Inogen One G3 User manual

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 1 of 20
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
96-03996-00-01
Revision F

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 2 of 20
This Manual applies to the following Inogen, Inc. products:
Inogen One G3 Oxygen Concentrator, model # IO-300
Inogen One AC Power supply, model # BA-301
Battery, model # BA-300
Battery, model # BA-316

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 3 of 20
TABLE OF CONTENTS
1. INFORMATION FOR PROVIDERS OF THE INOGEN ONE G3.................................................................................4
1.1. CAUTION AND WARNING STATEMENTS.........................................................................................................................4
2. SETTING UP A PATIENT ON INOGEN ONE G3 .......................................................................................................6
2.1. RECOMMENDATIONS FOR USE......................................................................................................................................6
2.2. SYSTEM COMPONENTS................................................................................................................................................6
2.3. USING THE INOGENONE G3........................................................................................................................................ 7
2.4. SELECTING THE PROPER FLOW SETTING..........................................................................................................................7
3. SERVICING THE INOGEN ONE G3 ...........................................................................................................................9
3.1. MAINTENANCE BY THE PROVIDER..................................................................................................................................9
3.2. MAINTENANCE BY THE PATIENT.................................................................................................................................. 13
3.3. EXPECTEDSERVICE REQUIREMENTS............................................................................................................................. 16
4. INOGEN ONE G3 SYSTEM SPECIFICATIONS.........................................................................................................16
5. INOGEN ONE G3 ERROR CODE TABLE..................................................................................................................18
6. ERROR RECALL..........................................................................................................................................................19
7. CONTACTS FOR MORE INFORMATION ................................................................................................................ 19

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 4 of 20
1. INFORMATION FOR PROVIDERS OF THE INOGEN ONE G3
Thank you for choosing to provide your patients with the Inogen One G3 oxygen concentrator.
We are pleased tooffer you and your patients one solution for your many oxygen needs.
This Technical Manual will familiarize you with provider-specific information regarding the
InogenOne G3OxygenConcentratorand itsaccessories. Beforereading thisTechnical Manual,
please read and review the Inogen One G3 Patient Manual for description and indications for
use of the device.
Be sure to thoroughlyread all ofthe information in this manual in itsentirety. If you have any
additional questions, please see the listof contacts at the end of this Technical Manual.
Instructions included in this Technical Manual are intended to help assure that patients are
given proper guidance in the use and function of the InogenOne G3 and its accessories. Proper
One G3, but will also protect the patient, prolong the life of the device, and help you avoid
unnecessary service calls and complaints from users.
1.1. Caution and Warning Statements
You will see Warnings and Cautions throughout this Technical Manual. To ensure effective
OxygenTherapyandproperoperationoftheInogenOne G3OxygenConcentrator,youmust
observe them carefully.
WARNING
A WARNING indicates that the personal SAFETY of the Patient may be involved.
Disregarding a WARNING could result in a significant injury. Be sure that patients
understand all WARNING statements.
CAUTION
A CAUTION indicates thata precaution or a service procedure must befollowed.
Disregarding a cautioncould leadto a minor injury or damage to the equipment.
Be sure that patients understand all CAUTIONstatements.

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 5 of 20
NOTE
A NOTE indicates specific information to improve ease of use or maintenance of
the equipment.
DESIGN
NOTE
A DESIGN NOTE indicates specific information regarding the design of the Inogen
One G3 and/or accessories. This information is included in this manual to provide
you with a greater working understanding of the device. This information is not
required to operate or maintain the Inogen One G3.
In many cases, warnings and cautions have been included in the Inogen One G3 User
Manual.

