with a nasal cannula to channel oxygen from the concentrator to the patient. The Inogen
One Oxygen Concentrator may be used in a home, institution, vehicle and various mobile
environments.
NOTE
Availability of an alternate source of oxygen is recommended in case of
power outage. Several certifying bodies for Home Health Care Providers
require that back-up oxygen be available to the patient. Supplemental
oxygen cylinders or extra Inogen One G3 Batteries may satisfy these
requirements.
CAUTION
Oxygen demand of some patients, particularly those with high breathing
rates and high flow settings, may exceed the capabilities of the Inogen One
G3. Inogen suggests that each patient be titrated to assure that the Inogen
One G3 is an appropriate solution for their needs.
2.2.System Components
The following are standard components of the Inogen One system:
oInogen One G3 Oxygen Concentrator
o8 Single Battery, BA-300
oAC to DC Power Supply, BA-301
oDC Power Cord
oCarry Bag
oCannula
Patient Set-Up. To properly set up a patient on the Inogen One G3 System, you may
need to provide:
oPulse Oximeter (for titration, not included)
oExtra cannulas (not included)
2.3.Using the Inogen One G3
To quickly configure the Inogen One G3 for patient use:
1. Slide the battery onto the bottom of the system until the latch clicks into place.
2. Connect AC power cord to the power supply.
3. Connect the power supply to the Inogen One G3.
4. Plug into closest AC outlet
5. Turn on the Inogen One G3 by pressing the on/off button.

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 5 of 16
6. Set the Inogen One G3 to correct flow setting prescribed by the physician or
clinician by pressing the + (increase flow) or – (decrease flow) button.
7. Attach cannula to the metal hose barb located next to the handle of the Inogen One
G3.
For further information regarding the use of the Inogen One G3, please consult the
User Manual.
2.4.Selecting the Proper Flow Setting
2.4.1. Bolus Volumes Specification
All oxygen conserving devices (OCD’s) function differently, and therefore it is prudent
to titrate patients for any new conserving device. Delivery timing, bolus volume, and
oxygen concentration all contribute to a patient’s fraction of inspired oxygen (FiO2),
and therefore to the OCD’s efficacy at maintaining the patient’s blood oxygen
saturation.
As an oxygen concentrator, the Inogen One G3 does not contain a finite stored
volume of oxygen, such as with compressed gas or liquid cryogenic systems. The
Inogen One G3 can provide oxygen to the patient as long as a source of electricity is
available. However, because the oxygen is being produced as it is used, supply of
oxygen is rate-limited. The Inogen One G3 delivers up to 1050 ml/min of 90% oxygen
(earlier models deliver up to 840 ml/min of 90% oxygen).
At each flow setting, the Inogen One generates a specific amount of oxygen (210ml
per setting), and the on-board OCD attempts to deliver all of this product to the
patient. This is equivalent to a conserving ratio of 4.76 at all flow settings and
breathing rates. Slower breathing patients will receive larger boluses, and faster
breathing patients will receive smaller boluses.
DESIGN
NOTE
This method of bolus volume determination is similar to what is
experienced by a patient using a continuous flow concentrator – actual
alveolar oxygen inspiration is more closely linked to flow setting than to
breathing rate.
In general, the Inogen One G3 delivers 14ml per bolus per flow setting at 15 breaths
per minute (210ml/min per flow setting). The following table summarizes the bolus
volumes delivered by the Inogen One OCD at 20C and Sea Level:
Flow
setting
Flow Rate
(ml +/- 10%)
180 min nominal max min nominal max min nominal max
1.0 210 18.9 21.0 23.1 9.5 10.5 13.6 7.6 8.4 9.2
2.0 420 37.8 42.0 46.2 18.9 21.0 27.2 15.1 16.8 18.5
3.0 630 56.7 63.0 69.3 28.4 31.5 40.8 22.7 25.2 27.7
4.0 840 75.6 84.0 92.4 37.8 42.0 54.4 30.2 33.6 37.0
5.0 1050 94.5 105.0 115.5 47.3 52.5 67.9 37.8 42.0 46.2
10 BPM
(+/- 3ml or +/- 10%)
20 BPM
(+/- 3ml or +/- 10%)
25 BPM
(+/- 3ml or +/- 10%)

