Intel H2000G Series User manual

Table of Contents
Product Features .....................................................................................................................1
Product Feature Overview .................................................................................................................................2
Server Chassis Components .............................................................................................................................2
Drive Bay ....................................................................................................................................................................4
Front Control Panel ..............................................................................................................................................5
Front Bezel ................................................................................................................................................................5
Hot-Swap SAS/SATA Backplane .....................................................................................................................6
3.5" Hot-swap Backplane .........................................................................................................................6
2.5" Hot-swap Backplane .........................................................................................................................8
Dummy Tray Cover ............................................................................................................................................10
Hardware Installations and Upgrades ............................................................................. 11
Before You Begin ................................................................................................................................................11
Tools and Supplies Needed .................................................................................................................11
System Reference ....................................................................................................................................11
Removing and Installing the Front Bezel ..................................................................................................12
Bezel Snap-ons .........................................................................................................................................12
Removing the Front Bezel ....................................................................................................................13
Installing the Front Bezel ......................................................................................................................13
Removing and Installing the Power Distribution Module Cover ....................................................14
Removing the Power Distribution Module Cover .......................................................................14
Installing the Power Distribution Module Cover .........................................................................15
Removing and Installing the Compute Module .....................................................................................16
Installing the Compute Module ..........................................................................................................16
Removing the Compute Module ........................................................................................................17
Removing and Installing the Redundant Power Supply Unit ..........................................................18
Removing the Power Supply Unit .....................................................................................................18

Installing the Power Supply Unit .......................................................................................................18
Installing a Hot-swap Storage Device .........................................................................................................19
3.5” Hard Disk Drive Assembly ...........................................................................................................19
Option to Install a 2.5” Solid State Device into a 3.5” Carrier ...............................................21
2.5” Storage Device (HDD or SSD) Assembly ...............................................................................22
Replacing the 2.5" Backplane Board ...........................................................................................................24
Removing the 2.5" Backplane Board ................................................................................................24
Installing the 2.5" Backplane Board ..................................................................................................25
Replacing the 3.5" Backplane Board ...........................................................................................................27
Removing the 3.5" Backplane Board ................................................................................................27
Installing the 3.5" Backplane Board ..................................................................................................28
Removing and Installing the Power Distribution Module ..................................................................30
Removing the Power Distribution Module ....................................................................................30
Installing the Power Distribution Module ......................................................................................30
Replacing the Front Control Panel Board .................................................................................................31
Removing the Front Control Panel Board ......................................................................................31
Installing the Front Control Panel Board ........................................................................................32

1
1Product Features
This chapter briefly describes the main features. This includes illustrations of
the product, a list of the product features, and diagrams showing the location
of important components and connections.
Figure 1. Product Overview
Figure 2. Product Rear View
AF006406
LOCK
UNLOCK
AF006517
Compute Module 4
Compute Module 2 Power Supply 1
Power Supply 2 Compute Module 3
Compute Module 1

2
Product Feature Overview
The following table summarizes the features of the product.
Table 1. Product Feature Set
Server Chassis Components
This section helps you identify the components of your product. If you are near
the server chassis, you can also use the Quick Reference Label provided on the
chassis cover to assist in identifying the components.
The Server Chassis supports four compute modules in the chassis. The whole
chassis view is as below (with the power distribution module cover removed).
Feature Description
Dimensions H2312XXKR2 •3.42 inches (86.9 mm) high
•17.24 inches (438 mm) wide
•30.35 inches (771 mm) deep
H2216XXKR2 •3.42 inches (86.9 mm) high
•17.24 inches (438 mm) wide
•28.86 inches (733 mm) deep
Package Dimensions 984X578X266 mm
Weight H2312XXKR2 Net weight 21.5kg, package weight 29.5kg
H2216XXKR2Net weight 20.5kg, package weight 28.4kg
Compute Module Support •Intel® Compute Module HNS2600KP Product Family
•Intel® Compute Module HNS2600TP Product Family
System Fans •One internal power supply fan for each installed power supply unit
•Three fans for each compute module
Power Supply Options 1600W AC Common Redundant Power Supply (CRPS), 80 plus Platinum
with PFC, supporting CRPS configuration
Storage Bay Options •12x 3.5-inch SATA/SAS drive bays – H2312XXKR2
•16x 2.5-inch SATA/SAS drive bays – H2216XXKR2