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 6 of 20
2. SETTING UP A PATIENT ON INOGEN ONE G3
2.1. Indications for Use
TheInogenOneG3OxygenConcentratorisusedonaprescriptivebasisbypatientsrequiring
supplemental oxygen. It supplies a high concentration of oxygen and is used with a nasal
cannula to channel oxygen from the concentrator to the patient. The Inogen One Oxygen
Concentrator may be used in ahome, institution,vehicle and variousmobile environments.
NOTE
Availability of an alternate source of oxygen is recommended in case of power
outage. Several certifying bodies for HomeHealth Care Providers require that
back-up oxygen be available to the patient. Supplemental oxygen cylindersor
extra Inogen One G3 Batteries may satisfy these requirements.
CAUTION
Oxygen demand of some patients, particularly those with high breathing rates
and high flow settings, may exceed the capabilities of the Inogen One G3. Inogen
suggests that each patient be titrated to assure that theInogen One G3 is an
appropriate solution for their needs.
2.2. System Components
The following are standard components of the Inogen One system:
oInogen One G3 Oxygen Concentrator
o8 Single Battery, BA-300
oAC to DC Power Supply, BA-301
oDC Power Cord
oCarry Bag
oCannula
Patient Set-Up. To properly set up a patient on the Inogen One G3 System, you may need
to provide:
oPulse Oximeter (for titration, not included)
oExtra cannulas (not included)

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 7 of 20
2.3. Using the Inogen One G3
To quickly configure the InogenOne G3 for patient use:
1. Slide the battery onto the bottom of the system until the latch clicks into place.
2. Connect AC power cord to the power supply.
3. Connect the power supply to the Inogen One G3.
4. Plug into closest AC outlet
5. Turn on the Inogen One G3 by pressing the on/off button.
6. Set the Inogen One G3 to correct flow setting prescribed by the physician or clinician
by pressing the + (increase flow) or (decrease flow) button.
7. Attach cannula to the metal hose barb located next to the handle of the Inogen One
G3.
For further information regarding the use of the Inogen One G3, please consult the User
Manual.
2.4. Selecting the Proper Flow Setting
2.4.1. Bolus Volumes Specification
All oxygen conserving devices function differently, and therefore it is prudent
to titrate patients for any new conserving device. Delivery timing, bolus volume, and
FiO2),
saturation.
As an oxygen concentrator, the Inogen One G3 does not contain a finite storedvolume
of oxygen, such as withcompressed gas or liquid cryogenic systems. The Inogen One
G3 can provide oxygen to the patient as long as a source of electricityis available.
However, because the oxygen is being produced as it is used, supply of oxygen is rate-
limited . The Inogen One G3 delivers up to 1050ml/min of 90% oxygen (earlier models
deliver up to 840 ml/min of 90% oxygen).
At each flow setting, the Inogen One generates a specific amount ofoxygen (210ml per
setting), and the on-board OCD attempts to deliver all of this product to the patient.
This is equivalent to a conserving ratio of 4.76 at all flow settings and breathing rates.

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 8 of 20
Slower breathing patients will receive larger boluses, and faster breathing patients will
receive smaller boluses.
DESIGN
NOTE
This method of bolus volume determination is similar to what is experienced by a
patient using a continuous flow concentrator actual alveolar oxygen inspiration
is more closely linked to flow setting than to breathing rate.
In general, the Inogen One G3 delivers 14ml per bolus per flow setting at 15 breaths per
minute (210ml/min per flow setting). The following table summarizes the bolus
volumes delivered by the Inogen One OCD at 20Cand Sea Level:
Flow
setting
Flow Rate
(ml +/- 10%)
180 min nominal max min nominal max min nominal max
1.0 210 18.9 21.0 23.1 9.5 10.5 13.6 7.6 8.4 9.2
2.0 420 37.8 42.0 46.2 18.9 21.0 27.2 15.1 16.8 18.5
3.0 630 56.7 63.0 69.3 28.4 31.5 40.8 22.7 25.2 27.7
4.0 840 75.6 84.0 92.4 37.8 42.0 54.4 30.2 33.6 37.0
5.0 1050 94.5 105.0 115.5 47.3 52.5 67.9 37.8 42.0 46.2
10 BPM
(+/- 3ml or +/- 10%)
20 BPM
(+/- 3ml or +/- 10%)
25 BPM
(+/- 3ml or +/- 10%)
DESIGN
NOTE
Bolus Volume is tunedto provide the correct bolus volume when delivered
through a nasal cannula such as the Salter Labs 1600Q. If bolus volumes are
measured without a cannula or with a different type of nasal cannula, bolus
volumes will vary fromvalues stated in the table above.
2.4.2. Trigger sensitivity
The conserver will trigger when the negative pressure at the internalsensor reaches -
0.12 cm H20 (+/- 20%). This low trigger sensitivity allows for breath detection ofvery
shallow breathing, but may also result in the occasional trigger due to motion of the
cannula or motion of the concentrator. The trigger sensitivity may vary
2.4.3. Flow Setting Selection Relative to Physician Prescription
Inogen has labeled each of the four settings to provide a guideline for matching the
setting of the device to the continuous flow prescription issued by thephysician.