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 6 of 16
DESIGN
NOTE
Bolus Volume is tuned to provide the correct bolus volume when
delivered through a nasal cannula such as the Salter Labs 1600Q. If
bolus volumes are measured without a cannula or with a different type
of nasal cannula, bolus volumes will vary from values stated in the table
above.
2.4.2. Trigger sensitivity
The conserver will trigger when the negative pressure at the internal sensor reaches -
0.12 cm H20 (+/- 20%). This low trigger sensitivity allows for breath detection of very
shallow breathing, but may also result in the occasional trigger due to motion of the
cannula or motion of the concentrator. The trigger sensitivity may vary
2.4.3. Flow Setting Selection Relative to Physician Prescription
Inogen has labeled each of the four settings to provide a guideline for matching the
setting of the device to the continuous flow prescription issued by the physician.
Actual correlation is dependent upon the patient’s breathing rates, inspiratory tidal
volume, and other physiologic factors. Inogen suggests that each patient be titrated
(a) while sedentary, (b) while active or ambulatory.
2.4.4. Use with the Inogen Satellite Conserver
The Inogen One G3 is not compatible with the Inogen One Satellite Conserver
3. SERVICING THE INOGEN ONE G3
3.1. Maintenance by the Provider
3.1.1. Authorized Repair Centers
The Inogen One G3 is only intended to be repaired by authorized repair centers. If a
repair is required, please contact Inogen to locate your nearest authorized repair
center. If you would like to become an authorized repair center, please contact
Inogen for access to certification training, service instructions, component part lists
and the necessary repair equipment.
3.1.2. Cleaning and Processing for Reuse
Reprocessing between patient use is required. Refer to the following guidance on
the process to clean and disinfect for reuse.
The following supplies are recommended:
oNitrile Gloves or equivalent
oSafety Glasses
oDisinfecting wipes or Spray designed to kill bacteria and viruses
oCompressed Air (30 psi / 207 kPa, for blowing off parts)
oParticulate Respirator (N95 rated)

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 7 of 16
The following safety precautions should be followed when cleaning and processing a
concentrator for reuse:
1. The cleaning process should be performed in a well-ventilated area.
2. Wear nitrile gloves, safety glasses, and a particulate respirator when
cleaning and disinfecting the concentrator.
3. Avoid touching your face during and after cleaning the concentrator to
prevent transfer of contaminants.
4. Immediately after cleaning remove gloves and wash hands.
The following steps should be performed to clean and disinfect the concentrator:
1. Put on personal protective equipment (PPE).
2. Disinfect by wiping down exterior surfaces with disinfecting wipes or spray.
Avoid getting moisture in or around the battery connectors, power jack, or
vents. Follow manufacturer’s instructions for application and surface dwell
times.
NOTE
The use of Nocolyse (OxyPharm) surface disinfectant system
has been approved for use in Europe. Not approved in United
States.
3. Cleaning. If visibly soiled, clean exterior surfaces using a soft cloth
dampened with a mild liquid detergent (such as Dawn™ in US) and water.
Then gently wipe dry. Avoid getting moisture in or around the battery
connectors, power jack, or vents. If items have scuff marks or other such
surface discoloration, use multi-surface sponge cleaner may be used.
4. Hard-Surfaces: (concentrator shell, batteries, power supplies, carts, pulse
oximeter, etc.): Disinfect and clean entire outer surface as necessary per
above.
5. Cords: Uncoil or untie cord(s). Disinfect entire length of cord(s) and
connectors at each end. Clean as necessary per above.
6. Disposables: If the disposable item has been opened or is dirty it is to be
discarded; otherwise, it does not need to be disinfected. Clean as
necessary per above.
7. Carry Bags: Disinfect entire outer and inner surfaces of carry bag. If the
carry bag is dirty and/or emits excessive odor, it is to be discarded. Clean
as necessary per above.
8. Literature: Literature does not need to be disinfected; if dirty, discard.
9. Packaging Materials: Packaging materials do not need to be disinfected; if
dirty, discard.
10.Once cleaned and disinfected, remove Particle Filters and blow off
accessible internal areas with compressed air to remove any visible debris.
11.Blow off Particle Filters with compressed air to remove any visible debris.

