Intel PXA255 User manual

Intel® PXA255 Processor
Electrical, Mechanical, and Thermal Specification
Data Sheet
Product Features
■High Performance Processor
— Intel® XScale™ Microarchitecture
—32 KB Instruction Cache
—32 KB Data Cache
—2 KB “mini” Data Cache
—Extensive Data Buffering
■Intel® Media Processing Technology
—Enhanced 16-bit Multiply
—40-bit Accumulator
■Flexible Clocking
—CPU clock from 100 to 400 MHz
—Flexible memory clock ratios
—Frequency change modes
■Rich Serial Peripheral Set
—AC97 Audio Port
—I2S Audio Port
—USB Client Controller
—High Speed UART
—Second UART with flow control
—UART with hardware flow control
—FIR and SIR infrared comm ports
■Low Power
—Less than 500 mW Typical Internal
Dissipation
—Supply Voltage may be Reduced to
1.00 V
—Low Power/Sleep Modes
■High Performance Memory Controller
—Four Banks of SDRAM - up to 100 MHz
—Five Static Chip Selects
—Support for PCMCIA or Compact Flash
—Companion Chip interface
■Additional Peripherals for system
connectivity
—Multimedia Card Controller (MMC)
—SSP Controller
—Network SSP controller for baseband
—I2C Controller
—Two Pulse Width Modulators (PWMs)
—All peripheral pins double as GPIOs
■Hardware debug features
■Hardware Performance Monitoring features
Order Number: 278805-002
February, 2004

2Data Sheet
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY
ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN
INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS
ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES
RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER
INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving, or life sustaining applications.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for
future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.
The PXA255 processor EMTS Data Sheet may contain design defects or errors known as errata which may cause the product to deviate from
published specifications. Current characterized errata are available on request.
MPEG is an international standard for video compression/decompression promoted by ISO. Implementations of MPEG CODECs, or MPEG enabled
platforms may require licenses from various entities, including Intel Corporation.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained by calling
1-800-548-4725 or by visiting Intel's website at http://www.intel.com.
Copyright © Intel Corporation, 2004
*Other names and brands may be claimed as the property of others.

PXA255 Processor — Electrical, Mechanical, and Thermal Specification
Data Sheet 3
Contents
1.0 About This Document............................................................................................7
2.0 Functional Overview ..............................................................................................7
3.0 Package Information ..............................................................................................8
3.1 Package Introduction.....................................................................................8
3.1.1 Functional Signal Definitions ............................................................8
3.1.1.1 PXA255 Processor Signal Pin Descriptions .....................8
3.2 Package Power Ratings ..............................................................................22
4.0 Electrical Specifications ......................................................................................22
4.1 Absolute Maximum Ratings.........................................................................22
4.2 Power Consumption Specifications.............................................................23
4.3 Operating Conditions...................................................................................25
4.4 Targeted DC Specifications.........................................................................26
4.5 Targeted AC Specifications.........................................................................27
4.6 Oscillator Electrical Specifications...............................................................28
4.6.1 32.768-kHz Oscillator Specifications..............................................28
4.6.2 3.6864 MHz Oscillator Specifications.............................................29
4.7 Reset and Power AC Timing Specifications................................................30
4.7.1 Power-On Timing ...........................................................................30
4.7.2 Hardware Reset Timing..................................................................32
4.7.3 Watchdog Reset Timing .................................................................32
4.7.4 GPIO Reset Timing ........................................................................32
4.7.5 Sleep Mode Timing ........................................................................33
4.8 Memory Bus and PCMCIA AC Specifications .............................................35
4.9 Peripheral Module AC Specifications ..........................................................37
4.9.1 LCD Module AC Timing..................................................................37
4.9.2 SSP Module AC Timing..................................................................37
4.9.3 Boundary Scan Test Signal Timings ..............................................38
4.10 AC Test Conditions .....................................................................................39