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 9 of 20
volume, and other physiologic factors. Inogen suggests that each patient be titrated
(a) while sedentary, (b) while activeor ambulatory.
2.4.4. Use with the Inogen Satellite Conserver
The Inogen One G3 is not compatible with the Inogen One Satellite Conserver
3. SERVICING THE INOGEN ONE G3
3.1. Maintenance by the Provider
3.1.1. Authorized Repair Centers
The Inogen One G3 is only intended tobe repaired by authorized repair centers. If a
repair is required, please contact Inogen to locate your nearest authorized repair
center. If you would like to become an authorized repair center, please contact Inogen
for access to certification training, service instructions, component part lists and the
necessary repair equipment.
3.1.2. Checking Life Clock, Serial #, and SW version
To check usage, press and hold the Alarm Bell Button for 5 seconds. The
display will show the hour meter
installed on the device.
NOTE
Do not disassemble the Inogen One G3 or any of the accessories or attempt any
maintenance other than tasks described in this Technical Manual unless you have
completed a training course through Inogen. Disassembly of the Inogen One G3
or any of the accessories without proper training certification will void the product
warranties. Contact Inogen for information about receiving proper training and
certification for service of the Inogen One G3 and accessories.
3.1.3. Suggested Materials for Regular Maintenance
To perform regular field maintenance (by a technician) on the Inogen One G3 System,
you may need:

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 10 of 20
oReplacement cannulas (RP-128)
oReplacement intake screens (RP-300 and RP-301)
oReplacement Inogen One G3 Batteries (BA-300 or BA-316)
oCannula barb removal tool (Spanner Wrench, RP-102)
oReplacement product filters (RP-101)
oUSB storage drive for data log transfers (such as PNY PN# P-FD2GBATT2-SF)
oExternal Oxygen Analyzer (such as Salter Labs PrO2 Check)
NOTE
During a normal field maintenance visit, the technician may elect to turn off the
concentrator for approximately 30minutes. If the patient requires oxygenduring
this period, Inogen recommends making arrangements to bring an extra oxygen
supply (such as a supplemental Inogen One G3 Concentrator).
3.1.4. System Inspection
At the start of any maintenance visit:
1. Be sure to ask the patient if they have experienced any difficulties in operating
the equipment.
2. Be sure to ask the patient if they have observed any malfunctions or changes in
characteristics of the equipment.
3. Visuallyinspectthedevice,batteries,andaccessoriesforcracksorotherdamage.
4. Feel the sides of the device for vibration and listen for unusual noises, rattles, or
other signs that the device requires service.
CAUTION
Discovery of cracks or other typesof external damage may be indicative of other
internal damage that may not be visible. If such external damage is discovered, be
certain to inquire as tohow it occurred, and whether any changes in the device
have been noticeable since its occurrence. If you have any concern over the safety
of the device, arrange for equipment servicing.
3.1.5. Product Filter
This filter is intended to protect the user from small particles in the product gas flow.
The Inogen One G3 includes a product filter, conveniently located behind the removable
cannula nozzle fitting. Inogen suggests that this filter be replaced between patients.