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 8 of 16
12.Disinfect any accessible area behind the Particle Filters with disinfecting
towels. Avoid getting moisture on the electronics (USB port and
motherboard). Replace the Particle Filters as necessary.
13.Disinfect batteries and power supplies by wiping down the exterior of them
with disinfecting towels or spray.
14.Remove and replace Output Filter per section 3.1.6 below.
15.Unit is now ready for reuse.
16.Remove PPE and wash hands with soap and water for a minimum of 20
seconds.
3.1.3. Checking Life Clock, Serial #, and SW version
To check usage, press and hold the Alarm Bell Button for 5 seconds. The
concentrator’s display will show the hour meter, the unit’s serial number, and the
software version installed on the device.
NOTE
Do not disassemble the Inogen One G3 or any of the accessories or
attempt any maintenance other than tasks described in this Technical
Manual unless you have completed a training course through Inogen.
Disassembly of the Inogen One G3 or any of the accessories without
proper training certification will void the product warranties. Contact
Inogen for information about receiving proper training and certification
for service of the Inogen One G3 and accessories.
3.1.4. Suggested Materials for Regular Maintenance
To perform regular field maintenance (by a technician) on the Inogen One G3
System, you may need:
oReplacement cannulas (RP-128)
oReplacement intake screens (RP-300 and RP-301)
oReplacement Inogen One G3 Batteries (BA-300 or BA-316)
oCannula barb removal tool (Spanner Wrench, RP-102)
oReplacement product filters (RP-101)
oUSB storage drive for data log transfers (such as PNY PN# P-FD2GBATT2-
SF)
oExternal Oxygen Analyzer (such as Salter Labs PrO2 Check)
NOTE
During a normal field maintenance visit, the technician may elect to turn
off the concentrator for approximately 30 minutes. If the patient requires
oxygen during this period, Inogen recommends making arrangements
to bring an extra oxygen supply (such as a supplemental Inogen One
G3 Concentrator).
3.1.5. System Inspection
At the start of any maintenance visit:

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 9 of 16
1. Be sure to ask the patient if they have experienced any difficulties in operating
the equipment.
2. Be sure to ask the patient if they have observed any malfunctions or changes
in characteristics of the equipment.
3. Visually inspect the device, batteries, and accessories for cracks or other
damage.
4. Feel the sides of the device for vibration and listen for unusual noises, rattles,
or other signs that the device requires service.
CAUTION
Discovery of cracks or other types of external damage may be
indicative of other internal damage that may not be visible. If such
external damage is discovered, be certain to inquire as to how it
occurred, and whether any changes in the device have been noticeable
since its occurrence. If you have any concern over the safety of the
device, arrange for equipment servicing.
3.1.6. Product Filter
This filter is intended to protect the user from small particles in the product gas flow.
The Inogen One G3 includes a product filter, conveniently located behind the
removable cannula nozzle fitting. Inogen suggests that this filter be replaced between
patients.
To replace the Product Filter:
1. Use the Cannula Barb Tool (available from Inogen as RP-102) to access the
product filter. The tool has two prongs which mate with two indentations
located on the surface of the metal cannula barb fitting on the Inogen One
G2.
2. Carefully remove the cannula fitting by unscrewing it in the counter-
clockwise direction.
3. The filter, a hard plastic disk with a silicone gasket on its outer edge, will be
visible in the recess once the hose barb is removed.
4. Remove the filter, and inspect the recess to make sure it is free of debris.
5. Install a new replacement filter.
6. Carefully screw the cannula barb fitting back into the recess (clockwise) until
it bottoms out on the filter gasket. Take care to squarely screw the nozzle
fitting into the threads, and not to over tighten.
WARNING
Failure to inspect and replace the product filter may result in the filter
becoming clogged or obstructed over time, and in reduced delivery of
oxygen to the patient.
3.1.7. Oxygen Purity Check
The oxygen concentration can be checked using the Salter Labs PrO2 Check
ultrasonic oxygen analyzer. The concentrator should be run for 10 minutes before
measuring the oxygen concentration. If the concentrator has not been used for more
than 2 weeks, the concentrator should be run for a minimum of 30 minutes to allow for
adjustments to the operating parameters prior to measuring the oxygen concentration.

