Inogen TIDAL ASSIST User manual

Nasal Pillow
Interface
Cinch
Left Side
Step
To TAVTM Approved
Gas Source Only
Mode Page 10-13
Pulse
Tidal Assist
Constant
Level
DECREASE
FLOW
INCREASE
FLOW
Page 10-13
Power / Silence Alarm
On / O
Silence Alarm
Page 10-13
Hold 3 seconds
Press briefly to
Quick Setup Guide *
* Reference Instructions For Use for additional information
96-09783-00-01 C, TAV QUICK REFERENCE GUIDE

Nasal Pillow
Interface
Cinch
Left Side
Step
To TAVTM Approved
Gas Source Only
Quick Troubleshooting Guide *
* Reference Instructions For Use for additional information
96-09783-00-01 C, TAV QUICK REFERENCE GUIDE
Note: if alarms cannot be cleared, turn o device and
call customer support. Use Bypass Valve if needed.
Alarms
Battery low - replace battery
1. Check tubing for kinks and leaks
2. Check connections
3. Check gas source
4. Check regulator adaptor
5. Turn Device o and then back on
Page 15
1. Check patient
2. Check nasal pillow interface fit
3. Check tubing for kinks and leaks
4. Check all connections
5. Turn Device o and then back on
1. Check Bypass Valve is closed
2. Turn Device o and then back on
Pull
Bypass Valve (2LPM constant)
Page 14
Hold 3 seconds
Power o