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 11 of 20
To replace the Product Filter:
1. Use the Cannula Barb Tool (available from Inogen as RP-102) to access the
product filter. The tool has two prongs which mate with two indentations
located on the surface of the metal cannula barb fitting on the Inogen One G2.
2. Carefullyremove thecannula fittingbyunscrewingitinthecounter-clockwise
direction.
3. The filter, a hard plastic disk with a silicone gasket on its outer edge, will be
visible in the recess once thehose barb is removed.
4. Remove the filter, and inspect the recess to make sure it is free of debris.
5. Install a new replacement filter.
6. Carefullyscrewthe cannula barb fitting back into therecess (clockwise) until it
bottomsoutonthefiltergasket. Takecaretosquarelyscrewthenozzlefitting
into the threads, and not to over tighten.
WARNING
Failure to inspect and replace the product filter may result in the filter becoming
clogged or obstructed over time, and in reduced delivery of oxygen to the patient.
3.1.6. Oxygen Purity Check
The oxygen concentration can be checked using the Salter Labs PrO2 Check ultrasonic
oxygen analyzer. The concentrator should be run for 10 minutes before measuring the
oxygen concentration. If the concentrator has not been used for morethan 2 weeks, the
concentrator should be run for a minimum of 30 minutes to allow for adjustments to
the operating parameters prior to measuring the oxygen concentration.
3.1.7. Data Logging
Operating data from your Inogen One G3 concentrator are periodicallyrecorded to flash
memory located within the device. Data is stored for a period of approximately 6-12
months; new data replaces the oldest data as it is collected.
Additionally, the device records errors and system information at the time of the error
which is useful in diagnostics.

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 12 of 20
3.1.7.1. The following information is a list of recorded parameters that can be
used to evaluate the device and its usage:
Real Time Clock
Life Clock
Flow Setting
Breaths per Minute
Low, Medium, and High Priority Errors
Ambient Pressure
System Temperature
Battery Status
Charging Status
3.1.8. Data Download
To download data from the Inogen One G3, you will need a USB mass storage device. If
one of the following drives cannot be obtained, the drive must be less than 2GB in
capacity and have a native file format of FAT32. The capacity of the drive and the file
system alone do not ensure compatibility withthe Inogen One G3.
Compatible USB drives include:
PNY Attache 2GB PN: P-FD2GBATT2-SF
SanDisk Cruzer Micro 2GB PN:SDCZ6-2048RB
Kingston Data Traveler G3 2GB PN:DTIG3/2GBZ
Kingston DataTraveler 102 2GB PN:DT102/2GB
Kingston DataTraveler DT101 2GB PN: DT101G2/2GB
Dane-Elec DNL 2GB PN:DNLDAZMP02GCAW
Transcend JetFlash V30 2GB PN:TS2GJFV30
Patriot Signature 2GB PN: PSF2GUSB
To collect data:
a) Withthe Inogen OneG3off, insertthe USB massstoragedevice into the USBport
behind the blue rubber cover
b) Plug in external power to the concentrator

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 13 of 20
c) Press bell
d) The admin -
e) bell
f)
g) type of USB mass storage device
3.2. Maintenance by the Patient
3.2.1. Cannula Replacement
The nasal cannula should be replaced on a regular basis. A single lumen cannula of four
to 25 feet in length must be used. Inogen has certified its performance data with the
Salter Laboratories 1600Q cannula.
CAUTION
Do not use total cannula tubing length exceeding 25 feet with the Inogen One G3
unless proper saturation has been verified by a clinician.
3.2.2. Intake Filter Cleaning
At thefrontofthe InogenOne G3, ambientairpasses through twogross particlescreens
that removes dust fragments. This particle screen must be cleaned on a weekly basis to
ensure adequate air flow through the device. If the particle screen is not cleaned
frequently, the life expectancy of the concentrator will be shortened due to higher
internal operating temperatures.
Particle screens should be cleaned using a mild detergent (e.g., dishwashing solution,
such as DawnTM) and water solution; be sure the filter is rinsed in water and allowed to
air dry before reuse. Additional replacement filters may be obtained from Inogen (RP-
300 or RP-301). There are other types of filters inside the Inogen One G3 that provide
additionalfiltration.Maintenanceofthesefiltersis notrequiredundernormaloperating
conditions.