3
Figure 3. Server Chassis Components
Note: The blank compute module bay must be covered by a dummy tray cover. When
removed, keep the dummy tray cover properly for future use.
Note: The compute module bay in the chassis requires either a compute module being
installed and powered up or a dummy tray cover installed to maintain proper
thermal environment for the other running compute modules in the same
chassis. In case of a compute module failure, remove the failed compute module,
and replace with a dummy tray cover until the new compute module is installed.
Label Description
A Front control panels
B Drive bays
C Power distribution module
D Power supply modules
E Hot-swap backplane (attached to the drive cage)
AF006407
LOCK
UNLOCK
B
A
C
D
E

4
Drive Bay
Figure 4. Front View
Figure 5. Front View
Each compute module has a dedicated drive array based on the backplane
controller design. Following are schemes for the drive array corresponding to
the compute module.
Figure 6. Drive Array Scheme
Figure 7. Drive Array Scheme on the
AF006720
NODE 4
NODE 2
NODE 3
NODE 1
AF006721
NODE 4
NODE 2
NODE 3
NODE 1
AF006515
NODE 4
NODE 2
NODE 3
NODE 1
0
0
2 2
1
1
Compute Module 3
Compute Module 1
0
0
2 2
1
1
Compute Module 4
Compute Module 2
AF006516
NODE 4
NODE 2
NODE 3
NODE 1
0 1
23
0 1
2 3
0 1
23
0 1
2 3
Compute Module 1 Compute Module 2
Compute Module 3 Compute Module 4

5
Front Control Panel
The server chassis contains two sets of control panels on the left and right rack
handles. Each control panel contains two sets of control buttons and LEDs for
each compute module. Following is the scheme of the control panel.
Figure 8. Front Control Panel Options
Front Bezel
The front bezel is available as an optional accessory for the server chassis.
Figure 9. Front Bezel
AF006722
NODE 4
NODE 2
NODE 3
NODE 1
Front Controls and LEDs
NODE 3
NODE 1
Power Button with LED
ID Button
with LED
Status LED Network
Link/Activity
LED
AF006671
AF004476

6
Hot-Swap SAS/SATA Backplane
The hot-swap SAS/SATA backplane serves as an interface between the mother
board and the drives. The following diagrams show the location for each
connector found on the backplane.
3.5" Hot-swap Backplane
Figure 10. 3.5" Backplane Components (Front View)
AF006418
C
A B
D
Label Description
A SATA/SAS connectors for node 1
B SATA/SAS connectors for node 2
C SATA/SAS connectors for node 3
D SATA/SAS connectors for node 4

7
Figure 11. 3.5" Backplane Components (Back View)
AF006419
A B C D E F G
HIJL
ON
M
K
Label Description
A 2-blade compute module power connector for node 4
B 2x40 pin bridge board connector for node 4
C 2x9 pin power supply input connector
D 2x9 pin Power supply input connector
E 2x7 pin power control cable connector
F 2-blade compute module power connector for node 3
G 2x40 pin bridge board connector for node 3
H 2x40 pin bridge board connector for node 1
I 20-pin front panel cable connector for node 1 and 3
J 2-blade compute module power connector for node 1
K 2x9 pin power supply input connector
L 2x9 pin power supply input connector
M 2x40 pin bridge board connector for node 2
N 2-blade compute module power connector for node 2
O 20-pin front panel cable connector for node 2 and 4

8
2.5" Hot-swap Backplane
Figure 12. 2.5" Backplane Components (Front View)
C
AF006410
D
A B
Label Description
A SATA/SAS connectors for node 1
B SATA/SAS connectors for node 2
C SATA/SAS connectors for node 3
D SATA/SAS connectors for node 4

9
Figure 13. 2.5" Backplane Components (Back View)
AF006411
A B C D F G
H
I
JKLNO M
E
Label Description
A 2-blade compute module power connector for node 4
B 2x40 pin bridge board connector for node 4
C 2x9 pin power supply input connector
D 2x7 pin power control cable connector
E 2x9 pin power supply input connector
F 2-blade compute module power connector for node 3
G 2x40 pin bridge board connector for node 3
H 2x40 pin bridge board connector for node 1
I 20-pin front panel cable connector for node 1 and 3
J 2-blade compute module power connector for node 1
K 2x9 pin power supply input connector
L 2x9 pin power supply input connector
M 2x40 pin bridge board connector for node 2
N 2-blade compute module power connector for node 2
O 20-pin front panel cable connector for node 2 and 4

10
Dummy Tray Cover
The dummy tray cover is shipped together with the chassis. It must be removed
before installing the compute module, or it must be restored if the compute
module is not to be installed.
Figure 14. Dummy Tray Cover
AF006723

11
2Hardware Installations and
Upgrades
Before You Begin
Before working with your server product, pay close attention to the Safety
Information at the beginning of this manual.
Warning: The transparent plastic protective films on the chassis top surface must be
removed for proper system cooling.
Note: Whenever you service the server chassis, you must first power down the server
and unplug all peripheral devices and the AC power cord.
Tools and Supplies Needed
•Phillips* (cross head) screwdriver (#1 bit and #2 bit)
•Needle nosed pliers
•Anti-static wrist strap and conductive foam pad (recommended)
System Reference
All references to left, right, front, top, and bottom assume that the reader is
facing the front of the chassis as it would be positioned for normal operation.