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 10 of 16
3.1.8. Data Logging
Operating data from your Inogen One G3 concentrator are periodically recorded to
flash memory located within the device. Data is stored for a period of approximately
6-12 months; new data replaces the oldest data as it is collected.
Additionally, the device records errors and system information at the time of the error
which is useful in diagnostics.
3.1.8.1. The following information is a list of recorded parameters that can
be used to evaluate the device and its usage:
•Real Time Clock
•Life Clock
•Flow Setting
•Breaths per Minute
•Low, Medium, and High Priority Errors
•Ambient Pressure
•System Temperature
•Battery Status
•Charging Status
3.1.9. Data Download
To download data from the Inogen One G3, you will need a USB mass storage device.
If one of the following drives cannot be obtained, the drive must be less than 2GB in
capacity and have a native file format of FAT32. The capacity of the drive and the file
system alone do not ensure compatibility with the Inogen One G3.
Compatible USB drives include:
•PNY Attache 2GB PN: P-FD2GBATT2-SF
•SanDisk Cruzer Micro 2GB PN:SDCZ6-2048RB
•Kingston Data Traveler G3 2GB PN:DTIG3/2GBZ
•Kingston DataTraveler 102 2GB PN:DT102/2GB
•Kingston DataTraveler DT101 2GB PN: DT101G2/2GB
•Dane-Elec DNL 2GB PN:DNLDAZMP02GCAW
•Transcend JetFlash V30 2GB PN:TS2GJFV30
•Patriot Signature 2GB PN: PSF2GUSB
To collect data:
a) With the Inogen One G3 off, insert the USB mass storage device into the USB
port behind the blue rubber cover
b) Plug in external power to the concentrator
c) Press the “alarm bell” and the “light” buttons for 5 seconds

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 11 of 16
d) The administrative mode menu will show normal. Press the “+” or “-“ buttons
until the LCD reads “Data Log”
e) Press the “alarm bell” button twice and the LCD will read “Transferring”
f) When the data is transferred, the LCD will read “Success”
g) If the LCD screen reads “Failure” try a different type of USB mass storage device
3.2.Maintenance by the Patient
3.2.1. Cannula Replacement
The nasal cannula should be replaced on a regular basis. A single lumen cannula of
four to 25 feet in length must be used. Inogen has certified its performance data with
the Salter Laboratories 1600Q cannula.
CAUTION
Do not use total cannula tubing length exceeding 25 feet with the
Inogen One G3 unless proper saturation has been verified by a
clinician.
3.2.2. Intake Filter Cleaning
At the front of the Inogen One G3, ambient air passes through two gross particle
screens that removes dust fragments. This particle screen must be cleaned on a
weekly basis to ensure adequate air flow through the device. If the particle screen is
not cleaned frequently, the life expectancy of the concentrator will be shortened due to
higher internal operating temperatures.
Particle screens should be cleaned using a mild detergent (e.g., dishwashing solution,
such as DawnTM) and water solution; be sure the filter is rinsed in water and allowed
to air dry before reuse. Additional replacement filters may be obtained from Inogen
(RP-300 or RP-301). There are other types of filters inside the Inogen One G3 that
provide additional filtration. Maintenance of these filters is not required under normal
operating conditions.
3.2.3. Surface Cleaning
The outside case should be cleaned using a cloth dampened with a solution of mild
detergent (e.g., dishwashing detergent, such as DawnTM) and water. Avoid getting
water in or around the battery connectors, power jack, or vents.
3.2.4. Battery Care and Maintenance
The Inogen One G3 Lithium Ion Battery requires special care to ensure proper
performance and long life. Use only Inogen One G3 Batteries with the Inogen One G3
Oxygen Concentrator.