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 14 of 20
3.2.3. Surface Cleaning
The outside case should be cleaned using a cloth dampened with a solution of mild
detergent(e.g.,dishwashingdetergent,suchasDawnTM) andwater. Avoidgettingwater
in or around the battery connectors, power jack, or vents.
3.2.4. Battery Care and Maintenance
The Inogen One G3 Lithium Ion Battery requires special care to ensure proper
performance and long life. Use only Inogen One G3 Batteries with the Inogen One G3
Oxygen Concentrator.
DESIGN
NOTE
The Inogen One G3 Oxygen Concentrator adjusts its oxygen production rate to
match the oxygen demand specified by the user flow setting. When the device
is used at lower settings, its battery life is extended. Additionally, at lower
flow settings, the concentrator does not generate as much heat and noise,
draw as much electric current from external power supplies, and many system
components do not wear as quickly.
Initial Battery State
The Inogen One G3 batteries are shipped 40% to 100% charged.
The battery can be used immediately; however, we recommend the battery be
charged upon receipt to ensure adequate run time.
Normal Charging
The battery is operating properly when a battery icon is displayed on the LCD
screen.
The Inogen One G3
packs. The Inogen One G3 batteries can be partially charged and discharged
without damaging the battery packs.
Effect of Temperature on Battery Performance
TheInogenOne G3batterypowerstheInogenOne G3OxygenConcentratorfrom

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 15 of 20
2 to 4.5 hours using the standard 8 cell pack (BA-300) under most environmental
conditions. To maintain maximum run-time of the battery, users should avoid
running in temperatures less than 40oF (4oC) or higher than 95oF (35oC) for
extended periods of time.
The number of cycles that the battery will last is highly dependent upon the
temperature at which the battery is charged. Inogen recommends that batteries
not be charged at roomtemperatures exceeding 75oF (24oC).
DESIGN
NOTE
The BA-300 and BA-316 will typically achieve 500 charge/discharge cycles while
retaining 80% of their original capacity if proper battery care is taken.
Battery Time Remaining Clock
The Inogen One G3 continuously displays battery time remaining. It may be
necessary to inform the user that this displayed time is onlyanestimate , and the
actual time remaining may vary from this value.
To avoid running out of battery power unexpectedly, users should regularly
monitor the displayed battery time remaining and/or carry a back-up power
supply (extra charged battery or AC Power Supply).
Storage
Instruct patients to remove the battery from the Inogen One G3 when it is not in
use to avoid inadvertent discharge. Leaving a battery attached to an idle Inogen
One G3 for prolonged periods will result in battery damage that will severely
shorten the expected life of the battery.
DESIGN
NOTE
When the concentrator is off but the battery installed, the battery will continue to
power draw will empty a full battery in approximately 2-3 weeks.
CAUTION
Leaving a Battery in theInogen One G3 while the device is unused will irreversibly
damage the battery. After such storage, the battery may not beable to recharge

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 16 of 20
or its life cycle and/or capacity will be greatly diminished. A full battery can be
damaged in as little as 20 days if left in the concentrator whilenot plugged in.
Instruct users to avoid storing the Inogen One G3 battery in extreme
temperatures, below -4oF (-20oC) or above 140oF (60oC), for any amount of time.
They should avoid leaving batteries in automobiles, where these temperatures
can be regularly exceeded. Storage of the Inogen One G3 battery in a cool, dry
location will help to maximize the longevity of the battery.
3.3. Expected Service Requirements
The following table is provided as anestimate only and assumes typicalenvironmental
conditions for temperature, humidity, and air pollution. Any smokingaround the
device will severely shorten its life expectancy. Please refer to product warranty
coverage terms.
Service Item
Estimated Service Requirement Frequency
Battery
500 full charge/discharge cycles (to approximately 80% capacity)
Compressor
Function of flow setting and time
20,000 run hours @ flow setting 4
25,000 run hours @ flow setting 2
Oxygen Sensor
No Service Requirement
Molecular Sieve
18 to 36 months depending on usage
Valves
25,000 run hours
Intake Filter
20,000 run hours (without smoke or other abnormal contaminants)
Cooling Fan
25,000 run hours
4. INOGEN ONE G3 SYSTEM SPECIFICATIONS
INOGEN ONE G3 CONCENTRATOR
Dimensions:
Length
Width
Height