12
Removing and Installing the Front Bezel
The server chassis supports the installation of an optional front bezel (Intel
product code: A2UBEZEL). The bezel kit includes a plastic lockable front bezel
and multiple bezel snap-ons allowing for OEM differentiation.
Bezel Snap-ons
The bezel kit provides three different bezel snap-ons to allow for OEM
differentiation; two different size badging snap-ons, and one decorative wave
snap-on.
To mount the snap-on to the bezel, insert the snap-on hooks into the bezel and
press to snap it into place.
Figure 15. Installing the Snap-on to the Front Bezel
To remove the snap-on from the bezel, squeeze the hooks at the rear of the
snap-on to release it (see letter A). Then remove the snap-on from the bezel (see
letter B).
Figure 16. Removing the Snap-on from the Front Bezel
AF005159
Badge
AF005160
Badge
A
B

13
Removing the Front Bezel
If your server chassis includes a front bezel, follow these steps to remove it from
the chassis:
1. Unlock the bezel.
2. Pull out the left side of the bezel from the rack handle (see letter A).
3. Rotate the left side of the bezel out away from the chassis to release the
latches on the right side from the rack handle (see letter B).
Figure 17. Removing the Front Bezel
Installing the Front Bezel
Note: Before installing the front bezel, you must install the rack handles.
1. Lock the right side of the bezel to the rack handle (see letter A).
2. Rotate the left side of the bezel towards the chassis and press the left side
of the bezel into the rack handle until it clicks into place (see letter B).
3. Lock the bezel.
Figure 18. Installing the Front Bezel
AF006421
A
B
AF006422
B
A

14
Removing and Installing the Power Distribution
Module Cover
Removing the Power Distribution Module Cover
The server chassis must be operated with the power distribution module cover
in place to ensure proper cooling. You will need to remove the cover to add or
replace the components inside of the chassis. Before removing the cover, power
down the server and unplug all peripheral devices and the power cables.
Note: A non-skid surface or a stop behind the server chassis may be needed to prevent
the server chassis from sliding on your work surface.
1. Remove the screw (see letter A).
2. Lift the cover from the front end to more than 45 degrees (see letter B)
and remove the cover.
Figure 19. Removing the Power Distribution Module Cover
AF006423
LOCK
UNLOCK
A
B

15
Installing the Power Distribution Module Cover
1. Place the cover onto the chassis and slide forward until the front edge of
the cover is pressed up against the back edge of the front drive bay (see
letter A).
2. Rotate the front end of the cover down to position and fix the cover with
the screw (see letter B).
Figure 20. Installing the Power Distribution Module Cover
AF006424
LOCK
UNLOCK
BA

16
Removing and Installing the Compute Module
Each compute module is identical in the chassis. They are designed for either
“cold” or “hot” swappable. The compute module can only be plugged from the
rear chassis.
Installing the Compute Module
1. While pressing the latch, pull out the dummy tray cover.
Figure 21. Removing the Dummy Tray Cover
2. Align and slide the compute module into the chassis.
Note: When the upper compute module is being inserted into the chassis,
make sure its front edge overrides the air duct edge of the lower
compute module.
3. While pressing the latch, push the compute module along the chassis rail
until the latch locks in position.
Figure 22. Installing the Compute Module
AF006703
Latch
AF006426
Latch

17
Removing the Compute Module
1. While pressing the latch, pull out the handle with the compute module.
Figure 23. Removing the Compute Module
2. Restore the dummy tray cover.
Figure 24. Restoring the Dummy Tray Cover
AF006425
Latch
Handle
AF006704

18
Removing and Installing the Redundant Power
Supply Unit
The server chassis is equipped with two redundant power supply units. Each of
them can be hot-swappable.
Caution: Installing two power supply units with different wattage ratings in a server
chassis is not supported. Doing so will not provide power supply redundancy and
will result in multiple errors being logged.
Removing the Power Supply Unit
While pressing the latch, pull out the handle with the power supply unit.
Figure 25. Removing the Power Supply Unit
Installing the Power Supply Unit
1. Align and slide the power supply unit into the power cage.
2. While pressing the latch, push the power supply unit along the power cage
rail until the latch locks in position.
Figure 26. Installing the Power Supply Unit
Handle Latch
AF006675
Handle Latch
AF006674