PXA255 Processor — Electrical, Mechanical, and Thermal Specification
4Data Sheet
Figures
1 Processor Block Diagram...................................................................................... 8
2 PXA255 processor .............................................................................................. 19
3 Power-On Reset Timing ...................................................................................... 31
4 Hardware Reset Timing ...................................................................................... 32
5 GPIO Reset Timing ............................................................................................. 33
6 Sleep Mode Timing ............................................................................................. 34
7 LCD AC Timing Definitions ................................................................................. 37
8 SSP AC Timing Definitions ................................................................................. 38
9 AC Test Load ...................................................................................................... 39
Tables
1 Related Documentation......................................................................................... 7
2 Processor Pin Types ............................................................................................. 9
3 Pin and Signal Descriptions for the PXA255 Processor........................................ 9
4 Pin Description Notes.......................................................................................... 18
5 PXA255 processor 256-Lead 17x17mm mBGA Pinout — Ballpad No. Order ....20
6θJA and Maximum Power Ratings........................................................................ 22
7 Absolute Maximum Ratings ................................................................................ 23
8 Power Consumption Specifications for PXA255 processor ................................24
9 Voltage, Temperature, and Frequency Electrical Specifications......................... 25
10 Standard Input, Output, and I/O Pin DC Operating Conditions........................... 26
11 Standard Input, Output, I/O Pin DC Operating Conditions for 2.5-V Memory ..... 27
12 Standard Input, Output, and I/O Pin AC Operating Conditions ........................... 28
13 32.768-kHz Oscillator Specifications................................................................... 28
14 3.6864-MHz Oscillator Specifications ................................................................. 29
15 Power-On Timing Specifications ......................................................................... 31
16 Hardware Reset Timing Specifications ............................................................... 32
17 GPIO Reset Timing Specifications...................................................................... 33
18 Sleep Mode Timing Specifications ...................................................................... 34
19 SRAM / ROM / Flash / Synchronous Fast Flash AC Specifications.................... 35
20 Variable Latency I/O Interface AC Specifications ............................................... 35
21 Card Interface (PCMCIA or Compact Flash) AC Specifications ......................... 36
22 Synchronous Memory Interface AC Specifications 1 ..........................................36
23 LCD AC Timing Specifications ............................................................................ 37
24 SSP AC Timing Specifications ............................................................................ 38
25 Boundary Scan Test Signal Timing..................................................................... 38

PXA255 Processor — Electrical, Mechanical, and Thermal Specification
Data Sheet 5
Revision History
Date Revision Description
March 2003 -001 First public release of the EMTS
February 2004 -002 Updated 400 MHz Idle mode power.

PXA255 Processor — Electrical, Mechanical, and Thermal Specification
6Data Sheet

About This Document
Intel® PXA255 Processor Electrical, Mechanical, and Thermal Specification 7
1.0 About This Document
This is the electrical, mechanical, and thermal specification data sheet for the Intel® PXA255
Processor. This data sheet contains a functional overview, mechanical data, package signal
locations, targeted electrical specifications (simulated), and bus functional waveforms. Detailed
functional descriptions other than parametric performance is published in the Intel® PXA255
Processor Developer's Manual. Refer to Table 1, “Related Documentation” for a list of documents
that support the PXA255 processor.
2.0 Functional Overview
The PXA255 processor provides high integration, high performance and low power consumption
for portable handheld and handset devices. These processors incorporate the Intel® XScale™
Microarchitecture based on the ARM* V5TE architecture. Refer to the Intel® XScale™
Microarchitecture for the Intel® PXA250 and PXA210 Applications Processors User’s Manual for
implementation details, extensions, and options implemented by the XScale microarchitecture.
The processor memory interface supports a variety of memory types that allow flexible design
requirements. Hooks for connection to two companion chips permit glueless connection to external
devices. An integrated LCD display controller supports displays and permits 1, 2, and 4-bit
grayscale, and 8- or 16-bit color pixels. A 256-byte palette RAM provides flexible color mapping
capabilities.
A rich set of serial devices as well as general-system resources provide enough compute and
connectivity capability for many applications. For details on the programming model and theory of
operation of each of these units, refer to the Intel® PXA255 Processor Developer's Manual. For the
processor block diagram, refer to Figure 1, “Processor Block Diagram” on page 8.
Table 1. Related Documentation
Document Title Order / Contact
Intel® PXA255 Processor Developer's Manual 278693
Intel® XScaleTM Microarchitecture for the PXA250 and PXA210 Applications
Processors Developer's Manual 278525
Intel® PXA255 Processor Design Guide 278694