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 12 of 16
DESIGN
NOTE
The Inogen One G3 Oxygen Concentrator adjusts its oxygen
production rate to match the oxygen demand specified by the user
flow setting. When the device is used at lower settings, its battery
life is extended. Additionally, at lower flow settings, the concentrator
does not generate as much heat and noise, draw as much electric
current from external power supplies, and many system components
do not wear as quickly.
Initial Battery State
The Inogen One G3 batteries are shipped 40% to 100% charged.
The battery can be used immediately; however, we recommend the battery be
charged upon receipt to ensure adequate run time.
Normal Charging
The battery is operating properly when a battery icon is displayed on the LCD
screen.
The Inogen One G3 batteries do not have a “memory” like older NiCad battery
packs. The Inogen One G3 batteries can be partially charged and discharged
without damaging the battery packs.
Effect of Temperature on Battery Performance
The Inogen One G3 battery powers the Inogen One G3 Oxygen Concentrator
from 2 to 4.5 hours using the standard 8 cell pack (BA-300) under most
environmental conditions. To maintain maximum run-time of the battery, users
should avoid running in temperatures less than 40oF (4oC) or higher than 95oF
(35oC) for extended periods of time.
The number of cycles that the battery will last is highly dependent upon the
temperature at which the battery is charged. Inogen recommends that batteries
not be charged at room temperatures exceeding 75oF (24oC).
DESIGN
NOTE
The BA-300 and BA-316 will typically achieve 500
charge/discharge cycles while retaining 80% of their original
capacity if proper battery care is taken.
Battery Time Remaining Clock
The Inogen One G3 continuously displays battery time remaining. It may be
necessary to inform the user that this displayed time is only an estimate, and
the actual time remaining may vary from this value.
To avoid running out of battery power unexpectedly, users should regularly
monitor the displayed battery time remaining and/or carry a back-up power
supply (extra charged battery or AC Power Supply).

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 13 of 16
Storage
Instruct patients to remove the battery from the Inogen One G3 when it is not in
use to avoid inadvertent discharge. Leaving a battery attached to an idle Inogen
One G3 for prolonged periods will result in battery damage that will severely
shorten the expected life of the battery.
DESIGN
NOTE
When the concentrator is off but the battery installed, the battery
will continue to provide a small amount of power to the
concentrator’s microprocessor. This power draw will empty a full
battery in approximately 2-3 weeks.
CAUTION
Leaving a Battery in the Inogen One G3 while the device is
unused will irreversibly damage the battery. After such storage,
the battery may not be able to recharge or its life cycle and/or
capacity will be greatly diminished. A full battery can be
damaged in as little as 20 days if left in the concentrator while
not plugged in.
Instruct users to avoid storing the Inogen One G3 battery in extreme
temperatures, below -4oF (-20oC) or above 140oF (60oC), for any amount of
time. They should avoid leaving batteries in automobiles, where these
temperatures can be regularly exceeded. Storage of the Inogen One G3 battery
in a cool, dry location will help to maximize the longevity of the battery.
3.3.Expected Service Requirements
The following table is provided as an estimate only and assumes typical
environmental conditions for temperature, humidity, and air pollution. Any smoking
around the device will severely shorten its life expectancy.Please refer to product
warranty coverage terms.
Service Item
Estimated Service Requirement Frequency
Battery
500 full charge/discharge cycles (to approximately 80% capacity)
Compressor
Function of flow setting and time
20,000 run hours @ flow setting 4
25,000 run hours @ flow setting 2
Oxygen Sensor
No Service Requirement
Molecular
Sieve
18 to 36 months depending on usage
Valves
25,000 run hours
Intake Filter
20,000 run hours (without smoke or other abnormal contaminants)
Cooling Fan
25,000 run hours