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 17 of 20
Cm
In
Cm
In
Cm
In
No battery
22.2
8.75
7.6
3.0
18.4
7.25
8 cell
battery
22.2
8.75
7.6
3.0
21.0
8.25
16 cell
battery
22.2
8.75
7.6
3.0
23.5
9.25
Weight:
4.8 pounds (includes 8 cell battery)
Noise:
<42 dB (G3) or 39 db (G3HF) on flow setting 2
Warm-Up Time:
Approximately 2 minutes
Oxygen
Concentration:
90 + 6/-3%
Flow Control Settings:
1,2,3,4,and 5 (G3HF only)
Power:
AC Power Supply
Input:100 to 240 VAC, 50 to 60 Hz, 1.0A to 0.5A
Output 19 VDC, 85 W
DC Input: 13.5 to 19 VDC, 10A
Rechargeable Battery: Voltage12.0 to 16.8 VDC,
Battery Duration:
Approximately 2 to 4 hours for 8 cell battery
Approximately 4 to 8 hours for 16 cell battery
Battery Charging
Time:
Approximately 2.25 to 4.25 hours for 8 cell battery
Approximately 4.25 to 8.00hours for 16 cell battery
Environmental Ranges
Intended for Use:
Temperature: 40 - 104oF (4 - 40oC)
Humidity: 0% to 95%, non-condensing
Classifications
Mode of Operation:
Continuous Duty
Type of Protection Against Electrical Shock:
Class II
Degree of Protection Against Electrical
Shock:
Type BF
Not intended for cardiac application
Degree of Protection Against Ingress of
Water:
Concentrator: IP 20
w/carry bag: IP 22

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 18 of 20
Degree of Safety for Application in
Presence of Anesthetic Gases:
Not suitable for such applications
5. INOGEN ONE G3 ERROR CODE TABLE
Error Code
Number
Explanation
Possible Causes & Troubleshooting
Instructions
001
Low voltage on power supply
Replace the power supply or remove
the battery to see if the concentrator
was running on battery power
004
Pressure Error
The concentrator was shut down due
to a pressure error. Check that the
sieve beds are installed properly.
016
System electric current out of
specifications
There may be a fault with the motor.
If the error is persistent, return the
concentrator for service
128
Signal or reading out of spec.
Applies to signals fromuser
interface and other internal
connections.
A sensor has given an out of range
reading and might need to be serviced
if the error persists after restarting
the concentrator.
System Hot
System Cold
Temperature out of
specifications
Remove the concentrator from the
carry bag and restart theconcentrator
after 10 minutes to cool down. If the
error persists, the fan may have failed.
If the System Cold message appears,
allow the concentrator to warm up for
15 minutes in a room temperature
environment and then restart the
concentrator.
Battery Hot
Warning
Battery Hot
Battery over temperature during
discharge
The concentrator might need to be
moved to a cooler location with
improved ventilation
Oxygen Low
The Oxygen purity is <82% for 30
minutes
The sieve beds may require servicing

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 19 of 20
Oxygen Error
The Oxygen purity is <50% for 10
minutes
The concentrator has a malfunction
such as a leak or afailed valve
Sensor Fail
The oxygen sensor is returning
false readings
If the problem persists, return the
concentrator for service
Battery Error/
Check Battery
The system is not properly
communicating with the battery
Remove and reinsert the battery to
clear the error. If the error persists,
replace the battery
Service
Needed/
Service Soon
The compressor has reached
maximum speed
The compressor is at its end of life or
there is a leak in the concentrator
External Power
Low
The input voltage is less than17V
Remove power to the concentrator
and remove and reinsert the battery.
Try another external power source
such as DC power
O2 Delivery
Error
A Breath is detected but oxygen
is not being delivered
Check for kinked tubing and listen for
proper exhaust noises. If problem
persists, return the concentrator for
service
O2 Service
Soon/
Replace
Columns
The adsorbent beds are near the
end of their useful life
Within approximately 30 days, replace
the adsorbent beds
6. ERROR RECALL
Certain errors can be recalled so that the device displays the last error that occurred. The last error
stored in memory may be accessed by holding the Plus button for 5 seconds while the unit is in
standby mode. All errors will be stored except when the unit is operating in special admin mode,
no breath detect, battery low, and Error 1.
7. CONTACTS FOR MORE INFORMATION
Inogen Website: Patient Issues: http://www.inogenone.com
Corporate: http://www.inogen.net

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 20 of 20
Inogen : 326 Bollay Dr
Goleta, CA 93117
1-866-765-2800
[email protected]