Package Information
8Intel® PXA255 Processor Electrical, Mechanical, and Thermal Specification
3.0 Package Information
3.1 Package Introduction
The PXA255 processor is offered in a 256-pin mBGA (refer to Figure 2, “PXA255 processor” on
page 19).
3.1.1 Functional Signal Definitions
3.1.1.1 PXA255 Processor Signal Pin Descriptions
Table 3, “Pin and Signal Descriptions for the PXA255 Processor” on page 9 describes the signal
definitions for the PXA255 processor. Figure 2, “PXA255 processor” on page 19 illustrates the
physical characteristics of the PXA255 processor. Table 5, “PXA255 processor 256-Lead
17x17mm mBGA Pinout — Ballpad No. Order” on page 20 describes the pinout for the PXA255
processor.
Figure 1. Processor Block Diagram
Intelfi XScale
Microarchitecture
Color or
Grayscale
LCD
Controller
RTC
OS Timer
PWM(2)
Int.
Controller
Clocks &
Power Man.
I2S
AC97
UARTs
NSSP
Slow IrDA
SSP
USB
Client
General Purpose I/O
ASIC
Socket
0
Socket
1
3.6864
MHz
Osc
32.768
KHz
Osc
DMA Controller
and Bridge
XCVR
SDRAM/
SMROM
4 banks
ROM/
Flash/
SRAM
4 banks
I2C
Fast IrDA
MMC
Peripheral Bus
System Bus
Memory
Controller
Variable
Latency I/O
Control
PCMCIA
& CF
Control
Dynamic
Memory
Control
Static
Memory
Control

Package Information
Intel® PXA255 Processor Electrical, Mechanical, and Thermal Specification 9
Some of the processor pins can be connected to multiple signals. The GAFRn_m registers
determine the signal connected to the pin. Some signals can go to multiple pins. The signal must be
routed to one pin only by using the GAFRn_m registers. Because this is true, some pins are listed
twice—once in each unit that can use the pin. Not all peripherals can be used simutaneously in one
design because different peripherals share the same pins.
Table 2. Processor Pin Types
Type Function
IC CMOS input
OC CMOS output
OCZ CMOS output, Hi-Z
ICOCZ CMOS bidirectional, Hi-Z
IA Analog Input
OA Analog output
IAOA Analog bidirectional
SUP Supply pin (either VCC or VSS)
Table 3. Pin and Signal Descriptions for the PXA255 Processor (Sheet 1 of 9)
Pin Name Type Signal Descriptions Reset State Sleep State
Memory Controller Pins
MA[25:0] OCZ Memory address bus. (output) Signals the address
requested for memory accesses. Driven Low Driven Low
MD[15:0] ICOCZ Memory data bus. (input/output) Lower 16 bits of the
data bus. Hi-Z Driven Low
MD[31:16] ICOCZ Memory data bus. (input/output) Used for 32-bit
memories. Hi-Z Driven Low
nOE OCZ Memory output enable. (output) Connect to the output
enables of memory devices to control data bus drivers. Driven High Note [4]
nWE OCZ Memory write enable. (output) Connect to the write
enables of memory devices. Driven High Note [4]
nSDCS[3:0] OCZ
SDRAM CS for banks 3 through 0. (output) Connect to
the chip select (CS) pins for SDRAM. For the PXA255
processor processor nSDCS0 can be Hi-Z, nSDCS1-3
cannot.
Driven High Note [5]
DQM[3:0] OCZ
SDRAM DQM for data bytes 3 through 0. (output)
Connect to the data output mask enables (DQM) for
SDRAM.
Driven Low Driven Low
nSDRAS OCZ SDRAM RAS. (output) Connect to the row address
strobe (RAS) pins for all banks of SDRAM. Driven High Driven High
nSDCAS OCZ SDRAM CAS. (output) Connect to the column address
strobe (CAS) pins for all banks of SDRAM. Driven High Driven High
SDCKE[0] OC
Synchronous Static Memory clock enable. (output)
Connect to the CKE pins of SMROM. The memory
controller provides control register bits for de-assertion.
Driven Low Driven Low