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 14 of 16
4. INOGEN ONE G3 SYSTEM SPECIFICATIONS
INOGEN ONE G3 CONCENTRATOR
Dimensions:
Length
Width
Height
Cm
In
Cm
In
Cm
In
No
battery
22.2
8.75
7.6
3.0
18.4
7.25
8 cell
battery
22.2
8.75
7.6
3.0
21.0
8.25
16 cell
battery
22.2
8.75
7.6
3.0
23.5
9.25
Weight:
4.8 pounds (2.19Kg.) (includes 8 cell battery)
Noise:
<42 dB (G3) or 39 db (G3HF) on flow setting 2
Warm-Up Time:
Approximately 2 minutes
Oxygen
Concentration:
90 + 6/-3%
Flow Control
Settings:
1,2,3,4,and 5 (G3HF only)
Power:
AC Power Supply
Input:100 to 240 VAC, 50 to 60 Hz, 1.0A to 0.5A
Output 19 VDC, 85 W
DC Input: 13.5 to 19 VDC, 10A
Rechargeable Battery: Voltage12.0 to 16.8 VDC,
Battery Duration:
Up to 4.7 hours with 8 cell battery
Up to 10 hours with 16 cell battery
Battery Charging
Time:
Up to 5 hours for 8 cell battery
Up to 8 hours for 16 cell battery
Environmental
Ranges Intended for
Use:
Temperature: 40 - 104oF (4 - 40oC)
Humidity: 0% to 95%, non-condensing
Classifications
Mode of Operation:
Continuous Duty
Type of Protection Against Electrical
Shock:
Class II
Degree of Protection Against Electrical
Shock:
Type BF
Not intended for cardiac application
Degree of Protection Against Ingress of
Water:
Concentrator: IP 20
w/carry bag: IP 22
Degree of Safety for Application in
Presence of Anesthetic Gases:
Not suitable for such applications

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 15 of 16
5. INOGEN ONE G3 ERROR CODE TABLE
Error Code
Number
Explanation
Possible Causes &
Troubleshooting Instructions
001
Low voltage on power supply
Replace the power supply or
remove the battery to see if the
concentrator was running on
battery power
004
Pressure Error
The concentrator was shut down
due to a pressure error. Check that
the sieve beds are installed
properly.
016
System electric current out of
specifications
There may be a fault with the
motor. If the error is persistent,
return the concentrator for service
128
Signal or reading out of spec.
Applies to signals from user
interface and other internal
connections.
A sensor has given an out of range
reading and might need to be
serviced if the error persists after
restarting the concentrator.
System Hot
System Cold
Temperature out of
specifications
Remove the concentrator from the
carry bag and restart the
concentrator after 10 minutes to
cool down. If the error persists, the
fan may have failed.
If the System Cold message
appears, allow the concentrator to
warm up for 15 minutes in a room
temperature environment and then
restart the concentrator.
Battery Hot
Warning
Battery Hot
Battery over temperature during
discharge
The concentrator might need to be
moved to a cooler location with
improved ventilation
Oxygen Low
The Oxygen purity is < 82% for
30 minutes
The sieve beds may require
servicing
Oxygen Error
The Oxygen purity is < 50% for
10 minutes
The concentrator has a
malfunction such as a leak or a
failed valve
Sensor Fail
The oxygen sensor is returning
false readings
If the problem persists, return the
concentrator for service
Battery Error/
Check Battery
The system is not properly
communicating with the battery
Remove and reinsert the battery to
clear the error. If the error persists,
replace the battery
Service
Needed/
Service Soon
The compressor has reached
maximum speed
The compressor is at its end of life
or there is a leak in the
concentrator
External Power
Low
The input voltage is less than
17V
Remove power to the concentrator
and remove and reinsert the
battery.

CONFIDENTIAL and
PROPRIETARY 96-03996-00-01 rev H DCR-20-328
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL Page 16 of 16
Try another external power source
such as DC power
O2 Delivery
Error
A Breath is detected but oxygen
is not being delivered
Check for kinked tubing and listen
for proper exhaust noises. If
problem persists, return the
concentrator for service
O2 Service
Soon/
Replace
Columns
The adsorbent beds are near
the end of their useful life
Within approximately 30 days,
replace the adsorbent beds
6. ERROR RECALL
To access the last recorded error code hold the (+) button for 5 seconds while
the concentrator is in standby mode.
No breath detect and low battery warnings are not recalled.
To display the elapsed time since the error occurred press and release the (+)
button.
To clear the error record, hold the Plus and Minus buttons simultaneously
while the error record is displayed.
Note: The availability of these functions is dependent on the software version
of the concentrator
7. CONTACTS FOR MORE INFORMATION
Inogen, Inc.
301 Cormar Drive
Goleta, CA 93117
Toll Free: 1-866-765-2800
http://www.inogenone.com
http://www.inogen.net