Package Information
10 Intel® PXA255 Processor Electrical, Mechanical, and Thermal Specification
SDCKE[1] OC
SDRAM and/or Synchronous Static Memory clock
enable. (output) Connect to the clock enable pins of
SDRAM. It is deasserted during sleep. SDCKE[1] is
always de-asserted upon reset. The memory controller
provides control register bits for de-assertion.
Driven low Driven low
SDCLK[0] OC
Synchronous Static Memory clock. (output) Connect to
the clock (CLK) pins of SMROM. It is driven by either the
internal memory controller clock, or the internal memory
controller clock divided by 2. At reset, all clock pins are
free running at the divide-by-2 clock speed and may be
turned off via free-running control register bits in the
memory controller. The memory controller also provides
control register bits for clock division and deassertion of
each SDCLK pin. SDCLK[0] control register assertion bit
defaults to on if the boot-time static memory bank 0 is
configured for SMROM.
SDCLK[1] OCZ SDRAM Clocks (output) Connect SDCLK[1] and
SDCLK[2] to the clock pins of SDRAM in bank pairs 0/1
and 2/3, respectively. They are driven by either the
internal memory controller clock, or the internal memory
controller clock divided by 2. At reset, all clock pins are
free running at the divide-by-2 clock speed and may be
turned off via free-running control register bits in the
memory controller. The memory controller also provides
control register bits for clock division and de-assertion of
each SDCLK pin. SDCLK[2:1] control register assertion
bits are always de-asserted upon reset.
Driven Low Driven Low
SDCLK[2] OC Driven Low Driven Low
nCS[5]/
GPIO[33] ICOCZ
Static chip selects. (output) Chip selects to static
memory devices such as ROM and Flash. Individually
programmable in the memory configuration registers.
nCS[5:0] can be used with variable latency I/O devices.
Pulled High -
Note[1] Note [4]
nCS[4]/
GPIO[80] ICOCZ
nCS[3]/
GPIO[79] ICOCZ
nCS[2]/
GPIO[78] ICOCZ
nCS[1]/
GPIO[15] ICOCZ
nCS[0] ICOCZ Static chip select 0. (output) Chip select for the boot
memory. nCS[0] is a dedicated pin. Driven High Note [4]
RD/nWR OCZ Read/Write for static interface. (output) Signals that the
current transaction is a read or write. Driven Low Holds last state
RDY/
GPIO[18] ICOCZ
Variable latency I/O ready pin. (input) Notifies the
memory controller when an external bus device is ready
to transfer data.
Pulled High -
Note[1] Note [3]
L_DD[8]/
GPIO[66] ICOCZ
LCD display data. (output) Transfers pixel information
from the LCD controller to the external LCD panel.
Memory controller alternate bus master request.
(input) Allows an external device to request the system
bus from the memory controller.
Pulled High -
Note[1] Note [3]
Table 3. Pin and Signal Descriptions for the PXA255 Processor (Sheet 2 of 9)
Pin Name Type Signal Descriptions Reset State Sleep State
